MOTA JETJAT ULTRA User manual

JETJAT®ULTRA™
Owner’s Manual
Ages
mota.com/ultra
Please read this manual carefully before flying! It has
valuable safety information and tips on fun and efficient
flight. Please keep this manual in a safe place.
8+
For Owner’s Manual updates, warranty information, and support,
please visit: https://www.mota.com/ultra

Drones are sophisticated precision devices capable of complex aerial
maneuvers. Please read these safety instructions before using
your drone. Failure to operate your drone safely could degrade its
perfomance and cause harm to people, animals, or property.
Please do not fly:
- Near or around obstacles such as birds or pets, aircraft, helicopters,
other drones, antennas or overhead lines, or airborne toys like kites.
-In or near airports or restricted areas.
-In adverse conditions such as strong winds, rain, hail, snow or sleet.
-If you are impaired, tired, or distracted.
FlySafely!

Find Out How:
Please do:
-Know and comply with laws and regulations respecting drone use
in your area.
-Keep hands away from rotors when drone is switched on.
-Fly within controller range.

OWNER’S MANUAL
TABLE OF CONTENTS
IN THE BOX 5
FLIGHT PREPARATION
7
CONTROLLER BATTERY INSTALLATION
JETJAT ULTRA
7
CHARGING YOUR JETJAT ULTRA
7
SAFE DISTANCE
8
PAIRING YOUR JETJAT ULTRA
APP INSTALLATION
10
WI-FI CONNECTION (IOS)
11
WI-FI CONNECTION (ANDROID)
12
USING THE JETJAT ULTRA APP
13
ACCESSING THE APP INTERFACE
15
APP CONTROL INTERFACE
16
17
18

OWNER’S MANUAL
TABLE OF CONTENTS
FLIGHT SETTINGS 19
ONE-TOUCH TAKE OFF / ONE-TOUCH LANDING 20
ONE-TOUCH 360º FLIPS / ONE-TOUCH CALIBRATION
TAKE PHOTOS AND VIDEOS
21
FLIGHT CONTROL
22
23
24
THROTTLE CONTROL 24
DIRECTIONAL CONTROL (ROLL LEFT / ROLL RIGHT)
PITCH CONTROL (FLY FORWARD / FLY BACKWARD)
ROTATION CONTROL (ROTATE LEFT / ROTATE RIGHT)
24
25
26
27
28
TRIM SETTINGS
MOTION SENSOR MODE
28AILERON CONTROL (ROLL LEFT / ROLL RIGHT)
RESPONSIVENESS MODES

AILERON CONTROL (LEFT / RIGHT) 31
30
MODE 1 / MODE 2 SWITCHING 31
32
MOTION SENSOR MODE
FLIGHT CONTROL SUMMARY
32
360º FLIPS
SPEED SELECTION
33
TROUBLESHOOTING
FAQ
ACCELEROMETER CALIBRATION
LOW BATTERY INDICATION
LOSS OF WI-FI COMMUNICATION
FAULTY TAKE OFF
35
36
34
34
35
35
OWNER’S MANUAL
TABLE OF CONTENTS
PITCH CONTROL (FLY FORWARD / FLY BACKWARD) 29

5
A
A
A A B B
B
B
A
A
A A B B
B
B
A
A
A A B B
B
B
IN THE BOX
JETJAT ULTRA
CAMERA
PROPELLERS
USB CHARGING CABLE
BUMPER GUARD
BLADE ABLADE B
BLADE A BLADE B
POWER SWITCH

6
IN THE BOX
JETJAT ULTRA
CONTROLLER
MODE 1/ MODE 2
SELECTION
POWER SWITCH LINKING INDICATOR
THROTTLE CONTROL
(ASCEND/DESCEND)
PITCH CONTROL
(FORWARD/
BACKWARD)
DIRECTIONAL
FLIGHT STICK
AILERON CONTROL
(LEFT/RIGHT)
THROTTLE
FLIGHT STICK
ROTATION CONTROL
(LEFT/RIGHT)
ADJUSTABLE PHONE HOLDER
ONE-TOUCH TAKE-OFF/
ONE-TOUCH LANDING
Please note: Throttle and
directional controls depicted
here are using Mode 2.
EXPANDABLE CONTROL GRIPS

7
1
FLIGHT PREPARATION
Controller Battery Installation
❶ OPEN THE BATTERY
COVER ON THE
CONTROLLER.
❷ INSTALL 2 AAA
BATTERIES
(NOT INCLUDED).
❸ CLOSE
THE BATTERY COVER.

8
Connect the drone to the charging gable,
then insert the charging cable into the
port of a USB charger. When the USB
indicator is ON, the battery is charging.
When the indicator is OFF, the battery is
fully charged. The USB charging cable is
compatible with a computer USB port,
an Apple charger, or any other USB
charging device, including portable USB
chargers and USB car chargers.
2Charging Your JETJAT ULTRA
FLIGHT PREPARATION
Charging Your JETJAT ULTRA

9
CAUTION
Battery life: Flight time is 4 – 5 minutes when battery
is charged and with minimal wind resistance.*
Land your JETJAT ULTRA immediately when the
battery is low and recharge.
Controller range: The effective range between
controller and drone is approximately 80 feet.*
Flying outside of the recommended range may
cause a crash or loss of the drone.
Warning: Do not fly in moderate or high winds, as the
drone may be carried away or crash. While flying, do not
throttle down quickly as this may cause the drone to lose
altitude uncontrollably.
3
*Flight time and controller
range depend on battery status
and condition, flight conditions,
and drone operation.
FLIGHT PREPARATION
Charging Your JETJAT ULTRA

10
Be aware of your drone’s
surroundings and avoid
flying near obstacles.
Fly your drone at
least 3 feet above
the ground.
While flying, do not
quickly throttle down
as this may cause the
drone to plummet and
result in damage.
123
FLIGHT PREPARATION
Safe Distance

11
Switch the drone and the controller
ON. The controller will beep once.
Push the Throttle Flight Stick on the
left to the full upward position. The
controller will beep once.
Pull the Throttle Flight Stick to the full
downward position. The controller
will beep once more, indicating
successful linking.
YourJETJATULTRAisnow ready for flight.
1 3
4
2
4
FLIGHT PREPARATION
Pairing JETJAT ULTRA with Controller

12
Install the App by following one of the
methods below
a) Please visit http://go.mota.
com/30.
b) Follow the QRC, below.
c) Once the page loads, follow the
link to download the MOTA JETJAT
ULTRA app from the Apple App
Store (for iOS) or Google Play (for
Android).
d) Search for JETJAT ULTRA in
iTunes in the Apple App Store (for iOS)
or Google Play (for Android).
5Download and Install the App
1
NOTE: To maximize the reception
of Wi-FI video streaming during
operation, point the antenna downward.
ANTENNA
FLIGHT PREPARATION
App Installation

13
CAUTION
When flying keep as much distance as
possible from other Wi-Fi signals in order
to avoid potential interference
Turn off Wi-Fi and reconnect if there is no
Wi-Fi signal found.
Completely exit the app when you need to
recharge the ULTRA’s battery.
Do not launch the app until a Wi-Fi
connection to the drone is restored.
Wi-Fi range is approximately 80 feet. To
ensure normal flight behavior, do not
exceed this range.
Wi-Fi Connection
Steps (iOS)
a) With the battery inserted into and
connected to the drone, turn ON the
power switch, and the power indicator
will begin to flash rapidly.
b) Go to the Settings menu of your
iPhone or iPad.
2
c) Select Wi-Fi to access the available
Wi-Fi networks.
FLIGHT PREPARATION
Wi-Fi Connection (iOS)

14
d) Connect to the network.
e) Navigate to the MOTA JETJAT Ultra app
on your device and tap the icon to display the
Home Screen.
FLIGHT PREPARATION
Conection Steps (iOS)

15
Wi-Fi Connection
Steps (Android)
a) With the battery inserted into and
connected to the drone, turn the power
switch ON. The power indicator will begin
to flash rapidly.
b) Go to the Settings menu of your Android
device.
d) Connect to the network.
e) Navigate to the MOTA JETJAT Ultra app on your mobile
device and tap the icon to display the Home Screen.
1
c) Select Wi-Fi to see available Wi-Fi networks.
FLIGHT PREPARATION
Wi-Fi Connection (Android)

16
1. Navigate to the MOTA JETJAT ULTRA
app on your mobile device and tap the icon
to display the Home Screen.
2. Tap “Play” to enter the Control Screen.
3. You will see the drone’s flight controls
overlaid on the streaming video from the
drone’s camera.
1Accessing the App Interface HOME SCREEN
USING THE JETJAT ULTRA APP
Accessing the App Interface

17
Note: When using the controller to guide the drone, please first link the drone with the
controller prior to connecting to Wi-Fi. Turn off the phone’s own control interface when using
the controller for an unobstructed view of the controls while streaming video.
USING THE JETJAT ULTRA APP
Accessing the App Interface
CONTROL SCREEN ON CONTROL SCREEN OFF

18
2
USING THE JETJAT ULTRA APP
App Control Interface
