RS419
RING SCANNER
QUICK REFERENCE GUIDE

Motorola Solutions reserves the right to make changes to any product to improve reliability,
function, or design.
Motorola Solutions does not assume any product liability arising out of, or in connection with, the
application or use of any product, circuit, or application described herein.
No license is granted, either expressly or by implication, estoppel, or otherwise under any patent
right or patent, covering or relating to any combination, system, apparatus, machine, material,
method, or process in which Motorola Solutions products might be used. An implied license exists
only for equipment, circuits, and subsystems contained in Motorola Solutions products.
Warranty
For the complete Motorola Solutions hardware product warranty statement, go to:
http://www.motorolasolutions.com/warranty.
Service Information
If you have a problem using the equipment, contact your facility’s Technical or Systems Support. If
there is a problem with the equipment, they will contact the Motorola Solution Global Customer
Support Center at: http:www.motorolasolutions.com/support.
For the latest version of this guide go to: http://supportcentral.motorola.com.

Introduction
The RS419 ring scanner is a modular, wearable laser scanner that allows the operator hands-free bar
code scanning capability. The scanner is used with the WT4090 and WT41N0 wearable terminal.
The RS419 is worn on the operator’s index finger, and utilizes a thumb-operated trigger. The
RS419 connects via an interface cable to the wearable terminal, which provides power and
performs the data collection functions. The RS419 is available in two configurations; a short cable
version for connection to a wrist mounted wearable terminal, and a long cable version for
connection to a hip mounted wearable terminal.
Scan LED
Exit Window
Finger Strap
Assembly
Connector
Scan Trigger
Trigger Assembly
Scan Assembly
Short Cable Version Shown

Changing Trigger Position
The trigger assembly of the RS419 rotates to provide left-hand or right-hand
use.
1. Determine whether the RS419 is used on the right or left hand.
2. Rotate the trigger assembly so that the scan trigger is positioned next to
the thumb when the RS419 is placed on the index finger.
Installation
The RS419 connects to the wearable terminal and mounts on the index finger.
1. On the wearable terminal, remove the connector cap.
2. Connect the RS419 interface cable to the wearable terminal interface connector. If connecting
to a wrist mounted wearable terminal, connect to the interface connector closest to the wrist.
CAUTION The trigger assembly only rotates 180° around the
back of the scan assembly. Do not rotate the trigger
assembly past the designed stops.

3. Slide the RS419 onto the index finger with the scan trigger next to the thumb.
4. Tighten the finger strap.
Scanner
Cable
Connector
Interface Connector

5. If required, cut excess finger strap material.
6. Warm boot the wearable terminal.
Using the Scanner
Not to be used in condensing environments.
To scan bar codes:
1. Turn on the wearable terminal.
2. Launch a scanning application.
3. Press the scan trigger and aim the RS419 at a bar code.
The scan LED lights red to indicate the laser is on.
4. Position the red laser beam so that it covers the entire length of the bar code.

5. If the decode is successful the LED turns green. The terminal beeps if programed accordingly.
Scanning Tips
• For larger bar codes, hold the RS419 farther away from the bar code.
• For bar codes with bars that are closer together, hold the RS419 closer to the bar code.
• The optimal scanning distance varies with bar code density, but 10 to 25 cm (4 to 10 inches)
generally works. Practice to determine what distances to work within.
• Do not position the RS419 exactly perpendicular to the bar code being scanned. In this
position, reflected light can bounce back into the exit window, and possibly prevent a
successful decode.
Finger Strap Assembly Replacement
The finger strap assembly can be changed for each user or for replacement. To replace the finger
strap assembly:
1. Press down on the finger strap assembly release tab.

2. Slide the finger strap assembly out of the trigger assembly.
3. Align a new finger strap assembly with the slot in the trigger assembly.
4. Push the finger strap assembly into the trigger assembly until the release tab clicks into place.
5. Insert your index finger through the finger strap. Tighten the strap and press the hook and pile
together.
6. If required, cut excess finger strap material.
Release Tab

Replacing the Trigger Assembly
To replace the trigger assembly:
1. Remove the finger strap assembly.
2. Turn the RS419 upside-down.
3. Remove the set screw with
screwdriver.
4. Turn the trigger assembly
counter-clockwise until the exit
window and scan trigger align.
5. Lift the trigger assembly off the scan
assembly.
6. Align replacement trigger assembly
with scan assembly.
7. Rotate trigger assembly 1/4 turn
clockwise.
8. Tighten the set screw with
screwdriver.
9. Replace finger strap assembly.

Cleaning
Approved Cleanser Active Ingredients
100% of the active ingredients in any cleaner must consist of one or some combination of the
following: isopropyl alcohol, bleach/sodium hypochlorite, hydrogen peroxide or mild dish soap.
Harmful Ingredients
The following chemicals are known to damage the plastics on the RS419 and should not come in
contact with the device: ammonia solutions, compounds of amines or ammonia; acetone; ketones;
ethers; aromatic and chlorinated hydrocarbons; acqueous or alcoholic alkaline solutions;
ethanolamine; toluene; trichloroethylene; benzene; carbolic acid and TB-lysoform.
CAUTION Always wear eye protection.
Read warning label on compressed air and alcohol product before using.
If you have to use any other solution for medical reasons please contact
Motorola Solutions for more information.
WARNING!AVOID EXPOSING THIS PRODUCT TO CONTACT WITH HOT OIL
OR OTHER FLAMMABLE LIQUIDS. IF SUCH EXPOSURE OCCURS,
UNPLUG THE DEVICE AND CLEAN THE PRODUCT IMMEDIATELY
IN ACCORDANCE WITH THESE GUIDELINES.

Cleaning Instructions
Do not apply liquid directly to the RS419. Dampen a soft cloth or use pre-moistened wipes. Do not
wrap the device in the cloth or wipe, but gently wipe the unit. Be careful not to let liquid pool around
the display window or other places. Allow the unit to air dry before use.
Special Cleaning Notes
Many vinyl gloves contain phthalate additives, which are often not recommended for medical use
and are known to be harmful to the housing of the RS419. The RS419 should not be handled while
wearing vinyl gloves containing phthalates, or before hands are washed to remove contaminant
residue after gloves are removed. If products containing any of the harmful ingredients listed above
are used prior to handling the RS419, such as hand sanitizer that contain ethanolamine, hands
must be completely dry before handling the RS419 to prevent damage to the plastics.
Materials Required
• Alcohol wipes
• Lens tissue
• Cotton tipped applicators
• Isopropyl alcohol
• Can of compressed air with a tube.

Cleaning the RS419
Housing
Using the alcohol wipes, wipe the housing.
Exit Window
Wipe the scanner exit window periodically with a lens tissue or other material suitable for cleaning
optical material such as eyeglasses.
Connector
1. Disconnect the RS419 from the WT41N0.
2. Dip the cotton portion of the cotton tipped applicator in isopropyl alcohol.
3. Rub the cotton portion of the cotton tipped applicator back-and-forth across the connector. Do
not leave any cotton residue on the connector.
4. Repeat at least three times.
5. Use the cotton tipped applicator dipped in alcohol to remove any grease and dirt near the
connector area.
6. Use a dry cotton tipped applicator and repeat steps 4 through 6.

7. Spray compressed air on the connector area by pointing the tube/nozzle about ½ inch away
from the surface.
8. Inspect the area for any grease or dirt, repeat if required.
Cleaning Frequency
The cleaning frequency is up to the customer’s discretion due to the varied environments in which
the mobile devices are used. They may be cleaned as frequently as required. However when used
in dirty environments it may be advisable to periodically clean the scanner exit window to ensure
optimum scanning performance.
CAUTION Do not point nozzle at yourself and others, ensure the nozzle or tube is
away from your face.

Troubleshooting
Symptom Probable Cause Action
Laser beam
does not
display when
pressing the
trigger.
Interface cable is not secure. Verify that the interface cable connection is
connected properly.
Power is not applied to RS419. Power for the RS419 is provided by the
wearable terminal. Verify that the wearable
terminal has a charged battery installed.
Scan enabled application on the
wearable terminal is not running.
Launch scanning application on the wearable
terminal.
RS419 does
not decode a
bar code.
Bar code is unreadable. Verify that the bar code is not defective, i.e.,
smudged or broken.
Exit window is dirty. Clean exit window with a lens tissue. Tissues
for eyeglasses work well. Do not use tissues
coated with lotion.
Symbology is not enabled. See your system administrator.

Ergonomic Recommendations
• Reduce or eliminate repetitive motion
• Maintain a natural position
• Reduce or eliminate excessive force
• Keep objects that are used frequently within easy reach
• Perform tasks at correct heights
• Reduce or eliminate vibration
• Reduce or eliminate direct pressure
Condensation
appears on
the inside or
the outside of
the exit
window.
Using the ring scanner in a hot and
humid environment after being in a
freezer environment.
Wipe condensation from exit window with a
soft cloth.
For condensation on the inside, dedicate ring
scanner to freezer or hot and humid
environment. Do not pass between
environments with the same ring scanner.
CAUTION In order to avoid or minimize the potential risk of ergonomic injury follow the
recommendations below. Consult with your local Health & Safety Manager to
ensure that you are adhering to your company’s safety programs to prevent
employee injury.
Symptom Probable Cause Action

• Provide adequate clearance
• Provide a suitable working environment
• Improve work procedures.
Regulatory Information
This device is approved under the Motorola Solutions, Inc.
All Motorola/Symbol devices are designed to be compliant with rules and regulations in locations
they are sold and will be labeled as required.
Local language translations are available at the following website:
http://supportcentral.motorola.com.
Any changes or modifications to Motorola/Symbol Technologies equipment, not expressly
approved by Motorola/Symbol Technologies, could void the user's authority to operate the
equipment.
For use only with Motorola/Symbol approved and UL Listed mobile computers. Symbol approved
and UL Listed accessories and/or Motorola/Symbol approved and UL Listed/Recognized battery
packs.

Laser Devices
Complies with 21CFR1040.10 AND 1040.11 except for deviations pursuant to Laser Notice NO. 50,
dated June 24, 2007 and IEC 60825-1 (Ed. 2.0), EN60825-1: 2007.
The laser classification is marked on one of the labels on the device.
Class 1 Laser devices are not considered to be hazardous when used for their intended purpose.
The following statement is required to comply with US and international regulations:
Caution: Use of controls, adjustments or performance of procedures other than those specified
herein may result in hazardous laser light exposure.
Class 2 laser scanners use a low power, visible light diode. As with any very bright light source,
such as the sun, the user should avoid staring directly into the light beam. Momentary exposure to
a Class 2 laser is not known to be harmful.

Radio Frequency Interference Requirements-FCC
Note: This equipment has been tested and found to comply with the limits for
a Class B digital device, pursuant to Part 15 of the FCC rules. These limits
are designed to provide reasonable protection against harmful interference
in a residential installation. This equipment generates, uses and can radiate
radio frequency energy and, if not installed and used in accordance with the
instructions, may cause harmful interference to radio communications. However there is no
guarantee that interference will not occur in a particular installation. If this equipment does cause
harmful interference to radio or television reception, which can be determined by turning the
equipment off and on, the user is encouraged to try to correct the interference by one or more of
the following measures:
• Reorient or relocate the receiving antenna
• Increase the separation between the equipment and receiver
• Connect the equipment into an outlet on a circuit different from that to which the receiver is
connected
• Consult the dealer or an experienced radio/TV technician for help.
Radio Frequency Interference Requirements - Canada
This Class B digital apparatus complies with Canadian ICES-003.
Cet appareil numérique de la classe B est conforme à la norme NMB-003 du Canada.

Marking and European Economic Area (EEA)
Statement of Compliance
Motorola/Symbol, hereby, declares that this device is in compliance with all the applicable
Directives, 2004/108/EC and 2005/95/EC. A Declaration of Conformity may be obtained from
http://www.motorola.com/doc.
Japan (VCCI) - Voluntary Control Council for Interference
Class B ITE
ߎߩⵝ⟎ߪޔᖱႎಣℂⵝ⟎╬㔚ᵄ㓚ኂ⥄ⷙ೙ද⼏ળ㧔㨂㧯㧯㧵㧕ߩၮḰߦၮߠߊࠢ࡜ࠬ $ ᖱႎ
ᛛⴚⵝ⟎ߢߔޕߎߩⵝ⟎ߪޔኅᐸⅣႺߢ૶↪ߔࠆߎߣࠍ⋡⊛ߣߒߡ޿߹ߔ߇ޔߎߩⵝ⟎߇࡜ࠫࠝ
߿࠹࡟ࡆ࡚ࠫࡦฃାᯏߦㄭធߒߡ૶↪ߐࠇࠆߣޔฃା㓚ኂࠍᒁ߈⿠ߎߔߎߣ߇޽ࠅ߹ߔޕ ขᛒ
⺑᣿ᦠߦᓥߞߡᱜߒ޿ขࠅᛒ޿ࠍߒߡߐ޿ޕ
Korea Warning Statement for Class B ITE
ὤG㦹Gⷸ ㇠G㟝G㣄G㙼G⇨Gⱬ
i ἽGὤὤ
O ᴴ㥉㟝Gⵝ㋕䋩㐔ὤ㣄㣠 P
㢨Gὤὤ⏈Gᴴ㥉㟝 Oi Ἵ PG㤸㣄䑀㤵䚝ὤὤ⦐㉐G㨰⦐Gᴴ㥉㜄㉐G㇠㟝䚌
⏈Gᶷ㡸G⯝㤵㡰⦐G䚌⮤ SG⯜☔G㫴㜡㜄㉐G㇠㟝䚔G㍌G㢼㏩⏼␘ U

Taiwan Statement
R32626
᪯⏗᝹ឬེ
ဳภ  RS419
ა⷏ຮ೙ㅧ
Waste Electrical and Electronic Equipment
(WEEE)
English: For EU Customers: All products at the end of their life must be returned to Motorola for recycling.
For information on how to return product, please go to: http://www.motorola.com/recycling/weee.
Français: Clients de l'Union Européenne: Tous les produits en fin de cycle de vie doivent être retournés à
Motorola pour recyclage. Pour de plus amples informations sur le retour de produits, consultez :
http://www.motorola.com/recycling/weee.
Español: Para clientes en la Unión Europea: todos los productos deberán entregarse a Motorola al final de
su ciclo de vida para que sean reciclados. Si desea más información sobre cómo devolver un producto,
visite: http://www.motorola.com/recycling/weee.
Bulgarish: За клиенти от ЕС: След края на полезния им живот всички продукти трябва да се връщат
на Motorola за рециклиране. За информация относно връщането на продукти, моля отидете на адрес:
http://www.motorola.com/recycling/weee.
