Morel Elate Carbon/Pro 52 User manual

Elate Carbon
Installation Guide
Elate Carbon / Pro
Components
52, 62, 53, 63, 93, 52A,
62A, 53A, 63A, 93A
Alto tweeter, MT450,
MW5, MW6, MW9, MM3,
MXT280C, MXT380C

Dear Customer,
Thank you for choosing Morel for your car audio speaker solution.
Morel prides itself on engineering and producing the best high-fidelity speaker systems.
We hope you enjoy your Elate Carbon speakers for years to come.
If you have any questions, please contact your Morel dealer or Morel support at:
www.morelhifi.com

Elate Carbon Components
Elate Carbon MW5, MW6, and MW9 Woofer MT450 Tweeter
MXT380c/MXT280c Crossover MM3 MidrangeAlto Tweeter (PRO line only)
X2
X6 X6
X2 X2 X2
X4
X2
X2
X2
X2 X2
(6”) (5”, 9”)
X8
X6
X8 X2 X2
X6
X2X2 X2 X2
X8X2 X8

MW6 woofer
Woofer, Midrange and Alto Tweeter mounting
MM3
MW5 and MW9 woofer
5”: ø122mm (4.80”)
9”: ø192mm (7.56”)
6”: ø141mm (5.55”)
MM3: ø83mm (3.3”)
Add black tack
in 5 spots
Add black tack
in 5 spots
Add black tack
in 5 spots
ø55mm (2.16”)
Alto Tweeter

1 2
CLICK
ø47mm (2”)
3 4
25mm (1”)
1 2 3
MT450 Flush Mount MT450 Surface Mount
MT450 Tweeter and Crossover Mounting
Crossover mounting

2-WAY Crossover Alignment System 3-WAY Crossover Alignment System
2-WAY Systems Crossover 3-WAY Systems Crossover
Standard wire connection/
With bridged jumpers
Bi wire connection/
No bridged jumpers
Bi Amp connection/
No bridged jumpers
1 2 3 Standard wire connection/
With bridged jumpers
Bi wire connection/
No bridged jumpers
Bi Amp connection/
No bridged jumpers
1 2 3
x2 x2
Use the red jumper to
determinate the tweeter
level Use the red jumper to
determinate the tweeter
level
Use the red jumper to
determinate themidrange
level
Crossover Connections

Specications
Nominal Impedance (ohm) 4
Power Handling Wrms
Max. Trans. Pwr Handling Wrms
160
Sensitivity (2.83 V/1M) dB
1000
Frequency response Hz
85
Resonant Freq. Fs Hz
40-5000
64.4
Voice Coil Diameter mm (inch) 75 (3)
Voice Coil Height mm (inch) 14.50 (0.57)
Voice Coil Type/Former
Voice Coil Wire
DC Resistance (ohm) 3.6
Voice Coil Induct. @1 kHz (mH) 0.615
Magnet System
HE-Magnetic Gap Height mm (inch) 5 (0.20)
B-Flux Density (T) 0.66
BL Product/BXL 5.15
Max. Linear Ex./Xmax mm (inch) ±4.75mm (0.18)
Suspension Compliance CMS - mm/N 0.35
Electrical Q Factor QES 0.63
FS Hz
Voice Coil Diameter mm (inch)
Voice Coil Former
Voice Coil Wire
DC Resistance ohm
Magnet System
Dome Type
Dome Material
Unit Diameter mm (inch)
Mounting Depth mm (inch)
Mounting Cutout mm (inch)
Net Weight Kg (lb)
6
130
350
91
1400-25000
1000
28 (1.25)
Aluminium
HexatechTM Aluminium
5.2
Neodymium Rear Vented
AcuflexTMhand coated soft dome AcuflexTMhand coated soft dome
Silk
43.00 (1.69)
13.2 (0.52)
47.00 (2)
0.07 (0.15)
6
220
1000
91
1400-25000
900
28 (1.125)
Aluminium
HexatechTM aluminium
5.2
Neodymium rear
chamber underhung
Silk
67.00 (2.6)
32.00 (1.25)
55 (2.16)
0.35 (0.77)
QTS 0.56
QMS 4.15
Mech. Resistance RMS- N . S / M 1.32
Moving Mass MMS - gr/ounce 17(0.59)
Equiv. Can Air Load VAS - L (cu.ft3)4.5 (0.6)
Effective Piston Area SD sq.cm (sq.inch) 90 (13.95)
Cone Type Triple Layer Cone (TLC)
Cone Material Carbon Fibre composite Carbon Fibre composite Carbon Fibre composite
Unit Diameter mm(inch) 135 (5.25)
Mounting Depth mm (inch) 60 (2.36)
Mounting Cutout 120 (4.72)
Net Wight Kg (lb) 1.05 (2.31)
4
180
1000
87
30-4000
45
75 (3)
14.50 (0.57)
Titanium TitaniumTitanium
HexatechTM Aluminium HexatechTM AluminiumHexatechTM Aluminium
3.6
0.615
Neodymium Neodymium Double
magnet rear vented
Neodymium
5 (0.20)
0.75
6.51
±4.75mm (0.18)
0.67
0.47
0.43
7.19
1
18 (0.63)
13.3 (0.47)
120 (18.6)
Triple Layer Cone (TLC)
165 (6.50)
61 (2.40)
141 (5.55)
1.18 (2.60)
4
200
1000
89
25-3000
44
75 (3)
14.50 (0.57)
3.6
0.615
5 (0.20)
0.74
5.15
±4.75mm (0.18)
0.36
0.61
0.56
6
1.2
30 (1.05)
30.9 (1.1)
219 (33.95)
Triple Layer Cone (TLC)
222 (8.75)
71 (2.80)
192 (7.56)
1.42 (3.13)
Active Conguration
Elate Carbon:
53A, 63A, 93A
Setting up the Elate Carbon system using an external electronic crossover
network may very depending on the processor itself, the car cabin acoustic
attributes, and the mounting location of the drive units.
Choosing proper crossover points and slopes can greatly affect system
performance.
The following guidelines should be used to assure each drive unit in the
system performs to the highest level. The Optimal Crossover Point/Slope
guide should be used for most vehicle applications.
Advanced users may refer to the Recommended Crossover Range/Mini-
mum Slope guide for fine system tuning.
Optimal Crossover Point//Slope
Tweeter highpass: 3300Hz/12dB
Midrange lowpass: 3300Hz/12dB
Midrange highpass: 450Hz/12dB
Woofer lowpass: 450Hz/12dB
* Woofer highpass: 40Hz/12dB
Reccomended Crossover
Range/Minimum Slope
Tweeter highpass: 18000Hz-4000Hz/12dB
Midrange lowpass: 18000Hz-4000Hz/6dB
Midrange highpass: 300Hz-750Hz/12dB
Woofer lowpass: 350Hz-750Hz/6dB
* Woofer highpass: 40Hz-80Hz/12dB
Optimal Crossover Point//Slope
Tweeter highpass: 2000Hz/12dB
Woofer lowpass: 1800Hz/12dB
* Woofer highpass: 60Hz/12dB
Reccomended Crossover
Range/Minimum Slope
Tweeter highpass: 18000Hz-3000Hz/12dB
Woofer lowpass: 18000Hz-3000Hz/6dB
* Woofer highpass: 40Hz-80Hz/12dB
* When used with an active subwwofer system.
ELATE CARBON MW5 ELATE CARBON MW6WOOFERS ELATE CARBON MW9
Carbon Fibre composite
Aluminium
HexatechTM Aluminium
Neodymium
4
120
400
85
40-6000
93.6
54 (2.125)
10 (0.4)
3
0.175
4
0.94
4.2
±3mm(0.12)
0.54
0.54
0.45
2.66
1.17
5.3(0.21)
1.15(0.05)
38(1.5)
Triple Layer Cone (TLC)
100 (3.90)
38 (1.50)
83 (3.3)
0.38 (0.84)
ELATE CARBON MM3
W: 2500Hz/12dB
T: 2500Hz/12dB
W: 450Hz/12dB
M: 450Hz/12dB
2700Hz/12dB
T: 2700Hz/12dB
Crossover Controls Tweeter +/- 2dB Tweeter +/- 2dB
Mid 0/- 2dB
Wiring Options
* Morel operates a policy of continuous products design improvement, consequently specifications are
subject to alteration without prior notice
Bi wire / Bi amp Bi wire / Bi amp
MT450MIDS & TWEETERS ALTO
MXT280C MXT380CCROSSOVERS
Crossover Point
Nominal Impedance (ohm)
Power Handling Wrms
Max. Trans. Pwr Handling Wrms (10ms)
Sensitivity (2.83 V/1M) dB
Frequency Response Hz
Elate Carbon:
52A, 62A, 92A

Wishing you many years of sound enjoyment!
Morel America, Chandler, AZ, USA
Toll free number:1-877-667-3511
Fax: [phone]
E-mail: [email protected]
www.morelhifi.com
Morel, Ness Ziona, 70400 Israel.
Tel: [phone]
Fax: [phone]
E-mail: info@morelhifi.com
