MOOSE CST403 User manual

CST403
PUBLIC ADDRESS SPEAKER
Dear customer,
Thank you for choosing MOOSE branded products!
To ensure this product is installed properly, please read these instructions carefully before you begin. This high
quality speaker is prepared to provide many years of service but can be damaged by improper handling and/or
installation. Be sure your installation conforms to local codes. This MOOSE product is proudly developed and
manufactured in PORTUGAL - EUROPE (EU).
Configuration
Power handling capacity
LOW/MID freq.
Frequency response
Horinzal coverage angle
Vertical coverage angle
SPL (1W/1kHz)
High impedance input
Public address column speaker
20W rms
4x 3" rubber cone woofer
100Hz - 19kHz
120°
30°
90dB @ 1m
100V line transformer
Technical specifications
Installation Instructions
PRE INSTALLATION
INSTALLATION
Acoustical
Cabinet
Grille
Color
Hardware
Dimensions
Weight
Extruded aluminium construction
Custom perforated metal grille
Black or white textured powder coating
C-sup M for wall mounting
80x90x390mm
3Kg
Physical
www.moosesound.com
PROUDLY DEVELOPED AND
MANUFACTURED IN PORTUGAL
Rua do Padrão 52, 4440-617 Valongo, PORTUGAL. Telf.: [phone], Fax: [phone], [e-mail]
MOOSE is a brand or PROFACTOR S.A.
80 90
390
Unpack the speaker.
Take a moment to check the fixture to make sure there is no damage. Verify that you have all the necessary tools, fittings
and connection hardware to complete the installation and connection. The Speaker is supplied with the wall mount bracket
and 4 screws. Provide suitable structural support to fully support the speaker.
STEP 1: Set the location of the Speaker on the wall where is to be installed.
STEP 2: Mark the location of the bracket holes using the 1:1 scaled diagram/mould (figure 1)
STEP 3: Drill 6mm holes and then screw brackets on the wall with the supplied screws. First fasten upper screws in bracket
only to support the weight.
STEP 4: After the Speaker is installed and well fixed to the wall using the 4 screws supplied it is possible to connect the
signal cable to the high impedance 100V line input respecting polarity (+/-).

FIGURE 1
SCALE 1:1
