Morris FSI-13370 User manual

FSI-13370
14 place settings
Alt function

Witheachwashcycle.
Compartment
For programmes with pre-wash only.
(Follow the user instructions!)
Electric indicator on control panel (if provided).
Check the rinse aid level
(On models with water softener system only.)
Electric indicator on control panel (if provided).
If there is no salt warning light in the control panel
(for some models), you can estimate when to fill the salt into
the softener by the number of cycles the dishwasher has run.
Check the regeneration
salt level
Load the baskets
Select a programme
Close the door, turn on the water tap and press the Start/Pause button. The machine will start working
after about 10 seconds.
Running the dishwasher
Switch off the appliance
Turn off the water tap,
unload the baskets
Fill the detergent dispenser
Warning: wait a few minutes (about 15 minutes) before unloading the dishwasher to avoid handling
the dishes and utensils while they are still hot and more susceptible to break.
They will alsodry better.Unload the appliance, startingfrom the lower basket.
Changing the programme
Add forgotten dishes in the
dishwasher.
Scrape off any large amount of leftover food. Soften remnants of burnt food in pans,
then load the baskets. Refer to the dishwasher loadinginstructions.
Press the Programme button until the selected programme lights up.
( See the section entitled Operationg instruction )“”
When the working cycle has finished, the buzzer of the
dishwasher will sound 8 times, then stop.
Turn off the appliance using the power switch button.
If the appliance is switched
off during a wash cycle.
Openthe door carefully.
Hotsteammayescape
when the door is opened!
If the appliance is switched off during a wash cycle, when switched
on again, please re-select the washing cycle and operate the dishwasher
according to the original Power-on state ).
Switch on the appliance Press the Power button to switch on the appliance, Open the door.
For detailed operating method read the corresponding content onthe instruction manual.
1. Arunning cycle can only be modified if it has been running for a short time. Otherwise the detergent
may have already been released and the water already drained. If this is the case, the detergent
dispenser must be refilled.
2. Press the Start/Pause button then press the program button for more than 3 seconds to cancel the
running programme.
3. Select a new programme.
4. Restart thedishwasher.
1.Press the start/pause button to stop the machine.
2.Open the door.
3.Add the forgotten dishes.
4.Close the door, then press the start/pause button, the dishwasher will
start running again after 10 seconds.

To review the section on troubleshooting Tips
will help youtosolve some common problems
by yourself .
Dear Customer,
Please carefully readthismanual before usingthe
dishwasher, itwill help you touseandmaintain the
dishwasher properly.
Pass it on to anysubsequent owner ofthe appliance.
Thismanualcontains sections on safety Instructions,
Operating Instructions, InstallationInstructionsand
Troubleshooting Tips, etc.
The manufacturer, following a policy of constant
development andupdating of the product, may
make modifications without giving prior notice.
Keep it as arefer in the later days.
If you can not solvethe problems by yourself ,
please ask for the help of professional technicians.
This appliance is intended tobe used in household
andsimilar applications suchas:
-staff kitchen areas in shops,offices and other
working environments;
-farm houses;
-byclients inhotels, motels and otherresidential
type environments;
-bed and breakfast type environments.
Dishwasher Features.................................... ...3
A Water Softener...........................................4、
Attention before or after loading the Dishwasher
Baskets..........................................................9
FilteringSystem.............................................13
Caring for the Dishwasher..................... .........14.
B Loading the Salt intothe Softener.................5、
C Fill theRinseAid Dispenser.........................5、
D FunctionofDetergent .................................6 、
WashCycleTable...........................................11
Turning on theAppliance................................12
Change the Programme.............. ................12....
At the Ene of the Wash Cycle...........................12
PositioningtheAppliance................... ..........15..
Water Connection.................................. .......16.
About Power Connection........................ .......15.
Start of dishwasher................................ ......17..
Beforecallingforservice........................... .....18.
Errorcodes.................................... ..............19.
Technical information.............................. .....20..
ControlPanel...................................................3
The Method Loading Normal Dishware.............10

This appliance must be grounded. In the event of a
malfunction or breakdown, grounding will reduce
the risk of anelectric shock by providing a path of
least resistance of electric current. This appliance
is equipped with a cord having an equipment-
grounding conductor and a grounding plug.
The plug must be plugged into an appropriate outlet
that is installed and grounded in accordance with
all local codes and ordinances.
Keep children away from detergent and rinse aid, keep
child away from the open door of the dishwasher,
there could still be some detergent left inside.
ren
Donotabuse,siton,orstandonthedoorordish
rack of the dishwasher.
Do not touch the heating element during or
immediately after use.
(This instruction is only applicable to machines
with a visual heating element.)
Do not wash plastic items unless they are marked
dishwasher safe or the equivalent. For plastic items
not so marked, check the manufacturer's
recommendations.
Use only detergent and rinse additives
designed for an automatic dishwasher.
Never use soap, laundry detergent, or hand
washing detergent in your dishwasher. Keep
these products out of the reach of children.
During installation, the power supply must not
be excessively or dangerously bent or flattened.
Do not tamper with controls.
Do not place any heavy objects the
door when it is open. The appliance could tip
forward.
on or stand on
When loading items to be washed:
1) Locate sharp items so that they are not likely
to damage the door seal;
2 Warning: Knives and other utensils with
sharp points must be loadedin the basket
with their points down orplaced in a
horizontalposition.
)
When using your dishwasher, youshould
prevent plastic items from coming into contact
with the heating element.(This instruction is only
applicable to machines with a visual heating
element.)
Ifthesupplycordisdamaged, itmustbereplaced
bythemanufactureroritsserviceagentora
similarly qualified person in order to avoid a
hazard.
Please dispose of packing materials properly.
Use the dishwasher only for its intended function.
Remove the door to the washing compartment when
removing an old dishwasher from service or discarding it.
Dishwasher detergents are strongly alkaline, they
can be extremely dangerousif swallowed.Avoid
contact with skin and eyes and keep children away
from the dishwasher when the door is open.
Check that the detergent comparment isempty
after completion of the wash cycle.
The applianceis to be connected to the water
mains using new hose sets and that old hose-sets
should not be reused.
The maximum number of place settings to be
washed is14.
The maximum permissible inlet water pressure is
1Mpa.
The minimum permissible inlet water pressure is
0.04Mpa.
Children should be supervised to ensure that they do
not play with the appliance.
This appliance is not intended for use by persons
(including children with reduced physical, sensory or
mental capabilities, or lack of experience and
knowledge ,unless they have been given supervision
or instruction concerning use of the appliance by a
person responsible for their safety.
)
When using your dishwasher, follow the precautions listed below:
The door should not be left open,
since this could increase the risk of tripping.
Improper connection of the equipment-grounding
conductor can result in the risk of an electric shock.
Check with a qualified electrician or service
representative if you are in doubt whether the
appliance is properly grounded. Do not modify the
plug provided with the appliance; If it does not fit
the outlet. Have a proper outlet installed by a
qualified electrician.
Do not operate your dishwasher unless all
enclosure panels are properly in place. Open
the door very carefully if the dishwasher is
operating, there is a risk of water squirting out.

Dispose of the dishwasher packaging material correctly.
All packaging materials can be recycled.
Plastic parts aremarked with thestandard international abbreviations:
PE for polyethylene, e.g. sheet wrapping material
PS for polystyrene, e.g. paddingmaterial
POM polyoxymethylene, e.g. plastic clips
PP polypropylene, e.g. Salt filler
ABS Acrylonitrile Butadiene Styrene, e.g. Control Panel .
Packaging materialcouldbe dangerous for children!
Fordisposing ofpackage and theappliance please goto arecycling centre. Therefore cut
off the powersupplycableand make the doorclosingdevice unusable.
Cardboard packaging ismanufactured from recycled paperand shouldbe disposedin the
waste papercollection for recycling.
By ensuring thisproduct is disposed of correctly, you will help prevent potential negative
consequences for the environment and human health, which could otherwise be caused
by inappropriatewaste handlingof this product.
For more detailed informationabout recycling of this product, please contact your local
city office and your household waste disposal service.
DISPOSAL: Do not dispose this product as unsorted municipal waste. Collection of such
waste separately for special treatment is necessary.






beforeusingit forthe first time.
To getthe best performance from yourdishwasher,read all operating instructions
11 12
Back View
1
2
3
4
5
7
8
910
Front view
Lower basket
Salt container
Dispenser
Cupshelf
Spray arms
Filter assembly
Inlet pipe connector
Drain pipe
Upperbasket
Cutlery rack
Top spray arm
1
Innerpipe
5
6
7
8
9
10
12
11
3
24
6
Power Button:To turn on/off the power supply.
Program Button :To Pressthebutton toselect
appropriate Program.
Programindicators: to show which program you
have chose;
1.
2.
3.
4. Alt Button: Dual zone wash function, press the button
toselect eitherupperbasket orlower basket loaded,
and the response indicator will blinking.
5.
6.
7.
DelayButton :To Press thebutton to delay.
Child lock button: press the buttons simultaneously
to lockthe program.
Start /Pause button: Tostart the selected washing
program or pause the washing program when the
machine is working.
8.
9.
10.
11.
Salt warning lights: To show when the salt container
need to be ref illed.
rinse aidwarning lights: Toshow when the
dispenserneed to be ref illed.
Delay t ime,Remain t ime ,orerrorcodes indicator.
SprayArms indicators :to show whick spray arms
will work.

The water softener must be set manually, using the water hardness dial.
The water softener is designed to remove minerals and salts from the water, which wouldhave
a detrimentalor adverse effect on the operation of the appliance.
The higher the content of these minerals and salts, theharder your water is.
The softener should be adjusted according to the hardness ofthe water in your area. Your localWaterAuthority
can advise youon thehardnessofthewater inyourarea.
Adjusting Salt Consumption
The dishwasher is designed to allow for adjustment in the amount of salt consumed based on the hardness of
thewater used.This is intended tooptimise and customise thelevel o f salt consumption.
1. Switch on theappliance;
2. Press the Start/Pause button for morethan 5 seconds to start the water
softener set model within 60seconds after the appliance was
switched on;
3. Press the button to select the proper setaccording to
your local environment, the sets will change in the following
sequence: H1->H2->H3->H4->H5->H6;
4. Press the On/Offbutton or no operation for 5 seconds to end the set up model.
Start/Pause
WATER SOFTENER
Thehardness ofthe water variesfrom place to place.If hard water is used inthe dishwasher, deposits will
form on the dishesand utensils.
Theapplianceisequipped with aspecial softener that uses a salt container specifically designed to eliminate
lime and minerals from the water.
Contact your local water board for information on the hardness of your water supply.
dH mmol/l
0~90~5 0~0.94 H1 0/
10-20
6-11 1.0-2.0 H2 20 60
21-30
12-17 2.1-3.0 H3 30 50
H4 40
40
fH
0~6
7-14
15-21
Clarke
WATER HARDNESS
SelectorPosition Salt consumption
(gram/cycle) Auto nomy
(cycles/1kgs)
Please follow the steps below for adjustment in salt consumption.
18-22 31-40 22-28 3.1-4.0
If your model does not have any water softener, you mayskip this section.
Clark:British degree
fH: French degree
DH: German degree
dH=1.25Clarke=1.78fH=0.178mmol/l
1
41-60
23-34 4.1-6.0 H5 50 30
H6 60 20
29-42
The manufactory setting: H4 (EN 50242)
35-55 61-98 43-69 6.1-9.8
Before using your dishwasher for the first time:
A. Set the water softener
B. Add 1.5Kg dishwasher salt and then full fill the salt container with water
C. Filltherinseaiddispenser
D. Fill in detergent

1. The salt container must only be refilled when the salt warning light in the control panel comes on.
Depending on how well the salt dissolves, thesalt warning light may still be on even though the
salt container is filled.
If there is no salt warning light in the control panel (forsome Models),you can estimate whento fill
the salt into the softener by the cycles that the dishwasher has run.
2. If thereare spills of the salt, a soak or a rapid program should be run to remove the excessivesalt.
Always use the salt intended foruse with dishwasher.
The salt container islocated beneath the lower basket and should be filled as explained
inthe following:
Attention!
Only use salt specifically designed for the use in dishwashers! Every other type of
salt not specificallydesigned for the use in a dishwasher, especially table salt, will
damage the water softener. In case of damages caused by the use of unsuitable
salt the manufacturer does not give any warranty nor is liable for any damagescaused.
Only fillwithsalt just before starting one of thecomplete washingprograms.
This will prevent any grains of salt or salty water, which may have been spilled,
remaining on the bottom of the machine for any periodof time, which maycause
corrosion.
Therinse aid isreleasedduringthe final rinse to prevent water from forming droplets onyour dishes,which can
leave spots and streaks. It also improvesdrying by allowing water toroll offthe dishes. Your dishwasher is
designed to useliquidrinseaids.The rinseaiddispenser islocated inside thedoor next to the detergentdispenser.
To fill the dispenser, open the cap and pour the rinse aid into the dispenser until the level indicator turns completely
black. The volume ofthe rinseaidcontainer is about 110ml.
RinseAid Dispenser
Function of RinseAid
Rinse aid is automatically added during thelast rinse, ensuring thorough rinsing, and spot and streakfree drying.
Attention!
Only use branded rinse aid for dishwasher. Never fill therinse aid dispenser withanyother substances
(e.g. Dishwasher cleaning agent, liquid detergent). This would damage the appliance.
Full fill the salt container withwater,It isnormal for asmall amount ofwater tocome outofthe
salt container.
AAfter the lowerbasket has been removed, unscrew and remove the cap from the salt container.
C
DAfterfilling the container , screw the cap tightly back clockwise.
EThe saltwarninglightwillstop being after thesaltcontainer has beenfilled withsalt.
FImmediately afterfilling the salt into the salt container, a washing program should be started
program Otherwise the filter system, pump or other important parts of the machine may be damaged
bysalty water.This isoutof warranty.
(Wesuggest to use a short
).
BPlace theend of thefunnel (supplied) into the hole and introduce about 1.5kg of dishwasher salt.

To open the dispenser, turn the cap to the "open" (left) arrow and lift it out.
Pour the rinse aid into the dispenser, being careful not tooverfill.
Replace the cap by inserting italigned with "open" arrow and turning it tothe closed (right) arrow.
Adjusting RinseAid Dispenser
The rinse aid dispenser has six or four settings.Always start with the dispenser
set on "4". If spots and poor drying are a problem, increase the amount of rinse
aid dispensed by removing the dispenser lidand rotating the dial to "5". If the
dishes still are not drying properlyor are show spots,adjust the dial to the next
higher lever until your dishes are spot-free. The recommended setting is "4".
(Factory value is "4".)
Increasethe dose if thereare drops of waterorlimespotsonthe dishes afterwashing.
Reduce itifthere aresticky whitish stains on your dishes ora bluish film on glasswareor
knife blades.
1
2
3
As the rinse aid diminishes, the size of the black dot
ontherinse aidlevel indicator changes, as illustrated below.
Full
3/4full
1/2full
1/ 4full- Should refilltoeliminate spotting
Empty
When to Refill the RinseAid Dispenser
Ifthereis no rinse-aid warning light in thecontrolpanel, you can estimatethe amount from the colour
of the optical level indicator C located next to the cap. When the rinse-aidcontainer is full, the whole
indicator will be dark .As the rinse-aid diminishes, the size of the dark dot decreases. You should never let
the rinse aid level fall 1 / 4 full.
during the next wash. Don'tforget toreplacethe cap before you closedishwasherdoor.
Clean up any rinse aid spilled while during filling with an absorbent cloth to avoid excessive foaming
Detergents with its chemical ingredients are necessary toremove dirt, crush dirt and transport itoutof the dishwasher.
Mostof the commercial qualitydetergentsare suitableforthispurpose.
""
ProperUse ofDetergent
Useonly detergent specifically made for the use indishwashers. Keep yourdetergent fresh and dry.
Don't putpowdered detergentinto the dispenseruntil you're ready to wash dishes.
Attention!

Amount ofDetergent toUse
Dishwasher detergent is corrosive! Take care to keepit out of reach of children.
Based ontheir chemicalcomposition, detergentscan besplitintwo basic types:
Detergent tabletsofdifferent brandsdissolve at different speeds. For thisreasonsome
detergenttablets cannot dissolve and develop theirfullcleaning power during short
programs. Therefore please use long programs when using detergent tablets, to
ensure the complete removal of detergent residuals.
The dispenser must be refilled before the start of each wash cycle following the instructions
provided in the wash cycle table . Your dishwasher uses less detergent and rinse aid than
Conventionaldishwasher.Generally, only one tablespoon of detergent is needed for
anormalwashload. Moreheavily soileditemsneedmore detergent.Alwaysaddthe
detergent justbefore starting the dishwasher, otherwise it couldget damp and will not
dissolve properly.
Concentrated Detergent
DetergentTablets
Detergent Dispenser
conventional, alkaline detergents with caustic components
low alkaline concentrated detergents with natural enzymes
Normally new pulverised detergent is without phosphate.Thus the watersoftener function of
phosphate is not given. In this case we recommend to fill salt in the salt container even when
the hardness of water is only 6 dH. If detergents without phosphate are used in the case of hard water
often white spots appear on dishes and glasses. In this case please add more detergent to reach
better results. Detergents without chlorine do only bleach a little. Strong and coloured spots will not
be removed completely. Inthiscase please choosea program with ahigher temperature.
°
Detergents
There are 3 sorts of detergents
1.Withphosphate and withchlorine
2.With phosphate and without chlorine
3.Without phosphate and without chlorine
Always add the detergent just before starting each wash cycle.
Only use branded detergent aidfor dishwasher.
If the lid is closed: press release button.The lid will spring open.

Fill the detergent dispenser with detergent.
The marking indicates the dosing levels , as
illustrated on the right:
Theplace of main wash cycledetergent placed.
Theplace of pre-wash cycle detergent placed.
Please observe themanufacturers dosing and storage
Recommendationsas statedonthedetergent packaging.
Close the lid and press untilit locks in place.
If the dishes are heavily soiled, place anadditional
detergent dose in the pre-wash detergent chamber.This detergent will take effectduring the pre-wash phase.
A
B
Fill in Detergent
You findinformation about the amount ofdetergent for thesingle programme onthe last page.
Pleaseaware, that according tothe level soiling and the specific hardness of waterdifferencesare possible.
Pleaseobserve themanufacturer's recommendations onthe detergentpackaging.
AB

Cutlery withwooden,horn china or
mother-of-pearl handles
Plastic items that are not heat resistant
Older cutlery with glued parts that are not
temperatureresistant
Bonded cutlery items or dishes
Pewter or cooper items
Crystal glass
Steel items subject to rusting
Wooden platters
Items madefromsyntheticfibres
Some types of glasses can become
dull aftera large number of washes
Silver and aluminum parts have a
tendencyto discolourduring washing
Glazed patterns may fade if machine
washed frequently
Are not suitable Are oflimited suitability
Dishes and itemsofcutlery mustnot lie inside oneanother, or cover each other.
To avoid damage to glasses, theymust not touch.
Load large itemswhich are most difficult to clean into the lower basket.
The upper basket isdesigned to hold more delicate and lighter dishware such as glasses, coffee
andteacups
Long bladed knives stored in an upright position are a potential hazard!
Long and/or sharp items of cutlery such as carving knives must be positioned
horizontally in the upper basket.
Please do not overload your dishwasher. This is important forgoodresultsand for
reasonable consumption of energy.
Load hollow items such as cups, glasses, pans etc. With the opening facing downwardsso that
water cannot collect in the container or a deepbase.
Consider buyingutensilswhich are identified asdishwasher-proof.
Usea mild detergent thatis describedas 'kind todishes'. If necessary, seek further
information from the detergent manufacturers.
For particular items,select aprogramwithaslowa temperature aspossible.
To prevent damage, do not take glass andcutlery out of the dishwasher immediately
after the programme has ended.
(For best performance of the dishwasher, follow theseloading guidelines.
Features and appearance of baskets and cutlerybaskets may vary from your model.)
Scrape off any largeamounts ofleftover food.Soften remnants of burnt food in pans.
It is not necessary to rinse thedishes under running water.
Place objects in the dishwasher in following way:
1.Items such as cups, glasses, pots/pans, etc. are faced downwards.
2.Curved items, or ones with recesses, should be loaded aslant so that water can run off.
3.All utensils are stacked securely and can not tipover.
4.All utensils are placed in the way thatthe spray arms can rotate freely during washing.
Very small items should not be washed in the dishwasher as they could easily fall out of the basket.
To prevent water dripping from the upperbasket into the lower basket, we recommend thatyou
empty the lower basket first and thenthe upper basket.

The upper basket is designed to holdmore delicate
and lighter dishware such as glasses, coffee and
teacups and saucers, as wellas plates,small bowls
andshallowpans (as long astheyare not toodirty).
Positionthedishes andcookwaresothatthey will
notgetmoved bythespray ofwater.
We suggest that you place large items and the most
difficultto cleanitems areto be placedintothelower
basket: suchaspots, pans, lids, serving dishes and
bowls, as shown in the figure below. It is preferable to
place serving dishes and lids on the side of the racks
in order to avoid blocking the rotation of the top spray
arm.
Pots,servingbowls,etc,mustalwaysbeplacedtopdown.
Deep pots should be slanted to allow water to flow out.
Please be reminded that:
The Bottom Basket features folding spikes so that larger or more pots and pans can be loaded.
Folding Spikes of Lower Basket
For better stacking of pots and pans,
the spikescan be folded down as
show in the picture right.
Folding back the cup shelives
For better stacking of pots and pans,
the spikes can be folded down as
show in the picture right.
Cutleryshouldbe placed inthecutlery rackseparately
from each other in the appropriate positions, and do
make sure the utensils do not nest together, this may
causebadperformance.
Adjusting the Upper Basket
The heightof the upper basketcanbe adjusted inorderto
create more space for large utensils both forthe upper
/lower basket.Theheightof the upperbasket canbe
adjusted by lift upthe basket for the upper position, and up
press the handle to lower the upper basket, see thepicture
below:

Starting a cycle wash
Draw out the lower and upper basket, load thedishes and push them back.
Itis commended to load the lower basketfirst, then the upper one (see the sectionentitled
Loadingthe Dishwasher ).
Pour in the detergent (see the sectionentitled Salt, Detergent and RinseAid ).
Insert the plug into the socket. The power supplyis 220-240 VAC /50 HZ, the specification
of the socket is 10A 250VAC. Make sure that the water supply is turned on to full pressure.
Close the door, press the P button to switch on the machine.
Press the program button , the wash program will bechanged as follows direction:
If a program is selected, the response light will light. Then press the Start/Pause button, the
dishwasher beginsto start.
“”
“”
ower
Intensive->Normal->Eco ->60min->Rapid ;->Glass ->Soak
1
2
3
4
5
*EN 50242 : This programme is the test cycle. The information for comparability test
in accordance with EN 50242, as follows:
Capacity: 14 setting
Position Upper basket: upper wheels on rails
Rinse aid setting: 6
The power consumption of off-mode is 0.6W, left-on mode is 0.8W.
Means: need to fill rinse into the Rinse-Aid Dispenser.
()
Eco.
Intensive
Normal
(*EN 50242)
(or )3in1
5/30g
(or )3in1
5/30g
(or )3in1
5/30g
Rapid
Pre-wash (50 )
Main wash(65 )
Rinse
Rinse
Rinse (55 )
Drying
℃
℃
℃
Pre-wash (45 )
Wash (50 )
Rinse
Rinse (60 )
Drying
℃
℃
℃
Pre-wash
Wash (50 )
Rinse
Rinse (60 )
Drying
℃
℃
Wash (40 )
Rinse
Rinse (45 )
℃
℃
180
175
165
40
1.2
0.93
1.5
0.6
17
14
11
10
60 min
Pre-wash (50 )
Wash (62 )
Rinse (60 )
Drying
℃
℃
℃60 10
1.15
5/30g
20g
Soak
Rinse
80.1
3.5
Glass
115 14
0.87
5/25g
Pre-wash
Wash (40 )
Rinse
Rinse (60 )
Drying
℃
℃
Fornormallysoiledloads,
such as pots plates glasses
and lightly soiled pans.
、、
Standarddaily cyclefor
normallysoiled loads, such
aspots plates glasses.、、
For heaviest soiled crockery,
andnormally soiled pots
pans dishes etc with dried
onsoiling;
、
、
Forlightlysoiled loadsthat
donot needexcellent drying
efficiency.
Ashorter wash for lightly
soiled loadsand quick wash
To rinse dishes that you plan
towash laterthat day
Forlightlysoiled crockery
and glass

When the working cycle has finished, the buzzer of the dishwasher will soundfor 8 seconds, then stop. Turn off
the appliance using the Power switch button, shut off the water supply and open the door of the dishwasher.
Wait for a few minutes before unloading thedishwashertoavoidhandlingthe dishes and utensils while they
are still hot and more susceptible to breakage. Theywill alsodry better.
Switch Off the Dishwasher
The program light is on but is not blinking, only in this case the programme has ended.
Power1.Switch off the dishwasher by pressing the button.
2.Turnoffthewatertap!
Open the door carefully.
Hot dishes are sensitive to knocks. The dishes should thereforebe allowedto cool down around 15 minutes
before removing from the appliance.
Open the dishwasher's door, leave it ajar and wait a few minutes before removing the dishes. In this way they
will be cooler andthe drying will be improved.
Unloadingthedishwasher
It is normal that the dishwasher is wet inside.
Empty thelower basket first and then the upper one.This will avoid water dripping from the upper Basket onto
the dishes in thelower one.
If you open the door , the machine will pause. The program lightwill
stop blinking and the buzzerwill mooing every minute unless you closethe door .After
you close the door ,the machine will keepon working after 10 seconds.
during awash cycle
Premise:
Acycle that is underway can only be modified if it has only been running for a short time. Otherwise, the
detergent may havealready been released, and the appliance may have already drained the wash water.
If this is the case, the detergent dispenser must be refilled (see the section entitled " Loading the
Detergent " ).
Press the Start/Pause button , the machine will be in standby state, press the program button more than
3s then you can change the program to the desired cycle setting (see the section entitled " Starting awash
cycle. . ." ).
1
2
Aforgotten dish can be added any time before the detergent cup opens.
Add forgotten dishes.
Close the door
After the spray arms stop working,you can open the door
completely.
2
3
Open the door a little to stop the washing.
14
5
6
Press the Start/Pause button
Press the button, the dishwasher will run
after 10 seconds.
Start/Pause
When you press the Start/Pausebutton to pause during washing, the running indicator will
stop blinking and the dishwasher will mooing every minute unless youpressthe
button to start.Start/Pause
Wash the arms in soapy and warm water and use a soft brush to
cleanthejets. Replace them afterrinsing themthoroughly.
When following this procedure from step1 to step 3, the filter system will be removed;
when following it from Step 3 to Step 1, the filter system will be installed.
It is dangerous to open the door when washing, because the hot water may scald you.

The filter preventslarger remnantsof food or other objects from getting inside thepum.
Theresidues may block the filter, in this case they mustbe removed.
The filter system consists of a coarse filter,a flat (Main filter)
Anda microfilter(Fine filter).
Food and soil particles trapped in thisfilter arepulverizedby a
special jet on the lower spray arm andwashed down todrain.
Larger items, such as pieces of bones or glass, that couldblock
the drainaretrappedin the coarse filter.To remove theitems
caught by the filter, gently squeeze the tap on thetop of this
filterandliftout.
Thisfilter holds soil and food residues in the sumpareaand
prevents itfrom beingredeposit on the dishes during wash cycle.
Main filter
1
Coarse filter
2
Fine filter
3
2
3
1
Filterassembly
Thefilter efficiently
For best performance and results, the filter must be cleaned regularly. this reason, it isa goodidea to
remove the larger foodparticlestrapped in the filter aftereach wash cycleby rinsing the semicircular filter and
cup under runningwater. To remove the filter device, pull the cup handle in the upwarddirection.
removes food particles from the wash water, allowing it to be recycledduring the cycle.
For
The dishwasher must never be used without the filters.
Improper replacementof the filter may reduce the performancelevel ofthe appliance
and damage dishes and utensils.
1
2
Step 1 Turn the filter in anti-clockwisedirection,：
Step 2 lift the filter assy up：
When following this procedure from step1 to step 2, the filter system will be removed;
when following it from Step 2 to Step 1, the filter system will be installed.

The control panel can be cleaned by using a lightly dampenedcloth.
After cleaning, make sure to dry it thoroughly.
For the exterior, use a good appliance polish wax.
Neveruse sharp objects, scouring pads orharsh cleaners on any part of the dishwasher.
ProtectAgainst Freezing
1.Cut off the electrical power to the dishwasher.
2.Turn off the water supply and disconnect the water inlet pipe from the water valve.
3.Drain the water from the inlet pipe and water valve. (Use a pan to gather the water)
4.Reconnect the water inlet pipe to the water valve.
5.Remove the filter at the bottomof the tub and use a sponge to soak up water in the sump.
please take frost protection measures onthe dishwasher in winter.Every fter washing cycles,
please operate as follows time a
：
Cleaning the Filter
CleaningThe Door
To clean the coarsefilter and the fine filter, use a cleaning brush. Reassemble thefilter parts as shown in the figures
on thelast page and reinsert the entire assembly in the dishwasher, positioning itin its seat and pressing downwards.
When cleaning the filters, don't knock on them. Otherwise, the filters could be
contorted andtheperformance ofthe dishwashercouldbedecreased.
To clean theedge around the door, you should use only a soft warm, damp cloth.
To avoid penetrationof water into thedoor lock and electrical components,do not
use a spray cleaner of any kind.
Never usea spray cleaner toclean the door panel as it may damage the door lock
and electrical components.
Abrasive agents or some paper towels should not be used because of therisk of
scratching or leaving spots on the stainless steel surface.
Cleaning the SprayArms
If your dishwasher cannot work because of the ice,
please contact professional service persons.
It is necessary to clean the spray arms regularly for hard
water chemicalswillclogthesprayarmjetsandbearings.
- Inspect the filters for blockingafter every time the dishwasher has been used.
- By unscrewing the coarse filter, you can remove the filter system. Removeany foodremnants and
cleanthefilters underrunningwater.
Remarks:
The entire filter assemblyshouldbe cleanedonce a week.
To remove thelower spray arm, pull out thespray arm upward.
To remove the upper spray arm, hold the nut, rotate the arm
clockwise toremoveit.
Wash the arms in soapy and warm water and use a soft brush to
clean the jets. Replace them after rinsing them thoroughly.

Itis recommend that yourun a washcycle withthe
dishwasher emptyand thenremove the plugfrom the
socket, turn off the water supply and leave the door of
the appliance slightly open. This will help the door
sealstolastlonger andpreventodoursfromforming
withintheappliance.
If the appliance must be moved, tryto keep it in the
verticalposition. Ifabsolutelynecessary,itcanbe
positioned on its back.
Oneofthefactorsthatcauseodourstoforminthe
dishwasher is food thatremains trapped in the seals.
Periodic cleaning with adamp sponge will prevent this
from occurring.
Ensure the voltage and frequency of the power being corresponds to
those on the rating plate. Only insert the plug into anelectricalsocket which is earthed
properly. If the electrical socket to which the appliance must be connected is not
appropriate fortheplug, replacethe socket, ratherthan usingaadaptors or thelike as
they couldcause overheating andburns.
Pleaselook at therating label to know the rating voltage and connect the dishwasher to the appropriate power supply.
Use the required fuse 10 amp,time delay fuse or circuit breakerrecommended and provide separate circuit serving
only this appliance.
Position the appliancein the desired location.The back should rest against thewall behind it, and the sides,
along the adjacent cabinets or walls.The dishwasher is equipped with water supply and drain hoses that can
be positioned either to the rightor the left sidesto facilitateproperinstallation.
Once the applianceis positioned for levelling, the height of the dishwasher
may be alteredvia adjustment of the screwing level ofthe feet. In any case,
theappliance should not beinclined more than 2 .
For personal safety:
DO NOT USEAN EXTENSION CORD OR AN ADAPTER PLUG WITH THIS APPLIANCE.
DO NOT, UNDERANY CIRCUMSTANCES, CUT OR REMOVE THE EARTHING
CONNECTION FROM THE POWER CORD.
Before cleaning or performing maintenance, always
remove the plug from the socket.
Tocleantheexteriorandrubberparts ofthedishwasher,
donot use solventsor abrasive cleaningproducts.
Only use acloth with warm soapy water.
To remove spots or stains from the surface of the
interior, use a cloth dampened withwaterana little
vinegar, ora cleaning product madespecifically for
dishwashers.
Remove the Plug
No Solvents orAbrasive Cleaning Moving theAppliance
Seals
After every wash, turn off the water supply to the
appliance and leave the door slightlyopen so that
moisture and odours arenot trapped inside.
After EveryWash
When not inUse for aLongTime
This appliance must be earthed. In the event of a malfunction or breakdown, earthing will reduce the risk of
electric shock by providing a path of least resistance for the electric current. This appliance is equipped with a
cord having an equipment-earthing conductor and an earthing plug. The plug must be plugged into an
appropriate outlet that is installed and earthed in accordance with all local standards and requirements.

for personal safety:
DO NOT USE AN EXTENSION CORD OR AN ADAPTER PLUG WITH THIS APPLIANCE.
DO NOT, UNDER ANY CIRCUMSTANCES, CUT OR REMOVE THE
FROM THE POWER CORD. EARTHING CONNECTION
Improper connection of the equipment earthing conductor can result in the risk of an
electric shock.
Check with a qualified electrician or service representative if you are in doubt whether the
appliance is properly earthed.
Do not modify the plug provided with the appliance. If the plug does not fit properly to the
outlet, please have a qualified electrician to install a proper outlet.
Insert the drainhose into a drainpipe with a minimumdiameterof 40mm, or let it run into the sink, making sure to
avoid bending or crimping it.Thetopof the hose must be lessthan1000mm.
A
Counter
Front
Drain pipe
NOTE
The top of the hose
must be less than
1000mm.
φ40mm
B
Pull The safety supply hoses completely out from storage compartment located at rear of dishwasher.
Turn water fully on before starting the dishwasher.
1
Tighter the screws of the safety supply hose to the faucet with thread 3/4inch.
2
3
The appliance must be connected to the water mains using new hose-sets.
The old hose-sets should not be reused.
Water pressure must be between 0,04 MPa and 1 MPa. If the pressure is below theminimum
consult our Service Department for advice.
Please closethe hydrant after using.
Turn off the water.
Release the water pressure by depressing the pressure release button. This relieves water pressure and protects you, and
the room, from severe splashing.
Unscrew The safety supply hose from the faucet..
2
1
Connect the cold water supply hose to a threaded 3/4(inch) connector and make sure that it is fastened tightly in place.
If the water pipes are new or have not been used for an extended period of time, let the water run to make sure that the
water is clearandfreeof impurities. If this precaution is not taken, there is a risk that the water inlet can get blocked and
damage the appliance.
A hose that attaches to a sink spray can burst if it is installed on the same water line as the dishwasher. If your sink has one, it
is recommended thet the hose be disconnected and the hole plugged.
The safety supply hose consists of the double walls. The hose's system guarantees its intervention by blocking the flow of water
in case of the supply hose breaking and when the air space between the supply hose itself and the outer corrugated hose is full
of water.

The followingthings should be checked before starting the dishwasher.
The content of this manual is very helpfulto the users.
After installation, please make sure tokeep this manual.
1
The dishwasher is leveland fixed properly
2 The inlet valve is open
3 There is a leakage at theconnections ofthe conducts
4 The wires are tightly connected
5 The power is switched on
6 The inlet and drain hoses are knotted
7 Allpackingmaterialsand printings should be taken outfromthe dishwasher
Extension Hose
Ifyouneeda drainhoseextension,make sure tousea similar drain hose.
It must be no longer than 4 metres; otherwise the cleaning effectof the dishwasher could be reduced.
Water Outlet
Connect the waterdrain hose.Thedrain hose mustbe correctly fittedto avoid water leaks.
Ensure that the water drain hose is not kinked orsquashed.
If the sink is 1000 higher from the floor, the excess waterin hoses cannot be drained directly
into the sink.Itwillbenecessary todrainexcesswaterfrom hoses into abowlorsuitable
container that is held outside and lower than the sink.
How to Drain ExcessWater From Hoses
Syphon Connection
The waste connection must be at a height less than 100 cm (maximum) from the bottom of the dish.
The waterdrainhose should befixed .
