EXO™Vandal Resistant
High Denition Camera Systems
For Harsh Environments
The EXO Vandal Resistant High Denition (HD) Network Camera System is the professional’s choice for capturing brilliant, 1080P
full HD video in urban areas, prisons, and other high risk applications. Built with hardened components to withstand extreme
temperature ranges, power surges and heavy impacts.
Available Features
•
HD 1080P models
• 20x & 30x optical zoom models
• 30x zoom models have image stabilization
• ONVIF, PSIA (Milestone, ONSSI), and GENETEC API, supported
• Meets NEMA 4 and NEMA TS2 standards (most models)
• Micro-SD / SDHC / SDXC / support
• H.264 High Prole, MJPEG compression
• Video motion detection
• Audio synchronization
• Temperature range: -58ºF to 140ºF (-50°C to 60°C),
up to 165ºF (74ºC), Per NEMA TS2
• Proprietary surge protection
(Ethernet, power and alarm / data wires)
• Multiple mounting options
• IK10 Vandal Resistant
∙
MADEIN
BUY AMERICA COMPLIANT • COUNTRY OF ORIGIN U.S.A.
USA

EXO™Vandal Resistant
©2013 Moog, Inc. All rights reserved.
Product and company names listed are trademarks
or trade names of their respective companies
The outdoor pan-tilt-zoom high denition (HD) IP
video camera has been integrated with a
ruggedized aluminum outdoor dome housing
with a integral pan-tilt-zoom mechanism.
The EXO Vandal Resistant camera system is
ideal for applications needing extra protection
from vandalistic attacks, it’s been built to
withstand violent impacts. Constructed of cast
aluminum with an OptiClear polycarbonate
dome this unit is ideal in urban areas, prisons
and other areas where there is a high probability
of attacks on surveillance equipment.
Models:
EXVW7C2-2
20x optical zoom,
wall mount
with sunshield
EXVP7C2-2
20x optical zoom,
Pendant mount
with sunshield
EXVW7C2-3
30x optical zoom,
wall mount
with sunshield
EXVP7C2-3
30x optical zoom,
Pendant mount
with sunshield
Camera
20x 30x
Image Sensor: 1/2.8-type Exmor CMOS
Lens / Digital Zoom:
20x Optical Zoom,
f=4.7mm (wide) to 94.0mm
(tele); 12x (240x with optical
zoom)
30x Optical Zoom,
f=4.6mm (wide) to
138.0mm (tele); 12x (360x
with optical zoom)
Minimum Illumination: Color: 1.2Lux (F1.6 50IRE); B&W: 0.3Lux (F1.6 50IRE)
Shutter Speed: Automatic or user selectable
Selectable Shutter Speeds: 1/1 to 1/10,000s, 22 steps
Pan/Tilt/Zoom:
Pan: 360º continuous rotation; Tilt: 0º to 95º above horizon;
Speed: 0.5°-80°/sec manual operation, 120°/sec preset
Horizontal Viewing Angle:
55.4º (wide) to
2.9º (tele end)
59.5º (wide) to
2.1º (tele end)
Image Stabilization: No Yes
Maximum Lens Aperture:
Minimum of f/1.6 (wide)
to f/3.5 (tele)
Minimum of f/1.6 (wide)
to f/4.7 (tele)
Protocols
Networking: IPv4/v6, UDP, TCP, IGMP, ICMP, ARP, DHCP, DNS
Streaming: RTP, HTTP
Management: RTSP, HTTP, HTTPS, Bonjour, NTP, Telnet, SNMP
Security:
Password protection, HTTPS encryption, digest
authentication, user access log
System Administration: Web GUI interface (HTTP or HTTPS)
Access Control: SSL, Basic and Digest Authentication
Audio / Video Buffering: Recorded ASF les to micro-SD medium
Long Term System
Conguration Memory:
System conguration stored on internal ash
Software Update: Fault-tolerant, remote accessible
Alarm Events: Triggered by external input or internal event monitoring
Network: Standard 10/100 Base-T Ethernet port
Edge Recording:
One (1) micro-SD / SDHC / SDXC interface (2-32GB
Sold Seperatly, class 6 or above micro SD card)
System Integration
Application Programming Interface: GENETEC API, PSIA (Milestone, ONSSI), ONVIF
Event Triggers: Video motion detection, temperature, memory card full
Event Actions: Video recording to edge storage
Sensor and Surveillance Systems
2525 Park Central Boulevard, Decatur, GA 30035 USA +1.770.987.7550 www.MoogS3.com
EXO™Vandal Resistant
Form 500-894 0413
Video
Video Compression: H.264 High, Main and Baseline proles Motion JPEG
Resolutions:
H.264: 1920x1080, 1280x720, 640x360, H.264 or
Motion JPEG: 640x360, 4CIF, VGA, 2CIF, CIF
Frame Rate: Up to HD 1080p @ 30 fps720p @ 60fps
Video Streaming: User selectable (1) H.264 and (1) H.264 or MJPEG
Image Settings:
Wide dynamic range (WDR), manual shutter time,
compression, color, brightness, sharpness, white balance,
exposure control, exposure zones, backlight compensation,
ne tuning of behavior at low light, rotation, text and image
overlay, privacy masks, image freeze on PTZ
Data Rate:
Variable Bit Rate, Motion adaptive variable bit rate and
Constant Bit Rate modes. 64 kbps – 6 Mbps per channel
(requires less than 1 Mbps @ 4CIF/30fps)
MADEIN
BUY AMERICA COMPLIANT • COUNTRY OF ORIGIN U.S.A.
USA
Environmental
Humidity: 0-100% N.C per MIL-E-5400T, paragraphs 3.2.24.4
Impact Rating: IK-10
Ingress Protection Rating: IP66
Maximum Windload: 150mph (240kph)
Operating Temperature:
-58ºF to 140ºF (-50°C to 60°C), up to 165ºF (74ºC),
Per NEMA TS2
Vibration: Conforms to NEMA TS2, para 2.1.9
Electrical
Alarm Inputs / Output: 2 / 1; Two (2) digital input pins
Power Input / Input Voltage: 24Vac, 80W
Surge Protection:
Proprietary two (2) stage surge protection
(3 year warranty)
Audio Streaming: Two-way: Uncompressed PCM High-delity AAC-LC G.711
Audio Input / Output:
Single analog audio input; Single analog audio output
(External Microphone and Speaker required)
Connectors:
RJ45 for 10BASE-T/100BASE-TX, Pheonix style connectors
for AC/DC power, 4 congurable alarm inputs / outputs, mic
in, line mono input, line mono output to active speaker
EXO Vandal Resistant
General
Housing Style: Aluminum and Stainless steel hardware
Dome: OptiClear Polycarbonate
Mounting Style: Wall and pendant mount models
Mounting Pattern:
Pendant: 1.5”npt;
Wall: (4) 2”x5.5” bolt pattern, .38” dia.
Net Weight: 13 lb (5.9 Kg)
Dimensions (h*w*d): 14.7” x 8.2” x 14.7” (375 x 210 x 375mm)
Warranty: 3 years, including surge protection
Accessories:
APM6G
Pole mount adapter, Moog grey
ACA2G
Corner mount adapter, Moog grey
WM20GG
Gooseneck wall mount, Moog grey
PRM50G
Large parapet mount, White
Regulatory and Certications
ONVIF CE REACH NEMA Rating RoHS UL Listed WEEE
Weee
PENDING
