XG0781 151104
RP424PFC
RP-Series
Indoor
Resi
dential
Fireplace
Installation & Maintenance Manual
Installer: Leave this manual with the appliance.
Consumer: Retain this manual for future reference.
NOTICE
If the information in these instructions is not followed exactly, a fire or explosion
may result causing property damage, personal injury or death.
WARNING
This fireplace is certified to ANSI Z21.50 / CSA 2.22 Vented Fireplace Standard as a
power assisted direct vent fireplace. This product uses outdoor air for combustion and
and exhausts combustion products outdoors.
NOTICE
Canadian Heating Products Inc. Langley, BC V4W 4A1 | Montigo Del Ray Corp. Ferndale, WA 98248

Page 2 XG0781 - 151104
Table of Contents
RP424PFC Indoor Gas Fireplace
Introduction 3
Unit Specications 4
Section A: Before You Begin 5
Rating label sample: Natural Gas Sample Shown 5
Section 1: Product Dimensions 6
Introduction to the RP-Series Fireplace: 7
Basic Operation: 8
Unpacking the Crate 10
Converting to Rear Vent 14
Section 2: Framing 16
Section 3: Finishing 19
Section 4: Wiring 21
Section 5: Installing the gas line 23
Section 6: Venting Conguration 24
PV VEX58-300 Vertical Power Vent Detail 25
PVVEX58-300 Power Vent Locations 26
PVHEX58-300 Horizontal Power Vent Detail 27
PVHEX58-300 Power Vent Locations 28
PV HFL58-300 Horizontal Power Vent Detail 29
PVHFL58-300 Power Vent Locations 30
Section 8:Testing the System 32
Testing the Lights 32
Accessing the Valve 33
Testing the Gas Pressure 35
Section 9: Installing Accessories 38
Firestone / Fireglass Installation 38
Ceramic Speckled Stone Installation 38
Driftwood Log Set (Optional) 39
Section 10: Installing the Glass 42
Unpacking the Glass Crate: 42
Using the Glass Handling Tool: 44
Installing the Mirror Glass Firebox Liner: 45
Installing the Glass Barriers: 46
Section 11: First Fire 50
Ignition Sequence 50
Adjusting the Fan Speed 51
Section 12: Operation 52
Section 13: Maintenance 54
General 54
Cleaning 54
Replacing Light Bulbs 55
Replacing the Vacuum Switches 56
Replacing the Delay Timer 58
Replacing the Valve 60
Replacing the Burner 62
Replacing the Pilot 66
Replacing the Thermal Switches 68
Replacing the Control Box 73
Vent Maintenance / Inspection 74
Replacing Glass 75
Troubleshooting 76
Replacement Parts 80
Appendix A: Warranty 81
Appendix B: State of Massachusetts 82

Page 3
XG0781 - 151104
RP424PFC Indoor Gas Fireplace
Safety Alert Key
Introduction
CAUTIO N
Glass doors on gas fireplaces are extremely hot while the fireplace is on and
remain hot even after the fireplace has been turned off. Safety screens are
available and can reduce the risks of severe burns. Please keep children away
from the fireplace at all times.
CAUTION
Glass doors on gas replaces are extremely hot while the replace is on and
remain hot even after the replace has been turned off. Keep children away from
the replace at all times.
Congratulations on your purchase of a Montigo Fireplace.
With over 30 years of experience, Montigo is committed to providing
you with a gas replace that is not only a beautiful addition to your
space, but that is also designed and manufactured to the highest
safety, reliability and engineering standards.
We strongly encourage you to read and carefully follow the instructions
laid out in this Installation, Operation and Maintenance Manual
and retain it for your future reference. Pay special attention to all
cautions, warnings, and notices throughout this manual intended
to ensure your safety.
This manual covers installation, operation and maintenance. Lighting,
operation and care of this replace can be easily performed by the
homeowner. All installation and service work should be performed
by a qualied or licensed installer, plumber or gas tter as certied
by the state, province, region or governing body where the replace
is being installed.
This installation, operation and maintenance manual is applicable
to the models described below. Refer to your rating plate to verify
included options.
Warranty and Installation Information: (See Appendix B)
The Montigo warranty will be voided by, and Montigo disclaims any
responsibility for, the following actions:
► Modication of the replace and/or components including
Direct-Vent assembly or glass doors.
► Use of any component part not manufactured or approved
by Montigo in combination with this Montigo replace system.
► Installation other than as instructed in this manual.
Consult your local Gas Inspection Branch on installation requirements
for factory-built gas replaces. Installation & repairs should be done
by a qualied contractor.
RP424PFCN-I X 45,000 X X
RP424PFCL-I X 45,000 X X
MODEL Natural Gas Liquid Propane Gas Rating (BTU hr) Linear Burner w/ Glass Accessories Honeywell Hot Surface Ignition
This appliance is equipped for altitudes from 0 - 4500 feet
[0 -1370 m]. For higher altitudes contact your Montigo dealer.
Introduction
Young children should be carefully supervised when they are
in the same room as the applicance. Toddlers, young children
and others may be susceptible to accidental contact burns. A
physical barrier is recommended if there are at risk individuals
in the house. To restrict access to a fireplace or stove, install
an adjustable safety gate to keep toddles, young children and
other at risk individuals out of the room and away from hot
surfaces.
CAUTION

RP424PFC Indoor Gas Fireplace
Page 4 XG0781 - 151104
Installation
Introduction
Unit Specications
Model Number RP424PFCN-I RP424PFCL-I
Input Rating 45,000 45,000
Gas Supply Pressure 7" WC 11" WC
Manifold Pressure 3.5" WC 10" WC
Orice Size (DMS) 3 @ #48 3 @ 1.15 mm
Pilot Orice Size (No.) BCR18 BBR10
Fireplace Electrical Requirement 115VAC, 60Hz, 5 Amps 115VAC, 60Hz, 5 Amps
Lighting Electrical Requirement 115VAC, 60Hz, 3 Amps 115VAC, 60Hz, 3 Amps
Vent Size 5"/8" 5"/8"
Minimum Vent Length 1' (Rear Vent) 1' (Rear Vent)
Maximum Vent Length 25' 25'
Maximum Wall Switch Cable 20' (supplied) 20' (supplied)
Maximum Power Vent Cable
(EPVH) As ordered As ordered
Maximum Control Cable 30' (supplied) 30' (supplied)
Control Box Power Cord 10" 10"
PVVEX58-300 2.4 Amps 2.4 Amps
PVHEX58-300 2.4 Amps 2.4 Amps
PVHFL58-300 2.4 Amps 2.4 Amps
Crate Dimensions 74.5" x 40.5" x 66.25" 74.5" x 40.5" x 66.25"
Crated Weight 877 lbs. 877 lbs.
Fireplace Weight (excluding
glass & media) 436 lbs* 436 lbs*
Light Bulb Specication 20W, G6.35, 2.5 Amps, Qty 12 20W, G6.35, 2.5 Amps, Qty 12
Control Box Fuse Specication 5 Amps 5 Amps
Certication(s) ANSI Z21.50-2014 / CSA 2.22-2014 Vented Gas Fireplaces
CGA 2.17-M91 - Gas-Fired Appliances for Use at High Altitudes
*The replace weight is not evenly distributed. This replace is heavier at the rear

RP424PFC Indoor Gas Fireplace
Page 5
XG0781 - 151104
Installation
Section A: Before You Begin
Introduction
Rating label sample: Natural Gas Sample Shown
Installation and repairs should be done by an authorized gas fireplace service technician.
Theapplianceshouldbeinspectedbeforeuseandatleastannuallybyaprofessional.More
frequent cleaning may be required due to excessive lint from carpeting, bedding material,
etc. It is imperative that control compartments, burners and circulating air passageways of
thefireplaceare kept clean.
NOTICE
IMPORTANT MESSAGE: SAVE THESE INSTRUCTIONS
The RP-Series Power Vent replaces must be installed in
accordance with these Instructions. Carefully read all the
instructions in this manual rst. Consult the Local Gas Branch to
determine the need for a permit prior to starting the installation.
It is the responsibility of the installer to ensure this replace is
installed in compliance with the manufacturers instructions and
all applicable codes.
BEFORE YOU START:
Due to high operating temperatures, this appliance should be located out of traffic &
away from furniture and draperies.
Children and adults should be alerted to the hazards of the high surface temperature,
which could cause burns or clothing ignition.
Youngchildren should be carefully supervised when they are in thesameroomasthe
appliance.
Clothing or other flammable materials should not be placed on or near the appliance.
CAUTION
Contents of the Crate:
• RP424PFC Fireplace
• Control Box
•Chosen Burner Media
• Glass Crate
•Glass Removal Tool
• Rear Vent Conversion Tube (located inside the control
box)
• Installation & Maintenance Manual



 












RP424PFC_lbl1209-v1.0 OCT.21..2015
  










 











  


 


 




    






 
 
 


 




 
Teklynx LabelView Demo
Rating Plate Locations:
• Inside the control box
• Under the burner
•On the rear of the appliance

RP424PFC Indoor Gas Fireplace
Page 6 XG0781 - 151104
Installation
Introduction
5"
126
8"
203
24"
610
48"
1218
12"
305
61"
1548
14"
356
51
2
"
140
95
8
"
243
65"
1650
10 1
8
"
258
66 7
8
"
1698
44 5
8
"
1132
31
2
"
90
5
8
"
16
23 7
8
"
607
50"
1270
56 1
4
"
1427
24"
610
53"
1346
Section 1: Product Dimensions
Figure 1.RP424PFC Fireplace Dimensions (Tolerance ±⅛") [3mm]
11 7
8
"
303
10"
255
31
4
"
82
11 1
2
"
292
71
4
"
186
53
4
"
148
13
8
"
34
95
8
"
244
Figure 1a. RP424PFC Control Box Dimensions (Tolerance ±⅛") [3mm]
11 7
8
"
303
10"
255
31
4
"
82
11 1
2
"
292
71
4
"
186
53
4
"
148
13
8
"
34
95
8
"
244
11 7
8
"
303
10"
255
31
4
"
82
11 1
2
"
292
71
4
"
186
53
4
"
148
13
8
"
34
95
8
"
244
11 7
8
"
303
10"
255
31
4
"
82
11 1
2
"
292
71
4
"
186
53
4
"
148
13
8
"
34
9
5
8
"
244
Front View Rear View
Right Side View
Top View

RP424PFC Indoor Gas Fireplace
Page 7
XG0781 - 151104
Installation
PVVEX58-300
Vertical Power Vent
PVHEX58-300
Horizontal Power Vent
PVHFL58-300
Horizontal Power Vent
Flush / Louvered
Control Panel
On/Off Switch - Standard
Single Pole On/Off
Switch
(not supplied)
Light - Standard
Single Pole On/Off
Switch
(not supplied)
115 VAC 60 Hz
supply from
distribution panel
RP424PFC
Fireplace
Power Vent Control Cable
(Not supplied. Order required
length from your Montigo Dealer)
Appropriate Montigo Venting
Components 5" x 8"
Light Wiring
(not supplied)
Control Box Cable
30' supplied standard
20' low voltage wire supplied
Outer glass
barrier
Figure 2. RP424PFC major components
Introduction
The complete system will require a RP424PFC rebox,
appropriate venting, suitable termination, and control panel.
Review the installation sequence on page 8 for general
information on preparing for a successful installation of
your replace. The RP-Series replace is not intended
to be used as a primary heat source and should not be
connected and operated with a thermostat switch.
Introduction to the RP-Series Fireplace:
The RP424PFC includes a protective tempered glass barrier
designed to meet the 2015 safety standard to protect young
children and other at-risk individuals from serious burns.

RP424PFC Indoor Gas Fireplace
Page 8 XG0781 - 151104
Installation
Introduction
Install location:
The RP-Series replace may be installed in any location that
maintains proper clearances to air conditioning ducts, electrical
wiring, and plumbing. Safety, as well as efciency of operation,
must be considered when selecting the replace location. Try
to select a location that does not interfere with room trafc,
has adequate ventilation, and offers an accessible pathway for
Power Vent installation. A gas appliance must not be connected
to a chimney ue serving a separate solid-fuel burning
appliance. Ensure the replace is installed in a way that the
ow of combustion and ventilation air is not obstructed.
Basic Operation:
The gas control components of this replace are located at the
rear of the replace. All models are supplied with a Honeywell
smart valve gas control and do NOT have a variable ame
control. A differential pressure switch located at the rear of
the replace monitors airow and controls the gas valve.
A thermal switch located on the top of the rebox acts as a
secondary safety system to shut down the replace in the
event that normal operating temperatures are exceeded. These
components communicate with the electrical control panel
through a nine conductor cable supplied with the replace.
To operate the replace, Montigo supplies 20' of low voltage
wire from the electrical control panel. Connect the two wire
harnesses to a standard single pole ON/OFF switch to the
location of your choice. You may extend these wires up to 100'
in length with a wire of equal quality.
This replace is equipped with lights which need to be wired
through an ON/OFF wall switch as shown in the schematic.
If possible, wire the lights and power vent on the same circuit
breaker.
ON/OFF control of this appliance can also be performed using
an optional remote control available from your Montigo dealer.
Do not use this appliance if any part has been under water.
Immediately call a qualied service technician to inspect the
appliance and to replace any part of the control system and any
gas control that has been under water.
Installation Sequence
■ Unpacking and set-up
■ Rear vent conversion
■ Fireplace placement and securing
■ Framing
■ Power connection
■ Gas connection
■ Power vent termination installation (see manual provided
with the power vent chosen)
■ Vent installation
■ Test ring
■ Wall boarding / nishing
■ Installation of glass barriers / accessories
Installation and repairs should be done by a qualied contractor
and must conform to:
•InstallationsinCanada must conform to the local codes or
in the absence of local codes to the current version of Natural Gas
and Propane Installation Code, CSA B149. Electrical Installations
must conform to the local codes or, in the absence of local codes,
to the current version of Canadian Electrical Code, CSA C22.1.1
• Installations in the USA must conform to the local codes
or in the absence of local codes to the current version of National
Fuel Gas Code, ANSI Z223.1/NFPA 54. Electrical Installations must
conform to the local codes or, in the absence of local codes, to the
current version of the National Electrical Code, ANSI/NFPA 70.
SeeAppendixB for installation within the State of Massachusetts.
Fuel Type
Verify that your replace is compatible with your available gas
type. Natural Gas or Propane shown by "N" or "L" in your model
number on rating plate.
The RP424PFC is classified underpower vented fireplace systems.
Underno circumstances can these models be installed without a
Power Vent Module. For Horizontal Vent Installations, use 5”/8”
Power Vent Motor PVHEX58-300 or PVHFL58-300.
PVVEX58-300.
For Vertical Vent Installations, use 5”/8” Power Vent Motor
WARNING

RP424PFC Indoor Gas Fireplace
Page 9
XG0781 - 151104
Installation
Figure 3. RP424PFC Major Components Overview
Vent Connection
Service Access
Panel
Ignition
System
Glass Barrier
Burners
FRONT
SIDE
RIGHT SIDE
Rear Vent
Access Plate
Valve Cover
Gas Valve
Hold Down
Brackets x4
Accent Light
Electrical
Connection
Gas Line
Connection
Vacuum Switch
Assembly
Light Delay Timer
Assembly
Vent Configuration
Switch
LEFT SIDE
RP424PFC Major Components Overview:

RP424PFC Indoor Gas Fireplace
Page 10 XG0781 - 151104
Installation
Figure 4.
Step 2: Remove the cardboard wrapping from the crate.
Figure 5.
Step3: Remove the center brace from the top of the crate by removing
the wood screws securing the brace to the crate ends.
Figure 6.
Step 4: Remove the support that is secured between the Accessory
Tray and the Vent Connection.
Figure 7.
Step5: Remove the screws securing the right side of the crate where
indicated in Figure 8.
Figure 8.
Step 6: Remove the Accessory Tray.
Figure 9.
Unpacking the Crate
The RP424PFC is packaged with the ease of unpacking in mind.
Use the following steps to unpack the crate.
Step 1: Remove the cardboard covering the Accessory tray on top
of the replace.

RP424PFC Indoor Gas Fireplace
Page 11
XG0781 - 151104
Installation
Step 7: Remove the screws securing the bottom of the glass crate
at both ends.
Figure 10.
Step8: Obtain assistance in lifting the glass crate from the crate. The
glass crate weighs approximately 200lbs and contains all the glass
for the replace. This crate can be placed in a safe location until it is
needed. See Section10 for instructions on installing the glass panes.
Step 9: Unscrew and remove the left side of the crate.
Figure 11.
Figure 12.
Step 10: Remove the screws securing the shipping support bracket
to the front end of the crate. Shipping support bracket shown from
inside the replace.
Figure 13. View from inside replace.
Figure 14.
Step 11: Unscrew and remove the front of the crate. Repeat for the
rear of the crate.

RP424PFC Indoor Gas Fireplace
Page 12 XG0781 - 151104
Installation
Note: The shipping support bracket and rear of the replace can be
used to assist in lifting and moving the appliance to the install location.
Ensure all 8 screws are installed before using the shipping support
bracket to lift the appliance. There are four lifting points comprised
of 1.5" lifting holes. Slide a bar or strap through the lifting holes as
shown to assist in moving.
Lifting hole
Step 11: The appliance is anchored to the base of the crate at each
corner using hold down brackets and lag bolts. Remove lag bolts
using a 7/16" socket wrench. If desired, the hold down brackets may
be left on the appliance to mount in the install location.
Figure 15.
Figure 16.
Step 12: It is now possible to unscrew and remove the shipping
support bracket, however, we recommend leaving the shipping
support bracket in place until all framing is complete. The bracket
maintains the correct opening size during install.
Figure 17.
Lifting hole
Figure 16a.
The weight in this replace is NOT evenly distributed. This
replace is heavier at the rear. Use caution when lifting to avoid
injury or damage.
CAUTION

RP424PFC Indoor Gas Fireplace
Page 13
XG0781 - 151104
Installation
Step 13: Cardboard is used to protect the burner against dust and
debris. Remove prior to install.
Step 14: Remove the screw securing the control box to the rear of
the appliance. Replace the screw after removing the control box.
Figure 18.

RP424PFC Indoor Gas Fireplace
Page 14 XG0781 - 151104
Installation
Figure 19.
Step 2: Remove the Inner Vent Cover.
Figure 20.
Step 3: Remove the Pressure Tube using 1/2" wrench.
Figure 21.
Step 4: Find the Rear Conversion Pressure Tube Kit located in the
Control Box.
Figure 22.
Step 5: Attach the Rear Conversion Pressure Tube using 1/2"
wrench. Ensure the tube points straight out the rear of the appliance.
Figure 23.
Converting to Rear Vent
The RP424PFC can be easily converted from top vent to rear vent
by following the steps below.
Step1: Remove the Outer Vent Cover from the back of the replace.

RP424PFC Indoor Gas Fireplace
Page 15
XG0781 - 151104
Installation
Step 6: Remove the Intake Collar from the top of the replace.
Figure 24.
Step 7: Remove the Exhaust Collar from inside the top of the
Exhaust Box.
Figure 25.
Step 8: Align the Exhaust Collar with a 5" gasket. Secure to the
back of the Exhaust Box.
Figure 26.
Figure 27.
Step 8: Align the Intake Collar with an 8" gasket. Secure to the back
of the Fireplace.
Figure 28.
Step 9: Align the Inner Vent Cover with a 5" gasket. Secure to the
top of the Exhaust Box.
Step 9: Align the Outer Vent Cover with an 8" gasket. Secure to the
top of the replace.
Figure 29.

RP424PFC Indoor Gas Fireplace
Page 16 XG0781 - 151104
Installation
Section 2: Framing
Clearances to combustibles:
To ensure the replace operates safely, all models must maintain
the following clearances to combustibles:
RP-
424PFC 0" 0" 0" 0" 0" 0" 0" 0"
MODEL Top - Rear Vent †
Rear - Top Vent
Top - Top Vent †
† Note: C l e a r a n c e f r o m t o p o f  r e p l a c e t o a c o m b u s t i b l e c e i l i n g
within the replace enclosure.
Venting is approved in this appliance to zero clearance to combustible
material.
Rear - Rear Vent Sides Floor Mantel Venting
When planning your installation, take into consideration the
area around the appliance where combustible building materi-
als cannot be placed. Install in accordance with this manual,
regardless of the type of construction used or any other consid-
eration.
Wall Board
Framing
Flooring
Finishing
Material
Wall Board
Framing
Glass
RP424PFC
Figure 30. RP424PFC Typical Framing
Whenthis appliance is installeddirectlyon any combustible materialotherthanwood
flooring, it must be installed on a metal or wood panel extending the full width and
depth of the appliance or a fire will occur causing serious injury, property damage or
even death.
DANGER

RP424PFC Indoor Gas Fireplace
Page 17
XG0781 - 151104
Installation
Framing Dimensions:
53"
1346
68 1
2
"
1738
19"
483
13 3
8
"
+
-
1/4"
1/4"
339
+
-
6
6
62 1
4
"
+
-
1/4"
1/4"
1582
+
-
6
6
Top Vent
24"
610
1/8" [3mm] Unless otherwise noted.
68 1
2
"
1740
53"
1346
19"
483
44 5
8
"
1133
24"
610
Rear Vent
1/8" [3mm] Unless otherwise noted.
Figure 31. RP424PFC Framing Dimensions

RP424PFC Indoor Gas Fireplace
Page 18 XG0781 - 151104
Installation
76 3
4
"
+
-
1/4"
1/4"
1949
+
-
6
6
53"
1346
28 1
4
"
+
-
1/4"
1/4"
719
+
-
6
6
Rear Vent with 90 Elbow
24"
610
1/8" [3mm] Unless otherwise noted.
53"
1346
77 1
2
"
+
-
1/4"
1/4"
1967
+
-
6
6
29 1
2
"
+
-
1/4"
1/4"
751
+
-
6
6
51
2
"
140
44 5
8
"
1133
24"
610
Rear Vent with PVHFL58-300
1/8" [3mm] Unless otherwise noted.
Figure 31a. RP424PFC Framing Dimensions

RP424PFC Indoor Gas Fireplace
Page 19
XG0781 - 151104
Installation
Combustible mantels and mouldings may be safely installed over the top and on the front of the replace provided that they do not cover
any portion of the glass viewing area or prohibit the removal of glass panels in any way.
The face of the replace may be painted to match the room decor, provided you use a heat-resistant paint. Decorative facing must not
extend into the replace opening at all because it will interfere with removal of glass barriers.
Finishing Around the Fireplace
Section 3: Finishing
Figure 32. Combustible Mantles and Facings (image cropped for illustration, not to scale).
Note: Dimensions shown in inches. Combustible dimensions referenced above applies to all three sides of the appliance.
0
1
2
3
4
5
6
12 11 10 9 8 7 6 5 4 3 2 1
7
0
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
Combustible Construction
allowed is shaded area
Combustible Construction
allowed in shaded area
112 11 10 9 8 67 5 4 3 2
0
1
2
3
4
5
6
12 11 10 9 8 7 6 5 4 3 2 1
7
0
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
Combustible Construction
allowed is shaded area
Combustible Construction
allowed in shaded area
112 11 10 9 8 67 5 4 3 2
TOP
BOTTOM
Combustible
Framing

RP424PFC Indoor Gas Fireplace
Page 20 XG0781 - 151104
Installation
1"
25
15"
381
5"
127
11
4
"
33
48"
[1219]
8"
203
24
[610]
DO NOT SCREW,
DRILL OR NAIL
IN THESE AREA'S DUE
TO POSSIBLE DAMAGES
TO GLASS
(BOTH SIDES)
DO NOT SCREW,
DRILL OR NAIL
IN THIS AREA DUE
TO POSSIBLE DAMAGES
TO GAS LINE
(BOTH SIDES)
Careful consideration should be taken when nishing the outer surface of the replace. Never penetrate areas shown in Figure 32a.
Never penetrate any surface beyond a depth of 1/4".
Figure 32a.
NOTE: National Canadian Gas Association mantel test requirements are for re hazard prevention to combustible materials.
New technology, to meet consumer and government demands for the wise use of energy, has prompted us to manufacture many models
of replaces which are hot, fuel and energy efcient.
Please be aware; temperatures over the mantel will rise above normal room temperature and walls above replace may be hot to touch.
We recommend careful consideration be given to the effects of elevated mantel temperatures which may be in excess of product design, for
example: candles, plastic or pictures. This can cause melting, deformation, discolouration or premature failure of T.V. and radio components.
Mantels & Surrounds
