Superb Image Quality with Added Intelligence
Super Dynamic III
Color Dome Camera
WV-CS954
The new Panasonic WV-CS954 Super Dynamic III dome
camera is equipped with a 30x optical zoom lens.
Combined with a 10x digital zoom, for a total zoom capability
up to 300x, this camera can identify distant subjects.
With its Pixel Based 128x Dynamic Range, the WV-CS954
works beautifully even when contrast changes from scene to
scene. Area free natural contrast image correction ensures
accurate reproduction, whatever the subject. Horizontal resolution
is also significantly higher, 540 lines (typical) in color or 570 lines
in B/W. Plus, images stay clear and sharp in lighting as low as
0.5 lux (0.05 fc, in color) and 0.04 lux (0.004 fc, in B/W).
Adaptive Digital Noise Reduction eliminates streaking from
objects such as headlights. Its 0.065°/sec. ultra slow speed fine
control and powerful zoom let you zoom in smoothly on your
subject. Whatever the situation, WV-CS954 offers dramatic
improvement in subject identification.
Additional intelligent features include Auto Image Stabilizer
to eliminate blurring if the camera is shaken. Scene Change
Detection to send the alarm signal if the camera is interfered with,
Auto Tracking of intruders, and 256 preset positions.
Combining extraordinary image quality with added intelligence,
the WV-CS954 brings unprecedented reliability to 24-hour surveillance.
•
Higher horizontal resolution of 540-line (typical) at color mode, and 570-line at B/W mode.
•Minimum illumination of 0.5 lux (0.05 fc) at color mode, and 0.04 lux
(0.004 fc) at B/W mode (Sens. up; off, AGC High).
•Innovative intelligent features:
*Auto image stabilizer function for applications where vibration or wind
is a concern, e.g. passing vehicles.
*Scene change detection alarms when lens is covered, spray painted,
removed, defocused or camera angle is changed.
*
Auto tracking function tracks moving objects and keeps them centered in
the field of view. Perfect for restricted areas and after hour applications.
•Day/Night operation can be selected to automatically or manually switch
from color to B/W.
•Privacy zone masking function.
•Linear 32x electronic sensitivity enhancement function.
•Digital motion detector.
•30x optical zoom lens (3.8 -114 mm at F1.4) plus 10x electronic digital
zoom for total zoom capacity of 300x.
•Auto focus lens.
•Digital-FLIP by memory allows automatic180° turn.
•Patrol Learn function (8 zone total).
•Auto panning function with 256 preset positions.
•360° endless panning.
•Panning speed of max. 400°/s at preset mode and 0.065°/s super
fine control at manual mode.
•Image Hold function during panning.
•Multiplex-coaxial or RS-485 data communication.
•Four (4) alarm inputs and two (2) outputs terminals.
•16 alphanumeric character display.
•Internal/Line-lock/Multiplexed Vertical Drive (VD2) synchronization.
•24V AC, 60Hz power source.
•Optional smoked dome cover, ceiling and wall mounts brackets are
available for various applications.
KEY FEATURES
•All-in-one color surveillance dome camera unit.
•The new Pixel Based 128x Dynamic Range with area free natural
contrast image correction adjusts moment-to-moment changes in
contrast to view subjects accurately in all areas and positions.

WV-CS954 x 8 WV-CP480 Series x 8
Color Monitor x 2
RGB Monitor
Digital Disk Recorder
WJ-HD316A
2 drive bays
Extension Unit
WJ-HDE300
4 drive bays
Extension Unit
WJ-HDE300
4 drive bays
Extension Unit
WJ-HDE300
4 drive bays
Extension Unit
WJ-HDE300
4 drive bays
+
LAN/WAN
Internet
PC
PC
Ethernet
(10Base-T/100Base-TX)
System Controllers (Max. 4)
WV-CU650
PS-Data
CH8 CH9 CH16CH2CH1
Extension Unit
WJ-HDE300
4 drive bays
Extension Unit
WJ-HDE300
4 drive bays
Extension Unit
WJ-HDE300
4 drive bays
SYSTEM EXAMPLE
Unit : mm (inches)
Model No. WV-CS954
General
Pick-up Device 1/4-type interline transfer CCD
Effective Pixels 768 (H) x 494 (V)
Scanning Area 3.65 mm (H) x 2.74 mm (V)
Signal NTSC/EIA
Synchronization Internal / Line-Lock / Multiplexed Vertical Drive (VD2)
Scanning 2:1 interlace
Scanning Frequencies Horizontal: 15.734 kHz, Vertical: 59.94 Hz
Video Output VBS: 1.0 V [p-p] /75 Ω(BNC connector)
Horizontal Resolution 540 lines (in color, typical)
(Center) 520 lines minimum (in color, HIGH mode)
480 lines minimum (in color, NORMAL mode)
570 lines minimum (in B/W)
Minimum Illumination
0.5 lux (0.05 fc) (in color) 0.04 lux (0.004 fc) (in B/W) *SENSE UP: OFF, AGC: HIGH
Dynamic Range 52 dB typical (SUPER-DYNAMIC III : ON)
Signal-to-Noise Ratio 50 dB minimum (AGC: OFF)
Ambient Operating Temperature –10 °C - +50 °C (14 °F -122 °F) Humidity; 90 % max. (non-condensation)
Power Source and Consumption 24 V AC, 60 Hz; 13.0 W
Dimensions 154.5 mm (D) x 233 mm (H) (6-1/16" (D) x 9-3/16" (H))
Weight approx. 2.2 kg (4.84 lbs.)
Pan and Tilt
Panning Range 360° endless
Panning Modes Manual, auto, manual position, sequential position
Panning Speed*
Manual: approx. 0.065°/s -120°/s 8 steps, 16 steps, 64 steps Preset: approx. 400°/s
Tilting Range –5° - 185° (horizontal - vertical - horizontal) (According to the TILT ANGLE)
Tilting Modes Manual, manual position, sequential position
Tilting Speed*
Manual: approx. 0.065°/s - 120°/s 8 steps, 16 steps, 64 steps Preset: approx. 400°/s
* Actual speed depends on type of optional controller being used.
Lens
Zoom Ratio 300x (30x optical zoom plus 10x electronic digital zoom)
Focal Length 3.8 mm - 114 mm
Maximum Aperture Ratio 1:1.4 (WIDE) - 3.7 (TELE)
Object Distance 1.5 m
Iris Range F1.4 - 22, Close
Angular Field of View Horizontal: 1.9° (TELE) - 52° (WIDE) Vertical: 1.4° (TELE) - 40° (WIDE)
Main Functions
Controller Interface Coaxial Multiplex System, RS-485 Transmission
Control Functions Pan and tilt, zoom and focus, 256 preset positions, home position, patrol
AGC ON (LOW/MID/HIGH), OFF
Character Display ON, OFF (Preset ID, camera ID, area title: 16 alphanumeric characters)
Zoom Speed approx. 6.0 seconds (TELE to WIDE) in manual mode
Zoom Ratio Control 1x - 300x (Over 30x is electronic zoom)
Password Lock All menus
Focus Speed approx. 6.0 seconds (FAR to NEAR, full TELE zoom) in manual mode
Auto Focus MANUAL/AUTO (PAN, TILT, ZOOM linked)
Iris ALC (Adjustable OPEN/CLOSE output target level)/MANUAL
Shutter OFF (1/60), AUTO, 1/100, 1/250, 1/500, 1/1,000, 1/2,000, 1/4,000, 1/10,000
Electronic Sensitivity Enhancement 32x max. (AUTO or FIX; Factory Default: AUTO (2))
Auto Mode OFF, SEQ, SORT, AUTO PAN, PATROL, AUTO TRACK
Auto Pan Key SEQ, SORT, AUTO PAN, PATROL, AUTO TRACK
Digital Flip ON/OFF
Super Dynamic III ON/OFF
Motion Detector OFF/MODE1/MODE2
Alarm Input/Output 4 inputs (ALARM IN 1- ALARM IN 4) 2 outputs (ALARM/AUX1, BW/AUX2)
Black and White Mode Switchin g AUTO/ON/OFF
Privacy Zone ON/OFF (8 zone settings)
Patrol STOP/PLAY/LEARN
Cleaning ON/OFF
Image Hold ON/OFF
STABILIZER ON/OFF
Scene Select Setting INDOOR (L) / INDOOR (H) / OUTDOOR (L) / OUTDOOR (H)
Language Setting English, German, French, Italian, Spanish, Russian, Chinese, Japanese
SPECIFICATIONS
OPTIONAL ACCESSORIES
WV-CS3S
Smoke Cover
WV-Q105
Direct
Ceiling Installation
WV-Q116
Embedded
Ceiling Installation
WV-Q117
Suspended
Ceiling Installation
WV-Q118
Wall Installation
24V AC Power Connector
Video Output Connector
Decorative Cover
Safety Wire
Lens
RS-485 Data Port
Alarm Output Connector
Alarm Input Connector
Camera Mounting Base
Dome Cover
MAJOR OPERATING CONTROLS & TERMINALS
SR72.5
158(6-1/4")75(2-15/16") 25(1")
83.5(3-5/16") 83.5(3-5/16")
46(1-13/16")
46(1-13/16")
233(9-3/16")
4.54-
145(5-11/16")
154.5(6-1/16")
APPEARANCE
