Montigo H38DF-CLCR Instruction Manual

®
C US
Read and understand this manual. Improper installation, adjustment, alteration,
service or maintenance can cause serious injury, property damage or even death.
For assistance or additional information consult a qualified installer, service
agency or the gas supplier.
DANGER
Glass doors on gas fireplaces are extremely hot while the fireplace is on and
remain hot even after the fireplace has been turned off. Safety screens are
available and can reduce the risks of severe burns. Please keep children away
from the fireplace at all times.
CAUTION
Installation & Maintenance Manual
Do not store or use gasoline or any other flammable vapors and liquids in the vicinity of
this or any other gas burning appliance. A fire or explosion my occur causing serious
injury, property damage or even death.
WARNING
Installer: Leave this manual with the appliance. Do not remove.
Consumer: Retain this manual for maintenance and future reference. Do not Discard.
NOTICE
IF YOU SMELL GAS
Do not try to light any appliance.
Do not touch any electrical switch; do not use any phone in your building.
Immediately call your gas supplier from a neighbor's phone. Follow the gas
supplier's instructions.
If you cannot reach your gas supplier, call the fire department.
DANGER
Irritant
Cutting
Watch your step
Slippery floor
High temperatures
Glass hazard
Danger of suffocation
High voltage
Toxic
Flammable materials
Corrosive
Fork lift trucks
Danger overhead crane
Explosion risk
Oxidising
Danger of death
Biohazard
Laser Radiation
Danger of entrapment
Hot surface
General Warning
Blank
Gas bottles
Watch for
falling objects
Electricity
Danger for cutter
Entrapment hazard
Battery hazard
Rotating parts
Low temperature
Strong magnetic field
Optical radiation
Non ionizing
radiation
Radiation
Hazardous to the
Environment
Danger of harming
your hands
Irritant
Cutting
Watch your step
Slippery floor
High temperatures
Glass hazard
Danger of suffocation
High voltage
Toxic
Flammable materials
Corrosive
Fork lift trucks
Danger overhead crane
Explosion risk
Oxidising
Danger of death
Biohazard
Laser Radiation
Danger of entrapment
Hot surface
General Warning
Blank
Gas bottles
Watch for
falling objects
Electricity
Danger for cutter
Entrapment hazard
Battery hazard
Rotating parts
Low temperature
Strong magnetic field
Optical radiation
Non ionizing
radiation
Radiation
Hazardous to the
Environment
Danger of harming
your hands
Irritant
Cutting
Watch your step
Slippery floor
High temperatures
Glass hazard
Danger of suffocation
High voltage
Toxic
Flammable materials
Corrosive
Fork lift trucks
Danger overhead crane
Explosion risk
Oxidising
Danger of death
Biohazard
Laser Radiation
Danger of entrapment
Hot surface
General Warning
Blank
Gas bottles
Watch for
falling objects
Electricity
Danger for cutter
Entrapment hazard
Battery hazard
Rotating parts
Low temperature
Strong magnetic field
Optical radiation
Non ionizing
radiation
Radiation
Hazardous to the
Environment
Danger of harming
your hands
Irritant
Cutting
Watch your step
Slippery floor
High temperatures
Glass hazard
Danger of suffocation
High voltage
Toxic
Flammable materials
Corrosive
Fork lift trucks
Danger overhead crane
Explosion risk
Oxidising
Danger of death
Biohazard
Laser Radiation
Danger of entrapment
Hot surface
General Warning
Blank
Gas bottles
Watch for
falling objects
Electricity
Danger for cutter
Entrapment hazard
Battery hazard
Rotating parts
XG0213 040512.1
H38DF-CLCR
HL38DF-CLCR
HP38DF-CLCR
Indoor
Corner Unit
Resi
dential
Gas Fireplace
Langley, BC V4W 4A1 |  Ferndale, WA 98248


You must read and understand this manual prior to installation, operation or
troubleshooting this appliance. Please retain this owner’s manual for furure reference
and maintenance.
NOTICE
Table of Contents

XG0213 - 040512.1
INTRODUCTION .................................................................................3
BEFORE YOU START: .......................................................................4
Section A: Before You Begin .............................................................4
Section 1: Installation Overview and Product Dimensions ..............5
Section 2: Framing the Fireplace .......................................................6
Clearances .................................................................................7
Installing the Standoffs .......................................................................7
Installing the Nailing Flange Extension ...............................................7
Section 3: The Direct Vent System .............................................8 - 16
Converting from Top Vent to Rear Vent ..............................................8
Installing a Roof mounted Termination ........................................9 - 10
Venting Layout ................................................................................9
Roof mounted Terminations .......................................................9
Standard Top Vent (no elbows or offsets) ..................................9
Top Vent (two elbows one offset) ...............................................9
Top Vent (multi-elbows and offsets) ...........................................9
Standard Roof Vent (one elbows no offsets) ...........................10
Roof Mounted Termination Venting Components .........................10
Installing a Wall mounted Termination .............................................. 11
▪ Standard PTO Installation ..........................................................11
▪ Pre-installed MSR Frame ..........................................................11
▪ Pre-installed BSR Frame ........................................................... 11
▪ Installing MOSR Frame .............................................................11
▪ Installing VSS Termination Shield .............................................. 11
▪ Installing PTKOG Heat Guard ...................................................11
Venting Layout ........................................................................12 - 14
▪ Top Vent, Wall mounted Graph ..................................................12
▪ Top Vent, Wall mounted HP38C* Graph ...................................12
▪ Top Vent, Wall mounted termination (one elbow) ......................12
▪ Top Vent, Wall mounted termination HP38C*(one elbow) .........12
▪ Top Vent, Wall mounted termination (multi elbow) .....................13
▪ Top Vent, Wall mounted termination HP38C* (multi elbow) .......13
▪ Rear Vent, Wall mounted Graph, H*38C* ..................................14
▪ Rear Vent, Wall mounted Graph, HP38C* .................................14
Wall Mounted Termination Venting Components ..........................15
Heat Shields ...............................................................................16
▪ Installing a RHS102 Wall Mounted Heat Shield ....................16
▪ Installing a RHS101 Wall Mounted Heat Shield ....................16
Section 4: Wiring .............................................................................17
▪ SIT - IPI gas control and pilot ................................................17
▪ Installing the remote On/Off Wall switch ...............................17
▪ Honeywell gas control and pilot ............................................17
Section 5: Installing the Gas Line ....................................................18
Fuel Conversion ...............................................................................18
Gas Pressure ...............................................................................18
Gas Connection ...............................................................................18
Section 6: Finishing ..........................................................................19
Mantels & Surrounds ........................................................................19
Section 7: Installing & Removing the Door ......................................20
Section 8: Installing the Accessories .........................................21 - 23
Installing the Logset ..........................................................................21
Installing the HP38C* Logset ............................................................22
Installing Firestones in N.G. (Natural Gas) Fireplaces .....................23
Installing Firestones in L.P. (Propane) Fireplaces ...........................23
Section 9: Operation .................................................................24 - 26
▪ Start-up Sequence with Standing (Continuous) Pilot .................24
▪ Start-up Sequence SIT-Proame Electronic Ignition ................26
▪ Start-up Sequence with Honeywell Electronic Ignition .............25
Maintenance: ........................................................................27 - 28
▪ General ...............................................................................27
▪ Cleaning ...............................................................................27
▪ Hi-Lo Burner Adjustment ............................................................27
▪ Pilot Burner Adjustment .............................................................27
▪ Troubleshooting .........................................................................28
▪ Replacement Parts List ..............................................................28
Appendix: ........................................................................29 - 31
A. Power Vent Locations ...................................................................29
B. Warranty ...............................................................................30
C. State of Massachusetts ................................................................31


Indicates a hazardous situation which, if not
avoided, WILL result in death or serious
injury or property damage.
Indicates a hazardous situation which, if not
avoided, COULD result in death or serious
injury or property damage.
Indicates a hazardous situation which, if not
avoided, WILL result in minor or moderate
injury.
Address practices that are important, but
not related to personal injury
DANGER WARNING
CAUTION NOTICE

Safety Alert Key
Introduction
XG0213 - 040512.1
INTRODUCTION
Congratulations on your purchase of a .
With over 30 years of experience, Montigo is committed to providing you
with a gas replace that is not only a beautiful addition to your space, but
that is also designed and manufactured to the highest safety, reliability and
engineering standards.
We strongly encourage you to read and carefully follow the instructions laid
out in this Installation, Operation and Maintenance Manual and retain it for
your future reference. Pay special attention to all cautions, warnings, and
notices throughout this manual intended to ensure your safety.
This manual covers installation, operation and maintenance. Lighting, operation
and care of this replace can be easily performed by the homeowner. All
installation and service work should be performed by a qualied or licensed
installer, plumber or gas tter as certied by the state, province, region or
governing body where the replace is being installed.
This installation, operation and maintenance manual is applicable to the
models described below. Refer to your rating plate to verify included options.
Throughout this manual instructions are applicable to all models designated
as  unless otherwise noted in the Table.

The Montigo warranty will be voided by, and Montigo disclaims any responsibility
for, the following actions:
► Modication of the replace and/or components including Direct-
Vent assembly or glass doors.
► Use of any component part not manufactured or approved by
Montigo in combination with this Montigo replace system.
► Installation other than as instructed in this manual.
Consult your local Gas Inspection Branch on installation requirements for
factory-built gas replaces. Installation & repairs should be done by a qualied
contractor.
 
Hot glass will cause
burns. Do not touch
glass until unit is cooled.
Never allow children to
touch glass.
Irritant
Cutting
Watch your step
Slippery floor
High temperatures
Glass hazard
Danger of suffocation
High voltage
Toxic
Flammable materials
Corrosive
Fork lift trucks
Danger overhead crane
Explosion risk
Oxidising
Danger of death
Biohazard
Laser Radiation
Danger of entrapment
Hot surface
General Warning
Blank
Gas bottles
Watch for
falling objects
Electricity
Danger for cutter
Entrapment hazard
Battery hazard
Rotating parts
Low temperature
Strong magnetic field
Optical radiation
Non ionizing
radiation
Radiation
Hazardous to the
Environment
Danger of harming
your hands
             
    
    
    
    
    
    
    
    
    
    
    
    
    
    
    
    

 XG0213 - 040512.1

Installation

IMPORTANT MESSAGE: SAVE THESE INSTRUCTIONS
The  Direct Vent replace must be installed in accordance with
these Instructions. Carefully read all the Instructions in this manual
rst. Consult the Local Gas Branch to determine the need for a permit
prior to starting the installation. It is the responsibility of the installer to
ensure this replace is installed in compliance with the manufacturers
instructions and all applicable codes.
BEFORE YOU START:
Installation Checklist
 Determine the desired install location of your replace.
 See  Dimensions on , and refer to the Framing
Section 2 for details.
 Select the location of your termination and resulting vent run.
 

 Should it be impossible to meet the venting requirements laid out
in : Venting, please contact your local Montigo dealer
regarding the use of a Montigo Power Vent.
 Lay out the Vent run; calculating the required elbows and straight
runs of 5"/8" ex or rigid pipe.
 Layout Electrical Requirements Refer to  : Wiring for
Details.
 Refer to : Installing the Gas Line for details on the gas
connection and access.
 Refer to local codes and guidelines for installation requirements.
 Installation and repairs should be done by a qualied contractor
and must conform to:
•  must conform to the local codes or
in the absence of local codes to the current version of Natural Gas and
Propane Installation Code, CSA B149. Electrical Installations must
conform to the local codes or, in the absence of local codes, to the
current version of Canadian Electrical Code, CSA C22.1.1
• must conform to the local codes or in
the absence of local codes to the current version of National Fuel Gas
Code, ANSI Z223.1/NFPA 54. Electrical Installations must conform to
the local codes or, in the absence of local codes, to the current version
of the National Electrical Code, ANSI/NFPA 70. See  for
installation within the State of Massachusetts.
Installation and repairs should be done by an authorized gas fireplace service technician.
The appliance should be inspected before use and at least annually by a professional. More
frequesnt cleaning may be required due to exessive lint from carpeting, bedding material,
ect. It is imperative that control compartments, burners and circulating air passageways of
the fireplace are kept clean.
NOTICE
Due to high operating temperatures, this appliance should be located out of traffic &
away from furniture and draperies.
Children and adults should be alerted to the hazards of the high surface temperature,
which could cause burns or clothing ignition.
Young children should be carefully supervised when they are in the same room as the
appliance.
Clothing or other flammable materials should not be placed on or near the appliance.
CAUTION
When this appliance is installed directly on any combustible material other than wood
flooring, it must be installed on a metal or wood panel extending the full width and
depth of the appliance or a fire will occur causing serious injury, property damage or
even death.
DANGER


XG0213 - 040512.1

Installation

. Fireplace dimensions with attached Nailing Flange for Corner Left shown, Fireplace dimensions same for corner right.(Tolerance ± ⅛").
Please review the Pre-Installation Checklist on   for general
information on preparing for a successful installation of your replace.
The  replace may be installed in any location that maintains
proper clearances to air conditioning ducts, electrical wiring and plumbing.
Safety, as well as efciency of operation, should be considered when
selecting the replace location. Select a location that does not interfere
with room trafc, has adequate ventilation and offers an accessible path
for Direct Vent installation.

20
5
16
”
5”
8”
25¼”
Depth
22¼”
Opening
5”
8”
33” Rear
Vent
3”
39½”
Height
24¾”
Opening
42
¼
” Width
39
3
16
” Opening
H38DF
CL
(
corner
l
e
ft)
Top View
H38DF CL (corner left)
Front View H38DF CL (corner left)
S
i
de
Vi
e
w
4¾”
6”
4” Nailing Flange
4” Nailing Flange

 XG0213 - 040512.1

Installation

Frame in the enclosure for the unit with framing materials. The framed
opening for the assembled replace is 48 " wide, 44 " high, 25 1/4"
deep, see .
       

.
. Framing dimensions.
 Combustible Framing for shelves over the unit. Top vent.
 Combustible Framing for shelves over the replace, Rear vent.
48”
25¼” *43 ¾”
48”
25¼”
*43 ¾”
H38DF CL Corner Left H38DF CR Corner Right
* = Approximate Dimensions to center
For best results mount non-combustible stud onto unit
prior to installation, then bolt to 2 X 4 header and floor.
Non combustible
stud included with unit.
44” 44”
 Non Combustible Framing with alcove above replace, Top Vent.

 



 
* = Approximate Dimensions to center
For best results mount non-combustible stud onto unit
prior to installation, then bolt to 2 X 4 header and floor.
Non combustible
stud included with unit.
 
Combustible Shelf
46”
Min. 44”
Exterior
Wall
90 elbow
1” Min.
4” Nailing flange or
Non-combustible material
17 1/2”
Min.
Combustible Header
Combustible
Shelf
59”
Min.
44”
Exterior
Wall
18”
Max.
90 elbow *
See Note:
C
ombustible
Header
1” Min .
90 elbow
1” Min.
4” Nailing flange or
Non-combustible material
13”Min.
Floor
39 5/8”
44”
C
ombustible
Header
Min. 1 ”
2”
Ceiling level
Non-Combustible
Header
Non-Combustible
materials. Alcove
over fireplace.
Top Vent
Non-Combustible
Materials, with Low
profile mantel / Alcove
over fireplace.
84”
min.


XG0213 - 040512.1

Installation
  †  †         
         

When installing a shelf over the top of the replaces, the following
guidelines must be adhered to:
For Rear Vent applications, the minimum clearance is 1" from the rear of
the replace to a wall, or any combustible materials, and 13" clearance
from the top of the replace to the underside of any combustible shelf
materials.
For Top Vent applications, the minimum clearance is 1" from the rear
of the replace to a wall, or any combustible materials, and 17 1/2" to
the underside of any combustible shelf materials.
1” clearance is maintained on sides and bottom of vent runs and 2”
above horizontal vent runs to any combustible material.

To avoid elevated mantel temperatures, all H*38C* gas replaces
are required to have the supplied standoffs installed. The replace is
supplied with two standoffs. Bend and install these standoffs on top
of the replace as shown in  ensuring that the height of the
standoff maintains a 4" clearance from the top of the unit to the 1st
combustible stud.

The 4" nailing ange extension is shipped attached to the top edge of
the replace, see .
The nailing ange extension may be substituted with a piece of 
 material of the same thermal characteristics, ie: cement
board or equivalent to t the opening. This is recommended in applications
where the facing materials will not adhere to the metal nailing ange.
To remove the Nailing Flange Extension follow the directions below:
 Installing the  standoffs.
†  Clearance from top of replace to a combustible ceiling within
the replace enclosure.
 Finished removing Nailing Flange extension.
 Remove screws from top of the unit
 Remove shell and insulation from the top of unit. Remove screws
from outer edge.
 Remove the nailing ange extension from the unit. Reinstall shell
and insulation. Screw shell in place.
4”

 XG0213 - 040512.1

Installation

Montigo supplies a variety of direct venting and termination options.

 It should also be
selected such that it provides the shortest vent run possible. Should
it be impossible to ensure that the termination is the highest point or
should it be impossible to meet the venting guidelines laid out below
please contact your Montigo dealer to discuss power venting options.



        
.




Top vent.
CONVERTING TO TOP VENT / REAR VENT
Use the following instructions to convert an  for Rear Vent use:
1. Remove the Rear ue cover and gasket (5" and 8") on the ue
outlet, as shown in 
2. Next, Remove the Top ue collar's (5" and 8") on the ue outlet,
as shown in 
3. Install the (removed) Rear ue cover and gasket material, to the
Top vent outlet. Fasten the cover with included hardware, as
illustrated .
4. Install the (5" and 8") collars to the rear vent outlet using the
included hardware, as illustrated .   













. Flue cover and collar installation, Rear Vented replace.
. Flue cover and collar removal, Top Vented replace.
5” Inner Flue Collar
8” Outer Flue Collar
Flue Gasket
Flue Cover Plate
8” Outer Flue Collar
5” Inner Flue Collar
Flue Gasket
Flue Cover Plate


XG0213 - 040512.1

Installation
 Top vent, Roof mounted termination with no offset in vent run.
. Top vent, Roof mounted with 1 offset (1 offset= two 90° bends).
. Top vent, Roof mounted with 2 offsets (1 offset= two 90°
bends).

The following details are some possible congurations for Roof
mounted terminations.
Support ring
Support plate
Firestop
32’ max.
2’ min.
Obstacle
PVTK1
Termination
Support ring
Support plate
Firestop
32’ max.
2’ min.
PVTK1
Termination
Support straps or
support plate & ring
2’ min.
Firestop
Firestop
Firestop
32’ max Support plate
& ring
Obstacle
PVTK1
Termination
 






The maximum termination point is 32’ above the replace (NOTE:
if the maximum termination height is used, the ame pattern
may be affected).
The Vertical termination must be a minimum 2’ higher than where
the termination exits the roong materials, (asphalt shingles,
cedar shakes, etc). This distance should be measured from the
high side of the roof slope where the ue ashing intersects the
roong materials. (see Figures 9 to 9c).
Termination location must be a minimum 6’ from a mechanical
air inlet.
Termination location must be a minimum 18” from a parapet wall.
For a more detailed diagram of allowed termination locations,
see .
A maximum of two offsets (each offset is made up of 2-90°
bends) may be made.
Firestops must be installed as required by National & local codes
Ensure all runs are supported with a minimum of 3 supports
per 10’ of venting.
Install all roof ashing and storm collars as shown.

 XG0213 - 040512.1

Installation
. Rear vent, Roof mounted venting (1 = 90° bend).
Support ring
Support plate 32’ M a.x
PVTK1
Termination
*18” Max. See
Note below
Storm Collar
 Elbow must be installed directly off the back of the replace. If
additional horizontal distance is required the vent run must be increased
a 2:1 Horizontal to Vertical ratio. See vent graph, for
rear vented, wall mounted terminations


XG0213 - 040512.1

Installation
1
12”
2”
12”
12”
 




A Termination with a Built-In Frame is installed during framing of a structure.
1. Frame the termination opening to 11" x 11".
2. Install exterior sheathing to the structure framing.
3. Fasten the termination to the sheathing using a minimum of 4 screws.
MSR Frame
PTO-4 (5"/8")
Termination
PTO-4F (5"/8")
Termination
 Installing a PTO-F termination.
 Installing a PTO termination with the MSR frame.
 Installing the VSS Vinyl Shield.

The VSS Termination shield is installed when the exterior of a structure
is clad with Vinyl siding. It is placed directly above, and on-centre with
the termination.

Terminations with a MSR frame allow the installation of the frame prior
to installation of the termination.
1. Frame the termination opening to 12" x 12".
2. Secure the MSR Frame to the exterior sheathing of the structure.
3. Fasten the termination to the MSR Frame using a minimum of 4 screws.
 Installing a PTO termination with the BSR frame.

Terminations with a BSR frame allow the installation of the frame in
masonry prior to the installation of the termination
1. Frame the BSR opening to 12" x 12".
2. Secure the BSR Frame to the exterior sheathing of the structure.
1. Frame the MOSR opening to 12" x 12".
2. Fasten the MOSR frame to the interior side of the studs, concrete,
or nished wall construction using a minimum of 4 screws.
3. Insert the termination into the MOSR frame as shown here, (from
the inside) and attach to the MOSR by installing a min. quantity of
4 bolts into the threaded nuts on the MOSR Frame.

A Termination with a MOSR Frame is installed from the inside of the
structure. These are commonly used in high-rise construction.
MOSR Frame
PTO-4 (5"/8")
Termination
 Installing a PTO termination with the MOSR frame.
BSR Frame
PTKOG (5"/8")
     is recommended
in installations where the termination is located within 7' feet above
grade, or above a pedestrian walkway, and may be Required by code
in Public areas.
1. Ensure that the two longmounting brackets are facing the bottom
of the termination. (See inset). This will provide more heat protection
at the top of the termination, where temperatures are highest.
2. Attach to the faceplate of the termination using four sheet metal
screws.
 Installing a PTO termination heat guard.
1
1”
11”
Framing
Exterior
Sheathing
Fastening Hardware,
minimum 4-screws
Framing
Exterior
Sheathing
Fastening Hardware,
minimum 4-screws
PTO-4 (5"/8")
Termination
Framing
Exterior
Sheathing
Fastening Hardware,
minimum 4-screws
12”
12”
Fastening Hardware,
minimum 4-screws
Framing, con-
crete or other
materials
Exterior Sheath-
ing, concrete or
other materials
Exterior Vinyl
siding
PTO-4 (5"/8")
Termination
VSS Vinyl shield

 XG0213 - 040512.1

Installation



Vent terminations must not be recessed in walls or siding.
For Heat Shield requirements see .
Once the proposed venting layout has been determined refer to
either to ensure the layout is acceptable.
Wall Mounted Terminations: TOP VENT
All dimension lengths for vertical or horizontal runs are measured
from center of the vent pipe.
Venting runs must fall within the limits set by the venting graphs,
see Figure 12 or 12a.
The Venting Graph
Measure the vertical height from the replace hearth to the centre of
the termination and the horizontal run from the replace ue collar to
the wall ange of the termination. Plot on the Venting Graph 
 with an 'X'.
If the 'X' falls on or above the top boundary of the shaded area, the
installation is acceptable.

If the vertical dimension from the hearth is 126" and the horizontal
run to the wall ange of the vent termination is 138", this would be
an acceptable installation.

If the vertical dimension from the hearth is 36" and the horizontal
run to the wall ange of the vent termination is 84", 


If the vertical dimension from the oor of the replace is 60" and
the horizontal run to the wall ange of the vent termination is 144",

 H38C* or HL38C* Top Vent Venting Graph for wall mounted
terminations.
. H38C* or HL38C* Top Vented, wall mounted installation with
one 90° bend. The vent run must comply with Venting Graph for Top
vent, wall mounted terminations, Figure 12.
 HP38C* Top Vent Venting Graph for wall mounted
terminations.
 HP38C* Top Vented, wall mounted installation with one 90° bend.
The vent run must comply with Venting Graph for Top vent, wall mounted
terminations, Figure 12a.
46”
A
C
B
.
Unacceptable vent run
within shaded area.
Acceptable vent run
within non-shaded area.
18”
If your installation does not
fall within the venting graph
parameters, please contact a
local Montigo dealer for Power
Venting options.
59”
A
C
B
Unacceptable vent run
within shaded area.
Acceptable vent run
within non-shaded area.
18”If your installation does not
fall within the venting graph
parameters, please contact a
local Montigo dealer for Power
Venting options.
Heat
Shield
Termination
Hearth
Exterior
Wall
59” Min.
18” Max
Flex of Rigid
section
Heat
Shield
Termination
Hearth
Exterior
Wall
46” Min.
18” Max
Flex section


XG0213 - 040512.1

Installation
. H38C*, HL38C* or HP38C* Top Vented, wall mounted
Multi-elbow installation. See Venting Graph for Top vent, wall mounted
terminations, Figure 12 or 12a.
WARNING:
An inspection of the explosion relief appers and door
 be made prior to lighting the replace. A faulty seal
on the door gasket and/or explosion ports will result in
products of combustion leaking into the living space and
may result in carbon monoxide poisoning.
Solid
Section
Flex
Section
Hearth
150”max Heat
Shield
Termination
Exterior
Wall
Heat
Shield
Solid Section
Flex Section
Hearth
Termination
Exterior
Wall
30” max
126” max
 . H38C*, HL38C* or HP38C* Top Vented, wall mounted
Retracted Multi-elbow installation. See Venting Graph for Top vent, wall
mounted terminations, Figure 12 or 12a.

 XG0213 - 040512.1

Installation
. H38C* & HL38C* Rear Vent Venting Graph for wall mounted
terminations.
 H38C* & HL38C* Rear Vented, wall mounted multi-elbow
termination installation. The vent run must comply with the Venting Graph
for Rear vent, wall mounted terminations, Figure 14.




All dimension lengths for vertical or horizontal runs are measured
from center of the vent pipe.
Venting runs must fall within the limits set by the venting graphs,
see Figure 14 or 14a.
Fireplace must be converted to Rear Vent conguration prior to
running vent, see Figure 8 and 8a.
The Venting Graph
Measure the vertical height from the replace hearth to the centre of
the termination and the horizontal run from the replace ue collar to
the wall ange of the termination. Plot on the Venting Graph Figure 14
or 14a with an 'X'.
If the 'X' falls on or above the top boundary of the shaded area, the
installation is acceptable.

If the vertical dimension from the hearth is 84" and the horizontal
run to the wall ange of the vent termination is 48", this would be
an acceptable installation.

If the vertical dimension from the hearth is 108" and the horizontal
run to the wall ange of the vent termination is 108", this would be
an acceptable installation.

If the vertical dimension from the oor of the replace is 66" and
the horizontal run to the wall ange of the vent termination is 90",

 HP38C* Rear Vented, wall mounted Multi-elbow termination
installation. The vent run must comply with the Venting Graph for Rear vent,
wall mounted terminations, Figure 14a.
HP38C* Rear Vent Venting Graph for wall mounted terminations.
WARNING:
42” Max.
59” Min.
18”
Max.
26”Min.
33”
Hearth
Flex or Rigid
Section
18”
59”
AC
B
If your installation does not
fall within the venting graph
parameters, please contact local
Montigo dealer for Power
Venting options.
Unacceptable vent run
within shaded area.
Acceptable vent run
within non-shaded area.
59”
AC
B
64”
Acceptable vent run
within non-shaded area.
Unacceptable vent run
within shaded area.
If your installation does not
fall within the venting graph
parameters, please contact local
Montigo dealer for Power
Venting options.
An inspection of the explosion relief appers and door MUST be made
prior to lighting the replace. A faulty seal or door gasket and/or explosion
ports will result in products of combustion leaking into the living space and
may result in carbon monoxide poisoning.
64” Max.
59” Min.
18”
Max.
Flex or Rigid
Section
26”
Min.
33”


XG0213 - 040512.1

Installation
 


 



 





 







 º
º
º
º
 
 
 

 
 
Connection and installation of the vent components should
adhere to the following guidelines:
 








Montigo recommends the use of a ex section for the nal pipe
connected directly to the replace offering greater exibility of
installation and absorption of movement.
Firestops must be installed as required by National & local codes.
Montigo recommends that all exterior corners and joints be sealed
with exterior caulking. However, we encourage you to consult
your Building Envelope Engineer or Waterproong Consultant
for further recommendations.
Use any combination of rigid and ex pipe as required and in
any orientation (Male connectors can face in any direction).
Flex sections may be stretched up to 50% of their total length
(e.g. a 24” section maybe stretched to 36”).
Connect all vent sections using a minimum of three sheet metal
screws on the outer pipe ue.
Ensure the pipe ends male to female slide in a minimum of 1
1/2” of overlap.
Ensure all runs are supported with a minimum of 3 supports
per 10’ of venting.
When hanging/ supporting venting, ensure that 1” clearance
is maintained on sides and bottom of vent runs and 2” above
horizontal vent runs to any combustible material.
Rigid pipe may be cut less than half way from the
Ensure when cutting sections of rigid pipe to maintain integrity
of internal supports.
Place the springs, supplied with the pipe kit, between the outer
and inner pipes to keep the pipes separate and avoid any
possible hot spots.

 XG0213 - 040512.1

Installation
Heat Shields

Use the RHS103 where the termination is closer to the replace than
36" horizontally and 60" vertically. To install the RHS103, Slide the Inner
Section over the vent pipe that will connect to the replace. Then fasten
the vent pipe to the back of the replace with a minimum of three sheet
metal screws. From the outside slide outer ring to outer section and
then slide the RHS103 outer section on, see . To complete the
installation fasten the Heat Shield Outer Section & Termination frame
to the structure .
 RHS103 Installation. (Install by sliding Outer Section over
vent pipe where it passes through the combustible construction.
 Heat Shield after sliding the outer section in place.
. RHS103 Installation.
Outer Shield 9 1/2”
3/8” Min. Both sides Typical
3/8” Min.
3/8” Min .
Combustible Framing
12” x 12”
Inner Shield 9 3/8”
Outer Ring 10 1/4”
 RHS103 Installation. (Minimum requirements).
RHS103
Heat Shield
36” Min
60”Min.
RHS103 Outer Ring
Termination
Drywall / sheetrock
RHS103 Heat Shield, inner Section
RHS103 Heat Shield
Outer Section
Combustible
framing
Termination
Drywall / sheetrock
RHS103 Heat Shield, inner Section
RHS103 Heat Shield
Outer Section
Vent pipe, from fireplace
RHS103 Outer Ring


XG0213 - 040512.1

Installation


  
  
  
  
. Wiring Diagram for the SIT Proame Electronic Ignition with remote control
Honeywell (Q3450)
Pilot Assembly
Pilot Electrical
Harness Connector
Honeywell Gas
Control (SV9501M)
Gas Control
Connector
Junction Box
115VAC
24VAC
40 VA
Transformer
Black
White
Green
Gnd Screw
Wall Switch
Fan Plug
Receptacle
. Wiring with Honeywell gas control and pilot.





REMOTE
Receiver 14
Pin Connector
Pilot
(CPI / IPI MODE
MOTOR
IPI/CPI
RECEIVER SPLIT FLOW
ON / OFF
TH
TPTH
DC SUPPLY
GROUND
885 Valve
Orange Green
Chassis
connection
Remote control
Not Used)
Battery
Holder
4 x 1.5V
AA Type
120 Vac INPUT
7.5V DC
Output
AC Adaptor
Receiver 14
Battery Holder
w/ Switch
ON/REMONTE/OFF
(Not Used)
Receiver 14
Battery Holder
Top View

The H38C* gas valve may be connected to a wall
switch. Do  connect any external power to
the remote switch. The valve will generate its own
power on a millivolt circuit Use only low voltage
wire, and  The switch location must not
exceed 30' from the replace.
. Wiring with SIT Nova 820.





Manifold Pressure
Test Connection
Wall Switch
Power
Generator
Pilot Adjustment Screw
Inl
e
t Pr
essu
r
e
'Hi-Lo' Adjustment Knob
Gas Control Knob (Shown in “Pilot” position)

 XG0213 - 040512.1

Installation

. Gas line access.
3 3/8"
2 1/2" 1 1/8"
14 1/4"
1 1/2"
5"
2 5/8"

Verify that your replace is compatible with your available gas
type. (Natural Gas or Propane shown by "N" or "L" in your
model number
If gas type is not compatible, contact your local Montigo
representative to purchase a conversion kit.
Conversion kits must be installed by a qualied service technician.

Optimum appliance performance requires proper input pressures.
Gas line sizing requirements will be determined in ANSI Z221.3
National Fuel Gas Code in the USA and CAN/CGA B149 in
Canada.
Pressure requirements are:
  
  
  
The manifold outlet pressure is set from the factory to the
appropriate pressure but should be veried.
To check pressures, control valves have a provision to remove
a 1/8” N.PT. plug to be tted with a hose barb.
Montigo requires a service shut off valve be located in an
accessible location to isolate the gas supply.
Only install gas shut-off valves approved for use by the state,
province, or other governing body in which the replace is being
installed.

See  below for location of gas line access.
Flexible gas connectors must not exceed 3 feet in length, unless
allowable within local regulations.
Connect incoming gas line to the 1/2"or 3/8" gas inlet port.
Purge all air out of gas line.
Check appliance connection, valve and valve train under normal
operating pressure with a commercially available leak check
solution.

After gas line is connected, each appliance connection, valve and valve train MUST
be checked while under normal operating pressure with either a Liquid Solution, or
Leak Detection Device, to locate any source of leak. Tighten any areas where
bubbling appears or a leak is detected until bubbling stops completely or leak is no
longer detected. DO NOT use a flame of any kind to test for leaks. A fire or explosion
will occur, causing serious injusy, property damage or death.
DANGER
When pressure testing the fireplace, Gas line, and input system follow the appropriate
local codes or your area. DO NOT connect the fireplace to pressures in excess of
1/2lb. This will damage the gas control valve.
NOTICE


XG0213 - 040512.1

Installation

. Combustible mantles and facings

 National Canadian Gas Association mantel test requirements
are for re hazard prevention to combustible materials.
New technology, to meet consumer and government demands for the
wise use of energy, has prompted us to manufacture many models of
replaces which are hot, fuel and energy efcient.

Combustible mantels and mouldings may be safely installed over the
top and on the front of the replace provided that they do not project
beyond shaded area shown in 

When sizing the nish material for your replace, it is important to
remember the following: 
             
        

The face of the replace may be painted to match the room decor,
provided you use a heat-resistant paint. Decorative facing must not
extend past the replace opening at all, because it will interfere with
the access to retainers for removal of glass door.
We recommend careful consideration be given to the effects of elevated mantel
temperatures which may be in excess of product design, for example: candles, plastic
or pictures. This can cause melting, deformation, discoloration or premature failure of
T.V. radio, and other electronic components.
CAUTION
 Combustible surrounds.
Side wall clearances are 3". Combustible surrounds may be installed
with 3" clearance to the side of the replace as shown in .
Non-Combustible
Header
Drywall/
Sheetrock
Facing Material
When covering the upper metal portion of the fireplace, (as shown, Fig.21)
with a non-combustible m aterial, P lease Note: The decorative facing
materials may be subject to temperatures in excess of 250° F. This should
be considered when selecting facing materials.

Combustible
Construction allowed
in shaded area
Top of fireplace
4” Nailing flange
Combustible Facing
Material
or Non-combustible
Horizontal Run (in)
Vertica
l
Run (in)
Combustible header
Steel Stud Construction
allowable in grey area

 XG0213 - 040512.1

Installation

Removing the Front door:
The door is removed in a few simple steps. Follow these
below to remove the Horizontal access panel, unlatch the door buckles
and, remove the door. Replace in reverse order. The smaller Side door
is bolted in place.
. Locate the door buckles.
Door Latch Hook
Door Latch Slot
Hand-hold

 Removing and installing the Horizontal Access Panel

. Door buckle Tool
1
Step 4:
Firmly grasp hand-hold
end of Door buckle tool
and place the machined
end in the slot under door
frame. (as shown)

Step 2:
Step 3:
Step 1:
Remove the Horizontal cover
by placing ngers in both nger
holes, then pushing away from
you and lifting out. Place it
aside during maintenance or
cleaning.
Install in reverse order.
Remove the Horizontal Access Panel:
To install the door, hook the top edge of the door frame into place. Lower
and rest the door frame in place and fasten the buckles.

2
Step 5:
Ensure the tool is rmly
in the lower end of the
slot, (as shown), Then pull
toward you (Caution: hold
the tool securely).
3
Step 6:
Pull hard if necessary to
release the spring ten-
sion. (Caution: The latch
springs back with force,
hold the tool securely).
4
Step 7:
Remove the tool from
the latch slot. Ensure the
latches are hanging freely,
the hook end is released
from the bottom of the door.
(Repeat all 4-steps for the
remaining latches).



 Removing and installing the glass door.

Step 8:
Grasp the Door on either side, usually midway and lift upward, lift
the door carefully up and away from the front of the replace. See
. Place the Door aside in a safe place while maintenance
and / or cleaning is being performed.
Door buckles
Small glass door
affixed to frame
with hardware.
Finger Holes
Installed Gas
Valve Cover
