Montigo MAHANA PL42VO Instruction Manual

Page 1 XG0219 - 080421
Installation & Maintenance Manual
• The installation of this fireplace must be done by a qualified and
certified gas appliance installer.
• Check local codes and read all instructions prior to installation.
• Installer: leave this manual with the appliance.
• Consumer: retain this manual for future reference.
®
C
US
CARBON MONOXIDE HAZARD
This appliance can produce carbon
monoxide, which has no odor.
Using it in an enclosed space can
kill you.
Never use this appliance in an
enclosed space such as a camper,
tent, car or home.
WARNING: For Outdoor Use Only.
DANGER
If you smell gas:
• Shut off gas to the appliance.
• Extinguish any open flame.
• If odor continues, keep away from the appliance and
immediately call your gas supplier or fire department.
WARNING
Do not store or use gasoline, or other flammable vapors and
liquids, in the vicinity of this or any other appliance.
A propane-cylinder not connected for use shall not be
stored in the vicinity of this or any other appliance.
WARNING
Improper installation, adjustment, alteration, service or
maintenance can cause injury or property damage.
Read the installation, operating, and maintenance instructions
thoroughly before installing or servicing this equipment.
DANGER
MAHANA PL42VO
28,000 btu/hr Natural Gas or Propane Gas
MAHANA PL60VO
47,000 btu/hr Natural Gas or Propane Gas
Outdoor Gas Fireplace
Some materials used in the manufacturing process of this product can
expose you to Benzene which is known in the State of California to
cause cancer and birth defects or other reproductive harm. For more
information go to www.P65warnings.ca.gov
WARNING

General Information & Safety
Page 2 XG0219 - 080421
Contents
Conditions and Limitations ......................................................................................................... 3
Getting Started............................................................................................................................. 4
Gas line and connection:..................................................................................................... 4
Electrical: ............................................................................................................................. 4
Safe Operating Practices............................................................................................................. 5
Certification ................................................................................................................................. 6
Rating Plate Location: ......................................................................................................... 6
Full Rating Plate Location: .................................................................................................. 6
Appliance Certification................................................................................................................ 7
Certification ......................................................................................................................... 7
Installation Standards: ....................................................................................................... 7
High Altitude Installations:.................................................................................................. 7
Operational Warnings.................................................................................................................. 7
Dimensions .................................................................................................................................. 8
MAHANA PL42VO Dimensions............................................................................................. 8
MAHANA PL60VO Dimensions............................................................................................. 8
Control Box Dimensions...................................................................................................... 9
Location Considerations............................................................................................................ 10
MAHANA Exploded Part View .................................................................................................... 11
Tools and Supplies required...................................................................................................... 11
Tool List.............................................................................................................................. 11
Supply List ......................................................................................................................... 11
Gas supply requirements .......................................................................................................... 12
Electrical Requirements ............................................................................................................ 12
MAHANA PL42VO Framing......................................................................................................... 13
PL42VO In The Wall and Corner Installation..................................................................... 13
PL42VO Standalone Installation........................................................................................ 13
MAHANA PL60VO Framing......................................................................................................... 14
PL60VO In The Wall and Corner Installation..................................................................... 14
PL60VO Standalone Installation........................................................................................ 14
Clearances ................................................................................................................................. 15
Mantels & Surrounds......................................................................................................... 15
Clearance Specifications................................................................................................... 15
Finishing .................................................................................................................................... 16
Standalone......................................................................................................................... 16
In The Wall Installation...................................................................................................... 16
Fireplace Facing ................................................................................................................ 16
Mounting the Fireplace Control Box ................................................................................. 17
Wiring................................................................................................................................. 17
Wiring Instructions (remote box to main control box).................................................... 19
Wiring Instructions.............................................................................................................20
LED Strip Instructions.........................................................................................................21
Gas connection ...........................................................................................................................22
Installing the louvres..................................................................................................................23
Installing & Removing the Door .................................................................................................24
Removing the door .............................................................................................................24
Installing the Door ..............................................................................................................24
Installing the Firestones.............................................................................................................25
Installing Optional Media ...........................................................................................................26
Installing Optional Speckled Stones .................................................................................26
Installing Optional Driftwood Log Set (PL42VO)................................................................26
Installing Optional Media ...........................................................................................................27
Installing Optional Media ...........................................................................................................28
Installing Optional Driftwood Log Set (PL60VO)................................................................28
Startup and initial operation ......................................................................................................30
LED Operation Verification – Applicable if light kit (MCLEDVO) is installed ....................30
Initial Fireplace Operation Verification – If gas supply is connected...............................30
Initial Fireplace Operation Verification – If gas supply not yet connected ......................30
Optimizing the Fan Speed .................................................................................................30
Operating the Fireplace..............................................................................................................31
Remote (RXM40VACVO)..............................................................................................................33
Installation..........................................................................................................................33
Remote................................................................................................................................33
Receiver ..............................................................................................................................33
BATTERY LIFE......................................................................................................................34
Battery Operated Device ....................................................................................................34
LEARNING TRANSMITTER TO RECEIVER.............................................................................34
TROUBLE SHOOTING............................................................................................................34
LED Remote Control Operation (MCLEDVO-01)..........................................................................35
Programming (Code Clearing and Code Matching)...........................................................35
LED Remote Control Operation (MCLEDVO-02)..........................................................................36
Programming (Code Matching)..........................................................................................36
Installing & Removing the Screen (For cleaning outside of glass)...........................................37
Replacement Screens:........................................................................................................37
Troubleshooting guide................................................................................................................38
Maintenance / Cleaning Instructions.........................................................................................39
Appendix B: Warranty.................................................................................................................40
Appendix B: Warranty Continued...............................................................................................41
Appendix B: Amendment
(Gas Fireplace / Equipment sold in the State of Massachusetts)��������������������������������������������������������42

General Information & Safety
Page 3
XG0219 - 080421
Montigo products are designed with superior components and materials, and are assembled by trained craftsmen who take great pride in their work.
Every component has been thoroughly inspected by a qualified technician before packaging and shipping to ensure that you, the customer, receive
the quality product you expect from Montigo.
Montigo warrants its products against manufacturing defects to the
original homeowner only, provided that the purchase was made through
an authorized Montigo dealer and is subject to the following conditions
and limitations:
• This limited warranty does not cover damages caused by misuse, lack
of maintenance, grease fires, hostile environments, accident, alterations,
abuse or neglect and parts installed from other manufacturers will nullify
this warranty. Discoloration to plastic parts from chemical cleaners or
UV exposure is not covered by this warranty.
• This limited warranty further does not cover any scratches, dents,
painted finishes, corrosion or discoloring by heat, abrasive and chemical
cleaners, nor chipping on porcelain enamel parts.
• Should deterioration of parts occur to the degree of non-performance
(rusted through or burnt through) within the duration of the warranted
coverage, a replacement part will be provided.
• After the first year, with respect to this Limited Warranty Montigo may, at
its discretion, fully discharge all obligations with respect to this warranty
by refunding to the original warranted purchaser the wholesale price of
any warranted but defective part(s).
• Montigo will not be responsible for the installation, labor or any other
costs or expenses related to the re-installation of a warranted part, and
such expenses are not covered by this warranty.
• Notwithstanding any provision contained in this Limited Warranty
Montigo’s responsibility under this warranty is defined as above and it
shall not in any event extend to any incidental, consequential, or indirect
damages.
Conditions and Limitations
• This warranty defines the obligation and liability of Montigo with respect
to the Montigo fireplace and any other warranties expressed or implied
with respect to this product, its components or accessories are
excluded.
• Montigo neither assumes, nor authorizes any third party to assume, on
its behalf, any other liabilities with respect to the sale of this product.
• Montigo will not be responsible for: over firing, blow outs caused
by environmental conditions such as strong winds, or inadequate
ventilation,
• Any damages to the fireplace due to weather damage, hail, rough
handling, damaging chemicals or cleaners will not be the responsibility
of Montigo.
• The bill of sale or copy will be required together with a serial number
and a model number when making any warranty claims from Montigo.
• Montigo reserves the right to have its representative inspect any
product or part prior to honoring any warranty claim.
• Montigo shall not be liable for any transportation charges, labor costs,
or export duties.
For outdoor use only
Improper installation, adjustment, alteration, service or maintenance
can cause injury or property damage. Read the installation, operating
and maintenance instructions thoroughly before installing or servicing
this gas appliance.
WARNING

General Information & Safety
Page 4 XG0219 - 080421
Congratulations on the purchase of aCongratulations on the purchase of a
Montigo FireplaceMontigo Fireplace
This product must be installed by a qualified installer.
• Do not install this model inside your home or any other confined space.
• See location section for minimum outdoor space requirements.
• Only burn this model with the glass front installed including the safety
screen protecting you from accidental contact with the hot glass.
• Please unpack the fireplace and count all of the parts before you start
installing.
• Make sure you inspected this fireplace for possible freight damage as
well as scratches to the front portion of this fireplace. To clean the front
portion use a mild cleaning agent and wipe the stainless steel in the
direction of the grain.
• Build a structure of your choice around the fireplace with wood, steel
studs or any other conventional building materials.
• Select a location that will limit the exposure to strong winds.
• Follow the location section guidelines for installations in smaller spaces
Gas line and connection:
• Have a certified gas fitter install a gas line that will supply the required
level of gas to the left side of this fireplace with an accessible gas
service shut off valve. Gas supply as per the rating and pressures
shown in section "Gas Connection"
Getting Started
Electrical:
• The unit has built in fans to force out all of the heat right above the
glass window. Due to the glass window, this model is less sensitive to
moderate wind conditions.
• Select a location where you would like to install the control box that will
control this fireplace.
• Install a 120 Volt cable from this box to the fireplace as per the electrical
diagram.
• Plug the power cable from your control box into a power supply that is
protected by a ground fault Breaker ( GFCI )
• The toggle switch that is located on the left side of the control box will
start the blowers running.
• Safety switches in the bottom of the fireplace will sense the moving air
stream and activate the gas burner system.
• The electrical installation must comply with applicable standards.
Ensure that all power to the appliance is off at the electrical breaker
or fuse before beginning installation. Ensure gas is turned off at the
shutoff valve before beginning installation.
During unpacking and assembly we recommended you wear work
gloves and safety glasses for your protection. Although we make every
effort to make the assembly process as problem free and safe as
possible, it is characteristic of fabricated steel parts that the edges and
corners might be sharp and could cause cuts if handled incorrectly.
WARNING
CAUTION

General Information & Safety
Page 5
XG0219 - 080421
• Contact with this appliance can cause severe burns.
• Installation and repair must be done by a qualified service person.
The appliance should be inspected before use and at least annually
by a qualified service person. More frequent cleaning may be required
as necessary. It is imperative the control compartment, burners and
circulating air passageways of the appliance be kept clean.
• Do not operate appliance before reading and understanding operating
instructions. Failure to operate appliance according to operating
instructions could cause fire or injury.
• Risk of burns. The appliance should be turned off and cooled before
servicing.
• Do not install damaged, incomplete or substitute components.
• Young children should be carefully supervised when they are in the
area of the appliance. Toddlers, young children and others may
be susceptible to accidental contact burns. A physical barrier is
recommended if there are at risk individuals in the vicinity. To restrict
access to an appliance or stove, install an adjustable safety gate to
keep toddlers, young children and other at risk individuals out of the
vicinity and away from hot surfaces.
• Ensure you have incorporated adequate safety measures to protect
infants/toddlers from touching hot surfaces.
• Under no circumstances should this appliance be modified.
• Keep the packaging material out of reach of children and dispose of the
material in a safe manner. As with all plastic bags, these are not toys
and should be kept away from children and infants.
• Do not leave appliance unattended when in use.
• For outdoor use only.
• This unit is not for use with solid fuel.
• Improper installation, adjustment, alteration, service, or maintenance
can cause injury or property damage. Read the installation, operating
and maintenance instructions thoroughly before installing or servicing
this equipment.
• This appliance shall be used ONLY outdoors in a well-ventilated space
and shall NOT be used inside a building, garage, or any other enclosed
area.
• Clothing or other flammable materials should not be hung from the
Safe Operating Practices
appliance, or placed on or near the appliance.
• Any guard or other protective device removed for servicing the
appliance must be replaced prior to operating the appliance.
• Inspect the fuel supply connection for signs of leakage (including the
hose for Propane models) before each use of the appliance.
• To extend the life of your appliance, protect and cover it from the
elements when not in use.
• Inspect the burner before each use, burner must be replaced prior to
the appliance being put into operation if it is evident that the burner is
damaged. Replacement burner shall be one specified by Montigo.
• Inspect the hose before each use of the appliance, if applicable. Hose
assembly must be replaced prior to the appliance being put into
operation if there is evidence of excessive abrasion or wear or if the
hose is damaged. Replacement hose assembly shall be that specified
by the Montigo.
• This product must be installed by a licensed plumber or gas fitter. See
appendix B for installation within the Commonwealth of Massachusetts
requirements.
• The appliance must be isolated from the gas supply piping system by
closing its individual manual shutoff valve during any pressure testing of
the gas supply piping system at test pressures equal to or less than 1/2
psi (3.5 kPa).

General Information & Safety
Page 6 XG0219 - 080421
Rating Plate Location:
The rating plate can be found on the underside of the control box
cover.
Full Rating Plate Location:
A rating plate with additional information can be found secured with
velcro on the inside wall of the base of the firebox. To access the
rating plate, the door and lower air baffle can first be removed for
easier access. (See Door Installation/Removal section for instructions)
Certification



 












LBA1200-V1.0 OutdoorCabanaFireHSI. 07.26.2016
  










 


    




  

  







    






 
 
 


 

 
Figure 1 Rating plate example
Figure 2 Control box rating plate
Figure 3 Full Rating plate
Figure 4 Removal of lower air bae

General Information & Safety
Page 7
XG0219 - 080421
Operational Warnings
WARNING! Initial Lighting: When lit for the first time, the appliance
emits a slight odor. This is a normal temporary condition caused
by the “burn-off” of internal paints and lubricants used in the
manufacturing process and does not occur again. Simply run the main
burner on high for up to 8 hours.
WARNING! You must have clear and easy access to the manual
shut off valve AFTER the appliance is installed and connected to
the gas supply in order to safely turn off the gas to the appliance for
emergencies.
WARNING! Never use this appliance for other than the intended use.
WARNING!
• Children and adults should be alerted to the hazards of high surface
temperatures and should stay away from the appliance to avoid
burns or clothing ignition.
• Children should be carefully supervised when they are in the area of
the appliance.
• Maintain 36" clearance from appliance front to any combustible
material.
• Clothing or other flammable materials should not be hung from the
appliance, or placed on or near the appliance.
• Any guard or protective device removed for servicing the appliance
must be replaced prior to operating the appliance.
• Installation and repair should be done by a qualified service person.
• The appliance should be inspected before each use and at least
annually by a qualified service person. More frequent cleaning
may be required as necessary. It is imperative that the control
compartment, burners and circulating air passageways of the
appliance be kept clean.
NOTE The appliance has been designed with several safety features,
which include a safety valve. If the burner flame is extinguished the
appliance will automatically shut down.
This appliance is also equipped with two air proving switches
which will shut off gas to the burner if the air supply to the unit is
compromised.
WARNING! Any modification to the appliance may compromise the
safety of this appliance.
Do not operate the appliance if any part has been under water.
Immediately call a qualified service technician to inspect the appliance
and replace any part of the control system and any gas control, which
has been underwater.
Certification
Standard: ANSI Z21.97-2014/CSA 2.41-2014
Type of Appliance: Outdoor Decorative Gas Appliance
Approvals: Approved for use in USA and Canada. Approved for use in the
State of Massachusetts
Certification Agency: Canadian Standards Association (CSA)
Installation Standards:
The installations must confirm with the requirements listed in this
document and to local codes. In the absence of local codes, it must
conform to the National Standards listed below. The appliance must be
electrically wired and grounded in accordance with the local codes and in
the absence of local codes must confirm to the National Standards listed
below.
USA: National Fuel Gas Code: ANSI 223.1/NFPA54
National Electrical Code: NFPA 70
Canada: Natural Gas and Propane Installation Code CSAB149.1
Canadian Electrical Code CSA 22.1
Appliance Certification
MAHANA
MODEL FUEL ORIFICE
SIZE
MAX. INPUT
Btu/Hr
MIN GAS INLET
PRESSURES
PL42VONE Natural Gas 1.45mmx3 28,000 5.5” W.C.
PL42VOLE Propane Gas #64x3 28,000 11.0” W.C.
PL60VONE Natural Gas 1.45mmx5 47,000 5.5” W.C.
PL60VOLE Propane Gas #64x5 47,000 11.0” W.C.
Figure 5 PL42VO, PL60VO Gas Standards
High Altitude Installations:
If the heating value of the Natural Gas or Propane supply is derated to
compensate for the high altitude, the following requirements may not apply.
Please check with your local gas supplier or authority having jurisdiction
and contact your Montigo dealer.
USA: This appliance is approved for installations up to an altitude of 2000 ft.
(610 m) above sea level. For installations beyond this level, please contact
your Montigo dealer for high altitude conversion kits.
CANADA: This appliance is approved for installations up to an altitude of
4500 ft. (1370m) above sea level. For installations beyond this level, please
contact your Montigo dealer for high altitude conversion kits.

Page 8 XG0219 - 080421
Installation
Dimensions
The fireplace may be installed
in any location that maintains
proper clearances to air
conditioning ducts, electrical
wiring and plumbing. Safety, as
well as efficiency of operation,
should be considered when
selecting the fireplace location.
Select a location that does not
interfere with room traffic, and
has adequate ventilation as
described in the location section.
MAHANA PL42VO Dimensions
MAHANA PL60VO Dimensions
3/4"
19
26 7/8"
681
1 1/4"
30
ELECTRICAL
42"
1067
22 1/4"
565
36 3/4"
932
13 1/2"
343
5 3/4"
146
39 3/4"
1011
43 3/4"
1111
12 1/2"
317
12 3/4"
325
11 5/8"
294
41 5/8"
1056
4 7/8"
124
3 1/4"
82
GAS
1:34
SIZE
DWG. NO.
A
REV.
SHEET 1 OF 2
WEIGHT:
P42VFO
FINISH
MATERIAL
DIMENSIONS ARE IN INCHES
TOLERANCES:
FRACTIONAL
1/32"
TWO PLACE DECIMAL
.015"
THREE PLACE DECIMAL
.005"
ALL BENDS ARE ASSUMED
TO BE 90
UNLESS NOTED
OTHERWISE.
CHECKED BY
DRAWN BY
TMC
DATE
NAME
A
19/07/2016
P42 Vent Free - OD
THE INFORMATION CONTAINED IN THIS DRAWING IS THE SOLE PROPERTY OF CANADIAN HEATING PRODUCTS. ANY REPRODUCTION IN PART OR AS A WHOLE WITHOUT THE WRITTEN PERMISSION OF CANADIAN HEATING PRODUCTS IS PROHIBITED.
PROPRIETARY AND CONFIDENTIAL
Y:\Products\Residential Products\R&D Projects\P42VFO\Cad Drawings\TMC April 2016 Revision with Rick\P42VFO
July-19-16 9:10:47 AM
SCALE
NAME
CHECKED
DRAWN
THIRD ANGLE PROJECTION
DATE
FRACTIONAL
X.XX
X.XXX
ANGULAR:
DIM ARE IN INCHES
UNLESS OTHERWISE SPECIFIED
ALL BENDS ARE 90
1/8
.015
.005
1
5 3/4"
11 1/4"
27 1/4"
ELECTRICAL
14 1/8"
61 1/4"
63 3/4"
67 5/8"
29 1/4"
63 3/4"
65 5/8"
63 3/8"
13 3/8" 13"
4 7/8"
3 1/4"
28 3/8"
GAS
1:16
DWG. NO. REV.
1 OF 1
B
THE INFORMATION CONTAINED IN THIS DRAWING IS THE SOLE PROPERTY OF CANADIAN HEATING PRODUCTS. ANY REPRODUCTION IN PART OR AS A WHOLE WITHOUT THE WRITTEN PERMISSION OF CANADIAN HEATING PRODUCTS IS PROHIBITED.
PROPRIETARY AND CONFIDENTIAL
Tuesday, August 29, 2017 9:04:00 AM
SCALE:
P6016VFONE
P6016VFONE-Overall
SHEET:
SIZE
B
CF 5/16/2017
CF
5/18/2017
60in Cabana Fireplace
Y:\Products\Residential Products\R&D Projects\P6016VONE\CAD Files\P6016VFONE-Overall
NAME
CHECKED
DRAWN
THIRD ANGLE PROJECTION
DATE
FRACTIONAL
X.XX
X.XXX
ANGULAR:
DIM ARE IN INCHES
UNLESS OTHERWISE SPECIFIED
ALL BENDS ARE 90
1/8
.015
.005
1
5 3/4"
11 1/4"
27 1/4"
ELECTRICAL
14 1/8"
61 1/4"
63 3/4"
67 5/8"
29 1/4"
63 3/4"
65 5/8"
63 3/8"
13 3/8" 13"
4 7/8"
3 1/4"
28 3/8"
GAS
1:16
DWG. NO. REV.
1 OF 1
B
THE INFORMATION CONTAINED IN THIS DRAWING IS THE SOLE PROPERTY OF CANADIAN HEATING PRODUCTS. ANY REPRODUCTION IN PART OR AS A WHOLE WITHOUT THE WRITTEN PERMISSION OF CANADIAN HEATING PRODUCTS IS PROHIBITED.
PROPRIETARY AND CONFIDENTIAL
Tuesday, August 29, 2017 9:04:00 AM
SCALE:
P6016VFONE
P6016VFONE-Overall
SHEET:
SIZE
B
CF 5/16/2017
CF
5/18/2017
60in Cabana Fireplace
Y:\Products\Residential Products\R&D Projects\P6016VONE\CAD Files\P6016VFONE-Overall
PL42VO Fireplace Dimensions (Tolerance ±⅛") [3mm]
PL60VO Fireplace Dimensions (Tolerance ±⅛") [3mm]

Page 9
XG0219 - 080421
Installation
8
27
64
"
6
19
64
"
3
53
64
"
4
15
16
"
21
64
"
19
64
"
6
15
16
"
5
33
64
"
3
15
16
"
1
2
"
3
16
" MOUNTING HOLES
USE #8 SCREWS FOR MOUNTING
USE #8 SCREWS
FOR MOUNTING
OVERALL
DIMENSIONS
MOUNTING
DIMENSIONS
Control Box Dimensions
Use #8 screws for
mounting
Use #8 screws for mounting
Mounting
dimentions
Overall
dimentions
Control Box Dimensions (Tolerance ±⅛") [3mm]

Page 10 XG0219 - 080421
Installation
Figure 6
Figure 7 Figure 8
Figure 9
Location Considerations
The fireplace is designed for outdoor use up to a temperature of -40
deg F and may be installed as a standalone unit or built into an outside
wall. It may be installed in covered or screened porches that meet these
minimum requirements:
• For covered porches, a minimum of ONE full side and ONE HALF
side (top portion of the wall) must be open to outside ventilation.
• For screened porches, a minimum of TWO full sides must be
screened with > 75% open area screen.
• Minimum Ceiling Height – 36 inches from the top of the fireplace
opening.
• Minimum Distance to Combustibles in the front – 36 inches from the
screen surface
• Mantle and side wall restrictions- see the finishing section
• Clearance from Grade to fireplace opening- 12 inches (for USA). 0
inches for Canada
If this appliance is installed into a wall, you must:
• Provide access to the gas shutoff valve
• Flash the front perimeter of the appliance in accordance with
regional requirements using exterior caulking or appropriate
materials to prevent the penetration of water around the appliance
into the wall. Considerations must be taken to manage the
water that may penetrate through the appliance to prevent water
accumulation and flooding at the bottom of the fireplace enclosure.
The fireplace enclosure has water drainage holes and must be
installed with proper drainage. Montigo encourages you to consult
your Building Envelope Engineer or Waterproofing Consultant for
further recommendations.
This appliance may be installed on a wood or combustible deck.
Refer to Framing section for framing dimensions and clearances.
Installation MUST comply with local, regional, state and national codes
and regulations. Consult authorities having jurisdiction over restrictions,
installation inspections and permits
With walls on all sides, but at
least one permanent opening at
ground level and no overhead
cover.
A three sided enclosure must
feature 30 percent or more of the
upper area of the enclosure is
permanently open.
Within a partial enclosure which includes an overhead cover and no more
than two sidewalls. These sidewalls may be parallel, as in a breezeway, or
at right angles to each other.

Page 11
XG0219 - 080421
Installation
MAHANA Exploded Part View
SCREEN
WINDOW
BURNER TRAY
BURNER ASSY
FANS
LED ASSY
VACUUM SWITCH
ASSY
VACUUM TUBING
ASSY
MAIN ASSY
1:8
SIZE
DWG. NO.
A
REV.
SHEET 1 OF 2
WEIGHT:
P42VFO
FINISH
MATERIAL
DIMENSIONS ARE IN INCHES
TOLERANCES:
FRACTIONAL
1/32"
TWO PLACE DECIMAL
.015"
THREE PLACE DECIMAL
.005"
ALL BENDS ARE ASSUMED
TO BE 90
UNLESS NOTED
OTHERWISE.
CHECKED BY
DRAWN BY
TMC
DATE
NAME
A
28-Jul-16
P42 Vent Free - OD
THE INFORMATION CONTAINED IN THIS DRAWING IS THE SOLE PROPERTY OF CANADIAN HEATING PRODUCTS. ANY REPRODUCTION IN PART OR AS A WHOLE WITHOUT THE WRITTEN PERMISSION OF CANADIAN HEATING PRODUCTS IS PROHIBITED.
PROPRIETARY AND CONFIDENTIAL
Y:\Products\Residential Products\R&D Projects\PL42VO\Cad Drawings\TMC April 2016 Revision with Rick\P42VFO
November-15-16 9:37:02 AM
SCALE
Tools and Supplies required
Tool List
• Phillips head screwdriver
• Wrenches (5/8”, 1”, and 8mm)
• Voltmeter
• 3/16” Allen key
• 1/4" barb x 1/8” MPT fitting, with corresponding deep socket
• Manometer (to measure gas pressures)
Supply List
• Non-corrosive leak test solution
• Control box mounting screws #8
• Fireplace mounting screws
• 3 Conductor outdoor power cable 18AWG (Live, Neutral, Ground)
(30ft. or as required)
SCREEN
WINDOW
BURNER TRAY
LED ASSEMBLY
MAIN ASSEMBLY
VACUUM SWITCH ASSEMBLYFANS
BURNER ASSEMBLY
The list below is only for guidance, please review the instructions fully before installation.

Page 12 XG0219 - 080421
Installation
Figure 10 Gas and electrical
Electrical RequirementsGas supply requirements
Electrical Cover
Plate
SCREEN
WINDOW
BURNER TRAY
BURNER ASSY
FANS
LED ASSY
VACUUM SWITCH
ASSY
VACUUM TUBING
ASSY
MAIN ASSY
1:8
SIZE
DWG. NO.
A
REV.
SHEET 1 OF 2
WEIGHT:
P42VFO
FINISH
MATERIAL
DIMENSIONS ARE IN INCHES
TOLERANCES:
FRACTIONAL
1/32"
TWO PLACE DECIMAL
.015"
THREE PLACE DECIMAL
.005"
ALL BENDS ARE ASSUMED
TO BE 90
UNLESS NOTED
OTHERWISE.
CHECKED BY
DRAWN BY
TMC
DATE
NAME
A
28-Jul-16
P42 Vent Free - OD
THE INFORMATION CONTAINED IN THIS DRAWING IS THE SOLE PROPERTY OF CANADIAN HEATING PRODUCTS. ANY REPRODUCTION IN PART OR AS A WHOLE WITHOUT THE WRITTEN PERMISSION OF CANADIAN HEATING PRODUCTS IS PROHIBITED.
PROPRIETARY AND CONFIDENTIAL
Y:\Products\Residential Products\R&D Projects\PL42VO\Cad Drawings\TMC April 2016 Revision with Rick\P42VFO
November-15-16 9:37:02 AM
SCALE
Figure 11 Electrical Plate location
Gas Shut off
Valve (supplied)
Remote
Control Box
On/Off Toggle
Switch and fan
speed switch
6 conductor cable 30ft supplied by Montigo
3 conductor outdoor power cable 16AWG
(not supplied)
3 conductor
cable (supplied)
3 conductor
cable
(supplied)
Power Outlet
with GFCI
Gas Line
The fireplace is supplied with a waterproof control box which may be
mounted to an outside wall and a 3 foot powercord. A GFCI protected
plug to plugin the control box is required within 3 feet of the control box.
Electrical Requirement for Control Box: 120VAC, 60 Hz, 5 A. GFCI
protected plug required.
30 foot communication cable is supplied with the fireplace to connect
the control box to the fireplace.
3 conductor (Live, Neutral, and Ground) outdoor rated cable must be
supplied by the installer to provide 120VAC power from the control box
to the Fireplace (see figure below).
The optional Fireplace remote control comes in a separate water tight
box and can be mounted to the outside wall close to the fireplace control
box and needs to be wired to the control box using a 3-conductor
outdoor rated cable (supplied).
Have a certified gas fitter install a gas line that will supply the required
level of gas to the left side of this fireplace with an accessible gas service
shut of valve. (shut off valve supplied)
Montigo requires a service shut off valve be located in an accessible
location to isolate the gas supply.
Only install gas shut-off valves supplied or approved for use by the
state, province, or other governing body in which the fireplace is being
installed.
Flexible gas connectors must not exceed 3 feet in length, unless
allowable within local regulations.
Connect incoming gas line to the 1/2"or 3/8" gas inlet port.
Keep the hose out of pathways where people may trip over it or in areas
where the hose may be subject to accidental damage
Figure 12 Gas connection
GAS PRESSURE
• Optimum appliance
performance requires proper
input pressures.
• Gas line sizing requirements
will be determined in ANSI
Z221.3 National Fuel Gas
Code in the USA and CAN/
CGA B149 in Canada.
Pressure requirements are:
Gas Pressure Natural Gas Propane
Minimum inlet
pressure
5.5in. w.c. 11in. w.c.
Manifold pressure 3.5in. w.c. 10in. w.c.

Page 13
XG0219 - 080421
Installation
MAHANA PL42VO Framing
NOTE: Pre-fabricated stainless
steel enclosure for the PL42VO
is available from Montigo
(Product code: PL42VOBE)
Frame in the enclosure for the
unit with framing materials.
The framed opening for the
assembled fireplace is 42’’
wide, x 27 1/2’’ high.
NOTE: When constructing the
framed opening, please ensure
there is access to install the
gas line and electrical when the
unit is installed.
NOTE: This unit features two
drainage holes on each of the
sides of the unit. Be sure to
plan a drain system for both
in the wall and standalone
installations.
Typical Installation Shown
PL42VO Standalone Installation
PL42VO In The Wall and Corner Installation
4 Screws Top & Bottom
3 Screws Left & Right
DRAINAGE HOLES
(BOTH SIDES)
1:32
SIZE
DWG. NO.
A
REV.
SHEET 3 OF 3
WEIGHT:
P42VFO WALL INSTALLATION
FINISH
MATERIAL
DIMENSIONS ARE IN INCHES
TOLERANCES:
FRACTIONAL
1/32"
TWO PLACE DECIMAL
.015"
THREE PLACE DECIMAL
.005"
ALL BENDS ARE ASSUMED
TO BE 90
UNLESS NOTED
OTHERWISE.
CHECKED BY
DRAWN BY
TMC
DATE
NAME
15-Aug-16
THE INFORMATION CONTAINED IN THIS DRAWING IS THE SOLE PROPERTY OF CANADIAN HEATING PRODUCTS. ANY REPRODUCTION IN PART OR AS A WHOLE WITHOUT THE WRITTEN PERMISSION OF CANADIAN HEATING PRODUCTS IS PROHIBITED.
PROPRIETARY AND CONFIDENTIAL
\\pdm\shared$\Products\Residential Products\R&D Projects\PL42VO\Cad Drawings\MANUAL VIEWS\WALL\P42VFO WALL INSTALLATION
August-15-16 10:47:52 AM
SCALE
Figure 13 In the wall dimensions
27.500
32.500
14.750
42.000
1:36
SIZE
DWG. NO.
A
REV.
SHEET 2 OF 3
WEIGHT:
P42VFO WALL INSTALLATION
FINISH
MATERIAL
DIMENSIONS ARE IN INCHES
TOLERANCES:
FRACTIONAL
1/32"
TWO PLACE DECIMAL
.015"
THREE PLACE DECIMAL
.005"
ALL BENDS ARE ASSUMED
TO BE 90
UNLESS NOTED
OTHERWISE.
CHECKED BY
DRAWN BY
TMC
DATE
NAME
15-Aug-16
THE INFORMATION CONTAINED IN THIS DRAWING IS THE SOLE PROPERTY OF CANADIAN HEATING PRODUCTS. ANY REPRODUCTION IN PART OR AS A WHOLE WITHOUT THE WRITTEN PERMISSION OF CANADIAN HEATING PRODUCTS IS PROHIBITED.
PROPRIETARY AND CONFIDENTIAL
\\pdm\shared$\Products\Residential Products\R&D Projects\PL42VO\Cad Drawings\MANUAL VIEWS\WALL\P42VFO WALL INSTALLATION
August-15-16 10:47:52 AM
SCALE
Figure 14 In the wall dimensions
52"
42 1/2"
15 1/2"
14 3/4"
49"
26 15/16"
42"
7"
Add dimensions to this sheet
Create new sheet with fireplace
attached to framing
Add note to point to screws
Add view to show cut-away for
drainiage holes
1:24
SIZE
DWG. NO.
A
REV.
SHEET 2 OF 3
WEIGHT:
FRAME
FINISH
MATERIAL
DIMENSIONS ARE IN INCHES
TOLERANCES:
FRACTIONAL
1/32"
TWO PLACE DECIMAL
.015"
THREE PLACE DECIMAL
.005"
ALL BENDS ARE ASSUMED
TO BE 90
UNLESS NOTED
OTHERWISE.
CHECKED BY
DRAWN BY
DATE
NAME
15-Aug-16
THE INFORMATION CONTAINED IN THIS DRAWING IS THE SOLE PROPERTY OF CANADIAN HEATING PRODUCTS. ANY REPRODUCTION IN PART OR AS A WHOLE WITHOUT THE WRITTEN PERMISSION OF CANADIAN HEATING PRODUCTS IS PROHIBITED.
PROPRIETARY AND CONFIDENTIAL
\\pdm\shared$\Products\Residential Products\R&D Projects\PL42VO\Cad Drawings\MANUAL VIEWS\STAND ALONE\FRAME
August-15-16 2:16:02 PM
SCALE
Figure 15 Front
52"
42 1/2"
15 1/2"
14 3/4"
49"
26 15/16"
42"
7"
Add dimensions to this sheet
Create new sheet with fireplace
attached to framing
Add note to point to screws
Add view to show cut-away for
drainiage holes
1:24
SIZE
DWG. NO.
A
REV.
SHEET 2 OF 3
WEIGHT:
FRAME
FINISH
MATERIAL
DIMENSIONS ARE IN INCHES
TOLERANCES:
FRACTIONAL
1/32"
TWO PLACE DECIMAL
.015"
THREE PLACE DECIMAL
.005"
ALL BENDS ARE ASSUMED
TO BE 90
UNLESS NOTED
OTHERWISE.
CHECKED BY
DRAWN BY
DATE
NAME
15-Aug-16
THE INFORMATION CONTAINED IN THIS DRAWING IS THE SOLE PROPERTY OF CANADIAN HEATING PRODUCTS. ANY REPRODUCTION IN PART OR AS A WHOLE WITHOUT THE WRITTEN PERMISSION OF CANADIAN HEATING PRODUCTS IS PROHIBITED.
PROPRIETARY AND CONFIDENTIAL
\\pdm\shared$\Products\Residential Products\R&D Projects\PL42VO\Cad Drawings\MANUAL VIEWS\STAND ALONE\FRAME
August-15-16 2:16:02 PM
SCALE
Figure 16 Back
52"
42 1/2"
15 1/2"
14 3/4"
49"
26 15/16"
42"
7"
Add dimensions to this sheet
Create new sheet with fireplace
attached to framing
Add note to point to screws
Add view to show cut-away for
drainiage holes
1:24
SIZE
DWG. NO.
A
REV.
SHEET 2 OF 3
WEIGHT:
FRAME
FINISH
MATERIAL
DIMENSIONS ARE IN INCHES
TOLERANCES:
FRACTIONAL
1/32"
TWO PLACE DECIMAL
.015"
THREE PLACE DECIMAL
.005"
ALL BENDS ARE ASSUMED
TO BE 90
UNLESS NOTED
OTHERWISE.
CHECKED BY
DRAWN BY
DATE
NAME
15-Aug-16
THE INFORMATION CONTAINED IN THIS DRAWING IS THE SOLE PROPERTY OF CANADIAN HEATING PRODUCTS. ANY REPRODUCTION IN PART OR AS A WHOLE WITHOUT THE WRITTEN PERMISSION OF CANADIAN HEATING PRODUCTS IS PROHIBITED.
PROPRIETARY AND CONFIDENTIAL
\\pdm\shared$\Products\Residential Products\R&D Projects\PL42VO\Cad Drawings\MANUAL VIEWS\STAND ALONE\FRAME
August-15-16 2:16:02 PM
SCALE
Figure 17 Standalone Dimensions
A
A
4 Screws Top & Bottom
3 Screws Left & Right
SECTION A-A
1:14
SIZE
DWG. NO.
A
REV.
SHEET 3 OF 3
WEIGHT:
STAND ALONE
FINISH
MATERIAL
DIMENSIONS ARE IN INCHES
TOLERANCES:
FRACTIONAL
1/32"
TWO PLACE DECIMAL
.015"
THREE PLACE DECIMAL
.005"
ALL BENDS ARE ASSUMED
TO BE 90
UNLESS NOTED
OTHERWISE.
CHECKED BY
DRAWN BY
TMC
DATE
NAME
15-Aug-16
THE INFORMATION CONTAINED IN THIS DRAWING IS THE SOLE PROPERTY OF CANADIAN HEATING PRODUCTS. ANY REPRODUCTION IN PART OR AS A WHOLE WITHOUT THE WRITTEN PERMISSION OF CANADIAN HEATING PRODUCTS IS PROHIBITED.
PROPRIETARY AND CONFIDENTIAL
\\pdm\shared$\Products\Residential Products\R&D Projects\PL42VO\Cad Drawings\MANUAL VIEWS\STAND ALONE\STAND ALONE
August-15-16 2:16:01 PM
SCALE
Figure 18 Standalone Dimensions
*12" minimum above grade is
required for US installations
*
DRAINAGE HOLES
(BOTH SIDES)
4 SCREWS TOP & BOTTOM
3 SCREWS LEFT & RIGHT
4 SCREWS TOP & BOTTOM
3 SCREWS LEFT & RIGHT
62 7/16"
42 7/8"
NAME
CHECKED
DRAWN
THIRD ANGLE PROJECTION
DATE
FRACTIONAL
X.XX
X.XXX
ANGULAR:
DIM ARE IN INCHES
UNLESS OTHERWISE SPECIFIED
ALL BENDS ARE 90
1/8
.015
.005
1
48 1/8"
ZERO CLEARANCE
AT CORNERS ONLY
1:16
DWG. NO. REV.
1 OF 1
C
THE INFORMATION CONTAINED IN THIS DRAWING IS THE SOLE PROPERTY OF CANADIAN HEATING PRODUCTS. ANY REPRODUCTION IN PART OR AS A WHOLE WITHOUT THE WRITTEN PERMISSION OF CANADIAN HEATING PRODUCTS IS PROHIBITED.
PROPRIETARY AND CONFIDENTIAL
Monday, September 18, 2017 11:44:35 AM
SCALE:
42in CABANA, VENT FREE, OUTDOOR
P42VFO
SHEET:
SIZE
C
CANADIAN HEATING
PRODUCTS
27342 GLOUCESTER WAY,
LANGLEY, BC, V4W 4A1
CF 7/18/2016
CF
9/18/2017
PL42VO
Y:\Products\Residential Products\R&D Projects\PL42VO\Cad Drawings\MANUAL VIEWS\P42VFO CORNER
Figure 19 Corner dimensions

Page 14 XG0219 - 080421
Installation
MAHANA PL60VO Framing
Frame in the enclosure for the
unit with framing materials.
The framed opening for the
assembled fireplace is 66’’
wide, x 27 7/8’’ high.
NOTE: When constructing the
framed opening, please ensure
there is access to install the
gas line and electrical when the
unit is installed.
NOTE: This unit features two
drainage holes on each of the
sides of the unit. Be sure to
plan a drain system for both
in the wall and standalone
installations.
Typical Installation Shown
PL60VO Standalone Installation
PL60VO In The Wall and Corner Installation
NAME
CHECKED
DRAWN
THIRD ANGLE PROJECTION
DATE
FRACTIONAL
X.XX
X.XXX
ANGULAR:
DIM ARE IN INCHES
UNLESS OTHERWISE SPECIFIED
ALL BENDS ARE 90
1/8
.015
.005
1
4 SCREWS TOP & BOTTOM
DRAINAGE HOLES
(BOTH SIDES)
3 SCREWS LEFT & RIGHT
1:32
DWG. NO. REV.
3 OF 3
A
THE INFORMATION CONTAINED IN THIS DRAWING IS THE SOLE PROPERTY OF CANADIAN HEATING PRODUCTS. ANY REPRODUCTION IN PART OR AS A WHOLE WITHOUT THE WRITTEN PERMISSION OF CANADIAN HEATING PRODUCTS IS PROHIBITED.
PROPRIETARY AND CONFIDENTIAL
Tuesday, January 23, 2018 11:42:45 AM
SCALE:
Wall Installation
P6016VFONE WALL INSTALLATION
SHEET:
SIZE
A
CANADIAN HEATING
PRODUCTS
27342 GLOUCESTER WAY,
LANGLEY, BC, V4W 4A1
CF 7/19/2016
CF
8/31/2017
60in CABANA
Y:\Products\Residential Products\R&D Projects\P6016VONE\CAD Files\Manual Drawings\ P6016VFONE WALL INSTALLATION
Figure 20 In the wall dimensions
NAME
CHECKED
DRAWN
THIRD ANGLE PROJECTION
DATE
FRACTIONAL
X.XX
X.XXX
ANGULAR:
DIM ARE IN INCHES
UNLESS OTHERWISE SPECIFIED
ALL BENDS ARE 90
1/8
.015
.005
1
66.000
27.880
32.880
14.750
14.750
1:32
DWG. NO. REV.
2 OF 3
A
THE INFORMATION CONTAINED IN THIS DRAWING IS THE SOLE PROPERTY OF CANADIAN HEATING PRODUCTS. ANY REPRODUCTION IN PART OR AS A WHOLE WITHOUT THE WRITTEN PERMISSION OF CANADIAN HEATING PRODUCTS IS PROHIBITED.
PROPRIETARY AND CONFIDENTIAL
Tuesday, January 23, 2018 11:42:45 AM
SCALE:
Wall Installation
P6016VFONE WALL INSTALLATION
SHEET:
SIZE
A
CANADIAN HEATING
PRODUCTS
27342 GLOUCESTER WAY,
LANGLEY, BC, V4W 4A1
CF 7/19/2016
CF
8/31/2017
60in CABANA
Y:\Products\Residential Products\R&D Projects\P6016VONE\CAD Files\Manual Drawings\ P6016VFONE WALL INSTALLATION
Figure 21 In the wall dimensions
NAME
CHECKED
DRAWN
THIRD ANGLE PROJECTION
DATE
FRACTIONAL
X.XX
X.XXX
ANGULAR:
DIM ARE IN INCHES
UNLESS OTHERWISE SPECIFIED
ALL BENDS ARE 90
1/8
.015
.005
1
14 3/4"
76"
16" 16" 16"
42 1/2"
66"
26 15/16"
7"
73"
1:24
DWG. NO.
REV.
2 OF 3
THE INFORMATION CONTAINED IN THIS DRAWING IS THE SOLE PROPERTY OF CANADIAN HEATING PRODUCTS. ANY REPRODUCTION IN PART OR AS A WHOLE WITHOUT THE WRITTEN PERMISSION OF CANADIAN HEATING PRODUCTS IS PROHIBITED.
PROPRIETARY AND CONFIDENTIAL
Monday, September 18, 2017 3:50:32 PM
SCALE:
FRAME60
SHEET:
SIZE
CANADIAN HEATING
PRODUCTS
27342 GLOUCESTER WAY,
LANGLEY, BC, V4W 4A1
CF 7/19/2016
CF
9/18/2017
Y:\Products\Residential Products\R&D Projects\P6016VONE\CAD Files\Manual Drawings\ STAND ALONE 60
Figure 22 Front
NAME
CHECKED
DRAWN
THIRD ANGLE PROJECTION
DATE
FRACTIONAL
X.XX
X.XXX
ANGULAR:
DIM ARE IN INCHES
UNLESS OTHERWISE SPECIFIED
ALL BENDS ARE 90
1/8
.015
.005
1
14 3/4"
76"
16" 16" 16"
42 1/2"
66"
26 15/16"
7"
73"
1:24
DWG. NO.
REV.
2 OF 3
THE INFORMATION CONTAINED IN THIS DRAWING IS THE SOLE PROPERTY OF CANADIAN HEATING PRODUCTS. ANY REPRODUCTION IN PART OR AS A WHOLE WITHOUT THE WRITTEN PERMISSION OF CANADIAN HEATING PRODUCTS IS PROHIBITED.
PROPRIETARY AND CONFIDENTIAL
Monday, September 18, 2017 3:50:32 PM
SCALE:
FRAME60
SHEET:
SIZE
CANADIAN HEATING
PRODUCTS
27342 GLOUCESTER WAY,
LANGLEY, BC, V4W 4A1
CF 7/19/2016
CF
9/18/2017
Y:\Products\Residential Products\R&D Projects\P6016VONE\CAD Files\Manual Drawings\ STAND ALONE 60
Figure 23 Back
NAME
CHECKED
DRAWN
THIRD ANGLE PROJECTION
DATE
FRACTIONAL
X.XX
X.XXX
ANGULAR:
DIM ARE IN INCHES
UNLESS OTHERWISE SPECIFIED
ALL BENDS ARE 90
1/8
.015
.005
1
14 3/4"
76"
16" 16" 16"
42 1/2"
66"
26 15/16"
7"
73"
1:24
DWG. NO. REV.
2 OF 3
THE INFORMATION CONTAINED IN THIS DRAWING IS THE SOLE PROPERTY OF CANADIAN HEATING PRODUCTS. ANY REPRODUCTION IN PART OR AS A WHOLE WITHOUT THE WRITTEN PERMISSION OF CANADIAN HEATING PRODUCTS IS PROHIBITED.
PROPRIETARY AND CONFIDENTIAL
Monday, September 18, 2017 3:50:32 PM
SCALE:
FRAME60
SHEET:
SIZE
CANADIAN HEATING
PRODUCTS
27342 GLOUCESTER WAY,
LANGLEY, BC, V4W 4A1
CF 7/19/2016
CF
9/18/2017
Y:\Products\Residential Products\R&D Projects\P6016VONE\CAD Files\Manual Drawings\ STAND ALONE 60
Figure 24 Standalone Dimensions
NAME
CHECKED
DRAWN
THIRD ANGLE PROJECTION
DATE
FRACTIONAL
X.XX
X.XXX
ANGULAR:
DIM ARE IN INCHES
UNLESS OTHERWISE SPECIFIED
ALL BENDS ARE 90
1/8
.015
.005
1
A
A
4 Screws Top & Bottom
3 Screws Left & Right
SECTION A-A
1:20
DWG. NO. REV.
3 OF 3
THE INFORMATION CONTAINED IN THIS DRAWING IS THE SOLE PROPERTY OF CANADIAN HEATING PRODUCTS. ANY REPRODUCTION IN PART OR AS A WHOLE WITHOUT THE WRITTEN PERMISSION OF CANADIAN HEATING PRODUCTS IS PROHIBITED.
PROPRIETARY AND CONFIDENTIAL
Monday, September 18, 2017 3:44:08 PM
SCALE:
STAND ALONE 60SLDASM
SHEET:
SIZE
CANADIAN HEATING
PRODUCTS
27342 GLOUCESTER WAY,
LANGLEY, BC, V4W 4A1
CF 7/19/2016
CF
9/18/2017
Y:\Products\Residential Products\R&D Projects\P6016VONE\CAD Files\Manual Drawings\ STAND ALONE 60
Figure 25 Standalone Dimensions
*12" minimum above grade is
required for US installations
*
DRAINAGE HOLES
(BOTH SIDES)
4 SCREWS TOP & BOTTOM3 SCREWS LEFT & RIGHT
4 SCREWS TOP & BOTTOM
3 SCREWS LEFT & RIGHT
87"
66 15/16"
65 1/2"
NAME
CHECKED
DRAWN
THIRD ANGLE PROJECTION
DATE
FRACTIONAL
X.XX
X.XXX
ANGULAR:
DIM ARE IN INCHES
UNLESS OTHERWISE SPECIFIED
ALL BENDS ARE 90
1/8
.015
.005
1
ZERO CLEARANCE
AT CORNERS ONLY
1:16
DWG. NO. REV.
1 OF 1
B
THE INFORMATION CONTAINED IN THIS DRAWING IS THE SOLE PROPERTY OF CANADIAN HEATING PRODUCTS. ANY REPRODUCTION IN PART OR AS A WHOLE WITHOUT THE WRITTEN PERMISSION OF CANADIAN HEATING PRODUCTS IS PROHIBITED.
PROPRIETARY AND CONFIDENTIAL
Wednesday, November 15, 2017 12:56:34 PM
SCALE:
P6016VFONE
P6016VFONE
SHEET:
SIZE
B
CANADIAN HEATING
PRODUCTS
27342 GLOUCESTER WAY,
LANGLEY, BC, V4W 4A1
CF 7/18/2016
CF
9/18/2017
PL60
Y:\Products\Residential Products\R&D Projects\P6016VONE\CAD Files\Manual Drawings\ P6016VFONE CORNER

Page 15
XG0219 - 080421
Installation
Combustible mantels and mouldings may be safely installed over the top
and on the front of the fireplace provided that they do not project beyond
shaded area shown.
Mantels & Surrounds
Clearances
NOTE: National Canadian Gas Association mantel test requirements are
for fire hazard prevention to combustible materials.
Please be aware; temperatures over the mantel will rise above normal
room temperature and walls above fireplace may be hot to touch.
Side wall clearances are 6" as shown.
45°
6"
152
6"
152
Window Opening
Allowable Sidewall Clearances
Wall Board
Not Alowable
Sidewall
Allowable
Area
Figure 26 Sidewall Clearance
Clearance Specifications
• Full combustible construction allowed including combustible facing
material
• 6” minimum clearance to perpendicular wall
• Minimum clearance to ceiling (from fireplace opening): 36”
• Distance to combustible material in front: 36”
not allowable
We recommend careful consideration be given to the effects of
elevated mantel temperatures which may be in excess of product
design, for example; candles, plastic or pictures. This can cause
melting, deformation, discolouration or premature failure of T.V. radio,
and other electronic components.
CAUTION
Wall board
Window opening
Sidewall
allowable
area
Not allowable
123456789101112
1
5
11
15
2
6
12
16
3
9
7
13
17
4
10
8
14
Vertical Height (In.)
Horizontal Run (In.)
Combustible header
Figure 21.a Combustible mantles and facings. (Not to scale)
Combustible facing material
Combustible construction
allowed in shaded area
Combustible facing material

Page 16 XG0219 - 080421
Installation
Finishing
Standalone
12" MIN
FRAMING
FINISHING MATERIAL
WALL BOARD
P42VFO
FLOORING
Extend vertical beams of wood to show that its a wall
Change to wood instead of marble
Separate drawing for framing with dimensions for the opening, depth also
Add sheet to show dimensions of framing only
Another sheet view with just the fireplace in the framing pointing out the holes for screwing to wood
1:17
SIZE
DWG. NO.
A
REV.
SHEET 1 OF 3
WEIGHT:
P42VFO WALL INSTALLATION
FINISH
MATERIAL
DIMENSIONS ARE IN INCHES
TOLERANCES:
FRACTIONAL
1/32"
TWO PLACE DECIMAL
.015"
THREE PLACE DECIMAL
.005"
ALL BENDS ARE ASSUMED
TO BE 90
UNLESS NOTED
OTHERWISE.
CHECKED BY
DRAWN BY
TMC
DATE
NAME
15-Aug-16
THE INFORMATION CONTAINED IN THIS DRAWING IS THE SOLE PROPERTY OF CANADIAN HEATING PRODUCTS. ANY REPRODUCTION IN PART OR AS A WHOLE WITHOUT THE WRITTEN PERMISSION OF CANADIAN HEATING PRODUCTS IS PROHIBITED.
PROPRIETARY AND CONFIDENTIAL
\\pdm\shared$\Products\Residential Products\R&D Projects\PL42VO\Cad Drawings\MANUAL VIEWS\WALL\P42VFO WALL INSTALLATION
August-15-16 10:47:52 AM
SCALE
Figure 27 In the wall nishing
FRAMING
P42VFO
WALL BOARD/FINISHING MTL
12"
MIN
DRAINAGE HOLES
(BOTH SIDES)
1:18
SIZE
DWG. NO.
A
REV.
SHEET 1 OF 3
WEIGHT:
STAND ALONE
FINISH
MATERIAL
DIMENSIONS ARE IN INCHES
TOLERANCES:
FRACTIONAL
1/32"
TWO PLACE DECIMAL
.015"
THREE PLACE DECIMAL
.005"
ALL BENDS ARE ASSUMED
TO BE 90
UNLESS NOTED
OTHERWISE.
CHECKED BY
DRAWN BY
TMC
DATE
NAME
15-Aug-16
THE INFORMATION CONTAINED IN THIS DRAWING IS THE SOLE PROPERTY OF CANADIAN HEATING PRODUCTS. ANY REPRODUCTION IN PART OR AS A WHOLE WITHOUT THE WRITTEN PERMISSION OF CANADIAN HEATING PRODUCTS IS PROHIBITED.
PROPRIETARY AND CONFIDENTIAL
\\pdm\shared$\Products\Residential Products\R&D Projects\PL42VO\Cad Drawings\MANUAL VIEWS\STAND ALONE\STAND ALONE
August-15-16 2:16:01 PM
SCALE
Figure 28 Standalone Finishing
In The Wall Installation
Fireplace Facing
When sizing the finish material
for your fireplace, it is important
to remember the following:
THE OPENING MUST NOT BE
OBSTRUCTED IN ANY WAY - to
do so restricts the air supply for
the control compartments and
heat exchanger it also prevents
access for servicing controls.
Decorative facing must not
extend past the fireplace
opening, because it will interfere
with the access to retainers
for removal of glass door and
restrict airflow into the unit.
*12" minimum above grade is for
US installations only
*
*
Framing
Framing
Fireplace
Fireplace
Flooring
Drainage holes
(both sides)
Wall board/Finishing material
Finishing material
Wall board

Page 17
XG0219 - 080421
Installation
Figure 29 Control box mounting
Control Box Install
Installations in Canada must be electrically grounded in accordance
with CSA C22.1 Canadian Electrical Code Part 1 and/or Local Codes.
Installations in the USA must be electrically grounded in accordance
with local codes or, in the absence of local codes, with the National
Electrical Code, ANSI/NFPA 70.
Note: If any of the original wire supplied with the appliance is replaced,
it must be with the same it's equivalent.
Connect a 3-Conductor outdoor rated cable from the control box wire
marked "to blowers in fireplace" to the 3 wires on the right side of the
fireplace.
The control box must be mounted in the orientation shown above with
the wires descending from the bottom to minimize the potential for
water ingress.
Wiring
A qualified electrician must install the wiring. The unit is supplied
with an external electrical control box pre-wired by the factory. The
control box is connected to the fireplace with a control cable that will
communicate with the fireplace. The control box should be located
where it can be accessed when the fireplace has been finished in.
USE #8
SCREWS FOR
MOUNTING
Figure 30 Wires to Blowers
Ensure the wires are properly isolated from metal parts or control
system will be damaged.
CAUTION
Use #8 screws for
mounting
Use #8 screws for
mounting
Mounting the Fireplace Control Box
Install the Fireplace Control Box in an accessible location within 3' of
the fireplace. The location should be where maintenance, adjustments
and service may be made easily.
Mount the control box with 4 #8 screws (not supplied) and seal with
an outdoor rated sealant.

Page 18 XG0219 - 080421
Installation
(3 IN PL60VO UNITS)
Wiring Connection
LED
PWR
SUPPLY LED
CONTROLLER
Plug
110V 24V
Multiple
Connection
Options
120VAC
3 foot
Power Cord
Fireplace
Brown
White
Fast/Slow
SW
On/Off
SW
M
Flue Gas
SW
Combustion
SW
Gas Valve LED Lighting
Control Box
24VDC
White
Black
Green
White
Black
Red
Red
Black
Black +RGB
Speed
control
Red
Fireplace Blowers
M
Blue
Brown
+-
White
Stripe
Black
Red
Green
Blue
Tie together Red
and Black
for use
without a remote
PWR
White
Black
Red
Red
Red
White
Black
Red
With Optional Remote
Without Remote
Remote
Black
Off
Remote
On
Yellow
White
Yellow
to control box
to flue switch
Gas Valve
Figure 34 Wiring schematic

Page 19
XG0219 - 080421
Installation
6 37
64
"
4 15
16
"
3 15
64
"
USE #8
SCREWS FOR
MOUNTING
2 19
32
"
4 1
4
"
OVERALL
DIMENSIONS
MOUNTING
DIMENSIONS
(SHOWN w/o RECEIVER)
Use #8 screws
for mounting
MOUNTING
DIMENSIONS
(Shown w/o receiver)
1� Attach the remote control box within 3 feet of main control box� (the
remote receiver is attached with velcro and may have to be removed
to access mounting screw slots�
Wiring Instructions
(remote box to main control box)
A qualied electrician must install the remote control system.
Turn off all power and gas to replace.
This remote control system must be installed exactly as outlined in
these instructions. Read all instructions completely before attempting
installation. Follow instructions carefully during installation. Any
modications of this remote control or any of its components will void
the warranty and may pose a re hazard.
WARNING
ITEM No. PART No. DESCRIPTION QTY. REV.
1 EC1458 JUNCTION BOX 9100 NO TERM 125x167x82mm 1
2
HW2212 VELCRO, 1"x2.75" MATED HOOK/LOOP 1
3
RX5010-
RECEIVER
ON/OFF 110V RECEIVER FOR TOUCHSCREEN REMOTE 1
4
EC1462 NYLON STRAIN RELIEF CONNECTOR, 1/2" 1
1:2
SIZE
DWG. NO.
A
REV.
SHEET 1 OF 3
WEIGHT:
FINISH
MATERIAL
DIMENSIONS ARE IN INCHES
TOLERANCES:
FRACTIONAL
1/32"
TWO PLACE DECIMAL
.015"
THREE PLACE DECIMAL
.005"
ALL BENDS ARE ASSUMED
TO BE 90
UNLESS NOTED
OTHERWISE.
CHECKED BY
DRAWN BY
DATE
NAME
18/08/2016
THE INFORMATION CONTAINED IN THIS DRAWING IS THE SOLE PROPERTY OF CANADIAN HEATING PRODUCTS. ANY REPRODUCTION IN PART OR AS A WHOLE WITHOUT THE WRITTEN PERMISSION OF CANADIAN HEATING PRODUCTS IS PROHIBITED.
PROPRIETARY AND CONFIDENTIAL
August-18-16 11:16:59 AM
SCALE
P42 REMOTE CONTROL
ELECTRICAL BOX
ECA102
2� Locate the wire running from the remote receiver and remove the wire
nuts at the ends of the wires�
3� Feed the wire into the control box side�
4� Connect the wires shown above from the remote receiver to the wires
from the control box� Black to black, red to red, and white to white�
Loosen relief connector nuts before
feeding wire through
5� After the wires are connected, tighten the strain relief connector nuts�

Page 20 XG0219 - 080421
Installation
LED Remote Receiver Installation (Optional Accessory)
This remote control system must be installed exactly as outlined
in these instructions. Read all instructions completely before
attempting installation. Follow instructions carefully during
installation. Any modifications of this remote control or any of its
components will void the warranty and may pose a fire hazard.
WARNING
Wiring Instructions
A qualified electrician must install the remote control system.
Turn off all power and gas to fireplace.
1. The remote receiver is installed in the main control box. To start,
remove the wire nut from the wire feeding into the control box.
2. Place a Velcro strip (provided) on the bottom of the control box to
fasten the receiver in place, with the other strip on the bottom of the
receiver. Then place the receiver into the box.
3. Connect the white power connector from the LED receiver to the
connector from the control box.
4. Connect the wires from the remote receiver to their respective
terminals in the LED receiver (BK-Black R-Red G-Green BL-Blue)
Figure 43 Removal of wire nut Figure 44 Removal of wire nut
Figure 45 Attaching the receiver Figure 46 Attaching the receiver
Figure 47 Connecting the LED receiver
Figure 48 Wiring the LED receiver
