Montigo H42-DF Instruction Manual

H42DF HL42DF
HR42DF HW42DF
Indoor
Resi
dential
Gas Fireplace
®
C US
Read and understand this manual. Improper installation, adjustment, alteration,
service or maintenance can cause serious injury, property damage or even death.
For assistance or additional information consult a qualified installer, service
agency or the gas supplier.
DANGER
Glass doors on gas fireplaces are extremely hot while the fireplace is on and
remain hot even after the fireplace has been turned off. Safety screens are
available and can reduce the risks of severe burns. Please keep children away
from the fireplace at all times.
CAUTION
Installation & Maintenance Manual
Do not store or use gasoline or any other flammable vapors and liquids in the vicinity of
this or any other gas burning appliance. A fire or explosion my occur causing serious
injury, property damage or even death.
WARNING
Installer: Leave this manual with the appliance. Do not remove.
Consumer: Retain this manual for maintenance and future reference. Do not Discard.
NOTICE
IF YOU SMELL GAS
Do not try to light any appliance.
Do not touch any electrical switch; do not use any phone in your building.
Immediately call your gas supplier from a neighbor's phone. Follow the gas
supplier's instructions.
If you cannot reach your gas supplier, call the fire department.
DANGER
Irritant
Cutting
Watch your step
Slippery floor
High temperatures
Glass hazard
Danger of suffocation
High voltage
Toxic
Flammable materials
Corrosive
Fork lift trucks
Danger overhead crane
Explosion risk
Oxidising
Danger of death
Biohazard
Laser Radiation
Danger of entrapment
Hot surface
General Warning
Blank
Gas bottles
Watch for
falling objects
Electricity
Danger for cutter
Entrapment hazard
Battery hazard
Rotating parts
Low temperature
Strong magnetic field
Optical radiation
Non ionizing
radiation
Radiation
Hazardous to the
Environment
Danger of harming
your hands
Irritant
Cutting
Watch your step
Slippery floor
High temperatures
Glass hazard
Danger of suffocation
High voltage
Toxic
Flammable materials
Corrosive
Fork lift trucks
Danger overhead crane
Explosion risk
Oxidising
Danger of death
Biohazard
Laser Radiation
Danger of entrapment
Hot surface
General Warning
Blank
Gas bottles
Watch for
falling objects
Electricity
Danger for cutter
Entrapment hazard
Battery hazard
Rotating parts
Low temperature
Strong magnetic field
Optical radiation
Non ionizing
radiation
Radiation
Hazardous to the
Environment
Danger of harming
your hands
Irritant
Cutting
Watch your step
Slippery floor
High temperatures
Glass hazard
Danger of suffocation
High voltage
Toxic
Flammable materials
Corrosive
Fork lift trucks
Danger overhead crane
Explosion risk
Oxidising
Danger of death
Biohazard
Laser Radiation
Danger of entrapment
Hot surface
General Warning
Blank
Gas bottles
Watch for
falling objects
Electricity
Danger for cutter
Entrapment hazard
Battery hazard
Rotating parts
Low temperature
Strong magnetic field
Optical radiation
Non ionizing
radiation
Radiation
Hazardous to the
Environment
Danger of harming
your hands
Irritant
Cutting
Watch your step
Slippery floor
High temperatures
Glass hazard
Danger of suffocation
High voltage
Toxic
Flammable materials
Corrosive
Fork lift trucks
Danger overhead crane
Explosion risk
Oxidising
Danger of death
Biohazard
Laser Radiation
Danger of entrapment
Hot surface
General Warning
Blank
Gas bottles
Watch for
falling objects
Electricity
Danger for cutter
Entrapment hazard
Battery hazard
Rotating parts
XG0148 111111.1
Langley, BC V4W 4A1 |  Ferndale, WA 98248


You must read and understand this manual prior to installation, operation or
troubleshooting this appliance. Please retain this owner’s manual for furure reference
and maintenance.
NOTICE
XG0146 - 111111.1
Table of Contents

Introduction .................................................................................3
Models .................................................................................3
Section A: Before you Start
Before you Start .................................................................................4
Installation Checklist ...............................................................................4
Section 1: Installation Overview and Product Dimensions .....................5
Section 2: Framing the Fireplace .......................................................6 - 7
Clearances .................................................................................7
Installing the Standoffs .......................................................................7
Installing the Nailing Flange Extension ...............................................7
Section 3: The Direct Vent System ..................................................8 - 16
Air bafe positioning .......................................................................8
Section 3-1: Converting from Top Vent to Rear Vent ..............................8
Section 3-2: Installing a Roof mounted Termination .........................9 - 10
▪ Section 3-2-1: Venting Layout ..........................................................9
▪ Roof mounted Terminations
Standard Top Vent (no elbows or offsets).......................................9
Top Vent (two elbows one offset) ...................................................9
Top Vent (multi-elbows and offsets) ...............................................9
Standard Roof Vent (one elbows no offsets) ................................10
Section 3-3: Installing a Wall mounted Termination ..............................11
▪ Standard PTO Installation .......................................................... 11
▪ Pre-installed MSR Frame ..........................................................11
▪ Pre-installed BSR Frame ........................................................... 11
▪ Installing MOSR Frame .............................................................11
▪ Installing VSS Termination Shield .............................................. 11
▪ Installing PTKOG Heat Guard ...................................................11
▪ Section 3-3-1: Venting Layout ........................................................12
▪ Top Vent, Wall mounted Graph ..................................................12
▪ Top Vent, Wall mounted termination (one elbow) ......................12
▪ Top Vent, Wall mounted termination (multi elbow) .....................12
▪ Top Vent, Wall mounted termination (45° corner) ......................13
▪ Top Vent, Wall mounted termination (-45° corner) .....................13
▪ Rear Vent, Wall mounted Termination Graph ............................14
▪ Standard Rear Vent, (no elbows or offsets) ...............................14
▪ Rear Vent, Wall mounted termination (two elbows) ...................14
▪ Section 3-3-2: Venting Components ..............................................15
▪ Section 3-3-3: Heat Shields ...........................................................16
▪ Installing a RHS8 Wall Mounted Heat Shield .............................16
▪ Installing a RHS101 Wall Mounted Heat Shield .........................16
Section 4: Wiring ...............................................................................17
▪ SIT - Nova 820 gas control and pilot .....................................17
▪ SIT - Proame gas control and pilot ......................................17
▪ Honeywell gas control and pilot ............................................17
▪ Installing remote On/Off wall switch ......................................18
▪ Installing HFK Fan Kit ............................................................18
Section 5: Installing the Gas Line .........................................................19
Section 5-1: Fuel Conversion ................................................................19
Section 5-2: Gas Pressure ....................................................................19
Section 5-3: Gas Connection ................................................................19
Section 6: Finishing ..............................................................................20
Section 7: Installing and Removing the Door .......................................21
Section 8: Installing the Accessories .............................................22 - 25
▪ Installing the H42DF Log Set .....................................................22
▪ Installing the HL42DF Firestones ..............................................23
▪ Installing the HR42DF Articial River Rocks ..............................24
▪ Installing the HW42DF Wildre Log set .....................................25
Section 9: Operation ......................................................................26 - 28
▪ Start-up Sequence with Continuous Pilot .......................................26
▪ Start-up Sequence SIT-Proame Gas valve ..................................27
▪ Start-up Sequence with Honeywell Electronic Ignition ..................28
Maintenance ........................................................................29 - 31
▪ General ...............................................................................29
▪ Cleaning ...............................................................................29
▪ Hi-Lo Burner Adjustment ............................................................29
▪ Pilot Burner Adjustment .............................................................29
▪ Troubleshooting .....................................................................30
SIT- Nova 820 Gas Control Valve ........................................30
SIT-Proame Electronic Gas Control Valve .........................30
Honeywell Gas Control Valve ..............................................30
▪ Replacement Parts List ..............................................................31
Appendix
A. Termination Locations ..............................................................32
B. Warranty ...............................................................................33
C. State of Massachusetts. ..........................................................34


XG0146 -111111.1
Indicates a hazardous situation which, if not
avoided, WILL result in death or serious
injury or property damage.
Indicates a hazardous situation which, if not
avoided, COULD result in death or serious
injury or property damage.
Indicates a hazardous situation which, if not
avoided, WILL result in minor or moderate
injury.
Address practices that are important, but
not related to personal injury
DANGER WARNING
CAUTION NOTICE

Safety Alert Key
Introduction
 
Hot glass will cause
burns. Do not touch
glass until unit is cooled.
Never allow children to
touch glass.
Irritant
Cutting
Watch your step
Slippery floor
High temperatures
Glass hazard
Danger of suffocation
High voltage
Toxic
Flammable materials
Corrosive
Fork lift trucks
Danger overhead crane
Explosion risk
Oxidising
Danger of death
Biohazard
Laser Radiation
Danger of entrapment
Hot surface
General Warning
Blank
Gas bottles
Watch for
falling objects
Electricity
Danger for cutter
Entrapment hazard
Battery hazard
Rotating parts
Low temperature
Strong magnetic field
Optical radiation
Non ionizing
radiation
Radiation
Hazardous to the
Environment
Danger of harming
your hands
Congratulations on your purchase of a Montigo Fireplace.
With over 30 years of experience, Montigo is committed to providing you
with a gas replace that is not only a beautiful addition to your space, but
that is also designed and manufactured to the highest safety, reliability
and engineering standards.
We strongly encourage you to read and carefully follow the instructions
laid out in this Installation, Operation and Maintenance Manual and retain
it for your future reference. Pay special attention to all cautions, warnings,
and notices throughout this manual intended to ensure your safety.
This manual covers installation, operation and maintenance. Lighting,
operation and care of this replace can be easily performed by the
homeowner. All installation and service work should be performed by a
qualied or licensed installer, plumber or gastter as certied by the state,
province, region or governing body where the replace is being installed.
This installation, operation and maintenance manual is applicable to the
models described below. Refer to your rating plate to verify included
options. Throughout this manual instructions are applicable to all models
designated as  unless otherwise noted.

The Montigo warranty will be voided by, and Montigo disclaims any
responsibility for, the following actions:
► Modication of the replace and/or components including Direct-
Vent assembly or glass doors.
► Use of any component part not manufactured or approved by
Montigo in combination with this Montigo replace system.
► Installation other than as instructed in this manual.
Consult your local Gas Inspection Branch on installation requirements
for factory-built gas replaces. Installation & repairs should be done by
a qualied contractor.
    
    
    
    
    
    
    
    
    
    
    
    
    
                  


 XG0148 -111111.1
Installation

IMPORTANT MESSAGE: SAVE THESE INSTRUCTIONS
The  Direct Vent replace must be installed in accordance
with these Instructions. Carefully read all the Instructions in this manual
rst. Consult the Local Gas Branch to determine the need for a permit
prior to starting the installation. It is the responsibility of the installer to
ensure this replace is installed in compliance with the manufacturers
instructions and all applicable codes.
BEFORE YOU START:
Installation Checklist
Determine the desired install location of your replace.
See , Dimensions on  and refer to the Framing
 for details.
Select the location of your termination and resulting vent run.

.
Should it be impossible to meet the venting requirements laid
out in : Venting, please contact a local Montigo dealer
regarding the use of a Montigo Power Vent.
Lay out the Vent run; calculating the required elbows and straight
runs of 5"/8" flex or rigid pipe.
Layout Electrical Requirements Refer to Wiring, for
Details.
Refer to Installing the Gas Line, for details on the
gas connection and access.
Refer to local codes and guidelines for installation requirements.
        
:
• must conform to the local codes or in the
absence of local codes to the current version of Natural Gas and Propane
Installation Code, CSA B149. Electrical Installations must conform to
the local codes or, in the absence of local codes, to the current version
of Canadian Electrical Code, CSA C22.1.1
• must conform to the local codes or in
the absence of local codes to the current version of National Fuel Gas
Code, ANSI Z223.1/NFPA 54. Electrical Installations must conform to
the local codes or, in the absence of local codes, to the current version
of the National Electrical Code, ANSI/NFPA 70. See  for
installation within the State of Massachusetts.
Due to high operating temperatures, this appliance should be located out of traffic &
away from furniture and draperies.
Children and adults should be alerted to the hazards of the high surface temperature,
which could cause burns or clothing ignition.
Young children should be carefully supervised when they are in the same room as the
appliance.
Clothing or other flammable materials should not be placed on or near the appliance.
CAUTION
When this appliance is installed directly on any combustible material other than wood
flooring, it must be installed on a metal or wood panel extending the full width and
depth of the appliance or a fire will occur causing serious injury, property damage or
even death.
DANGER
Installation and repairs should be done by an authorized gas fireplace service technician.
The appliance should be inspected before use and at least annually by a professional. More
frequesnt cleaning may be required due to exessive lint from carpeting, bedding material,
etc. It is imperative that control compartments, burners and circulating air passageways of
the fireplace are kept clean.

Young children should be carefully supervised when they are
in the same room as the applicance. Toddlers, young children
and others may be susceptible to accidental contact burns. A
physical barrier is recommended if there are at risk individuals
in the house. To restrict access to a fireplace or stove, install
an adjustable safety gate to keep toddles, young children and
other at risk individuals out of the room and away from hot
surfaces.
CAUTION



XG0148 - 111111.1
Installation

Please review the Installation Checklist on  for general information
on preparing for a successful installation of your replace.
The  replace may be installed in any location that maintains
proper clearances to air conditioning ducts, electrical wiring and plumbing.
Safety, as well as efciency of operation, should be considered when
selecting the replace location. Select a location that does not interfere
with room trafc, has adequate ventilation and offers an accessible path
for Direct Vent installation.
Fireplace dimensions. (Tolerance ± ⅛").

20”
28”
12½”
C
L
8”
5”
1”
Top View
6½"
5¼"
28¾"
(Opening)
40½"
1¼"
1"
39½"
(Opening)
1¼"1¼"
42"
Front View
40½"
5"
8"
33"
20"
Side View


 XG0148 -111111.1
Installation

1). Frame in the enclosure for the unit with framing materials. The
framed opening for the assembled replace is 44" wide, x 46 1/2"
high x 21 5/8" deep, see Figure 2 .
 When constructing the framed opening, please ensure there is
access to install the gas line when the unit is installed. See Figure 22
* When sheetrock is not used behind the
replace, framing depth 21 5/8" may be
reduced by 5/8".
Framing dimensions.
 Combustible Framing for shelves over the replace, Top vent.
 Non Combustible Framing for Top Vent or Rear Vent with
Alcove Above Fireplace. 

 Combustible Framing for shelves over the replace, Rear vent.

44”
46 1/2”
* 21 5/8”
0" c
l
earance
to corners only
68”
44”
48 1/8”
Min.
84”
12”
door
opening
3”
Rear
Vent
Ceiling level
Floor
Top Vent
18”
max.
Min 1”
Non-Combustible
Header
Non-Combustible
materials. Alcove
over fireplace.
33”
Exterior
Wall
Non-Combustible
Nailing Flange,
(supplied) figure 7
.
REAR VENT
N.G ONLY
46 1/2”
9”
40 1/8”
33”
18”
max.
Combustible
Header
Combustible
Shelf
Non-Combustible
Nailing Flange,
(supplied) figure 7.
Exterior
Wall
REAR VENT
N.G ONLY
46”
PEL Shor t
90° elbow
46 1/2”
17 1/2” Combustible
Header
Combustible
Shelf
Non-Combustible
Nailing Flange,
(supplied) figure 7
.
Exterior
Wall



XG0148 - 111111.1
Installation
Clearances
When installing a shelf over the top of the replaces, the following
guidelines must be adhered to:
For , the minimum clearance is 1" from the rear
of the replace to a wall, or any combustible materials, and 9" clearance
from the top of the replace to the underside of any combustible shelf
materials.
For , the minimum clearance is 1" from the rear
of the replace to a wall, or any combustible materials, and 17 1/2" to
the underside of any combustible shelf materials, Figure 4.
1” clearance is maintained on sides and bottom of vent runs and 2”
above horizontal vent runs to any combustible material.
The replace clearances:
      
 † †    
6”
 Installing the Nailing Flange Extension.
Installing The Standoffs
       

The replace is supplied with two standoffs. Bend and install these
standoffs on top of the replace ensuring that the height of the standoff
maintains a 6" clearance.
 Installing the standoff's.
Installing the Nailing Flange Extension
Once the replace is placed into the rough framed opening, the supplied
Nailing Flange (Part No. ) must be fasten securely into place,
with nails or wood screws. as shown in Figure 7.
 The nailing ange extension can be substituted with a piece of
 material of the same size and thermal characteristics,
ie: cement board or equivalent. This is recommended in applications
where the facing materials will not adhere to the metal nailing ange.
6"
†  Clearance from top of replace to a combustible ceiling within
the replace enclosure.


 XG0148 -111111.1
Installation

Flue cover and collar removal, Top Vented replace.
Flue cover and collar installation, Rear Vented replace
 
Use the following instructions to convert an  for Rear Vent use:
1. Remove the Rear ue cover and gasket (5" and 8") on the ue
outlet, as shown in Figure 9.
2. Next, Remove the Top ue collar's (5" and 8") on the ue outlet,
as shown in Figure 9.
3. Install the (removed) Rear ue cover and gasket material, to the
Top vent outlet. Fasten the cover with included hardware, as
illustrated Figure 9a.
4. Install the (5" and 8") collars to the rear vent outlet using the
included hardware, as illustrated Figure 9a.
5” Inner Flue Collar
8” Outer Flue Collar
Flue Gasket
Flue Cover Plate
8” Outer Flue Collar
5” Inner Flue Collar
Flue Gasket
Flue Cover Plate
Montigo supplies a variety of direct venting and termination options.

 It should also be
selected such that it provides the shortest vent run possible. Should
it be impossible to ensure that the termination is the highest point
or to meet the venting guidelines laid out below please contact your
Montigo dealer to discuss power venting options.



        
.

.


Top vent.

Air Bafe is shipped open. If you are top venting the air bafe
should be closed following these steps:
Air bafe in open position.
Push the air bafe inward as far as possible and screw the air
bafe closed.
Air bafe in closed position



XG0148 - 111111.1
Installation
 



 


The maximum termination point is 32’ above the replace (NOTE:
if the maximum termination height is used, the ame pattern
may be affected).
The Vertical termination must be a minimum 2’ higher than where
the termination exits the roong materials, (asphalt shingles,
cedar shakes, etc). This distance should be measured from the
high side of the roof slope where the ue ashing intersects the
roong materials. (see Figures 10 to 10c ).
Termination location must be a minimum 6’ from a mechanical
air inlet.
Termination location must be a minimum 18” from a parapet wall.
For a more detailed diagram of allowed termination locations,
see .
A maximum of two offsets (each offset is made up of 2-90°
bends) may be made.
Firestops must be installed as required by National & local codes.
Ensure all runs are supported with a minimum of 3 supports
per 10’ of venting.
Install all roof ashing and storm collars as shown.
. Top vent, Roof mounted termination with no offset in vent run.
 Top vent, Roof mounted with 1 offset (1 offset= two 90° bends).
 Top vent, Roof mounted with 2 offsets (1 offset= two 90° bends).

The following details are some possible congurations for Roof
mounted terminations. See below.
Support ring
Support plate
Firestop
32’ max.
2’ min.
PVTK1
Termination
Support ring
Support plate
Firestop
32’ max.
2’ min.
Obstacle
PVTK1
Termination
PEXT
PEXT-10
Adaptor
Flue
Collar
Support straps or
support plate & ring
2’ min.
Firestop
Firestop
Firestop
32’ max Support plate
& ring
Obstacle
PVTK1
Termination


 XG0148 -111111.1
Installation
 Rear vent, Roof mounted venting (1 = 90° bend).
Support ring
Support plate 32’ max
P
VTK1
Termination
18”
Max.



XG0148 - 111111.1
Installation
1
12”
2”
12”
12”
 



1). Installation of Termination with built in frame
A Termination with a Built-In Frame is installed during framing
of a structure. 1. Frame the termination opening to 11" x 11".
2. Install exterior sheathing to the structure framing.
3. Fasten the termination to the sheathing using a minimum of 4 screws.
MSR Frame
PTO-4 (5"/8")
Termination
PTO-4F (5"/8")
Termination
 Installing a PTO-F termination.
 Installing a PTO termination with the MSR frame.
 Installing the VSS Vinyl Shield.
5). Installation of a termination shield for Vinyl Siding
The VSS Termination shield is installed when the exterior of a structure
is clad with Vinyl siding. It is placed directly above, and on-center with
the termination.
2). Installation of termination frame at time of framing
Terminations with a MSR frame allow the installation of the frame prior
to installation of the termination.
1. Frame the termination opening to 12" x 12".
2. Secure the MSR Frame to the exterior sheathing of the structure.
3. Fasten the termination to the MSR Frame using a minimum of 4 screws.
 Installing a PTO termination with the BSR frame.
3). Installation of termination frame at time of framing
in Masonry
Terminations with a BSR frame allow the installation of the
frame in masonry prior to the installation of the termination
1. Frame the BSR opening to 12" x 12".
2. Secure the BSR Frame to the exterior sheathing of the structure.
3. Fasten the termination to the BSR Frame using a minimum of 4 screws.
1. Frame the MOSR opening to 12" x 12".
2. Fasten the MOSR frame to the interior side of the studs, concrete,
or nished wall construction using a minimum of 4 screws.
3. Insert the termination into the MOSR frame as shown here, (from
the inside) and attach to the MOSR by installing a min. quantity of
4 bolts into the threaded nuts on the MOSR Frame.
4). Installation of termination from inside structure
A Termination with a MOSR Frame is installed from the inside of the
structure. These are commonly used in high-rise construction.
MOSR Frame
PTO-4 (5"/8")
Termination
 Installing a PTO termination with the MOSR frame.
BSR Frame
PTKOG (5"/8")
Installing Heat Guards over Terminations is recommended
in installations where the termination is located within 7'
feet above grade, or above a pedestrian walkway, and may
be Required by code in Public areas.
1. Ensure that the two longmounting brackets are facing the bottom
of the termination. (See inset). This will provide more heat protection
at the top of the termination, where temperatures are highest.
2. Attach to the faceplate of the termination using four sheet metal
screws.
 Installing a PTO termination heat guard.
1
1”
11”
Framing
Exterior
Sheathing
Fastening Hardware,
minimum 4-screws
Framing
Exterior
Sheathing
Fastening Hardware,
minimum 4-screws
PTO-4 (5"/8")
Termination
Framing
Exterior
Sheathing
Fastening Hardware,
minimum 4-screws
12”
12”
Fastening Hardware,
minimum 4-screws
Framing, con-
crete or other
materials
Exterior Sheath-
ing, concrete or
other materials
Exterior Vinyl
siding
PTO-4 (5"/8")
Termination
VSS Vinyl shield


 XG0148 -111111.1
Installation
The Venting Graph: H*42DF*
Measure the vertical height from the replace hearth to the centre of the
termination and the horizontal run from the replace ue collar to the wall
ange of the termination. Plot on the Venting Graph Figure 13 with an 'X'.
If the 'X' falls on or above the top boundary of the shaded area, the
installation is acceptable.

If the vertical dimension from the hearth is 84" and the horizontal run to
the wall ange of the vent termination is 36", this would be an acceptable
installation.

If the vertical dimension from the hearth is 72" and the horizontal run to
the wall ange of the vent termination is 66", this would be an acceptable
installation.

If the vertical dimension from the oor of the replace is 72" and the
horizontal run to the wall ange of the vent termination is 108", 

 H*42DF* Top Vent Venting Graph for wall mounted terminations.
 


Vent terminations must not be recessed in walls or siding.
For Heat Shield requirements see .
Once the proposed venting layout has been determined refer
to Figure 13 or 15 to ensure the layout is acceptable.
 TOP VENT
All measurements for vertical or horizontal runs are measured
from center of the vent pipe.
Venting runs must fall within the limits set by the venting graph,
see Figure 13.

The following details are some possible congurations for Wall
mounted terminations.
 Top Vented, wall mounted installation with one 90° bend. The vent
run must comply with Venting Graph for Top vent, wall mounted terminations,
Figure 13.
. Top Vented, wall mounted Multi-elbow installation. See Venting
Graph for Top vent, wall mounted terminations, Figure 13.
WARNING:
An inspection of the explosion relief appers and door
 be made prior to lighting the replace. Faulty seal
on the door gasket and/or explosion ports will result in
products of combustion leaking into the living space and
may result in carbon monoxide poisoning.
42”
46”
BC
A
Vertical Run (in.)
Unacceptable vent run
within shaded area.
Acceptable vent run
within non-shaded area.
If your installation does not fall
within the venting graph parameters,
please contact a local Montigo
dealer for Power Venting options.
Solid Section
Flex Section
Hearth
15’foot Max.
Heat
Shield
Termination
Exterior
Wall
Heat
Shield
Termination
Hearth Exterior
Wall
46”Min.
42” Max.
Flex or Ridig
section



XG0148 - 111111.1
Installation
Heat Shield
96”Min.
120” Max
. Top Vented, wall mounted Retracted Multi-elbow installation.
See Venting Graph for Top vent, wall mounted terminations, Figure 13.


 XG0148 -111111.1
Installation
 Corner installation. (NG Models Only)  Flex installation. (NG Models Only)
 
Attach an PEL-45 (45° elbow) directly onto the ue collar. Cut the
PXT-20 to suit, and attach it to the PEL-45. Slide the replace into
position and attach to the termination.
 
Use an PTO-3 termination and an PFL-1 or PFL-2/PFL-2 (12" or 24"
compressed length) and a frame, if appropriate.Flex may be turned
to obtain desired degree of angle required but must not exceed 45°.
 
The Kit includes a heat
shield, a PFL-12 (f/f) exible pipe, and a termination with or without
a mounting frame.
PEL-45 Elbow
PEL-90 Elbow
PXT-18
Heat Shield
Heat Shield



XG0148 - 111111.1
Installation
 Rear Vent Venting Graph for wall mounted terminations.
REAR VENT
All dimension lengths for vertical or horizontal runs are measured
from center of the vent pipe.
Venting runs must fall within the limits set by the venting graphs,
see Figure 15.
Fireplace must be converted to Rear Vent conguration prior to
running vent, see Figure 9 and 9a.
The Venting Graph
Measure the vertical height from the replace hearth to the centre of the
termination and the horizontal run from the replace ue collar to the wall
ange of the termination. Plot on the Venting Graph Figure 15 with an 'X'.
If the 'X' falls on or above the top boundary of the shaded area, the
installation is acceptable.

If the vertical dimension from the hearth is 120" and the horizontal
run to the wall ange of the vent termination is 138", this would be
an acceptable installation.

If the vertical dimension from the hearth is 48" and the horizontal
run to the wall ange of the vent termination is 96",


If the vertical dimension from the oor of the replace is 72" and
the horizontal run to the wall ange of the vent termination is 120",

WARNING:
An inspection of the explosion relief appers and door
 be made prior to lighting the replace. Faulty seal
on the door gasket and/or explosion ports will result in
products of combustion leaking into the living space and
may result in carbon monoxide poisoning.
 Rear Vented, wall mounted Multi-elbow termination installation.
Installation for H*42DF* must have a minimum vertical rise of 52".The vent run
must comply with the Venting Graph for Rear vent, wall mounted terminations,
Figure 15.
. Straight run, Rear Vented, wall mounted termination for H*42DF*,
Figure 15. N.G. (Natural Gas) equipped replaces ONLY. For Propane
replaces, see gure 15b below.
 


PXT Extension
RHS101 Heat
Shield
Termination
H
earth Exterior
Wall

33"
6”
30” Max.
52” Min.
18”
Max.
Flex or Rigid
Section
19”
Min.
33”
6”
33”
18” NG Only
A
B
C
52”
48”
Unacceptable vent run
within shaded area.
Acceptable vent run
within non-shaded area.
If your installation does not fall
within the venting graph parameters,
please contact a local Montigo
dealer for Power Venting options.


 XG0148 -111111.1
Installation
 


 



 





 







 º
º
º
º
 
 
 

 
 
Connection and installation of the vent components should
adhere to the following guidelines:
Montigo recommends the use of a ex section for the nal pipe
connected directly to the replace offering greater exibility of
installation and absorption of movement.
Firestops must be installed as required by National & local codes.
Montigo recommends that all exterior corners and joints be sealed
with exterior caulking. However, we encourage you to consult
your Building Envelope Engineer or Waterproong Consultant
for further recommendations.
 
The following components and associated Montigo part numbers for
installation of a roof or wall mounted termination. 
 Use of non-Montigo parts will  the warranty
and may impede operation of the replace.
Use any combination of rigid and ex pipe as required and in
any orientation (Male connectors can face in any direction).
Flex sections may be stretched up to 50% of their total length
(e.g. a 24” section maybe stretched to 36”).
Connect all vent sections using a minimum of three sheet metal
screws on the outer pipe ue.
Ensure the pipe ends male to female slide in a minimum of 1
1/2” of overlap.
Ensure all runs are supported with a minimum of 3 supports
per 10’ of venting.
When hanging/ supporting venting, ensure that 1” clearance
is maintained on sides and bottom of vent runs and 2” above
horizontal vent runs to any combustible material.
Rigid pipe may be cut less than half way from the
Ensure when cutting sections of rigid pipe to maintain integrity
of internal supports.
Place the springs, supplied with the pipe kit, between the outer
and inner pipes to keep the pipes separate and avoid any
possible hot spots.







XG0148 - 111111.1
Installation


The RHS8 Heat shield  be used  
 of the replace, (see gure 16a). For applications within
these dimensions the RHS101 Heat Shield  be used.
To install the RHS8, frame an opening in combustible construction,
Figure 16 below. Slide the Heat shield in place over the vent pipe
which attaches to the replace. After the replace and vent pipe has
been installed, clearances should match the dimensions in Figure 16.
 RHS8 Installation. (Install by sliding over vent pipe where it passes
through the combustible construction).  RHS101 Installation. (Install by sliding Outer Section over vent pipe
where it passes through the combustible construction.
 Heat Shield. After sliding the outer section in place.
 RHS8 Installation. (Minimum requirements).
RHS8 Heat Shield
1” Min. Both sides Typical
1” Min.
1” Min.
Combustible Framing
RHS8 Heat
Shield
36” Min
60” Min.
Termination
Drywall / sheetrock
RHS101 Heat Shield, inner Section
RHS101 Heat Shield
Outer Section
Combustible
framing
Termination
Drywall / sheetrock
RHS101 Heat Shield, inner Section
RHS101 Heat Shield
Outer Section
Vent pipe, from fireplace
RHS101 Installation.
Outer Shield 10 1/4”
3/8” Min. Both sides Typical
3/8” Min.
3/8” Min .
Combustible Framing
Inner Shield 9 3/8”

The RHS101 Heat shield  be used where the RHS8 Termination
()  be used. Use the RHS101 where any
of the dimensions are within the parameters shown,.
To install the RHS101, Slide the Inner Section over the vent pipe that
will connect to the replace. Then fasten the vent pipe to the back of the
replace with a minimum of three sheet metal screws. From the outside
slide the RHS101 outer section on see . To complete the
installation fasten the Heat Shield Outer Section & Termination frame
to the structure .


 XG0148 -111111.1
Installation







Wiring Diagram for the SIT Proame Electronic Ignition
Wiring Diagram for gas control and pilot.
Honeywell (Q3450)
Pilot Assembly
Pilot Electrical
Harness Connector
Honeywell Gas
Control (SV9501M)
Gas Control
Connector
Junction Box
115VAC
24VAC
40 VA
Transformer
Black
White
Green
Gnd Screw
Wall Switch
Fan Plug
Receptacle
Manifold Pressure
Test Connection
Wall Switch
Power
Generator
Pilot Adjustment Screw
Inl
e
t Pr
essu
r
e
'Hi-Lo' Adjustment Knob
Gas Control Knob (Shown in “Pilot” position)
 Wiring Diagram for  gas and pilot.
Orange Green
Red
Black
880 Valve
Battery
Holder
4 x 1.5V
AA Type
Chassis
connection
120 Vac INPUT
7 Vdc STABILIZED
SUPPLY OUTPUT
ON / OFF
ON/OFF IPI/CPI
BATTERY
DC SUPPLY
VALVE
GROUND
DFC
(CPI / IPI MODE
Not Used)




  
  



XG0148 - 111111.1
Installation
 which employ the fans must be grounded in
accordance with local codes or, in the absence of local codes, with the
National Electrical Code, 
For more information see the  included with
the fan kit.
NOTE: If any of the original wire supplied with the appliance
is replaced, it must be replaced with the same type,
or its equivalent.
 Wiring diagram for optional fans.
G
L2-WH
L1-BLK
p g
Quick Connect
lu to motor
5/1/60 Supply
G L1 L2
optional
All replaces may be equipped with optional fan kits for circulating
heat into the living space.
 which employ the fans must be electrically
grounded in accordance with   Canadian Electrical Code
Part 1 and/or Local Codes.

The * gas valve may be connected to a wall switch. Do 
connect any external power to the remote switch. The valve will
generate its own power on a millivolt circuit or will draw its power from
an AC Connection inside the replace, depending on the model of the
unit. Use only low voltage wire, and connect any external
power to the remote switch.
Refer to for wiring requirements.
 The switch location must not exceed 30' from the replace.


 XG0148 -111111.1
Installation

 After gas line is connected, appliance connection
valve and valve train must be checked while under normal
operating pressure with either a liquid solution, or leak
detection device, to locate any source of leak. Tighten any
areas where bubbling appears or leak is detected until
bubbling stops completely or leak is no longer detected.

Gas line access.
Gasline Access
0.875” dia.
7”
to center
2”
The manifold outlet pressure is set from the factory to the
appropriate pressure but should be veried.
To check pressures, control valves have a provision to remove
a 1/8” N.PT. plug to be tted with a hose barb.
Montigo requires a service shut off valve be located in an
accessible location to isolate the gas supply.
Only install gas shut-off valves approved for use by the state,
province, or other governing body in which the replace is being
installed.
 
See Figure 22 for location of gas line access.
Flexible gas connectors must not exceed 3 feet in length, unless
allowable within local regulations.
Connect incoming gas line to the 1/2"or 3/8" gas inlet port.
Purge all air out of gas line.
Check appliance connection, valve and valve train under normal
operating pressure with a commercially available leak check
solution.

Section 5-1: FUEL CONVERSION
Verify that your replace is compatible with your available gas
type. (Natural Gas or Propane shown by "N" or "L" in your
model number
If gas type is not compatible, contact your local Montigo
representative to purchase a conversion kit.
Conversion kits must be installed by a qualied service technician.
Section 5-2: GAS PRESSURE
Optimum appliance performance requires proper input pressures.
Gas line sizing requirements will be determined in ANSI Z223.1
National Fuel Gas Code in the USA and CAN/CGA B149 in
Canada.
Pressure requirements are:
  
  
  
We recommend careful consideration be given to the effects of elevated mantel
temperatures which may be in excess of product design, for example: candles, plastic
or pictures. This can cause melting, deformation, discoloration or premature failure of
T.V. radio, and other electronic components.
CAUTION
When pressure testing the fireplace, Gas line, and input system follow the appropriate
local codes or your area. DO NOT connect the fireplace to pressures in excess of
1/2lb. This will damage the gas control valve.
NOTICE
