Motion VISION X User manual
user’s manual
2
IMPORTANT SAFETY INSTRUCTIONS!
1 Read these instructions.
2 Keep these instructions.
3 Heed all warnings.
4 Follow all instructions.
5 Do not use this apparatus near water.
6 Clean only with dry cloth.
7 Do not block any ventilation openings. Install in accordance with the manu-
facturer's instructions.
8 Do not install near any heat sources such as radiators, heat registers, stoves,
or other apparatus (including amplifiers) that produce heat.
9 Do not defeat the safety purpose of the polarized or grounding-type plug. A
polarized plug has two blades with one wider than the other. A grounding
type plug has two blades and a third grounding prong. The wide blade or
the third prong are provided for your safety. If the provided plug does not fit
into your outlet, consult an electrician for replacement of the obsolete outlet.
10 Protect the power cord from being walked on or pinched, particularly at
plugs, convenience receptacles, and the point where they exit from the
apparatus.
11 Only use attachments/accessories specified by the manufacturer.
12 Use only with the cart, stand, tripod, bracket, or
table specified by the manufacturer, or sold with
the apparatus. When a cart is used, use caution
when moving the cart/apparatus combination to
avoid injury from tip-over.
13. Unplug this apparatus during lightning storms or when unused for long peri-
ods of time.
14. Refer all servicing to qualified service personnel. Servicing is required when
the apparatus has been damaged in any way, such as power-supply cord
or plug is damaged, liquid has been spilled or objects have fallen into the
apparatus, the apparatus has been exposed to rain or moisture, does not
operate normally, or has been dropped.
15. To completely disconnect this equipment from the AC mains, disconnect the
power supply cord plug from the AC receptacle.
16. The mains plug of the power supply cord shall remain readily operable.
17 CAUTION: Danger of explosion if battery is incorrectly replaced. Replace only
with the same or equivalent type (AAA). Dispose of dead batteries in accor-
dance with local regulation.
18. To prevent overheating, do not cover the apparatus. Install in accordance
with the manufacturer’s instructions.
19. No naked flame sources, such as candles, should be placed on the product.
20. Do not expose this apparatus to dripping or splashing and ensure that no
objects filled with liquids, such as vases, are placed on the apparatus.
21. Batteries (battery pack or batteries installed) shall not be exposed to exces-
sive heat such as sunshine, fire, or the like.
22. For apparatus mounted to wall, the apparatus shall be installed on solid
wood, bricks, concrete or solid wood columns and battens.
23. DO NOT overload wall outlets or extension cords beyond their rated capacity
as this can cause electric shock or fire.
24. Minimum distances around the apparatus for sufficient ventilation.
25. The ventilation should not be impeded by covering the ventilation openings
with items, such as newspapers, tablecloths,curtains, etc.
26. Do not ingest the battery, Chemical Burn Hazard.
27. Keep new and used batteries away from children.
28. If the battery compartment does not close securely, stop using the product
and keep it away from children.
29. If you think batteries might have been swallowed or placed inside any part of
the body, seek immediate medical attention.
30. The battery (battery or batteries or battery pack) shall not be exposed to
excessive heat such as sunshine, fire or the like.
31. Risk of leakage. Only use the specified type of Batteries. Never mix new and
used batteries. Observe correct polarity. Remove batteries from products that
are not in use for extended periods of time. Store batteries in a dry place.
32. Do not recharge non-rechargeable batteries.
33. Avoid exposure to extreme heat or cold.
The lightning bolt flash with arrowhead
symbol within an equilateral triangle,
is intended to alert the user to the pres-
ence of potentially “dangerous voltage” within the
product’s enclosure that may be of sufficient magni-
tude to constitute a risk of electric shock to persons.
The exclamation point within an equi-
lateral triangle is intended to alert the
user to the presence of important oper-
ating and maintenance (servicing) instructions in the
literature accompanying the appliance.
Do Not Open! Risk of Electrical Shock. Voltages in this equip-
ment are hazardous to life. No user-serviceable parts inside.
Refer all servicing to qualified service personnel. To prevent
fire or shock hazard, do not expose this module to moisture.
MOTION VISION X
Tested to comply with FCC standards.
FOR HOME OR OFFICE USE
3
34. This equipment is a Class II or double insulated electrical appli-
ance. It has been designed in such a way that it does not require
a safety connection to electrical earth.
35. Danger of explosion if battery is incorrectly replaced. Replace only with the
same or equivalent type.
36. (The remote control supplied with) This product contains a AAA battery. If the
AAA battery is swallowed, it can cause severe internal burns in just 2 hours
and can lead to death.
37. Do not handle leaking or damaged AAA batteries.
38. THIS PRODUCT CONTAINS A AAA BATTERY. IF MISUSED OR ABUSED THIS
CAN RESULT IN:
- Smoke or gas hazard
- Heat hazard
- Fire hazard
- Explosion hazard
WARNING: This product is intended to be operated ONLY from the AC Voltages listed
on the back panel or included power supply of the product. Operation from other voltages
other than those indicated may cause irreversible damage to the product and void the
product warranty. The use of AC Plug Adapters is cautioned because it can allow the
product to be plugged into voltages in which the product was not designed to operate. If
the product is equipped with a detachable power cord, use only the type provided with
your product or by your local distributor and/or retailer. If you are unsure of the correct
operational voltage, please contact your local distributor and/or retailer.
This device complies with Part 15 of the FCC Rules. Operation is subject to the follow-
ing two conditions: (1) This device may not cause harmful interference, and (2) this
device must accept any interference received, including interference that may cause
undesired operation.
FEDERAL COMMUNICATIONS COMMISSION INTERFERENCE
STATEMENT: This equipment has been tested and found to comply with the limits
for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are
designed to provide reasonable protection against harmful interference in a residential
installation. This equipment generates, uses and can radiate radio frequency energy
and, if not installed and used in accordance with the instructions, may cause harmful
interference to radio communications. However, there is no guarantee that interfer-
ence will not occur in a particular installation. If this equipment does cause harmful
interference to radio or television reception, which can be determined by turning the
equipment off and on, the user is encouraged to try to correct the interference by one
or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from that to which
the receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help.
Approved under the verification provision of FCC Part 15 as a Class B Digital Device.
Any changes or modifications not expressly approved by the grantee of this device
could void the user’s authority to operate the equipment.
RF EXPOSURE WARNING: This equipment must be installed and operated in accor-
dance with provided instructions and the antenna(s) used for this transmitter must be
installed to provide a separation distance of at least 20 cm from all persons and must
not be co-located or operating in conjunction with any other antenna or transmitter. End-
users and installers must be provide with antenna installation instructions and transmitter
operating conditions for satisfying RF exposure compliance.
5GHz RF DEVICE STATEMENT: This device operates in the 5.15–5.25GHz
frequency range and is restricted to indoor use only. Outdoor operations in the 5150–
5250MHz frequency range is prohibited.
CANADA, INDUSTRY CANADA (IC) NOTICES: This Class B digital apparatus
complies with Canadian ICES-003 and RSS-210. Operation is subject to the following
two conditions: (1) this device may not cause interference, and (2) this device must
accept any interference, including interference that may cause undesired operation
of the device.
RADIO FREQUENCY (RF) EXPOSURE INFORMATION: The radiated out-
put power of the Wireless Device is below the Industry Canada (IC) radio frequency
exposure limits. The Wireless Device should be used in such a manner such that the
potential for human contact during normal operation is minimized. This device has
also been evaluated and shown compliant with the IC RF Exposure limits under mobile
exposure conditions. (antennas are greater than 20cm from a person’s body).
Caution: (i) The device operating in the band 5150–5250 MHz is only for indoor use
to reduce the potential for harmful interference to co-channel mobile satellite systems;
(ii) The maximum antenna gain permitted for devices in the bands 5250–5350 MHz
and 5470–5725 MHz shall comply with the e.i.r.p. limit; and (iii) The maximum
antenna gain permitted for devices in the band 5725–5825 MHz shall comply with
the e.i.r.p. limits specified for point-to-point and non point-to-point operation as
appropriate. (iv) Users should also be advised that high-power radars are allocated
as primary users (i.e. priority users) of the bands 5250–5350 MHz and 5650–5850
MHz and that these radars could cause interference and/or damage to LE-LAN devices.
CE: Hereby, MartinLogan Ltd., declares that this Motion Vision X is in compliance
with the essential requirements and other relevant provisions of:
1995/5/EC – R&TTE
2004/108/EC – EMC
2006/95/EC – LVD
2011/65/EU – ROHS2
4
Introduction and Overview.................... 6
Placement and Mounting .......................6
Location...............................6
Installing on a Flat Surface...................6
On-Wall Installation .......................6
Connection. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Power Connection ........................9
Signal Connection ........................9
An Introduction to Audio Connections ..........11
Network Connection for DTS Play-Fi®. . . . . . . . . . .12
Subwoofer Connection ....................12
IR Input ..............................14
Surround Sound Decoding .....................14
Digital Inputs (Optical and Coaxial) ...........14
Analog Input...........................14
DTS Play-Fi .................................15
Network Requirements ....................15
DTS Play-Fi App Requirements ...............15
Wi-Fi Setup and Status Button ...............15
Downloading the DTS Play-Fi App.............15
Connecting to a Wireless Network: Acces Point Setup
..15
Connecting to a Wireless Network: Wi-Fi Protected Setup (WPS)
..16
Connecting to a Wired Network .............16
Playing Audio Using Play-Fi ....................17
Controlling Multiple Speakers. . . . . . . . . . . . . . . .18
Additional Play-Fi Features ..................18
How to use Connect ..........................18
Updates and Rebooting .......................19
DTS Play-Fi App Update ...................19
DTS Play-Fi Module Update .................19
Soundbar Firmware Update.................19
Rebooting Your Soundbar ..................19
Top Panel Controls ...........................19
Remote Control ..............................20
Changing the Remote’s Battery...............20
Programming a Second Remote ..............20
The Menu System ............................20
Entering and Exiting the Menu ...............20
An Overview of the Menu Structure ............21
Navigating the Menu .....................22
Menu Options..........................22
Sub ..............................22
Bass Level..........................23
Install .............................23
Surround. . . . . . . . . . . . . . . . . . . . . . . . . . .23
Stereo ............................24
Modes............................24
Display ...........................24
Power ............................25
Learn .............................25
Source Name .......................26
Service............................26
Contacting Customer Service ...................27
General Information ..........................27
Warranty Information .....................27
Serial Number .........................27
Service ..............................27
Frequently Asked Questions....................28
Troubleshooting .............................29
Specifications ...............................32
Dimensional Drawings ........................33
Serial Number:_____________________________
Record your serial number here for easy reference.
You will need this information when filling out your
warranty registration. The serial number is located on
the back of the sound bar and on the product carton.
WEEE NOTICE
Note: This mark applies only to countries within the European
Union (EU) and Norway.
In accordance with the European Union WEEE (Waste Electrical and Electronic
Equipment) directive 2002/96/EC effective August 13, 2005, we would like
to notify you that this product may contain regulated materials which upon
disposal, according to the WEEE directive, require special reuse and recycling
processing. For this reason Martin Logan has arranged with our distributors in
European Union member nations to collect and recycle this product at no cost
to you.
To find your local distributor please contact the dealer from whom you pur-
locator at www.martinlogan.com.
Please note, only this product itself falls under the WEEE directive. When dis-
posing of packaging and other related shipping materials we encourage you to
recycle these items through the normal channels.
WARNING/CAUTION!
• Hazardous voltages exist inside—do not remove cover.
• Refer servicing to a qualified technician.
• To prevent fire or shock hazard, do not expose this module to moisture.
• Unplug speaker should any abnormal conditions occur.
• Turn speaker off before making or breaking any signal connections!
• The power cord should not be installed, removed, or left detached from the
speaker while the other end is connected to an AC power source.
• No candles or other sources of open flame should be placed on the speaker.
• No liquids either in glasses or vases should be placed on speaker.
• Speaker should not be exposed to dripping or splashing liquids.
• The terminals marked with the lightning bolt symbol should be connected by
an instructed person or by way of ready made terminals.
• The power cord should remain readily operable should any abnormal
conditions occur.
• Any changes or modifications not expressly approved by the grantee of this
device could void the user’s authority to operate the equipment.
5
c
60
inch
(152
em)
78 inch
(198
em)
wall mount installation template
(iY"
'ii]
digital
optical cable
--
~-
power
cord
6
INTRODUCTION AND OVERVIEW
Thank you—the MartinLogan owner, for loving
what we do, and making it possible for us to do
what we love.
MartinLogan’s dedicated in-house engineering
and design team developed the Motion Vision
X soundbar to deliver exceptional multi-channel
performance from a single system that easily
integrates and installs in a diverse variety of envi-
ronments—whether table or wall mounted. The
Motion Vision X produces an enveloping field of
richly detailed audio for both music and movies
via three tweeters incorporating MartinLogan’s
award-winning Folded Motion technology, four
high-performance woofers, and seven channels of
dedicated amplification representing 100 watts of
total system power.
Advanced digital signal processing technology
allows MartinLogan to replace five dedicated
home theater speakers with a one piece solution
capable of reproducing multi-channel recordings
with unflinching accuracy, resolution, and detail—
the inspiration behind every MartinLogan design.
The Motion Vision X reproduces front left, right,
and center channels via the system’s dedicated
tweeters and woofers. Surround channels are simu-
lated using sophisticated digital signal processing
that directs sound from the system’s tweeters and
woofers throughout the room.
Additionally, for a fully authentic surround sound
experience, the Motion Vision X’s built in SWT-2
wireless transmitter makes connecting a dedicated
compatible MartinLogan subwoofer as simple as
the push of a button—no wires necessary.
The Motion Vision X’s simple remote control quickly
adjusts volume and selects inputs. The remote also
allows you to easily switch between three discrete
acoustic modes—’Night’ mode (to dial down the
bass), ‘Bass +’ mode (for those moments requiring
a little extra thunder), and a ‘Normal’ mode that
restores normal levels.
PLACEMENT AND MOUNTING
LOCATION
We recommend locating the soundbar centered
directly above or below your video display. The
soundbar menu allows you to optimize acoustic
performance for either ‘on-wall’ or ‘on-shelf’ instal-
lations. You will learn more about accessing these
options in the “Controls” section of this manual.
INSTALLING ON A FLAT SURFACE
If you have a surface that provides a wide, level,
and stable platform (such as a table or audio/video
rack), the soundbar can be placed directly on top.
When installing the system in this configuration,
use the soundbar’s menu system to choose
‘INSTAL > ON.SHLF’ [ON SHELF].
Please note: This soundbar is not magnetically
shielded and therefore should not be placed directly
beneath or on top of a CRT (cathode ray tube)
television. The magnetic field of the soundbar will
not affect plasma and LCD style televisions.
ON-WALL INSTALLATION
Note: These instructions assume the mounting
surface is standard wood frame and sheetrock
construction. If you wish to mount to another type
of surface, consult a bonded contractor.
7
Note: When installing the system in this configu-
ration, use the soundbar’s menu system to choose
‘INSTAL > ON.WALL’.
Required tools (not included):
• Stud finder
• Level
• Electric drill and drill bits
• Phillips screwdriver
Required hardware (included):
• (1) Installation template
• (1) Wall bracket
Required hardware (not included):
• (5) Screws appropriate for mounting surface
• (5) Sheet rock anchors (sized for screws)
1 Locate mounting location using a level and the
installation template (fig. 1).
2 Mark the three central pilot hole locations and
remove the installation template (fig. 1).
3 Using a stud finder, determine if there is a wall
stud directly behind one of the three center
screw locations (fig. 2a).
Fig. 1
WARNING! We strongly recom-
mend locating the wall bracket so
at least one of the screw locations
attaches to a stud. WARNING!
To prevent injury, this apparatus must be secure-
ly attached to the floor/wall in accordance
with the installation instructions.
8
If no stud is found: use the center most screw
location and drill a pilot hole for the wall anchor.
Install a wall anchor at this location. If a wall
stud is found: drill a pilot hole into the stud.
4 Using a screw, attach the wall bracket to the
wall. DO NOT tighten (fig. 2b).
5 Using a stud finder, determine if a wall stud
is directly behind any of the remaining screw
locations (fig. 2a).
If no stud is found: use the top and bottom
center-most screw locations. If a wall stud is
found: use the top and bottom screw locations
with a stud behind them.
Use a level to square the wall bracket and mark
the remaining pilot hole locations (fig. 2b).
6 Remove the wall bracket or pivot to access the
remaining screw locations (fig. 2b).
If no stud is found: drill pilot holes and install
wall anchors. If a wall stud is found: drill pilot
holes into the stud.
7 Using the screws, attach the wall bracket to the
wall. DO NOT fully tighten.
8 Use a level to square the wall bracket. Tighten
all screws (fig. 2b).
9 Attach audio and power cables as needed.
Refer to the ‘Connection’ section of this manual.
10 Move the soundbar into place and drop the
shoulder bolts into the wall bracket keyholes.
Before releasing, make sure the soundbar has
dropped fully into the keyholes and is held firm-
ly in place (fig. 3).
Fig. 2b
Fig. 2a
9
Fig. 3
CONNECTION
WARNING! Turn your soundbar
off before making or breaking any
signal connections! WARNING!
The power cord should not be
installed, removed, or left detached from the
soundbar while the other end is connected to
an AC power source.
POWER CONNECTION
The power cord should be firmly inserted into
the AC power receptacle on the rear connection
panel of the soundbar, then to any convenient AC
wall outlet. The soundbar also integrates a signal
sensing power supply that automatically switches
off after sensing no audio signal for 30 minutes
(this will only occur when the menu’s power setting
is set to ‘Auto’).
If you remove your soundbar from the country of
original sale, be certain that AC power supplied
in any subsequent location is suitable before con-
necting and operating the soundbar. Substantially
impaired performance or severe damage may
occur to the soundbar if operation is attempted
from an incorrect AC power source.
SIGNAL CONNECTION
When utilizing the soundbar to reproduce audio, a
television’s audio output should be defeated. Some
televisions will allow you to turn off the internal
speaker via the television’s menu system. Other
televisions may require you to turn the television’s
volume to “zero” or “mute”.
Additionally, your television may require you to
turn on the digital optical or digital coaxial output
and configure the output for 5.1 surround sound.
Please refer to your television’s manual.
10
Fig. 5
Connections are made at the signal input section
on the rear electronics panel of the soundbar. Your
soundbar features three wired audio inputs:
• 1 x Digital Optical inputs
• 1 x Digital Coaxial input
• 1 x Left/Right Analog (3.5mm) input
When connecting your system, there are any
variety of configurations that will work, and these
methods will vary based on user preference.
Some users will choose to route all sources (such
as DVD player, cable box, game console, media
streamer, etc.) to their television via a digital (optical or
coaxial) connection and use the television to switch
between audio/video sources. The advantage of
this connection method is that only one audio cable
(either a digital optical or digital coaxial cable)
needs to connect between the television and the
soundbar—and changing the input on your television
will change the audio signal being sent to the
soundbar (without having to change the input setting
on the soundbar itself). Please note: most televisions
are not capable of passing multi-channel encoded
audio signals and will down-mix these signals to
a 2-channel stereo mix before sending them to the
television’s digital output.
Most users will want to run cables directly from
the source to the soundbar while simultaneously
running HDMI from each source to the TV for the
video signal. This has the advantage of allowing
the soundbar to receive multi-channel encoded
material. However, some newer source devices
turn off their optical/coaxial outputs when their
HDMI output is used.
Depending on your number of sources, the TV may be
used for switching some sources while audio output
from the primary source devices may be directly con-
nected to the soundbar for multi-channel sound.
A few important points to remember when connecting
your soundbar:
• Digital optical and digital coaxial connections
will provide the highest audio fidelity when
connecting to the soundbar.
• If your soundbar is not producing sound or
surround sound from your Blu-ray player, DVD
player, or other multi-channel audio capable
11
source, you may need to set the player’s digital
audio output to “Bitstream” (also called “Raw”,
“Direct Digital”, or “High Bit Rate”). If “PCM” is
selected you’ll lose the multi-channel encoded
sound. Some players only require you to turn
PCM off to configure for multi-channel encoded
sound. Please refer to your player’s manual.
• In a setup where HDMI is used to connect your
audio/video source component to your television,
you will likely need to run an additional digital
optical or coaxial cable between the source com-
ponent and your soundbar. This extra connection
HDMI: HDMI utilizes one cable to pass high-definition video signals and multi-
channel encoded digital audio between a source component and television
or receiver. Your soundbar is not equipped with an HDMI input. However,
in many installations you will want to use HDMI to connect a video source
component to your television (to pass video) and an additional digital optical
or digital coaxial cable (to pass audio) to the soundbar.
Digital Optical: Digital optical utilizes one cable to pass digital audio
information (no video). A digital optical cable offers a high-quality digital
connection and passes multi-channel encoded audio between a source
component and an audio output device.
Digital Coaxial: Digital coaxial utilizes one cable to pass digital audio information (no
video). A digital coaxial cable offers a high-quality digital connection and passes
multi-channel encoded audio between a source component and an audio output
device. Please note: The ‘RCA’ style end of a digital coaxial cable is identical
to those found on common left/right analog RCA cables. However, a cable
designed specifically for digital coaxial connections should be employed—do not use a standard left/
right analog RCA style cable because it will likely not be up to the task of handling the high bit-rate nec-
essary for a reliable digital connection.
Analog Left/Right RCA to Stereo 3.5mm: Analog cables are used to pass
audio information (no video). Older gaming consoles, portable media player
docks, VCRs and similar source components (which are not capable of playing
multi-channel encoded content) will often offer connection only through left/
right analog RCA cables. To connect to these devices use a Left/Right RCA
to stereo 3.5mm cable.
Play-Fi®: This audio streaming technology allows a wide variety of devices
to connect to an audio output device and stream audio. Play-Fi establishes a
connection directly with an audio output device and requires both devices to
be connected to a local area network (via a Wi-Fi or Ethernet connection).
ANINTRODUCTION TO AUDIO CONNECTIONS
12
will allow for multi-channel encoded audio to
reach the soundbar.
• Audio-only sources capable of only stereo output
(such a portable media player docks or CD play-
er) will often connect directly to the soundbar via
the analog input.
NETWORK CONNECTION FOR DTS PLAY-FI®
To stream audio to your soundbar via DTS Play-Fi,
a LAN (local area network) connection is required.
This connection can be established using Wi-Fi
or Ethernet. Refer to the DTS Play-Fi section of this
manual for setup and usage details.
SUBWOOFER CONNECTION
You may choose to employ a separate subwoofer
to reproduce the .1/LFE channel information in
multi-channel recordings and/or reinforce bass per-
formance of stereo recordings. Any aftermarket home
theater subwoofer can be connected via the sound-
bar’s “LFE Out” RCA connection. We, of course,
recommend using a superb MartinLogan subwoofer.
Additionally, this soundbar integrates a built-in
SWT-2 subwoofer wireless transmitter compatible
with select MartinLogan subwoofers. Subwoofers
utilizing SWT-2 technology will reference this wireless
system on the connection panel.
Please note: When utilizing a wireless connection,
it is not necessary to use the SWT-2 wireless transmitter
included with the subwoofer.
No Subwoofer
For systems not using a separate subwoofer, use
the soundbar’s menu system and choose “SUB >
NO SUB”. This sets the soundbar to reproduce the
entire frequency range when playing content.
Wired Subwoofer Connection
Using a high-quality RCA style cable designed for
subwoofer connection, connect “Sub Out” from the
soundbar to the “LFE In/Sub In” on the subwoofer.
Use the soundbar’s menu system and choose ‘SUB
> WIRED’.
Reference your subwoofer’s manual to learn how to
properly adjust the sub’s level and phase controls
to achieve proper blending with the soundbar. The
subwoofer’s crossover should be set to “bypass”,
“LFE”. For subwoofers that do not have a “bypass”
or “LFE” crossover setting, we recommend adjusting
the crossover to its highest setting.
Wireless Subwoofer Connection
Press the subwoofer’s sync button and hold for 3
seconds. The subwoofer’s LED will blink quickly.
Use the soundbar’s menu system and choose ‘SUB
> WIRELS > SYNC’. The soundbar will display
‘PSH.BTN’ [PUSH BUTTON].
If pairing has completed successfully, the subwoofer’s
LED will stop blinking and remain on and the sound-
bar will display ‘SYNCED’. Please note: If a link
is not established after 30 seconds, the subwoofer’s
LED will start blinking slowly and the soundbar will
display ‘FAILED’. Repeat if syncing fails.
Reference your subwoofer’s manual to learn how to
properly adjust the sub’s level and phase controls.
The subwoofer’s crossover should be set to “bypass”
or “LFE”. For subwoofers that do not have a “bypass”
or “LFE” crossover setting, we recommend adjusting
the crossover to its highest setting.
Please note: MartinLogan once utilized a
wireless subwoofer connection system named
“SWT-1”. Subwoofers equipped with SWT-1 tech-
13
Fig. 6
[video:
HDMI*]
Television
•Although
HDMI
offers
the
highest
quality
video
connection,
another
type
af
cable
such
as
composite
[good],
s-video
[better],
or
component
[best]
might
be
required
by
your
television
or
video
source
component~specially
when
using
sources
such
as
VCRs
or
older
game
consoles.
'
Digital
Out
' ' ' '
--~·-@
Non
Multi-Channel
Audlo.Nldeo
Sources:
Audio
Only
Sources:
MP3
Player,
CD
Player,
Etc.
VCR,
Older Game Console,
Etc.
[analog]
[video:
HDMI*]
MuiH-Channel
Audfo.Nldeo
Sources:
Blu-ray,
DVD,
Game
Console,
Cable
Box,
Satellite
Tuner,
Etc.
[Alia
lag
l1]
[Sub
OutJ
[Eth11111
In]
[AC
ro..lnJ
[II
II]
\
Pu!ple
[Cau:
In]
~
[Optical
In]
\ \
~
Orange
: :
14
SURROUND SOUND DECODING
This soundbar is capable of detecting and auto-
matically decoding multi-channel audio formats,
such as those found on DVD and Blu-ray movies.
DIGITAL INPUTS (Optical and Coaxial)
When utilizing a digital connection, the soundbar
can process the following formats: Dolby®Digital,
DTS Digital Surround™, and digital stereo.
ANALOG INPUT
Digitally encoded sound information cannot be
transmitted to an analog input. This connection
method is adequate for most devices that only
offer two channels of output (such as VCRs, CD
players, older game consoles, or portable media
player docks). Although most surround sound
capable devices, such as DVD and Blu-ray play-
ers, offer both analog and digital connections, the
digital connection should always be employed. If
a source device is connected via an analog left/
right RCA connection, the 5.1-channel encoded
audio content will not be sent to the soundbar.
nology are not capable of wireless connectivity
with this soundbar—a wired connection will work
for these subwoofers.
Please note: If you decide to no longer use
wireless, turn off the soundbar’s wireless transmitter
by using the menu system and choosing ‘SUB >
WIRELS > TRN.OFF’ [TURN OFF] or ‘SUB > NO
SUB’. Doing this will turn off the transmitter and
automatically set the soundbar for no sub.
WARNING! When operating wirelessly, the
subwoofer may be susceptible to RF interference
in the 2.4GHz bandwidth from microwave ovens
and wireless devices such as Wi-Fi systems, video
game consoles, cordless telephones, Bluetooth
devices, and baby monitors. Generally, this issue
(intermittent sound or slight popping noises) is eas-
ily resolved by physically separating problematic
devices from one another—a distance as little as
two feet will often alleviate the interference. In the
case of microwave ovens, the interference will only
occur when the microwave is operating.
Using a MartinLogan Dynamo Subwoofer
When configuring your subwoofer we recom-
mend beginning with the following settings:
Low-pass: Bypass
Phase: 180
Volume: Knob set to vertical (12-o’clock to
1-o’clock position)
IR INPUT
This mono 3.5mm jack allows you to connect after
market IR repeater systems to the soundbar.
15
DTS PLAY-FI®
NETWORK REQUIREMENTS
You must have the following to connect your soundbar
to your network:
• A wireless router.
• A high-speed internet connection for reliable
playback of internet based music services.
• Have your network password ready before
connecting the soundbar to your network.
TIP! If wireless connectivity is weak or not available,
connect to your router with an Ethernet cable.
TIP! Your soundbar communicates with wireless
networks that support 802.11g/n. For best
performance, a network that supports 802.11n
wireless technology is recommended. A network
supporting 802.11b may be used, but it will
effectively stream to only one device equipped with
DTS Play-Fi®. Your soundbar communicates over a
2.4 GHz wireless band, however, it can become
slow in locations, such as apartments, where
many routers are in operation. Consequently, your
soundbar is capable of jumping onto a 5 GHz
band on dual band wireless routers.
DTS Play-Fi®APP REQUIREMENTS
• An Android device running Android 2.2 or later.
• An iOS device running iOS 6.0 or later.
• A Windows® PC running Windows 7, 8 (32
and 64 bit), or later.
WI-FI SETUP AND STATUS BUTTON
The Wi-Fi Setup and Status button tells you what
your soundbar is doing (fig. 7).
• Rapid Blinking: booting up.
• Blinking: connecting to a wireless router.
• Slow Pulse: Access Point Setup Mode.
• Two Blinks: WPS (Wi-Fi Protected Setup) Mode.
• Solid: wirelessly connected to a router.
• Off: connected to a router using an Ethernet
connection.
DOWNLOADING THE DTS PLAY-FI APP
Android Device Users: Download the free DTS Play-Fi
app from Google Play or the Amazon App Store.
iOS Device Users: Download the free DTS Play-Fi
app from the Apple App Store.
PC Users: Download and install the free DTS Play-Fi
program from https://play-fi.com/apps/windows
CONNECTING TO A WIRELESS NETWORK:
ACCESS POINT SETUP
Access Point Setup causes your soundbar to behave
as if it were a wireless router. Using your mobile
device or Wi-Fi capable PC, you connect directly
to your soundbar using Wi-Fi, select your home
wireless network, and enter the network password.
1. For optimal setup conditions place your soundbar
next to your wireless router. The soundbar can
be moved to its final location after wi-fi setup.
2. Plug in your soundbar and press the Power button.
3. The Wi-Fi Setup and Status button will start
rapidly blinking for 20 seconds while your
soundbar boots. If this is the first time your
Fig. 7
16
new soundbar is plugged in, the Wi-Fi Setup
and Status button will start pulsing slowly. If
the soundbar is already configured to connect
to a wi-fi network, the button will turn solid
(connected) or blink rapidly (not connected).
4.
Once the Wi-Fi Setup and Status button starts
pulsing slowly, your soundbar is in Access Point
Mode and ready to connect to your wireless
network. Note: If the soundbar’s Wi-Fi Setup
and Status button is not pulsing slowly, press
and hold the button for 8 seconds until you have
heard two tones—one at 3 seconds and another
at 8 seconds. The soundbar will display “ACCS.
PNT.” After 20 seconds, the Wi-Fi Setup and
Status button will begin pulsing slowly to indicate
Access Point mode is ready. At anytime you can
press the button again to cancel the setup mode.
5. Launch the DTS Play-Fi®app.
Android Device Users:
a) The app will automatically find your device
and provide prompts for setup.
b) Touch the “Setup” button on the screen.
c)
Enter the password for your wireless network;
the app will connect your device to your
network.
d) Once your device is connected, you will
notice that the Wi-Fi Setup and Status button
on your soundbar will change from blinking
to solid. This may take up to a minute. If, after
a minute, the button continues to blink rapidly,
setup failed and you should try again.
iOS Device Users:
a) The app will prompt you to set up a new
speaker. Click on the screen to view setup
instructions. If the app does not prompt you
to set up a new device, within the app, go
to ‘Settings > Add Play-Fi Device’. Follow
the on-screen instructions.
b)
You will be prompted to exit the DTS Play-Fi
app and open your iOS device’s Settings app.
c) Select Wi-fi in Settings. Ensure that Wi-Fi is
enabled on your device. Select the Wi-Fi
network with “Play-Fi ” in the name.
d) Once your soundbar is selected as the Wi-Fi
network, exit iOS Settings and open the DTS
Play-Fi app. You should now be prompted to
select your wireless network and enter your
wireless network password.
e)
Once your device is connected, you will
notice that the Wi-Fi Setup and Status button
on your soundbar will change from blinking
to solid. This may take up to a minute. If, after
a minute, the button continues to blink rapidly,
setup failed and you should try again.
PC Users:
a)
The app will automatically find your device and
provide prompts for set up. If the app does not
prompt you to set up a new device, within the
app go to the settings screen and click ‘Setup
Play-Fi Device’. Follow the on-screen instructions.
b) Click the “Set-up” button on the screen.
c) Select the speaker(s) you want to set up.
d)
Enter the password for your wireless network;
the app will connect your device to your
network. You will notice the Wi-Fi Setup and
Status button will have changed from blinking
to solid. This may take up to a minute. If, after
a minute, the button continues to blink rapidly,
setup failed and you should try again.
6 Your soundbar is now connected to your wireless
network. Reconnect your mobile device or PC
to your wireless network. You may re-name your
device using the app.
CONNECTING TO A WIRELESS NETWORK:
WI-FI PROTECTED SETUP (WPS)
Wi-Fi Protected Setup (WPS) is a feature found on
most wireless routers that allows your soundbar
product to securely and automatically connect
17
without needing to enter a password. WPS is not
a standard feature on all routers, and only one
wireless device can be set up at a time.
Check your router’s owner’s manual to see if WPS
is an available feature, or look for a button on your
router marked with the WPS logo ( ). If your router
does not have WPS, then use the Access Point
Wireless Setup.
1. For optimal setup conditions place your soundbar
next to your wireless router. The soundbar can
be moved to its final location after wi-fi setup
2.
Plug in your soundbar and press the Power button.
3. The Wi-Fi Setup and Status button will start
rapidly blinking for 20 seconds while your
soundbar boots. If this is the first time your
new soundbar is plugged in, the Wi-Fi Setup
and Status button will start pulsing slowly. If
the soundbar is already configured to connect
to a wi-fi network, the button will turn solid
(connected) or blink rapidly (not connected).
4. For 3 seconds, press the soundbar’s Wireless
Setup and Status button until you hear a tone.
The soundbar will display “WF.SETUP” and
after a few seconds the Wi-Fi Setup and Status
button will blink twice in continuous intervals
to indicate WPS mode. At any time you can
press the Wi-Fi Setup and Status button again
to cancel the setup mode.
5 Now push the WPS button ( ) on your router.
6.
Once the Wi-Fi Setup and Status button is solid (not
blinking), this indicates your soundbar is connected
to the wireless network. This may take up to a
minute. If, after a minute, the button continues to
blink rapidly, setup failed and you should try again.
7. Connect your mobile device or PC to the
same network as your soundbar. Launch the
DTS Play-Fi®app. Upon launching, it will
automatically detect your soundbar and should
prompt you to name your soundbar.
CONNECTING TO A WIRED NETWORK
1. Using an Ethernet cable, connect your soundbar
to your router.
2. Plug in your soundbar and press the Power button.
3. The Wi-Fi Setup and Status button will start
rapidly blinking for about 20 seconds while
your soundbar is booting up.
4. The Wi-Fi Setup and Status button turns off
when the soundbar is connected via Ethernet.
5. Connect your mobile device or PC to the
same network as your soundbar. Launch
the DTS Play-Fi app. Upon launching, it will
automatically detect your soundbar and should
prompt you to name your soundbar.
PLAYING AUDIO USING PLAY-FI
Note: Future updates to the DTS Play-Fi application
may change functionality.
1. Launch the DTS Play-Fi app on your mobile
device or PC (located in the system tray).
2. Android and iOS Device Users: Within the
Play-Fi app, select your music source. You can
choose from your personal music library, Internet
Radio, or from select internet music services. PC
Users: Any audio content from your computer
can be streamed using Play-Fi.
18
3.
If you have more than one Play-Fi
®
speaker
connected to your network, you will be prompted
to select the speaker to which you want to stream.
CONTROLLING MULTIPLE SPEAKERS
If you have more than one Play-Fi speaker connect-
ed to your network, you can simultaneously stream
the same audio to multiple speakers.
1. Android and iOS Device Users: Within the
app, press the Play-Fi logo in the lower corner
of the app. PC Users: open the Play-Fi program
using the icon in your system tray.
2.
Select additional devices to play audio from.
PC Users: The free version of the Windows app
may not allow streaming to multiple speakers. An
upgraded version of the DTS Play-Fi app, with this
capability, can be purchased from the DTS website.
Note: 8 Play-Fi speakers can be synced to play
the same audio content at the same time. We
recommend up to 32 Play-Fi speakers on a network
for the best experience, but the only limit to connected
devices is how many your router can support.
TIP! Primary and Secondary Speakers
When streaming audio content to multiple devices,
you will be asked to assign them to two categories:
primary and secondary devices. The DTS Play-Fi
module requires a primary device be selected.
This maximizes synchronization between multiple
devices simultaneously streaming the same content.
Select the DTS Play-Fi device with the strongest
signal as your primary device. Secondary devices
connect to your primary device, so if you disable
your primary device, you will need to select a
new primary device before audio resumes on your
secondary devices.
ADDITIONAL PLAY-FI FEATURES
New versions of the Play-Fi app will add features
not mentioned in this manual. Please refer to the
app and related documentation for details on new
and enhanced features such as streaming different
audio content to multiple zones and grouping of two
discrete speakers for stereo (left/right) playback.
You’ll need Spotify Premium to use Connect, see
details overleaf.
1. Add your new device to the same wifi network
as your phone, tablet or PC (see product user
instructions for details).
2. Open the Spotify app on your phone, tablet or
PC, and play any song.
3. If you’re using the app on a phone - tap the
song image in the bottom left of the screen. For
tablet and PC move to step 4.
4. Tap the Connect icon
5. Pick your device from the list. If you can’t see
it, just check it’s connected to the same wifi
network as your phone, tablet or PC.
All done! Happy listening.
Licenses
The Spotify Software is subject to third party
licenses found here:
www.spotify.com/connect/third-party-licenses.
HOW TO USE CONNECT
19
TOP PANEL CONTROLS
Your soundbar features six buttons on top of the
unit to control the following functions:
POWER: Turns the soundbar on. Press and
hold for 2 seconds to turn the soundbar off (fig. 9).
PREVIOUS/NEXT INPUT: Cycles through the
inputs. The order of inputs is: Digital Optical > Digital
Coaxial > Left/Right Analog > Play-Fi (fig. 8).
VOL+/VOL–: Adjusts volume (fig. 8).
MUTE: When muted, the soundbar will display
‘MUTE’. Pressing this button a second time or
pressing either volume button will restore the previ-
ous volume setting (fig. 8).
Accessing the Menu: To access the menu,
for 2 seconds press and hold the center button.
After the menu is activated, the buttons will function
as up/down/left/right/enter. Exit the menu by
repeatedly pressing the left directional button (fig.
9 and fig. 10).
Wi-Fi Setup and Status: For information on
this button, please refer to the Play-Fi section of this
manual (fig. 9).
Fig. 8
Fig. 9
UPDATES AND REBOOTING
DTS PLAY-FI®APP UPDATE
If the DTS Play-Fi app on your mobile device or
PC requires an update, you will be notified that an
update is available and guided through the update
process.
DTS PLAY-FI MODULE UPDATE
The DTS Play-Fi module within your speaker will
occasionally require an update. If an update is
needed, the DTS Play-Fi app will notify you and
guide you through the update process.
SOUNDBAR FIRMWARE UPDATE
Your soundbar may occasionally require firmware
updates. Please check www.martinlogan.com for
the latest firmware updates.
REBOOTING YOUR SOUNDBAR
On the soundbar’s top control panel, press and
release both the Next and Previous Input (< and >)
buttons. Upon releasing the button, two tones will
play and the soundbar will reboot. This reboot will
cycle the power off and on and force the soundbar
to reconnect to your network.
20
Your soundbar remote controls these functions:
POWER: Turns the soundbar on and off.
VOL+/VOL–: Adjusts volume level.
MUTE: When muted, the soundbar will display
‘MUTE’. Pressing this button a second time or
pressing either volume button will restore the previ-
ous volume setting.
MENU: Enters the soundbar menu. Exit the menu
by pushing the menu button again.
BASS MODE – NIGHT: Reduces bass output
and compresses the dynamic range
.
BASS MODE – BASS+: Increases bass output.
BASS MODE – NORMAL: Restores normal levels.
INPUT: Activates the selected input.
CHANGING THE REMOTE’S BATTERY
The remote control for your speaker uses two AAA
type batteries. Access the battery compartment by
using a Phillips screwdriver to remove the screw lo-
cated on the bottom of the remote.
PROGRAMMING A SECOND REMOTE
This soundbar can be programmed to respond to
a second remote. See “The Menu System” section
of this manual for programming instructions.
Please note:
There may be remote controls
that the soundbar cannot learn or that the sound-
bar can not learn correctly. Due to the number of
available remote controls, it is impossible to advise
which will or will not work.
Please note: When learning from a second remote,
you will likely find it does not have buttons that directly
correspond with all available soundbar commands.
Not all soundbar commands have to be programmed.
Some remote controls offer ‘function’ buttons (F1, F2,
etc.) that can be used to program unique soundbar
commands such as ‘NITE.MD’ or ‘OPTIC’.
Please note:
Some remote controls offer discrete
‘power on’ and ‘power off’ buttons. Some offer
only a single button to toggle power on and off.
The learning function of the soundbar allows you to
program for either scenario.
REMOTE CONTROL
THE MENU SYSTEM
ENTERING AND EXITING THE MENU
To access the menu from the remote, press
‘Menu’. To exit the menu from the remote, press
‘Menu’ again or repeatedly press left until the
menu exits.
To access the menu from the top panel, for 2 sec-
onds press and hold the center button (fig. 9). To
exit, repeatedly press the left directional button.
The menu auto exits after 30 seconds.
Caution! Danger of explosion
if battery is incorrectly replaced.
Replace only with the same or
equivalent type.
