Montigo C38-DV User manual

n Check local codes
and read all
instructions prior to
installation.
n Leave this manual
with the owner.
Gas FireplaceGas Fireplace
Gas FireplaceGas Fireplace
Gas Fireplace
C38-DV
InstallationInstallation
InstallationInstallation
Installation
Operation &Operation &
Operation &Operation &
Operation &
MaintenanceMaintenance
MaintenanceMaintenance
Maintenance
What To Do If You Smell Gas:
• Do not try to light any appliance.
• Do not touch any electrical switch; do not use any phone in your building.
• Immediately call your gas supplier from a neighbor's phone. Follow the gas
supplier's instructions.
• If you cannot reach your gas supplier, call the fire department.
Warning:
Improper installation, adjustment,
alteration, service or maintenance can
cause injury or property damage. Refer to
this manual. For assistance or additional
information consult a qualified installer,
service agency or the gas supplier.
For Your Safety:
Do not store or use gasoline
or other flammable vapors
and liquids in the vicinity of
this or any other appliance.
Questions? Email us at [email protected] or visit our website at www.montigo.com.

Page 2Page 2
Page 2Page 2
Page 2
C38-DV Gas Fireplace
Part No. XG0118B
Introduction
Thank You for choosing a Montigo C-Series Fireplace.
About the C38 Fireplace:
The C38-D includes a 25,000 BTU dual burner with embers and a
ive piece ceramic logset. This model is available in our versions.
n C38DT - Top Vent, Millivolt Pilot
n C38DR - Rear Vent, Millivolt Pilot
n C38DT-S - Top Vent, Pilotless Ignition (STB)
n C38DR-S - Rear Vent, Pilotless Ignition (STB)
The C38-DV is rated or Natural Gas at 25,000 BTU/H (7.33 Kilowatts)
Input or Propane at 25,000 BTU/H (7.33 Kilowatts) Input.
How to use this manual:
This manual covers all models and unless otherwise speci ied, the
designation C38-DV re ers to all models. Sections which are speci ic to
a particular model are marked with a symbol,
plus the appropriate model number.
Warranty and Installation Information:
The Montigo warranty will be voided by, and Montigo disclaims any
responsibility or, the ollowing actions:
nModi ication o the ireplace and/or components including Direct-
Vent assembly or glass doors.
nUse o any component part not manu actured or approved by
Montigo in combination with this Montigo ireplace system.
nInstallation other than as instructed in this manual.
Consult your local Gas Inspection Branch on installation requirements
or actory-built gas ireplaces. Installation & repairs should be done by
a quali ied contractor.
Installations in Canada must con orm to the current CAN/CGA B-
149.1 and .2 Gas Installation Code and local regulations. I the optional
air-circulating an kit is installed, it must be electrically grounded in
accordance with CSA C22.1 Canadian Electrical Code Part 1 and/or
Local Codes.
Installations in the USA must con orm to local codes, or in the
absense o local codes to the National Fuel Gas Code, ANSI Z223.1-
1988. I the optional air-circulating an is installed, it must be grounded
in accordance with local codes or, in the absence o local codes, with
the National Electrical Code, ANSI/NFPA 70-1987.
Table Of Contents
Introduction............................................................................. 2
Installation
Installing the Fireplace Shell ........................................... 3
Installing the Gasline ...................................................... 4
The Remote Switch ....................................................... 4
Direct Vent Installation ................................................... 4
General Requirements ...................................... 4
Terminations ..................................................... 4
Top Vent Models with horizontal venting ............ 6
Top Vent Models with vertical venting ................ 8
Rear Vent Models ............................................. 9
Construction around the ireplace
Facing ............................................................. 11
Mantels and Surrounds ................................... 11
Wiring ....................................................................... 11
Removing and Installing the Door ................................ 12
Installing the Logset ..................................................... 13
Installing the Horizontal Trim ........................................ 13
Operation ........................................................................ 14 - 16
Maintenance ................................................................... 16 - 17
Warranty ................................................................................. 18
Appendix
A. Termination Locations ............................................. 19
B. Wiring or Pilotless Ignition (STB) Equipped Units .... 20
CAUTIONSCAUTIONS
CAUTIONSCAUTIONS
CAUTIONS
Due to its high operating temperatures, the appliance
should be located out o tra ic & away rom urniture and
draperies.
nChildren and adults should be alerted to the hazards
o the high sur ace temperature, which could cause
burns or clothing ignition.
nYoung children should be care ully supervised when
they are in the same room as the appliance.
nClothing or other lammable materials should not be
placed on or near the appliance.

Page 3Page 3
Page 3Page 3
Page 3
C38-DV Gas Fireplace
Part No. XG0118B
Installing The Fireplace Shell
The ireplace may be installed in any location that is ree o air
conditioning ducts, electrical wiring and plumbing. Sa ety, as well as
e iciency o operation, must be considered when selecting the
ireplace location. Try to select a location that does not inter ere with
room tra ic, has adequate ventilation, and o ers an accessible
pathway or Direct Vent installation. Re er to page 4 - Vent Installation
or more in ormation.
The ireplace dimensions are shown below:
Installation
When installing a shel over the top o the ireplace, the ollowing
guidelines must be adhered to: For Rear Vent models (C38-DR), the
minimum clearance rom the top o the ireplace to a shel is 7 ¼". For
Top Vent models (C38-DT), the minimum clearance is 15". (Minimum
1" clearance must still be maintained around the vent pipes.)
Figure 4. Framing for shelves over the fireplace.
Top VentRear Vent
Figure 3. Corner framing dimensions.
Figure 2. Framing dimensions.
* When sheetrock is
not used behind the
ireplace, raming
depth may be
reduced to 16 7/8"
Framing
WARNING:
When this appliance is installed directly on carpeting, tile or any
combustible material other than wood looring, it must be installed
on a metal or wood panel extending the ull width and depth o
the appliance.
Top Vent
Front View Rear Vent
Clearances
These clearances apply to all dimensions except the framed opening,
where the clearance to combustibles is 0". The C38-D clearances to
combustible materials are:
Top - Rear Vent* 7 ¼"
Top - Top Vent 15"
Back 1"
Flue 1"
Sides 0"
Floor 0"
Mantle** 8"
* Clearance rom the top o the ireplace to a combustible
ceiling within the ireplace enclosure.
** Re er to page 10.
Unprotected combustible walls which are perpendicular to the ireplace
opening, must not project beyond the shaded area shown in Figure 20.
For protection against reezing temperatures, it is recommended that
outer walls o the chase be insulated with a vapour barrier. This will
reduce the possibility o a cold-air convection current on the ireplace.
Figure 1. Fireplace dimensions.

Page 4Page 4
Page 4Page 4
Page 4
C38-DV Gas Fireplace
Part No. XG0118B
Vent Installation
This section covers the installation o direct venting and terminations.
Installation Requirements
nC38-DV ireplaces are certi ied or use with Montigo Premium Series
(5" / 8") venting components. The C38-DV Top ent may be used
with Standard Series (4"/7") components on vertical vent runs only.
nMinimum 1" clearance to combustibles required or vent pipes
nUse only certified Montigo vent components. (Use o other
parts will void the Montigo warranty, and may impede the
operation o the ireplace.)
nAll joints must be secured with a minimum o two screws per joint
nVent terminations must not be recessed in walls or siding
nHorizontal runs must be supported by a minimum o two supports
per horizontal run. A minimum o one screw on each side o
support is also required
nFlex vent sections may be stretched up to 50% o their total length
(eg. a 24" section may be stretched to 36")
nMaximum horizontal run or a lex section with no vertical rise is 3 eet.
nFlex vent sections over 3 eet must all within the limits set by the
venting graph and must have a minimum vertical rise o 3 inches
per oot o lex.
nSolid vent sections may be cut less than hal way rom the tapered end
ent Terminations
Selecting A Termination Location
Choosing your vent termination location will help to determine whether
you need to use a top vent or rear vent ireplace. Figure 6, below,
shows typical ireplace locations and the venting options they provide.
For a more detailed diagram o allowed termination locations, see
Appendix B.
Cautions:Cautions:
Cautions:Cautions:
Cautions:
Installing The Gas Line
The gas line must be installed be ore inishing the C38-DV Fireplace.
Natural Gas requires a minimum inlet gas supply pressure o 5.5"
W.C. & a mani old pressure o 3.5" W.C. Propane Gas requires a
minimum inlet gas supply pressure o 11" W.C. & a mani old pressure
o 10" W.C. Provision must also be made or a 1/8" N.P.T. plugged
tapping and be accessible or test gauge connection immediately
upstream o the gas supply controls to the appliance. The ireplace gas
connection and the main operating gas valve is located behind the
removable brass trim at the bottom o the unit and need only be
attached to the gas line with an approved itting, as required by the
applicable installation codes.
Installation
Figure 6. Fireplace locations and vent terminations.
Note: A ter gas line is connected, each appliance connection,
valve and valve train must be checked while under
normal operating pressure with either a liquid solution, or
leak detection device, to locate any source o leak. Tighten
any areas where bubbling appears or leak is detected until
bubbling stops completely or leak is no longer detected.
DO NOT use a flame of any kind to test for leaks.
Installing The Remote Switch
The C38-D 's gas valve, located behind the lower brass trim, may be
connected to a wall switch. The valve generates its own power on a
millivolt circuit. Use only low voltage wire, and DO NOT connect
any external power to it.
Re er to Figure 26 or wiring requirements.
Note: The switch location must not exceed 30' rom the ireplace.
Figure 5. as line access.
The appliance and its individual shuto valve must be disconnected
rom the gas supply piping system during any pressure testing o that
system at test pressures in excess o 1/2 psig (3.5 kPa).
The appliance must be isolated rom the gas supply piping system by
closing its individual manual shuto valve during any pressure testing o
the gas supply piping system at test pressures equal to or less than 1/2
psig (3.5 kPa).
nVent terminations can be very hot. I the termination is less than
7 eet above a public walkway, it should be itted with a certi ied
Montigo Heat Guard. (Part no. PTKOG)
nDo not obstruct, or attempt to conceal, the vent termination.
These actions will a ect the operation o the ireplace, and may
be hazardous.
nIn heavy snow areas, take extra care to prevent snow buildup
rom obstructing the vent termination.

Page 5Page 5
Page 5Page 5
Page 5
C38-DV Gas Fireplace
Part No. XG0118B
Installing Terminations with Built-In Frames
Installing Terminations with MSR Frames
12
12
1. Frame the termination opening to 12" x 12".
2. Fasten the termination to the studs using a minimum o 4 screws.
11
11
1. Frame the termination opening to 11" x 11".
2. Fasten the termination to the studs using a minimum o 4
screws.
Installing Terminations with MOSR Frames
1212
12
MOSR
1. Frame the termination opening to 12" x 12".
2. Fasten the MOSR rame to the interior side o the studs using a
minimum o 4 screws.
3. Insert the termination into the MOSR rame as shown here, and
attach by screwing through the our pilot holes in the termination.
MSR
PTO-3
PTO-3F
PTO-3
PTKOGPTKOG
PTKOGPTKOG
PTKOG
1. Ensure that the two long mounting brackets are acing the
bottom o the termination. (See inset). This will provide more
heat protection at the top o the termination, where temperatures
are highest.
2. Attach to the aceplate o the termination using our sheet metal
screws.
Installing Heat Guards over Terminations
Installation

Page 6Page 6
Page 6Page 6
Page 6
C38-DV Gas Fireplace
Part No. XG0118B
Installation
Top Vent Venting Runs
For the C38-DV Top ent, there are two types o installations: A)
Through-The-Wall Installations and B) Vertical (Through-The-Roo )
Installations.
A) Through-The-Wall Installations
Be ore you install any venting, you must determine whether the venting
run will be acceptable. Unacceptable venting can a ect the ireplace's
combustion.
The enting Graph
Measure the vertical height rom the ireplace hearth to the centre
o the termination and the horizontal run rom the rom the
ireplace lue collar to the wall lange o the termination. Plot on the
Venting Graph (Fig. 7) with an 'X'.
I the 'X' alls on or above the top boundary o the shaded area,
the installation is acceptable.
Example A: (Acceptable Installation)
I the vertical dimension rom the hearth is 84" and the
horizontal run to the wall lange o the vent termination is 36",
this would be an acceptable installation.
Example B: (Acceptable Installation)
I the vertical dimension rom the hearth is 90" and the
horizontal run to the wall lange o the vent termination is
120", this would be an acceptable installation.
Example C: (Unacceptable Installation)
I the vertical dimension rom the loor o the ireplace is 72"
and the horizontal run to the wall lange o the vent termina-
tion is 84", this would NOT be an acceptable installation.
Figure 7. Venting raph
Figure 8. Heat Shield. Install by sliding over the vent pipe where it
passes through combustible construction.
Heat Shields
Due to high lue temperatures, heat shields are required on all
C38-DV installations (except those with vertical terminations) at
the point where the venting connects
to the termination. With the heat
shield, vent clearances can be
maintained at 1".
012 24 36 48 60 72 84 96 108 132120 144 156 168 180
Horizontal Run (in.)
H arth
0
12
24
36
48
60
72
84
96
108
Available Top ent Components
The ollowing venting components are available or the C38-D
Top ent:
A - Termination PTO-3 (3" length)
PTO-3F (3" length)
B - Stucco Kits MSR (stucco rame)
MOSR (stucco can)
BSR (brick can)
C - Flex sections PFL-1 (12" section)
PFL-2 (24" section)
PFL-3 (36" section)
PFL-4 (48" section)
D - Rigid sections PEXT-1 (12" m/ section)
PEXT-2 (24" m/ section)
PEXT-3 (36" m/ section)
PEXT-4 (48" m/ section)
PEXT-6 (72" m/ section)
E - Elbows PEL-90MM (m/m 90° elbow)
PEL-90FF ( / 90° elbow)
PEL-90FM ( /m 90° elbow)
NOTES: All dimension lengths or vertical or horizontal runs are
measured rom center o the vent pipe.
Venting runs must all within the limits set by the
venting graph (see Figure 7).

Page Page
Page Page
Page
C38-DV Gas Fireplace
Part No. XG0118B
Installation
T rmination
Example 1:Example 1:
Example 1:Example 1:
Example 1:
For our shortest venting con iguration use components A and F (see
Figure 9a).
Figure 9a. Typical Top Vent installation. If the 90° elbow is
installed directly on the fireplace, the height to the
center of the termination is 43½".
Horizontal enting
Figure 9b. Typical Top Vent installation. The solid sections can be
used in various combinations to obtain the desired vent
run. The vent run must fall within the limits set by the
venting graph.
90° Elbow
PEXT S ction
Example 2:
Rigid sections and an elbow used in conjunction with 3 t. lex section
(PFL-3) will, when extended in a ive oot chase, allow or a maximum
horizontal run o twelve and one-hal eet rom the centre o the
ireplace to outside wall and a minimum o 7'6" when retracted in
opposite direction (see Figure 10 and 11).
"C" lex sections and "D" rigid sections may be used in conjunction with
one another to obtain di erent possible horizontal length installations.
NOTE: Flex section with no vertical rise must not exceed maximum
horizontal length o 3 eet (see Figure 12). Flex runs over 3 eet must
all within the limits set by the venting graph, and must have a minimum
vertical rise o 3" per oot o lex.
Figure 10. Extended Installation using a combination of solid and
flex venting. Use the vent graph to determine your
allowable run, then select appropriate components.
Figure 11. Retracted Installation using a combination of solid and
flex venting. Use the vent graph to determine your
allowable run, then select appropriate components.
H arth
T rmination
Ext rior
Wall
3' max.
Fl x S ction
H arth
Fl x S ction T rmination
Ext rior
Wall
126"
30" Max.
Solid S ction w/
90° Elbow
H arth
Fl x S ction
Solid S ctions
T rmination
Ext rior
Wall
150" max.
30" max.
Rigid S ction
PEL-90F/F Elbow Rigid S ction
Figure 12. Horizontal flex installation with no vertical rise.

Page 8Page 8
Page 8Page 8
Page 8
C38-DV Gas Fireplace
Part No. XG0118B
Storm collar
Support ring
MEXT
Solid S ction
Roof flashing
30' max.
* Minimum 1" cl aranc to all combustibl s
Support plat
Fir stop
Fir stop
2' min.
MXT-10
Adaptor
MEXT
Flu
Collar
2' min.
Storm collar
Support ring
Roof flashing
30' max.
* Minimum 1" cl aranc to all combustibl s
Support plat
Fir stop
Installation
B. ertical (Through-The-Roof) Installations
5/8" with option for 4/7"
nVertical rise >12' can be reduced
nVertical Terminations must be installed:
•minimum 2' (two eet) above the highest point where
vent passes through the roo .
•minimum 6' (six eet) rom a mechanical air inlet
•minimum 3' (three eet) rom a parapet wall.
nMaximum vent height is 30 eet above ireplace.
Note: Flame characteristics will change i the maximum vent height
is used.
nMinimum clearances 1" rom vent to all combustible materials must
be maintained.
Figure 13.a Straight, vertical venting using required adaptor.
nA maximum o two o sets with 90° bends may be made and shall not
exceed total length o 25% o the vertical vent height, when measured
center to center o piping.
Example: Typical vent installation.
20' vertical vent
2 - 2' o sets required
25% o 20' = 5' max. o set allowed
This venting con iguration meets requirements.
Figure 14a. Vertical venting with 1 offset.
30' max.
30' max.
Rigid S ction
A
A.Mal /F mal
B.F mal /F mal
C.Mal Flu Collar
B
C
Figure 13b. Reducing Vertical Vent from 5/8" to 4/7".
ent Restrictors
When venting vertically, Vent Restrictors may be added to enhance the
burn characteristics o the ireplace.
Part Size 5"/8" enting 4"/7" enting
- Termination n/a PVTK-1 MVTK-1
B - Flex sections 12" length PFL-1 MFL-1
24" length PFL-2 MFL-2
36" length PFL-3 MFL-3
48" length PFL-4 MFL-4
C - Solid sections 12" length PEXT-1 MEXT-1
24" length PEXT-2 MEXT-2
36" length PEXT-3 MEXT-3
48" length PEXT-4 MEXT-4
D - Support Ring
& Plate PSPXT-8 MSPXT-7
E - Firestop PS-8 FS-7
F - Roof Flashing (1/12-7/12 pt.) PRF-7 MRF-7
(7/12-12/12 pt.) PRF-12 MRF-12
G - daptor/ (5"/8" to 4"/7") PV 5487
Vent Reducer

Page 9Page 9
Page 9Page 9
Page 9
C38-DV Gas Fireplace
Part No. XG0118B
Installation
2. 45° Corner Installation.
Attach an PEL-45 (45° elbow) directly onto the lue collar. Cut the
PXT-20 to suit, and attach it to the PEL-45. Slide the ireplace into
position and attach to the termination. Maximum horizontal run
must not exceed 20".
Rear Vent Venting Runs
The C38-D Rear ent has three possible installations which do not
require vertical li t:
Heat Shields
Due to high lue temperatures, heat shields are required on all C38-DV
installations (except those with vertical terminations) at the point where
the venting connects to the termination. With the heat shield, vent
clearances can be maintained at 1". *Heat Shields are included
See Figure 8.
1. Straight Installation.
The height rom the hearth to the center o the termination is
28 3/8". C38-DV Rear Vent versions are supplied with a 20"
extension pipe (PXT-20) with emale/ emale connections. For
shorter installations, cut the PXT-20 to the desired length.
For extended installations, use the PXT-20 section as supplied or a
20" vent run.
Note: For Rear Vent models, maximum horizontal run with no
vertical li t must never exceed 20".
Flue Collar
Heat Shield
EXT-18
Termination
Figure 15. Extended installation.
Heat Shield
EXT-18
Termination
EEL-45
Elbow
Flue Collar
Figure 16. Corner installation.
3. Corner Installation — 45° or less.
Use an PTO-3 termination and an PFL-1 or PFL-2 (12" or 24"
compressed length) and a rame, i appropriate. Flex may be
turned to obtain desired degree o angle required but must not
exceed 45°.
Figure 17. Flex installation.
Heat Shield
Termination
Flex
Section
Flue Collar
PXT-20
PXT-20
PEL-45
Figure 14b. Vertical venting with 2 offsets.
2' min.
2'
Storm collar
Roof flashing
30' max.
* Minimum 1" cl aranc to all combustibl s
Support straps or
support plat & ring
Fir stop
Fir stop
Fir stop
Support plat
& ring
30' max.

Page 10Page 10
Page 10Page 10
Page 10
C38-DV Gas Fireplace
Part No. XG0118B
Installation
B. Multi-Elbow Installations
For more di iicult installation situations, the C38-DV Rear Vent may
be installed with two — 90° elbows and up to 15' o horizontal run. I
using this installation option, you must adhere to the ollowing
guidelines:
nthe irst 90° elbow must be placed directly on the lue collar
nyou must have a minimum vertical li t o 50" (measured rom
the hearth)
nyour vent run must all within the limits set by Figure 18a
Be ore you install any venting, you must determine whether the
venting run will be acceptable. Unacceptable venting can a ect the
ireplace's combustion.
The enting Graph
Measure the vertical height rom the ireplace hearth to the centre
o the termination and the horizontal run rom the rom the ireplace
lue collar to the wall lange o the termination. Plot on the Venting
Graph (Fig. 18a) with an 'X'.
I the 'X' alls on or above the top boundary o the shaded area, the
installation is acceptable.
Example A: (Acceptable Installation)
I the vertical dimension rom the hearth is 84" and the
horizontal run to the wall lange o the vent termination is 36",
this would be an acceptable installation.
Example B: (Acceptable Installation)
I the vertical dimension rom the hearth is 90" and the
horizontal run to the wall lange o the vent termination is 126",
this would be an acceptable installation.
Example C: (Unacceptable Installation)
I the vertical dimension rom the loor o the ireplace is 78"
and the horizontal run to the wall lange o the vent termination
is 108", this would NOT be an acceptable installation.
Figure 18a. C38-DV Rear Vent Venting raph
0 12 24 36 48 60 72 84 96 108 132120 144 156 168 180
Horizontal Run (in.)
H arth
0
12
24
36
48
60
72
84
96
108
Installation Of Rear Vent DV
C38-DV Rear Vent versions are supplied with an PXT-20 ( emale/
emale) section. In addition, the ollowing venting components are
available or Rear ent installations:
A - Termination PTO-3 (3" length)
PTO-3F (3" length)
B - Stucco Kits MSR (stucco rame)
BSR-4 (4" brick rame)
BSR-6 (6" brick rame)
MOSR (stucco can)
C - Flex sections PFL-1 (12" section)
PFL-2 (24" section)
PFL-3 (36" section)
PFL-4 (48" section)
D - Solid sections PEXT-1 (12" section)
PEXT-2 (24" section)
PEXT-3 (36" section)
PEXT-4 (48" section)
E - 90 degree elbow PEL-90MM (m/m 90° elbow)
PEL-90FF ( / 90° elbow)
PEL-90FM ( /m 90° elbow)
PEL-45FM ( /m 45° elbow)
Figure 18b. Multi-elbow installation. Distance 'H' must be a
minumum of 50". The vent run must comply with figure
18a.
NOTES: All dimension lengths or vertical or horizontal runs
are measured rom center o the vent pipe.
Venting runs must all within the limits set by the
venting graph (see Figure 18a).
8"
H
L
18"

Page 11Page 11
Page 11Page 11
Page 11
C38-DV Gas Fireplace
Part No. XG0118B
Finishing Around the Fireplace
Combustible mantels and mouldings may be sa ely installed over the top
and on the ront o the ireplace provided that they do not project
beyond shaded area shown in Figure 19. Side wall clearances are 3".
Combustible surrounds may be installed with 3" clearance to the side o
the ireplace as shown in Figure 20.
Fireplace Facing
When selecting the inish material or your ireplace, it is important to
remember the ollowing: TRIMS MUST NOT BE OBSTRUCTED IN
ANY WAY - to do so restricts the air supply for the control
compartments and heat exchanger it also prevents access for
servicing controls.
The ace o the ireplace may be painted to match the room decor,
provided you use a heat-resistant paint. Decorative acing must not
extend past the ireplace opening at all, because it will inter ere with the
access to retainers or removal o glass door.
Installation
Figure 19. Combustible mantles and facings.
Mantels, Hearth, & Surrounds
NOTE: National Canadian Gas Association mantel test requirements
are or ire hazard prevention to combustible materials.
NOTE: It is not required that you install a mantel, hearth or surround.
New technology, to meet consumer and government demands or the
wise use o energy, has prompted us to manu acture many models o
ireplaces which are hot, uel and energy e icient.
Please be aware; temperatures over the mantel will rise above normal
room temperature and walls above ireplace may be hot to touch.
We recommend care ul consideration be given to the e ects o
elevated mantel temperatures which may be in excess o product
design, or example: candles, plastic or pictures. This can cause
melting, de ormation, discoloration or premature ailure o T.V. and
radio components.
Painting:
Special care is recommended by the Master Painters and Decorators
Association, when painting the ireplace surrounds, to select and apply
a quality Alkyd sealer prior to the applying o latex paints. This is to
prevent leaching o water rom evaporation and causing a brownish
staining e ect to paint over coats.
Sh trock/
Drywall
H ad r
3
45°
Figure 20. Combustible surrounds.

Page 12Page 12
Page 12Page 12
Page 12
C38-DV Gas Fireplace
Part No. XG0118B
Removing and Installing
the Door
Removing the Door:
Remove the trim (as described on the next page) to access the door
latches. Open the latches by pulling Part A upwards and towards you
to disengage Part B rom the door. Li t Part B clear o the door.
Repeat or all three latches. Be sure to hold the door care ully so it
does not all. (See figure 23a.)
Installation
Once the three latches are unhinged, tilt the top o the door orward
and li t it out o the slots. See figures 23b and 23c.
Figure 23a. Operating the door latches.
Figure 22a. Wiring for optional air circulating fan kit.
G
L1-WH
L2-BLK
Quick Conn ct
plug to motor
Wiring for the optional Fan Kit
All C38-DV ireplaces may be equipped with optional an kits (Part
no. RFK1001, RFK1003, RFK1006 or RFK1007) or circulating heat
into the living space.
Installations in Canada which employ the ans must be electri-
cally grounded in accordance with CSA C22.1 Canadian Electrical
Code Part 1 and/or Local Codes.
Installations in the USA which employ the ans must be
grounded in accordance with local codes or, in the absence o
local codes, with the National Electrical Code, ANSI/NFPA 70-
1987.
For more in ormation see the Fan Kit Installation Guide included
with the an kit.
NOTE: I any o the original wire supplied with the appliance is replaced, it
must be replaced with the same type, or its equivalent.
Figure 22b. Wiring schematic for optional fan kit.
115/1/60 Supply
G L1 L2
Figure 23b. Removing the door.

Page 13Page 13
Page 13Page 13
Page 13
C38-DV Gas Fireplace
Part No. XG0118B
Installation
NOTES:
nIf logs are not placed properly, excessive sooting will result.
nThe surface of the logs will crack due to the heat from the
flames. This is a normal occurance.
Embers
Log 'D' Log 'E'
Flame Shaper
Log 'A'
Log 'C' Log 'B'
Figure 23c. Removing the door.
Re-installing the door:
To re-install the door, tilt the top edge towards you and line up the tabs
o the bottom o the door with the slots on the ireplace. Place the tabs
into the slots, and tilt the top o the door back towards the ireplace as
ar as it will go. Close the latches by hooking Part B onto the groove at
the top o the door and pushing Part A down completely.
Figure 25. Installing the horizontal trim pieces.
Installing the Trim & Baffle
The ireplace is shipped with 6 horizontal trim pieces (3 upper and 3
lower), which must be ield-installed.
Install the trim by placing the top edge o the trim over to the
retainer clips on either side o the ireplace. Push the bottom edge
irmly inwards and the trim will snap on. (See figure 25) Remember to
slide the ba le into the top trim piece . (See Inset)
Note: Ba le should rest on top o the tabs.
Inset. Slide in baffle
before installing top trim.
Installing the Log Set
Installing the Logs:
The C38-D is supplied with ive ceramic ibre logs. Unpack the logs
and handle them very care ully.
1. Remove the door cover and the glass door.
2. Place the Back log onto the back log rest as shown below in igure
24a. The log has lip on the bottom which its into the slot on the log rest.
3. Place the Front log onto the ront log rest as shown in igure 24a.
Center the log rom side to side, and push it against the back o
the log rest. Care ully push the log onto the metal spikes on the log rest.
4. Place the top logs in position as shown in igure 24b, place the
centre log down irst, then the right and le t logs.
5. Start the ireplace. I the lame appears satis actory, replace the
glass door and door cover.
Figure 24a. Positioning for the front and back logs.
Figure 24b.Proper log placement.

Page 14Page 14
Page 14Page 14
Page 14
C38-DV Gas Fireplace
Part No. XG0118B
WARNING:WARNING:
WARNING:WARNING:
WARNING: If you do not follow these instructions exactly, a fire or explosion
may result causing property damage, personal injury or loss of life.
nI you cannot reach your gas supplier, call the Fire
Department.
C. Use only your hand to push in or turn the gas control knob.
Never use tools. I the knob will not push in or turn by
hand, don't try to repair it, call a quali ied service technician.
Force or attempt to repair may result in a ire or explosion.
D. Do not use this appliance i any part has been under water.
Immediately call a quali ied service technician to inspect the
appliance and to replace any part o the control system, and
any gas control which has been under water.
A. This appliance has a pilot which must be lighted by hand.
When lighting the pilot, ollow these instructions exactly.
B. BEFORE LIGHTING smell all around the appliance area or
gas. Be sure to smell next to the loor because some gas is
heavier than air and will settle on the loor.
What To Do If You Smell Gas:
nDo not try to light any appliance.
nDo not touch any electrical switch; do not use any
phone in your building.
nImmediately call your gas supplier rom a neighbour's
phone. Follow the gas supplier's instructions.
To Turn Off Gas To Appliance:
Operation - Model C38-DV
3. Push in gas control knob slightly and turn clockwise
to "O ". Do not orce.
4. Flip up the lower trim.
1. Turn o remote switch.
2. Flip down the lower trim.
1. STOP! Read the sa ety in ormation above on this label.
2. Flip down the lower trims.
3. Push in gas control knob and turn clockwise to
"OFF."
4. Wait ive (5) minutes to clear out any gas. Smell or gas,
including near the loor. I you then smell gas, STOP!
Follow "B" in the sa ety in ormation above on this label. I
you don't smell gas, go to the next step.
5. Locate pilot burner (See illustration at right.) and ollow
steps below.
6. Turn knob on gas control counterclockwise to
"PILOT."
7. Push in gas control knob completely and hold. Light with
Piezo Igniter button. Continue to hold the control knob in or
about (1) minute a ter the pilot is lit. Release the knob and it
will pop back up. Pilot should remain lit. I it goes out repeat
steps 3 through 8.
nI knob does not pop up when released. Stop and
immediately call your service
technician or gas supplier.
nI the pilot will not stay lit a ter
several tries, turn the gas control
knob to "OFF" and call your service
technician or gas supplier.
8. Push in gas control knob and turn counterclockwise
to "ON."
9. Flip up the lower trim.
10.Turn on remote switch to ignite ire.
Lighting Instructions:
C38-DV
with Millivolt (Standing) Pilot
For Your Safety - READ BEFORE LIGHTING:
Gas Control Knob
(Shown in "Pilot" postion.) NOTE:NOTE:
NOTE:NOTE:
NOTE: Knob cannot be turned from
"PILOT" to "OFF" unless knob is
pushed in slightly. Do not force.

Page 15Page 15
Page 15Page 15
Page 15
C38-DV Gas Fireplace
Part No. XG0118B
with Pilotless (Spark-to-Burner) Ignition
Operation - Model C38-DV-S
C38-DV-S
A. This appliance does not have a pilot. It is equipped with an
ignition device which automatically lights the burner. Do not
attempt to light the burner by hand.
B. BEFORE OPERATING smell all around the appliance area or
gas. Be sure to smell next to the loor because some gas is
heavier than air and will settle on the loor.
What To Do If You Smell Gas:
nDo not try to light the appliance.
nDo not touch any electrical switch. Do not use any phone in
your building.
nImmediately call your gas supplier rom a neighbour's
1. STOP! Read the sa ety in ormation above on this label.
2. Make sure the wall switch is in the "OFF" position. Flip down the lower
horizontal trim.
3. Wait 5 minutes to clear out any gas. I you smell gas, STOP! Follow "B" in
the sa ety in ormation above on this label. I you don't smell gas, go to step
4.
4. Find the indicator light on the control module, located under the ireplace near
the gas control valve. I the indicator light is lashing slowly, the system is
ready or lighting.
5. Turn on the wall switch. You will hear a 'ticking' sound as the system
attempts to light the ireplace. I success ul, the main burner will ignite, and the
indicator light will lash quickly.
I not success ul, the system will automatically close the gas valve to stop
the low o gas. The indicator light will double lash, and the system will lock
out or ive minutes.
6. Flip up the lower horizontal trim.
1. Turn o the wall switch.
phone. Follow the gas suppliers instructions.
nI you cannot reach your gas supplier, call the Fire Depart-
ment.
C. Do not tamper with, or attempt to repair the gas control valve. I
the system does not operate properly, call your service techni-
cian or gas supplier. Force or attempted repair may result in a
ire or explosion.
D. Do not use this appliance i any part has been under water.
Immediately call a quali ied service technician to inspect the
appliance and to replace any part o the control system, and any
gas control which has been under water.
2. I service is to be per ormed, turn o all electric power to the appliance.
Control Module
Indicator Light
Rear Burner Tube
Ignitor / Flame
Sensor Probe
OUT
Gas Control Valve
WARNING: I you do not ollow these instructions exactly, a ire or explosion may result
causing property damage, personal injury or loss o li e.
For Your Safety - READ BEFORE LIGHTING:
To Turn Off Gas To Appliance:
Lighting Instructions:

Page 16Page 16
Page 16Page 16
Page 16
C38-DV Gas Fireplace
Part No. XG0118B
Maintenance
WW
WW
WARNING:ARNING:
ARNING:ARNING:
ARNING:
Do not attempt to clean glass when hot.
Do not clean glass with abrasive materials as any glass
etching may cause premature glass ailure.
CAUTIONSCAUTIONS
CAUTIONSCAUTIONS
CAUTIONS
nFireplace gas control must be in the “OFF” position and pilot
and main burners extinguished when cleaning appliance with
a vacuum.
nDoors and logs can get very hot. Handle only when cool.
General
nHave the ireplace installation inspected yearly, including a
visual check o the vent system, the burner and the pilot lame.
For your convenience a 1/8" mani old pressure tap is supplied
on the gas valve or a test gauge connection. See Figure 27.
nFor Natural Gas this appliance requires a minimum inlet
pressure o 5.5" W.C. and a mani old pressure o 3.5" W.C.
nFor Propane Gas this appliance requires a minimum inlet
pressure o 11" W.C. and a mani old pressure o 10" W.C.
nAlways keep the ireplace area clear and ree o combustible
materials, as well as gasoline and other lammable vapours and
liquids.
nDo not use this appliance i any part has been under water.
Immediately call a quali ied service technician to inspect the
appliance and to replace any part o the control system and any
gas control which has been under water.
Operation
Lighting Instructions
See pages 14 and 15.
Burner Adjustment
The C38-DV (millivolt model only) is equipped with an adjustable
burner, allowing you to raise or lower the lames. To adjust the lames,
locate the black knob marked 'Hi-Lo', in the centre o the gas control
valve (See Figure 26). The ront burners are not adjustable.
nTo raise the lame height, turn the black knob (located behind the
lower trim) counterclockwise.
nTo lower the lame height, turn clockwise.
Figure 26. 'Hi-Lo' Adjustment on the C38-DV's gas valve.
Cleaning
When the ireplace is irst activated, there may be some smoking
and a visible ilm may be le t on the glass. This is a normal
condition, and is the result o burning o protective coatings on
new metal.
nGlass must be cleaned periodically to remove any ilm (which
is a normal biproduct o combustion) which may be visible.
Film can easily be removed by removing the door, as shown
on page 12-13. Handle the door care ully, and clean it with
non-abrasive glass cleaners. One o the most e ective
products is Kel Kem.
nSilicone seals on inner door during initial iring will "o gas",
leaving a visual deposit o a white substance on combustion
chamber walls. This can easily be removed using normal
household products.
nUse a vacuum cleaner or whisk broom to keep the control
compartment, burner, and irebox ree rom dust and lint.
nLogs may be cleaned periodically with a vacuum to remove
soot or other contaminates.
Note: C38-DV-S models (pilotless ignition) do not feature
hi/lo adjustment.

Page 1Page 1
Page 1Page 1
Page 1
C38-DV Gas Fireplace
Part No. XG0118B
Maintenance
Troubleshooting C38-DV-S
Gas Control Valve (C38-DV)
Figure 27 Sit Nova 820 gas valve.
Pilot Burner Adjustment (C38-DV)
1. Locate Pilot Adjustment Screw. (See figure 27.)
2. Adjust pilot screw to provide properly sized lame as shown in figure
28).
3. A ter installing or servicing, leak test with a soap solution with main
burner on. Coat pipe and tubing joints, gasket etc. with soap solution.
Bubbles indicate leaks. Tighten any areas where the bubbles
appear until the bubbling stops completely.
Figure 28. Pilot Burner
Manifold Pr ssur
T st Conn ction
Pilot Adjustm nt Scr w
Inl t
Pr ssur
Pow r
G n rator
Wall Switch
Troubleshooting
The ollowing is a troubleshooting chart o possible problems:
PROBLEM CORRECTI E ACTION
Noisy Pilot Flame Locate pilot adjustement screw on
gas control valve. Flame is decreased by
turning adjustment screw clockwise.
Pilot won’t ignite Disconnect remote wires and try to
light pilot. I pilot now works, remote
connections are aulty. Check wiring
diagram figure 27.
Main burner will 1. Check wiring (see figure 27).
not light 2. Check wall switch or proper
connection.
C38-DV
A. Diagnosing the status using the indicator light.
The LED indicator light on the control module will show the control
system's current status.
LED Pattern Status
No Light System does not have power.
Action: Ensure that the power cord is
plugged into the PPO-D box. See
Figure 30.
Slow Steady Flash System is ready.
Fast Steady Flash System is trying to light the burner.
Double Flashes 5 Minute Lockout. The system did not
light/remain lighted success ully.
Action: Wait ive minutes be ore
attempting to re-light the burner.
Continuous On Hard system lockout. You must inplug
the power cord rom the PPO-D box to
reset the system. (See figure 30.)

Page 18Page 18
Page 18Page 18
Page 18
C38-DV Gas Fireplace
Part No. XG0118B
The WarrantyThe Warranty
The WarrantyThe Warranty
The Warranty
The Companies warrants the Montigo Gas Appliance to be ree rom de ects in materials and workmanship at the time o manu acture. On the Montigo, there is a ten-
year warranty on the irebox and its components, a ive-year warranty on the main burner and pilot burner, and a one-year warranty on the gas control valve and ibre logs.
Glass, plated/painted inishes, and re ractory lining are exempt.
Remedy And Exclusions
The coverage o this Warranty is limited to all components o the Gas Appliance manu actured by The Companies.
This Warranty only covers Montigo Gas Appliances installed in the United States or Canada.
I the components o the Gas Appliance covered by this Warranty are ound to be de ective within the time rame stated (see The Companies right o investigation outlined
below). The Companies will, at its option, replace or repair de ective components o the Gas Appliance manu actured by The Companies at no charge, and will also pay
or reasonable labour costs incurred in replacing or repairing components. I repair or replacement is not commercially practical, The Companies will, at its option, re und
the purchase price o the Montigo Gas Appliance.
This Warranty covers only parts and labour as provided above. In no case shall The Companies be responsible or materials, components, or construction which are not
manu actured or supplied by The Companies, or or the labour necessary to install, repair or remove such materials, components or construction. All replacement or repair
components will be shipped F.O.B. the nearest The Companies actory.
Qualifications To The WarrantyQualifications To The Warranty
Qualifications To The WarrantyQualifications To The Warranty
Qualifications To The Warranty
The Gas Appliance Warranty outlined above is urther subject to the ollowing quali ications:
(1) The Gas Appliance must be installed in accordance with The Companies installation instructions and local building codes. The Warranty on this Montigo Gas Appliance
covers only the component parts manu actured by The Companies. The use o components manu actured by others with this Montigo Gas Appliance could create
serious sa ety hazards, may result in the denial o certi ication by recognized national sa ety agencies, and could be in violation o local building codes. This warranty
does not cover any damages occurring rom the use o any components not manu actured or supplied by The Companies
(2) The Montigo Gas Appliance must be subjected to normal use. The Gas Appliances are designed to burn gas only. Burning conventional ireplace uels such as wood,
coal or any other solid uel will cause damage to the Gas Appliance, will produce excessive temperatures and will result in a ire hazard.
Limitations On LiabilityLimitations On Liability
Limitations On LiabilityLimitations On Liability
Limitations On Liability
It is expressly agreed and understood that The Companies sole obligation, and purchaser's exclusive remedy under this Warranty, under any other warranty, expressed
or implied, or in contract, tort or otherwise, shall be limited to replacement, repair, or re und, as speci ied above.
In no event shall The Companies be responsible or any incidental or consequential damages caused by de ects in its products, whether such damage occurs or is discovered
be ore or a ter replacement or repair, and whether or not such damage is caused by The Companies negligence. Some states do not allow the exclusion or limitation o
incidental or consequential damages, so the above limitation or exclusion may not apply to you. The duration o any implied warranty with respect to this Montigo Gas Appliance
is limited to the duration o the oregoing warranty. Some states do not allow limitation on how long an implied warranty lasts, so the above may not apply to you.
Investigation Of Claims Against WarrantyInvestigation Of Claims Against Warranty
Investigation Of Claims Against WarrantyInvestigation Of Claims Against Warranty
Investigation Of Claims Against Warranty
The Companies reserves the right to investigate any and all claims against this Warranty and to decide upon method o settlement.
The Companies Are Not Responsible For Work Done Without Written Consent
The Companies shall in no event be responsible or any warranty work done without irst obtaining The Companies written consent.
Dealers Have No Authority To Alter This Warranty
The Companies employees and dealers have no authority to make any warranties nor to authorize any remedies in addition to or inconsistent with those stated above.
How THow T
How THow T
How T
o Register A Claim Against Wo Register A Claim Against W
o Register A Claim Against Wo Register A Claim Against W
o Register A Claim Against Warrantyarranty
arrantyarranty
arranty
In order or any claim under this Warranty to be valid, The Companies must be noti ied o the claimed de ect in writing or by telephone, as soon as reasonably possible
a ter the de ect is discovered. Claims against this Warranty in writing should include the date o installation, and a description o the de ect.
Other RightsOther Rights
Other RightsOther Rights
Other Rights
This Warranty gives you speci ic legal rights, and you may also have other rights which vary rom state to state.
NOTE: The Companies as stated above re er to - Canadian Heating Products Inc. and/or Montigo Del Ray Corp.
Canadian Heating Products Inc. and/or Montigo DelRay Corp. reserves the right to make changes at any time, without
notice, in design, materials, specifications, prices and also to discontinue colors, styles and products.
Warranty

Page 19Page 19
Page 19Page 19
Page 19
C38-DV Gas Fireplace
Part No. XG0118B
Appendix A - Termination Locations
A= clearancetotheterminationframeabovegrade,veranda,porch,
deck,orbalcony [16 inches(41cm)minimum]
B= clearance to door, or sides and top of window, that may be opened
[16inches(41cm)minimumforappliances
≤≤
≤≤
≤ 100000BTU/H(30kW)]
C= clearance to bottom of window that may be opened horizontally
[36inches(92cm)minimumforappliances
≤≤
≤≤
≤ 100000BTU/H(30kW)]
D= no clearance to permanently closed window when installed with
approvedglasspenetrationtermination
E= clearanceto permanently closed window[16inches41cm
recommendedtopreventcondensationonwindow]
F= verticalclearancetoventilatedsoffitlocatedabovethetermination
withina horizontal distanceof 2 feet(61 cm)fromthe centrelineof
thetermination [22 inches (56cm) minimum]
G= clearancetounventilatedsoffit
[16inches(41cm)minimumtonon-combustibles]
[22inches(56cm)minimum to combustibles]
H= clearancetooutsidecorner[9inches(23 cm) minimum]
I= clearancetoinsidecorner[12inches(31cm)minimum]
J= *not to be installed abovea meter/regulator assemblywithin
40"(103 cm) horizontally fromthecentreline of the regulator
K= clearancetoserviceregulatorventoutlet [3 feet minimum in the
United States] [*6 feet (1.8 m) minimum in Canada]
L = clearance to nonmechanical air supply inlet to building or the
combustionairinlettoanyotherappliance[16inches(41cm)
minimumforappliances
≤≤
≤≤
≤ 100000BTU/H(30kW)]
M= clearancetomechanicalairsupplyinlet
[*6 feet (1.8 m) minimum]
N= †clearanceabovepavedsidewalkorapaveddrivewaylocatedon
public property [*7 feet (2.1 m) minimum]
P= clearanceunderveranda,porch,deck,orbalcony
[16inches(41 cm)minimum‡tonon-combustibles]
[22inches(56cm) minimum‡to combustibles]
Q= clearanceabove aroof[24inches(61cm)minimum]
R= clearancetoadjacent walls and neighbouringbuildings
[18inches(46 cm) minimum]
S= clearancefromcornerinrecessedlocation
[12inches(31 cm) minimum]
T= maximumdepth inrecessedlocation
[48 inches (122cm)minimum]
U= minimum width for back wall of recessed location
[24 inches (61 cm) minimum]
V= nohorizontalclearancebetween the frames oftwoterminations
thatarelevel.
W= horizontalclearancebetweentheframesoftwoterminationsthat
are not level. [36 inches (92 cm) minimum]
†aventshall not terminatedirectlyaboveasidewalkorpaved
driveway which is located between two single family dwellings
andserves bothdwellings
‡onlypermitted ifveranda, porch, deck,or balcony hasan open
sidethatisequalto or greater than the depthoftheenclosedarea
*asspecifiedinCGAB149InstallationCodes.Note: local Codes or
Regulationsmayrequiredifferentclearances

Page 20Page 20
Page 20Page 20
Page 20
C38-DV Gas Fireplace
Part No. XG0118B
Figure 29b.Wiringschematicforusingtwowallswitches:onetocontrol
thefireplace andaanothertocontroloptionalfansforthe
fireplace.
Option - Single Wall Switch
for STB Control Only
Use this wiring option when installing a single wall switch to control the
ireplace only. The switch on the yellow circuit controls the Spark To
Burner (STB) system. The blue circuit provides power to the optional
ans and is always hot.
The ireplace can be sa ely wired this way, even i ans are not installed.
The ans can be added later, i desired.
Option B - Two Wall Switches
for STB and Fan Control
This wiring option is or installing two wall switches. The switch on the
yellow circuit controls the Spark To Burner (STB) system. The other
switch (blue circuit) is or controlling the optional ans.
The ireplace can be sa ely wired this way, even i ans are not installed.
The ans can be added later, i desired.
Figure 29a. Wiringschematicforusingasinglewallswitchtocontrolthe
fireplace.Thecircuitthatsupplieselectricitytotheoptional
fansisalwayshot.
Figure 30. STBsystemwiringschematicshowingthewiringofthecontrolmodule
andgascontrolvalvetothehouseholdelectricalsupply.
System Wiring Schematic
WARNING:
Unplug the Power Cord Before
Resetting the Spill Switch
The spill switch is located behind the
upper horizontal trims on the right hand
side o the ireplace. I the spill switch trips
it will shut down the ireplace (causing the
red button to pop out).
You must disconnect the power cord
rom the PPO-D box (see ig. 3), be ore
resetting the switch. To reset the switch,
push the red buttom in using the bottom
o a pen or other blunt object.
Appendix B - Wiring for STB-Equipped fireplaces
