Morrison 571551 User manual

571551 - Petrol Hedge Trimmer Owner’s Manual - May 2014
www.morrisonoutdoor.com
Petrol Hedge Trimmer
Owner’s Manual
WARNING
Always wear eye and hearing protection when operating this machine.
Minimize the risk of injury: Read this manual and familiarize yourself with its contents.
This product is intended for outdoor use only and should be used only in well ventilated areas.
Part No: 571551
Revised May 2014
Pantone 1797C

2
571551 - Petrol Hedge Trimmer Owner’s Manual - May 2014
Contents
egaPnoitpircseD
3noitcudortnI.1
3tnemnorivnEehtfonoitcetorP.2
3slobmyS.3
4atadlacinhceT.4
1 Introduction
Before you start working with your new machine, please
read carefully the instruction manual. Please follow the
instructions marked as Attention! or Warning!
2 Protection of the Environment
Please ensure ecological disposal of all materials you do not
need any more. Any machinery, oils and packaging should be
sorted and deposited at a local recycling centre.
3 Symbols
You will find a number of symbols on the hedge trimmer.
The symbols will provide you with important information about
the product or instructions for its use.
Attention: When handling the hedge trimmer
please follow specific safety measures!
• Before you use the trimmer please read the whole
instruction manual and make sure you under stand it.
Non-compliance with the instructions can
ENDANGER YOUR LIFE!
Attention Wear hearing,
vision, head
protective
aids.
Read the
instruction
manual.
Wear
protective
clothing.
Wear gloves. Wear safety
boots.
Attention
danger of fire
due to fuel
ignition.
4snoitcurtsniytefaS.5
6. Before the first use of the machine 5
5)a.tcip(enihcamehtgnitratS.7
gninoitcnufremmirtegdeH.8
9. Work safely and with prudence
6snoitcurtsniecnanetniaM.01
atadleuF.11 6
seruliafenigne/sriapeR.21 7
6
6

3
571551 - Petrol Hedge Trimmer Owner’s Manual - May 2014
Contents
egaPnoitpircseD
3noitcudortnI.1
3tnemnorivnEehtfonoitcetorP.2
3slobmyS.3
4atadlacinhceT.4
1 Introduction
Before you start working with your new machine, please
read carefully the instruction manual. Please follow the
instructions marked as Attention! or Warning!
2 Protection of the Environment
Please ensure ecological disposal of all materials you do not
need any more. Any machinery, oils and packaging should be
sorted and deposited at a local recycling centre.
3 Symbols
You will find a number of symbols on the hedge trimmer.
The symbols will provide you with important information about
the product or instructions for its use.
Attention: When handling the hedge trimmer
please follow specific safety measures!
• Before you use the trimmer please read the whole
instruction manual and make sure you under stand it.
Non-compliance with the instructions can
ENDANGER YOUR LIFE!
Attention Wear hearing,
vision, head
protective
aids.
Read the
instruction
manual.
Wear
protective
clothing.
Wear gloves. Wear safety
boots.
Attention
danger of fire
due to fuel
ignition.
4snoitcurtsniytefaS.5
6. Before the first use of the machine 5
5)a.tcip(enihcamehtgnitratS.7
gninoitcnufremmirtegdeH.8
9. Work safely and with prudence
6snoitcurtsniecnanetniaM.01
atadleuF.11 6
seruliafenigne/sriapeR.21 7
6
6

4
571551 - Petrol Hedge Trimmer Owner’s Manual - May 2014
4 Technical data
5 Safety Instructions
To use the hedge trimmer safely it is important to follow all
instructions and information in the instruction manual dealing
with safety, assembly and machine operation. Anybody who
will carry out machine operation or maintenance should be
familiar with the instruction manual. Children should not use
the hedge trimmer. When operating this unit the user should be
vigilant of proximity to other people, animals and any potential
hazards. This hedge trimmer should be used in conjunction
with any laws or bylaws. The manufacturer cannot be hold
liable if unauthorised changes were carried out to the machines
and the changes resulted in damage.
Caution! When using machine tools it is important
to follow basic preventive measures. Please follow
the tips and instructions stated in the additional
safety instructions.
1. Use the hedge trimmer in safe working conditions. The
Morrison Hedge Trimmer is only designed for outdoors use.
Use only outdoors to avoid build up of noxious gases.
Always inspect your working area for potential hazards
before beginning work.
2. Keep a safe proximity to others. Always maintain a safe
distance (outside of swing radius) from any other persons,
or animals.
3. Ensure safe tool storage. Machines that are not at
use should be stored at a dry place if possible high up
alternatively they should be locked away so that other
persons could not gain access to them.
4. Use the right tool for each job. Only use the Morrison
Hedge Trimmer on work specified by the manufacturer.
5. Wear appropriate clothing. Wear clothes that
are strong and not loose fitting when operating
machine.
6. Use personal protective aids. Wear safety shoes
with steel toe boxes and non slippery soles.
7. Wear protective glasses. Objects can be flung
away by the machine.
8. Wear hearing protective aids. Wear hearing
protective aids, e.g. ear plugs.
9. Hand protection. Wear thick gloves – good
protection is provided by gloves made of leather.
10. Hedge trimmer transportation. Only transport
the hedge trimmer when turned off and with blade cover in
position.
11. Do not use hedge trimmer while impaired. Never use
this machine when under the influence of alcohol, drugs
or any mind altering substance. Do not use when suffering
injury that will affect use.
12. Switch unit off before refuelling. Switch hedge
trimmer off and allow to cool before refuelling.
Never use fuel near naked flame. Be sure to avoid
smoking near fuel and machinery.
13. Usage period and breaks. After a longer period of usage
you might experience problems with blood circulation in
your hands due to the vibrations. The period of usage can
be extended by wear ing suitable gloves and taking regular
breaks. Please be aware that the time of usage is lowered
by personal dispositions to bad circulation, a low outside
temperature or a firm grip of the tool when working.
14. Watch for damaged parts. The machine should be
carefully inspected before use. If there is damage of any
sort this should be assessed ,and if necessary repaired by
a Garden Product Service person before use.
15. Make sure that the protective cover of the hedge trimmer
works perfectly and it is installed in such a way that the
knife teeth are always covered.
16. Turn off machine before repairing. Ensure machine is
turned off before beginning repair/adjustment work.
Caution!! Using other knife bars and other
fixtures and extensions that are not expressly
recommended can endanger people and property.
The machine can be used only for the designed purpose. Any
machine usage at variance with its purpose is considered
unprofessional usage. The user is liable for the damage caused
to property and injuries resulting from this unprofessional
handling, and not the manufacturer.
The manufacturer cannot be liable in case the machine was
modified or used unprofessionally and damage arose as the
result of these actions.
When handling the machine professionally there is always
some risk that cannot be eliminated.
The machine type and construction might present the
following potential risks:
• Contact with an unprotected knife bar
(danger of cutting yourself)
• Touching the trimmer in operation
(danger of cutting yourself)
• Unexpected, sudden movements of the cut material and its
parts (danger of cutting yourself)
• Spurning of faulty knife teeth and parts of knife bar
(danger of cutting yourself)
• Hearing injuries if appropriate safety aids are not worn.
• Creation of harmful dust or gas when using the machine in
closed premises (sickness).
• Do not use deformed or damaged cutting knives
(knife bar destruction).
If you have any doubt over condition of petrol
hedge trimmer, consult a specialist garden
product service person before beginning use.
6 Before the first use
of the machine
Caution! Before you start using the hedge trimmer
make sure it is in a sound operational condition. If
you have any doubts, do not start the machine!
Pay attention mainly to the following points:
• Cutting knives are installed in correct position
• All switches are going easily
• Spark plug is installed safely. If the plug is loose sparking
can occur followed by ignition of the created mixture of
fuel and air.
Before starting the machine all necessary safety and protective
devices must be duly installed in their positions.
The cutting knife must be loose enough to move.
Before starting the hedge trimmer make sure the knife is
installed correctly and the movable parts are not jammed.
Caution! If in any doubts contact a specialist
grade product service person.
7 Starting the machine (pict. a)
1. Pour mixed fuel into the relevant tank. Make sure you do
not spill any fuel (danger of ignition). Fuel mix composition
can be found in Chapter 12.
2. Move at least 3 metres from the place of refuelling. Do not
start the machine in closed or badly ventilated premises.
3. Click switch (3) into the ON position. If starting a cold
engine the choke switch (8) must be moved to the left.
4. Using the hand fuel
pump (9) fuel can
be pumped into
the carburettor.
This will lessen the
number of start
attempts after a
longer break.
5. Now place the
hedge trimmer
on the ground,
straddle the
machine and place
one hand on the
side grip (7). Use
your other hand
to pull the starting
cable (1) and wait
for the engine to start.
ATTENTION! Do not pull too much; the cable
length is 90 cm. Watch the movable knife.
6. Once the engine is running, pump the throttle fully a few
times. After about the fourth time you can move the choke
to the right.
7. Using the tongue (5) you can move the handle. If you
want to switch off the machine, put the switch (3) into the
“OFF” position.
9
1
23
4
5
6
7
Picture a
180°
Net Weight (kg) 57
Outward Size Total Length (mm) 113
Total Width (mm) 250
Total Height (mm) 230
Blade Type Double Sided
Total Length (mm) 600
Power Transmission Method Automatic, centrifugal clutch, spur
gear, cam-crank
Reduction Rate 5.1 : 1
(46 : 9)
Engine Name of Engine 1E34FL-S
Type Single sylinder air cooling 2-cycle
gasoline engine
Displacement Volume (cc) 25.4
Maximum Output (kW/r/min) 0.65/7500
Fuel Tank Capacity 0.5
Fuel Used Mixture 30:1 (when using market oil)
Lubricating Oil Used 2-cycle engine oil
Carburetor Diaphragm, rotary valve
Sparking Method IC-controlled fly wheel magnet
Sparking Plug L9T
Starting Method Recoil starter
Sound Power Values (db(A)) < 95
Vibration Values (m/s2)< 15
Vibration test standard & Noise test standard:
LY/T 1619-2004: Garden machinery - Portable powered hedge-trimmers

5
571551 - Petrol Hedge Trimmer Owner’s Manual - May 2014
4 Technical data
5 Safety Instructions
To use the hedge trimmer safely it is important to follow all
instructions and information in the instruction manual dealing
with safety, assembly and machine operation. Anybody who
will carry out machine operation or maintenance should be
familiar with the instruction manual. Children should not use
the hedge trimmer. When operating this unit the user should be
vigilant of proximity to other people, animals and any potential
hazards. This hedge trimmer should be used in conjunction
with any laws or bylaws. The manufacturer cannot be hold
liable if unauthorised changes were carried out to the machines
and the changes resulted in damage.
Caution! When using machine tools it is important
to follow basic preventive measures. Please follow
the tips and instructions stated in the additional
safety instructions.
1. Use the hedge trimmer in safe working conditions. The
Morrison Hedge Trimmer is only designed for outdoors use.
Use only outdoors to avoid build up of noxious gases.
Always inspect your working area for potential hazards
before beginning work.
2. Keep a safe proximity to others. Always maintain a safe
distance (outside of swing radius) from any other persons,
or animals.
3. Ensure safe tool storage. Machines that are not at
use should be stored at a dry place if possible high up
alternatively they should be locked away so that other
persons could not gain access to them.
4. Use the right tool for each job. Only use the Morrison
Hedge Trimmer on work specified by the manufacturer.
5. Wear appropriate clothing. Wear clothes that
are strong and not loose fitting when operating
machine.
6. Use personal protective aids. Wear safety shoes
with steel toe boxes and non slippery soles.
7. Wear protective glasses. Objects can be flung
away by the machine.
8. Wear hearing protective aids. Wear hearing
protective aids, e.g. ear plugs.
9. Hand protection. Wear thick gloves – good
protection is provided by gloves made of leather.
10. Hedge trimmer transportation. Only transport
the hedge trimmer when turned off and with blade cover in
position.
11. Do not use hedge trimmer while impaired. Never use
this machine when under the influence of alcohol, drugs
or any mind altering substance. Do not use when suffering
injury that will affect use.
12. Switch unit off before refuelling. Switch hedge
trimmer off and allow to cool before refuelling.
Never use fuel near naked flame. Be sure to avoid
smoking near fuel and machinery.
13. Usage period and breaks. After a longer period of usage
you might experience problems with blood circulation in
your hands due to the vibrations. The period of usage can
be extended by wear ing suitable gloves and taking regular
breaks. Please be aware that the time of usage is lowered
by personal dispositions to bad circulation, a low outside
temperature or a firm grip of the tool when working.
14. Watch for damaged parts. The machine should be
carefully inspected before use. If there is damage of any
sort this should be assessed ,and if necessary repaired by
a Garden Product Service person before use.
15. Make sure that the protective cover of the hedge trimmer
works perfectly and it is installed in such a way that the
knife teeth are always covered.
16. Turn off machine before repairing. Ensure machine is
turned off before beginning repair/adjustment work.
Caution!! Using other knife bars and other
fixtures and extensions that are not expressly
recommended can endanger people and property.
The machine can be used only for the designed purpose. Any
machine usage at variance with its purpose is considered
unprofessional usage. The user is liable for the damage caused
to property and injuries resulting from this unprofessional
handling, and not the manufacturer.
The manufacturer cannot be liable in case the machine was
modified or used unprofessionally and damage arose as the
result of these actions.
When handling the machine professionally there is always
some risk that cannot be eliminated.
The machine type and construction might present the
following potential risks:
• Contact with an unprotected knife bar
(danger of cutting yourself)
• Touching the trimmer in operation
(danger of cutting yourself)
• Unexpected, sudden movements of the cut material and its
parts (danger of cutting yourself)
• Spurning of faulty knife teeth and parts of knife bar
(danger of cutting yourself)
• Hearing injuries if appropriate safety aids are not worn.
• Creation of harmful dust or gas when using the machine in
closed premises (sickness).
• Do not use deformed or damaged cutting knives
(knife bar destruction).
If you have any doubt over condition of petrol
hedge trimmer, consult a specialist garden
product service person before beginning use.
6 Before the first use
of the machine
Caution! Before you start using the hedge trimmer
make sure it is in a sound operational condition. If
you have any doubts, do not start the machine!
Pay attention mainly to the following points:
• Cutting knives are installed in correct position
• All switches are going easily
• Spark plug is installed safely. If the plug is loose sparking
can occur followed by ignition of the created mixture of
fuel and air.
Before starting the machine all necessary safety and protective
devices must be duly installed in their positions.
The cutting knife must be loose enough to move.
Before starting the hedge trimmer make sure the knife is
installed correctly and the movable parts are not jammed.
Caution! If in any doubts contact a specialist
grade product service person.
7 Starting the machine (pict. a)
1. Pour mixed fuel into the relevant tank. Make sure you do
not spill any fuel (danger of ignition). Fuel mix composition
can be found in Chapter 12.
2. Move at least 3 metres from the place of refuelling. Do not
start the machine in closed or badly ventilated premises.
3. Click switch (3) into the ON position. If starting a cold
engine the choke switch (8) must be moved to the left.
4. Using the hand fuel
pump (9) fuel can
be pumped into
the carburettor.
This will lessen the
number of start
attempts after a
longer break.
5. Now place the
hedge trimmer
on the ground,
straddle the
machine and place
one hand on the
side grip (7). Use
your other hand
to pull the starting
cable (1) and wait
for the engine to start.
ATTENTION! Do not pull too much; the cable
length is 90 cm. Watch the movable knife.
6. Once the engine is running, pump the throttle fully a few
times. After about the fourth time you can move the choke
to the right.
7. Using the tongue (5) you can move the handle. If you
want to switch off the machine, put the switch (3) into the
“OFF” position.
9
1
23
4
5
6
7
Picture a
180°

6
571551 - Petrol Hedge Trimmer Owner’s Manual - May 2014
8 Hedge trimmer functioning
The Morrison hedge trimmer is equipped with quick stop
function which stops the knife immediately once the throttle is
released to prevent a possible accident.
If you want to switch off the machine, you must move the
switch (pict. a; item 3) into the “OFF”position.
• When cutting hedges comply with regulations valid in the
relevant country and local regulations.
• If the branches are bigger than the maximal cutting power,
they must be removed by other machinery.
• If heavy pruning is required, you should work in stages.
9 Work safely and
with prudence
1. Hold the hedge trimmer safely in both hands!
2. Trim and cut only wood and wooden objects!
3. Work with consideration and do not threaten anyone when
cutting. Work calmly with prudence!
4. Work when it is light and visible!
5. Constantly watch the cutting knife!
6. Never cut below shoulder height!
7. Work only with a sharpened and correctly installed
cutting knife!
8. Do not stand on a ladder when working!
9. Work only on sound and stable ground!
10 Maintenance Instructions
ATTENTION! The following instructions are
valid for standard working conditions. In case
of aggravated conditions such as heavy dust
contents, wood with a high content of resin or
longer working periods the interval must be
shortened accordingly.
Before you start work check the following:
• throttle
• visually check the whole machine
• position of the knife bar or the cutting knife
• degree of sharpness
• wear and tear or the guiding bar damage
After you finish working check
the whole machine and clean it.
Regularly check and maintain the following:
• air filter (clean if necessary)
• spark plugs pict. a; item 6 (if replacement is needed)
• cutting knife sharpness (clean well and lubricate)
When repairing or maintaining the hedge trimmer, have it
always switched off.
11 Fuel data
Refuelling
Mix unleaded petrol with brand oil for two-stroke engines with
air cooling in the 1:30 ratio. This means that for example 5 l of
petrol is mixed with 0,16 l of oil.
12 Repairs/engine failures
Repairs that require special professional knowledge should be carried out by authorised service centres.
Unprofessional interference can damage the machine or endanger your safety.
ydemeResuaCeruliaF
Engine not starting pulliF.1knatytpmE.1
,semitlarevesroftrats,elttorhtehtesolC.2enignededoolF.2
in case of need take out the spark plug
and dry it
3. Fouled spark plug (remains of carbon on
the electrodes) electrodes too
far away
3. Clean the spark plug, check its
temperature, replace if needed.
Adjust at 0.6-0.7 mm
riahtiwrotterubracehtnaelC.4stejstirorotterubracdeluoF.4
ronoitcennocgulpkrapsdegamaD.5
damaged spark plug
5. Replace
6. Incentive spar missing 6. Check short circuit button cable, ignition
module, in case of need replace. Adjust
the gap (0,3-0,4 mm).
Engine runs too fast when idle ehtesolcylevitanretla;ylwolspumraW.1enignedloC.1
choke a bit.
Engine does not reach its
maximal capacity
1. Fouled spark plug (remains of car
bon on the electrodes) electrodes too far
away
1. Clean the spark plug, check its
temperature, replace if needed.
Adjust at 0.6-.07 mm.
riahtiwrotterubracehtnaelC.2stejstiroro
tterubracdeluoF.2
3. Fouled air fi naelC.3retl
evomer,tinaelcdnatsuahxeehttuoekaT.4lennahctsuahxe,tsuahxE.4
remains of carbon
gnilaestonesacknarcnignirgnilaeS.5
properly
5. Replace
6. Worn cylinders, pistons and piston rings 6. Replace the cylinder, piston or piston
rings, reface the cylinder and piston,
assembly
snoitcurtsniehtotgnidroccapulliF.7)liohcumoot(ximleufgnorW.7
revuoleludomnoitingiehttsujdA.8noitingidaB.8
(0.3-0.4 mm)
Engine would not stop 1. Spark plug is light grey with signs of
heating (heating drops)
1. Install a spark plug with a higher thermal
value
2. Remains of carbon in the combustion
area
2. Clean cylinder head, piston bottom and
cylinder channels
Engine failures

7
571551 - Petrol Hedge Trimmer Owner’s Manual - May 2014
8 Hedge trimmer functioning
The Morrison hedge trimmer is equipped with quick stop
function which stops the knife immediately once the throttle is
released to prevent a possible accident.
If you want to switch off the machine, you must move the
switch (pict. a; item 3) into the “OFF”position.
• When cutting hedges comply with regulations valid in the
relevant country and local regulations.
• If the branches are bigger than the maximal cutting power,
they must be removed by other machinery.
• If heavy pruning is required, you should work in stages.
9 Work safely and
with prudence
1. Hold the hedge trimmer safely in both hands!
2. Trim and cut only wood and wooden objects!
3. Work with consideration and do not threaten anyone when
cutting. Work calmly with prudence!
4. Work when it is light and visible!
5. Constantly watch the cutting knife!
6. Never cut below shoulder height!
7. Work only with a sharpened and correctly installed
cutting knife!
8. Do not stand on a ladder when working!
9. Work only on sound and stable ground!
10 Maintenance Instructions
ATTENTION! The following instructions are
valid for standard working conditions. In case
of aggravated conditions such as heavy dust
contents, wood with a high content of resin or
longer working periods the interval must be
shortened accordingly.
Before you start work check the following:
• throttle
• visually check the whole machine
• position of the knife bar or the cutting knife
• degree of sharpness
• wear and tear or the guiding bar damage
After you finish working check
the whole machine and clean it.
Regularly check and maintain the following:
• air filter (clean if necessary)
• spark plugs pict. a; item 6 (if replacement is needed)
• cutting knife sharpness (clean well and lubricate)
When repairing or maintaining the hedge trimmer, have it
always switched off.
11 Fuel data
Refuelling
Mix unleaded petrol with brand oil for two-stroke engines with
air cooling in the 1:30 ratio. This means that for example 5 l of
petrol is mixed with 0,16 l of oil.
12 Repairs/engine failures
Repairs that require special professional knowledge should be carried out by authorised service centres.
Unprofessional interference can damage the machine or endanger your safety.
ydemeResuaCeruliaF
Engine not starting pulliF.1knatytpmE.1
,semitlarevesroftrats,elttorhtehtesolC.2enignededoolF.2
in case of need take out the spark plug
and dry it
3. Fouled spark plug (remains of carbon on
the electrodes) electrodes too
far away
3. Clean the spark plug, check its
temperature, replace if needed.
Adjust at 0.6-0.7 mm
riahtiwrotterubracehtnaelC.4stejstirorotterubracdeluoF.4
ronoitcennocgulpkrapsdegamaD.5
damaged spark plug
5. Replace
6. Incentive spar missing 6. Check short circuit button cable, ignition
module, in case of need replace. Adjust
the gap (0,3-0,4 mm).
Engine runs too fast when idle ehtesolcylevitanretla;ylwolspumraW.1enignedloC.1
choke a bit.
Engine does not reach its
maximal capacity
1. Fouled spark plug (remains of car
bon on the electrodes) electrodes too far
away
1. Clean the spark plug, check its
temperature, replace if needed.
Adjust at 0.6-.07 mm.
riahtiwrotterubracehtnaelC.2stejstiroro
tterubracdeluoF.2
3. Fouled air fi naelC.3retl
evomer,tinaelcdnatsuahxeehttuoekaT.4lennahctsuahxe,tsuahxE.4
remains of carbon
gnilaestonesacknarcnignirgnilaeS.5
properly
5. Replace
6. Worn cylinders, pistons and piston rings 6. Replace the cylinder, piston or piston
rings, reface the cylinder and piston,
assembly
snoitcurtsniehtotgnidroccapulliF.7)liohcumoot(ximleufgnorW.7
revuoleludomnoitingiehttsujdA.8noitingidaB.8
(0.3-0.4 mm)
Engine would not stop 1. Spark plug is light grey with signs of
heating (heating drops)
1. Install a spark plug with a higher thermal
value
2. Remains of carbon in the combustion
area
2. Clean cylinder head, piston bottom and
cylinder channels
Engine failures

571551 - Petrol Hedge Trimmer Owner’s Manual - May 2014
Head Office - New Zealand
1-37 Mt Wellington Highway, Panmure, Auckland 1060
P.O. Box 14 349, Panmure, Auckland 1741
