Morga MPC-136A User manual

USER MA UAL
Pr ssur
Cook r MPC-136A
E-mail: [e-mail]
www.morgan.my
Market Expansion
Services by
www.dksh.com.my
facebook.com/morganappliances

32
Thank you for purchasing a quality MORGA appliance. We trust that you will have a pleasant
experience with your new product. To guarantee safety and best efficiency, please read this
manual carefully and keep a copy for future reference.
PARTS IDENTIFICATION
SPECIFICATIONS
C O N T E N T S
3
3
4
4
6
6
7
8
10
11
PARTS IDENTIFICATION
SPECIFICATIONS
INTRODUCTION TO THE PRESSURE COOKER
I PORTANT SAFEGUARDS
ABOUT THE INNER POT
BEFORE FIRST USE
USING THE PRESSURE COOKER
OPERATING INSTRUCTIONS
CARE & CLEANING
TROUBLE SHOOTING
1. Exhaust Valve
2. Open Handle
3. Seal Ring
4. Lid
5. Float
6. Anti-blocking Cover
7. Aluminum Alloy Coated Non-stick
Inner Pot
8. Base
9. Control Panel
10. Power Cord
11. Rice spoon
12. easuring cup
13. Dew collector
1
3
7
8
2
4
5
6
9
10
1
11 12 13
MODEL MPC-136A
RATED VOLTAGE / FREQUE CY 220-240V~ 50/60Hz
RATED WATTAGE 1000W
CAPACITY 6.0L

54
INTRODUCTION TO THE PRESSURE COOKER IMPORTANT SAFEGUARDS
The pressure cooker is an all-purpose cooking unit that cooks food without the need for oxygen. Foods
cooked in a pressure cooker will retain color, flavor, vitamins and minerals because of the small amount
of liquid used and the quick cooking time. No salt nor additional fats or oils are needed. The cooking
process is fully automated. Depending on the chosen program, you can cook rice, beans/tendon, soups,
chicken/meat, stew, fish and many more.
ATTENTION!
For additional protection it is reasonable to install a residual current device (RCD) with nominal
operation current not exceeding 30 mA. To install RCD, contact an authorized technician.
IMPORTANT SAFEGUARDS
When using electric appliances, basic safety precautions should always be followed including
the following:
SAFETY PRECAUTIONS
1. Read all instructions carefully and retain them for future reference.
2. Before connecting to the power supply, ensure that the unit is earthed and its voltage corresponds
to the voltage indicated on the power supply rating label.
3. The power cord is equipped with a “BS” power plug built into the socket with a reliable grounding
contact.
4. Always disconnect appliance from the power supply when not in use or before cleaning.
5. It is recommended to use a dedicated power socket that is not shared with other electrical
appliances.
6. To protect against electric shock, do not immerse power cord, power plug, or any parts of the unit
in water or other liquids.
7. Do not operate the appliance with a damaged power cord or power plug or after it malfunctions or
has been damaged in any manner. In such a situation, it is recommended to return the unit to your
nearest Authorized Service Centre for examination, repair, or adjustment.
8. Do not connect this appliance into a power extension socket shared by other appliances. Use only
a dedicated power supply source.
9. Do not hang power cord over edge of table or counter or touch hot surfaces nor bend, twist or place
the power cord under the weight of sharp or heavy objects.
10. Use only the removable parts supplied with the unit.
11. Place the appliance on a flat heat-resistant surface away from moisture, heat sources and open
flame.
12. Operate the appliance in places with proper ventilation
13. Do not expose the appliance to direct sunlight
14. Do not locate the appliance close to walls and furniture. The gap between the pressure cooker body
and the wall or furniture should be at least 20cm and the gap above the pressure cooker should be
at least 30-40cm.
15. This appliance is meant only for indoor use. Do not use the it outdoors.
16. Do not touch the unit body, power cord or power plug with wet hands.
17. Never pull or yank the power cord to unplug it from the power supply or when moving the appliance.
18. Do not operate the appliance near containers filled with water, next to a kitchen sink, in wet
basements or near a swimming pool.
19. If the appliance is dropped into water, unplug it from the power supply immediately and retrieve it
from the water. Contact your authorized service center for the further inspection of the appliance.
20. Do not insert foreign objects into the steam release openings, and ensure no foreign objects get
stuck between the lid and body of the appliance.
21. Do not leave the operating unit unattended and always switch it off and unplug the unit when not in
use.
22. WARNING: Do not touch the lid, bowl and body is extremely hot during operation.
23. Exercise extra caution when touching hot surfaces.
24. Beware of hot steam escaping the floating valve and pressure regulator valve during cooking or
when opening the lid.
25. Keep hands and face away from the appliance to avoid hot steam and to prevent scalds during
operation.
26. Do not leave the pressure cooker lid open during the operation.
27. Never use the unit without the installed bowl and the pressure control valve. Do not switch the
appliance on without food and liquids in the inner pot.
28. Do not use the appliance if the power plug, power cord, inner pot, sealing ring or the main body is
damaged.
29. Follow the recommended amounts of dry products and liquids.
30. Do not remove the inner pot during operation.
31. Do not place the appliance on other household equipment.
32. Do not exceed the maximum water level indicated in the inner pot to prevent overflow.
33. Do not place the cooking utensils inside the pot while cooking.
Attention! When cooking food, watch the level of liquid in the bowl, add water to the bowl as needed.
Do not leave the unit unattended!
34. Never carry or lift the appliance by the handle on the lid.
35. Be very careful when opening the appliance’s lid. Rotate the pressure control valve carefully and
wait for pressure to be released before opening the lid.
36. Always keep the pressure control and lid blocking system valves clean.
37. Clean the appliance regularly to ensure optimal performance.
Attention! Do not allow children to play with polyethylene bags or packaging film. Danger of
suffocation!
38. Do not carry or move the appliance during operation. To move it, first unplug it from the power
supply, release the pressure, and empty all contents from the inner pot before carrying it and placing
on a heat-resistant surface.
39. This appliance is not intended for use by persons (including children) with reduced physical, sensory
or mental capabilities or lack of experience and knowledge, unless they have been given
supervision or instruction concerning use of the unit by a person responsible for their safety.
40. Do not attempt to repair the unit yourself. Contact an authorized service center for all repair issues.
41. Keep the unit in a dry cool place out of reach of children and disabled persons.
THE U IT IS I TE DED FOR HOUSEHOLD USE O LY

7
USING THE PRESSURE COOKER
6
ABOUT THE INNER POT
• The use of the inner pot and its parts are for the intended purposes only. Do not use the inner pot for
cooking food on heating units or cooking surfaces.
• Do not replace the inner pot with another container.
• Ensure the heating element surface and bottom of the inner pot is clean and dry.
• To avoid damaging the non-stick coating, do not use the inner pot for washing and mixing products.
Never chop products in the inner pot.
• Never leave or keep any foreign objects in the inner pot.
• When cooking, stir the products in the inner pot only with a plastic spatula.
• Do not use metal objects which can scratch the non-stick coating of the inner pot.
• Wash the inner pot immediately after cooking dishes with spices and seasonings.
• To avoid damaging the inner pot coating, do not immerse it under cold water immediately after
cooking. Allow it to cool down before washing.
•The inner pot is not dishwasher safe.
• ATTENTION! During first use, the heating element may discharge an odor. This is normal.
• Never leave the operating unit unattended.
• To cancel a current operation mode, press and hold the Keep Warm/Cancel button.
• NOTES:
– Although the appliance features a 24-hour Keep Warm function, it is not advisable to leave cooked
food in the inner pot overnight as it may spoil the food.
– Do not use the keep warm function for heating up foods.
• Pressure modes in the inner pot
– If pressure control valve is locked, the appliance will cook using maximum pressure.
• Loading foods and connecting to the power supply Notes:
– Ensure there are no foreign objects, dirt or moisture on the heating element and on the bottom of
the inner pot.
– Wipe the outer surface and the bottom of the inner pot dry before use.
– Do not allow obstructions on the temperature sensor located in the middle of the heating element.
– Ensure that the level of ingredients and liquids does not exceed the maximal mark and is not lower
than the minimal mark.
– Example: To cook rice, measure rice using the measuring cup, and fill water level following the
scale inside the bowl:
– Water level is given in cups «CUP». Pour water up to the corresponding mark.
– Example: After putting four measuring cups of cereal, pour water till the mark «4 CUP».
– For porridge it is recommended to use rice and water in the proportion of 1:3.
– Remove the lid by turning the lid in clockwise direction.
– Detach the inner pot and place food into the inner pot.
– Insert the inner pot into the heating element.
• Before installing the inner pot, ensure that the outer surface is clean and dry, and is in secure contact
with the surface of the heating element.
• Before installing the lid, check the valve and the blocking system elements. They should be clean and
the blocking system valve should be lowered.
• Place the lid on the unit and turning in the anticlockwise direction to lock it.
• Press ON/OFF button, “00:00” will show on the display screen. Then you can start cooking as
following instruction in different situation.
• Unpack the unit, remove any stickers and packaging materials.
• Place the appliance on a flat, heat-resistant surface away from all kitchen heat sources (such as gas
cooker, electric cooker or cooking unit).
• Allow at least 20cm gap between the appliance body and wall, and 30-40cm gap above the unit.
• Do not place the appliance close to objects that can be damaged escaping hot steam.
Attention! Do not place the unit near bathtubs, kitchen sinks or other containers filled with water.
• Turn the lid in the direction of the symbol and detach it.
• Wash all removable parts with a soft sponge and a neutral detergent and rinse them under running
water and dry before reassembly.
• Remove the silicon lid gasket, wash with warm water and neutral detergent, then rinse, allow to dry
and reassemble.
• Clean the unit body with a damp cloth, then wipe it dry.
• ATTENTION: Do not leave the lid of the unit opened during operation.
BEFORE FIRST USE

8 9
OPERATING INSTRUCTIONS OPERATING INSTRUCTIONS
COOKING FUNCTION TIMES
COOKI G PROGRAMS A D THEIR DURATIO
Cooking program Temperature (ºC) Default time Cooking time
eat Chicken 100-110ºC 40 min 45 min
Beef 100-110ºC 40 min 45 min
Bean Tendons 100-110ºC 45 min 51 min
Cook w/oil 95-100ºC 21 min 21 min
Rice 100-110ºC 22 min 26 min
Porridge 100-110ºC 35 min 41 min
ultigrain Porridge 100-110ºC 45 min 50 min
Soup 100-110ºC 45 min 55 min
Cooking time: Heating time + keep pressure time.
ATTENTION!
• In cooking mode, if the air release valve is not positioned correctly, air will release automatically.
• In pressure holding mode, the heating plate will power on continuously (power off when pressure is
higher than the maximum operating pressure, and power on when pressure is lower than the
maximum operating pressure).
• In keep warm mode, the heating plate will power on continuously (power off when temperature is
higher than the keep warm temperature and power on when temperature is lower than the keep warm
temperature).
• If keep warm function is not required, power off and unplug the power cord.
OPENING THE LID
ATTE TIO ! Always follow the recommendations for opening the lid as below.
• Beware of hot steam released from the floating valve and pressure regulator valve when opening
the lid.
• Keep hands and face away from the appliance to prevent scalds from hot steam.
• Release the inner pot pressure by pressing on the pressure control valve.
• When no more steam is released, remove the lid by turning it in clockwise direction.
• Carefully use protective mitts to remove the inner pot.
• Unplug the appliance from the power supply as it cools down.
1. Connect the appliance to a power supply and it will go into power-off state with a beep.
– Press the “ON/OFF” button. The device will enter standby mode with a beep and the screen will
display “88:88”.
2. Select a function.
– Press a desired function button: Rice, bean/tendon, soup, chicken/meat, stew, fish.
3. If no any action within 10s, the cooking function will automatically activate.
PRESET TIME FUNCTION
1. Select a function.
2. Press the “PRESET / KEEP PRESSURE TI E” button and hold for a few seconds, the “PRESET /
KEEP PRESSURE TI E” button will illuminate, and the numbers on display will flash. Keep pressing
“+/-” button to choose the delay time you want.
3. If no any action, the unit will automatically start counting down the preset time.
Remarks:
• PRESET TI E function is to set how much later the device will start to work.
• Default preset time is 2 hours. aximum delayed-start time is 24 hours.
KEEP PRESSURE TIME FUNCTION
1. Select a cooking function or skip this step.
2. Press the “PRESET / KEEP PRESSURE TI E” button, the “PRESET / KEEP PRESSURE TI E”
button will illuminate, and the numbers “P:XX” on the display will flash. Keep pressing “+/-” button to
choose the delay time you want.
3. If no any action, the unit will automatically start heating or start counting down the default preset time.
Remarks:
• The unit will enter into keep pressure mode when inner pressure reaches the default pressure after
heating.
• Keep pressure time ranges from 1 min to 60 mins.
• Cooking time includes heating and keep pressure time.
KEEP WARM/CANCEL BUTTON
• When the appliance is in operation, press the “KEEP WAR /CANCEL” button to enter standby mode
and keep warm.
• After cooking completes, the appliance will automatically switch to keep warm mode, and the KEEP
WAR light will be lit.
• Keep warm for 10mins after switching to keep warm mode to make rice taste better.
• Do not keep warm for more than 12 hours.
• During keep warm mode, water droplets will appear on the edge of the inner pot.

10 11
CARE & CLEANING TROUBLE SHOOTING
PROBLEM POSSIBLE CAUSES SOLUTIO
Lid is difficult to close Sealing ring not properly Reposition the sealing ring correctly.
installed.
Floating valve stuck in upwards Push down the floating valve so that it
position. does not block the locking pin.
Difficult to open Pressure trapped inside the Use the steam release handle to reduce
the lid appliance. the pressure inside the appliance. Open
the lid after the pressure has completely
released.
Floating valve stuck in upwards Push down the floating valve lightly.
position.
Steam escapes from Sealing ring not installed. Install the sealing ring.
the side of the lid Sealing ring damaged. Replace the sealing ring.
Foreign objects stuck to the Clean the sealing ring.
sealing ring.
Lid not closed properly. Open and close the lid again.
Steam leaks from Food debris stuck on the floating Clean the floating valve silicone seal.
floating valve valve silicone seal.
Floating valve silicone seal worn Replace the floating valve silicone seal.
out
Float valve unable to Food or water below the Add more water or ingredients.
rise minimum level.
Floating valve obstructed by the Close the lid completely (see ”cooking
lid locking pin. preparation” section).
Steam escapes from Steam release handle not locked Turn the release handle to the sealing
floating valve in sealing position. position.
continuously Pressure control fail. Contact support online.
Heating element Lid not closed properly. Open then close the lid again.
does not heat up Heating element failure. Contact support online.
during operation
Circuit failure. Contact support online.
Display flashes “Lid” Lid is not locked at the correct Close lid for pressure cooking or open the
position for the selected program. lid for sauteing
Rice half cooked or Too little water. Adjust rice to water ratio according to too
hard recipe.
Cover opened too early. Leave cover on for 5 more minutes after
cooking completes.
Rice too soft Too much water. Adjust rice to water ratio according to
recipe.
• Disconnect the power cord from the power supply and allow the appliance to cool down completely.
• Discard any water remnants from the dew collector after every use.
• Wipe the appliance body and the lid using a damp cloth.
• Wash all removable parts including the inner pot with a soft sponge and neutral detergent, then rinse
under running water.
• Do not place the inner pot in the dishwashing machine.
• To clean the lid fully, perform the following steps:
– Detach the sealing ring from the lid and wash thoroughly.
– Detach the pressure control valve from the lid and wash it thoroughly.
– Wash the lid thoroughly, especially the valve with the blocking system and the pressure control
valve opening.
– Dry all parts thoroughly and reassemble back to their proper places.
• After appliance has cooled down completely, wipe the heating element surface with a soft and slightly
damp cloth. Do not allow water to seep inside the appliance body.
• Do not immerse the appliance body, power cord and power plug in water or any other liquids.
• Wipe the appliance body with a damp cloth and then wipe dry. Do not use abrasive detergents for
washing the unit and accessories.
STORAGE
• Unplug the unit and clean it.
• Keep the unit away from children in a dry cool place.
