Petrol Line Trimmer
BCL250/B
Owner’s Manual
Important
Please read this Owner’s Manual and the Express Warranty before using this product. The Warranty does
not cover damage due to misuse or failure to follow the operating and installation instructions.
Keep the instructions in a safe place for future use.
Part No: 548955.A.0
June 2017

32
Do not operate this machine before it has been
assembled correctly and you have read and understood
these instructions.
Contents
General Safety Rules 2
Specific Safety Rules for Trimmer Use 2
Symbols 3
Service 3
Specifications 3
Packing List 3
Assembly 3
Operation 4
Maintenance 4
Troubleshooting 6
Thank you for buying the Morrison BCL250/B line trimmer. Your
new trimmer has been engineered and manufactured to Morrison’s
high standard for dependability, ease of operation, and operator
safety. Properly cared for, it will give you years of rugged, trouble-
free performance.
WARNING
To reduce the risk of injury, the user must read and
understand the operator’s manual.
WARNING
Do not attempt to operate this trimmer until you have read
thoroughly and understood completely all instructions,
safety rules etc contained in this manual. Failure to comply
may result in accidents involving fire, electric shock or
serious personal injury. Save operator’s manual and review
frequently for continuing safe operation, and instructing
others who may use this tool.
READ ALL INSTRUCTIONS.
General Safety Rules
• For safe operation, read and understand all instructions before
using the trimmer. Follow all safety Instructions. Failure to
follow all safety Instructions listed below, can result in serious
personal injury.
• Do not allow children or untrained individuals to use this unit
• Never start or run the engine in a closed or poorly ventilated
area; breathing exhaust fumes can kill.
• Clear the work area before each use. Remove all objects such
as rocks, broken glass, nails, wire, or string which can be
thrown or become entangled in the bump head.
• Wear full eye and hearing protection while operating this unit.
• Wear heavy long pants, boots, and gloves. Do not wear loose
fitting clothing, short pants, jewellery of any kind, or use with
bare feet.
• Secure long hair so it is above shoulder level to prevent
entanglement in any moving parts.
• Keep all bystanders, children, and pets at least 15m away.
• Do not operate this unit when you are tired, ill, or under the
Influence of alcohol, drugs, or medication.
• Do not operate in poor lighting.
• Keep firm footing and balance. Do not overreach. Overreaching
can result in loss of balance or exposure to hot surfaces.
• Keep all parts of your body away from any moving part.
• Do not touch area around the muffler or cylinder of the trimmer,
these parts get hot from operation.
• Always stop the engine and remove the spark plug wire before
making any adjustments or repairs except for carburetor
adjustments.
• Inspect the unit before each use for loose fasteners, fuel leaks,
etc. Replace any damaged parts before use.
• It has been reported that vibrations from hand-held tools may
contribute to a condition called Raynaud’s Syndrome in certain
individuals. Symptoms may include tingling, numbness and
blanching of the fingers, usually apparent upon exposure to
cold. Hereditary factors, exposure to cold and dampness, diet,
smoking and work practices are all thought to contribute to the
development of these symptoms.
It is presently unknown what, if any, vibrations or extent of
exposure may contribute to the condition. There are measures
that can be taken by the operator to possibly reduce the
effects of vibration:
a. Keep your body warm in cold weather. When operating
the unit wear gloves to keep the hands and wrists
warm. It is reported that cold weather is a major factor
contributing to Raynaud’s Syndrome.
b. After each period of operation, exercise to increase
blood circulation.
c. Take frequent work breaks. Limit the amount of exposure
per day.
If you experience any of the symptoms of this condition,
immediately discontinue use and see your physician
about these symptoms.
• Keep the tool well maintained, fasteners tightened and worn
parts replaced.
• Mix and store fuel in a container approved for fuel.
• Mix fuel outdoors where there are no sparks or flames.
• Wipe up any fuel spillage. Move 9m away from refueling site
before starting engine.
• Stop the engine and allow to cool before refueling or storing
the unit.
• Allow the engine to cool; empty the fuel tank and secure the
unit from moving before transporting in a vehicle.
Specific Safety Rules For
Trimmer Use
• Replace bump head if cracked, chipped, or damaged in
anyway. Be sure the bump head is properly installed and
securely fastened. Failure to do so can cause serious injury.
• Make sure all guards, straps, deflectors and handles are
properly and securely attached.
• Use only the manufactures replacement line in the cutting
head. Do not use any other cutting attachment.
• Never operate unit without the safety guard in place and in
good condition.
• Maintain a firm grip on both handles while trimming.
• Keep bump head below waist level. Never cut with the bump
head located over 76 cm or more above the ground.
• Start the engine carefully with hands and feet well away from
the cutting means.
• Never fit metal cutting elements.
• Do not use for lawn edge trimming.
• Never store the machine with petrol in the tank inside a building
where fumes may reach an open flame or spark.
• To reduce fire hazard, keep the engine and silencer free of
grass, leaves or excessive grease.
• Do not change the engine governor or over speed the engine.
• Replace faulty silencers and spark arrestors, if fitted.
Keep the instructions in a safe place for future use.
Symbols
Important: Some of the following symbols may be used on
your tool. Please study them and learn their meaning. Proper
interpretation of these symbols will allow you to operate the tool
better and safer.
Safety Alert Symbol
Indicates danger, warning or caution. It means at-
tention!!! Your safety is involved.
Read Your Operator’s Manual
Your manual contains special messages to bring
attention to potential safety concerns cis well as
operating and servicing information. Please read all
the information carefully to ensure satisfaction and
safe use.
Wear eye and hearing protection
Wear eye and hearing protection when operating
this equipment.
Keep bystanders away
Keep all bystanders at least 15m away.
Ricochet
Danger of Ricochet.
RPM Decal
Rotational direction and maximum speed of the
shaft for the cutting attachment.
Boots
Wear non-slip safety footwear when using this
equipment.
Gloves
Wear non-slip, heavy-duty gloves.
No Smoking
Do not smoke when mixing fuel or filling fuel tank.
Petrol
Use unleaded petrol intended for motor vehicle
use with all octane rating of 90 ([R+M)/2) or higher.
Oil
Use synthetic 2-stroke oil for air cooled engines.
Mix Petrol and Oil
Mix the fuel mix thoroughly and also each time
before refuelling.
Switch
RUN / STOP Switch
Service
Servicing requires extreme care and knowledge and should be
performed only by a qualified service technician. For service we
suggest you return the product to your nearest authorised service
centre for repair. When servicing, use only identical replacement
parts.
Specifications
Model: Morrison BCL250/B
Engine type: Air cooled 2-stroke
Total displacement: 25.4cc
Fuel mix ratio: 50:1
Max engine power: 0.75 kw/6500rpm
Idle speed: 3000 ± 200rpm
Max rated speed: 7500 ± 300rpm
Cutting path: 440mm
Trimming line: 2.0mm x 2.5m x 2
Fuel tank volume: 800ml
Weight: 5.2kg
Specifications are subject to change without notice.
Packing List
Assembly
WARNING
If any parts are damaged or missing, do not operate this
tool until the parts are replaced. Failure to heed this warning
could result in serious personal injury.
WARNING
Do not attempt to modify this product or create accessories
not recommended for use with this product. Any such
alteration or modification is misuse and could result in a
hazardous condition leading to possible serious personal
injury.
WARNING
To prevent accidental starting that could cause serious
personal injury, always disconnect the engine spark plug
wire from the spark plug when assembling parts.
WARNING
Never attach or adjust any attachment while power head
is running. Failure to stop the engine may cause serious
personal injury.
WARNING
Be certain the knob is fully tightened before operating
equipment; check it periodically for tightness during use to
avoid serious injury.
Engine & Shaft
assembly x 1
Manual x 1
Handle Assembly x 1
Safety Guard
Assembly x 1
Lower Shaft
assembly x 1

54
Operation
Read the operation manual and follow all warnings and
safety instructions.
Wear eye protection and ear protection.
Keep all bystanders, especially children and pets, at
least 15m from the operating area.
FUEL AND REFUELING
HANDLING THE FUEL SAFELY
• Always handle fuel with care, it is highly flammable.
• Always refuel outdoors where there are no sparks and names.
Do not inhale fuel vapors.
• Do not let petrol or oil come in contact with your skin.
• Keep petrol and oil away from the eyes. If petrol or oil comes
in contact with the eyes, wash them immediately with clean
water. If irritation is still present, see a doctor Immediately.
• Clean up spilled petrol immediately.
MIXING THE FUEL (Fig. 3)
• This product is powered by a 2-stroke engine and requires
pre-mixing petrol and 2-stroke oil. Pre-mix unleaded petrol and
2-stroke engine oil in a clean container approved for petrol.
• This engine is certified lo operate on unleaded petrol intended
for automotive use with an octane rating of 90 {[R + M] / 2) or
higher.
• Do not use any type of pre-mixed petrol fall from fuel service
stations, this includes the pre-mixed petrol I oil intended for use
in mopeds, motorcycles, etc.
• Use synthetic 2-stroke oil only. Do not use automotive oil or
2-stroke outboard oil.
• Mix 2% synthetic 2-stroke oil into the petrol. This is a 50:1 ratio.
• Mix the fuel thoroughly and also each time before fueling.
• Mix in small quantities. Do not mix quantities larger than usable
in a 30 day period. Synthetic 2-stroke oil containing a fuel
stabilizer is recommended.
FILLING THE TANK
• Clean surface around fuel cap to prevent contamination.
• Loosen fuel cap slowly to release pressure and to keep fuel
from escaping around the cap.
• Carefully pour fuel mixture into the tank. Avoid spillage.
• Prior to replacing the fuel cap, clean and inspect the gasket.
• Immediately replace fuel cap end hand lighten.
• Wipe up any fuel spillage. Move 9m away from refuelling site
before starting engine.
NOTE: It is normal for smoke to be emitted from a new engine
during and after first use.
WARNING
Always shut off engine before fuelling. Never add fuel to a
machine with a running or hot engine. Move at least gm
from refuelling site before starling engine. Do not smoke!
STARTING AND STOPPING
WARNING
Never start or run the engine inside a closed or poorly
ventilated area; breathing exhaust fumes can kill.
To start a cold engine:
• Lay the trimmer on a level surface.
• Check the ON/OFF switch to be on “ON” position.
• PRIME - press the primer bulb 6 times slowly.
• SET the choke lever to the “START” position.
• Left hand SQUEEZING the throttle trigger.
• Right hand PULL the starter rope with a quick firm and
consistent upward motion until the engine fires or starts and
runs.
Note: If difficulties with starting are experienced (this may occur in
colder conditions) refer to troubleshooting section in this manual.
• Move the choke lever to “RUN” position.
• Allow engine to warm up for 5-20 seconds.
To start a warm engine:
With the ON/OFF switch on “ON” position, PULL the starter rope
with a quick firm and consistent upward motion until the engine
starts.
To stop the engine:
Slide the switch to “OFF” position for 2 seconds until the engine
stops
OPERATING THE TRIMMER
Hold the trimmer with the right hand on the rear handle and the left
hand on the front handle. Keep a firm grip with both hands while in
operation. Trimmer should be held at a comfortable position with
the rear handle about hip height.
Always operate trimmer at full throttle. Cut tall grass from
the top down. This will prevent grass from wrapping around the
shaft housing and bump head which may cause damage from
overheating. If grass becomes wrapped around the bump head,
stop the engine, disconnect the spark plug wire, and remove the
grass. Prolonged cutting at partial throttle will result in oil dripping
from the silencer.
Maintenance
WARNING
Use only original manufacturer’s replacement parts,
accessories and attachments. Failure to do so can cause
possible injury, poor performance and may void your
warranty.
• You may make adjustments and repairs described here. For
other repairs, have the trimmer serviced by an authorised
service agent.
• Consequences of improper maintenance may include excess
carbon deposits resulting in loss of performance and discharge
of black oily residue dripping from the muffler.
• Make sure all guards, straps, deflectors and handles are
properly and securely attached to avoid the risk of personal
injury.
CLEANING THE EXHAUST PORT AND MUFFLER
Depending on the type of fuel used, the type and amount of
oil used, and/or your operating conditions, the exhaust port
and muffler may become blocked with carbon deposits. If you
notice a power loss with your petrol powered tool, a qualified
service technician will need to remove these deposits to restore
performance.
SPARK ARRESTOR
This machine is fitted with a spark arrestor to help prevent fires. The
spark arrestor is fitted at the muffler discharging port. To ensure
proper performance of your product, tile spark arrestor must be
cleaned or replaced every 25 hours or each year. Please contact
your nearest service dealer for a new spark arrestor. To find your
nearest service dealer please visit our website.
CLEANING AIR FILTER
A dirty air filter will cause starting difficulty, loss of performance, and
shorten the life span of the engine. Check the air filter monthly. For
best performance, replace the air filter at least once a year.
• Loosen the air filter cover by turning the fixing knob counter
clockwise.
• Remove the airbox cover and the air filter
• Clean the foam filter element with warm soapy water. Rinse
and let dry.
NOTE: If the foam filter element is damaged, it should be replaced.
• Apply a light coat of engine oil to the roam filter element, then
squeeze it out.
• Reinstall the air filter.
NOTE: Make sure the filter is seated properly inside the cover.
Installing the filter incorrectly will allow dirt to enter the engine,
causing rapid engine wear.
• Reinstall the airbox cover and tighten the fixing knob to secure.
FUEL TANK
WARNING
A leaking fuel cap is a fire hazard and must be replaced
immediately.
The fuel cap contains a sealing gasket and a check valve to
ventilate built up fuel gasses. A clogged check valve will cause
poor engine performance. If performance improves when the fuel
cap is loosened, the check valve may be faulty. Replace fuel cap if
required.
The fuel supplied to the engine is passed through a filler to remove
any contaminants from entering the engine.
Contaminants in the fuel can cause poor performance and damage
to the engine.
The fuel filter is a non-serviceable item and if needed should be
replaced by an AUTHORISED SERVICE CENTRE.
SPARK PLUG REPLACEMENT
The electrode gap should be adjusted to 0.6-0.7mm.
IDLE SPEED ADJUSTMENT
If idle speed is too high and needs adjustment, turn the idle speed
screw counterclockwise to reduce the engine speed.
If the idle speed is too low and needs adjustment, turn the idle
speed screw clockwise to increase engine speed.
NOTE: The engine should be at normal operating temperature
before making adjustments to the idle speed.
STORING THE PRODUCT
• Clean all foreign material from the product. Store idle unit
indoors in a dry, well-ventilated area that is inaccessible to
children. Keep away from corrosive agents such as garden
chemicals.
• Abide by all ISO and local regulations for the safe storage and
handling of petrol.
WHEN STORING FOR 1 MONTH OR LONGER
Drain all fuel from tank into a container approved for petrol. Run
engine until it stops.

76
Troubleshooting
IF THESE SOLUTIONS DO NOT SOLVE THE PROBLEM, CONTACT YOUR AUTHORISED SERVICE DEALER.
PROBLEM POSSIBLE CAUSE SOLUTION
Engine will not start. 1. No spark.
2. No fuel.
3. Engine is flooded.
4. Starter rope pulls harder now than
when new.
1. Check spark. Remove spark plug. Re-
attach the spark plug cap and lay spark
plug on metal cylinder. Pull the starter
rope and watch for spark at spark
plug lip. If there is no spark, repeat test
withe new spark plug.
2. Push primer bulb until bulb is full of fuel.
If bulb does not fill, primary fuel delivery
system is blocked. Contact a servicing
dealer. If primer bulb fills, engine may
be flooded, proceed to next solution.
3. Set the choke lever to the RUN posi-
tion. Squeeze the throttle trigger and
pull the starter rope repeatedly until the
engine starts and runs. NOTE: De-
pending on the severity of the flooding,
this may require numerous pulls of the
rope.
4. Contact a servicing dealer.
Engine has difficulties starting in colder
(winter) conditions.
Fuel is having trouble atomizing in cold
conditions.
1. Lay the trimmer on a level surface.
2. Check the engine switch to be on
“RUN” position.
3. PRIME- press the primer bulb 10
times slowly.
4. SET the choke lever to the “START”
position.
5. Squeezing the throttle trigger.
6. PULL the starter rope with a quick firm
and consistent upward motion until
the engine starts/fires.
7. Re-adjust choke lever to hall way
end allow engine to warm up for 5-20
seconds. If the engine has attempted
to start but fails to run on, Re-start the
engine in the half choke position (half
way between start and run) and allow
engine to warm up.
Engine starts but will not accelerate. Engine requires approximately three minutes
to warm up.
Allow engine to completely warm up. If
engine does not accelerate after three min-
utes, contact a servicing dealer.
Engine starts but will only run at high speed
at half choke
Carburetor requires adjustment. Contact a servicing dealer.
Engine does not reach full speed and emits
excessive smoke.
1. Check oil fuel mixture.
2. Air filter is dirty.
3. Spark arrestor screen is dirty.
1. Use fresh fuel and the correct 2-stroke
oil mix.
2. Clean air filter. Refer to Cleaning the Air
Filter Foam earlier in this manual.
3. Contact a servicing dealer.
Engine starts, runs, and accelerates but will
not idle.
Idle speed screw on carburetor requires
adjustment.
Turn idle speed screw clockwise to increase
idle speed.
Troubleshooting
PROBLEM POSSIBLE CAUSE SOLUTION
Line will not advance. 1. Line welded to itself.
2. Not enough line on spool.
3. Line worn too short.
4. Line tangled on spool.
5. Engine speed too.
1. Lubricate with silicone spray.
2. Install more line. Refer to “Line
Replacement” earlier in this manual.
3. Pull lines while alternately pressing
down on and releasing bump head.
4. Remove line from spool and rewind.
Refer to “Line Replacement” earlier in
this manual.
5. Advance line at full throttle.
Grass wraps round shaft housing and bump
head.
1. Cutting tall grass at ground level.
2. Operating trimmer at part throttle.
1. Cut tall grass from the top down.
2. Operate trimmer at full throttle.
Bump knob hard to turn. Screw threads dirty or damaged. Clean threads and lubricate with grease - if
no improvement, replace bump knob.
Oil drips from muffler. 1. Operating trimmer at part throttle.
2. Check oil/fuel mixture.
3. Air filter dirty
1. Operate trimmer at full throttle.
2. Use fresh fuel and the correct synthetic
2-stroke oil mix.
3. Clean per instruction in Maintenance
Section.

Head Office - New Zealand
1-37 Mt Wellington Highway, Panmure, Auckland 1060
P.O. Box 14 349, Panmure, Auckland 1741
