Mophie powerstation go User manual

powerstation®go air
OPERATING INSTRUCTIONS
PROJECT: PS-GO-AIR | QSG DIMENSIONS: 112mm x 178mm BLEED: .125 CREATIVE DESIGNER: Sarah PRODUCTION ARTIST: Sarah PDM: Jessica / Mike PCM: Kaitlyn DATE: January 7, 2021 2:38 PM ARENA: 314-00934 REV: A
SPECIAL INSTRUCTIONS: • Saddle Stitched booklet, 20 pages. • RevA1_121820 • Shared across all HSN SKUs:
401107388, 401107389, 401107390, 401107391, 401107392, 401107393, 401107429
COLORS: CMYK+ Pantone 377C
powerstation go air | HSN | Quick Start Guide
English

2 3
mophie powerstation go air
Thank you for choosing mophie!
Powerful and loaded with features including an easy to use digital display,
the mophie powerstation go air can be used to safely jump start your
vehicle or inate your tires. The mophie powerstation go air provides
portable power so you can charge your phone, tablet and other electronic
devices anywhere! The mophie powerstation go air also includes a
convenient oodlight and emergency light. Compact, versatile and simple
to use, the mophie powerstation go air and all accessories t neatly in its
carrying pouch and is perfect to store in your home or vehicle for every day
use or an emergency need. Never be without a charge, a jump start, or with
a at tire again!
Safety precautions
DANGER-CAUTION Read and understand all safety information before
using this product. Failure to follow these instructions may result in
electrical shock, explosion, re which may result in serious injuries,
death or property damage.
- When used correctly, lithium- ion rechargeable batteries provide a safe
and dependable source of portable power. However, if they are misused
or abused, this may result in leakage, burns, re or explosion, causing
personal injury or damage to other devices.
- Misusing or incorrectly connecting your mophie powerstation go air may
cause electric shock to users and damage equipment.
- Do not operate in explosive atmospheres such as in the presence of
ammable liquids, gases or dust.
- Remove jump start clamps from vehicle battery after jump starting vehicle.
- Keep your mophie powerstation go air dry and away from moisture and
corrosive materials. The mophie powerstation go air should not be used
near water or wet areas such as bathtubs, showers, bathrooms, sinks,
swimming pools or basements.
- Do not expose your mophie powerstation go air to moisture, water, rain,
or snow.
- Keep your mophie powerstation go air away from heat sources,
including open ames, radiators, stoves, ovens, and any other devices
that product heat.
- The lithium-ion rechargeable battery used in this charging device may
present a risk of re or chemical burn if mistreated. Do not expose to re
or excessive temperature. Do not expose to heat above 212°F (100°C)
or incinerate.
- In the unlikely event of leakage or explosion use sand or a chemical
re extinguisher.
- Your mophie powerstation go air may become warm under extended
high power operation. Do not cover, wrap, or otherwise restrict the
mophie powerstation go air during operation.
- Do not disassemble your mophie powerstation go air. There are no user-
serviceable parts inside. Incorrect reassembly may result in shock or
re hazard.
PROJECT: PS-GO-AIR | QSG DIMENSIONS: 112mm x 178mm BLEED: .125 CREATIVE DESIGNER: Sarah PRODUCTION ARTIST: Sarah PDM: Jessica / Mike PCM: Kaitlyn DATE: January 7, 2021 2:38 PM ARENA: 314-00934 REV: A
SPECIAL INSTRUCTIONS: • Saddle Stitched booklet, 20 pages. • RevA1_121820 • Shared across all HSN SKUs:
401107388, 401107389, 401107390, 401107391, 401107392, 401107393, 401107429
COLORS: CMYK+ Pantone 377C
powerstation go air | HSN | Quick Start Guide
English

4 5
Table of contents
2 | Safety Precautions
6 | Included Items
8 | Operating Instructions
15 | Specications
17 | Warranty and Contact Information
- Do not drop or subject to strong impacts. Do not operate your mophie
powerstation go air if it has received a sharp blow, or has otherwise been
damaged in any way.
- Do not puncture, crush or subject to mechanical shock.
- Only charge your mophie powerstation go air by the specied method
with the specied charging adapter provided with the unit.
- Do not use any non-mophie-branded accessories with the mophie
powerstation go air. Doing so may cause electric shock to users and
damage equipment.
- The mophie powerstation go air, along with its accessories, are not toys
and should be kept away from children.
- Make sure the jumper cables are fully plugged into the jump start output
before trying to jumpstart your vehicle.
- Do not touch red (positive) and black (negative) jumper clamps together
at any point.
- Do not insert any foreign object into the ports or openings of your
mophie powerstation go air.
- Do not clean your mophie powerstation go air with harsh chemicals,
soaps or detergents. Just wipe the case with a soft cloth.
- Make sure the mophie powerstation go air’s charging ports do not
become contaminated with lint or other debris. Use a canned-air type of
product periodically to ensure that the port openings are clear.
- When using the air compressor, always check and follow the
manufacturer’s recommended pressure. Use caution as the air hose and
connectors may get hot after extended use.
- Batteries should be recycled or disposed of as per state and
local guidelines.
- Storage: -4°F - 158°F (-20°C - 70°C), Discharge: 14°F - 122°F (-10°C - 50°C),
Charge: 32°F - 113°F (0°C - 45°C)
PROJECT: PS-GO-AIR | QSG DIMENSIONS: 112mm x 178mm BLEED: .125 CREATIVE DESIGNER: Sarah PRODUCTION ARTIST: Sarah PDM: Jessica / Mike PCM: Kaitlyn DATE: January 7, 2021 2:38 PM ARENA: 314-00934 REV: A
SPECIAL INSTRUCTIONS: • Saddle Stitched booklet, 20 pages. • RevA1_121820 • Shared across all HSN SKUs:
401107388, 401107389, 401107390, 401107391, 401107392, 401107393, 401107429
COLORS: CMYK+ Pantone 377C
powerstation go air | HSN | Quick Start Guide
English

6 7
Included items
- mophie powerstation go air
- Jumper Cables
- Carrying Pouch
- AC Wall Plug
- 24in Air Hose Extension
- Interchangeable Air Nozzle Kit
1 | Jump Start Output
2 | Jump-Start Button
3 | Digital Screen
4 | Pressure Unit Button
5 | USB Outputs
6 | Pressure Settings (+) and (-)
7 | Air Compressor ON/OFF Button
8 | USB ON/OFF Button
9 | Air Hose
10 | Charging Input
11 | Floodlight ON/OFF Button
12 | Floodlight/Emergency Light
13 | 24 Inch Air Hose Extension
14 | Jumper Cable Clamps
15 | Wall Charging Adapter
16 | Tapered Air Nozzle
17 | Ination Needle
18 | Presta Valve Adapter
1
2
6
34
7
5
8
9
10
11
12
13
14
15 16
17
18
PROJECT: PS-GO-AIR | QSG DIMENSIONS: 112mm x 178mm BLEED: .125 CREATIVE DESIGNER: Sarah PRODUCTION ARTIST: Sarah PDM: Jessica / Mike PCM: Kaitlyn DATE: January 7, 2021 2:38 PM ARENA: 314-00934 REV: A
SPECIAL INSTRUCTIONS: • Saddle Stitched booklet, 20 pages. • RevA1_121820 • Shared across all HSN SKUs:
401107388, 401107389, 401107390, 401107391, 401107392, 401107393, 401107429
COLORS: CMYK+ Pantone 377C
powerstation go air | HSN | Quick Start Guide
English

8 9
While charging, the digital screen will illustrate
the charge percentage of the powerstation go
air. When fully charged, disconnect the cable.
Operating instructions
IMPORTANT: Before using the powerstation go air for the rst time, fully
charge it.
To charge your powerstation go air, use the provided Wall Charging
Adapter, and plug the AC adapter plug into the charge input. Next,
connect the AC adapter into a wall outlet. The powerstation go air will
automatically begin charging. When the powerstation go air is fully
charged, all ve battery indicator lights will be solid white and the digital
screen will indicate 100% charge. (This could take up to 9 hours).
NOTE:
The powerstation go air is designed to charge
between 32°F-113°F (0-45° C). A “TEMP”
indicator will be illustrated on the digital display
if the powerstation go air is attempted to be
charged outside of this temperature range.
Jump starting your vehicle with the powerstation go air
1. Plug the jumper cables into the jump start output on the powerstation
go air.
NOTE: Make sure the jumper cables are fully plugged into the jump start
output before trying to jump your vehicle.
2. Attach the jumper-cable clamps to the vehicle battery.
- Red clamp on positive terminal (+)
- Black clamp on negative terminal (-)
NOTE:
Once the jumper cable clamps are attached to the vehicle battery, the LCD
will display the vehicle battery voltage.
- Do not touch red (positive) and black (negative) clamps together at any
point. If the jump start button ashes red, the jumper cables have been
connected incorrectly. If this ashing red condition occurs, disconnect
the jumper cables from vehicle battery and restart the process from
Step 1.
PROJECT: PS-GO-AIR | QSG DIMENSIONS: 112mm x 178mm BLEED: .125 CREATIVE DESIGNER: Sarah PRODUCTION ARTIST: Sarah PDM: Jessica / Mike PCM: Kaitlyn DATE: January 7, 2021 2:38 PM ARENA: 314-00934 REV: A
SPECIAL INSTRUCTIONS: • Saddle Stitched booklet, 20 pages. • RevA1_121820 • Shared across all HSN SKUs:
401107388, 401107389, 401107390, 401107391, 401107392, 401107393, 401107429
COLORS: CMYK+ Pantone 377C
powerstation go air | HSN | Quick Start Guide
English

10 11
3. Press the“Jump Start” button and wait for a solid green light.
NOTE: A ashing green light indicates safety checks are in progress.
Do not disconnect the jumper cables when the Jump-Start button is
illuminated solid green. If you wish to cancel a jump-start attempt, simply
press the Jump-Start button again and the solid green light will turn o
indicating that the jump-start attempt has been cancelled.
4. Start your vehicle.
NOTE: If your vehicle fails to start after the rst attempt, wait 30 seconds and
repeat step 3 and step 4. If your vehicle does not start after three attempts,
we recommend you consult a certied mechanic.
5. Disconnect the jumper-cable clamps from the car battery.
NOTE:
- The jump start function can not be used in conjunction with USB
charging or the air compressor. Please ensure that you have not activated
the USB or Air Compressor output modes when attempting to jump start
your vehicle.
- When attempting to jump-start your vehicle, turn o your headlights
and any other components that may drain your car battery.
- The powerstation go air is designed to allow a jump start when used
within a safe temperature range. A“TEMP” indicator will be illustrated on
the digital display if used outside of the temperature operating range.
Jump start troubleshooting tips
Condition Potential Cause Solution
The Jump-Start button has been
pressed but nothing happens
The USB ON/OFF Button or
the Air Compressor ON/OFF
Button has been pressed.
The jump start output can not
be used in conjunction with the
USB output or air compressor
modes. Ensure that both USB and
AIR Compressor modes are o.
powerstation go air displays a
red “BATT TOO LOW” message
The powerstation go air is
not suciently charged to
jump start the vehicle.
Recharge the powerstation go air
and verify at least 50% charged. Then
try the jump start process again.
powerstation go air Jump
Start button ashes red
and a SAFETY CHECK FAIL
message is displayed The jumper cables have not
been properly connected
to the vehicle battery.
Check the jumper cables and ensure
that the red clamp is connected
to the positive terminal (+) and
the black clamp is connected
to the negative terminal (-).
powerstation go air Jump
Start button ashes
green continuously The powerstation go air is
waiting to be connected to
a battery or a SAFETY CHECK
FAIL has been triggered.
Check the jumper cables and ensure
they are properly connected to the
battery. Check and ensure the vehicle
battery voltage is greater than 2.0V.
If the SAFETY CHECK FAIL indicator
is triggered during the jump start
process, it is recommended that you
consult with a certied mechanic.
powerstation go air displays a
blue or red “TEMP”indicator The powerstation go air
has detected a low or high
temperature condition.
Disconnect the powerstation go
air and allow unit to acclimate
to temperature operating range
(14°F-122°F) (-10°C - 50°C).
You can not successfully
jump start your vehicle.
The powerstation go air
displays a vehicle battery
voltage greater than 12.0V
The powerstation go air
detects that it is connected
to a vehicle battery with a
normal starting voltage. This
could indicate that another
vehicle component is faulty.
It is recommended that you consult
with a certied mechanic.
powerstation go air Jump
Start and On/O button
ashes red and white
This could occur when
attempting to jump start a
vehicle while other electrical
components (i.e. headlights,
heater, radio, etc.) are on.
Turn o your headlights and
any other components that may
drain your car battery and try
the jump start process again.
The vehicle battery
may be faulty.
It is recommended that you consult
with a certied mechanic.
NOTE: If none of these troubleshooting tips work, please consult a certied
mechanic for assistance.
PROJECT: PS-GO-AIR | QSG DIMENSIONS: 112mm x 178mm BLEED: .125 CREATIVE DESIGNER: Sarah PRODUCTION ARTIST: Sarah PDM: Jessica / Mike PCM: Kaitlyn DATE: January 7, 2021 2:38 PM ARENA: 314-00934 REV: A
SPECIAL INSTRUCTIONS: • Saddle Stitched booklet, 20 pages. • RevA1_121820 • Shared across all HSN SKUs:
401107388, 401107389, 401107390, 401107391, 401107392, 401107393, 401107429
COLORS: CMYK+ Pantone 377C
powerstation go air | HSN | Quick Start Guide
English

12 13
Charging an electronic device using the USB output ports
1. Your powerstation go air is compatible with the charging cable provided
with your electronic device. To use, plug the Standard USB end of the
cable into either one of the two 5V/2.4A USB Output ports located on
your powerstation go air.
2. Turn on the USB charging by pressing the USB Power ON/OFF Button on
the powerstation go air.
NOTE: The powerstation go air USB charging feature will automatically
power o after 30 minutes of inactivity.
powerstation go air compressor
The powerstation go air comes equipped with a 24 Inch Air Hose Extension
and Interchangeable Air Nozzles. Simply twist on the corresponding nozzle
to inate balls, pool oaties, bike tires, and more!
1. Connect the air hose to the tire or use the appropriate nozzle to connect
to your inatable device.
2. Press the (+) or (-) button to set the desired pressure. The pressure
measuring units can be changed by pressing the UNIT button.
3. Once the desired pressure has been set, begin inating by pressing
the Air Compressor ON/OFF button. The air compressor will shut o
automatically once the pressure has been reached.
NOTE: The air compressor can be started or stopped at any point by
pressing the air compressor ON/OFF button. The (+) and (-) may be long
pressed to set the desired pressure quickly.
Note: Always check and follow the manufacturer’s recommended
pressure. Use caution as the air hose and connectors may get hot after
extended use. The powerstation go air compressor is designed to
automatically stop after an extended run-time or if an over-temperature
protection set point is reached.
PROJECT: PS-GO-AIR | QSG DIMENSIONS: 112mm x 178mm BLEED: .125 CREATIVE DESIGNER: Sarah PRODUCTION ARTIST: Sarah PDM: Jessica / Mike PCM: Kaitlyn DATE: January 7, 2021 2:38 PM ARENA: 314-00934 REV: A
SPECIAL INSTRUCTIONS: • Saddle Stitched booklet, 20 pages. • RevA1_121820 • Shared across all HSN SKUs:
401107388, 401107389, 401107390, 401107391, 401107392, 401107393, 401107429
COLORS: CMYK+ Pantone 377C
powerstation go air | HSN | Quick Start Guide
English

14 15
mophie smart charge technology
Your powerstation go air contains mophie SMART CHARGE TECHNOLOGY
to achieve greater compatibility for charging standard 5V USB electronic
devices. mophie SMART CHARGE TECHNOLOGY will allow the powerstation
go air to communicate with your electronic device and provide the fastest
and safest charge for that device.
Compatibility
Standard 5V USB electronic devices including: mobile phones, tablets, PSP,
NDS, MP3, MP4, MP5, Bluetooth, GPS, cameras, and more.
Using your powerstation go air oodlight
The oodlight can be turned on and o by simply pressing and releasing
the oodlight ON/OFF button. The rst press will turn on the oodlight.
Second press will turn on the red emergency light. Third press will turn
on SOS ashing red light. The oodlight will automatically turn o after 2
hours of inactivity.
NOTE: Do not look directly into the LED oodlight.
Tablets Smartphones Digital Camera Headphones
Mobile Gaming Wearables
Floodlight On/O Button
Specications
Battery Pack Energy: ............................. contains a 55500 mWh internal battery
Jump Start: ................................................................................................. 12V/600Amps
Air Compressor: ............................................................................................. 100PSI max
Input: .................................................................................................................... 14V/0.85A
USB Output: ............................................................................................ 2 x USB 5V/2.4A
Dimensions: ........................................................................... 4.65 x 9.52 x 1.85 inches
Weight: ..................................................................................................................... 2.54 lbs
Operating Temperature (During Charging): ............... 32°F - 113°F (0°C - 45°C)
Operating Temperature: ................................................ 14°F - 122°F (-10°C - 50°C)
PROJECT: PS-GO-AIR | QSG DIMENSIONS: 112mm x 178mm BLEED: .125 CREATIVE DESIGNER: Sarah PRODUCTION ARTIST: Sarah PDM: Jessica / Mike PCM: Kaitlyn DATE: January 7, 2021 2:38 PM ARENA: 314-00934 REV: A
SPECIAL INSTRUCTIONS: • Saddle Stitched booklet, 20 pages. • RevA1_121820 • Shared across all HSN SKUs:
401107388, 401107389, 401107390, 401107391, 401107392, 401107393, 401107429
COLORS: CMYK+ Pantone 377C
powerstation go air | HSN | Quick Start Guide
English

16 17
Compliance with FCC Regulation
This device complies with part 15 of the FCC Rules and RSS-Gen of IC Rules.
Operation is subject to the following two conditions:
(1) This device may not cause harmful interference, and
(2) this device must accept any interference received, including
interference that may cause undesired operation.
NOTE: This equipment has been tested and found to comply with the limits
for a Class B digital device, pursuant to part 15 of the FCC Rules. These
limits are designed to provide reasonable protection against harmful
interference in a residential installation. This equipment generates, uses,
and can radiate radio frequency energy and, if not installed and used in
accordance with the instructions, may cause harmful interference to radio
communications. However, there is no guarantee that interference will not
occur in a particular installation.
If this equipment does cause harmful interference to radio or television
reception, which can be determined by turning the equipment o and on,
the user is encouraged to try to correct the interference by one or more of
the following measures:
- Reorient or relocate the receiving antenna.
- Increase the separation between the equipment and receiver.
- Connect the equipment into an outlet on a circuit dierent from that to
which the receiver is connected.
- Consult the dealer or an experienced radio/TV technician
for help.
CAUTION: To comply with the limits of the Class B digital device, pursuant
to Part 15 of the FCC Rules, this device must be used with certied
peripherals and shielded cables. All peripherals must be shielded and
grounded. Operation with non-certied peripherals or non-shielded cables
may result in interference to radio or reception.
Limited warranty
At mophie, we are dedicated to making the best quality products. To back
this up, this product is warranted for 2 years. For full details regarding
warranty terms, exclusions and limitations, please visit: mophie.com/
warranty. This warranty does not aect any statutory rights that you may
be entitled to. Keep a copy of your purchase receipt as proof of purchase.
Be sure to register your product at mophie.com.
PROJECT: PS-GO-AIR | QSG DIMENSIONS: 112mm x 178mm BLEED: .125 CREATIVE DESIGNER: Sarah PRODUCTION ARTIST: Sarah PDM: Jessica / Mike PCM: Kaitlyn DATE: January 7, 2021 2:38 PM ARENA: 314-00934 REV: A
SPECIAL INSTRUCTIONS: • Saddle Stitched booklet, 20 pages. • RevA1_121820 • Shared across all HSN SKUs:
401107388, 401107389, 401107390, 401107391, 401107392, 401107393, 401107429
COLORS: CMYK+ Pantone 377C
powerstation go air | HSN | Quick Start Guide
English

18 19
PROJECT: PS-GO-AIR | QSG DIMENSIONS: 112mm x 178mm BLEED: .125 CREATIVE DESIGNER: Sarah PRODUCTION ARTIST: Sarah PDM: Jessica / Mike PCM: Kaitlyn DATE: January 7, 2021 2:38 PM ARENA: 314-00934 REV: A
SPECIAL INSTRUCTIONS: • Saddle Stitched booklet, 20 pages. • RevA1_121820 • Shared across all HSN SKUs:
401107388, 401107389, 401107390, 401107391, 401107392, 401107393, 401107429
COLORS: CMYK+ Pantone 377C
powerstation go air | HSN | Quick Start Guide
English

Customer Service
Telephone: 1-888-8mophie (1-888-866-7443)
International: [phone]
Web: www.mophie.com/cs
© 2020 mophie inc. mophie, powerstation, Stay Powerful, and the mophie logo are
trademarks of mophie inc. All rights reserved. Patents: mophie.com/patents.
314-00934-A
PROJECT: PS-GO-AIR | QSG DIMENSIONS: 112mm x 178mm BLEED: .125 CREATIVE DESIGNER: Sarah PRODUCTION ARTIST: Sarah PDM: Jessica / Mike PCM: Kaitlyn DATE: January 7, 2021 2:38 PM ARENA: 314-00934 REV: A
SPECIAL INSTRUCTIONS: • Saddle Stitched booklet, 20 pages. • RevA1_121820 • Shared across all HSN SKUs:
401107388, 401107389, 401107390, 401107391, 401107392, 401107393, 401107429
COLORS: CMYK+ Pantone 377C
powerstation go air | HSN | Quick Start Guide
English
