Morphy Richards VAPOCARE User manual

Instruction manual
Please read and keep these instructions for future use
Mode d'emploi
Merci de bien vouloir lire et conserver ces instructions pour pouvoir les consulter ultérieurement
Bedienungshandbuch
Lesen Sie bitte diese Anleitungen und bewahren Sie sie für einen eventuellen späteren Gebrauch auf
Manual de instrucciones
Lea estas instrucciones atentamente y guárdelas
Istruzioni
Si raccomanda di conservare queste istruzioni per uso futuro
Vejledning
Du skal læse og beholde denne vejledning til fremtidig brug
Návod k použití
Přečtěte si tyto pokyny a uschovejte si je pro budoucí použití
Kullanım kılavuzu
Lütfen gelecekte kullanmak üzere bu talimatları okuyun ve saklayın
Instruction manual
Please read and keep these instructions for future use
g
f
d
p
i
q
}
∂
t

2
g
f
d
e
i
q
∂
t
g Health & Safety
The use of any electrical appliance requires the following common sense safety rules.
Please read these instructions carefully before using the product.
• This appliance can be used by children aged from 8 years
and above and persons with reduced physical, sensory or
mental capabilities or lack of experience or knowledge if they
have been given supervision or instruction concerning use
of the appliance in a safe way and understand the hazards
involved. Children shall not play with the appliance. Cleaning
and user maintenance shall not be made by children without
supervision.
• Keep the appliance and its cord out of reach of children less
than 8 years of age at all times.
• The appliance must not be left unattended while it is
connected to the supply mains.
• The appliance must be used and rested on a stable surface.
• When placing the iron on the base or on its heel, ensure that
the surface on which the heel or base is placed is stable.
• The appliance is not to be used if it has been dropped, if there
are visible signs of damage or it is leaking.
• The plug must be removed from the socket outlet before the
water reservoir is filled with water.
• Do not operate with a damaged vapour mist cord, power cable
or grommet, they must be replaced by the manufacturer, its
service agent or similarly qualified person in order to avoid a
hazard.
CAUTION - HOT: Burns can occur from touching hot
parts or the iron rest.
WARNING: To avoid electric shock, do not immerse
appliance in water / liquid.
Check that the voltage on the rating plate of your appliance
corresponds with your house electricity supply which must
be A.C. (Alternating current).
Do not let the power cable come into contact with the hot
Thermoglass soleplate of the iron.
Should the fuse in the mains plug require changing, a 13
amp BS1362 fuse must be fitted.
WARNING: This appliance must be earthed.
Quick start guide
For more detailed information on using your Vapocare
vapour iron, please read this instruction manual.
Download the QR Reader App on your smart phone and
scan the QR code to see a visual demonstration of the
Vapocare iron.
or visit http://www.morphyrichards.redefine.com
1 Fill the water tank (6).
2 Re-attach the water tank. Plug in your Vapocare iron.
3 Press the precision temperature button once to turn
on your Vapocare vapour iron. Scroll through the
temperature settings to select the desired setting.
4 When the temperature is reached, the temperature
indicator lights (15) will stop flashing and you can start
ironing.
5 Press the precision vapour mist trigger (2) to apply
a light vapour mist onto the creased areas of your
garment.
6 See the creases disappear with ease through the
Thermoglass soleplate (3) without the need for steam.

4
g
f
d
e
i
q
∂
t
1
2
3
5
6
7
8
9
13
14
10
11
12
15
4
12
34
56
7 8
910

6
g
f
d
e
i
q
∂
t
Features
1 Vapour nozzle
This patented technology makes ironing easy and gives your
clothes a superior finish without the need for steam, using 75%
less energy.
2 Precision vapour mist trigger
Simply press and hold to activate the spray that penetrates deep
into the fibres to remove creases with ease. You can apply a
light spray to your garments before you start ironing or apply a
heavier mist for more stubborn creases. You should not need to
press the trigger at all times.
3 Thermoglass soleplate
This patented technology means the iron heats up quickly and
the impact resistant ceramic glass lets you see the creases
disappear as you iron.
4 Precision temperature control / Standby
One-touch heat selection lets you select the right temperature
for your clothes with ease.
One touch selection turns on your vapour iron. Press and hold
for three seconds to turn your vapour iron off / into standby.
5 Limescale free
The patented vapour mist technology means no more limescale
build up and no need for cartridges.
6 Removable water tank
Easy to fill straight from the tap, the iron uses 80% less water
and gives you up to 2 hours continuous ironing time.
7 A better experience
The vapour spray system is surprisingly quiet and doesn’t create
humidity like steam irons can.
8 Ergonomic design
The lightweight iron can be replaced on the heat-safe iron rest
(13) whilst ironing. The base is easy to carry and keep the cable
tidy for storage.
9 Power cable
Plug into the mains outlet to power the appliance.
10 Power cable storage
When the product is not in use, the power cable may be stored
here to keep the cable tidy.
11 Power light
This light remains constantly lit throughout use, except when the
auto shut-off feature is activated.
12 Vapour spray cord
Takes water from the water tank for applying vapour to your
garments.
13 Iron rest
With rubber heat-resistant pads to safely rest your iron whilst in
use.
WARNING: The metal area of the iron rest may get hot during
use.
14 Base
The easy to carry base pumps the water from the water tank up
through the vapour spray cord.
15 Temperature indicator lights
Flash until the selected temperature is reached and the iron is
ready to use.
Temperature guide
Heat setting markings in the temperature guide (below) match those of the International Textile Care Labelling Code. Please
check your garment label before ironing to avoid damage.
Symbol (120ºC Max) (160ºC Max) Warm (210ºC Max) MAX setting (220ºC)
Control Do not iron • •• ••• MAX
Fabric Nylon, Acetates, Wool, Polyester Cotton, Linen
synthetic fabrics mixtures Linen Rayon,
Rayon mixtures
Before use
Unwind and straighten the power cable (9) and vapour spray
cord (12).
For first use, follow the ‘Quick Start Guide’ on page 3.
NOTE: When you have plugged in your Vapocare vapour iron,
press the precision temperature control (4) once to turn the
product on.
NOTE: For first use, you will need to hold the precision
vapour mist trigger (2) for up to one minute before water
vapour is produced from the vapour nozzle (1). It is normal
for the product to make a loud noise during this process.
Textiles and clothes should carry ironing instructions. If not,
follow the temperature guide above, but test the temperature
by ironing the hem of the garment or similar discreet area
first. It is advised to begin with ‘cool’ fabrics and work up to
higher settings. An iron heats up quicker than it cools down
so you’ll save time and electricity.
If you turn the temperature down from a hot setting to a
cooler setting, wait until the temperature indicator lights (15)
have stopped flashing before you continue ironing.
NOTE: Hold the base with both hands when handling,
moving and storing the unit.
Filling
Never use battery topping up fluid or water containing
any substances like starch, sugar, fragrant additives or
defrosted water from a refrigerator.
Unlike conventional irons, the Vapocare iron is designed
for use with tap water.
Re-filling during use 7:
If you press the precision vapour mist trigger (2), and the
water level is low, the vapour nozzle (1) will flash, a beep
will be heard, and the unit will not produce vapour. If this
happens, remove the water tank (6) and refill with water (see
steps 1 and 2 of ‘Quick Start Guide’ on page 3) and replace
the water tank.
NOTE: You can still use your product without vapour.
Features
Dry ironing:
To use your Vapocare iron as a dry iron only, follow steps 3,
4 and 6 of ‘Quick Start Guide’. You do not need to put water
in the tank (6).
Auto shut-off 8:
If the Vapocare iron is not used for 10 minutes, the product
will automatically enter standby mode, both for safety and to
save energy.
Wake the product by pressing either the precision
temperature control (4) or the precision vapour mist trigger
which will illuminate the power light (11). The previous
temperature setting will be restored.
Please wait until the temperature indicator lights (15) stop
flashing before resuming ironing.
Emptying and storing 9
When you have finished Ironing, press and hold the precision
temperature control (4) for three seconds to switch the
Vapocare iron into standby.
Unplug and empty all water from the water tank and place
the iron on the base (14). Use the power cable storage hole
(10) to keep the power cable (9) tidy.
NOTE: Do not store the vapour spray cord (12) in the power
cable storage (10), this is for the storage of the power cable
(9) only. 10
Maintenance
To clean the Thermoglass soleplate:
Wait until cold and use a damp cloth and mild detergent to
wipe over, then wipe dry. Do not spray detergent directly
onto the soleplate.
To remove fibres from the Thermoglass soleplate:
If any man-made fibres fuse to the Thermoglass soleplate (3),
set the iron to the 3-dot or MAX position and pass it over a
clean piece of cotton to draw the deposit off the surface.
To clean the exterior:
Allow the unit to cool and wipe over with a damp cloth and
mild detergent, then wipe dry.

8
g
f
d
e
i
q
∂
t
Troubleshooting
When I press the precision vapour mist trigger (2), no
vapour sprays from the vapour mist nozzle (1) but the
nozzle flashes and beeps.
Solution
• Check the water tank (6) is full and the base (14) is
resting on a level surface. The water may be below the
minimum level.
• If the water tank is full, check the water tank is correctly
located in the base.
21
When I press the precision vapour mist trigger (2)
the nozzle light turns on, I can hear the pump but no
water sprays out of the vapour mist nozzle (1).
Solution
• There may be a blockage in the vapour system. You need
to remove the vapour mist nozzle (1):
1 Turn the clear nozzle cover anti-clockwise until it is
released.
2 Unscrew the nozzle by rotating it anti-clockwise.
3 Tap the vapour nozzle gently on a hard surface to
remove any loose debris.
4 Plug the product in and press the precision vapour
mist trigger (2) for around 30 seconds to remove any
blockages from the system. Do this over a sink or
suitable container.
NOTE: Water will jet out under high pressure.
Reassemble the vapour nozzle and nozzle cover; this is
a reversal of the removal procedure. Press the precision
vapour mist trigger to test the system. If the system is
still blocked, repeat the process or call our helpline for
further instructions.
There is a loud noise when I press the precision
vapour mist trigger (2).
Solution
• This is normal when you operate the product for the first
time as the vapour system is being primed.
• If you hear a loud noise but no vapour is sprayed, check
for blockages as above.
The iron is plugged in and switched on at the socket
but will not heat up.
Solution
• This product has an auto shut-off feature. Check
that this has not been activated by pressing either
the precision vapour mist trigger (2) or the precision
temperature control (4) which will wake the product.
• Check that the thermoglass soleplate (3) is not
damaged. For your safety, this product will not power up
if it is damaged.
• Check that the main fuse board in your house has not
tripped. If tripped, contact the customer helpline (see
below).
• Check the fuse in the plug.
The iron does not get hot enough. Solution
• Check the garments are not too damp through the use
of too much vapour mist.
• Check that the temperature indicator light (15) is set to
the right level (see ‘Temperature guide’ on page 7).
The temperature will default to MAX when the iron is first
turned on.
Contact Us
Helpline
If you are having a problem with your appliance, please call
our Helpline, as we are more likely to be able to help than the
store you purchased the item from. Please have the product
name, model number and serial number to hand when you
call to help us deal with your enquiry quicker.
UK Helpline 0344 871 0945
EIRE Helpline 1800 409 119
Talk To Us
If you have any questions or comments, or want some great
tips to help you get the most out of your products, join us
online:
Website www.morphyrichards.co.uk/redefine
Blog www.morphyrichards.co.uk/blog
Facebook facebook.com/morphyrichardsuk
Twitter @loveyourmorphy
Email customer[email protected]
THIS SECTION IS ONLy APPLICABLE FOR
CUSTOMERS IN UK AND IRELAND
Registering your
two year guarantee
Your standard one year guarantee is extended for an
additional 12 months when you register the product within
28 days of purchase with Morphy Richards. If you do not
register the product with Morphy Richards within 28 days,
your product is guaranteed for 1 year. To validate your 2 year
guarantee register with us online at www.morphyrichards.
co.uk
N.B. Each qualifying product needs to be registered with
Morphy Richards individually. Please refer to the one year
guarantee for more information.
Your one year guarantee
It is important to retain the retailer’s receipt as proof of
purchase. Staple your receipt to this back cover for future
reference. Please quote the following information if the
product develops a fault. These numbers can be found on the
base of the product.

10
g
f
d
e
i
q
∂
t
Model no.
Serial no.
All Morphy Richards products are individually tested before
leaving the factory. In the unlikely event of any appliance
proving to be faulty within 28 days of purchase, it should be
returned to the place of purchase for it to be replaced. If the
fault develops after 28 days and within 12 months of original
purchase, you should contact the Helpline number quoting
Model number and Serial number on the product, or write to
Morphy Richards at the address shown. You may be asked to
return a copy of proof of purchase. Subject to the exclusions
set out below (see Exclusions), the faulty appliance will
then be repaired or replaced and dispatched usually within
7 working days of receipt. If, for any reason, this item is
replaced during the 1 year guarantee period, the guarantee
on the new item will be calculated from original purchase
date. Therefore it is vital to retain your original till receipt or
invoice to indicate the date of initial purchase. To qualify for
the 1 year guarantee, the appliance must have been used
according to the instructions supplied. For example, crumb
trays should have been emptied regularly.
EXCLUSIONS
Morphy Richards shall not be liable to replace or repair the
goods under the terms of the guarantee where:
1 The fault has been caused or is attributable to accidental
use, misuse, negligent use or used contrary to the
manufacturer’s recommendations or where the fault has
been caused by power surges or damage caused in
transit.
2 The appliance has been used on a voltage supply other
than that stamped on the products.
3 Repairs have been attempted by persons other than our
service staff (or authorised dealer).
4 The appliance has been used for hire purposes or non
domestic use.
5 The appliance is second hand.
6 Morphy Richards are not liable to carry out any type of
servicing work, under the guarantee.
7 Plastic filters for all Morphy Richards kettles and coffee
makers are not covered by the guarantee.
8 Batteries and damage from leakage are not covered by
the guarantee.
9 The filters have not be cleaned and replaced as
instructed.
This guarantee does not confer any rights other than those
expressly set out above and does not cover any claims for
consequential loss or damage. This guarantee is offered as
an additional benefit and does not affect your statutory rights
as a consumer.
Your International
two year guarantee
This appliance is covered by two-year repair or replacement
warranty.
It is important to retain the retailers receipt as proof of
purchase. Staple your receipt to this back cover for future
reference.
Please quote the following information if the product
develops a fault. These numbers can be found on the base
of the product.
Model no.
Serial no.
All Morphy Richards products are individually tested before
leaving the factory. In the unlikely event of any appliance
proving to be faulty within 28 days of purchase it should be
returned to the place of purchase for it to be replaced.
If the fault develops after 28 days and within 24 months of
original purchase, you should contact your local distributor
quoting Model number and Serial number on the product, or
write to your local distributor at the addresses shown.
You will be asked to return the product (in secure, adequate
packaging) to the address below along with a copy of proof
of purchase.
Subject to the exclusions set out below (1-9) the faulty
appliance will then be repaired or replaced and dispatched
usually within 7 working days of receipt.
If for any reason this item is replaced during the 2-year
guarantee period, the guarantee on the new item will be
calculated from original purchase date. Therefore it is vital to
retain your original till receipt or invoice to indicate the date
of initial purchase.
To qualify for the 2-year guarantee the appliance must have
been used according to the manufacturers instructions. For
example, appliances must have been descaled and filters
must have been kept clean as instructed.
The local distributor shall not be liable to replace or repair
the goods under the terms of the guarantee where:
1 The fault has been caused or is attributable to
accidental use, misuse, negligent use or used contrary
to the manufacturers recommendations or where the
fault has been caused by power surges or damage
caused in transit.
2 The appliance has been used on a voltage supply other
than that stamped on the products.
3 Repairs have been attempted by persons other than our
service staff (or authorised dealer).
4 Where the appliance has been used for hire purposes or
non domestic use.
5 The appliance is second hand.
6 The local distributor are not liable to carry out any type
of servicing work, under the guarantee.
7 The guarantee excludes consumables such as bags,
filters and glass carafes.
8 Batteries and damage from leakage are not covered by
the guarantee.
9 The filters have not be cleaned and replaced as
instructed.
This guarantee does not confer any rights other than those
expressly set out above and does not cover any claims for
consequential loss or damage. This guarantee is offered
as an additional benefit and does not affect your statutory
rights as a consumer.
AUSTRALIAN WARRANTY
This appliance is guaranteed for 2 years against faulty
material, components and workmanship.
This warranty is in addition and does not affect your statutory
rights.
Proof of purchase must be produced for any warranty benefit.
In the unlikely event of any appliance proving to be faulty,
securely pack and return the item to the place of purchase
accompanied by the original receipt or invoice.
Our goods come with guarantees that cannot be excluded
under the Australian Consumer Law. You are entitled
to a replacement or refund for a major failure and for
compensation for any other reasonably foreseeable loss or
damage. You are also entitled to have the goods repaired or
replaced if the goods fail to be of acceptable quality and the
failure does not amount to a major failure.
Not covered by this warranty
(Australian only)
• If the appliance has not been used in accordance with
the manufacturers’ recommendations or Instructions.
• If the fault is deemed to be caused by abuse, misuse,
neglect, modifications or in proper use and or care
Eg: Kettles: Excessive build up of scale.
Toasters: Excessive build up of crumbs or foreign matter
etc.
• Connection to incorrect voltage to that stamped on the
product.
• Unauthorised repairs.
• Appliance used other than for domestic purposes.
• Excluding bags, filters, glass, carafes, and cutting blades.
• Freight and insurance costs.
If for any reason this item is replaced during the 2 year
guarantee period, the guarantee on the new item will be
calculated from original purchase date. Therefore it is vital to
retain your original receipt or invoice to indicate the date of
original purchase.
Morphy Richards’s policy is to continually improve quality
design and product quality. The company therefore reserves
the right to change any specifications or to carry out
modifications as deemed worthy at any time.
The Australian supplier ASKO Appliances reserves the right to
repair, modify, exchange or replace the faulty appliance with
the same or similar model or product of equivalent value.

12
g
f
d
e
i
q
∂
t

RN360001 MEE REV1 06/15
