DSP56311EVM PRODUCT INSTALLATION GUIDE
DSP56311EVMIG/D
Rev. 1.1, 12/1999
Welcome and thank you for choosing this Motorola
DSP Development Tools product. This document
provides instructions on how to set up the DSP56311
Evaluation Module (EVM) product.
If you have any questions, please contact the DSP
Technical Support organization via e-mail at:
[email protected]
or on the World Wide Web at:
http://www.motorola.com/SPS/DSP/support
To obtain any DSP Software Tools documentation,
please go to the DSP Tools web site on the World
Wide Web at:
www.motorola.com/SPS/DSP/tools/documentation
Kit Contents
Your DSP56311EVM product includes the following
components:
Hardware
- DSP56311EVM board
- Parallel port extender cable
- Plastic standoffs and plastic screws
DSP56311EVM Development Tools CD-ROM
- DSP56300 Tools Software
- Device and tools documentation
- Tutorial/example software
Printed Documentation
- DSP56311EVM Development Tools Release Notes
- DSP56311EVM Product Installation Guide
(this document)
1
For information regarding the DSP
Tools please access our site on the
World Wide Web at:
http://www.motorola.com/SPS/DSP/tools
This document contains information on a
new product. Motorola reserves the right to
make changes without further notice to any
of its products herein.
Motorola and are registered trademarks
of Motorola, Inc. All other tradenames,
trademarks, and registered trademarks are
the property of their respective owners.
© Copyright Motorola, Inc., 1999. All rights reserved.
6
DSP56311EVM Sample Code
The DSP56311EVM kit includes sample software that demonstrates various features of the DSP56311 processor
and the DSP56311EVM board. You will need an audio input source and headphones or amplified speakers to run
some of the sample code. The sample code is located at installed directory\dsp56311evm\sample_code.
The following demonstration source codes are included:
60Hz Demonstration (60hzdemo.asm):
This sample code illustrates many features of the DSP56311EVM product. An external audio signal is first applied into an input of the EVM
board. A 60Hz signal is generated by the DSP. Both the external signal and the 60Hz signal are added producing a digital audio signal with an
apparent 60Hz hum. The resultant signal is then sent to a digital 60Hz notch filter which removes the 60Hz hum.
Audio Pass Through Demonstration (pass.asm):
This sample code passes digital audio signals directly though the DSP without any modifications.
Echo Demonstration (echo.asm):
This sample code allows a user to input an audio signal into the EVM. The audio signal passes through the on-board codec and the digital signal
is then processed through the DSP. During the processing of the signal, a delay is added to the signal to achieve a simple echo.
Flash Memory Demonstration (flash.asm):
This sample code illustrates the use of the on board flash memory. The memory can be used to store
user-bootable code.
Filter Test Demonstration (fltr_tst.asm):
This sample code demonstrates the use of the on-board external memory, analog circuitry, and OnCE
port circuitry of the DSP56311EVM.
Please refer to the actual source code files for more information about the sample code.
1PHX36644-0 Printed in USA 4/01 Prisma Graphic #4802 300 LITDEVSY
Freescale Semiconductor, I
Freescale Semiconductor, Inc.
For More Information On This Product,
Go to: www.freescale.com
nc...

DSP56311EVM PRODUCT INSTALLATION GUIDE
Install Motorola’s DSP56311EVM Development Tools
2
System Requirements:
Windows PC (Pentiumâclass, or higher), 32 Mbytes of RAM,
Windowsâ95/98 or Windows NTâ4.0 operating system, 50 Mbytes
of hard drive space, parallel port, CD-ROM drive, and mouse.
1. Insert the DSP56311EVM Development Tools CD-ROM into
your computer’s CD-ROM drive.
2. If you have Autorun activated, the installation software will
start automatically. Otherwise, click on the Start button, select
Run and type the CD-ROM’s drive letter and \win\setup.exe
in the Open: text box. (For example, D:\win\setup.exe)
3. Follow the Motorola software installation instructions on your
screen.
3
Set Up the DSP56311EVM Board
The DSP56311EVM is shipped
with all the jumper blocks in the
default configuration. The photo
on the left shows the default
configuration for your reference.
For more information on the
jumper configuration of the
DSP56311EVM, refer to the
DSP56311EVM Hardware
Reference Manual on the
DSP56311EVM Development
Tools CD-ROM.
4
Connect the DSP56311EVM to your PC
1. Connect the DB25 plug end of
the parallel port extender cable to
the parallel port on your computer.
2. Connect the DB25 receptacle
end of the parallel port extender
cable to the parallel port connector
labeled P2 on the DSP56311EVM
Board.
3. Plug 2.1 mm coax connector of
7-12 V, 500 mA power supply
(supplied by user) into the P6
connector on the DSP56311EVM
board.
4. Plug the other end of the power
5
The DSP56311EVM Browser and Tutorial
The DSP56311EVM browser provides access to
product information, release notes, documentation,
tutorial, installation guide, install information, and
contact information. The DSP56311EVM browser will
automatically launch if Autorun is enabled on your
computer. If Autorun is not enabled, click the
start.exe file to launch the browser.
To run Motorola’s DSP56311EVM Tutorial, click on the tutorial
button in the DSP56311EVM browser. Example software is
included in the tutorial program supplied on the DSP56311EVM
Development Tools CD-ROM.
