Montigo C34-DV Owner's manual

■Check local codes
and read all
instructions prior to
installation.
■Leave this manual
with the owner.
Gas Fireplace
C34-DV
Installation
Operation &
Maintenance
What To Do If You Smell Gas:
 Do not try to light any appliance.
 Do not touch any electrical switch; do not use any phone in your building.
 Immediately call your gas supplier from a neighbor's phone. Follow the gas
supplier's instructions.
 If you cannot reach your gas supplier, call the fire department.
Warning:
Improper installation, adjustment,
alteration, service or maintenance can
cause injury or property damage. efer to
this manual. For assistance or additional
information consult a qualified installer,
service agency or the gas supplier.
For Your Safety:
Do not store or use gasoline
or other flammable vapors
and liquids in the vicinity of
this or any other appliance.
Questions? Email us at [email protected] or visit our website at www.montigo.com.

Page 2
C34-DV Gas Fireplace
Part No. XG0117B
Introduction
Thank You for choosing a Montigo C-Series Fire lace.
About the C34 Fireplace:
The C34-DVincludes a 20,000 BTU dual burner with embers and a
five iece ceramic fibre logset. This model is available in four versions.
nC34DT-To Vent, Millivolt Pilot
nC34DR- Rear Vent, Millivolt Pilot
nC34DT-S- To Vent, Pilotless Ignition (STB)
nC34DR-S-Rear Vent, Pilotless Ignition (STB)
The C34-DV is rated for Natural Gas at 20,000 BTU/H (7.33 Kilowatts)
In ut or Pro ane at 20,000 BTU/H (7.33 Kilowatts) In ut.
How to use this manual:
This manual covers all models and unless otherwise s ecified, the
designation C34-DV refers to all models. Sections which are s ecific to a
articular model are marked with a symbol, lus the
a ro riate model number.
Warranty and Installation Information:
The Montigo warranty will be voided by, and Montigo disclaims any
res onsibility for, the following actions:
Modification of the fire lace and/or com onents including Direct-Vent
assembly or glass doors.
Use of any com onent art not manufactured or a roved by
Montigo in combination with this Montigo fire lace system.
Installation other than as instructed in this manual.
Consult your local Gas Ins ection Branch on installation requirements for
factory-built gas fire laces. Installation & re airs should be done by a
qualified contractor.
InstallationsinCanada must conform to the current CAN/CGAB-
149.1 and .2 Gas Installation Code and local regulations. If the o tional
air-circulating fan kit is installed, it must be electrically grounded in
accordance with CSAC22.1 Canadian Electrical Code Part 1 and/or
Local Codes.
InstallationsintheUSA must conform to local codes, or in the
absence of local codes to the National Fuel Gas Code, ANSIZ223.1-
1988. If the o tional air-circulating fan is installed, it must be grounded in
accordance with local codes or, in the absence of local codes, with the
National Electrical Code, ANSI/NFPA70-1987.
Table Of Contents
Introduction ............................................................................ 2
Installation
Installing the Fire lace Shell ........................................... 3
Installing the Gasline ....................................................... 4
The Remote Switch ........................................................ 4
Direct Vent Installation .................................................... 4
General Requirements ....................................... 4
Terminations ...................................................... 4
To Vent Models with horizontal venting ............. 6
To Vent Models with vertical venting ................. 8
Rear Vent Models .............................................. 9
Construction around the fire lace
Facing ............................................................. 11
Mantels and Surrounds.................................... 11
Wiring ....................................................................... 11
Removing and Installing the Door ................................. 12
Installing the Logset ...................................................... 13
Installing the Horizontal Trim ......................................... 13
Operation ........................................................................ 14 - 16
Maintenance ................................................................... 16 - 17
Warranty ................................................................................ 18
Appendix
A. Termination Locations .............................................. 19
B. Wiring for Pilotless Ignition (STB) Equi ed Units ...... 20
CAUTIONS
Due to its high o erating tem eratures, the a liance should
be located out of traffic & away from furniture and dra eries.
Children and adults should be alerted to the hazards of
the high surface tem erature, which could cause burns
or clothing ignition.
Young children should be carefully su ervised when
they are in the same room as the a liance.
Clothing or other flammable materials should not be
laced on or near the a liance.

Page 3
C34-DV Gas Fireplace
Part No. XG0117B
Installing The Fireplace Shell
The fire lace may be installed in any location that is free of air
conditioning ducts, electrical wiring and lumbing. Safety, as well as
efficiency of o eration, must be considered when selecting the fire lace
location. Try to select a location that does not interfere with room traffic,
has adequate ventilation, and offers an accessible athway for Direct
Vent installation. Refer to age 4 - VentInstallationfor more information.
The fire lace dimensions are shown below:
Installation
When installing a shelf over the to of the fire lace, the following
guidelines must be adhered to: For Rear Vent models (C34-DR), the
minimum clearance from the to of the fire lace to a shelf is 7". For To
Vent models (C34-DT), the minimum clearance is 15". (Minimum1"
clearancemuststillbemaintainedaroundtheventpipes.)
Figure 4. Framing for shelves over the fireplace.
To VentRear Vent
Figure 3. Corner framing dimensions.
Figure 2. Framing dimensions.
* When sheetrock is
not used behind the
fire lace, framing
de th may be
reduced to 13 3/4"
Framing
WARNING:
When this a liance is installed directly on car eting, tile
or any combustible material other than wood flooring, it
must be installed on a metal or wood anel extending the
full width and de th of the a liance.
To Vent
Front View Rear Vent
Clearances
These clearances a ly to all dimensions excepttheframedopening,
where the clearance to combustibles is 0". The C34-DVclearances to
combustible materials are:
Top-RearVent* 7"
Top-TopVent 15"
Back 0"
Flue 1"
Sides 1"
Floor 0"
Mantle** 6"
* Clearance from the to of the fire lace to a combustible
ceiling within the fire lace enclosure.
** Refer to age 10.
Un rotected combustible walls which are er endicular to the fire lace
o ening, must not roject beyond the shaded area shown in Figure 19b.
For rotection against freezing tem eratures, it is recommended that
outer walls of the chase be insulated with a va our barrier. This will
reduce the ossibility of a cold-air convection current on the fire lace.
Figure 1. Fireplace dimensions.

Page 4
C34-DV Gas Fireplace
Part No. XG0117B
ent Installation
This section covers the installation of direct venting and terminations.
Installation Requirements
C34-DV fire laces are certified for use with Montigo Premium
Series (5" / 8") venting com onents. The C34-DV Top Vent may
be used with Standard Series (4"/7")com onents on vertical vent
runs only.
Minimum 1" clearance to combustibles required for vent i es
Use only certified Montigo vent components. (Use of other arts will
void the Montigo warranty, and may im ede the o eration of the
fire lace.)
All joints must be secured with a minimum of two screws er joint
Vent terminations must not be recessed in walls or siding
Horizontal runs must be su orted by a minimum of two su orts
er horizontal run. A minimum of one screw on each side of
su ort is also required
Flex vent sections may be stretched u to 50% of their total length
(eg. a 24" section may be stretched to 36")
Maximum horizontal run for a flex section with no vertical rise is 3 feet.
Flex vent sections over 3 feet must fall within the limits set by the
venting gra h and must have a minimum vertical rise of 3 inches
er foot of flex.
Solid vent sections may be cut less than half way from the ta ered end
Vent Terminations
Selecting A Termination Location
Choosing your vent termination location will hel to determine whether
you need to use a to vent or rear vent fire lace. Figure 6, below,
shows ty ical fire lace locations and the venting o tions they rovide.
For a more detailed diagram of allowed termination locations, see
AppendixB.
Cautions:Cautions:
Cautions:Cautions:
Cautions:
Installing The Gas Line
The gas line must be installed before finishing the C34-DV Fire lace.
NaturalGas requires a minimum inlet gas su ly ressure of 5.5"
W.C. & a manifold ressure of 3.5" W.C. PropaneGas requires a
minimum inlet gas su ly ressure of 11" W.C. & a manifold ressure of
10" W.C. Provision must also be made for a 1/8" N.P.T. lugged ta ing
and be accessible for test gauge connection immediately u stream of the
gas su ly controls to the a liance. The fire lace gas connection and
the main o erating gas valve is located behind the removable brass trim
at the bottom of the unit and need only be attached to the gas line with an
a roved fitting, as required by the applicableinstallation codes.
Installation
Figure 6. Fireplace locations and vent terminations.
Note: After gas line is connected, eachappliance connection,
valve and valve train must be checked while under
normal o erating ressure with either a liquid solution, or
leak detection device, to locate any source of leak. Tighten
any areas where bubbling a ears or leak is detected until
bubbling sto s com letely or leak is no longer detected.
DO NOT use a flame of any kind to test for leaks.
Installing The Remote Switch
The C34-DV's gas valve, located behind the lower brass trim, may be
connected to a wall switch. The valve generates its own ower on a
millivoltcircuit. Use onlylow voltage wire,and DO NOT connect
any external ower to it.
Refer to Figure 26 for wiring requirements.
Note: The switch location must not exceed 30' from the fire lace.
Figure 5. Gas line access.
The a liance and its individual shutoff valve must be disconnected from
the gas su ly i ing system during any ressure testing of that system
at test ressures in excess of 1/2 sig (3.5 kPa).
The a liance must be isolated from the gas su ly i ing system by
closing its individual manual shutoff valve during any ressure testing of
the gas su ly i ing system at test ressures equal to or less than 1/2
sig (3.5 kPa).
Vent terminations can be very hot. If the termination
is less than 7 feet above a ublic walkway, it should
be fitted with a certified Montigo Heat Guard. (Part no.
PTKOG)
Do not obstruct, or attem t to conceal, the vent
termination. These actions will affect the o eration
of the fire lace, and may be hazardous.
In heavy snow areas, take extra care to revent snow
buildu from obstructing the vent termination.

Page 5
C34-DV Gas Fireplace
Part No. XG0117B
Installing Terminations with Built-In Frames
Installing Terminations with MSR Frames
12
12
1. Frame the termination o ening to 12" x 12".
2. Fasten the termination to the studs using a minimum of 4 screws.
11
11
1. Frame the termination o ening to 11" x 11".
2. Fasten the termination to the studs using a minimum of 4 screws.
Installing Terminations with MOSR Frames
1212
12
MOSR
1. Frame the termination o ening to 12" x 12".
2. Fasten the MOSR frame to the interior side of the studs using a
minimum of 4 screws.
3. Insert the termination into the MOSR frame as shown here, and
attach by screwing through the four ilot holes in the termination.
MSR
PTO-3
PTO-3F
PTO-3
PTKOG
1. Ensure that the two longmounting brackets are facing the bottom of
the termination. (See inset). This will rovide more heat rotection
at the to of the termination, where tem eratures are highest.
2. Attach to the face late of the termination using four sheet metal
screws.
Installing Heat Guards over Terminations
Installation

Page 6
C34-DV Gas Fireplace
Part No. XG0117B
Installation
Top ent enting Runs
For the C34-DV TopVent, there are two ty es of installations: A)
Through-The-Wall Installations and B) Vertical (Through-The-Roof)
Installations.
A) Through-The-Wall Installations
Before you install any venting, you must determine whether the venting
run will be acce table. Unacce table venting can affect the fire lace's
combustion.
The Venting Graph
Measure the vertical height from the fire lace hearth to the centre of the
termination and the horizontal run from the from the fire lace flue collar to
the wall flange of the termination. Plot on the Venting Gra h (Fig. 7) with
an 'X'.
If the 'X' falls on or above the to boundary of the shaded area, the
installation is acce table.
Example A: (Acceptable Installation)
If the vertical dimension from the hearth is 84" and the horizontal
run to the wall flange of the vent termination is 36", this would be
an acce table installation.
Example B: (Acceptable Installation)
If the vertical dimension from the hearth is 90" and the horizontal
run to the wall flange of the vent termination is 120", this would be
an acce table installation.
Example C: (Unacceptable Installation)
If the vertical dimension from the floor of the fire lace is 72" and
the horizontal run to the wall flange of the vent termination is 84",
this would NOT be an acceptable installation.
Figure 7. Venting Graph
Figure 8. Heat Shield. Install by sliding over the vent pipe where it
passes through combustible construction.
Heat Shields
Due to high flue tem eratures, heat shields are required on all C34-DV
installations (exce t those with vertical
terminations) at the oint where the
venting connects to the termination. With
the heat shield, vent clearances can be
maintained at 1".
012 24 36 48 60 72 84 96 108 132120 144 156 168 180
Horizontal Run (in.)
Hearth
0
12
24
36
48
60
72
84
96
108
Available Top Vent Components
The following venting com onents are available for the C34-DV Top
Vent:
A - Termination PTO-3 (3" length)
PTO-3F (3" length)
B - Stucco Kits MSR (stucco frame)
MOSR (stucco can)
BSR (brick can)
C - Flex sections PFL-1 (12" section)
PFL-2 (24" section)
PFL-3 (36" section)
PFL-4 (48" section)
D - Rigid sections PEXT-1 (12" m/f section)
PEXT-2 (24" m/f section)
PEXT-3 (36" m/f section)
PEXT-4 (48" m/f section)
PEXT-6 (72" m/f section)
E - Elbows PEL-90MM (m/m 90° elbow)
PEL-90FF (f/f 90° elbow)
PEL-90FM (f/m 90° elbow)
NOTES: All dimension lengths for vertical or horizontal runs are
measured from center of the vent i e.
Venting runs must fall within the limits set by the venting
gra h (see Figure 7).

Page 7
C34-DV Gas Fireplace
Part No. XG0117B
Installation
Termination
Example 1:
For our shortest venting configuration use com onents A and F (see
Figure 9a).
Figure 9a. ypical op Vent installation. If the 90° elbow is
installed directly on the fireplace, the height to the
center of the termination is 43½".
Horizontal Venting
Figure 9b. ypical op Vent installation. he solid sections can be
used in various combinations to obtain the desired vent
run. he vent run must fall within the limits set by the
venting graph.
90° Elbow
PEXT Section
Example2:
Rigid sections and an elbow used in conjunction with 3 ft. flex section
(PFL-3) will, when extended in a five foot chase, allow for a maximum
horizontal run of twelve and one-half feet from the centre of the fire lace
to outside wall and a minimum of 7'6" when retracted in o osite direction
(see Figure 10 and 11).
"C" flex sections and "D" rigid sections may be used in conjunction with
one another to obtain different ossible horizontal length installations.
NOTE:Flex section with no vertical rise must not exceed maximum
horizontal length of 3 feet (seeFigure12). Flex runs over 3 feet must fall
within the limits set by the venting gra h, and must have a minimum
vertical rise of 3" er foot of flex.
Figure 10. Extended Installation using a combination of solid and
flex venting. Use the vent graph to determine your
allowable run, then select appropriate components.
Figure 11. Retracted Installation using a combination of solid and
flex venting. Use the vent graph to determine your
allowable run, then select appropriate components.
Figure12. Horizontal flex installation with no vertical rise.
Hearth
Termination
Exterior
Wall
3' max.
Flex Section
Hearth
Flex Section Termination
Exterior
Wall
Solid Sections
Hearth
Flex Section
Solid Sections Termination
Exterior
Wall
150" max.
30" max.
RigidSection
PEL-90F/F Elbow
RigidSection

Page 8
C34-DV Gas Fireplace
Part No. XG0117B
Storm collar
Support ring
MEXT
Solid Section
Roof flashing
30' max.
* Minimum 1" clearance to all combustibles
Support plate
Firestop
Firestop
2' min.
MXT-10
Adaptor
MEXT
Flue
Collar
2' min.
Storm collar
Support ring
Roof flashing
30' max.
* Minimum 1" clearance to all combustibles
Support plate
Firestop
Installation
B. Vertical (Through-The-Roof) Installations
5/8" with option for 4/7"
■Vertical rise >12' can be reduced
■Vertical Terminations must be installed:
•minimum 2' (two feet) above the highest oint where
vent asses through the roof.
•minimum 6' (six feet) from a mechanical air inlet
•minimum 3' (three feet) from a ara et wall.
■Maximum vent height is 30 feet above fire lace.
Note: Flame characteristics will change if the maximum vent height is
used.
■Minimum clearances 1" from vent to all combustible materials must be
maintained.
Figure13.a Straight, vertical venting using required adaptor.
■A maximum of two offsets with 90° bends may be made and shall not
exceed total length of 25% of the vertical vent height, when measured
center to center of i ing.
Exam le: Ty ical vent installation.
20' vertical vent
2 - 2' offsets required
25% of 20' = 5' max. offset allowed
This venting configuration meets requirements.
Figure 14a. Vertical venting with 1 offset.
30'max.
30'max.
Rigid Section
A
A.Male/Female
B.Female/Female
C.Male Flue Collar
B
C
Figure 13b. Reducing Vertical Vent from 5/8" to 4/7".
Vent Restrictors
When venting vertically, Vent Restrictors may be added to enhance the
burn characteristics of the fire lace.
Part Size 5"/8" Venting 4"/7" Venting
A - Termination n/a PVTK-1 MVTK-1
B - Flex sections 12" length PFL-1 MFL-1
24" length PFL-2 MFL-2
36" length PFL-3 MFL-3
48" length PFL-4 MFL-4
C - Solid sections 12" length PEXT-1 MEXT-1
24" length PEXT-2 MEXT-2
36" length PEXT-3 MEXT-3
48" length PEXT-4 MEXT-4
D - Support Ring
& Plate PSPXT-8 MSPXT-7
E - Firestop PS-8 FS-7
F - Roof Flashing (1/12-7/12 pt.) PRF-7 MRF-7
(7/12-12/12 pt.) PRF-12 MRF-12
G - Adaptor/ (5"/8" to 4"/7") PVA5487
Vent Reducer

Page 9
C34-DV Gas Fireplace
Part No. XG0117B
Installation
2. 45° Corner Installation.
Attach an PEL-45 (45° elbow) directly onto the flue collar. Cut the
PXT-20 to suit, and attach it to the PEL-45. Slide the fire lace into
osition and attach to the termination.
Heat Shields
Due to high flue tem eratures, heat shields are required on all C34-DV
installations (exce t those with vertical terminations) at the oint where
the venting connects to the termination. With the heat shield, vent
clearances can be maintained at 1". *Heat Shields are included
See Figure 8.
1. Straight Installation.
The height from the hearth to the center of the termination is 28
3/8". C34-DV Rear Vent versions are su lied with a 20" extension
i e (PXT-20) with female/female connections. For shorter
installations, cut the PXT-20 to the desired length.
For extended installations, use the PXT-20 section as su lied for a
20" vent run.
Flue Collar
Heat Shield
EXT-18
Termination
Figure 15. Extended installation.
Heat Shield
EXT-18
Termination
EEL-45
Elbow
FlueCollar
Figure 16. Corner installation.
3. Corner Installation — 45° or less.
Use an PTO-3 termination and an PFL-1 or PFL-2 (12" or 24"
com ressed length) and a frame, if a ro riate. Flex may be turned
to obtain desired degree of angle required but must not exceed 45°.
Figure 17. Flex installation.
Heat Shield
Termination
Flex
Section
Flue Collar
PXT-20
PXT-20(cut to length)
PEL-45
Figure 14b. Vertical venting with 2 offsets.
2' min.
2'
Storm collar
Roof flashing
30' max.
* Minimum 1" clearance to all combustibles
Support straps or
support plate & ring
Firestop
Firestop
Firestop
Support plate
& ring
30'max.
Rear ent enting Runs
The C34-DVRearVenthas three ossible installations which do not
require vertical lift:
Note: For Rear Vent models, maximum horizontal run with no
vertical lift must never exceed 20".

Page 10
C34-DV Gas Fireplace
Part No. XG0117B
Installation
B. Multi-Elbow Installations
For more diffiicult installation situations, the C34-DV Rear Vent may be
installed with two — 90° elbows and u to 15' of horizontal run. If using
this installation o tion, you must adhere to the following guidelines:
■the first 90° elbow must be laced directly on the flue collar
■you must have a minimum vertical lift of 50" (measured from the
hearth)
■your vent run must fall within the limits set by Figure 18a
Before you install any venting, you must determine whether the venting
run will be acce table. Unacce table venting can affect the fire lace's
combustion.
The Venting Graph
Measure the vertical height from the fire lace hearth to the centre of the
termination and the horizontal run from the from the fire lace flue collar to
the wall flange of the termination. Plot on the Venting Gra h (Fig. 18a)
with an 'X'.
If the 'X' falls on or above the to boundary of the shaded area, the
installation is acce table.
Example A: (Acceptable Installation)
If the vertical dimension from the hearth is 84" and the horizontal
run to the wall flange of the vent termination is 36", this would be an
acce table installation.
Example B: (Acceptable Installation)
If the vertical dimension from the hearth is 90" and the horizontal
run to the wall flange of the vent termination is 126", this would be
an acce table installation.
Example C: (Unacceptable Installation)
If the vertical dimension from the floor of the fire lace is 78" and the
horizontal run to the wall flange of the vent termination is 108", this
would NOT be an acceptable installation.
Figure 18a. C34-DV Rear Vent Venting Graph
012 24 36 48 60 72 84 96 108 132120 144 156 168 180
Horizontal Run (in.)
Hearth
0
12
24
36
48
60
72
84
96
108
Installation Of Rear ent D
C34-DV Rear Vent versions are su lied with an PXT-20 (female/
female) section. In addition, the following venting com onents are
available for Rear Vent installations:
A - Termination PTO-3 (3" length)
PTO-3F (3" length)
B - Stucco Kits MSR (stucco frame)
BSR-4 (4" brick frame)
BSR-6 (6" brick frame)
MOSR (stucco can)
C - Flex sections PFL-1 (12" section)
PFL-2 (24" section)
PFL-3 (36" section)
PFL-4 (48" section)
D - Solid sections PEXT-1 (12" section)
PEXT-2 (24" section)
PEXT-3 (36" section)
PEXT-4 (48" section)
E - 90 degree elbow PEL-90MM (m/m 90° elbow)
PEL-90FF (f/f 90° elbow)
PEL-90FM (f/m 90° elbow)
PEL-45FM (f/m 45° elbow)
Figure 18b. Multi-elbow installation. Distance 'H' must be a
minumum of 50". he vent run must comply with figure
18a.
NOTES: All dimension lengths for vertical or horizontal runs are
measured from center of the vent i e.
Venting runs must fall within the limits set by the venting
gra h (see Figure 18a).
8"
H
L
18"

Page 11
C34-DV Gas Fireplace
Part No. XG0117B
Finishing Around the Fireplace
Combustible mantels and mouldings may be safely installed over the to
and on the front of the fire lace rovided that they do not roject beyond
shaded area shown in Figure 19a. Side wall clearances are 3".
Combustible surrounds may be installed with 3" clearance to the side of
the fire lace as shown in Figure19b.
Fireplace Facing
When selecting the finish material for your fire lace, it is im ortant to
remember the following: MUSTNOTBEOBSTRUCTEDINANYWAY
- to do so restricts the air supply for the control compartments
and heat exchanger it also prevents access for servicing
controls.
The face of the fire lace may be ainted to match the room decor,
rovided you use a heat-resistant aint. Decorative facing must not
extend ast the fire lace o ening at all, because it will interfere with the
access to retainers for removal of glass door.
Installation
Figure 19a. Combustible mantles and facings.
Mantels & Surrounds
NOTE: National Canadian Gas Association mantel test requirements are
for fire hazard revention to combustible materials.
New technology, to meet consumer and government demands for the
wise use of energy, has rom ted us to manufacture many models of
fire laces which are hot, fuel and energy efficient.
Please be aware; tem eratures over the mantel will rise above normal
room tem erature and walls above fire lace may be hot to touch.
We recommend careful consideration be given to the effects of elevated
mantel tem eratures which may be in excess of roduct design, for
exam le: candles, lastic or ictures. This can cause melting, deforma-
tion, discoloration or remature failure of T.V. and radio com onents.
Painting:
S ecial care is recommended by the Master Painters and Decorators
Association, when ainting the fire lace surrounds, to select and a ly a
quality Alkydsealer rior to the a lying of latex aints. This is to
revent leaching of water from eva oration and causing a brownish
staining effect to aint over coats.
Sheetrock/
Drywall
Header
3
4
5
°
Figure 19b. Combustible surrounds.

Page 12
C34-DV Gas Fireplace
Part No. XG0117B
Removing and Installing
the Door
RemovingtheDoor:
Remove the trim (as described on the next age) to access the door
latches. O en the latches by ulling Part A u wards and towards you to
disengage Part B from the door. Lift Part B clear of the door. Re eat for
all three latches. Be sure to hold the door carefully so it does not fall.
(Seefigure23a.)
Installation
Once the three latches are unhinged, tilt the to of the door forward and
lift it out of the slots. Seefigures23band23c.
Figure 23a. Operating the door latches.
Figure 22a. Wiring for optional air circulating fan kit.
G
L1-WH
L2-BLK
Quick Connect
plug to motor
Wiring for the optional Fan Kit
All C34-DV fire laces may be equi ed with o tional fan kits (Part no.
RFK1001, RFK1003, RFK1006 or RFK1007)for circulating heat into the
living s ace.
InstallationsinCanada which em loy the fans must be electrically
grounded in accordance with CSAC22.1 Canadian Electrical Code Part
1 and/or Local Codes.
Installationsin theUSA which em loy the fans must be grounded in
accordance with local codes or, in the absence of local codes, with the
National Electrical Code, ANSI/NFPA70-1987.
For more information see the FanKitInstallationGuide included with
the fan kit.
NOTE: If any of the original wire su lied with the a liance is re laced, it
must be re laced with the same ty e, or its equivalent.
Figure 22b. Wiring schematic for optional fan kit.
115/1/60 Supply
G L1 L2
Figure 23b. Removing the door.

Page 13
C34-DV Gas Fireplace
Part No. XG0117B
Installation
Cautions:
■If logs are not laced ro erly, excessive sooting
will result.
■The surface of the logs will crack due to the heat
from the flames. This is a normal occurance.
Embers
Log 'D' Log 'E'
Flame Sha er
Log 'A'
Log 'C' Log 'B'
Figure 23c. Removing the door.
Re-installing the door:
To re-install the door, tilt the to edge towards you and line u the tabs of
the bottom of the door with the slots on the fire lace. Place the tabs into
the slots, and tilt the to of the door back towards the fire lace as far as it
will go. Close the latches by hooking Part B onto the groove at the to of
the door and ushing Part A down com letely.
Figure25. Installing the horizontal trim pieces.
Installing the Trim & Baffle
The fire lace is shi ed with 6 horizontal trim ieces (3 u er and 3
lower), which must be field-installed.
Install the trim by lacing the to edge of the trim over to the retainer cli s
on either side of the fire lace. Push the bottom edge firmly inwards and
the trim will sna on. (Seefigure25) Install the u er trim ieces so that
the baffle is resting between the to and middle iece, as shown below.
The trim iece with the Montigo Emblem should be installed on the lower
middle cli s with the emblem on the right side.
Installing the Log Set
Installing the Logs:
The C34-DVis su lied with five ceramic fibre logs. Un ack the logs and
handle them very carefully.
1. Remove the door cover and the glass door.
2. Place the Back log onto the back log rest as shown below in figure
24a. The log has li on the bottom which fits into the slot on the log rest.
3. Place the Front log onto the front log rest as shown in figure 24a.
Center the log from side to side, and ush it against the back of
the log rest. Carefully ush the log onto the metal s ikes on the log rest.
4. Place the to logs in osition as shown in figure 24b, lace the
centre log down first, then the right and left logs.
5. Start the fire lace. If the flame a ears satisfactory, re lace the
glass door and door cover.
Figure 24a.Positioning for the front and back logs.
Figure 24b.Proper log placement.

Page 14
C34-DV Gas Fireplace
Part No. XG0117B
WARNING: If you do not follow these instructions exactly, a fire or explosion
may result causing property damage, personal injury or loss of life.
■If you cannot reach your gas su lier, call the Fire
De artment.
C. Use only your hand to ush in or turn the gas control knob.
Never use tools. If the knob will not ush in or turn by
hand, don't try to re air it, call a qualified service
technician. Force or attem t to re air may result in a fire or
ex losion.
D. Do not use this a liance if any art has been under water.
Immediately call a qualified service technician to ins ect
the a liance and to re lace any art of the control system,
and any gas control which has been under water.
A. This a liance has a ilot which must be lighted by hand.
When lighting the ilot, follow these instructions exactly.
B. BEFORE LIGHTING smell all around the a liance area
for gas. Be sure to smell next to the floor because some
gas is heavier than air and will settle on the floor.
What To Do If You Smell Gas:
■Do not try to light any a liance.
■Do not touch any electrical switch; do not use any
hone in your building.
■Immediately call your gas su lier from a neighbour's
hone. Follow the gas su lier's instructions.
To Turn Off Gas To Appliance:
Operation - Model C34-D
3. Push in gas control knob slightly and turn clockwise
to "Off". Do not force.
4. Fli u the lower trim.
1. Turn off remote switch.
2. Fli down the lower trim.
1. STOP! Read the safety information above on this label.
2. Fli down the lower trims.
3. Push in gas control knob and turn clockwise to
"OFF."
4. Wait five (5) minutes to clear out any gas. Smell for gas,
including near the floor. If you then smell gas, STOP!
Follow "B" in the safety information above on this label. If
you don't smell gas, go to the next ste .
5. Locate ilot burner (See illustration at right.) and follow
ste s below.
6. Turn knob on gas control counterclockwise to
"PILOT."
7. Push in gas control knob com letely and hold. Light with
Piezo Igniter button. Continue to hold the control knob in for
about (1) minute after the ilot is lit. Release the knob and it
will o back u . Pilot should remain lit. If it goes out re eat
ste s 3 through 8.
■If knob does not o u when released. Sto and
immediately call your service
technician or gas su lier.
■If the ilot will not stay lit after
several tries, turn the gas control
knob to "OFF" and call your service
technician or gas su lier.
8. Push in gas control knob and turn counterclockwise
to "ON."
9. Fli u the lower trim.
10.Turn on remote switch to ignite fire.
Lighting Instructions:
C34-DV
with Continuous Pilot
For Your Safety - READ BEFORE LIGHTING:
Gas Control Knob
(Shown in "Pilot" postion.) NOTE: Knob cannot be turned from
"PILOT" to "OFF" unless knob is
pushed in slightly. Do not force.

Page 15
C34-DV Gas Fireplace
Part No. XG0117B
Operation - Model C34-D -S
C34-DV-S
with Pilotless (Spark-to-Burner) Ignition
A. This a liance does not have a ilot. It is equi ed with an
ignition device which automatically lights the burner. Do not
attem t to light the burner by hand.
B. BEFORE OPERATING smell all around the a liance area for
gas. Be sure to smell next to the floor because some gas is
heavier than air and will settle on the floor.
What To Do If You Smell Gas:
nDo not try to light the a liance.
nDo not touch any electrical switch. Do not use any hone in
your building.
nImmediately call your gas su lier from a neighbour's
1. STOP! Read the safety information above on this label.
2. Make sure the wall switch is in the "OFF" osition. Fli down the lower
horizontal trim.
3. Wait 5 minutes to clear out any gas. If you smell gas, STOP! Follow "B" in
the safety information above on this label. If you don't smell gas, go to ste
4.
4. Find the indicator light on the control module, located under the fire lace near
the gas control valve. If the indicator light is flashing slowly, the system is
ready for lighting.
5. Turn on the wall switch. You will hear a 'ticking' sound as the system
attem ts to light the fire lace. If successful, the main burner will ignite, and the
indicator light will flash quickly.
If not successful, the system will automatically close the gas valve to sto
the flow of gas. The indicator light will double flash, and the system will lock
out for five minutes.
6. Fli u the lower horizontal trim.
1. Turn off the wall switch.
hone. Follow the gas su liers instructions.
nIf you cannot reach your gas su lier, call the Fire De art-
ment.
C. Do not tam er with, or attem t to re air the gas control valve. If
the system does not o erate ro erly, call your service techni-
cian or gas su lier. Force or attem ted re air may result in a
fire or ex losion.
D. Do not use this a liance if any art has been under water.
Immediately call a qualified service technician to ins ect the
a liance and to re lace any art of the control system, and any
gas control which has been under water.
2. If service is to be erformed, turn off all electric ower to the a liance.
Control Module
Indicator Light
Rear Burner Tube
Ignitor / Flame
Sensor Probe
OUT
Gas Control Valve
WARNING: If you do not follow these instructions exactly, a fire or ex losion may result
causing ro erty damage, ersonal injury or loss of life.
For Your Safety - READ BEFORE LIGHTING:
To Turn Off Gas To Appliance:
Lighting Instructions:

Page 16
C34-DV Gas Fireplace
Part No. XG0117B
Maintenance
WARNING:
Do not attem t to clean glass when hot.
Do not clean glass with abrasive materials as any
glass etching may cause remature glass failure.
CAUTIONS
Fire lace gas control must be in the “OFF” osition and
ilot and main burners extinguished when cleaning
a liance with a vacuum.
Doors and logs can get very hot. Handle only when cool.
General
Have the fire lace installation ins ected yearly, including a visual
check of the vent system, the burner and the ilot flame. For your
convenience a 1/8" manifold ressure ta is su lied on the gas
valve for a test gauge connection. See Figure 27.
For NaturalGas this a liance requires a minimum inlet ressure of
5.5" W.C. and a manifold ressure of 3.5" W.C.
For PropaneGasthis a liance requires a minimum inlet ressure
of 11" W.C. and a manifold ressure of 10" W.C.
Always kee the fire lace area clear and free of combustible
materials, as well as gasoline and other flammable va ours and
liquids.
Do not use this a liance if anyparthasbeenunderwater.
Immediately call a qualified service technician to ins ect the a liance
and to re lace any art of the control system and any gas control
which has been under water.
Operation
Lighting Instructions
See ages 14 and 15.
Burner Adjustment
The C34-DV is equi ed with an adjustable burner, allowing you to
raise or lower the flames. To adjust the flames, locate the black knob
marked 'Hi-Lo', in the centre of the gas control valve (See Figure 26).
The front burners are not adjustable.
■To raise the flame height, turn the black knob (located behind the
lower trim) counterclockwise.
■To lower the flame height, turn clockwise.
Figure 26. 'Hi-Lo' Adjustment on the C34-DV's gas valve.
Cleaning
When the fire lace is first activated, there may be some smoking and a
visible film may be left on the glass. This is a normal condition, and is the
result of burning of rotective coatings on new metal.
Glass must be cleaned eriodically to remove any film (which is a
normal bi roduct of combustion) which may be visible. Film can
easily be removed by removing the door, as shown on age 12-13.
Handle the door carefully, and clean it with non-abrasive glass
cleaners. One of the most effective roducts is Kel Kem.
Silicone seals on inner door during initial firing will "off gas", leaving a
visual de osit of a white substance on combustion chamber walls.
This can easily be removed using normal household roducts.
Use a vacuum cleaner or whisk broom to kee the control
com artment, burner, and firebox free from dust and lint.
Logs may be cleaned eriodically with a vacuum to remove soot or
other contaminates.
Note: C34-DV-Imodels (pilotlessignition)donot
featurehi/lo adjustment.

Page 17
C34-DV Gas Fireplace
Part No. XG0117B
Maintenance
Gas Control alve
Figure 27 Sit Nova 820 gas valve.
Pilot Burner Adjustment
1. Locate Pilot Adjustment Screw. (Seefigure27.)
2. Adjust ilot screw to rovide ro erly sized flame as shown in
figure 28).
3. After installing or servicing, leak test with a soa solution with main
burner on. Coat i e and tubing joints, gasket etc. with soa solution.
Bubbles indicate leaks. Tighten any areas where the bubbles
a ear until the bubbling sto s com letely.
Figure 28. Pilot Burner
Manifold Pressure
Test Connection
Pilot Adjustment Screw
Inlet
Pressure
Power
Generator
Wall Switch
Troubleshooting
The following is a troubleshooting chart of ossible roblems:
PROBLEM CORRECTIVEACTION
Noisy Pilot Flame Locate ilot adjustement screw on
gas control valve. Flame is decreased by
turning adjustment screw clockwise.
Pilot won’t ignite Disconnect remote wires and try to light
ilot. If ilot now works, remote
connections are faulty. Check wiring
diagram figure27.
Main burner will 1. Check wiring (seefigure27).
not light 2. Check wall switch for ro er
connection.
C34-DV
Troubleshooting C38-DV-S
A. Diagnosing the status using the indicator light.
The LED indicator light on the control module will show the control
system's current status.
LED Pattern Status
No Light System does not have ower.
Action: Ensure that the ower cord is
lugged into the PPO-D box. See
Figure 30.
Slow Steady Flash System is ready.
Fast Steady Flash System is trying to light the burner.
Double Flashes 5 Minute Lockout. The system did not
light/remain lighted successfully.
Action: Wait five minutes before
attem ting to re-light the burner.
Continuous On Hard system lockout. You must in lug
the ower cord from the PPO-D box to
reset the system. (See figure30.)

Page 18
C34-DV Gas Fireplace
Part No. XG0117B
The WarrantyThe Warranty
The WarrantyThe Warranty
The Warranty
The Com anies warrants the Montigo Gas A liance to be free from defects in materials and workmanshi at the time of manufacture. On the Montigo, there is a ten-
year warranty on the firebox and its com onents, a five-year warranty on the main burner and ilot burner, and a one-year warranty on the gas control valve and fibre logs.
Glass, lated/ ainted finishes, and refractory lining are exem t.
Remedy And Exclusions
The coverage of this Warranty is limited to all com onents of the Gas A liance manufactured by The Com anies.
This Warranty only covers Montigo Gas A liances installed in the United States or Canada.
If the com onents of the Gas A liance covered by this Warranty are found to be defective within the time frame stated (see The Com anies right of investigation outlined
below). The Com anies will, at its o tion, re lace or re air defective com onents of the Gas A liance manufactured by The Com anies at no charge, and will also ay
for reasonable labour costs incurred in re lacing or re airing com onents. If re air or re lacement is not commercially ractical, The Com anies will, at its o tion, refund
the urchase rice of the Montigo Gas A liance.
This Warranty covers only arts and labour as rovided above. In no case shall The Com anies be res onsible for materials, com onents, or construction which are not
manufactured or su lied by The Com anies, or for the labour necessary to install, re air or remove such materials, com onents or construction. All re lacement or re air
com onents will be shi ed F.O.B. the nearest The Com anies factory.
Qualifications To The WarrantyQualifications To The Warranty
Qualifications To The WarrantyQualifications To The Warranty
Qualifications To The Warranty
The Gas A liance Warranty outlined above is further subject to the following qualifications:
(1) The Gas A liance must be installed in accordance with The Com anies installation instructions and local building codes. The Warranty on this Montigo Gas A liance
covers only the com onent arts manufactured by The Com anies. The use of com onents manufactured by others with this Montigo Gas A liance could create
serious safety hazards, may result in the denial of certification by recognized national safety agencies, and could be in violation of local building codes. This warranty
does not cover any damages occurring from the use of any com onents not manufactured or su lied by The Com anies
(2) The Montigo Gas A liance must be subjected to normal use. The Gas A liances are designed to burn gas only. Burning conventional fire lace fuels such as wood,
coal or any other solid fuel will cause damage to the Gas A liance, will roduce excessive tem eratures and will result in a fire hazard.
Limitations On LiabilityLimitations On Liability
Limitations On LiabilityLimitations On Liability
Limitations On Liability
It is ex ressly agreed and understood that The Com anies sole obligation, and urchaser's exclusive remedy under this Warranty, under any other warranty, ex ressed
or im lied, or in contract, tort or otherwise, shall be limited to re lacement, re air, or refund, as s ecified above.
In no event shall The Com anies be res onsible for any incidental or consequential damages caused by defects in its roducts, whether such damage occurs or is discovered
before or after re lacement or re air, and whether or not such damage is caused by The Com anies negligence. Some states do not allow the exclusion or limitation of
incidental or consequential damages, so the above limitation or exclusion may not a ly to you. The duration of any im lied warranty with res ect to this Montigo Gas A liance
is limited to the duration of the foregoing warranty. Some states do not allow limitation on how long an im lied warranty lasts, so the above may not a ly to you.
Investigation Of Claims Against WarrantyInvestigation Of Claims Against Warranty
Investigation Of Claims Against WarrantyInvestigation Of Claims Against Warranty
Investigation Of Claims Against Warranty
The Com anies reserves the right to investigate any and all claims against this Warranty and to decide u on method of settlement.
The Com anies Are Not Res onsible For Work Done Without Written Consent
The Com anies shall in no event be res onsible for any warranty work done without first obtaining The Com anies written consent.
Dealers Have No Authority To Alter This Warranty
The Com anies em loyees and dealers have no authority to make any warranties nor to authorize any remedies in addition to or inconsistent with those stated above.
How THow T
How THow T
How To Register A Claim Against Wo Register A Claim Against W
o Register A Claim Against Wo Register A Claim Against W
o Register A Claim Against Warrantyarranty
arrantyarranty
arranty
In order for any claim under this Warranty to be valid, The Com anies must be notified of the claimed defect in writing or by tele hone, as soon as reasonably ossible
after the defect is discovered. Claims against this Warranty in writing should include the date of installation, and a descri tion of the defect.
Other RightsOther Rights
Other RightsOther Rights
Other Rights
This Warranty gives you s ecific legal rights, and you may also have other rights which vary from state to state.
NOTE: he Companies as stated above refer to - Canadian Heating Products Inc. and/or Montigo Del Ray Cor .
Canadian Heating Products Inc. and/or Montigo DelRay Corp. reserves the right to make changes at any time, without
notice, in design, materials, specifications, prices and also to discontinue colors, styles and products.
Warranty

Page 19
C34-DV Gas Fireplace
Part No. XG0117B
Appendix A - Termination Locations
A= clearancetotheterminationframeabovegrade,veranda,porch,deck,or
balcony[16inches(41cm)minimum]
B= clearancetodoor,orsidesandtopofwindow,thatmaybeopened[16
inches(41cm)minimumforappliances
≤ 100000BTU/H(30kW)]
C= clearancetobottomof windowthatmaybeopenedhorizontally[36inches
(92cm)minimumforappliances
≤ 100000BTU/H(30kW)]
D= noclearancetopermanentlyclosedwindowwheninstalledwithapproved
glasspenetrationtermination
E= clearancetopermanentlyclosed window[16inches41cmrecommended
topreventcondensationonwindow]
F= verticalclearancetoventilatedsoffitlocatedabovetheterminationwithina
horizontaldistanceof2feet(61cm)fromthecentrelineofthetermination
[22inches(56cm)minimum]
G= clearancetounventilatedsoffit
[16inches(41cm)minimumtonon-combustibles]
[22inches(56cm)minimumtocombustibles]
H= clearancetooutsidecorner[9inches(23cm)minimum]
I= clearancetoinsidecorner[12inches(31cm)minimum]
J= *nottobeinstalledaboveameter/regulatorassemblywithin
40"(103cm)horizontallyfromthecentrelineoftheregulator
K= clearancetoserviceregulatorventoutlet[3feet minimumintheUnited
States][*6feet (1.8m)minimuminCanada]
L = clearancetononmechanicalairsupplyinlettobuildingorthecombustion
airinlettoanyotherappliance[16inches(41cm)minimumforappliances
≤ 100000BTU/H(30kW)]
M= clearancetomechanicalairsupplyinlet
[*6feet (1.8m)minimum]
N= †clearanceabovepavedsidewalkorapaveddrivewaylocatedon
publicproperty[*7feet(2.1m)minimum]
P= clearanceunderveranda,porch,deck,orbalcony
[16inches(41cm)minimum‡tonon-combustibles]
[22inches(56cm)minimum‡tocombustibles]
Q= clearanceabovearoof[24inches(61cm)minimum]
R= clearancetoadjacentwallsandneighbouringbuildings
[18inches(46cm)minimum]
S= clearancefromcornerinrecessedlocation
[12inches(31cm)minimum]
T= maximumdepthinrecessedlocation
[48inches(122cm)minimum]
U= minimumwidthforbackwallofrecessedlocation
[24inches(61cm)minimum]
V= nohorizontalclearancebetweentheframesoftwoterminationsthatare
level.
W= horizontalclearancebetweentheframesoftwoterminationsthatare
notlevel. [36inches(92cm)minimum]
†aventshallnotterminatedirectlyaboveasidewalkorpaveddriveway
whichislocatedbetweentwosinglefamilydwellingsandservesboth
dwellings
‡onlypermittedifveranda,porch,deck,orbalconyhasanopensidethat
isequaltoorgreaterthanthedepthoftheenclosedarea
*asspecifiedinCGAB149InstallationCodes.Note:localCodesor
Regulationsmayrequiredifferentclearances

Page 20
C34-DV Gas Fireplace
Part No. XG0117B
Figure 29b.Wiringschematicforusingtwowallswitches:onetocontrol
thefireplaceandaanothertocontroloptionalfansfor the
fireplace.
Option A - Single Wall Switch
for STB Control Only
Use this wiring o tion when installing a single wall switch to control the
fire lace only. The switch on the yellow circuit controls the S ark To
Burner (STB) system. The blue circuit rovides ower to the o tional
fans and is always hot.
The fire lace can be safely wired this way, even if fans are not installed.
The fans can be added later, if desired.
Option B - Two Wall Switches
for STB and Fan Control
This wiring o tion is for installing two wall switches. The switch on the
yellow circuit controls the S ark To Burner (STB) system. The other
switch (blue circuit) is for controlling the o tional fans.
The fire lace can be safely wired this way, even if fans are not installed.
The fans can be added later, if desired.
Figure 29a.Wiringschematicforusingasinglewallswitchtocontrolthe
fireplace.Thecircuitthatsupplieselectricitytotheoptional
fansisalwayshot.
Figure 30. STBsystemwiringschematicshowingthewiringofthecontrolmodule
andgascontrolvalvetothehouseholdelectricalsupply.
System Wiring Schematic
WARNING:
UnplugthePowerCord Before
Resetting the Spill Switch
The s ill switch is located behind the
u er horizontal trims on the right hand
side of the fire lace. If the s ill switch tri s
it will shut down the fire lace (causing the
red button to o out).
You must disconnect the ower cord
from the PPO-D box (see fig. 3), before
resetting the switch. To reset the switch,
ush the red buttom in using the bottom
of a en or other blunt object.
Appendix B - Wiring for STB-Equipped fireplaces
