Morris TTW-163 User manual

TTW-163

ToreviewthesectiononTroubleshootingTips
willhelp youto solve somecommon problems
by yourself .
Dear Customer,
Please carefully reading it before usingthe dishwasher
will help you to use and maintain the dishwasher properly.
Pass it on to any subsequentowner of the appliance.
This manual contains sections of Safety Instructions,
OperatingInstructions,Installation Instructions and
Troubleshooting Tips, etc.
The manufacturer, following a policy of constant
development andupdating of the product, may
make modifications without giving prior notice.
Keep it to refer to at a laterdate.
If you can not resolve the troubles by yourself ,
please ask for the help of professional technicians.
Dishwasher Features.................................... ...3
Attention before or after loading the Dishwasher
Baskets..........................................................8
FilteringSystem.............................................13
Caring for the Dishwasher..................... .........14.
A Loading the Salt into the Softener.................5、
B Fill theRinseAid Dispenser.........................5、
C Function ofDetergent.................................6 、
Loading the Basket...........................................8
Cutlery Basket................................................9
WashCycleTable...........................................11
Turning on theAppliance................................11
Change the Programme.............. ................12....
At the End ofthe Wash Cycle...........................12
PositioningtheAppliance................... ..........16..
Water Connection.................................. .......16.
About Power Connection........................ .......16.
Connection of Drain Hoses..................... .......17.
Start of dishwasher............................. .. ......18.. ..
Beforecallingfor service........................... .....19.
Errorcodes.................................... ..............20.
Technical information.............................. .....21..
Control Panel...................................................3
Whenloadbigger Dinner Plates .....................10
This appliance is intended tobe usedin household
andsimilarapplications suchas:
-staff kitchen areas in shops,offices and other
working environments;
-farm houses;
-by clients inhotels,motels and other residential
type environments;
-bed and breakfast type environments.

1
This appliance must be grounded. In the event of a
malfunction or breakdown, grounding will reduce
the risk of electric shock by providing a path of
least resistance of electric current. This appliance
is equipped with a cord having an equipment-
grounding conductor and a grounding plug.
The plug must be plugged into an appropriate outlet
that is installed and grounded in accordance with
all local codes and ordinances.
Keep children away from detergent and rinse aid, keep
child away from the open door of the dishwasher,
there could still be some detergent left inside.
ren
Do not abuse, sit on, or stand on the door or dish
rack of the dishwasher.
Do not touch the heating element during or
immediately after use.
(This instruction is only applicable to machines
with a visual heating element.)
Do not wash plastic items unless they are marked
dishwasher safe or the equivalent. For plastic items
not so marked, check the manufacturer's
recommendations.
Use only detergent and rinse additives
designed for an automatic dishwasher.
Never use soap, laundrydetergent, or hand
washing detergent in your dishwasher. Keep
these products out of the reach of children.
During installation, the powersupplymustnot
be excessivelyordangerouslybentorflattened.
The doorshouldnotbe left intheopenposition
sincethiscould present atrippinghazards.
Do not tamper with controls.
Do not place any heavy objects of stand on the
door when it is open. The appliance could tip
forward.
When loading items to be washed:
1) Locatesharp itemssothat theyarenot likely
todamagethedoorseal;
2 Warning: Knives and other utensils with
sharp points must be loadedin the basket
with their pointsdown orplacedin a
horizontalposition.
)
When using your dishwasher, you should
prevent plastic items from comingintocontact
withheatingelement.(Thisinstruction isonly
applicable to machines with a visual heating
element.)
If the supply cord is damaged, it must be replaced
by the manufacturer or itsserviceagent or a
similarly qualified person in order to avoid a
hazard.
Please dispose of packing materials properly.
Use the dishwasher only for its intended function.
Remove the door to the washing compartment when
removing an old dishwasher from service or discarding
it.
Dishwasher detergents arestrongly alkaline, they
can be extremely dangerous if swallowed.Avoid
contact with skin and eyesandkeep children away
from the dishwasherwhen the door is open.
Check that the detergent receptible is empty
after completion of the wash cycle.
The applianceis to be connected to the water
mains using new hosesets and that old hose-sets
should not be reused.
The maximumnumber of place settings to be
washed is6.
The maximumpermissible inlet water pressureis
1Mpa.
The minimumpermissibleinlet water pressureis
0.04Mpa.
Children should be supervised to ensure that they do
not play with the appliance.
This appliance is not intended for use by persons
(including children with reduced physical, sensory or
mental capabilities, or lack of experience and
knowledge ,unless they have been given supervision
or instruction concerning use of the appliance by a
person responsible for their safety.
)
When using your dishwasher, follow the precautions listed below:
Do not operate your dishwasher unless all
enclosure panels are properly in place. Open
the door very carefully if the dishwasher is
operating, there is a risk of water squirting out.
Improper connection of the equipment-grounding
conductor can result in a risk of electric shock.
Check with a qualified electrician or service
representative if you are in doubt whether the
appliance is properly grounded. Do not modify the
plug provided with the appliance; If it is not fit for
the outlet. Have a proper outlet installed by a
qualified electrician.

2
Dispose of the dishwasher packaging material correctly.
All packaging materials can be recycled.
Plastic parts are marked with thestandard international abbreviations:
PE for polyethylene, e.g. sheet wrapping material
PS for polystyrene,e.g.padding material
POM polyoxymethylene, e.g. plastic clips
PP polypropylene, e.g. Salt filler
ABS Acrylonitrile Butadiene Styrene, e.g. Control Panel .
Packaging material couldbe dangerous for children!
Fordisposing ofpackage and theappliance please goto arecycling centre. Therefore cut
offthe powersupplycable and makethe doorclosing device unusable.
Cardboard packaging ismanufactured from recycled paperand shouldbe disposedin the
waste papercollection for recycling.
By ensuring thisproduct is disposed of correctly, you will help prevent potential negative
consequences for the environment and human health, which could otherwise be caused
by inappropriatewaste handling of thisproduct.
For moredetailed informationabout recycling of this product, please contact your local
city office and your household waste disposal service.
DISPOSAL: Do not dispose this product as unsorted municipal waste. Collection of such
waste separately for special treatment is necessary.






3
Front view Back View
Filter assemblyDetergent Dispenser
Cup Shelf
Cutlery Basket RinseAid Dispenser
Inlet pipe connector
Drainpipeconnector
SprayArms Basket
1
Salt Container
5
67 89 10
3
2 4
3
26
4
7 8
910
5
1
beforeusing it for the first time.
To get the best performance from yourdishwasher, read all operatinginstructions
5
2
3
4
6
7
Power Button: To turn on/off the power supply.
Power Light:To be on when the ON/OFF Button is
Pressed down.
Washing Program Selector: To press the buttonto
select wash cycles.
Start/Reset Button: Pressthisbutton tostart or
pausethedishwasher.
Washing Program indicator lights
Delay Button ToPress thebutton todelay.：
8
9
SaltWarningLight:Tobeonwhenthesoftener
needs to be refilled.
Rinse-Aid Warning Light: Tobe on whenthe
rinse-aid dispenser needs to be refilled.
Delay time indicator light: When you delay time
(2, 4, 6, or 8 hours), the indicators light will be on
to show one of the delay time.
1
2
6
745 8
9
3
2h 4h 6h 8h
DELAY START
RESET
PROG. ON/OFF

normal for a small amount of water to come out of the salt container.Itis
1. The salt container must only be refilled when the salt warning light in the control panel comes on.
Depending on how fully the salt dissolves, the salt warning light may still be on even though the
salt container is filled.
If there is no salt warning light in the control panel (For some Models),you can judge when to load
the salt into the softener by the cycles that the dishwasher had run.
2. If there are spills of the salt,a soak or a rapid program should be run to remove the excess salt.
Always use salt intended for use withdishwasher.
The salt container is located beneath the basket and shouldbefilled as follows:
Attention!
Only use salt specifically designed for use in dishwashers!All other types of
salt not specifically designed for usein a dishwasher, especially table salt, will
damage the water softener. incase of damagescaused by theuse of unsuitable
salt the manufacturer does not give any warranty nor is liable forany caused
damages.
Only fill withsalt just before starting one of thecomplete washingprogrammes.
This will prevent any grains of salt or salty water, which may have been split,
remaining of the bottom of the machine for any period of time, which may cause
corrosion.
4
Therinse aid is releasedduring the final rinse to prevent water from forming droplets onyour dishes.That can leave
spots and streaks. It also improvesdryingby allowing water to sheet offthe dishes.Your dishwasher isdesigned to
useliquid rinseaids.The rinse aiddispenser islocated inside thedoor next to the detergentdispenser.To fill the
dispenser, open the capand pour the rinse aidintothe dispenseruntil thelevel indicatorturnscompletelyblack.
The volume of the rinse aid container is about 110ml.
RinseAid Dispenser
ARemove the basket and then unscrew and remove the cap from the salt container.
BBefore firstwash, add 1lt. of water in the salt container of your machine.
CPlace the end of the funnel (supplied) into the hole and introduce about 1kg of salt.
DAfter filling the container , screw the cap tightly back clockwise.
EUsually, the salt warning light will be cease to be illuminated within2-6 daysafter the salt container has been filledwith
salt.
FImmediately after filling the salt into the salt container, a washing programme should be started
Otherwisefiltersystem,pumpor other important parts of themachinemaybe damagedby salty
water.Itisoutof warranty.
If your model have water softener, youmay skip this section.no

To open the dispenser, turn the cap to the "open" (left) arrow and lift it out.
Pour the rinse aid into the dispenser, being careful not to overfill.
Replace the cap by inserting italigned with "open" arrow and turning it tothe closed (right) arrow.
Adjusting RinseAid Dispenser
The rinse aid dispenser has six or four settings.Always start with the dispenser
set on "4". If spots and poor drying are problems, increase the amount of rinse
aid dispensed by removing the dispenser lid and rotating the dial to "5". If the
dishes still are not drying properly or are spotted, adjust the dial to the next
higher number until your dishes are spot-free.The recommended setting is "4".
(Factory value is "4".)
Increase the dose if therearedrops of waterorlimespotsonthe dishes after washing.
Reduce itifthere aresticky whitish stains on your dishes ora bluish film on glassware or
knife blades.
1
2
3
As the rinse aid diminishes, the size of the black dot
ontherinse aidlevel indicator changes,as illustrated below.
Full
3/4full
1/2full
1/ 4full- Should refilltoeliminate spotting
Empty
5
When to Refill the RinseAid Dispenser
If thereis no rinse-aid warning light in the controlpanel, you can judge the amount of rinse-aid by the color
oftheoptical levelindicator located nextto thecap. Whentherinse-aidcontainer isfull,thewhole
indicator will be dark .As the rinse-aid diminishes, the size of the dark dot decreases. You should never let
therinseaidgetbelow1/4full.
during the nextwash. Don'tforgettoreplacethe cap before you close dishwasher door.
Clean up any rinse aid split during filling with an absorbent cloth to avoid excessive foaming
Detergents with its chemical ingredients are necessary to remove dirt,crush dirt and transport it outof the dishwasher.
Most of commercial quality detergents are suitable for this purpose.
""
Attention!
Only use branded rinse aid for dishwasher. Never filltherinseaid dispenserwithanyothersubstances
(e.g. Dishwasher cleaning agent, liquid detergent). This would damage the appliance.
Function of RinseAid
Rinse aid is automatically added during the last rinse, ensuring thorough rinsing, and spot and streak free drying.

6
Amount ofDetergentto Use
Basedontheir chemical composition, dishwasher can be split intwobasictypes:
Detergenttabletsofdifferent brandsdissolve at different speeds. For this reasonsome
detergenttablets cannot dissolve and develop theirfull cleaning power during short
programmes.Therefore pleaseuselong programmes whenusingdetergenttablets,to
ensure the complete removal of detergent residuals.
The dispenser must be refilled before the start of each wash cycle following the instructions
provided in the Wash Cycle Table .Your dishwasher uses less detergentandrinse aidthen
conventionaldishwasher. Generally, only one tablespoon ofdetergent isneededfor
a normal wash load.Also, more heavilysoiled items need more detergent.Always add the
detergentjust before starting the dishwasher, otherwise it couldgetdamp and will not
dissolve properly.
Concentrated Detergent
DetergentTablets
DetergentDispenser
Always add the detergent just before starting each wash cycle.
Only use branded detergentaidfordishwasher.
If the lid is closed: press release button.The lid springs open.
conventional, alkaline detergents with caustic components
low alkaline concentrated detergents with natural enzymes
Normally new pulverised detergent is without phosphate.Thewatersoftenerfunctionof
phosphate is not given. In this case we recommend to fill salt in the salt container even when
the hardnessof wateris only 6 dH.If detergents withoutphosphate wereusedin case of hardwater
often white spots appear at dishes and glasses. In this case please add more detergent toreach
better results. Detergents without chlorine do only bleach a little. Strong and coloured spots will not
removed completely. In this case please choose a programme with higher Temperature.
°
Detergent tablet
Detergent powder
Detergent tablets are only for the models with 3 in 1 function or 3 in 1 program.

7
Fill the detergent dispenser with detergent.
The marking indicates the dosing levels , as
illustrated on right:
Theplace of main wash cycle detergent placed.
Theplace of pre-wash cycle detergent placed.
Please observe themanufacturers dosing and storage
Recommendationsas statedonthedetergent packaging.
Close the lid and press until it locks in place.
If the dishes are heavily soiled, place an additional
detergent dose in the pre-wash detergent chamber.This detergent will take effect during the pre-wash phase.
A
B
Fill in detergent
You find information about the amount ofdetergent for thesingle programme onthe last page.
Pleaseaware, that according tothe level soiling and the specific hardness of water differencesarepossible.
Pleaseobserve themanufacturer's recommendationsonthe detergentpackaging.
Cutlery with wooden, horn china or
mother-of-pearl handles
Plastic items that are not
Older cutlery with glued parts that is not
temperature resistant
Bonded cutlery items or dishes
Pewteror cooper items
crystal glass
Steel items subject to rusting
Wooden platters
Items made from synthetic fibres
heat resistant
Sometypes ofglasses canbecome
dull after alargenumber of washes
Silverand aluminium partshavea
tendency to discolour during washing
Glazed patterns may fade if machine
washed frequently
Are not suitable Are of limited suitability
Don't putpowder detergentintothedispenser until you're ready to wash dishes.
Use only detergent specifically made for use in dishwashers. Keep your detergent fresh and dry.
Proper Use of Detergent
Dishwasher detergent is corrosive! Take care to keep it out of reach of children.
Usea mild detergent that isdescribed as'kind ofdishes'.If necessary, seek further
information from detergent manufacturers.
For particular items, select a programme with as low a temperature.
To prevent damage, donot take glass andcutlery out of the dishwasher immediately
after the programmehas ended.
Consider buying utensils which are identified as dishwasher-proof.

Position thedishes andcookware sothat theywill notget movedby thespray ofwater.
Loading theBasketLoading theBasket
8
Dishes anditems ofcutlery mustnot lieinside oneanother,or covereach other.
To avoiddamage toglasses, theymust nottouch.
Load large itemswhich are mostdifficult toclean into thebasket.
Long bladedknives storedin anupright positionare apotential hazard!
Long and/orsharp itemsof cutlerysuch ascarving knivesmust bepositioned
horizontally in thebasket.
Please donot overloadyour dishwasher. Thisis importantfor goodresults andfor
reasonable energyconsume.
Load hollowitems suchas cups,glasses, pansetc. Withthe openingdownwards sothat
water cannotcollect inthe containeror adeep base.
(For bestperformance of thedishwasher, followthese loading guidelines.
Features and appearanceof baskets andcutlery baskets mayvary from yourmodel.)
Scrape offany large amountsof leftover food.Soften remnants ofburnt food inpans
It isnot necessaryto rinsethe dishesunder runningwater.
Place objects inthe dishwasher infollowing way:
1.Itemssuch ascups, glasses,pots/pans, etc.are facedown.
2.Curved items,or those withrecesses, should beloaded at aslant so thatwater can runoff.
3.Allutensils arestacked securelyand cannot tipover.
4.All utensilsare placed inthe way that the sprayarms can rotatedfreely during washing.
NOTE:NOTE:
Very smallitems should notbe washed inthe dishwasher asthey could easilyfall out ofthe basket.
Attention beforeor afterloading theDishwasher BasketsAttention beforeor afterloading theDishwasher Baskets
IN
Saucers
4
Medium servingbowl
3
Glasses
1
Cups
6
Oval platter
7
Dinner plates
8
Soup plates
Dessert dishes
9
Dish
5
Cutlery basket
10
2
11
66
998877
33
55
11
22
44
33
1010
33

9
Cutlery should be placed inthe cutlery basket with handles atthe bottom. If the rack has sidebaskets, the spoon
shouldbe loadedindividually into the appropriateslots, especially long utensils shouldbeplaced inthehorizontal
position at the frontof the upperbasket as shown.
Do not let any item extend through bottom.
Always load sharp utensils with the sharp point down!
616
2
1
1
1
2
5
55
1
2
5
5
1
4
3
3
3
3
4
4
4
7
Teaspoons
4
Soup spoons
2
Forks
1
Serving forks
8
Serving spoons
6
Knives
5
3
Dessert spoons
7
Gravy ladles
3
5
4
48
3
2
22
Plate racksof Basket
The basket is fitted with plate racks which
can be stowed horizontal if required.

10
Plate racksof Basket
When load biggerDinner plates,
please fold the rack to left picture
showed location.
The maximum plate canbe loaded
is 270mm(10 inches)diameter.
When loadbigger DinnerPlatesWhen loadbigger DinnerPlates
Loading theBasketLoading theBasket
Position thedishes andcookware sothat theywill notget movedby thespray ofwater.
IN
Saucers
4
Large servingbowl
3
Glasses
1
Cups
6
7
Dinner plates
8
Soup plates
Dessert dishes
9
Dish
5
Cutlery basket
2
33
11
11
8866
22
44
33
55
99
77
66

11
Starting a washcycle...
Draw out the basket(seethesection entitled Loading the Dishwasher ).
Pour in the detergent (see the section entitled Salt,
DetergentandRinseAid ).
Insert the plug into thesocket. The powersupply is 220-240
VAC 50HZ,the specification of the socket is 10A250VAC.
Make sure that the water supply is turned on to full pressure.
“”
“
”
Press the program button , the wash program will be changed as follows direction
If a programisselected,theresponselightwilllight. Thenpressthe
Start/Reset button, the dishwasher begins to start.
Intensive->Normal->Eco->Rapid->Soak;
When you press the Start/Reset button to pause duringwashing,
the program light will stop blinking and the dishwasher will mooing
every minute unless youpressthe Start/Reset button tostart.
For normally soiled loads,
such as pots, plates,
glasses and lightly
soiledpans.
Standard daily cycle for
normallysoiled loads,
such as pots, plates,
glasses.
For heaviest soiled crockery,
andnormally soiled pots
pans dishes etc with dried
onsoiling
、
、
A shorter washfor lightly soiled
loads and quick wash
To rinse dishes that you
plan to wash later that day.
15g.
125
170
145
30
14
0.70
0.61
0.94
0.30
0.01
8.4
7.0
11.0
6.0
2.1
Pre-wash
Wash (60 )
Rinse
Rinse (70 )
Drying
℃
℃
Pre-wash
Wash (50 )
Rinse
Rinse (70 )
Drying
℃
℃
Pre-wash
Wash (40 )
Rinse ℃
Rinse
Intensive
Pre-wash 50
Wash (70 )
Rinse
Rinse
Rinse (70 )
Drying
℃
℃
℃
()
Soak
Rapid
Normal
(*EN 50242)
Eco
(or )3in1
3/15g
(or )3in1
3/15g
(or )3in1
3/15g
*EN 50242 : This programme is the test cycle. The information for comparability test
in accordance with EN 50242, as follows:
Capacity: 6setting
The power consumption of off-mode is 0.3W
left-on modeis 0.4W
Rinse aid setting: 6

It is dangerous to open the door when washing, because the hot water may scald you.
Whenthe working cycle has finished, the buzzer of dishwasher will sound 8 seconds, then stop.Turn off
the appliance using the ON/OFF button, shut off the water supply and open the door of the dishwasher.
Wait a few minutes before unloadingthe dishwasher to avoidhandling the dishes and utensils while they
are still hot and more susceptible to breakage. They will also dry better.
Switch Off the Dishwasher
1.Switch off the dishwasher by pressing the ON/OFF button.
2.Turnoffthewatertap!
Open the door carefully.
Hot dishes are sensitive to knocks. The dishes should therefore be allowedto cool down around 15 minutes
before removingfrom the appliance.
Open the dishwasher's door, leave it ajar and wait a few minutes before removing the dishes. In this way they
will be cooler and the drying will be improved.
Unloadingthedishwasher
It is normal that the dishwasher is wet inside.
will keep on working after 10 seconds.
Ifyou open the door when washing, themachine will pause. When you close the door , the machine
12
Aforgotten dish can be added any time before the detergent cup opens.
Add forgotten dishes.
Close the door
After the spray arms stop working,you can open the door
completely.
2
3
Open the door a little to stop the washing.
14
5
6
Premise: Otherwise, the detergent may have already been
released, and the appliance may have alreadydrained the wash water. If this
isthe case, the detergent dispenser must be refilled (seethe section entitled
" Loading the Detergent " ).
Press Start/Reset Button more than three seconds the machine will be in stand
bystate ,then you can change the program to the desired cycle setting(see
thesection entitled " Starting a wash cycle. . ." ).
The program lightsshow thestate of the dishwasher:
a) One of the programlights on----------stand byor pause
b) One of the programlights blinking----- run
You can modify the washing program, When the dishwasher just
runs for a short time.
Press the start/reset button
Press the start/reset button, the dishwasher will run
after 10 seconds.

7.Maintenance and Cleaning7.Maintenance and Cleaning
The filter preventlarger remnants offood or otherobjects from gettinginside the pump.
The filtersystem consists ofa coarse filter, aflat (Main filter)
and a microfilter (fine filter).
Food andsoil particlestrapped bythis filterare pulverizedby a
special jeton thespray armand washeddown todrain.
Main filter 1
Larger items, suchas pieces ofbone or glass,that could block
the drain aretrapped in thecoarse filter.To remove theitems
caught by thefilter, gentlysqueeze the tapon the topof this
filter andlift out.
Coarse filter3
This filterholds soiland foodresidue inthe sumparea and
prevents itfrom beingredeposit onthe dishesduring washcycle.
Fine filter 2
Filtering SystemFiltering System
Filter assembly
The filterefficiently removesfood particles fromthe wash water, allowing itto be re-cyclatedduring the cycle.
For best performanceand results, thefilter assembly mustbe regularly. For thisreason, it isa good ideato
remove the largerfood particles trappingin the filterafter each washcycle by rinsingthe filterand cup under
running water.To remove thefilter assembly, pull onthe cup handlein the upwarddirection.
WARNING!WARNING! Never runthe dishwasherwithout thefilters inplace.
The dishwashermust neverbe usedwithout thefilters.
Improper replacementof thefilter mayreduce theperformance levelof theappliance
and damagedishes andutensils.
nn
nn
nn
the filter system will be installed.
If do it from step1 to step 3, the filter system will be removed; while if do it from Step 3 to Step 1,
NOTE:NOTE:
13

The control panelcan be cleaned by using alightly dampened cloth and dry thoroughly.
The exterior use a good appliance polish wax.
Never use sharp objects, scouring pads or harsh cleaners on any part of the dishwasher.
ProtectAgainst Freezing
1.Cut off electrical power to the dishwasher.
2.Turn off the water supply and disconnect the water inlet pipe from the water valve.
3.Drain water from the inlet pipe and water valve. (Use a pan to catch the water)
4.Reconnect the water inlet pipe to the water valve.
5.Removethe filterat thebottomofthe tub anduse asponge touseup waterin sump.
please take frost protection measures ondishwasher in winter.E fter washingcycles,
please operate as follows ach time a
：
- Inspect the filters for blockingevery time the dishwasher has been used.
- By unscrewing the coarsefilter.you can remove thefilter system.Remove any food remnants and
cleanthefilters underrunningwater.
Remarks:
CleaningThe Filter
CleaningThe Door
To clean the coarse filter and the fine filter, use a cleaning brush. Reassemble thefilter parts as shown in the figures
inthe lastpageandreinsert the entire assemblyin the dishwasher, positioning in its seat and pressing downward.
The entirefilter assembly shouldbe cleanedonce a week.
Whencleaning the filters, don't knock on them. Otherwise, thefilters could be
contorted andtheperformance ofdishwasher couldbe debased.
To cleantheedgearoundthedoor, youshoulduseonlya soft warm,
damp cloth. To avoid penetration of water into the door lock and
electrical components, do not use a spray cleaner of any kind.
Never usea spray cleaner toclean the door panel as it may damage the door lock
and electricalcomponents.
Abrasive agent or some paper towel should not be used because of the risk of
scratching or leaving spots on the stainless steel surface.
14
If your dishwasher cannot work because of the ice, please contact professional service persons.

Itis recommend thatyourun awashcycle withthe
dishwasher empty and then remove the plug from the
socket, turn off the water supply and leave the door of
the appliance slightly open. This will help the door
sealsto ast longerandpreventodours from forming
withintheappliance.
If the appliance must be moved, try to keep it in the
verticalposition. Ifabsolutelynecessary, itcanbe
positioned on its back.
One ofthefactors thatcause odors to form inthe
dishwasher is food that remains trapped in the seals.
Periodic cleaning with adamp sponge will preventthis
from occurring.
After every wash, turn off the water supply to the
appliance and leave the doorslightlyopen sothat
moisture and odors are not trapped inside.
Before cleaning or performing maintenance, always
remove the plug from the socket.
Tocleantheexteriorandrubberpartsofthedishwasher,
donot use solventsor abrasivecleaningproducts.
Only use a cloth with warm soapy water.
To remove spots or stains from the surface of the
interior, use a cloth dampened with water with a little
vinegar, or a cleaning product madespecificallyfor
dishwashers.
After Every Wash
Remove the Plug
No Solvents orAbrasive Cleaning Moving theAppliance
Seals
When itis not in needfor a long time
15
The installationof the pipes
and electrical equipments
should be done by professionals.
Electrical Shock Hazard
Disconnect electrical power before
installingdishwasher.
Failureto do so can result indeath
or electrical shock.
The installationposition ofdishwasher should be near the existing inletanddrain
hosesandpowercord.
One side of the cabinet sink shouldbe chosen to facilitatethe connection ofdrain
hosesof the dishwasher.
Cleaning the SprayArms
Thespray arms canbe easily removed for periodiccleaning
of the nozzles, to prevent possible clogging. Wash them
under running water and carefully replace them in their seats,
checking that their rotary movementis inno way impeded.
Graspthe middle ofthe spray arm, pull itupwardsto remove
it.Wash thearms undera jetof running waterandreturn them
carefully to their seat. After reassembly, check that the spray
arms turn freely. Otherwise,check that they havebeen
installed correctly.

Ensure the voltage and frequency of the power being correspondsto
those on the rating plate. Only insert the plug into an electrical socket which is earthed
properly. If the electrical socket to which the appliance must be connected is not
appropriate fortheplug, replacethe socket, ratherthan usingaadaptors or thelike as
they couldcause overheatingandburns.
Pleaselook at therating label to know the rating voltage and connect the dishwasher to the appropriate power supply.
Use the required fuse 10 amp, timedelay fuse or circuit breaker recommended and provide separate circuit serving
only this appliance.
This appliance must be earthed. In the event of a malfunction or breakdown, earthing will reduce the risk of
electric shock by providing a path of least resistance for the electric current. This appliance is equipped with
a cord having an equipment-earthing conductor and an earthing plug. The plug must be plugged into an
appropriate outlet that is installed and earthed in accordance with all local standards and requirements.
For personal safety:
DO NOT USEAN EXTENSION CORD OR AN ADAPTER PLUG WITH THIS APPLIANCE.
DO NOT, UNDERANY CIRCUMSTANCES, CUT OR REMOVE THE EARTHING
CONNECTION FROM THE POWER CORD.
16
for personal safety:
DO NOT USE AN EXTENSION CORD OR AN ADAPTER PLUG WITH THIS APPLIANCE.
DO NOT, UNDER ANY CIRCUMSTANCES, CUT OR REMOVE THE
FROM THE POWER CORD. EARTHING CONNECTION
Improper connection of the equipment earthing conductor can result in the risk of an
electric shock.
Check with a qualified electrician or service representative if you are in doubt whether the
appliance is properly earthed.
Do not modify the plug provided with the appliance. If the plug does not fit properly to the
outlet, please have a qualified electrician to install a proper outlet.
and the sides, along the adjacent cabinets or wall. The dishwasher is equipped with water supply
Position the appliance in the desired location. The back should rest against the wall behind it,
and drain hosesthat canbepositioned totheright ortheleftto facilitate properinstallation.
Connect the cold water supply hose to a threaded 3/4(inch) connector and make sure
that it is fastened tightly in place.If the water pipes are new or have not been used for
an extended periodof time, let the water run to make sure that the wateris clear and
free ofimpurities. Ifthisprecaution isnottaken, thereis a risk that the water inletcan
get blocked and damagethe appliance.
Please close the hydrant afterusing.

Insert the drain hose intoa drainpipe with a minimum diameterof 4cm,or let it
runintothesink,makingsuretoavoidbendingorcrimpingit.Usethespe ial
plastic support thatcomes with the appliance.The free endof the hosemust be
ata height lowerthan75cmand must not be immersed inwater to avoid the back
flow of it.
c
17
The special plastic hose support mustbe solidlyfastened tothe wall to
prevent thedrainhose from movingand allowing water to spill outside
the drain.

18
If the sink is 1000 higher from the floor, the excesswater inhoses cannot be drained directly
into the sink. It will benecessary todrain excess water fromhoses into a bowl or suitable
container that is held outside and lower than the sink.
Connectthewater drain hose.Thedrain hosemustbecorrectlyfitted toavoid waterleaks.
Ensure that the water drain hose is not kinked or squashed.
If you need a drain hose extension, observe to use a similar drain hose.
Itmust benolonger than4metres; otherwise the cleaning effectofthe dishwasher couldbereduced.
Water Outlet
Extension Hose
How to Drain Excess Water From Hoses
The followingthingsshould be checked beforestarting the dishwasher.
1
The dishwasher is level andfixed properly
2 The inlet valve is open
3 There is aleakage at theconnections ofthe conducts
4 The wires are tightly connected
5 The poweris switched on
6 The inlet and drain hoses are knotted
7 Allpacking materials andprintings shouldbe taken out fromthe dishwasher
The content of this manual is very helpfulto the users.
After installation, please make sure to keep this manual.
