Morgan MVC-CYCLONE 60 User manual

USE MANUAL
Vacuum
Cleane MVC-CYCLONE 60
E-mail: [e-mail]
www.morgan.my
Market Expansion
Services by
www.dksh.com.my
facebook.com/morganappliances

3
IMPORTANT SAFEGUARDS
EAD ALL INST UCTIONS BEFO E USING THE APPLIANCE.
When using electrical appliances, basic precautions should always be followed, including the
following:
1. lease read this instruction manual carefully before first use. It is advisable to keep this instruction
manual for future reference
2. This appliance can be used by children aged from 8 years and above and persons with reduced
physical, sensory or mental capabilities or lack of experience and knowledge if they have been
given supervision or instruction concerning use of the appliance in a safe way and understand the
hazards involved.
3. Do not allow children to play with the appliance, clean or carry out maintenance works without
supervision.
4. DO NOT vacuum water, wet objects, liquids, ashes, hot coals, cigarette butts, matches or any hot,
smoking or burning objects, etc.
5. DO NOT vacuum flammable or combustible materials (i.e. lighter fluid, petrol, kerosene, etc.) or
use in the presence of explosive liquids or vapour.
6. DO NOT vacuum large objects, hard or sharp objects such as glass, nails, screws, coins, etc. that
are likely to cause damage to the appliance.
7. DO NOT use the vacuum without installing all the filters.
8. DO NOT store or use the appliance near high temperature areas.
9. DO NOT run over the power cord with the vacuum cleaner.
10. DO NOT use the vacuum cleaner if it is obstructed. Turn the appliance off and remove all
obstructions before continuing.
11. Never pull the appliance by the power cord. Instead, grasp the power plug and pull to disconnect.
12. Never leave the appliance unattended when connected to the power supply and/or switched on.
13. Never operate the appliance with a damaged power cord or power plug. If the power cord is
damaged, it must be replaced by the manufacturer, its service agent or similarly qualified persons
in order to avoid a hazard.
14. Do not attempt to modify this product in any way.
15. Empty the Dust box and clean the filters regularly to ensure optimal operation of the appliance.
16. Always turn off function controls before you connect or disconnect the appliance to or from the
power supply.
17. IM ORTANT: Always disconnect the appliance from the power supply when not in use, before
cleaning the filters or connecting/disconnecting the accessories.
18. Ensure that the voltage stated on the appliance’s rating label matches the appliance's power supply
voltage.
19. Never immerse the appliance in water or other liquids.
20. Never operate the appliance with a damaged power cord/plug or after a malfunction or if it has been
dropped or damaged in any manner.
21. This appliance is for domestic use only.
2
C O N T E N T S
3
4
4
5
6
7
Important Safeguards
arts Identification
Specifications
Operating Instructions
Care & Cleaning
Troubleshooting

54
PARTS IDENTIFICATION OPERATING INSTRUCTIONS
1
2
13
14
4
8
12
9
11
7
6
5
3
10
OPERATING AS AN UPRIGHT VACUUM CLEANER
1. Ensure there is a filter inside the dust box.
2. Ensure all parts are correctly connected and power is turned off before operating this appliance.
3. Installing the hand grip into the main body (refer to Fig.1):
– Apply a little force to ensure it locks into the interlocking tube.
– WARNING: Don’t overexert force when installing into the main body to prevent damaging the
lock.
5. To detach the hand grip, push and open the separation button and detach the hand grip (see Fig. 3).
6. Connect power plug into power supply.
7. Turn on power supply.
8. Move suction brush along surface to be cleaned such as table, corners and clothing.
9. Always detach the power cord from the power supply after every use.
4. Connect power plug into power supply.
5. Turn on power supply.
NOTE: Do not entwine the power cord over your feet or other heavy objects.
6. Move the floor nozzle up and down to clean the floor.
IMPORTANT: Keep appliance on a level surface.
7. Avoid pressing the floor nozzle on the floor or move it breadthwise to prevent damaging the floor.
8. Always detach the power cord from the power supply after every use.
OPERATING AS A COMPACT VACUUM CLEANER
1. Detach the hand grip and floor nozzle.
2. Attach the suction brush (refer to Fig.2).
3. Ensure there is a filter inside the dust box.
4. Ensure all parts are correctly connected and power is turned off before operating this appliance.
1. Hand grip
2. ower cord hook
3. Separation button
4. ower cord
5. ower switch
6. Main body
7. Dust box release button
8. Filter
9. Dust box
10. Suction brush
11. Floor brush
12. Cyclone separator
13. Nozzle
14. Brush clip
SPECIFICATIONS
MODEL MVC-CYCLONE 60
ATED VOLTAGE / F EQUENCY 220-240V~ 50/60Hz
ATED POWE 600W
MAX. SUCTION 16Kpa
DUST BOX CAPACITY 1.2L
Insert the Handgrip
P
Don’t touch the sepration Button
(figure 1)
Pull out the Handgrip
Push and open the
SeparationButton
(figure 3)
(figure 2)

7
TROUBLESHOOTING
P OBLEM POSSIBLE CAUSES SOLUTIONS
Motor not operating • Ensure power plug connected to the • Insert the power plug into the power
power supply. supply again securely.
• Ensure there is power supply. • Ensure there is proper power supply.
• Check if the power switch is turned on. • Ensure that the power switch is
turned on.
Suction power has reduced • Check whether air inlet is blocked by • Remove dirt and grime.
considerably dirt and grime.
• Check whether the dust box is full. • Empty the dust box.
• Check if the filter is blocked. • Clean the filter.
WA NING: Do not perform repairs yourself for your own safety if your appliance does not
function, is damaged or require spare part(s). The following table contains tips on how to deal
with minor problems yourself:
6
CARE & CLEANING
It is recommended to clean the vacuum cleaner regularly to ensure optimal performance and
lengthen its lifespan.
1. Detach the power plug from the power supply before cleaning and/or storing.
2. Do not use caustic or abrasive products to clean the housing or you may damage the surface.
3. Never immerse the appliance in water or any other liquids.
4. ress the dust box button to release and detach the dust box (see Fig. 4 & Fig. 5)
5. Detach the cyclone separator from the dust box (see Fig. 6).
6. Hold the dust box over a dustbin and empty it.
7. The dust box and nozzles can be washed in water. Allow to dry before reassembling.
NOTE: Do not use alcohol, gasoline or other abrasive cleansers to wash.
8. Use a clean damp cloth to clean the hand grip and main body.
9. Do not wash the filter in a washing machine. Clean it free of dust, wash in water and allow to dry
before assembling.
10. Assemble the filter and cyclone separator back into the dust box. (see Fig. 7)
Press
Remove
Fliter
Cyclone
separator
(figure 4)
(figure 5) (figure 6)
(figure 7)
Remove Dust Box Remove Filter
Remove Cyclone
separator
Installing cyclone
separator & filter
