Motorola solutions USB-AC56-NA-MSI User manual

User Guide
USB Wifi Adapter System
USB-AC56-NA-MSI
USB-AC56-EU-MSI
H4-AC-WIFI

MOTOROLA, MOTO, MOTOROLA SOLUTIONS, and the Stylized M Logo are trademarks or registered
trademarks of Motorola Trademark Holdings, LLC and are used under license. All other trademarks are the
property of their respective owners. © 2023 Motorola Solutions, Inc. All rights reserved.
© 2023,Avigilon Corporation. All rights reserved. All rights reserved. AVIGILON, the AVIGILON logo,
AVIGILON CONTROL CENTER and ACC are trademarks of Avigilon Corporation. Google Chrome and
Android are trademarks of Google Inc. Other names or logos mentioned herein may be the trademarks of
their respective owners. The absence of the symbols ™ and ® in proximity to each trademark in this document
or at all is not a disclaimer of ownership of the related trademark.
This document has been compiled and published using product descriptions and specifications available at
the time of publication. The contents of this document and the specifications of the products discussed
herein are subject to change without notice. Avigilon Corporation reserves the right to make any such
changes without notice. Neither Avigilon Corporation nor any of its affiliated companies: (1) guarantees the
completeness or accuracy of the information contained in this document; or (2) is responsible for your use of,
or reliance on, the information. Avigilon Corporation shall not be responsible for any losses or damages
(including consequential damages) caused by reliance on the information presented herein.
Avigilon Corporation
avigilon.com
PDF-WIFIWEB-A
Revision: 2 - EN
20230505
ii

Table of Contents
Introduction 1
System Requirements 1
Package Contents 1
Using the USB Wifi Adapter System 2
Creating the Initial User and Logging In 3
Adding an Android Shortcut 3
Adding an iOS Shortcut 4
Configuring the Camera 5
Live View 5
Zooming and Focusing the Camera 5
Adjusting the Image Quality 6
Setting the Camera's IP Address 6
Configuring 802.1x Port Based Authentication 7
Setting Time on the Camera 8
Setting the Camera Name and Location 8
Changing the Camera Password 8
Disabling Wifi Access 9
For More Information 10
Troubleshooting 11
Android Repeatedly Prompts to Login to Wifi 11
iOS Mobile Web Interface Missing Video/Tabs/Buttons 11
iii

Introduction
The USB Wifi Adapter System provides you with direct access to the camera mobile web interface. During the
camera installation process, you can connect the USB Wifi Adapter to the camera's micro USB port. Once
connected, you can access the camera through the wifi network created by the adapter.
The camera mobile web interface is a simplified version of the camera's full web browser interface. It gives
you access to the camera's live video stream and allows you to change the camera's network settings. You
will also be able to adjust some of the camera's image settings.
System Requirements
To use all the features provided by the USB Wifi Adapter, you must have access to a mobile device with wifi
receiving capability and a web browser installed.
The following mobile operating systems and browsers are supported by the wifi adapter:
lAndroid™ version 4.3 or later
oGoogle Chrome™ browser versions 39 or later
liOS 8.3 or later
oThe default system browser
Package Contents
lUSB Wifi Adapter
lMicro USB to USB adapter cable
lT20 Pin-In Torx bit
Introduction 1

Using the USB Wifi Adapter System
The USB Wifi Adapter creates a wifi network when it is connected to the camera. Once the wifi network is
active, you can connect and access the camera's mobile web interface.
1. Connect one end of the micro USB cable to the camera. For more information, see the illustrated
instruction manual provided with the USB Wifi Adapter System.
2. Connect the USB Wifi Adapter to the other end of the cable.
3. On your mobile device, access the wifi settings page and connect to one of the following wifi
networks:
lMSICam-<last 6 digits of the USB Wifi Adapter MAC address>
For example: MSICam-12a4b6
lAvigCam-<last 6 digits of the USB Wifi Adapter MAC address>
For example: AvigCam-12a4b6
Note: The network you connect to is based on the firmware your camera is operating.
Cameras with recent firmwares will connect to an MSICam network. Cameras with earlier
firmware versions will connect to an AvigCam network.
4. When you are prompted to enter a password, enter:
lmotorola for MSICam networks
lavigilon for AvigCam networks
5. Access the camera's mobile web interface at camera.lan.
If you are not automatically prompted to enter the username and password for the mobile web
interface, open your web browser and enter http://camera.lan.
The USB Wifi Adapter automatically redirects you to the correct IP address even if the camera has
been assigned a specific IP address.
6. Cameras manufactured after January 1, 2020, do not have a default username or password and will be
in a factory default state.
Important: You must create a user with administrator privileges before the camera is
operational.
When you are prompted, enter the camera's administrator username and password. Depending on the
manufacture date of your camera, you will have one of the two options below to log in for the first time:
lCameras manufactured after January 1, 2020: these cameras do not have a default username
or password and will be in a factory default state. Login with the username and password that
you create when first connecting. For more information, see Creating the Initial User and
Logging In on the next page.
Using the USB Wifi Adapter System 2

lCameras manufactured before January 1, 2020: login to the camera using the default username
of administrator with no password. It is recommended that you change the password after
you first login.
The first page you see displays the camera's live video stream. You can adjust the camera's zoom and focus
from this page. For more information, see Configuring the Camera on page5.
After you finish configuring the camera from the mobile web interface, disconnect the USB Wifi Adapter.
Creating the Initial User and Logging In
Cameras manufactured after January 1, 2020, do not have a default username and password and will be in a
factory default state.
Important: You must create a user with administrator privileges before the camera is operational.
Tip: Cameras manufactured before January 1, 2020, have a default username and password you can
use to log in. For more information, see Using the USB Wifi Adapter System on the previous page.
If the camera is in the factory default state, you will be redirected to the CREATEUSER page to create an
administrator user:
1. Enter a new Usename or keep the default administrator name.
2. Enter a new Password for the user. It is recommended to use a secure and complex password. The
relative strength of your password is shown below the password field.
To ensure that you've entered the correct password, select the Show password check box.
3. Tap CREATEUSER. After creating the user, you will be asked to login with the credentials you have
just created.
Adding an Android Shortcut
To make accessing the mobile web interface more convenient, you can add a shortcut to camera.lan on your
Android Home screen.
The added benefit of accessing the mobile web interface from a shortcut is that the browser automatically
hides the address bar, so there is more screen space dedicated to the mobile web interface.
1. Connect and login to the camera mobile web interface. For more information, see Using the USB Wifi
Adapter System on the previous page.
2. In the Google Chrome web browser, display the browser menu and select Add to Home screen.
A shortcut is added to your Home screen.
Next time you use the USB Wifi Adapter, you can access the camera's mobile web interface from the shortcut.
Creating the Initial User and Logging In 3

Adding an iOS Shortcut
To maximize the screen area used by the mobile web interface, add a shortcut to your Home screen.
The benefit of accessing the mobile web interface from a shortcut is that the browser automatically hides the
address bar and the toolbar bar, so there is more screen space dedicated to the mobile web interface.
1. On the wifi settings page, tap for the USB Wifi Adapter network.
2. On the following page, tap Join Network.
3. When you are prompted to enter a password, enter:
avigilon
4. Tap Join.
The captive portal browser immediately opens the mobile web interface and asks you for the camera
credentials.
5. Tap Cancel.
6. In the top corner of the browser, tap Cancel then select Use Without Internet.
The wifi settings page is displayed, and you are still connected to the wifi network.
7. From the home screen, open the Safari browser and enter http://camera.lan.
8. When you are prompted, enter the camera's administrator username and password.
The default username is administrator with no password.
9. In the browser, tap .
10. In the following dialog, tap Add to Home Screen.
11. When the confirmation message is displayed, tap Add.
A shortcut is added to your Home screen.
Next time you use the USB Wifi Adapter, you can access the camera's mobile web interface from the shortcut.
Adding an iOS Shortcut 4

Configuring the Camera
After you connect to the mobile web interface, you can see the camera's live video stream to confirm that the
camera is aimed in the right direction. You can also adjust the camera's zoom and focus, and its network
settings. If you need to configure more detailed image and display settings, use the camera's full web
interface or the Avigilon Control Center™ Client software.
Live View
The first page you see after you login to the mobile web interface is the camera's live video stream. You can
digitally zoom and pan the video image to confirm that the camera is able to capture the expected level of
detail in the scene.
To access this page from other parts of the mobile web interface, tap the top-left menu icon then select
Camera.
Note: Digitally zooming and panning the video image does not set the camera's zoom level. To set
the video's zoom level, you must move the Zoom slider. For more information, see Zooming and
Focusing the Camera below.
lTo zoom in, place two fingers on the video image panel and pull apart to zoom in.
lWhile zoomed in, drag the screen to pan across the video image.
lTo zoom out, place to fingers on the image panel and push together to zoom out.
To adjust the video image quality, tap IMAGE and make the required changes. For more information, see
Adjusting the Image Quality on the next page.
Zooming and Focusing the Camera
To set the mechanical zoom and focus of the camera, use the settings available on the ZOOM/FOCUS tab of
the Camera page. The settings are provided below the camera's live video stream. Refer to the live video
stream after you make each change to confirm that the video is correct.
lTo change the camera's zoom level, move the Zoom slider. The farther right you move the slider, the
closer the camera zooms in.
lTo focus the camera, complete the following steps:
a. In the Iris drop down list, select Open. When the iris is fully open, the camera's depth of field is
the shortest.
b. Tap AUTO to allow the camera to auto focus once.
c. If the preferred focus was not achieved, use the focus near and far buttons to adjust the focus.
The left arrow buttons focus the camera towards Zero (0), and the right arrow buttons focus the
Configuring the Camera 5

camera towards Infinity.
d. In the Iris drop down list, select Automatic.
Allow the camera a few moments to save and apply your changes to the video stream.
Adjusting the Image Quality
As you observe the live video stream, you can adjust the camera's image quality. This includes the camera's
compression and image rate for streaming video through the network, and some basic lighting settings.
Note: Some options may not be displayed if they are not supported by the camera.
1. On the Camera page, tap IMAGE.
2. In the settings area below the image panel, tap any of the following settings to expand the settings
menu. You can scroll through the available options then select the appropriate setting.
lQuality — Select an image quality setting. An image quality setting of 1will produce the highest
quality video and require the most bandwidth. The default setting is 6.
lMax Bitrate — Select the maximum bandwidth the camera can use in kilobits per second
(kbps).
lKeyframe Interval — Select the preferred number of frames between each keyframe.
It is recommended that you have at least one keyframe per second. So, if the image rate is set
to 30 images per second, you should select 30 for this setting.
lImage Rate — Select the number of images per second you want the camera to stream over
the network.
lResolution — Select the preferred image resolution.
lFlicker Control — If your video image flickers because of the fluorescent lights around the
camera, you can reduce the effects of the flicker by changing this setting to match the
frequency of your lights. Generally, Europe is 50 Hz and North America is 60 Hz.
3. If the camera supports wide dynamic range (WDR), select the Enable Wide Dynamic Range check box
to use this feature.
This allows the camera to adjust the video image to accommodate scenes where bright light and dark
shadow are clearly visible.
4. If the camera includes an IR illuminator, select the Enable IR check box to use this feature.
Allow the camera a few moments to save and apply your changes to the video stream.
Setting the Camera's IP Address
By default, the camera is set to automatically obtain an IPaddress.
If the camera needs to use a static IPaddress in your network, you can disable the Automatic Network
Adjusting the Image Quality 6

Configuration option.
1. In the mobile web interface, tap the top-left menu icon then select Network.
2. On the Network page, tap the GENERAL tab.
3. Tap the Automatic Network Configuration switch to disable automatic IP addressing.
Once disabled, the screen displays the static IP settings.
4. Enter the IP Address, Subnet Mask, and Default Gateway that you want to use.
5. Tap SAVE.
Configuring 802.1x Port Based Authentication
If your network switch requires 802.1x port based authentication, you can set up the appropriate camera
credentials so that the video stream is not blocked by the switch.
Note: The mobile web interface only supports configuring PEAP username and password
authentication. To set up EAP-TLS certificate authentication, you must use the full web browser
interface.
1. In the mobile web interface, tap the top-left menu icon then select Network.
2. On the Network page, tap the 802.1X tab.
3. From the bottom right corner, tap
4. In the following Edit Configuration screen, enter the authentication details:
oConfiguration Name — give the profile a name.
oEAP Identity — enter the username that will be used to authenticate the camera.
oPassword — enter the password that will be used to authenticate the camera.
To ensure that you've entered the correct password, select the Show password check box.
5. Tap SAVE. If this is the first profile added to the camera, it is automatically enabled.
The profile is added to the 802.1X tab. The check mark beside the profile name shows that it is
enabled.
6. To add a another profile, tap again and repeat the previous steps.
7. To enable a different profile, tap the profile in the list then tap ENABLE on the following screen.
8. To delete a profile, tap .
The following message is displayed:
Delete configuration?
This 802.1x configuration will be permanently removed.
lTap DELETE.
Configuring 802.1x Port Based Authentication 7

Setting Time on the Camera
When Avigilon cameras are connected to the Avigilon Control Center, the cameras always keep time through
the software. If a camera is connected to a different network video management software or is recording to
itself, the camera keeps time through a Network Time Protocol (NTP) server.
By default, the camera automatically uses DHCP to find an NTP server that is available on the network. If
there are no NTP servers in your network, you can manually set the camera to use a specific NTP server.
1. In the mobile web interface, tap the top-left menu icon then select Network.
2. On the Network page, tap the GENERAL tab.
3. Tap the Configure NTP from DHCP switch to disable the camera from automatically looking for an
NTP server through DHCP.
Once disabled, the NTP Server setting is displayed.
4. Enter the address of your preferred NTP server.
5. Tap SAVE.
Setting the Camera Name and Location
To help you identify the camera and where it is installed, you can assign a specific name and location to the
camera. By default, the camera name is its model number and the location is not defined.
1. In the mobile web interface, tap the top-left menu icon then select Network.
2. On the Network page, tap the GENERAL tab.
3. In the Name and Location area, tap the following fields then enter the appropriate details:
lCamera Name — enter a specific name for the camera.
lLocation — enter where the camera is installed.
4. At the bottom of the screen, tap SAVE.
Your changes are saved and the camera can now be identified by its new name and location.
Changing the Camera Password
By default, Avigilon cameras manufactured before January 1, 2020, do not have a password. This provides
you with easy access to the camera during installation, but can prove to be a security risk if you do not apply a
password after it is connected to your network video management system. While you are installing the
camera, you can apply a new password to the camera.
Note: If your camera was manufactured after January 1, 2020, you will be required to create a user
with administrator privileges before the camera is operational. For more information, see Creating
the Initial User and Logging In on page3.
Setting Time on the Camera 8

This password is required to access the camera's mobile web interface, full web browser interface and for
connecting the camera to a network video management system.
1. In the mobile web interface, tap the top-left menu icon then select Users and tap the UPDATE USER
tab. If your camera is using older firmware and there is no Users menu, select Network and tap the
SECURITY tab.
2. In the Change Administrator Password area, tap the text field and enter a new password.
To ensure that you've entered the correct password, select the Show password check box.
3. Tap CHANGE PASSWORD.
The following message is displayed:
Confirm Password Change
Are you sure you want to change the administrator password?
4. Tap CONFIRM.
5. When you are prompted to log in again, enter the administrator username and the new password.
Disabling Wifi Access
After you've configured the camera and will no longer need to access the mobile web interface, you can
disable wifi access so that other users with a USB Wifi Adapter cannot modify the camera settings.
Note: Once you disable wifi access, you cannot access the mobile web interface again unless you
reset the camera to the factory default settings.
1. In the mobile web interface, tap the top-left menu icon then select Network.
The first screen you see is the SECURITY tab.
2. At the bottom of the screen, tap the Wifi Configuration Support switch to disable wifi access.
The following message is displayed:
Disable Wifi
Are you sure you want to disable Wifi? This action cannot be reversed.
3. Tap CONFIRM.
You will no longer be able to access the mobile web interface.
Disabling Wifi Access 9

For More Information
The USB Wifi Adapter System provides you with access to the most basic settings required for installing a
camera into your surveillance network. For more advanced configuration options, you will need to access the
camera's full web browser interface or connect the camera to the Avigilon Control Center.
For more information, see the following manuals:
lAvigilon™ High Definition H4 and H5 IP Camera Web Interface User Guide
lAvigilon Control Center™ Client User Guide
For More Information 10

Troubleshooting
If the following troubleshooting solutions do not resolve your issue, contact Technical Support:
lUSB-AC56-NA-MSI/USB-AC56-EU-MSI - motorolasolutions.com/en_us/support.html
lH4-AC-WIFI – avigilon.com/support
Android Repeatedly Prompts to Login to Wifi
After you login to the wifi network and are able to access the mobile web interface without issue, Android
continues prompt you to login to the wifi network from the notification menu. When you tap the notification to
log in again, a 401 Unauthorized error message is displayed.
This occurs because you are connected to a closed wifi network without internet access. Android devices
display these notifications whenever they lose internet connection to the Google servers.
Perform any of the following:
lIgnore the error message and login prompts. You are still able to access the mobile web interface
regardless of the notifications.
lIn the top-right corner of the error message, tap the menu button and select Use this network as is
then access the mobile web interface as usual. The login prompts stop displaying while you are using
the mobile device, but may return once the device is idle.
iOS Mobile Web Interface Missing Video/Tabs/Buttons
After you login to the wifi network and login to the mobile web interface, you notice that some of the interface
buttons or tabs are missing. In some cases, the live video stream may be missing or changes are not saved.
This may occur if the captive portal browser recently updated and no longer supports the mobile web
interface.
The captive portal browser is different from Safari, so you should still be able to access the mobile web
interface using the other browser.
To use Safari instead of the captive portal browser, complete the following steps:
1. On the wifi settings page, tap for the USB Wifi Adapter network.
2. On the following page, tap Join Network.
3. When you are prompted to enter a password, enter:
lmotorola for MSICam networks
lavigilon for AvigCam networks
4. Tap Join.
The captive portal browser immediately opens the mobile web interface and asks you for the camera
Troubleshooting 11

credentials.
5. Tap Cancel.
6. In the top corner of the browser, tap Cancel then select Use Without Internet.
The wifi settings page is displayed, and you are still connected to the wifi network.
7. From the home screen, open the Safari browser and enter http://camera.lan.
8. When you are prompted, enter the camera's administrator username and password.
The default username is administrator with no password.
The camera's mobile web interface is displayed and should provide all the expected tabs, buttons and video
stream.
iOS Mobile Web Interface Missing Video/Tabs/Buttons 12
