Montigo H34D Owner's manual

■Check local codes
and read all
instructions prior to
installation.
■Leave this manual
with the owner.
Gas Fireplace
H34D
Installation
Operation &
Maintenance
What To Do If You Smell Gas:
• Do not try to light any appliance.
• Do not touch any electrical switch; do not use any phone in your building.
• Immediately call your gas supplier from a neighbor's phone. Follow the gas
supplier's instructions.
• If you cannot reach your gas supplier, call the fire department.
Warning:
Improper installation, adjustment,
alteration, service or maintenance can
cause injury or property damage. Refer to
this manual. For assistance or additional
information consult a qualified installer,
service agency or the gas supplier.
For Your Safety:
Do not store or use gasoline
or other flammable vapors
and liquids in the vicinity of
this or any other appliance.

Page 2
H34D Gas Fireplace
Part No. XG0130
Introduction
ThankYouforchoosingaMontigoGasFireplace.
About this Fireplace:
TheH34Disan18,000BTUfireplacewithapan-styleburnerand
glowingembers.ThisfireplacecanbeconvertedtobothaTopVentor
RearVentapplication,anditisavailableintwomodels.
H34D; ToporRearVent,MillivoltPilot
H34D-I;ToporRearVent,IntermittentPilot(HSI)
H34D-MH; Topor RearVent,MobileHome
For Mobile Home Approved Models See Appendix B
TheH34DisratedforNaturalGasat18,000BTU/H(5.28Kilowatts)
InputorPropaneat18,000BTU/H(5.28Kilowatts)Input.
How to use this manual:
Thismanualcoversinstallation,operationandmaintenance.Lighting,
operationandcareofthisfireplacecanbeeasilyperformedbythe
homeowner.However,allinstallationandserviceworkshouldbe
performedbyaqualifiedorlicensedinstaller,plumber,orgasfitterwho
isqualifiedorlicensedbythestate,province,region,orgoverning
bodyinwhichtheapplianceisbeinginstalled.
Thismanualcoversallmodelsandunlessotherwisespecified,the
designationH34Dreferstoallmodels.Sectionswhicharespecifictoa
particularmodelaremarkedwitha symbol, plustheappropri-
atemodelnumber.
Warranty and Installation Information:
TheMontigowarrantywillbevoidedby,andMontigodisclaimsany
responsibilityfor,thefollowingactions:
Modificationofthefireplaceand/orcomponentsincludingDirect-Vent
assemblyorglassdoors.
Useofanycomponentpartnotmanufacturedorapprovedby
MontigoincombinationwiththisMontigofireplacesystem.
Installationotherthanasinstructedinthismanual.
ConsultyourlocalGasInspectionBranchoninstallationrequirementsfor
factory-builtgasfireplaces.Installation&repairsshouldbedonebya
qualifiedcontractor.
InstallationsinCanadamustconformtothecurrentCAN/CGAB-
149.1and.2GasInstallationCodeandlocalregulations.Iftheoptional
air-circulatingfankitisinstalled,itmustbeelectricallygroundedin
accordancewithCSAC22.1CanadianElectricalCodePart1and/or
LocalCodes.
InstallationsintheUSAmustconformtolocalcodes,orinthe
absenceoflocalcodestotheNationalFuelGasCode,ANSIZ223.1-
1988.Iftheoptionalair-circulatingfanisinstalled,itmustbegroundedin
accordancewithlocalcodesor,intheabsenceoflocalcodes,withthe
NationalElectricalCode,ANSI/NFPA70-1987.
Table Of Contents
Introduction ............................................................................2
Installation
InstallingandFramingtheFireplace ...............................3
InstallingtheGasline.......................................................4
TheRemoteSwitch ........................................................4
DirectVentInstallation ....................................................4
GeneralVentingRequirements ..........................4
Terminations......................................................5
ConvertingtoToporRearVentmodel...............6
VentingforTopVentmodels ..............................7
VentingforRearVentmodels...........................10
Constructionaroundthefireplace
Facing .............................................................12
MantelsandSurrounds.................................... 12
Wiring .......................................................................13
InstallingOptionalFans.................................................13
RemovingandInstallingtheDoor.................................13
InstallingtheLogset ......................................................14
InstallingtheHorizontalTrim .........................................14
Operation ........................................................................15 - 17
Maintenance ...................................................................17 - 18
Warranty ................................................................................19
Appendix
A.TerminationLocations ..............................................20
B.MobileHomeApprovedModels ...............................21
CAUTIONS
Duetoitshighoperatingtemperatures,theapplianceshould
belocatedoutoftraffic&awayfromfurnitureanddraperies.
Children and adults should be alerted to the hazards of
the high surface temperature, which could cause burns
or clothing ignition.
Young children should be carefully supervised when
they are in the same room as the appliance.
Clothing or other flammable materials should not be
placed on or near the appliance.

Page 3
H34D Gas Fireplace
Part No. XG0130
Installing The Fireplace Shell
Thefireplacemaybeinstalledinanylocationthatmaintainsproper
clearancestoairconditioningducts,electricalwiringandplumbing.
Safety,aswellasefficiencyofoperation,mustbeconsideredwhen
selectingthefireplacelocation.Trytoselectalocationthatdoesnot
interferewithroomtraffic,hasadequateventilation,andoffersan
accessiblepathwayforDirectVentinstallation.Refertopage4-Vent
Installationformoreinformation.
Thefireplacedimensionsareshownbelow:
Installation
Wheninstallingashelfoverthetopof thefireplace,thefollowing
guidelinesmustbeadheredto: ForRearVentapplicationstheminimum
clearancefromthetopofthefireplacetoashelfis11".ForTopVent
applications,theminimumclearanceis171/2".(Minimum
2"clearancemuststillbemaintainedaroundtheventpipes.)
Figure 4. Framing for shelves over the fireplace.
TopVentRearVent
Figure 3. Minimum Corner framing dimensions, using a 45° elbow.
Figure 2. Framing dimensions.
* When sheetrock is
not used behind the
fireplace, framing
depth may be
reduced to 16"
Framing
WARNING:
When this appliance is installed directly on carpeting, tile
or any combustible material other than wood flooring, it
must be installed on a metal or wood panel extending the
full width and depth of the appliance.
Top View
Front View SideView
Clearances
Theseclearancesapplytoalldimensionsexcepttheframedopening,
wheretheclearancetocombustiblesis0".TheH34Dclearancesto
combustiblematerialsare:
Top-RearVent* 9"
Top-TopVent 17 1/2"
Back 2"
Sides 1"
Floor 0"
Mantle** 4"
* Clearancefromthetopofthefireplacetoacombustible
ceilingwithinthefireplaceenclosure.
** Refertopage11.
Unprotectedcombustiblewallswhichareperpendiculartothefireplace
opening,mustnotprojectbeyondtheshadedareashowninFigure23.
Forprotectionagainstfreezingtemperatures,itisrecommendedthat
outerwallsofthechasebeinsulatedwithavapourbarrier.Thiswill
reducethepossibilityofacold-airconvectioncurrentonthefireplace.
Figure 1. Fireplace dimensions.

Page 4
H34D Gas Fireplace
Part No. XG0130
Vent Installation
Thissectioncoverstheinstallationofdirectventingandterminations.
Installation Requirements
H34D fireplaces are certified for use with Montigo Standard Series
(4" / 7") venting components.
Minimum 2" clearance to combustibles required for vent pipes
Useonlycertified Montigo vent components. (Useofother partswillvoid the
Montigo warranty, and may impede the operation of the fireplace.)
All joints must be secured with a minimum of two screws per joint
Vent terminations must not be recessed in walls or siding
Horizontal runs must be supported by a minimum of two supports
per horizontal run. A minimum of one screw on each side of
support is also required
Flex vent sections may be stretched up to 50% of their total length
(eg. a 24" section may be stretched to 36").
Maximum horizontal run with no vertical rise is 6 feet.
Solid vent sections may be cut less than half way from the female end
Venting components can be used in any combination of solid/rigid
pipe or flex pipe and in any orientation (Male connectors can face
in any direction)
Vent Terminations
Selecting A Termination Location
Choosingyourventterminationlocationwillhelptodeterminewhether
youneedtouseatopventorrearvent fireplace.Figure6a,below,
showstypicalfireplacelocationsandtheventingoptionstheyprovide.
Foramoredetaileddiagramofallowedterminationlocations,see
AppendixA.
Cautions:Cautions:
Cautions:Cautions:
Cautions:
Installing The Gas Line
ThegaslinemustbeinstalledbeforefinishingtheH34DFireplace.
NaturalGasrequiresaminimum inletgassupply pressureof5.5"
W.C.&amanifoldpressureof3.5"W.C.PropaneGasrequiresa
minimuminletgassupplypressureof11"W.C.&amanifoldpressureof
10"W.C.Provisionmustalsobemadefora1/8"N.P.T.pluggedtapping
andbeaccessiblefortestgaugeconnectionimmediatelyupstreamofthe
gassupplycontrolstotheappliance.Thefireplacegasconnectionand
themainoperatinggasvalveislocatedbehindtheremovabletrimatthe
bottomoftheunitandneedonlybeattachedtothegasline withan
approvedfitting, asrequiredbythe applicable installation codes.
•Onlyusegasshut-offvalvesapprovedforusebythestate,province,
region,orgoverningbody,inwhichtheapplianceisbeinginstalled,or
asrequiredbytheapplicableinstallationcodes.
•Flexiblegasconnectorsmustnotexceed3feetinlength,unlessitis
allowable withinapplicableinstallationcodes.
Installation
Figure 6a. Fireplace locations and vent terminations.
Note: After gas line is connected, each appliance connection,
valve and valve train must be checked while under
normal operating pressure with either a liquid solution, or
leakdetectiondevice, to locateanysourceof leak. Tighten
any areas where bubbling appears or leak is detected until
bubbling stops completely or leak is no longer detected.
DO NOT use a flame of any kind to test for leaks.
Installing The Remote Switch
TheH34D'sgasvalve,locatedbehindthelowertrim,maybeconnected
toawallswitch.Thevalvegeneratesitsownpowerona millivolt
circuit. Use only low voltage wire, and DO NOT connectany
externalpowertoit.
RefertoFigure30forwiringrequirements.
Note: Theswitchlocationmustnotexceed30'fromthefireplace.
Figure 5. Gas line access.
Theapplianceanditsindividualshutoffvalvemustbedisconnectedfrom
thegassupplypipingsystemduringanypressuretestingofthatsystem
attestpressuresinexcessof1/2psig(3.5kPa).
Theappliancemustbeisolatedfromthegassupplypipingsystemby
closingitsindividualmanualshutoffvalveduringanypressuretestingof
thegassupplypipingsystemattestpressuresequaltoorlessthan1/2
psig(3.5kPa).
Vent terminations can be very hot. If the termination
is less than 7 feet above a public walkway, it should
befittedwithacertifiedMontigoHeatGuard.(Partno.
MTKOG)
Do not obstruct, or attempt to conceal, the vent
termination. These actions will affect the operation
of the fireplace, and may be hazardous.
Inheavysnowareas,takeextracaretopreventsnow
buildup from obstructing the vent termination.

Page 5
H34D Gas Fireplace
Part No. XG0130
Installing Terminations with Built-In Frames
Installing Terminations with MSR Frames
12
12
1. Frametheterminationopeningto12"x12".
2. Fastentheterminationtothestudsusingaminimumof4screws.
11
11
1. Frametheterminationopeningto11"x11".
2. Fastentheterminationtothestudsusingaminimumof4screws.
Installing Terminations with MOSR Frames
1212
12
MOSR
1. Frametheterminationopeningto12"x12".
2. FastentheMOSRframetotheinteriorsideofthestudsusinga
minimumof4screws.
3. InserttheterminationintotheMOSRframeasshownhere,and
attachbyscrewingthroughthefourpilotholesinthetermination.
MSR
MTO-3
MTO-3F
MTO-3
MTKOG
1. Ensurethatthetwolongmountingbracketsarefacingthebottomof
thetermination.(Seeinset).Thiswillprovidemoreheatprotection
atthetopofthetermination,wheretemperaturesarehighest.
2. Attachtothefaceplateoftheterminationusingfoursheetmetalscrews.
Installing Heat Guards over Terminations
Installation
Installing The Standoffs
To avoid elevated mantel temperatures, all H38DF gas fireplaces
are required to have the supplied standoffs installed.
Thefireplaceissuppliedwithtwostandoffs.Bendandinstallthese
standoffsontopofthefireplaceensuringthattheheightofthestandoff
maintainsa6"clearance.
Figure 6b. Installing the standoff's.

Page 6
H34D Gas Fireplace
Part No. XG0130
Installation
Converting to Top Vent/ Rear Vent
H34DL Top Vent
UsethefollowinginstructionstoconvertanH34DLforTopVentuse:
1.Installthe4"innerfluecapontherearflueoutletandsecurethe
capinplacewithfivescrews,asshowninfigure7a.
2. Installthe7"outerfluecapontherearflueoutlet,andsecureit
withfivescrews,asshowninfigure7a.
3.Installthefluegasketmaterialandfluecoverplateontherear
ventoutlet.Fastentheplate withfourscrews,asillustratedbelow.
4.Installthe4" innerfluecollarandthe7"outerfluecollarinplace
onthetopventoutlet using5screws,asillustratedbelow.
Figure 7a. Flue cap installation for Top Vented fireplace.
Figure 7b. Flue collar installation for Top Vented fireplace.
Figure 8a. Flue cap installation for Rear Vented fireplace.
Figure 8b. Flue collar installation for Rear Vented fireplace.
H34DL Rear Vent
UsethefollowinginstructionstoconvertanH34DLforTopVentuse:
1.Installthe4"innerfluecaponthetopflueoutletandsecurethe
capinplacewithfivescrews,asshowninfigure8a.
2. Installthe7"outerfluecaponthetopflueoutlet,andsecureit
withfivescrews,asshowninfigure8a.
3.Installthefluegasketmaterialandfluecoverplateonthetopvent
outlet.Fastentheplate withfourscrews,asillustratedinfigure8b.
4.Installthe4" innerfluecollarandthe7"outerfluecollarinplace
ontherearventoutlet using5screws,asillustratedbelow.

Page 7
H34D Gas Fireplace
Part No. XG0130
Installation
Available Top Vent Components
ThefollowingventingcomponentsareavailablefortheH34DTop
Vent:
A - Termination MTO-3 (3" length)
MTO-3F (3" length)
B - Stucco Kits MSR (stucco frame)
MOSR (stucco can)
BSR (brick can)
C - Flex sections MFL-1 (12" section)
MFL-2 (24" section)
MFL-3 (36" section)
MFL-4 (48" section)
D - Rigid sections MEXT-1 (12" m/f section)
MEXT-2 (24" m/f section)
MEXT-3 (36" m/f section)
MEXT-4 (48" m/f section)
E - Elbows MEL-90MM (m/m 90° elbow)
MEL-90FF (f/f 90° elbow)
MEL-90FM (f/m 90° elbow)
NOTES: Alldimensionlengthsforverticalorhorizontalrunsare
measuredfromcenteroftheventpipe.
Ventingrunsmustfallwithinthelimitssetbytheventing
graph (see Figure 9).
Top Vent Venting Runs
Beforeyouinstallanyventing,youmustdeterminewhethertheventing
runwillbeacceptable.Unacceptableventingcanaffectthefireplace's
combustion.
themaximumverticalventrunforaTopVentedunitis32feet
The Venting Graph
Measuretheverticalheightfromthefireplacehearthtothecentreofthe
terminationandthehorizontalrunfromthefromthefireplacefluecollarto
thewallflangeofthetermination.PlotontheVentingGraph(Fig.9)with
an'X'.
Ifthe'X'fallsonorabovethetopboundaryoftheshadedarea,the
installationisacceptable.
Example A: (Acceptable Installation)
Iftheverticaldimensionfromthehearthis108",andthehorizontal
runtothewallflangeoftheventterminationis180",thiswouldbe
anacceptableinstallation.
Example B: (Acceptable Installation)
If the vertical dimension from the hearth is 48" and the horizontal
run to the wall flange of the vent termination is 72", this would be
anacceptableinstallation.
Example C: (Unacceptable Installation)
If the vertical dimension from the floor of the fireplace is 60" and
the horizontal run to the wall flange of the vent termination is 144",
this would NOT be an acceptable installation.
Figure 9. Venting Graph.

Page 8
H34D Gas Fireplace
Part No. XG0130
Installation
Horizontal Venting
Figure 12. Typical Top Vent installation. The solid sections can be used in
various combinations to obtain the desired vent run. The vent
run must fall within the limits set by the venting graph.
Example2:
Rigidsectionsandanelbowusedinconjunctionwith3ft.flexsection
(MFL-3)will,whenextendedinafivefootchase,allowforamaximum
horizontalrunoftwelveandone-halffeetfromthecentreofthefireplace
tooutsidewallandaminimumof7'6"whenretractedinoppositedirection
(see Figure 13 and 14).
"C"flexsectionsand"D"rigidsectionsmaybeusedinconjunctionwith
oneanothertoobtaindifferentpossiblehorizontallengthinstallations.
Figure 13. Extended Installation using a combination of solid and flex
venting. Use the vent graph to determine your allowable
run, then select appropriate components.
Figure 14. Retracted Installation using a combination of solid and flex
venting. Use the vent graph to determine your allowable
run, then select appropriate components.
Figure 15. Horizontal flex installation with no vertical rise.
90° Elbow
MEXT
Section
Termination
Example 1:
ForourshortestventingconfigurationusecomponentsAandE(see
Figure 9a).
Figure 11. Typical Top Vent installation. If the 90° elbow is installed
directly on the fireplace, the height to the center of the
termination is 42 1/4".

Page 9
H34D Gas Fireplace
Part No. XG0130
Installation
B. Vertical (Through-The-Roof) Installations
■VerticalTerminationsmustbeinstalled:
•minimum 2' (two feet) above the highest point where
vent passes through the roof.
•minimum 6' (six feet) from a mechanical air inlet
•minimum 18" (1 1/2 feet) from a parapet wall.
■Maximumventheightis32feetabovefireplace.
Note:Flamecharacteristicswillchangeifthemaximumventheightis
used.
■Minimumclearances2"fromventtoallcombustiblematerialsmustbe
maintained.
A - Termination MVTK-1
B - Flex sections MFL-1 (12" length)
MFL-2 (24" length)
MFL-3 (36" length)
MFL-4 (48" length)
C - Solid sections MEXT-1 (12" length)
MEXT-2 (24" length)
MEXT-3 (36" length)
MEXT-4 (48" length)
D - Support Ring
& Plate MSPXT-7
E - Firestop FS-7
F - Roof Flashing MRF-7 (1/12-7/12 pt.)
MRF-12 (7/12-12/12 pt.)
Figure 16. Straight, vertical venting showing required MXT-10
adaptor (supplied with the MVTK-1 termination).
A maximum of two offsets (each offset has two 90° bends) may be
madeandshallnotexceedtotallengthof25%oftheverticalventheight,
when measured center to center of piping.
Example: Typicalventinstallation.
20'vertical vent
2 - 2' offsets required
25% of 20' = 5' max. offset allowed
Thisventing configurationmeetsrequirements.
Figure 18. Vertical venting with 2 offsets (1 offset= two 90° bends).
Figure 17. Vertical venting with 1 offset (1 offset= two 90° bends).
* Minimum 2" clearance to all combustibles.
* Minimum 2" clearance to all combustibles.
* Minimum 2" clearance to all combustibles.

Page 10
H34D Gas Fireplace
Part No. XG0130
Installation
Figure 20. Extended installation.
Figure 21a. Corner installation.
Figure 21b. Flex installation.
Rear Vent Venting Runs
TheH34DLRearVenthasthreepossibleinstallationswhichdonot
requireverticallift,alloftheseinstallationsrequirethatyouinstallthe
RHS101heatsheild.
1. Straight Installation.
Theheightfromthehearthtothecenteroftheterminationis27
3/8".H34DLRearVentversionsaresuppliedwitha18"extension
pipe(EXT18)withfemale/femaleconnections.Forshorterinstalla-
tions,cuttheEXT18tothedesiredlength.Refertofigure20.
Forextendedinstallations,usetheEXT18sectionassuppliedfora
18" vent run. Ensure that the RHS101 heat sheild is installed
before attaching the pipe to the termination.
Note: ForRearVentmodels,maximumhorizontalrunwithno
verticalliftmustneverexceed18".
2. 45° Corner Installation.
AttachanEEL-45(45°elbow)directlyontothefluecollar.Cutthe
EXT-18tosuit,andattachittotheEEL-45.Slidethefireplaceinto
positionandattachtothetermination.EnsurethattheRHS101
heat sheild is installed before attaching the pipe to the
termination.
3. Corner Installation — 45° or less.
UseanMTO-3terminationandanMFL-1orMFL-2(12"or24"
compressedlength)andaframe,ifappropriate.Flexmaybeturned
toobtaindesireddegreeofanglerequiredbutmustnotexceed45°.
Ensure that the RHS101 heat sheild is installed before
attaching the pipe to the termination.
Figure 19. Heat Shield. Install by sliding over the vent pipe where it
passesthroughcombustibleconstruction.
Heat Shield
The heat shield(RHS101)mustbeused on all installations straight
throughthewall,atthepointwheretheventpipeconnectstothe
termination.Withtheheatshield,properventclearancescanbe
maintained. The heat shield is not included with the fireplace.
Toinstalltheheatshield,slideonesectionovertheventpipeonthe
insideofthewallopening,withthecircularportioninsidethewallcavity.
Screwtheshieldinplaceoverthewallopening.Installthesecond
sectionontheoutsideofthewallopeningslidingthecircularportioninto
thewallopening.RefertoFigure19.

Page 11
H34D Gas Fireplace
Part No. XG0130
Installation
B. Multi-Elbow Installations
Formorediffiicultinstallationsituations,theH34DRearVentmaybe
installedwithtwo—90°elbowsandupto15'ofhorizontalrun.Ifusing
thisinstallationoption,youmustadheretothefollowingguidelines:
■thefirst90°elbowmustbeplaceddirectlyonthefluecollar
■youmusthaveaminimumverticalliftof46"(measuredfromthe
hearth)
■yourventrunmustfallwithinthelimitssetbyFigure18a
Beforeyouinstallanyventing,youmustdeterminewhethertheventing
runwillbeacceptable.Unacceptableventingcanaffectthefireplace's
combustion.
The Venting Graph
Measuretheverticalheightfromthefireplacehearthtothecentreofthe
terminationandthehorizontalrunfromthefromthefireplacefluecollarto
thewallflangeofthetermination.PlotontheVentingGraph(Fig.22)
withan'X'.
Ifthe'X'fallsonorabovethetopboundaryoftheshadedarea,the
installationisacceptable.
Example A: (Acceptable Installation)
Iftheverticaldimensionfromthehearthis84"andthehorizontal
runtothewallflangeoftheventterminationis36",thiswouldbean
acceptableinstallation.
Example B: (Acceptable Installation)
Iftheverticaldimensionfromthehearthis94"andthehorizontal
runtothewallflangeoftheventterminationis126",thiswouldbe
anacceptableinstallation.
Example C: (Unacceptable Installation)
Iftheverticaldimensionfromthefloorofthefireplaceis78"andthe
horizontalruntothewallflangeoftheventterminationis108",this
would NOT be an acceptable installation.
Figure 22. H34D Rear Vent Venting Graph
Installation Of Rear Vent DV
H34DRearVentversionsaresuppliedwithanEXT-18(female/female)
section.Inaddition,thefollowingventingcomponentsareavailablefor
Rear Vent installations:
A - Termination MTO-3 (3" length)
MTO-3F (3" length)
B - Stucco Kits MSR (stucco frame)
BSR-4 (4" brick frame)
BSR-6 (6" brick frame)
MOSR (stucco can)
C - Flex sections MFL-1 (12" section)
MFL-2 (24" section)
MFL-3 (36" section)
MFL-4 (48" section)
D - Solid sections MEXT-1 (12" section)
MEXT-2 (24" section)
MEXT-3 (36" section)
MEXT-4 (48" section)
E - 90 degree elbow MEL-90MM (m/m 90° elbow)
MEL-90FF (f/f 90° elbow)
MEL-90FM (f/m 90° elbow)
EEL-45 (f/m 45° elbow)
Figure 23. Multi-elbow installation. Distance 'H' must be a minumum
of 46". The vent run must comply with figure 18a.
NOTES: Alldimensionlengthsforverticalorhorizontalrunsare
measuredfromcenteroftheventpipe.
Ventingrunsmustfallwithinthelimitssetbytheventing
graph (see Figure 23).
8"
H
L
18"

Page 12
H34D Gas Fireplace
Part No. XG0130
Finishing Around the Fireplace
Combustiblemantelsandmouldingsmaybesafelyinstalledoverthetop
andonthefrontofthefireplaceprovidedthattheydonotprojectbeyond
shadedareashowninFigure 23.Sidewallclearancesare3".Combus-
tiblesurroundsmaybeinstalledwith3"clearancetothesideofthe
fireplaceasshowninFigure24.
Fireplace Facing
Whenselectingthefinishmaterialforyourfireplace,itisimportantto
rememberthefollowing:THELOWER GASCONTROLPANELMUST
NOT BE OBSTRUCTED IN ANY WAY - to do so restricts the air
supply for the control compartments and heat exchanger it also
prevents access for servicing controls.
Thefaceofthefireplacemaybepaintedtomatchtheroomdecor,
providedyouuseaheat-resistantpaint. Decorativefacingmustnot
extendpastthefireplaceopeningatall,becauseitwillinterferewiththe
accesstoretainersforremovalofglassdoor.
Installation
Figure 23. Combustible mantles and facings.
Mantels & Surrounds
NOTE:NationalCanadianGasAssociationmanteltestrequirementsare
forfirehazardpreventiontocombustiblematerials.
Newtechnology,tomeetconsumerandgovernmentdemandsforthe
wiseuseofenergy,haspromptedustomanufacturemanymodelsof
fireplaceswhicharehot,fuelandenergyefficient.
Pleasebeaware;temperaturesoverthemantelwillriseabovenormal
roomtemperatureandwallsabovefireplacemaybehottotouch.
Werecommendcarefulconsiderationbegiventotheeffectsofelevated
manteltemperatureswhichmaybeinexcessofproductdesign,for
example:candles,plasticorpictures. Thiscancausemelting,deforma-
tion,discolorationorprematurefailureofT.V.andradiocomponents.
Painting:
SpecialcareisrecommendedbytheMasterPaintersandDecorators
Association,whenpaintingthefireplacesurrounds,toselectandapplya
qualityAlkydsealerpriortotheapplyingoflatexpaints. Thisisto
preventleachingofwaterfromevaporationandcausingabrownish
stainingeffecttopaintovercoats.
Figure 24. Combustible surrounds.
Wiring
Gas Control and Pilot Wiring H34D-I
Honeywell (Q3450)
Pilot Assembly
Pilot Electrical
Harness Connector
Honeywell Gas
Control (SV9501M)
Gas Control
Connector Fuse
Limit
Switch Wall
Switch
Fan Plug
Receptacle
Junction Box
Junction Box Cover
White
Black
Green
40 VA
Transformer
115VAC
24VAC
Grnd Screw
Figure 25. Wiring for the H34D-I with Honeywell gas control and pilot.

Page 13
H34D Gas Fireplace
Part No. XG0130
Installation
Wiring for the optional Fan Kit
AllH34Dfireplacesmaybeequippedwithoptionalfankits forcirculating
heatintothelivingspace.
InstallationsinCanadawhichemploythefansmustbeelectrically
groundedinaccordancewithCSAC22.1CanadianElectricalCodePart
1and/orLocalCodes.
Installationsinthe USAwhichemploythefansmustbegroundedin
accordancewithlocalcodesor,intheabsenceoflocalcodes,withthe
NationalElectricalCode,ANSI/NFPA70-1987.
FormoreinformationseetheFanKit InstallationGuideincludedwith
thefankit.
NOTE: If any of the original wire supplied with the appliance is replaced, it
must be replaced with the same type, or its equivalent.
Figure 26b. Wiring schematic for optional fans.
Figure 26a. Wiring for optional fans.
Removing and Installing
the Door
Removing the door:
Thedoorisheldinplacebyaliponthetopofthemetalframeandtwo
bucklesatthebottom.Releasethebucklesandliftthedoorcarefullyup
andawayfromthefrontofthefireplace.Seefigures27aand27a.
Installing the door:
Hookthetopedgeofthedoorframeintoplace.Lowerandrestthedoor
frameinplaceandfastenthebuckles.Seefigures27aand27b.
Figure 27b. Removing and installing the glass door.
Figure 27a. Removing and installing the glass door.
115/1/60 Supply
G L1 L2
G
L2-WH
L1-BLK
pg
Quick Connect
lu to motor

Page 14
H34D Gas Fireplace
Part No. XG0130
Installation
Log 'D'
Cautions:
■If logs are not placed properly, excessive sooting
will result.
■The surface of the logs will crack due to the heat
from the flames. This is a normal occurance.
Installing the Log Set
Installing the Logs:
TheH34DFissuppliedwithfourceramicfibrelogsandaceramicfibre
logsetbase.Unpackthelogsandhandlethemverycarefully.
3. Place the bottom left and right logs as shown below in figure 28d.
4. Place the top left and right logs as shown in figure 28e.
1. Removetheglassdoor.
2. Thebaselogisfactory-installed,asshownbelowinfigure28b.
Figure 28a. H34DF's five piece logset.
Figure 28b. Base log placement.
Figure 28d. Bottom left and right log placement.
Figure 28e. Top left and right log placement.
Base Log
Bottom Left Log
Bottom Right Log
Top Left Log
Top Right Log
Base Log
Bottom Right Log
Bottom Left Log
Top Left Log Top Right Log
5. Start the fireplace. If the flame appears satisfactory, replace the
glass door. If the flame does not appear satisfactory, double-check
the air inlet and exhaust outlet pipe to ensure that they are
unobstructed.
Air Inlet Ports
Ember Chips
3. Arrange the ember chips on top of the burner tray. Care should
be taken when placing the ember chips, as blocked burner ports
may cause an incorrect flame pattern, carbon deposits and
delayed ignition. Also, the chips must never be placed in a way
that obstructs any of the air inlet ports, located at the rear of the
burner, as shown in figure 28c.
Figure 28c. Ember Chip placement.

Page 15
H34D Gas Fireplace
Part No. XG0130
WARNING: If you do not follow these instructions exactly, a fire or explosion
may result causing property damage, personal injury or loss of life.
■If you cannot reach your gas supplier, call the Fire
Department.
C. Use only your hand to push in or turn the gas control knob.
Never use tools. If the knob will not push in or turn by
hand, don't try to repair it, call a qualified service
technician. Force or attempt to repair may result in a fire or
explosion.
D. Do not use this appliance if any part has been under water.
Immediately call a qualified service technician to inspect
the appliance and to replace any part of the control system,
and any gas control which has been under water.
A. This appliance has a pilot which must be lighted by hand.
When lighting the pilot, follow these instructions exactly.
B. BEFORE LIGHTING smell all around the appliance area
for gas. Be sure to smell next to the floor because some
gas is heavier than air and will settle on the floor.
What To Do If You Smell Gas:
■Do not try to light any appliance.
■Do not touch any electrical switch; do not use any
phone in your building.
■Immediately call your gas supplier from a neighbour's
phone. Follow the gas supplier's instructions.
To Turn Off Gas To Appliance:
Operation - Model H34D
3. Push in gas control knob slightly and turn clockwise
to "Off". Do not force.
4. Flip up the lower trim.
1. Turn off remote switch.
2. Flip down the lower trim.
1. STOP! Read the safety information above on this label.
2. Flip down the lower trims.
3. Push in gas control knob and turn clockwise to
"OFF."
4. Wait five (5) minutes to clear out any gas. Smell for gas,
including near the floor. If you then smell gas, STOP!
Follow "B" in the safety information above on this label. If
you don't smell gas, go to the next step.
5. Locate pilot burner (See illustration at right.) and follow
steps below.
6. Turn knob on gas control counterclockwise to
"PILOT."
7. Push in gas control knob completely and hold. Light with
Piezo Igniter button. Continue to hold the control knob in for
about (1) minute after the pilot is lit. Release the knob and it
will pop back up. Pilot should remain lit. If it goes out repeat
steps 3 through 8.
■If knob does not pop up when released. Stop and
immediately call your service
technician or gas supplier.
■If the pilot will not stay lit after
several tries, turn the gas control
knob to "OFF" and call your service
technician or gas supplier.
8. Push in gas control knob and turn counterclockwise
to "ON."
9. Flip up the lower trim.
10.Turn on remote switch to ignite fire.
Lighting Instructions:
H34D
with Continuous Pilot
For Your Safety - READ BEFORE LIGHTING:
NOTE: Gascontrolknobcannotbeturnedfrom
"PILOT"to"OFF"unlessknob ispushed
inslightly. Donotforce.
Gas Control Knob
(Shown in "Pilot" postion.)

Page 16
H34D Gas Fireplace
Part No. XG0130
For Your Safety - READ BEFORE LIGHTING:
To Turn Off Gas To Appliance:
Lighting Instructions:
■If you cannot reach your gas supplier, call the Fire
Department.
C. Use only your hand to push in or turn the gas control knob.
Never use tools. If the knob will not push in or turn by
hand, don't try to repair it, call a qualified service techni-
cian. Force or attempt to repair may result in a fire or
explosion.
D. Do not use this appliance if any part has been under
water. Immediately call a qualified service technician to
inspect the appliance and to replace any part of the control
system, and any gas control which has been under water.
A. This appliance is equipped with an ignition system that
lights the pilot burner automatically. Do not attempt to
light the pilot by hand.
B. BEFORE LIGHTING smell all around the appliance area
for gas. Be sure to smell next to the floor because some
gas is heavier than air and will settle on the floor.
What To Do If You Smell Gas:
■Do not try to light any appliance.
■Do not touch any electrical switch; do not use any
phone in your building.
■Immediately call your gas supplier from a neighbour's
phone. Follow the gas supplier's instructions.
1. Turn off remote switch.
2. Flip down the lower trim.
3. Turn the switch on the gas control to "Off".
4. Flip up the trim.
1. STOP! Read the safety information above on this label.
2. Flip down the lower trims.
3. Turn switch on the gas control to OFF".
4. Wait 5 minutes to clear out any gas. If you smell gas,
STOP! Follow "B" in the safety information above on this
label. If you don't smell gas, go to the next step.
5. Turn switch on the gas control to "ON". NOTE: This unit is
equipped with an ignition system that lights the pilot burner
automatically. Do not attempt to light the pilot by hand.
6. Turn on wall switch.
7. Flip up the lower trim.
8. If the fireplace does not operate, follow the instructions "To
Turn Off Gas To Appliance" and call your service techni-
cian or gas supplier.
with Honeywell Electronic Ignition
WARNING: If you do not follow these instructions exactly, a fire or explosion may
result causing property damage, personal injury or loss of life.
Operation - Model H34D-I
H34D-I
Gas
Inlet
Gas Control Switch
Shown in "On" Position

Page 17
H34D Gas Fireplace
Part No. XG0130
Maintenance
WARNING:
Do not attempt to clean glass when hot.
Do not clean glass with abrasive materials as any
glass etching may cause premature glass failure.
CAUTIONS
Fireplace gas control must be in the “OFF” position and
pilot and main burners extinguished when cleaning
appliance with a vacuum.
Doorsandlogscangetveryhot.Handleonlywhencool.
General
Havethefireplaceinstallationinspectedyearly,includingavisual
checkoftheventsystem,theburnerandthepilotflame.Foryour
conveniencea1/8"manifoldpressuretapissuppliedonthegas
valveforatestgaugeconnection.SeeFigure29.
ForNaturalGasthisappliancerequiresaminimuminletpressureof
5.5"W.C.andamanifoldpressureof3.5"W.C.
ForPropaneGasthisappliancerequiresaminimuminletpressure
of 11"W.C.andamanifoldpressureof10"W.C.
Alwayskeepthefireplaceareaclearandfreeofcombustible
materials,aswellasgasolineandotherflammablevapoursand
liquids.
Donotusethisapplianceifanyparthasbeenunderwater.
Immediatelycallaqualifiedservicetechniciantoinspecttheappliance
andtoreplaceanypartofthecontrolsystemandanygascontrol
whichhasbeenunderwater.
Operation
Lighting Instructions
Seepages14and 15.
Burner Adjustment
TheH34Disequippedwithanadjustableburner,allowingyoutoraise
orlowertheflames.Toadjusttheflames,locatetheblackknobmarked
'Hi-Lo',inthecentreofthegascontrolvalve(SeeFigure29).Thefront
burnersarenotadjustable.
■Toraisetheflameheight,turntheblackknob(locatedbehindthe
lowertrim)counterclockwise.
■Tolowertheflameheight,turnclockwise.
Figure 29. 'Hi-Lo' Adjustment on the H34D's gas valve.
Cleaning
Whenthefireplaceisfirstactivated,theremaybesomesmokinganda
visiblefilmmaybeleftontheglass.Thisisanormalcondition,andisthe
resultofburningofprotectivecoatingsonnewmetal.
Glassmustbecleanedperiodicallytoremoveanyfilm(whichisa
normalbiproductofcombustion)whichmaybevisible.Filmcan
easilyberemovedbyremovingthedoor,asshown onpage12.
Handlethedoorcarefully,andcleanitwithnon-abrasiveglass
cleaners.OneofthemosteffectiveproductsisKelKem.
Siliconesealsoninnerdoorduringinitialfiringwill"offgas",leavinga
visualdepositofawhitesubstanceoncombustionchamberwalls.
Thiscaneasilyberemovedusingnormalhouseholdproducts.
Useavacuumcleanerorwhiskbroomtokeepthecontrol
compartment,burner,andfireboxfreefromdustandlint.
Logsmaybecleanedperiodicallywithavacuumtoremovesootor
othercontaminates.
Gas Control Knob
(Shown in "Pilot" postion.)
'Hi-Lo'AdjustmentKnob
Note: H34D-I (electronic ignition) or H34D-MH (mobile home)
models do not feature hi/lo adjustment.
For electronic ignition (HSI) models see figure 25, for
mobile home approved models see Appendix B.

Page 18
H34D Gas Fireplace
Part No. XG0130
Maintenance
Gas Control Valve
Pilot Burner Adjustment
1. LocatePilotAdjustmentScrew.(Seefigure30.)
2. Adjustpilotscrewtoprovideproperlysizedflameasshownin
figure 31).
3. Afterinstallingorservicing,leaktestwithasoapsolutionwithmain
burneron.Coatpipeandtubingjoints,gasketetc.withsoapsolution.
Bubblesindicateleaks.Tightenanyareaswherethebubbles
appearuntilthebubblingstopscompletely.
Figure 31. Pilot Burner.
Troubleshooting
Thefollowingisatroubleshootingchartofpossibleproblems:
PROBLEM CORRECTIVEACTION
NoisyPilotFlame Locatepilotadjustementscrewon
gascontrolvalve.Flameisdecreasedby
turningadjustmentscrewclockwise.
Pilotwon’tignite Disconnectremotewiresandtrytolight
pilot.Ifpilotnowworks,remote
connectionsarefaulty.Checkwiring
diagramfigure30.
Mainburnerwill 1. Checkwiring(seefigure 30).
notlight 2.Checkwallswitchforproper
connection.
H34D
Troubleshooting
Ifyourfireplacestilldoesnotoperatecorrectly,consultyourdealeror
themanufacturer.
All service and repairs should be performed by a qualified
agency.
Allspareparts,optionalfans,andoptionaltrimfinishesareavailablefrom
yourlocaldealerorthemanufacturer.
HONEYWELL SV 9500 /SV9600
Troubleshooting Sequence
NOTE: Before Troubleshooting, Familiarize Yourself With
The Startup And Checkout Procedure.
· Turn Gas Supply off
· Set thermostat to
call for heat
SV9500/SV9600
is powered
(24 VAC nominal)
NO
NO
NO
NO
NO
YES
YES
YES
YES
YES
YES
YES
NO
NO
NO
START
Igniter warms up
and glows red.
Pilot Valve opens.
Turn gas on.
Pilot Burner lights?
Main Valve opens?
SYSTEM OK
Unplug Pilot Burner Cable,
Measure Voltage at
SV9500/SV9600 HSI
Terminals (24 VAC
Nominal, See INSET)
Replace Igniter/
Flame Rod Assembly.
Replace Igniter/
Flame Rod Assembly.
Replace SV9500/SV9600
Measure Voltage to SV9500
/SV9600. Voltage must
be at least 19.5 VAC
Discard old Igniter/
Flame Rod Assembly.
Replace Igniter/Flame
Rod Assembly and retain.
Restart Troubleshooting
Sequence. Does main
valve open?
Replace
SV9500/
SV9600
Check
Transformer
Line Volt
Supply
Replace
SV9500/
SV9600.
Save old
Igniter/Flame
Rod Assembly
for service.
INSET
HSI
Terminals
CHECK:
· Line voltage power
· Low voltage transformer
· Limit Controller
· Thermostat
· Wiring
· Air proving switch on
combustion air blower system
· Vent damper (if used) is open
and end switch made
H34D-I
Figure 30. Sit Nova 820 gas valve.
Manifold Pressure
Test Connection
Pilot Adjustment Screw
Inlet
Pressure
Power
Generator
Wall Switch
Spill Switch

Page 19
H34D Gas Fireplace
Part No. XG0130
The WarrantyThe Warranty
The WarrantyThe Warranty
The Warranty
TheCompanieswarrants theMontigo Gas Applianceto befreefrom defectsin materials andworkmanship atthetime ofmanufacture. On theMontigo, there isa ten-
yearwarrantyonthefireboxanditscomponents,afive-yearwarrantyonthemainburnerandpilotburner,andaone-yearwarrantyonthegascontrolvalveandfibrelogs.
Glass,plated/paintedfinishes,andrefractoryliningareexempt.
Remedy And Exclusions
The coverage of this Warranty is limited to all components of the Gas Appliance manufactured by The Companies.
ThisWarranty only coversMontigo GasAppliances installed inthe UnitedStates or Canada.
IfthecomponentsoftheGasAppliancecoveredbythisWarrantyarefoundtobedefectivewithinthetimeframestated(seeTheCompaniesrightofinvestigationoutlined
below).TheCompanieswill,atitsoption,replaceorrepairdefectivecomponentsoftheGasAppliancemanufacturedbyTheCompaniesatnocharge,andwillalsopay
forreasonablelabourcostsincurredinreplacingorrepairingcomponents.Ifrepairorreplacementisnotcommerciallypractical,TheCompanieswill,atitsoption,refund
thepurchase priceof theMontigo GasAppliance.
ThisWarrantycoversonlypartsandlabourasprovidedabove.InnocaseshallTheCompaniesberesponsibleformaterials,components,orconstructionwhicharenot
manufacturedorsuppliedbyTheCompanies,orforthelabournecessarytoinstall,repairorremovesuchmaterials,componentsorconstruction.Allreplacementorrepair
componentswill be shippedF.O.B. thenearest TheCompanies factory.
Qualifications To The WarrantyQualifications To The Warranty
Qualifications To The WarrantyQualifications To The Warranty
Qualifications To The Warranty
TheGasApplianceWarranty outlinedaboveisfurthersubject tothe followingqualifications:
(1) TheGasAppliancemustbeinstalledinaccordancewithTheCompaniesinstallationinstructionsandlocalbuildingcodes.TheWarrantyonthisMontigoGasAppliance
coversonlythecomponentpartsmanufacturedbyTheCompanies.TheuseofcomponentsmanufacturedbyotherswiththisMontigoGasAppliancecouldcreate
serioussafetyhazards,mayresultinthedenialofcertificationbyrecognizednationalsafetyagencies,andcouldbeinviolationoflocalbuildingcodes.Thiswarranty
doesnotcover anydamagesoccurringfromthe useofany componentsnotmanufacturedor suppliedbyTheCompanies
(2) TheMontigoGasAppliancemustbesubjectedtonormaluse.TheGasAppliancesaredesignedtoburngasonly.Burningconventionalfireplacefuelssuchaswood,
coal or any other solid fuel will cause damage to the Gas Appliance, will produce excessive temperatures and will result in a fire hazard.
Limitations On LiabilityLimitations On Liability
Limitations On LiabilityLimitations On Liability
Limitations On Liability
ItisexpresslyagreedandunderstoodthatTheCompaniessoleobligation,andpurchaser'sexclusiveremedyunderthisWarranty,underanyotherwarranty,expressed
or implied, or in contract, tort or otherwise, shall be limited to replacement, repair, or refund, as specified above.
InnoeventshallTheCompaniesberesponsibleforanyincidentalorconsequentialdamagescausedbydefectsinitsproducts,whethersuchdamageoccursorisdiscovered
beforeorafterreplacement orrepair,andwhetherornotsuch damageiscausedbyTheCompaniesnegligence. Somestates donotallowtheexclusion orlimitationof
incidentalorconsequentialdamages,sotheabovelimitationorexclusionmaynotapplytoyou.ThedurationofanyimpliedwarrantywithrespecttothisMontigoGasAppliance
is limited to the duration of the foregoing warranty. Some states do not allow limitation on how long an implied warranty lasts, so the above may not apply to you.
Investigation Of Claims Against WarrantyInvestigation Of Claims Against Warranty
Investigation Of Claims Against WarrantyInvestigation Of Claims Against Warranty
Investigation Of Claims Against Warranty
TheCompanies reservesthe right toinvestigate anyand allclaims againstthis Warrantyand todecide uponmethod ofsettlement.
The Companies Are Not Responsible For Work Done Without Written Consent
TheCompaniesshall innoeventbe responsibleforanywarrantywork donewithoutfirst obtainingTheCompanieswritten consent.
Dealers Have No Authority To Alter This Warranty
TheCompaniesemployees anddealershave noauthoritytomake anywarrantiesnorto authorizeanyremedies inadditiontoor inconsistentwiththosestated above.
How THow T
How THow T
How T
o Register A Claim Against Wo Register A Claim Against W
o Register A Claim Against Wo Register A Claim Against W
o Register A Claim Against Warrantyarranty
arrantyarranty
arranty
Inorder forany claimunder thisWarranty tobe valid,The Companiesmust benotified ofthe claimeddefect inwriting orby telephone,as soonas reasonablypossible
after the defect is discovered. Claims against this Warranty in writing should include the date of installation, and a description of the defect.
Other RightsOther Rights
Other RightsOther Rights
Other Rights
This Warranty gives you specific legal rights, and you may also have other rights which vary from state to state.
NOTE: The Companies asstatedabove referto -Canadian Heating ProductsInc. and/orMontigo DelRay Corp.
Canadian Heating Products Inc. and/or Montigo DelRay Corp. reserves the right to make changes at any time, without
notice, in design, materials, specifications, prices and also to discontinue colors, styles and products.
Warranty

Page 20
H34D Gas Fireplace
Part No. XG0130
Appendix A - Termination Locations
A= clearancetotheterminationframeabovegrade,veranda,porch,deck,or
balcony[16inches(41cm)minimum]
B= clearancetodoor,orsidesandtopofwindow,thatmaybeopened[16
inches(41cm)minimumforappliances
≤ 100000BTU/H(30kW)]
C= clearancetobottomof windowthatmaybeopenedhorizontally[36inches
(92cm)minimumforappliances
≤ 100000BTU/H(30kW)]
D= noclearancetopermanentlyclosedwindowwheninstalledwithapproved
glasspenetrationtermination
E= clearancetopermanentlyclosed window[16inches41cmrecommended
topreventcondensationonwindow]
F= verticalclearancetoventilatedsoffitlocatedabovetheterminationwithina
horizontaldistanceof2feet(61cm)fromthecentrelineofthetermination
[22inches(56cm)minimum]
G= clearancetounventilatedsoffit
[16inches(41cm)minimumtonon-combustibles]
[22inches(56cm)minimumtocombustibles]
H= clearancetooutsidecorner[9inches(23cm)minimum]
I= clearancetoinsidecorner[12inches(31cm)minimum]
J= *nottobeinstalledaboveameter/regulatorassemblywithin
40"(103cm)horizontallyfromthecentrelineoftheregulator
K= clearancetoserviceregulatorventoutlet[3feet minimumintheUnited
States][*6feet (1.8m)minimum inCanada]
L = clearancetononmechanicalairsupplyinlettobuildingorthecombustion
airinlettoanyotherappliance[16inches(41cm)minimumforappliances
≤ 100000BTU/H(30kW)]
M= clearancetomechanicalairsupplyinlet
[*6feet (1.8m)minimum]
N= †clearanceabovepavedsidewalkorapaveddrivewaylocatedon
publicproperty[*7feet(2.1m)minimum]
P= clearanceunderveranda,porch,deck,orbalcony
[16inches(41cm)minimum‡tonon-combustibles]
[22inches(56cm)minimum‡tocombustibles]
Q= clearanceabovearoof[24inches(61cm)minimum]
R= clearancetoadjacentwallsandneighbouringbuildings
[18inches(46cm)minimum]
S= clearancefromcornerinrecessedlocation
[12inches(31cm)minimum]
T= maximumdepthinrecessedlocation
[48inches(122cm)minimum]
U= minimumwidthforbackwallofrecessedlocation
[24inches(61cm)minimum]
V= nohorizontalclearancebetweentheframesoftwoterminationsthatare
level.
W= horizontalclearancebetweentheframesoftwoterminationsthatare
notlevel. [36inches(92cm)minimum]
†aventshallnotterminatedirectlyaboveasidewalkorpaveddriveway
whichislocatedbetweentwosinglefamilydwellingsandservesboth
dwellings
‡onlypermittedifveranda,porch,deck,orbalconyhasanopensidethat
isequaltoorgreaterthanthedepthoftheenclosedarea
*asspecifiedinCGAB149InstallationCodes.Note:localCodesor
Regulationsmayrequiredifferentclearances
