Morgan MVC-P60 User manual

U ER MANUAL
MVC-P60
E-mail: [e-mail]
www.morgan.my
Market Expansion
Services by
www.dksh.com.my
facebook.com/morganappliances
2 in 1 Stick/
Han hel Vacuum
Cleaner

3
IMPORTANT SAFEGUARDS
Please read this instruction manual carefully and keep it in a safe place for future reference.
l emove all packing materials from this product before use.
l Ensure the voltage indicated on the product rating label is corresponds to the local power supply
voltage before operating the appliance.
l Always inspect the appliance before operating for the first time.
l Never operate the appliance with a damaged power cord / plug or after a malfunction or if it has been
dropped or damaged in any manner.
l Do not vacuum the following to avoid damaging the appliance or prevent a fire hazard.
– Burning or smoking substances such as hot charcoal, burning cigarette and more.
– Flammable and explosive products such as gasoline and alcohol.
– Sharp fragments such as glass, construction materials, nails and so forth.
– Water, chemicals and corrosive liquids.
l Disconnect the power cord from the power supply when cleaning, repairing or when appliance is not
in use. emember do not immerse the main vacuum cleaner in water, avoid approaching to heating
equipment or exposure to the sun to avoid fire.
l This appliance may be used by children aged 8 years and above and persons whose physical,
perceptive or mental skills are impaired or who are inexperienced or not knowledgeable about the
appliance as long as they are supervised or informed and made aware of the safe use of the
appliance and the encountered dangers.
l Children should not be allowed to play with the appliance.
l Cleaning and user maintenance should not be performed by children unless they are supervised by
an adult.
l Do not operate the appliance if it has malfunctioned or is damaged in any manner. Contact an
authorized service for inspection and repairs.
l Avoid operating the appliance continuously as this may cause the suction inlet to be obstructed. This
will generate excessive heat which can damage the motor.
l If the power cord / plug malfunctions or is damaged, use only original parts or parts recommended by
the manufacturer.
l When using the appliance, do not cover power cord with throw rugs, runners, or similar coverings. Do
not route power cord under furniture or appliances. Exercise caution so the power cord will not be
tripped over.
l Always unplug appliance when not in use.
Thank you for purchasing a quality MORGAN appliance. We trust that you will have a pleasant
experience with your new product. To guarantee safety and best efficiency, please read this
manual carefully and keep a copy for future reference.
2
C O N T E N T S
3
4
4
5
7
7
Important Safeguards
Parts Identification
Specifications
Operating Instructions
Troubleshooting
Care & Cleaning

54
PARTS IDENTIFICATION OPERATING INSTRUCTIONS
1
23
4
8
9
10
11
5
6
7
14
13
12
AS AN UPRIGHT VACUUM CLEANER
1. Before operating (Figure 1), press the dust cup button to
open and ensure that the dust cup is installed with filter
screen and HEPA.
2. eassemble the dust cup (Figure 2) and turn until a click is
heard, indicating that the button is locked.
3. Insert the metal tube into the main body hole and secure it
(Figure 3).
4. Install the desired brush into the metal tube (Figure 4).
5. Connect the power plug into the power supply (Figure 5).
6. Push the ON/OFF button switch in the direction of arrow to
begin operation.
7. Push the button switch back (Figure 6) and the vacuum
cleaner stops working.
Store it upright against the wall.
1. Main Body
2. On/Off Button
3. Power cord
4. Hepa Filter
5. Stainless Steel Mesh Filter
6. Dust Cup
7. Dust Cup elease Button
8. Connection Tube Button
9. Connection Tube Assembly
10. Swivel Head
11. otating Floor Brush
12. Ellipse Brush
13. Crevice Nozzle
14. Connector
SPECIFICATIONS
MODEL MVC-P60
RATED VOLTAGE / FREQUENCY 220-240V~ 50/60Hz
RATED POWER 600W
MAX. UCTION ≥18.0Kpa
DU T BOX CAPACITY 0.9L
(figure 1)
(figure 3)(figure 4)
(figure 5)
(figure 6)
(figure 2)

7
TROUBLESHOOTING
CARE & CLEANING
PROBLEM PO IBLE CAU E OLUTION
Motor not working Ensure power plug is connected Connect power plug into the power
securely to the power supply. supply again.
Ensure there is power. Ensure power supply is in good working
order.
Ensure power switch is turned on. Power on.
Low suction power Inspect whether air inlet is obstructed Remove obstruction.
with dirt.
Check if the dust box is full. Empty the dust box.
Check if the filter is obstructed. Clean the filter.
Please perform these troubleshooting before sending the appliance to the service center.
SERVICING OF DOUBLE-INSULATEDAPPLIANCES
A double-insulated appliance is marked with one or more of the following: The words “DOUBLE
INSULATION” or “DOUBLE INSULATED” or the double insulation symbol.
In a double-insulated appliance, two systems of insulation are provided instead of
grounding. No grounding means is provided on a double-insulated appliance, nor should
a means for grounding be added to the appliance. Servicing a double-insulated
appliance required extreme care and knowledge of the system, and should be done only
by qualified service personnel. eplacement parts for a double-insulated appliance must
be identical to the parts they replace.
POLARIZATION INSTRUCTIONS
To reduce the risk of electric shock, this appliance has a polarized plug (one blade is wider than the
order). This plug will fit in a polarized outlet only one way. If the plug does not fit fully in the outlet,
reverse the plug. If it still does not fit, contact a qualified electrician to install the proper outlet. Do not
modify the power plug in any way.
l The main unit and tube can be washed with a soft cloth with water.
The dust box and floor nozzle can be washed with running water.
Note: Do not use alcohol or gasoline.
l Filter: Not intended for wash-machine. emove dirt and dust from the
filter if dirty or when suction power is reduced. Wash with water and
allow to dry thoroughly.
l Note: Assemble the filter and cyclone separator back into the dust
cup after emptying contents.
l Any other servicing should be performed by an authorized service
representative.
6
OPERATING INSTRUCTIONS
AS A COMPACT VACUUM CLEANER
1. Press the connection tube button to detach it from the main body. (Figure
1).
2. Install the adapter (Figure 2).
3. Insert the crevice nozzle into the adapter and secure it (Figure 3).
4. Insert the power plug into the power supply and push the button switch in
the direction of the arrow to begin operation (Figure 4).
5. Push the button switch back to stop the appliance (Figure 5).
6. Press the dust cup button (Figure 6) to detach the dust cup component.
7. Detach the strainer (Figure 7) from the dust cup and discard contents.
8. Detach the HEPA filter and discard contents (Figure 8).
(figure 1)
(figure 2)
(figure 3)(figure 4)(figure 5)
(figure 7) (figure 8)
(figure 6)
