Mota Premium power train set Assembly instructions

Support: www.MotaToys.com/support/

Owner’s Manual

and Assembly Instructions

Please read and retain this document as it contains

important operational and safety information.

Meets or Exceeds ASTM F963; GB6675; EN 62115

Safety Standards.

MOTA TOYS –UNORTH, LLC

PO BOX 1116

Campbell, CA 95009-1116

USA

Support: www.MotaToys.com/support/

STOP!

In the event of damaged, defective, or non-working

unit,

DO NOT RETURN THIS TRAIN SET TO THE

STORE WHERE IT WAS PURCHASED.

Please review the information in this document. If

service is required, please contact MOTA®Toys

Support by visiting

http://www.MOTAToys.com/support/

or call +1-720-466-3869.

Support: www.MotaToys.com/support/

IMPORTANT INFORMATION

WARNING –Electric Hazard

This product is recommended for children over

fourteen years of age. Adult supervision is

required. During handling and operation, exercise

cautious to prevent electric shock.

IMPORTANT NOTICE

To ensure trouble-free operation, use only MOTA®

products with this train set. Use of non-compatible

system may damage or result in unsatisfactory

performance.

NOTE TO PARENTS

Adult supervision is required. Please examine the

product for potential hazards. Any damage parts

must be repaired or replaced immediately.

NOTE:

Similar to an actual train or any machinery, your MOTA®

train will work best after a few hours of running time.

Support: www.MotaToys.com/support/

LIST OF PARTS

1. Locomotive x 1

2. Coal Wagon x 1

3. Passenger Cars x 2

4. Curved Tracks x 12

5. Straight Tracks x 5

6. Terminal Rerailer x 1

7. Speed Controller x 1

8. Power Adapter x 1

9. Terminal Wire x 1

Support: www.MotaToys.com/support/

TRAIN ASSEMBLY - 1

Please check the list of contents to ensure you have all

the parts before starting assembly.

Choose a firm and flat surface for assembly such as a

tabletop, floor, or carpet.

It is recommended to place the tracks loosely on the flat

surface to ensure there is enough space for complete

assembly.

NOTE: Improper assembly will result in interrupted

electrical current and/or derailment of the train.

Support: www.MotaToys.com/support/

TRAIN ASSEMBLY - 2

When assembling the track, snap it together tightly

(figure 1) while making sure the rail and rail connectors

are aligned properly as shown in figure 2.

NOTE: Ensure rail connectors do not slip under the rails

without properly connecting.

Support: www.MotaToys.com/support/

TRAIN ASSEMBLY - 3

It is best to assemble the tracks where it will be

ultimately displayed and used. If assembled tracks must

be moved, please ensure tracks do not bend.

After track is assembled, please check all connectors to

make sure tracks are flush and level. Ensure there are

no bumps or distortions. Run your finger on the track

rails to ensure proper setup.

If there are any issues, please carefully check the rail

connectors or use a pair of pliers to make minor

adjustments as necessary.

Support: www.MotaToys.com/support/

POWER PACK

WARNING –RISK OF ELECTRIC SHOCK

To reduce the risk of fire or electric shock, do not

expose this unit to rain or moisture.

CAUTION –RISK OF ELECTRIC SHOCK

To prevent the risk of electric shock, do not remove the

cover. Do not connect this unit to AC outlet in

bathroom, near any sink, or in any other damp area. Do

not operate this unit when the power cord or cover

enclosure is damaged. Periodic examination is

recommended.

Support: www.MotaToys.com/support/

POWER PACK - CONNECTING

Before connecting the power pack, please place the

power slide to OFF position (figure 4).

Connect the terminal wire to the DC outputs as shown

in figure 5. DO NOT CONNECT THE TERMINAL WIRE TO

AC OUTPUTS AS IT WILL CAUSE THE LOCOMOTIVE

MOTOR AND LIGHTS TO BURNOUT. AC outputs are

used for accessories that may be attached to this unit at

a later time.

Support: www.MotaToys.com/support/

POWER PACK - CONNECTING

Connect the other end of the terminal wire to the re-

railer track by simply plugging it as shown in figure 6.

Place only the locomotive on the track by simply

running its wheels back and forth over the terminal re-

railer track as shown in figure 7. Be sure all wheels are

properly on the track before operating your train.

Support: www.MotaToys.com/support/

POWER PACK - OPERATION

Plug power pack into a wall outlet. Begin feeding power

to the train by slowing moving the power control knob

to forward position (figure 8).

Observe the direction in which the locomotive travels. If

it moves backward when control indicates forward,

simply flip and reconnect the terminal wire / track

connectors as shown in figure 9.

Support: www.MotaToys.com/support/

OPERATION - 2

You may now place additional cars on the track by

running their wheels back and forth over the terminal

re-railer track. To couple the cars, gently push them

together as shown in figure 10. Couplers will engage

automatically.

NOTE: Do not leave your train running unattended. You

will extend the mechanical life of your train by not

running it for prolonged periods in your absence.

Unplug the power pack when not in use.

Support: www.MotaToys.com/support/

TROUBLESHOOTING

Issue: Train doesn’t run.

Possible Cause

Solution

No Electricity

Please ensure the power pack

is plugged into a live wall

receptacle.

Wheels are not on the track

Please ensure the locomotive

and car wheels are on the

track.

Wiring issues

Please check to make sure all

wiring is secure and there are

no crossed wires.

Tracks not connecting

Please note electricity runs

through tracks. Ensure all

tracks are properly

assembled.

Short circuit

Please refer to short circuit

section.

Issue: Train details.

Possible Cause

Solution

Improper track connection

Please check the section

where it produced a bump or

derailing. Ensure all tracks are

properly installed and

connected. Refer to track

assembly for instructions.

Support: www.MotaToys.com/support/

TROUBLESHOOTING - 2

Issue: Cars do not stay coupled

Possible Cause

Solution

Improper connection

Please check the couplers,

clean as needed.

Issue: Power Pack is making noise.

Possible Cause

Solution

NORMAL

Power pack will usually make

“hum” when plugged in. This

is normal.

Issue: Train stops

Possible Cause

Solution

Short circuit

Please refer to short circuit

section.

Support: www.MotaToys.com/support/

SHORT CIRCUIT

If your train stops or fails to start, a short circuit is

possible. Unplug the power pack immediately. Derailed

wheels may cause a short circuit, please check to make

sure all wheels are properly on the track.

Check all connections and be sure no metal of any kind

is across the rails (figure 11). Including metal-coated

tinsels or holidays ornament hooks.

After checking the tracks carefully, resume operation.

Your power pack is protected by a circuit breaker that

automatically resets after a short circuit is detected.

Allow up to five minutes for circuit breaker to reset

before resuming operation.

Support: www.MotaToys.com/support/

CLEANING AND MAINTENACE

Care must be taken to clean and maintain your train for

optimal performance. Clean track and wheels provide

electrical contact for proper train operation. After every

eight hours of use, wipe the track rails and exposed

portions of your locomotive’s wheels with a soft, lint-

free cloth or cotton swab. Removal of black residue is

normal.

Do not use steep wool to clean your track. If your track

becomes dirty and dull looking, clean it with one of the

recommended track cleaners available at your local

hobby store. Common solvents are not recommended

as they may damage plastics. Please make sure you

track is free from lint, fiber, and loose material which

may be sucked into the motor.

After every 24 hours of operation, your train set

requires lubrication to keep it in optimal operation

condition. Do not use common household lubricants as

they may damage your train. Contact your local hobby

store for proper lubrication products and procedures.

Support: www.MotaToys.com/support/

If you have any questions,

please contact MOTA®

Support via

http://www.MotaToys.com/support

or by calling

+1-720-466-3869
