Moretti Reverso Manual

NOTICE D’ASSEMBLAGE
INSTRUCTIONS GUIDE
Table multi-jeux 4en1 - Modèle Reverso
x2

#4#3#2#1
#5 #6 #7 #8
#9 #10 #11 #12
#13
Leg Levelers
4pcs
Brush
1 pc
Cue
2 pcs
Chalk
2 pcs
2 pcs
Right Leg
2 pcs
Left Leg
Pool Balls
1 set 1 pc
Plastic triangle
#14 #15 #16
#17 #18 #19 #20
#21 #22 #23 #24
Table Tennis Bat
2 pcs
Table tennis ball
2 pcs
Table tennis
2 pcs
1 pc
Table Tennis Net
1 pc
Leg Support Panel
with Holes
Leg Support Panel
(no holes)
1 pc
Air Hockey Side
1 pc
T-shape Panel
2 pcs
Goal End Box
2 pcs
Table Tennis Support
4 pcs
2 pcs
Net Supprt Posts
2 pcs
Cue clip-Large Cue clip-Small
2 pcs 1 pc
Double Tier Ball Storage
1 pc
singleTier Storage
Billiard Table
1 pc

#28#27#26#25
#29 #30 #31 #32
#33 #34 #35 #36
#37
Allen Key
1 pc
Pusher Puck
2 pcs 2 pcs
Washer 5/16"X23mm
8 pcs
8 pcs
Bolt 5/16"X28mm
8 pcs
Bolt 1/4 "X51mm
Screw F4x45mm
8 pcs
Screw T4x45mm
12 pcs
Screw T4x32mm
20 pcs
Screw F3x12mm
8 pcs
#38
Screw T4x16mm
4 pcs
Washer 1/4"X16mm
8 pcs
Cable Clip
1 pc
Screw T4x12mm
1 pc

Step 1 -
TIP: Remember to leave the pilot holes on leg support panel #9 facing out
#6
#6 #7
#7
#8
#8
#9
#10
#15
#15
#1
#15
#15
#29 #30
#31
#38
Step 2 -
! MINIMUM OF TWO PEOPLE REQUIRED !

Step 3 -
#5
#5
#32
#32
#34

Step 5 - Fixing down the air hockey side
IMPORTANT: Make sure the air hockey power cable is passed through the exit hole pri-
-
from the ends.
#33
#27
#28
IMPORTANT -
ing the top down.
-
Step 4 #2

Step 7 - How to install the table tennis table
#3
#4
#11
#3
#3
#12
#12
Step 6
#33

Step 8 -
#13
#14
#16
#17
#35
#36
#36

User Guide
Changing Games
The Strikeworth 6 mulgame uses a rotang system to quickly change from one game
to another in less than 1 minute.
Starng with the pool table side facing up, ensure all pool balls are cleared from the
pockets and placed on the storage racks provided at the ends of the table. Secondly
ensure the air hockey power cable has been stowed away in the opening provided on
the side of the table. Now release the silver support aps from each corner of the table
and very gently rotate the games table over. Once the table is at and aligned, re seat
the silver support aps in place (Note : it may be necessary to slightly li the table in
order for the aps to close easily - this is completely normal due to the ght t re-
quired.
Using the Air Hockey Table
The air hockey table requires the power cable to be plugged in to drive the fan mount-
ed on the underside of the play surface, the fan drives air up through the table and al-
lows the pucks to oat across the surface. The cable linked to the fan must be stowed
in the opening provided on the side of the table during rotaon of the table.
Use of the Table Tennis
The table tennis tops are designed to sit on to the pool table side of the mulgame ta-
ble (Not the air hockey side). The tops simply sit on the pocket liners on the pool table
however addional supports for the pool table are also provided and can placed onto
the pool table surface if required. The net posts simply slide onto the edges of the ta-
ble tennis and the net can be ed to the posts using the elascated loops of material.
Safety Warnings
• Rotang tables have pinch points
• Please ensure children are fully supervised when rotang this table
• Keep hands away from the table ends when the table is being rotated
• Please do NOT sit or lean on the sides of this table - this table rotates and
is not designed to carry excessive weight
• Avoid drink or general liquid spills - the air hockey part of this table is elec-
trical
• Only use this table indoors - this table is NOT designed for outdoor use.
