Montigo C38-DV User manual

nCheck local codes
and read all
instructions prior to
installation.
nLeave this manual
with the owner.
Gas Fireplace
C38-DV
Installation
Operation &
Maintenance
What To Do If You Smell Gas:
 Do not try to light any appliance.
 Do not touch any electrical switch; do not use any phone in your building.
 Immediately call your gas supplier from a neighbor's phone. Follow the gas
supplier's instructions.
 If you cannot reach your gas supplier, call the fire department.
Warning:
Improper installation, adjustment,
alteration, service or maintenance can
cause injury or property damage. efer to
this manual. For assistance or additional
information consult a qualified installer,
service agency or the gas supplier.
For Your Safety:
Do not store or use gasoline
or other flammable vapors
and liquids in the vicinity of
this or any other appliance.

Page 2
C38-DV Gas Fireplace
Part No. XG0118C
Introduction
Thank You for choosing a Montigo C-Series Fireplace.
About the C38 Fireplace:
The C38-D includes a 25,000 BTU dual burner with e bers and a
five piece cera ic logset. This odel is available in four versions.
C38DT - Top Vent, Millivolt Pilot
C38DR - Rear Vent, Millivolt Pilot
C38DT-I - Top Vent, Inter ittent Pilot (HSI)
C38DR-I - Rear Vent, Inter ittent Pilot (HSI)
The C38-DV is rated for Natural Gas at 25,000 BTU/H (7.33 Kilowatts)
Input or Propane at 25,000 BTU/H (7.33 Kilowatts) Input.
How to use this manual:
This anual covers all odels and unless otherwise specified, the
designation C38-DV refers to all odels. Sections which are specific to
a particular odel are arked with a sy bol,
plus the appropriate odel nu ber.
Warranty and Installation Information:
The Montigo warranty will be voided by, and Montigo disclai s any
responsibility for, the following actions:
nModification of the fireplace and/or co ponents including Direct-
Vent asse bly or glass doors.
nUse of any co ponent part not anufactured or approved by
Montigo in co bination with this Montigo fireplace syste .
nInstallation other than as instructed in this anual.
Consult your local Gas Inspection Branch on installation require ents
for factory-built gas fireplaces. Installation & repairs should be done by
a qualified contractor.
Installations in Canada ust confor to the current CAN/CGA B-
149.1 and .2 Gas Installation Code and local regulations. If the optional
air-circulating fan kit is installed, it ust be electrically grounded in
accordance with CSA C22.1 Canadian Electrical Code Part 1 and/or
Local Codes.
Installations in the USA ust confor to local codes, or in the
absense of local codes to the National Fuel Gas Code, ANSI Z223.1-
1988. If the optional air-circulating fan is installed, it ust be grounded
in accordance with local codes or, in the absence of local codes, with
the National Electrical Code, ANSI/NFPA 70-1987.
Table Of Contents
Introduction............................................................................. 2
Installation
Installing the Fireplace Shell ........................................... 3
Installing the Gasline ...................................................... 4
The Re ote Switch ....................................................... 4
Direct Vent Installation ................................................... 4
General Require ents ...................................... 4
Ter inations ..................................................... 4
Top Vent Models with horizontal venting ............ 6
Top Vent Models with vertical venting ................ 8
Rear Vent Models ............................................. 9
Construction around the fireplace
Facing ............................................................. 11
Mantels and Surrounds ................................... 11
Wiring ....................................................................... 11
Re oving and Installing the Door ................................ 12
Installing the Logset ..................................................... 13
Installing the Horizontal Tri ........................................ 13
Operation ........................................................................ 14 - 16
Maintenance ................................................................... 16 - 17
Warranty ................................................................................. 18
Appendix
A. Ter ination Locations ............................................. 19
CAUTIONS
Due to its high operating te peratures, the appliance
should be located out of traffic & away fro furniture and
draperies.
nChildren and adults should be alerted to the hazards
of the high surface te perature, which could cause
burns or clothing ignition.
nYoung children should be carefully supervised when
they are in the sa e roo as the appliance.
nClothing or other fla able aterials should not be
placed on or near the appliance.

Page 3
C38-DV Gas Fireplace
Part No. XG0118C
Installing The Fireplace Shell
The fireplace ay be installed in any location that aintains proper
clearances to air conditioning ducts, electrical wiring and plu bing.
Safety, as well as efficiency of operation, ust be considered when
selecting the fireplace location. Try to select a location that does not
interfere with roo traffic, has adequate ventilation, and offers an
accessible pathway for Direct Vent installation. Refer to page 4 - Vent
Installation for ore infor ation.
The fireplace di ensions are shown below:
Installation
When installing a shelf over the top of the fireplace, the following
guidelines ust be adhered to: For Rear Vent odels (C38-DR), the
ini u clearance fro the top of the fireplace to a shelf is 7 ¼". For
Top Vent odels (C38-DT), the ini u clearance is 15". (Minimum
1" clearance must still be maintained around the vent pipes.)
Figure 4. Framing for shelves over the fireplace.
Top VentRear Vent
Figure 3. Corner framing dimensions.
Figure 2. Framing dimensions.
* When sheetrock is
not used behind the
fireplace, fra ing
depth ay be
reduced to 16 7/8"
Framing
WARNING:
When this appliance is installed directly on carpeting, tile or any
co bustible aterial other than wood flooring, it ust be installed
on a etal or wood panel extending the full width and depth of
the appliance.
Top Vent
Front View Rear Vent
Clearances
These clearances apply to all di ensions except the framed opening,
where the clearance to co bustibles is 0". The C38-D clearances to
co bustible aterials are:
Top-RearVent* 7 ¼"
Top-TopVent 15"
Back 1"
Flue 1"
Sides 0"
Floor 0"
Mantle** 8"
* Clearance fro the top of the fireplace to a co bustible
ceiling within the fireplace enclosure.
** Refer to page 11s.
Unprotected co bustible walls which are perpendicular to the fireplace
opening, ust not project beyond the shaded area shown in Figure 20.
For protection against freezing te peratures, it is reco ended that
outer walls of the chase be insulated with a vapour barrier. This will
reduce the possibility of a cold-air convection current on the fireplace.
Figure 1. Fireplace dimensions.

Page 4
C38-DV Gas Fireplace
Part No. XG0118C
Vent Installation
This section covers the installation of direct venting and ter inations.
Installation Requirements
nC38-DV fireplaces are certified for use with Montigo Pre iu Series
(5" / 8") venting co ponents. The C38-DV Top ent ay be used
with Standard Series (4"/7") co ponents on vertical vent runs only.
nMini u 1" clearance to co bustibles required for vent pipes
nUse only certified Montigo vent components. (Use of other
parts will void the Montigo warranty, and ay i pede the
operation of the fireplace.)
nAll joints ust be secured with a ini u of two screws per joint
nVent ter inations ust not be recessed in walls or siding
nHorizontal runs ust be supported by a ini u of two supports
per horizontal run. A ini u of one screw on each side of
support is also required
nFlex vent sections ay be stretched up to 50% of their total length
(eg. a 24" section ay be stretched to 36")
nMaxi u horizontal run for a flex section with no vertical rise is 3 feet.
nFlex vent sections over 3 feet ust fall within the li its set by the
venting graph and ust have a ini u vertical rise of 3 inches
per foot of flex.
nSolid vent sections ay be cut less than half way fro the tapered end
nVenting co ponents can be used in any co bination of solid/rigid
pipe or flex pipe and in any orientation (Male connectors can face
in any direction)
ent Terminations
Selecting A Termination Location
Choosing your vent ter ination location will help to deter ine whether
you need to use a top vent or rear vent fireplace. Figure 6, below,
shows typical fireplace locations and the venting options they provide.
For a ore detailed diagra of allowed ter ination locations, see
Appendix A.
Cautions:Cautions:
Cautions:Cautions:
Cautions:
Installing The Gas Line
The gas line ust be installed before finishing the C38-DV Fireplace.
Natural Gas requires a ini u inlet gas supply pressure of 5.5"
W.C. & a anifold pressure of 3.5" W.C. Propane Gas requires a
ini u inlet gas supply pressure of 11" W.C. & a anifold pressure
of 10" W.C. Provision ust also be ade for a 1/8" N.P.T. plugged
tapping and be accessible for test gauge connection i ediately
upstrea of the gas supply controls to the appliance. The fireplace gas
connection and the ain operating gas valve is located behind the
re ovable brass tri at the botto of the unit and need only be
attached to the gas line with an approved fitting, as required by the
applicable installation codes.
Installation
Figure 6. Fireplace locations and vent terminations.
Note: After gas line is connected, each appliance connection,
valve and valve train ust be checked while under
nor al operating pressure with either a liquid solution, or
leak detection device, to locate any source of leak. Tighten
any areas where bubbling appears or leak is detected until
bubbling stops co pletely or leak is no longer detected.
DO NOT use a flame of any kind to test for leaks.
Installing The Remote Switch
The C38-D 's gas valve, located behind the lower brass tri , ay be
connected to a wall switch. The valve generates its own power on a
millivolt circuit. Use only low voltage wire, and DO NOT connect
any external power to it.
Refer to Figure 27 for wiring require ents.
Note: The switch location ust not exceed 30' fro the fireplace.
Figure 5. Gas line access.
The appliance and its individual shutoff valve ust be disconnected
fro the gas supply piping syste during any pressure testing of that
syste at test pressures in excess of 1/2 psig (3.5 kPa).
The appliance ust be isolated fro the gas supply piping syste by
closing its individual anual shutoff valve during any pressure testing of
the gas supply piping syste at test pressures equal to or less than 1/2
psig (3.5 kPa).
nVent ter inations can be very hot. If the ter ination is less than
7 feet above a public walkway, it should be fitted with a certified
Montigo Heat Guard. (Part no. PTKOG)
nDo not obstruct, or atte pt to conceal, the vent ter ination.
These actions will affect the operation of the fireplace, and ay
be hazardous.
nIn heavy snow areas, take extra care to prevent snow buildup
fro obstructing the vent ter ination.

Page 5
C38-DV Gas Fireplace
Part No. XG0118C
Installing Terminations with Built-In Frames
Installing Terminations with MSR Frames
12
12
1. Fra e the ter ination opening to 12" x 12".
2. Fasten the ter ination to the studs using a ini u of 4 screws.
11
11
1. Fra e the ter ination opening to 11" x 11".
2. Fasten the ter ination to the studs using a ini u of 4
screws.
Installing Terminations with MOSR Frames
1212
12
MOSR
1. Fra e the ter ination opening to 12" x 12".
2. Fasten the MOSR fra e to the interior side of the studs using a
ini u of 4 screws.
3. Insert the ter ination into the MOSR fra e as shown here, and
attach by screwing through the four pilot holes in the ter ination.
MSR
PTO-3
PTO-3F
PTO-3
PTKOG
1. Ensure that the two long ounting brackets are facing the
botto of the ter ination. (See inset). This will provide ore
heat protection at the top of the ter ination, where te peratures
are highest.
2. Attach to the faceplate of the ter ination using four sheet etal
screws.
Installing Heat Guards over Terminations
Installation

Page 6
C38-DV Gas Fireplace
Part No. XG0118C
Installation
Top Vent Venting Runs
For the C38-DV Top ent, there are two types of installations: A)
Through-The-Wall Installations and B) Vertical (Through-The-Roof)
Installations.
A) Through-The-Wall Installations
Before you install any venting, you ust deter ine whether the venting
run will be acceptable. Unacceptable venting can affect the fireplace's
co bustion.
The enting Graph
Measure the vertical height fro the fireplace hearth to the centre
of the ter ination and the horizontal run fro the fro the
fireplace flue collar to the wall flange of the ter ination. Plot on the
Venting Graph (Fig. 7) with an 'X'.
If the 'X' falls on or above the top boundary of the shaded area,
the installation is acceptable.
Example A: (Acceptable Installation)
If the vertical di ension fro the hearth is 84" and the
horizontal run to the wall flange of the vent ter ination is 36",
this would be an acceptable installation.
Example B: (Acceptable Installation)
If the vertical di ension fro the hearth is 90" and the
horizontal run to the wall flange of the vent ter ination is
120", this would be an acceptable installation.
Example C: (Unacceptable Installation)
If the vertical di ension fro the floor of the fireplace is 72"
and the horizontal run to the wall flange of the vent ter ina-
tion is 84", this would NOT be an acceptable installation.
Figure 7. Venting Graph
Figure 8. eat Shield. Install by sliding over the vent pipe where it
passes through combustible construction.
Heat Shields
Due to high flue te peratures, heat shields are required on all
C38-DV installations (except those with vertical ter inations) at
the point where the venting connects
to the ter ination. With the heat
shield, vent clearances can be
aintained at 1".
012 24 36 48 60 72 84 96 108 132120 144 156 168 180
Horizontal Run (in.)
Hearth
0
12
24
36
48
60
72
84
96
108
Available Top ent Components
The following venting co ponents are available for the C38-D
Top ent:
A - Ter ination PTO-3 (3" length)
PTO-3F (3" length)
B - Stucco Kits MSR (stucco fra e)
MOSR (stucco can)
BSR (brick can)
C - Flex sections PFL-1 (12" section)
PFL-2 (24" section)
PFL-3 (36" section)
PFL-4 (48" section)
D - Rigid sections PEXT-1 (12" /f section)
PEXT-2 (24" /f section)
PEXT-3 (36" /f section)
PEXT-4 (48" /f section)
PEXT-6 (72" /f section)
E - Elbows PEL-90MM ( / 90° elbow)
PEL-90FF (f/f 90° elbow)
PEL-90FM (f/ 90° elbow)
NOTES: All di ension lengths for vertical or horizontal runs are
easured fro center of the vent pipe.
Venting runs must fall within the li its set by the
venting graph (see Figure 7).

Page 7
C38-DV Gas Fireplace
Part No. XG0118C
Installation
Termination
Example 1:
For our shortest venting configuration use co ponents A and F (see
Figure 9a).
Figure 9a. Typical Top Vent installation. If the 90° elbow is
installed directly on the fireplace, the height to the
center of the termination is 43½".
Horizontal enting
Figure 9b. Typical Top Vent installation. The solid sections can be
used in various combinations to obtain the desired vent
run. The vent run ust fall within the limits set by the
venting graph.
90° Elbow
PEXT Section
Example 2:
Rigid sections and an elbow used in conjunction with 3 ft. flex section
(PFL-3) will, when extended in a five foot chase, allow for a axi u
horizontal run of twelve and one-half feet fro the centre of the
fireplace to outside wall and a ini u of 7'6" when retracted in
opposite direction (see Figure 10 and 11).
"C" flex sections and "D" rigid sections ay be used in conjunction with
one another to obtain different possible horizontal length installations.
NOTE: Flex section with no vertical rise ust not exceed axi u
horizontal length of 3 feet (see Figure 12). Flex runs over 3 feet ust
fall within the li its set by the venting graph, and ust have a ini u
vertical rise of 3" per foot of flex.
Figure 10. Extended Installation using a combination of solid and
flex venting. Use the vent graph to determine your
allowable run, then select appropriate components.
Figure 11. Retracted Installation using a combination of solid and
flex venting. Use the vent graph to determine your
allowable run, then select appropriate components.
Hearth
Termination
Exterior
Wall
3' max.
Flex Section
Hearth
Flex Section Termination
Exterior
Wall
126"
30" Max.
Solid Section w/
90°Elbow
Hearth
Flex Section
Solid Sections Termination
Exterior
Wall
150" max.
30" max.
RigidSection
PEL-90F/F Elbow RigidSection
Figure 12. orizontal flex installation with no vertical rise.

Page 8
C38-DV Gas Fireplace
Part No. XG0118C
Storm collar
Support ring
MEXT
Solid Section
Roof flashing
30' max.
* Minimum 1" clearance to all combustibles
Support plate
Firestop
Firestop
2' min.
MXT-10
Adaptor
MEXT
Flue
Collar
2' min.
Storm collar
Support ring
Roof flashing
30' max.
* Minimum 1" clearance to all combustibles
Support plate
Firestop
Installation
B. ertical (Through-The-Roof) Installations
5/8" with option for 4/7"
nVertical rise >12' can be reduced
nVertical Ter inations ust be installed:
•ini u 2' (two feet) above the highest point where
vent passes through the roof.
• ini u 6' (six feet) fro a echanical air inlet
• ini u 18" (1 1/2 feet) fro a parapet wall.
nMaxi u vent height is 30 feet above fireplace.
Note: Fla e characteristics will change if the axi u vent height
is used.
nMini u clearances 1" fro vent to all co bustible aterials ust
be aintained.
Figure 13.a Straight, vertical venting using required adaptor.
nA axi u of two offsets(each offset has two 90° bends) ay be
ade and shall not exceed total length of 25% of the vertical vent height,
when easured center to center of piping.
Exa ple: Typical vent installation.
20' vertical vent
2 - 2' offsets required
25% of 20' = 5' ax. offset allowed
This venting configuration eets require ents.
Figure 14a. Vertical venting with 1 offset (1 offset= two 90° bends).
30'max.
30'max.
Rigid Section
A
A.Male/Female
B.Female/Female
C.Male Flue Collar
B
C
Figure 13b. Reducing Vertical Vent from 5/8" to 4/7".
ent Restrictors
When venting vertically, Vent Restrictors ay be added to enhance the
burn characteristics of the fireplace.
Part Size 5"/8" enting 4"/7" enting
A - Termination n/a PVTK-1 MVTK-1
B - Flex sections 12" length PFL-1 MFL-1
24" length PFL-2 MFL-2
36" length PFL-3 MFL-3
48" length PFL-4 MFL-4
C - Solid sections 12" length PEXT-1 MEXT-1
24" length PEXT-2 MEXT-2
36" length PEXT-3 MEXT-3
48" length PEXT-4 MEXT-4
D - Support Ring
& Plate PSPXT-8 MSPXT-7
E - Firestop PS-8 FS-7
F - Roof Flashing (1/12-7/12 pt.) PRF-7 MRF-7
(7/12-12/12 pt.) PRF-12 MRF-12
G - Adaptor/ (5"/8" to 4"/7") PVA5487
Vent Reducer

Page 9
C38-DV Gas Fireplace
Part No. XG0118C
Installation
2. 45° Corner Installation.
Attach an PEL-45 (45° elbow) directly onto the flue collar. Cut the
PXT-20 to suit, and attach it to the PEL-45. Slide the fireplace into
position and attach to the ter ination. Maximum horizontal run
must not exceed 20".
Rear Vent Venting Runs
The C38-D Rear ent has three possible installations which do not
require vertical lift:
Heat Shields
Due to high flue te peratures, heat shields are required on all C38-DV
installations (except those with vertical ter inations) at the point where
the venting connects to the ter ination. With the heat shield, vent
clearances can be aintained at 1". *Heat Shields are included
See Figure 8.
1. Straight Installation.
The height fro the hearth to the center of the ter ination is
28 3/8". C38-DV Rear Vent versions are supplied with a 20"
extension pipe (PXT-20) with fe ale/fe ale connections. For
shorter installations, cut the PXT-20 to the desired length.
For extended installations, use the PXT-20 section as supplied for a
20" vent run.
Note: For Rear Vent odels, axi u horizontal run with no
vertical lift ust never exceed 20".
Flue Collar
Heat Shield
EXT-18
Termination
Figure 15. Extended installation.
Heat Shield
EXT-18
Termination
EEL-45
Elbow
FlueCollar
Figure 16. Corner installation.
3. Corner Installation — 45° or less.
Use an PTO-3 ter ination and an PFL-1 or PFL-2 (12" or 24"
co pressed length) and a fra e, if appropriate. Flex ay be
turned to obtain desired degree of angle required but ust not
exceed 45°.
Figure 17. Flex installation.
Heat Shield
Termination
Flex
Section
Flue Collar
PXT-20
PXT-20
PEL-45
Figure 14b. Vertical venting with 2 offsets (1 offset= two 90° bends).
2' min.
2'
Storm collar
Roof flashing
30' max.
* Minimum 1" clearance to all combustibles
Support straps or
support plate & ring
Firestop
Firestop
Firestop
Support plate
& ring
30'max.

Page 10
C38-DV Gas Fireplace
Part No. XG0118C
Installation
B. Multi-Elbow Installations
For ore diffiicult installation situations, the C38-DV Rear Vent ay
be installed with two — 90° elbows and up to 15' of horizontal run. If
using this installation option, you ust adhere to the following
guidelines:
nthe first 90° elbow ust be placed directly on the flue collar
nyou ust have a ini u vertical lift of 50" ( easured fro
the hearth)
nyour vent run ust fall within the li its set by Figure 18a
Before you install any venting, you ust deter ine whether the
venting run will be acceptable. Unacceptable venting can affect the
fireplace's co bustion.
The enting Graph
Measure the vertical height fro the fireplace hearth to the centre
of the ter ination and the horizontal run fro the fro the fireplace
flue collar to the wall flange of the ter ination. Plot on the Venting
Graph (Fig. 18a) with an 'X'.
If the 'X' falls on or above the top boundary of the shaded area, the
installation is acceptable.
Example A: (Acceptable Installation)
If the vertical di ension fro the hearth is 84" and the
horizontal run to the wall flange of the vent ter ination is 36",
this would be an acceptable installation.
Example B: (Acceptable Installation)
If the vertical di ension fro the hearth is 90" and the
horizontal run to the wall flange of the vent ter ination is 126",
this would be an acceptable installation.
Example C: (Unacceptable Installation)
If the vertical di ension fro the floor of the fireplace is 78"
and the horizontal run to the wall flange of the vent ter ination
is 108", this would NOT be an acceptable installation.
Figure 18a. C38-DV Rear Vent Venting Graph
012 24 36 48 60 72 84 96 108 132120 144 156 168 180
Horizontal Run (in.)
Hearth
0
12
24
36
48
60
72
84
96
108
Installation Of Rear Vent DV
C38-DV Rear Vent versions are supplied with an PXT-20 (fe ale/
fe ale) section. In addition, the following venting co ponents are
available for Rear ent installations:
A - Ter ination PTO-3 (3" length)
PTO-3F (3" length)
B - Stucco Kits MSR (stucco fra e)
BSR-4 (4" brick fra e)
BSR-6 (6" brick fra e)
MOSR (stucco can)
C - Flex sections PFL-1 (12" section)
PFL-2 (24" section)
PFL-3 (36" section)
PFL-4 (48" section)
D - Solid sections PEXT-1 (12" section)
PEXT-2 (24" section)
PEXT-3 (36" section)
PEXT-4 (48" section)
E - 90 degree elbow PEL-90MM ( / 90° elbow)
PEL-90FF (f/f 90° elbow)
PEL-90FM (f/ 90° elbow)
PEL-45FM (f/ 45° elbow)
Figure 18b. Multi-elbow installation. Distance ' ' must be a
minumum of 50". The vent run must comply with figure
18a.
NOTES: All di ension lengths for vertical or horizontal runs
are easured fro center of the vent pipe.
Venting runs must fall within the li its set by the
venting graph (see Figure 18a).
8"
H
L
18"

Page 11
C38-DV Gas Fireplace
Part No. XG0118C
Finishing Around the Fireplace
Co bustible antels and ouldings ay be safely installed over the top
and on the front of the fireplace provided that they do not project
beyond shaded area shown in Figure 19. Side wall clearances are 3".
Co bustible surrounds ay be installed with 3" clearance to the side of
the fireplace as shown in Figure 20.
Fireplace Facing
When selecting the finish aterial for your fireplace, it is i portant to
re e ber the following: TRIMS MUST NOT BE OBSTRUCTED IN
ANY WAY - to do so restricts the air supply for the control
compartments and heat exchanger it also prevents access for
servicing controls.
The face of the fireplace ay be painted to atch the roo decor,
provided you use a heat-resistant paint. Decorative facing ust not
extend past the fireplace opening at all, because it will interfere with the
access to retainers for re oval of glass door.
Installation
Figure 19a. Combustible mantles and facings.
Mantels, Hearth, & Surrounds
NOTE: National Canadian Gas Association antel test require ents
are for fire hazard prevention to co bustible aterials.
NOTE: It is not required that you install a mantel, hearth or surround.
New technology, to eet consu er and govern ent de ands for the
wise use of energy, has pro pted us to anufacture any odels of
fireplaces which are hot, fuel and energy efficient.
Please be aware; te peratures over the antel will rise above nor al
roo te perature and walls above fireplace ay be hot to touch.
We reco end careful consideration be given to the effects of
elevated antel te peratures which ay be in excess of product
design, for exa ple: candles, plastic or pictures. This can cause
elting, defor ation, discoloration or pre ature failure of T.V. and
radio co ponents.
Painting:
Special care is reco ended by the Master Painters and Decorators
Association, when painting the fireplace surrounds, to select and apply
a quality Alkyd sealer prior to the applying of latex paints. This is to
prevent leaching of water fro evaporation and causing a brownish
staining effect to paint over coats.
Sheetrock/
Drywall
Header
3
4
5
°
Figure 20. Combustible surrounds.
Wiring
Gas Control and Pilot Wiring C34-DV-I
Honeywell (Q3450)
Pilot Assembly
Pilot Electrical
Harness Connector
Honeywell Gas
Control (SV9501M)
Gas Control
Connector Fuse
Limit
Switch Wall
Switch
Fan Plug
Receptacle
Junction Box
Junction Box Cover
White
Black
Green
40 VA
Transformer
115VAC
24VAC
Grnd Screw
Figure 21. Wiring for the C38-DV-I with oneywell gas control and
pilot.

Page 12
C38-DV Gas Fireplace
Part No. XG0118C
Removing and Installing
the Door
Removing the Door:
Re ove the tri (as described on the next page) to access the door
latches. Open the latches by pulling Part A upwards and towards you
to disengage Part B fro the door. Lift Part B clear of the door.
Repeat for all three latches. Be sure to hold the door carefully so it
does not fall. (See figure 23a.)
Installation
Once the three latches are unhinged, tilt the top of the door forward
and lift it out of the slots. See figures 23b and 23c.
Figure 23a. Operating the door latches.
Figure 22a. Wiring for optional air circulating fan kit.
G
L1-WH
L2-BLK
Quick Connect
plug to motor
Wiring for the optional Fan Kit
All C38-DV fireplaces ay be equipped with optional fan kits (Part
no. RFK1001, RFK1003, RFK1006 or RFK1007)for circulating heat
into the living space.
Installations in Canada which e ploy the fans ust be electri-
cally grounded in accordance with CSA C22.1 Canadian Electrical
Code Part 1 and/or Local Codes.
Installations in the USA which e ploy the fans ust be
grounded in accordance with local codes or, in the absence of
local codes, with the National Electrical Code, ANSI/NFPA 70-
1987.
For ore infor ation see the Fan Kit Installation Guide included
with the fan kit.
NOTE: If any of the original wire supplied with the appliance is replaced, it
ust be replaced with the sa e type, or its equivalent.
Figure 22b. Wiring schematic for optional fan kit.
115/1/60 Supply
G L1 L2
Figure 23b. Removing the door.

Page 13
C38-DV Gas Fireplace
Part No. XG0118C
Installation
NOTES:
nIf logs are not placed properly, excessive sooting will result.
nThe surface of the logs will crack due to the heat from the
flames. This is a normal occurance.
E bers
Log 'D' Log 'E'
Fla e Shaper
Log 'A'
Log 'C' Log 'B'
Figure 23c. Removing the door.
Re-installing the door:
To re-install the door, tilt the top edge towards you and line up the tabs
of the botto of the door with the slots on the fireplace. Place the tabs
into the slots, and tilt the top of the door back towards the fireplace as
far as it will go. Close the latches by hooking Part B onto the groove at
the top of the door and pushing Part A down co pletely.
Figure 25. Installing the horizontal trim pieces.
Installing the Trim & Baffle
The fireplace is shipped with 6 horizontal tri pieces (3 upper and 3
lower), which ust be field-installed.
Install the tri by placing the top edge of the tri over to the
retainer clips on either side of the fireplace. Push the botto edge
fir ly inwards and the tri will snap on. (See figure 25) Re e ber to
slide the baffle into the top tri piece . (See Inset)
Note: Baffle should rest on top of the tabs.
Inset. Slide in baffle
before installing top trim.
Installing the Log Set
Installing the Logs:
The C38-D is supplied with five cera ic fibre logs. Unpack the logs
and handle the very carefully.
1. Re ove the door cover and the glass door.
2. Place the Back log onto the back log rest as shown below in figure
24a. The log has lip on the botto which fits into the slot on the log rest.
3. Place the Front log onto the front log rest as shown in figure 24a.
Center the log fro side to side, and push it against the back of
the log rest. Carefully push the log onto the etal spikes on the log rest.
4. Place the top logs in position as shown in figure 24b, place the
centre log down first, then the right and left logs.
5. Start the fireplace. If the fla e appears satisfactory, replace the
glass door and door cover.
Figure 24a. Positioning for the front and back logs.
Figure 24b.Proper log placement.

Page 14
C38-DV Gas Fireplace
Part No. XG0118C
WARNING: If you do not follow these instructions exactly, a fire or explosion
may result causing property damage, personal injury or loss of life.
nIf you cannot reach your gas supplier, call the Fire
Depart ent.
C. Use only your hand to push in or turn the gas control knob.
Never use tools. If the knob will not push in or turn by
hand, don't try to repair it, call a qualified service technician.
Force or atte pt to repair ay result in a fire or explosion.
D. Do not use this appliance if any part has been under water.
I ediately call a qualified service technician to inspect the
appliance and to replace any part of the control syste , and
any gas control which has been under water.
A. This appliance has a pilot which ust be lighted by hand.
When lighting the pilot, follow these instructions exactly.
B. BEFORE LIGHTING s ell all around the appliance area for
gas. Be sure to s ell next to the floor because so e gas is
heavier than air and will settle on the floor.
What To Do If You Smell Gas:
nDo not try to light any appliance.
nDo not touch any electrical switch; do not use any
phone in your building.
nI ediately call your gas supplier fro a neighbour's
phone. Follow the gas supplier's instructions.
To Turn Off Gas To Appliance:
Operation - Model C38-DV
3. Push in gas control knob slightly and turn clockwise
to "Off". Do not force.
4. Flip up the lower tri .
1. Turn off re ote switch.
2. Flip down the lower tri .
1. STOP! Read the safety infor ation above on this label.
2. Flip down the lower tri s.
3. Push in gas control knob and turn clockwise to
"OFF."
4. Wait five (5) inutes to clear out any gas. S ell for gas,
including near the floor. If you then s ell gas, STOP!
Follow "B" in the safety infor ation above on this label. If
you don't s ell gas, go to the next step.
5. Locate pilot burner (See illustration at right.) and follow
steps below.
6. Turn knob on gas control counterclockwise to
"PILOT."
7. Push in gas control knob co pletely and hold. Light with
Piezo Igniter button. Continue to hold the control knob in for
about (1) inute after the pilot is lit. Release the knob and it
will pop back up. Pilot should re ain lit. If it goes out repeat
steps 3 through 8.
nIf knob does not pop up when released. Stop and
i ediately call your service
technician or gas supplier.
nIf the pilot will not stay lit after
several tries, turn the gas control
knob to "OFF" and call your service
technician or gas supplier.
8. Push in gas control knob and turn counterclockwise
to "ON."
9. Flip up the lower tri .
10.Turn on re ote switch to ignite fire.
Lighting Instructions:
C38-DV
with Millivolt (Standing) Pilot
For Your Safety - READ BEFORE LIGHTING:
Gas Control Knob
(Shown in "Pilot" postion.) NOTE: Knob cannot be turned from
"PILOT" to "OFF" unless knob is
pushed in slightly. Do not force.

Page 15
C38-DV Gas Fireplace
Part No. XG0118C
For Your Safety - READ BEFORE LIGHTING:
To Turn Off Gas To Appliance:
Lighting Instructions:
■If you cannot reach your gas supplier, call the Fire
Depart ent.
C. Use only your hand to push in or turn the gas control knob.
Never use tools. If the knob will not push in or turn by
hand, don't try to repair it, call a qualified service techni-
cian. Force or atte pt to repair ay result in a fire or
explosion.
D. Do not use this appliance if any part has been under
water. I ediately call a qualified service technician to
inspect the appliance and to replace any part of the control
syste , and any gas control which has been under water.
A. This appliance is equipped with an ignition syste that
lights the pilot burner auto atically. Do not attempt to
light the pilot by hand.
B. BEFORE LIGHTING s ell all around the appliance area
for gas. Be sure to s ell next to the floor because so e
gas is heavier than air and will settle on the floor.
What To Do If You Smell Gas:
■Do not try to light any appliance.
■Do not touch any electrical switch; do not use any
phone in your building.
■I ediately call your gas supplier fro a neighbour's
phone. Follow the gas supplier's instructions.
1. Turn off re ote switch.
2. Flip down the lower tri .
3. Turn the switch on the gas control to "Off".
4. Flip up the tri .
1. STOP! Read the safety infor ation above on this label.
2. Flip down the lower tri s.
3. Turn switch on the gas control to OFF".
4. Wait 5 inutes to clear out any gas. If you s ell gas,
STOP! Follow "B" in the safety infor ation above on this
label. If you don't s ell gas, go to the next step.
5. Turn switch on the gas control to "ON". NOTE: This unit is
equipped with an ignition syste that lights the pilot burner
auto atically. Do not attempt to light the pilot by hand.
6. Turn on wall switch.
7. Flip up the lower tri .
8. If the fireplace does not operate, follow the instructions "To
Turn Off Gas To Appliance" and call your service techni-
cian or gas supplier.
with Honeywell Electronic Ignition
WARNING: If you do not follow these instructions exactly, a fire or explosion may
result causing property damage, personal injury or loss of life.
Operation - Model C38-DV-I
C38-DV-I
Gas
Inlet
Gas Control Switch
Shown in "On" Position

Page 16
C38-DV Gas Fireplace
Part No. XG0118C
Maintenance
WARNING:
Do not atte pt to clean glass when hot.
Do not clean glass with abrasive aterials as any glass
etching ay cause pre ature glass failure.
CAUTIONS
nFireplace gas control ust be in the “OFF” position and pilot
and ain burners extinguished when cleaning appliance with
a vacuu .
nDoors and logs can get very hot. Handle only when cool.
General
nHave the fireplace installation inspected yearly, including a
visual check of the vent syste , the burner and the pilot fla e.
For your convenience a 1/8" anifold pressure tap is supplied
on the gas valve for a test gauge connection. See Figure 27.
nFor Natural Gas this appliance requires a ini u inlet
pressure of 5.5" W.C. and a anifold pressure of 3.5" W.C.
nFor Propane Gas this appliance requires a ini u inlet
pressure of 11" W.C. and a anifold pressure of 10" W.C.
nAlways keep the fireplace area clear and free of co bustible
aterials, as well as gasoline and other fla able vapours and
liquids.
nDo not use this appliance if any part has been under water.
I ediately call a qualified service technician to inspect the
appliance and to replace any part of the control syste and any
gas control which has been under water.
Operation
Lighting Instructions
See pages 14 and 15.
Burner Adjustment
The C38-DV ( illivolt odel only) is equipped with an adjustable
burner, allowing you to raise or lower the fla es. To adjust the fla es,
locate the black knob arked 'Hi-Lo', in the centre of the gas control
valve (See Figure 26). The front burners are not adjustable.
nTo raise the fla e height, turn the black knob (located behind the
lower tri ) counterclockwise.
nTo lower the fla e height, turn clockwise.
Figure 26. ' i-Lo' Adjustment on the C38-DV's gas valve.
Cleaning
When the fireplace is first activated, there ay be so e s oking
and a visible fil ay be left on the glass. This is a nor al
condition, and is the result of burning of protective coatings on
new etal.
nGlass ust be cleaned periodically to re ove any fil (which
is a nor al biproduct of co bustion) which ay be visible.
Fil can easily be re oved by re oving the door, as shown
on page 12-13. Handle the door carefully, and clean it with
non-abrasive glass cleaners. One of the ost effective
products is Kel Ke .
nSilicone seals on inner door during initial firing will "off gas",
leaving a visual deposit of a white substance on co bustion
cha ber walls. This can easily be re oved using nor al
household products.
nUse a vacuu cleaner or whisk broo to keep the control
co part ent, burner, and firebox free fro dust and lint.
nLogs ay be cleaned periodically with a vacuu to re ove
soot or other conta inates.
Note: C38-DV-I models (electronic ignition) do not feature
hi/lo adjustment.

Page 17
C38-DV Gas Fireplace
Part No. XG0118C
Maintenance
Gas Control Valve (C38-DV)
Figure 27 Sit Nova 820 gas valve.
Pilot Burner Adjustment (C38-DV)
1. Locate Pilot Adjust ent Screw. (See figure 27.)
2. Adjust pilot screw to provide properly sized fla e as shown in figure
28).
3. After installing or servicing, leak test with a soap solution with ain
burner on. Coat pipe and tubing joints, gasket etc. with soap solution.
Bubbles indicate leaks. Tighten any areas where the bubbles
appear until the bubbling stops co pletely.
Figure 28. Pilot Burner
Manifold Pressure
Test Connection
Pilot Adjustment Screw
Inlet
Pressure
Power
Generator
Wall Switch
Troubleshooting
The following is a troubleshooting chart of possible proble s:
PROBLEM CORRECTI E ACTION
Noisy Pilot Fla e Locate pilot adjuste ent screw on
gas control valve. Fla e is decreased by
turning adjust ent screw clockwise.
Pilot won’t ignite Disconnect re ote wires and try to
light pilot. If pilot now works, re ote
connections are faulty. Check wiring
diagra figure 27.
Main burner will 1. Check wiring (see figure 27).
not light 2. Check wall switch for proper
connection.
C38-DV
Troubleshooting
If your fireplace still does not operate correctly, consult your dealer or
the anufacturer.
All service and repairs should be performed by a qualified
agency.
All spare parts, optional fans, and optional tri finishes are available
fro your local dealer or the anufacturer.
HONE WELL SV 9500 /SV9600
Troubleshooting Sequence
NOTE: Before Troubleshooting, Familiarize Yourself With
The Startup And Checkout Procedure.
· Turn Gas Supply off
· Set thermostat to
call for heat
SV9500/SV9600
is powered
(24 VAC nominal)
NO
NO
NO
NO
NO
ES
ES
ES
ES
ES
ES
ES
NO
NO
NO
START
Igniter warms up
and glows red.
Pilot Valve opens.
Turn gas on.
Pilot Burner lights?
Main Valve opens?
SYSTEM OK
Unplug Pilot Burner Cable,
Measure Voltage at
SV9500/SV9600 HSI
Terminals (24 VAC
Nominal, See INSET)
eplace Igniter/
Flame od Assembly.
eplace Igniter/
Flame od Assembly.
eplace SV9500/SV9600
Measure Voltage to SV9500
/SV9600. Voltage must
be at least 19.5 VAC
Discard old Igniter/
Flame od Assembly.
eplace Igniter/Flame
od Assembly and retain.
estart Troubleshooting
Sequence. Does main
valve open?
eplace
SV9500/
SV9600
Check
Transformer
Line Volt
Supply
eplace
SV9500/
SV9600.
Save old
Igniter/Flame
od Assembly
for service.
INSET
HSI
Terminals
CHECK:
· Line voltage power
· Low voltage transformer
· Limit Controller
· Thermostat
· Wiring
· Air proving switch on
combustion air blower system
· Vent damper (if used) is open
and end switch made
C34-DV-I

Page 18
C38-DV Gas Fireplace
Part No. XG0118C
The WarrantyThe Warranty
The WarrantyThe Warranty
The Warranty
The Co panies warrants the Montigo Gas Appliance to be free fro defects in aterials and work anship at the ti e of anufacture. On the Montigo, there is a ten-
year warranty on the firebox and its co ponents, a five-year warranty on the ain burner and pilot burner, and a one-year warranty on the gas control valve and fibre logs.
Glass, plated/painted finishes, and refractory lining are exe pt.
Remedy And Exclusions
The coverage of this Warranty is li ited to all co ponents of the Gas Appliance anufactured by The Co panies.
This Warranty only covers Montigo Gas Appliances installed in the United States or Canada.
If the co ponents of the Gas Appliance covered by this Warranty are found to be defective within the ti e fra e stated (see The Co panies right of investigation outlined
below). The Co panies will, at its option, replace or repair defective co ponents of the Gas Appliance anufactured by The Co panies at no charge, and will also pay
for reasonable labour costs incurred in replacing or repairing co ponents. If repair or replace ent is not co ercially practical, The Co panies will, at its option, refund
the purchase price of the Montigo Gas Appliance.
This Warranty covers only parts and labour as provided above. In no case shall The Co panies be responsible for aterials, co ponents, or construction which are not
anufactured or supplied by The Co panies, or for the labour necessary to install, repair or re ove such aterials, co ponents or construction. All replace ent or repair
co ponents will be shipped F.O.B. the nearest The Co panies factory.
Qualifications To The WarrantyQualifications To The Warranty
Qualifications To The WarrantyQualifications To The Warranty
Qualifications To The Warranty
The Gas Appliance Warranty outlined above is further subject to the following qualifications:
(1) The Gas Appliance ust be installed in accordance with The Co panies installation instructions and local building codes. The Warranty on this Montigo Gas Appliance
covers only the co ponent parts anufactured by The Co panies. The use of co ponents anufactured by others with this Montigo Gas Appliance could create
serious safety hazards, ay result in the denial of certification by recognized national safety agencies, and could be in violation of local building codes. This warranty
does not cover any da ages occurring fro the use of any co ponents not anufactured or supplied by The Co panies
(2) The Montigo Gas Appliance ust be subjected to nor al use. The Gas Appliances are designed to burn gas only. Burning conventional fireplace fuels such as wood,
coal or any other solid fuel will cause da age to the Gas Appliance, will produce excessive te peratures and will result in a fire hazard.
Limitations On LiabilityLimitations On Liability
Limitations On LiabilityLimitations On Liability
Limitations On Liability
It is expressly agreed and understood that The Co panies sole obligation, and purchaser's exclusive re edy under this Warranty, under any other warranty, expressed
or i plied, or in contract, tort or otherwise, shall be li ited to replace ent, repair, or refund, as specified above.
In no event shall The Co panies be responsible for any incidental or consequential da ages caused by defects in its products, whether such da age occurs or is discovered
before or after replace ent or repair, and whether or not such da age is caused by The Co panies negligence. So e states do not allow the exclusion or li itation of
incidental or consequential da ages, so the above li itation or exclusion ay not apply to you. The duration of any i plied warranty with respect to this Montigo Gas Appliance
is li ited to the duration of the foregoing warranty. So e states do not allow li itation on how long an i plied warranty lasts, so the above ay not apply to you.
Investigation Of Claims Against WarrantyInvestigation Of Claims Against Warranty
Investigation Of Claims Against WarrantyInvestigation Of Claims Against Warranty
Investigation Of Claims Against Warranty
The Co panies reserves the right to investigate any and all clai s against this Warranty and to decide upon ethod of settle ent.
The Co panies Are Not Responsible For Work Done Without Written Consent
The Co panies shall in no event be responsible for any warranty work done without first obtaining The Co panies written consent.
Dealers Have No Authority To Alter This Warranty
The Co panies e ployees and dealers have no authority to ake any warranties nor to authorize any re edies in addition to or inconsistent with those stated above.
How THow T
How THow T
How To Register A Claim Against Wo Register A Claim Against W
o Register A Claim Against Wo Register A Claim Against W
o Register A Claim Against Warrantyarranty
arrantyarranty
arranty
In order for any clai under this Warranty to be valid, The Co panies ust be notified of the clai ed defect in writing or by telephone, as soon as reasonably possible
after the defect is discovered. Clai s against this Warranty in writing should include the date of installation, and a description of the defect.
Other RightsOther Rights
Other RightsOther Rights
Other Rights
This Warranty gives you specific legal rights, and you ay also have other rights which vary fro state to state.
NOTE: The Companies as stated above refer to - Canadian Heating Products Inc. and/or Montigo Del Ray Corp.
Canadian Heating Products Inc. and/or Montigo DelRay Corp. reserves the right to make changes at any time, without
notice, in design, materials, specifications, prices and also to discontinue colors, styles and products.
Warranty

Page 19
C38-DV Gas Fireplace
Part No. XG0118C
Appendix A - Termination Locations
A= clearancetotheterminationframeabovegrade,veranda,porch,
deck,orbalcony[16inches(41cm)minimum]
B= clearance to door, or sides and top of window, that may be opened
[16inches(41cm)minimumforappliances
≤≤
≤≤
≤ 100000BTU/H(30kW)]
C= clearance to bottom of window that may be opened horizontally
[36inches(92cm)minimumforappliances
≤≤
≤≤
≤ 100000BTU/H(30kW)]
D= no clearance to permanently closed window when installed with
approvedglasspenetrationtermination
E= clearancetopermanentlyclosed window[16inches41 cm
recommendedtopreventcondensation onwindow]
F= verticalclearancetoventilatedsoffitlocatedabovethetermination
withinahorizontal distance of 2 feet (61 cm) from the centrelineof
thetermination[22inches(56cm)minimum]
G= clearancetounventilatedsoffit
[16inches(41cm)minimumtonon-combustibles]
[22inches(56cm)minimum to combustibles]
H= clearancetooutsidecorner [9inches(23cm) minimum]
I= clearancetoinsidecorner [12inches(31cm)minimum]
J= *not to be installed above a meter/regulator assembly within
40"(103cm)horizontallyfromthecentrelineoftheregulator
K= clearancetoserviceregulatorventoutlet[3 feet minimum inthe
United States] [*6 feet (1.8 m) minimum in Canada]
L = clearance to nonmechanical air supply inlet to building or the
combustionairinletto anyotherappliance[16inches(41 cm)
minimumforappliances
≤≤
≤≤
≤ 100000BTU/H(30kW)]
M= clearancetomechanicalairsupplyinlet
[*6 feet (1.8 m) minimum]
N= †clearanceabovepavedsidewalkorapaveddrivewaylocatedon
public property [*7 feet (2.1 m) minimum]
P= clearanceunderveranda,porch,deck,orbalcony
[16inches(41 cm)minimum‡tonon-combustibles]
[22inches(56 cm)minimum‡tocombustibles]
Q= clearanceabovearoof[24inches(61cm)minimum]
R= clearancetoadjacentwallsandneighbouringbuildings
[18inches(46cm)minimum]
S= clearancefromcornerinrecessedlocation
[12inches(31cm)minimum]
T= maximumdepthinrecessedlocation
[48inches(122cm)minimum]
U= minimum width for back wall of recessed location
[24 inches (61 cm) minimum]
V= nohorizontalclearancebetweentheframesoftwoterminations
thatarelevel.
W= horizontalclearancebetweentheframesoftwoterminationsthat
are not level. [36 inches (92 cm) minimum]
†aventshall notterminatedirectlyaboveasidewalkorpaved
driveway which is located between two single family dwellings
andservesbothdwellings
‡onlypermitted if veranda, porch, deck, or balconyhas an open
sidethatisequalto or greater thanthedepthoftheenclosed area
*asspecifiedinCGAB149 InstallationCodes.Note:localCodesor
Regulationsmayrequiredifferentclearances

Canadian Heating Products Inc.
Langley, BC V4W 4A1
Montigo Del Ray Corp.
Ferndale, WA 98248
XG0118C Rev. 00 - 04/03
