Montigo H38DF PFC Instruction Manual

H38DF PFC
HL38DF PFC
HP38DF PFC
Peninsula
Indoor
Resi dential Gas
Fireplace
®
C US
Read and understand this manual. Improper installation, adjustment, alteration,
service or maintenance can cause serious injury, property damage or even death.
For assistance or additional information consult a qualified installer, service
agency or the gas supplier.
DANGER
Do not store or use gasoline or any other flammable vapors and liquids in the vicinity of
this or any other gas burning appliance. A fire or explosion my occur causing serious
injury, property damage or even death.
WARNING
Installer: Leave this manual with the appliance. Do not remove.
Consumer: Retain this manual for maintenance and future reference. Do not Discard.
NOTICE
IF YOU SMELL GAS
Do not try to light any appliance.
Do not touch any electrical switch; do not use any phone in your building.
Immediately call your gas supplier from a neighbor's phone. Follow the gas
supplier's instructions.
If you cannot reach your gas supplier, call the fire department.
DANGER
Irritant
Cutting
Watchyour step
Slipperyfloor
Hightemperatures
Glasshazard
Dangerof suffocation
Highvoltage
Toxic
Flammablematerials
Corrosive
Forklift trucks
Dangeroverhead crane
Explosionrisk
Oxidising
Dangerof death
Biohazard
LaserRadiation
Dangerof entrapment
Hotsurface
GeneralWarning
Blank
Gasbottles
Watchfor
fallingobjects
Electricity
Dangerfor cutter
Entrapmenthazard
Batteryhazard
Rotatingparts
Lowtemperature
Strongmagnetic field
Opticalradiation
Nonionizing
radiation
Radiation
Hazardousto the
Environment
Dangerof harming
yourhands
Irritant
Cutting
Watchyour step
Slipperyfloor
Hightemperatures
Glasshazard
Dangerof suffocation
Highvoltage
Toxic
Flammablematerials
Corrosive
Forklift trucks
Dangeroverhead crane
Explosionrisk
Oxidising
Dangerof death
Biohazard
LaserRadiation
Dangerof entrapment
Hotsurface
GeneralWarning
Blank
Gasbottles
Watchfor
fallingobjects
Electricity
Dangerfor cutter
Entrapmenthazard
Batteryhazard
Rotatingparts
Lowtemperature
Strongmagnetic field
Opticalradiation
Nonionizing
radiation
Radiation
Hazardousto the
Environment
Dangerof harming
yourhands
Irritant
Cutting
Watchyour step
Slipperyfloor
Hightemperatures
Glasshazard
Dangerof suffocation
Highvoltage
Toxic
Flammablematerials
Corrosive
Forklift trucks
Dangeroverhead crane
Explosionrisk
Oxidising
Dangerof death
Biohazard
LaserRadiation
Dangerof entrapment
Hotsurface
GeneralWarning
Blank
Gasbottles
Watchfor
fallingobjects
Electricity
Dangerfor cutter
Entrapmenthazard
Batteryhazard
Rotatingparts
Lowtemperature
Strongmagnetic field
Opticalradiation
Nonionizing
radiation
Radiation
Hazardousto the
Environment
Dangerof harming
yourhands
Irritant
Cutting
Watchyour step
Slipperyfloor
Hightemperatures
Glasshazard
Dangerof suffocation
Highvoltage
Toxic
Flammablematerials
Corrosive
Forklift trucks
Dangeroverhead crane
Explosionrisk
Oxidising
Dangerof death
Biohazard
LaserRadiation
Dangerof entrapment
Hotsurface
GeneralWarning
Blank
Gasbottles
Watchfor
fallingobjects
Electricity
Dangerfor cutter
Entrapmenthazard
Batteryhazard
Rotatingparts
XG0816 150204.1
Installation & Maintenance Manual
Lighting Instruction Updates
Lighting Instruction UpdatesLighting Instruction Updates
Lighting Instruction Updates
Replace the warning label with danger label in the
Replace the warning label with danger label in the Replace the warning label with danger label in the
Replace the warning label with danger label in the
Lighting instructions
Lighting instructionsLighting instructions
Lighting instructions
Canadian Heating Products Inc. Langley, BC V4W 4A1 | Montigo Del Ray Corp. Ferndale, WA 98248

Page 2
You must read and understand this manual prior to installation, operation or
troubleshooting this appliance. Please retain this owner’s manual for future reference
and maintenance.
NOTICE
Table of Contents
H*38DF PFC Peninsula Gas Fireplace
XG0816 - 150204.1
Instruction Manual Contents
INTRODUCTION� � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � 3
Safety Alerts� � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � 3
Before You Start:. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Installation Checklist . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Rating Plate Sample . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Section 1: Installation Overview and Product Dimensions� � � � � � � 6
Section 2: Framing � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � 7
Clearances . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Installing The Standoffs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Nailing Flange Extension . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Section 3: Venting � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � 9
Section 3-1: Converting to Rear Vent � � � � � � � � � � � � � � � � � � � � � � � � � 9
Section 3-2: INSTALLING A ROOF MOUNTED DIRECT VENT
TERMINATION (PVTK-1) � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � 10
Section 3-2-1: VENTING LAYOUT. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
Roof mounted Terminations . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
Section 3-3: INSTALLING A WALL MOUNTED DIRECT VENT
TERMINATION � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � 12
Section 3-3-1: VENTING LAYOUT: Wall mounted termination. . . . . . . . . . . 13
Section 3-3-2: VENTING COMPONENTS . . . . . . . . . . . . . . . . . . . . . . 17
Section 3-3-3: Heat Shields . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
Section 4: Wiring � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � 19
Section 5-1: FUEL CONVERSION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
Section 5-2: GAS PRESSURE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
Section 5-3: GAS CONNECTION. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
Section 5: Installing the Gas Line � � � � � � � � � � � � � � � � � � � � � � � � � � � � 20
Section 6: Finishing Around the Fireplace� � � � � � � � � � � � � � � � � � � � � 21
Section 7: Screen Installation and Removal � � � � � � � � � � � � � � � � � � � 22
Section 8: Installing & Removing the Door � � � � � � � � � � � � � � � � � � � � 23
Section 9: Installing the Accessories � � � � � � � � � � � � � � � � � � � � � � � � � 25
Installing the HP38PF* Logs and Embers. . . . . . . . . . . . . . . . . . . . . . . . . . . . 26
Operation � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � 28
Standing (Continuous) Pilot Ignition (SIT NOVA 820) . . . . . . . . . . . . . . . . . . 28
SIT Proame 2 Electronic Ignition. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29
Honeywell Electronic Ignition. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30
Maintenance� � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � 31
General . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31
Cleaning . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31
Hi-Lo Burner Adjustment: (SIT Nova 820). . . . . . . . . . . . . . . . . . . . . . 31
Pilot Burner Adjustment. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31
Troubleshooting: � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � 32
SIT Nova 820: . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32
SIT Proame 2:. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32
Replacement Parts:� � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � 33
Appendix A: Venting Terminations � � � � � � � � � � � � � � � � � � � � � � � � � � � 34
Appendix B: Warranty� � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � 35
Appendix C: State of Massachusetts � � � � � � � � � � � � � � � � � � � � � � � � � 36

Page 3
Indicates a hazardous situation which, if not
avoided, WILL result in death or serious
injury or property damage.
Indicates a hazardous situation which, if not
avoided, COULD result in death or serious
injury or property damage.
Indicates a hazardous situation which, if not
avoided, WILL result in minor or moderate
injury.
Address practices that are important, but
not related to personal injury
DANGER WARNING
CAUTION NOTICE
H*38DF PFC Peninsula Gas Fireplace
Safety Alert Key
Introduction
XG0816 - 150204.1
Safety Alerts
INTRODUCTION
Congratulations on your purchase of a Montigo Fireplace.
Withover 30years ofexperience, Montigoiscommittedtoproviding
you with a gas replace that is not only a beautiful addition to your
space, but that is also designed and manufactured to the highest
safety, reliability and engineering standards.
We strongly encourage you to read and carefully follow the
instructionslaid out inthis Installation,Operation and Maintenance
Manualand retain itfor yourfuture reference. Payspecialattention
to all cautions, warnings, and notices throughout this manual
intended to ensure your safety.
This manual covers installation, operation and maintenance.
Lighting, operation and care of this replace can be easily
performed by the homeowner. All installation and service work
should be performed by a qualied or licensed installer, plumber
or gastter as certied by the state, province, region or governing
body where the replace is being installed.
This installation, operation and maintenance manual is applicable
to the models described below. Refer to your rating plate to
verify included options. Throughout this manual instructions are
applicable to all models designated as H*38PF* unless otherwise
noted in the Table.
Warranty Information: (See Appendix B)
The Montigo warranty will be VOIDED by, and Montigo disclaims any
responsibility for the following actions:
► Modication of the replace and/or components including Direct-
Vent assembly or glass doors.
► Use of any component part not manufactured or approved by
Montigo in combination with this Montigo replace system.
► Installation other than as instructed in this manual.
Consult your local Gas Inspection Branch on installation requirements
for factory-built gas replaces. Installation & repairs should be done by
a qualied contractor.
MODEL Natural Gas Liquid Propane Gas Rating (BTU hr) Traditional Burner w/ Logset Premium Burner w/ Logset Linear Burner w/ Glass media Accessories Standing Pilot Ignition Honeywell HSI Ignition SIT Electronic Ignition
H38DFPFCN X 34,000 X X
H38DFPFCN-F X 34,000 X X
H38DFPFCL X 32,000 X X
H38DFPFCL-F X 32,000 X X
HL38DFPFCN X 34,000 X X
HL38DFPFCN-F X 34,000 X X
HL38DFPFCL X 32,000 X X
HL38DFPFCL-F X 32,000 X X
HP38DFPFCN-F X 34,000 X X
HP38DFPFCL-F X 32,000 X X
Young children should be carefully supervised when they are
in the same room as the applicance. Toddlers, young children
and others may be susceptible to accidental contact burns. A
physical barrier is recommended if there are at risk individuals
in the house. To restrict access to a fireplace or stove, install
an adjustable safety gate to keep toddles, young children and
other at risk individuals out of the room and away from hot
surfaces.
CAUTION

Page 4 XG0816 - 150204.1
H*38DF PFC Peninsula Gas Fireplace
Installation
Due to high operating temperatures, this appliance should be located out of traffic &
away from furniture and draperies.
Children and adults should be alerted to the hazards of the high surface temperature,
which could cause burns or clothing ignition.
Young children should be carefully supervised when they are in the same room as the
appliance.
Clothing or other flammable materials should not be placed on or near the appliance.
CAUTION
When this appliance is installed directly on any combustible material other than wood
flooring, it must be installed on a metal or wood panel extending the full width and
depth of the appliance or a fire will occur causing serious injury, property damage or
even death.
DANGER
Installation Checklist
Determine the desired install location of your replace.
See Section 1, Dimensions on Page 5, and refer to the Framing
Section 2 for details.
Select the location of your termination and resulting vent run.
Yourselectedtermination location mustbethe highestpoint
in the Direct Vent installation.
Should it be impossible to meet the venting requirements laid
out in Section 3: Venting, please contact a local Montigo dealer
regarding the use of a Montigo Power Vent.
Lay out the Vent run; calculating the required elbows and straight
runs of 5"/8" flex and/or rigid pipe.
Layout Electrical Requirements Refer to Section 4: Wiring for
Details.
Refer to Section 5: Installing the Gas Line for details on the gas
connection and access.
Refer to local codes and guidelines for installation requirements.
Installation and repairs should be done by a qualied
contractor and must conform to:
•Installations in Canada must conform to the local codes or in the
absence of local codes to the current version of Natural Gas and Propane
Installation Code, CSA B149. Electrical Installations must conform to
the local codes or, in the absence of local codes, to the current version
of Canadian Electrical Code, CSA C22.1.1
• Installations in the USA must conform to the local codes or in
the absence of local codes to the current version of National Fuel Gas
Code, ANSI Z223.1/NFPA 54. Electrical Installations must conform to
the local codes or, in the absence of local codes, to the current version
of the National Electrical Code, ANSI/NFPA 70. See Appendix C for
installation within the State of Massachusetts.
IMPORTANT MESSAGE: SAVE THESE INSTRUCTIONS
The H*38PF* Direct Vent replace must be installed in accordance with
these Instructions. Carefully read all the Instructions in this manual
rst. Consult the Local Gas Branch to determine the need for a permit
prior to starting the installation. It is the responsibility of the installer to
ensure this replace is installed in compliance with the manufacturers
instructions and all applicable codes.
Before You Start:
Installation and repairs should be done by an authorized gas fireplace service technician.
The appliance should be inspected before use and at least annually by a professional. More
frequent cleaning may be required due to excessive lint from carpeting, bedding material,
etc. It is imperative that control compartments, burners and circulating air passageways of
the fireplace are kept clean.
NOTICE
WARNING
A barrier designed to reduce the risk of burns from hot viewing glass is provided with this
appliance and shall be installed for the protection of children and other at-risk individuals.
If the barrier becomes damaged, the barrier shall be replaced with the manufacturer’s
barrier for this appliance.
WARNING
Any safety screen, guard, or barrier removed for servicing an appliance must be replaced
prior to operating the appliance.

Page 5
XG0816 - 150204.1
H*38DF PFC Peninsula Gas Fireplace
Installation
Rating Plate Sample



 












LB1223-V5.0 SIT IPI -with screen JUN 16.2014
  










 


    




  

  








    






 
 
 


 


Teklynx LabelView Demo



 













LBL1205-V6.1 Stand. Pilot- Screen DEC06.2014
  










 


    




  

  








    






 
 
 


 



Teklynx LabelView Demo
Figure A: Rating Plate for IPI eletronic ignition Figure B: Rating Plate for standing pilot (SIT)

Page 6 XG0816 - 150204.1
H*38DF PFC Peninsula Gas Fireplace
Installation
Section 1: Installation Overview and Product Dimensions
Pleasereview the InstallationCheckliston Page4forgeneral information
on preparing for a successful installation of your replace.
The H*38PF* replace may be installed in any location that maintains
properclearancesto air conditioningducts,electricalwiringand plumbing.
Safety, as well as efciency of operation, should be considered when
selecting the replace location. Select a location that does not interfere
with room trafc, has adequate ventilation and offers an accessible path
for Direct Vent installation.
Figure 1� Fireplace dimensions with Nailing Flange Extension shown (Tolerance ± ⅛").
The replace dimensions are shown below:
Top View
53
4
"
146
4"
102
47
8
"
123
21 5
8
"
548
33"
839
41 1
2
"
1054
75
8
"
194
8"
204mm
5"
128mm
25"
635
33 7
8
"
860
23 5
8
"
600
25"
636
39 5
8
"
1007
Front View
Side View

Page 7
XG0816 - 150204.1
H*38DF PFC Peninsula Gas Fireplace
Installation
Section 2: Framing
Note: Images are shown without screens for clarity purposes. However,
your replace should not be operated without proper installation of
screens.
1). Frame in the enclosure for the unit with framing materials. The
framed opening for the assembled replace is 23 3/4" wide, x 44"
high x 41" deep, see Figure 2 .
NOTE: When constructing the framed opening, please ensure there is
access to install the gas line when the unit is installed. See Figure 21�
Figure 2� Framing dimensions.
Figure 3� Combustible Framing for shelves over the replace, Rear vent.
Figure 5� Non Combustible Framing with alcove above replace, Top Vent.
41
23 3/4
44
Figure 4� Combustible Framing for shelves over the replace, Top vent.
11”
Min.
Combustible Shelf
33”
44”
Exterior
Wall
Combustible Header
12” Max.
4” Nailing flange
or Non-combustible
material.
46” Min
17 1/2”
2” Min.
44”
Combustible Shelf
Combustible Header
Min.
Exterior
Wall
PEL Short
90 elbow 4” Nailing flange
or Non-combustible
material.
58” Min for HP
Floor
39 5/8”
44”
Combustible
Header
Min. 1 ”
2”
Ceiling level
Non-Combustible
Header
Non-Combustible
materials. Alcove
over fireplace.
Top Vent
Non-Combustible
Materials, with Low
profile mantel / Alcove
over fireplace.
84”
min.

Page 8 XG0816 - 150204.1
H*38DF PFC Peninsula Gas Fireplace
Installation
Clearances
When installing a shelf over the top of the replaces, the following
guidelines must be adhered to:
For Rear Vent applications, the minimum clearance is 2" from the rear of
the replace to a wall, or any combustible materials, and 11" clearance
from the top of the replace to the underside of any combustible shelf
materials.
For Top Vent applications, the minimum clearance is 2" from the rear of
the replace to a wall, or any combustible materials, and 17 1/2" to the
underside of any combustible shelf materials.
For Horizontal vent pipes, ensure that 1” clearance is maintained on
sides and bottom of vent runs and 2” above horizontal vent runs to any
combustible material.
MODEL Top - Rear vent † Top - Top vent † Rear Sides Floor Mantel
H*38PF* 11" 17 1/2" 2" 1" 0" See Section 6:
Finishing around
the replace
Installing The Standoffs
To avoid elevated mantel temperatures, all H*38PF*-Series gas
replaces are required to have the supplied standoffs installed.
The replace is supplied with two standoffs. Bend and install these
standoffs on top of the replace ensuring that the height of the standoff
maintains a 8" clearance.
† Note: Clearance from top of replace to a ceiling within the replace
enclosure.
8”
Fasten Standoffs
in gutter
Figure 6� Installing the standoff's.
Nailing Flange Extension
The 4" nailing ange extension is shipped attached to the top edge of
the replace, see Figure 1.
The nailing ange extension may be substituted with a piece of NON-
Combustible material of the same thermal characteristics, ie: cement
board or equivalent to t the opening. This is recommended in applications
where the facing materials will not adhere to the metal nailing ange.
To remove the Nailing Flange Extension follow the directions below:
Figure 7c� Finished removing Nailing Flange extension.
Figure 7� Remove screws from top of the unit
Figure 7a� Remove shell and insulation from the top of unit. Remove screws
from outer edge.
Figure 7b� Remove the nailing ange extension from the unit. Reinstall shell
and insulation. Screw shell in place.

Page 9
XG0816 - 150204.1
H*38DF PFC Peninsula Gas Fireplace
Installation
Note: Images are shown without screens for clarity purposes. However,
your replace should not be operated without proper installation of
screens.
Figure 8� Flue cover and collar removal, Top Vented replace.
Figure 8a� Flue cover and collar installation, Rear Vented replace.
Section 3-1: Converting to Rear Vent
Use the following instructions to convert a H*38PF* for Rear Vent use:
1. Remove the Rear ue cover and gasket (5" and 8") on the ue
outlet, as shown in Figure 8.
2. Next, Remove the Top ue collar's (5" and 8") on the ue outlet,
as shown in Figure 8.
3. Install the (removed) Rear ue cover and gasket material, to the
Top vent outlet. Fasten the cover with included hardware, as
illustrated Figure 8a.
4. Install the (5" and 8") collars to the rear vent outlet using the
included hardware, as illustrated Figure 8a.
Montigo supplies a variety of direct venting and termination options.
The direct vent termination location MUST be selected such that
it is the highest point in the venting assembly� It should also be
selected such that it provides the shortest vent run possible. Should
it be impossible to ensure that the termination is the highest point or
should it be impossible to meet the venting guidelines laid out below
please contact your Montigo dealer to discuss power venting options.
NOTES FOR PLANNING VENTING:
Venting can originate from the unit through the top or
through the rear
Venting can terminate through the roof or through an
exterior wall.
Refer to Appendix A - Termination Locations to ensure the
planned termination location is acceptable.
Once the termination location has been established, refer
to the appropriate section below for installation details
All replaces shipped from the factory are Top vent.
Silicone application is NOT required when joining Montigo
vent pipes and components�
See Section 3-1 for converting the unit from top vent to rear vent�
5”Inner Flue
Cover Plate
8”Outer Flue
Cover Plate
8”Outer
Flue Collar
5”Inner
Flue Collar
Flue Collar
8”Outer
Flue Collar
5”Inner Flue
C
over Plate
Outer Flue
Outer Plate
Section 3: Venting

Page 10 XG0816 - 150204.1
H*38DF PFC Peninsula Gas Fireplace
Installation
Section 3-2: INSTALLING A ROOF MOUNTED DIRECT VENT
TERMINATION (PVTK-1)
This section applies to installations where the direct vent termi-
nation will be roof mounted�
Section 3-2-1: VENTING LAYOUT
Selection of components and details of venting lay out should
adhere to the following guidelines:
The maximum termination point is 32’ above the replace (NOTE:
if the maximum termination height is used, the ame pattern
may be affected).
The Vertical termination must be a minimum 2’ higher than
where the termination exits the roong materials, (asphalt
shingles,cedarshakes, etc)�Thisdistanceshouldbe measured
from the high side of the roof slope where the ue ashing
intersects the roong materials. (see Figures 9 - 9c).
For a detailed diagram of allowed termination locations, see
Appendix A�
Termination location must be a minimum 6’ from a mechanical
air inlet.
A maximum of two offsets (each offset is made up of 2-90°
bends) may be made for vertical vent runs.
Firestops must be installed as required by National & local codes.
Ensure all horizontal runs are supported with a minimum of 3
supports per 10’ of venting.
Install all roof ashing and storm collars as shown.
Figure 9.Top vent, Roof mounted termination with no offset in vent run.
Figure 9a� Top vent, Roof mounted with 1 offset (1 offset= two 90° bends).
Figure 9b�Top vent, Roof mounted with 2 offsets (1 offset= two 90° bends).
Roof mounted Terminations
The following details are some possible congurations for Roof
mounted terminations.
Support ring
Support plate
Firestop
32’ max.
2’ min.
PVTK1
Termination
Support straps or
support plate & ring
2’ min.
Firestop
Firestop
Firestop
32’ max Support plate
& ring
Obstacle
PVTK1
Termination
Support ring
Support plate
Firestop
32’ max.
2’ min.
Obstacle
PVTK1
Termination

Page 11
XG0816 - 150204.1
H*38DF PFC Peninsula Gas Fireplace
Installation
Note: Images are shown without screens for clarity purposes. However,
your replace should not be operated without proper installation of
screens.
Figure 9c� Rear vent, Roof mounted venting (1 = 90° bend).
Support ring
Support plate 32’ Ma.x
P
VTK1
Termination
12” Max.

Page 12 XG0816 - 150204.1
H*38DF PFC Peninsula Gas Fireplace
Installation
1
12”
2”
12”
12”
Section 3-3: INSTALLING A WALL MOUNTED DIRECT VENT
TERMINATION
This section applies to installations where the direct vent termi-
nation will be wall mounted�
1)� Installation of Termination with built in frame
ATermination with aBuilt-InFrameisinstalledduring framing ofastructure.
1. Frame the termination opening to 11" x 11".
2. Install exterior sheathing to the structure framing.
3. Fasten the termination to the sheathing using a minimum of 4 screws.
MSR Frame
PTO-4 (5"/8")
Termination
PTO-4F (5"/8")
Termination
Figure 10� Installing a PTO-F termination.
Figure 10a� Installing a PTO termination with the MSR frame.
Figure 10d� Installing the VSS Vinyl Shield.
5)� Installation of a termination shield for Vinyl Siding
The VSS Termination shield is installed when the exterior of a structure
is clad with Vinyl siding. It is placed directly above, and on-center with
the termination.
2)� Installation of termination frame at time of framing
Terminations with a MSR frame allow the installation of the frame prior
to installation of the termination.
1. Frame the termination opening to 12" x 12".
2. Secure the MSR Frame to the exterior sheathing of the structure.
3. Fastenthe termination totheMSR Frame usingaminimumof 4screws.
Figure 10b� Installing a PTO termination with the BSR frame.
3)� Installation of termination frame at time of framing in
Masonry
Terminations with a BSR frame allow the installation of the frame in
masonry prior to the installation of the termination
1. Frame the BSR opening to 12" x 12".
2. Secure the BSR Frame to the exterior sheathing of the structure.
3. Fastenthe termination totheBSR Frameusinga minimum of4screws.
1. Frame the MOSR opening to 12" x 12".
2. Fasten the MOSR frame to the interior side of the studs, concrete,
or nished wall construction using a minimum of 4 screws.
3. Insert the termination into the MOSR frame as shown here, (from
the inside) and attach to the MOSR by installing a min. quantity of
4 bolts into the threaded nuts on the MOSR Frame.
4)� Installation of termination from inside structure
A Termination with a MOSR Frame is installed from the inside of the
structure. These are commonly used in high-rise construction.
MOSR Frame
PTO-4 (5"/8")
Termination
Figure 10c� Installing a PTO termination with the MOSR frame.
BSR Frame
MTKOG (5"/8")
Installing Heat Guards over Terminations is recommended
in installations where the termination is located within 7' feet above
grade, or above a pedestrian walkway, and may be Required by code
in Public areas.
1. Ensure that the two long mounting brackets are facing the bottom of
the termination. (See inset). This will provide more heat protection
at the top of the termination, where temperatures are highest.
2. Attach to the faceplate of the termination using four sheet metal
screws.
Figure 11� Installing a PTO termination heat guard.
1
1”
11”
Framing
Exterior
Sheathing
Fastening Hardware,
minimum 4-screws
Framing
Exterior
Sheathing
Fastening Hardware,
minimum 4-screws
PTO-4 (5"/8")
Termination
Framing
Exterior
Sheathing
Fastening Hardware,
minimum 4-screws
12”
12”
Fastening Hardware,
minimum 4-screws
Framing, con-
crete or other
materials
Exterior Sheath-
ing, concrete or
other materials
Exterior Vinyl
siding
PTO-4 (5"/8")
Termination
VSS Vinyl shield

Page 13
XG0816 - 150204.1
H*38DF PFC Peninsula Gas Fireplace
Installation
The Venting Graph: H*38PF*
Measure the vertical height from the replace hearth to the centre of
the termination and the horizontal run from the replace ue collar to
the wall ange of the termination. Plot on the Venting Graph Figure 12
or 13 with an 'X'.
If the 'X' falls on or above the top boundary of the shaded area, the
installation is acceptable.
Example A: (Acceptable Installation)
If the vertical dimension from the hearth is 114" and the horizontal
run to the wall ange of the vent termination is 126", this would be
an acceptable installation.
Example B: (Unacceptable Installation)
If the vertical dimension from the hearth is 48" and the horizontal
run to the wall ange of the vent termination is 84", this would
NOT be an acceptable installation�
Example C: (Unacceptable Installation)
If the vertical dimension from the oor of the replace is 60" and
the horizontal run to the wall ange of the vent termination is 144",
this would NOT be an acceptable installation�
Figure 12� H38PF* or HL38PF* Top Vent Venting Graph for wall mounted
terminations.
Figure 12a� H38PF* or HL38PF* Top Vented, wall mounted installation with
one 90° bend. The vent run must comply with Venting Graph for Top vent, wall
mounted terminations, Figure 12.
Section 3-3-1: VENTING LAYOUT: Wall mounted termination�
Selection of components and details of venting layout should
adhere to the following guidelines:
Vent terminations must not be recessed in walls or siding.
For Heat Shield requirements see Section 3-3-3.
Once the proposed venting layout has been determined refer
to Figure 12, 13, 14, or 14a to ensure the layout is acceptable.
Notes Wall Mounted Terminations: TOP VENT
All measurements for vertical or horizontal runs are measured
from center of the vent pipe.
Venting runs must fall within the limits set by the venting graph,
see Figure 12 or 13.
Figure 13� HP38PF* Top Vent Venting Graph for wall mounted terminations.
58”
A
C
B
.
Unacceptable vent run
within shaded area.
Acceptable vent run
within non-shaded area.
If your installation does not fall with-
in the venting graph parameters,
please contact a local Montigo
dealer for Power Venting options.
19”
42”
46”
A
C
B
If your installation does not fall with-
in the venting graph parameters,
please contact a local Montigo
dealer for Power Venting options.
Unacceptable vent run
within shaded area.
Acceptable vent run
within non-shaded area.
Figure 13a� HP38PF* Top Vented, wall mounted installation with one 90° bend.
The vent run must comply with Venting Graph for Top vent, wall mounted
terminations, Figure 13.
Heat Shield
Termination
Exterior
Wall
Hearth
Flex or Rigid
Insulated Sleeve
CRS101
19” Max
58”Min
.
Heat Shield
46”Min.
Termination
Exterior
Wall
Hearth
Flex or Rigid
Insulated Sleeve
CRS101
42” Max.

Page 14 XG0816 - 150204.1
H*38DF PFC Peninsula Gas Fireplace
Installation
Note: Images are shown without screens for clarity purposes. However,
your replace should not be operated without proper installation of
screens.
Figure 13b.H38PF* , HL38PF* or HP38PF* Top Vented, wall mounted Multi-
elbow installation. See Venting Graph for Top vent, wall mounted terminations,
Figure 12 or 13.
Solid
Section
Flex
Section
Hearth
150” Max.
Heat
Shield
Termination
Exterior
Wall
Heat
Shield
Termination
Exterior
Wall
30” Max.
126” Max.
Solid
Section
Flex
Section
Hearth
Figure13b.H38PF*,HL38PF*orHP38PF*Top Vented, wall mounted Retracted
Multi-elbow installation. See Venting Graph for Top vent, wall mounted
terminations, Figure 12 or 13.

Page 15
XG0816 - 150204.1
H*38DF PFC Peninsula Gas Fireplace
Installation
Figure 14a� HP38PF* Rear Vent Venting Graph for wall mounted terminations.
Figure 14� H38PF* or HL38PF* Rear Vent Venting Graph for wall mounted
terminations.
Notes Wall Mounted Terminations: REAR VENT
Alldimension lengthsforvertical orhorizontalruns aremeasured
from center of the vent pipe.
Venting runs must fall within the limits set by the venting graphs,
see Figure 14 or 14a.
Fireplace must be converted to Rear Vent conguration prior to
running vent, see Figure 8 and 8a.
The Venting Graph
Measure the vertical height from the replace hearth to the centre of
the termination and the horizontal run from the replace ue collar to
the wall ange of the termination. Plot on the Venting Graph Figure 14
or 14a with an 'X'.
If the 'X' falls on or above the top boundary of the shaded area, the
installation is acceptable.
Example A: (Acceptable Installation)
If the vertical dimension from the hearth is 120" and the horizontal
run to the wall ange of the vent termination is 138", this would be
an acceptable installation.
Example B: (Unacceptable Installation)
If the vertical dimension from the hearth is 60." and the horizontal
run to the wall ange of the vent termination is 84", this would
NOT be an acceptable installation�
Example C: (Unacceptable Installation)
If the vertical dimension from the oor of the replace is 72" and
the horizontal run to the wall ange of the vent termination is 120",
this would NOT be an acceptable installation�
53”
42”
33”
12”
B
C
A
Unacceptable vent run
within shaded area.
Acceptable vent run
within non-shaded area.
If your installation does not fall within
the venting graph parameters, please
contact a local Montigo dealer for
Power Venting options.
Figure 15.H38PF* , HL38PF* or HP38PF* Straight run, Rear Vented, wall
mounted termination. The vent run must comply with the Venting Graph for
Rear vent, wall mounted terminations, Figure 14 or 14a.
Hearth
12”
MAX.
Heat
Shield
Termination
Exterior
Wall
33”
NOTE: 12” MAX�
horizontal run with
no vertical lift�
42”
60”
A
C
B
Acceptable vent run
within non-shaded area.
Unacceptable vent run
within shaded area.
12”
33”If your installation does not fall within
the venting graph parameters, please
contact a local Montigo dealer for
Power Venting options.

Page 16 XG0816 - 150204.1
H*38DF PFC Peninsula Gas Fireplace
Installation
Note: Images are shown without screens for clarity purposes. However,
your replace should not be operated without proper installation of
screens.
Figure 15b� HP38PF* Rear Vented, wall mounted Multi-elbow termination
installation. The vent run must comply with the Venting Graph for Rear vent,
wall mounted terminations, Figure 14a.
42” Max.
60” Min.
12”
Max.
27”Min.
33”
Hearth
Flex or Rigid
Section
Figure 15a� H38PF* or HL38PF* Rear Vented, wall mounted Multi-elbow
termination installation. The vent run must comply with the Venting Graph for
Rear vent, wall mounted terminations, Figure 14.
42” Max.
53” Min.
12”
Max.
20”Min.
33”
Hearth
Flex or Rigid
Section

Page 17
XG0816 - 150204.1
H*38DF PFC Peninsula Gas Fireplace
Installation
Connection and installation of the vent components should
adhere to the following guidelines:
Section 3-3-2: VENTING COMPONENTS
The following components and associated Montigo part numbers for
installation of a roof or wall mounted termination. Use only Montigo
Vent Components� Use of non-Montigo parts will VOID the warranty
and may impede operation of the replace.�
A - Termination PTO4 (3" Length)
PTO-F (3" Length)
PVTK1
B - Frame Kits MSR (Stucco Frame)
MOSR (Stucco Frame)
BSR-4 (4" Brick Frame)
BSR-6 (6" Brick Frame)
C - Flex Sections PFL - 1 (12" f/f Section)
PFL - 18 (18" f/f Section)
PFL - 2 (24" f/f Section)
PFL - 3 (36" f/f Section)
PFL - 4 (48" f/f Section)
PFL - 6 (72" f/f Section)
D - Rigid Sections PXT - 5 (5" f/f Section)
PXT - 10 (10" f/f Section)
PXT - 20 (20" f/f Section)
PEXT - 1 (12" f/m Section)
PEXT - 2 (24" f/m Section)
PEXT - 3 (36" f/m Section)
PEXT - 4 (48" f/m Section)
PEXT - 6 (72" f/m Section)
E - Elbows PEL-90MM (m/m 90ºElbow)
PEL-90FF ( f/f 90ºElbow)
PEL-90FM ( f/m 90ºElbow)
PEL-45FM ( f/m 45ºElbow)
F - Support Ring & Plate PSPXT-8
G - Firestop FS-8
H - Roof Flashing PRF-7 (1/12 - 7/12 pt�)
PRF-12 (7/12 - 12/12 pt�)
I - Heat Shield RHS101
J - Heat Guard MTKOG
IMPORTANT:
Please Refer to your Building Envelope Engineer
or Waterproong Consultant for a review of ALL
penetrations through exterior walls or the roof�
Montigo recommends the use of a ex section for the nal pipe
connected directly to the replace offering greater exibility of
installation and absorption of movement.
Firestops must be installed as required by National & local codes.
Montigorecommends that allexteriorcorners and jointsbesealed
with exterior caulking. However, we encourage you to consult
your Building Envelope Engineer or Waterproong Consultant
for further recommendations.
Use any combination of rigid and ex pipe as required and in
any orientation (Male connectors can face in any direction).
Flex sections may be stretched up to 50% of their total length
(e.g. a 24” section maybe stretched to 36”).
Connect all vent sections using a minimum of three sheet metal
screws on the outer pipe ue.
Ensure the pipe ends male to female slide in a minimum of 1
1/2” of overlap.
Ensure all horizontal runs are supported with a minimum of 3
supports per 10’ of venting.
When hanging/ supporting venting, ensure that 1” clearance
is maintained on sides and bottom of vent runs and 2” above
horizontal vent runs to any combustible material.
Rigidpipe may becutlessthan halfwayfromthe female endonly�
Ensure when cutting sections of rigid pipe to maintain integrity
of internal supports.
Place the springs, supplied with the pipe kit, between the outer
and inner pipes to keep the pipes separate and avoid any
possible hot spots.

Page 18 XG0816 - 150204.1
H*38DF PFC Peninsula Gas Fireplace
Installation
Note: Images are shown without screens for clarity purposes. However,
your replace should not be operated without proper installation of
screens.
Figure 16� RHS8 Installation. (Install by sliding over vent pipe where it passes
through the combustible construction). Figure 17� RHS101 Installation. (Install by sliding Outer Section over vent pipe
where it passes through the combustible construction.
Figure 17a� Heat Shield. After sliding the outer section in place.
Figure 16a� Minimum requirements for RHS8
Section 3-3-3: Heat Shields
Installing a Wall Mounted RHS8 Heat shield
The RHS8 Heat shield CANNOT be used WITHIN 36" horizontal or
60" vertically of the replace, (see gure 16a). For applications within
these dimensions the RHS101 Heat Shield MUST be used. .
To install the RHS8, frame an opening in combustible construction,
Figure 16 below. Slide the Heat shield in place over the vent pipe
which attaches to the replace. After the replace and vent pipe has
been installed, clearances should match the dimensions in Figure 16.
Installing a Wall Mounted RHS101 Heat shield�
The RHS101 Heat shield MUST be used where the RHS8 Termination
(Figure 16 and 16a) CANNOT be used. Use the RHS101 within 36"
horizontal or 60" vertical�
To install the RHS101, Slide the Inner Section over the vent pipe that will
connect to the replace. Fasten the vent pipe to the back of the replace
with a Min. of three sheet metal screws.
Next, slide the RHS101 outer section from the outside of the structure,
see Figure 17.
To complete the installation fasten the Heat Shield Outer Section &
Termination frame to the structure Figure 17a.
RHS8 Heat Shield
1” Min. Both sides Typical
1” Min.
1” Min.
Combustible Framing
Figure 17b� RHS101 Installation.
Outer Shield 10 1/4”
3/8” Min. Both sides Typical
3/8” Min.
3/8” Min .
Combustible Framing
12” x 12”
Inner Shield 9 3/8”
RHS8 Heat
Shield
36” Min
60” Min.
Termination
Termination
Drywall / sheetrock
RHS101 Heat Shield, inner Section
RHS101 Heat Shield
Outer Section
Combustible
framing
Termination
Drywall / sheetrock
RHS101 Heat Shield, inner Section
RHS101 Heat Shield
Outer Section
Vent pipe, from fireplace

Page 19
XG0816 - 150204.1
H*38DF PFC Peninsula Gas Fireplace
Installation
Section 4: Wiring
Models Included
H38DFPFCN-F HL38DFPFCN-F HP38DFPFCN-F
H38DFPFCL-F HL38DFPFCL-F HP38DFPFCL-F
Figure 18. Wiring Diagram for the SIT Proame 2 Electronic Ignition with remote control
Honeywell (Q3450)
Pilot Assembly
Pilot Electrical
Harness Connector
Honeywell Gas
Control (SV9501M)
Gas Control
Connector
Junction Box
115VAC
24VAC
40 VA
Transformer
Black
White
Green
Gnd Screw
Wall Switch
Fan Plug
Receptacle
Figure 20. Wiring with Honeywell gas control and pilot.
Installing the remote On/Off Wall Switch
The SIT Nova 820 gas valve may be connected
to a wall switch. Do NOT connect any external
powerto the remoteswitch.Thevalve will generate
its own power on a millivolt circuit Use only low
voltage wire, and NOTE: The switch location must
not exceed 30' from the replace.
Figure 19. Wiring with SIT Nova 820.
Models Included
H38DFPFCN
H38DFPFCL
HL38DFPFCN
HL38DFPFCL
Manifold Pressure
Test Connection
Wall Switch
Power
Generator
Pilot Adjustment Screw
Inl
e
t Pr
essu
r
e
'Hi-Lo' Adjustment Knob
Gas Control Knob (Shown in “Pilot” position)
Models Included
H38DFPFCN-I
H38DFPFCL-I
HL38DFPFCN-I
HL38DFPFCL-I
NOTE: If any of the original wire supplied with the appliance is replaced,
it must be replaced with the same type, or its equivalent.
1.5V AA type
1.5V AA type
1.5V AA type
1.5V AA type
BLACK
WHITE
GREEN
To PPO
SPARK
SENSOR
RED
BLACK
BATTERY
PACK
MAIN ON/OFF
SWITCH
YELLOW/GREEN
885 PROFLAME
PILOT
BURNER
ORANGE
GREEN
BLACK
BROWN
YELLOW
ORANGE
6
10
4
6
3
4
OPTIONAL CPI/IPI SWITCH BLUE
WHITE
X10
X11
X12
X13
X1
X6
X5
X4
X3
X2
LED Lights
LED1 - Red LED
LED2 Amber LED
3.15A FUSE
SW1

Page 20 XG0816 - 150204.1
H*38DF PFC Peninsula Gas Fireplace
Installation
Optimumapplianceperformance requires properinputpressures.
Gas line sizing requirements will be determined in ANSI Z223.1
National Fuel Gas Code in the USA and CAN/CGA B149 in
Canada.
Pressure requirements are:
Gas Pressure Natural Gas Propane
Minimum inlet pressure 5�5in� w�c� 11in� w�c�
Manifold pressure 3�5in� w�c� 10in� w�c�
The manifold outlet pressure is set from the factory to the
appropriate pressure but should be veried.
To check pressures, control valves have a provision to remove
a 1/8” N.PT. plug to be tted with a hose barb.
Montigo requires a service shut off valve be located in an
accessible location to isolate the gas supply.
Only install gas shut-off valves approved for use by the state,
province, or other governing body in which the replace is being
installed.
Figure 21� Gas line access.
3”
Gasline Access
7/8”dia hole
Electrical
A
ccess 2”x 3”
6 1/2”
Section 5: Installing the Gas Line
We recommend careful consideration be given to the effects of elevated mantel
temperatures which may be in excess of product design, for example: candles, plastic
or pictures. This can cause melting, deformation, discoloration or premature failure of
T.V. radio, and other electronic components.
CAUTION
When pressure testing the fireplace, Gas line, and input system follow the appropriate
local codes or your area. DO NOT connect the fireplace to pressures in excess of
1/2lb. This will damage the gas control valve.
NOTICE
Note: Images are shown without screens for clarity purposes. However,
your replace should not be operated without proper installation of
screens.
WARNING:
An inspection of the explosion relief appers and door
MUST be made prior to lighting the replace. A faulty seal
on the door gasket and/or explosion ports will result in
products of combustion leaking into the living space and
may result in carbon monoxide poisoning.
Section 5-1: FUEL CONVERSION
Verify that your replace is compatible with your available gas
type. (Natural Gas or Propane shown by "N" or "L" in your
model number
If gas type is not compatible, contact your local Montigo
representative.
Conversion kits must be installed by a qualied service technician.
Section 5-2: GAS PRESSURE
See Figure 21 for location of gas line access.
Flexible gas connectors must not exceed 3 feet in length, unless
allowable within local regulations.
Connect incoming gas line to the 1/2"or 3/8" gas inlet port.
Purge all air out of gas line.
Check appliance connection, valve and valve train under normal
operating pressure with a commercially available leak check
solution.
DO NOT USE A FLAME OF ANY KIND TO TEST FOR LEAKS�
Section 5-3: GAS CONNECTION
WARNING
When installing the replace - gas lines, ttings,
accessories or any other objects cannot impede the
proper movement of the door buckles.
