PARTS IDENTIFICATION
DESCRIPTION:
• Modern and elegant design
• Multiple air-filtering system assures
hygienic cleaning
• Accessories: floor brush, nozzle etc.
• User-friendly wire rewinder pedal
IMPORTANT SAFETY INSTRUCTIONS
• If the supply cord is damaged,it must be replaced by the manufacturer or its service agent or a
similarly qualified person. This appliance is solely intended for household use only.
• Do not use for vacuuming detergent kerosene, glass,
needle, cigarette ash, water etc.
• The appliance should not be exposed to
extreme heat
* Features are subject to
change from time to time.
* Features shown here are
illustrative purposes only.
C O N T E N T S
3
3-4
4
5
5
6
6-7
7
Parts Identification
Important safety instructions
Important safety precautions
Vacuum Cleaner Assembly
Operating Instructions
Cleaning tools
Cleaning and maintenance
Troubleshooting
MVC-CC1601BL(IM)070114_Layout 1 1/27/14 4:05 PM Page 2

54
IMPORTANT SAFETY INSTRUCTIONS VACUUM CLEANER ASSEMBLY
• Do not vacuum any moist or liquid substances.
Never immerse the appliance in water.
• Unplug the appliance from the power socket after
every use and before cleaning.
• Pull and detach the power plug to disconnect the
appliance from the power socket.
IMPORTANT SAFETY PRECAUTIONS
• This appliance is not intended for use by persons (including children) with reduced physical, sensory
or mental capabilities, or lack of experience and knowledge, unless they have been given
supervision or instruction concerning use of the appliance by a person responsible for their safety.
• Children should be supervised to ensure that they do not play with the appliance.
• Do not insert any ob ect into the vents. Do not operate
appliance with any opening vents and always keep
appliance free of dust, lint hair etc.
CONNECT THE HOSE TO THE VACUUM CLEANER
• Insert flexible hose into the air-intake: press the knob until it clicks
into position.
• Remove the flexible hose: unplug the appliance and press the knob
at the end of the hose. Remove it from the air-intake opening.
OPERATING INSTRUCTIONS
• A yellow mark on the power cord shows the ideal cable length. Do
not expand the cable beyond the red mark.
• To rewind the power cord, press the rewinder pedal with one hand
and guide the cord with the other hand.
• Press the power switch to turn on the appliance.
• Use the speed selector to control the suction power of the cleaner.
• Alternatively, the suction power can be ad usted using the sliding
control on the angled pipe.
• Place the telescopic tube into the fixing hook of the appliance when
appliance is not in use.
• Caution: Do not move the appliance when the telescopic tube is still
attached to the fixing hook.
ATTACH THE TELESCOPIC TUBE TO THE ANGLED
PIPE
ATTACH THE FLOOR BRUSH TO THE TELESCOPIC
TUBE.
• Do not operate the appliance without the dust container
or dust bag.
• Do not vacuum any flour, cement etc. to prevent
overloads.
• The appliance should only be cleaned with a dry or damp
cloth.
• Never immerse in water or any other liquids. Do not use
any solvents for cleaning.
MVC-CC1601BL(IM)070114_Layout 1 1/27/14 4:05 PM Page 3

7
TROUBLESHOOTING
Before you contact our service centre, please ensure the following:
PROBLEM POSSIBLE REASON(S) ACTIONS
Motor does not start – Power cord not firmly plugged into – Plug unit firmly
power outlet – Check the power outlet
– Power outlet damaged – Switch on the appliance
Suction power is weak – Unit is clogged – Remove the blockage
– Dust filter needs cleaning – Clean the dust filter
– Dust container not securely positioned – Close the dust container
– Filter is blocked – Clean the filter
The power cord cannot be wound Cord may be twisted or detached from Draw the wire a little then rewind
completely the winding wheel
The power cord wire cannot Cord may be twisted or detached from Press the rewinder button and try again
be released the winding wheel
Speed selector does not function Appliance is defective Return the appliance to an authorized
service centre
Power cord winds back une pectedly Rewind mechanism is defective Return the appliance to an authorized
service centre
The dust container can not be closed Dust filter is not in the position Reposition the dust filter and retry
WARNING:
If the supply cor is amage , have it replace by the manufacturer, service agent or a
similarly qualifie person.
REPLACE THE OUTLET FILTER
• Detach the grille by pulling firmly away from the appliance, remove
the outlet filter and replace the new filter. Fix the grille again.
Dust Cup
Frame
CLEANING THE HEPA FILTER
• Clean the filter in water and allow them to dry completely
before replace them.
CLEANING THE DUST CUP
• Clean dust cup with water and a little detergent (if
needed). Allow the filter to dry completely before
replacing
6
CLEANING TOOLS
CREVICE TOOL
• For cleaning diificult to reach places such as corner edges, drawers, gaps,
keyboards, bookshelves or windows.
CONVERTIBLE BRUSH
• Turn the crevice tool 90° and attach it to the extension tube. This tool is ideal
for cleaning beds, sofa, couch etc.
CLEANING AND MAINTENANCE
EMPTYING THE DUST CONTAINER
• After removing the flexible hose, press the cover lock button and
open the dust container.
• Remove the dust filter from the container.
• Close the dust container until it is firmly locked to position.
REPLACE THE MOTOR FILTER
• Open the dust container and remove the motor filter. Fix the new filter
in the position
USE OF THE SELECTOR ON FLOOR
BRUSH
• Bristles extend for carpets. Bristles retract for
solid, hard floors
IF THE ANGLED PIPE IS BLOCKED
• Insert it into the air-intake and switch the appliance on to release
blockage
