Motorola D10 SERIES User manual

Warning: Charge the handset for 24 hours before use.
Motorola D10
Models: D1001, D1002, D1003 and D1004
Digital Cordless Telephone

Welcome...
to your new Motorola D10 Digital Cordless Telephone!
• All handsets fully cordless for locating anywhere within range.
• 100 Name and number phonebook.
• Copy phonebook entries between handsets.
• Speakerphone for hands-free conversations.
• Caller ID shows you who’s calling and see details of the last 50 callers in a Calls list.1
• Register up to 5 handsets to a single base and register each handset with up to 4
dierent bases.
• Make internal calls, transfer external calls, hold 3-way conversation between two
internal callers and an external caller.
• ECO mode reduces the transmitted power and energy consumption.
Need help?
If you have any problems setting up or using your D10, please contact Customer
Services on (65) 68412668.
Email: [email protected]
Alternatively, you may nd the answer in the ‘Help’ section at the back of this guide.
Please note that this equipment is not designed for making emergency telephone
calls when the power fails. Alternative arrangements should be made for access to
emergency services.
1You must subscribe to your network provider’s Caller ID or Call Waiting service for
these features to work. A subscription fee may be payable.

This user guide provides you with all the information you need to get the
most from your phone.
To set up your phone, follow the simple instructions in ‘Getting Started’,
on the next few pages.
IMPORTANT
Only use the telephone line cord supplied.
Got everything?
• Cordless handset
• Cordless base
• 2 x rechargeable Ni-MH battery cells
• Power adaptor for the base
• Telephone line cord
If you have purchased a D10 multiple pack you will also have the following
additional items:
• Cordless handset & charger
• 2 x rechargeable Ni-MH battery cells
• Power adaptor for the charger
ECOMOTO: a convergence of eorts by marketing, design, research, engineering
and supply chain management that leads to better products for everyone. A holistic
view that focuses on both social and environmental responsibility. A passion and a
shared point of view.
The right thing to do.
• Meets and / or exceeds EMEA environmental regulatory requirements.
• Eco friendly packaging with a minimum 20% post consumer
recycled content.
• Phone housing is built with a minimum of 25% post consumer recycled content plastic.
• Energy eicient charger that meets EU Code of Conduct requirements.
• ECO mode function which reduces the transmitted power and energy consumption,
please refer to page 37.

4
1. Getting started .....................................................................7
2. Getting to know your phone ..............................................11
3. Using the phone .................................................................16
3.1 Make a call .....................................................................................................16
3.2 Pre-dial ...........................................................................................................16
3.3 Dial one touch numbers 1 to 9 ......................................................................16
3.4 Call from the phonebook ..............................................................................16
3.5 Call from the Calls list....................................................................................16
3.6 Answer a call ..................................................................................................16
3.7 Adjust volume ................................................................................................17
3.8 Mute...............................................................................................................17
3.9 End a call........................................................................................................17
3.10 Switch handset on/o....................................................................................17
3.11 Intercom.........................................................................................................17
3.11.1 Call another handset...........................................................................17
3.11.2 Transfer an external call to another handset.......................................18
3.11.3 Three-party conference call ...............................................................18
4. Phonebook .........................................................................19
4.1 View and dial phonebook entries .................................................................19
4.2 Store an entry.................................................................................................19
4.3 Entering names..............................................................................................19
4.4 Character map...............................................................................................20
4.5 Enter a pause .................................................................................................20
4.6 View an entry .................................................................................................20
4.7 Edit an entry...................................................................................................21
4.8 Delete an entry ..............................................................................................21
4.9 List entry.........................................................................................................21
4.10 Delete all entries ............................................................................................21
4.11 Store a one touch memory number..............................................................22
4.12 Delete a one touch memory number............................................................22
4.13 Copy phonebook to another handset ..........................................................22
5. Caller ID and Calls list ........................................................24
5.1 Calls list ..........................................................................................................24
5.1.1 View the Calls list ................................................................................24
5.1.2 Dial from the Calls list .........................................................................24
5.1.3 Save a number from the Calls list to the phonebook.........................25
5.1.4 Delete a Calls list entry .......................................................................25
5.1.5 Delete entire Calls list.........................................................................25
5.2 Redial .............................................................................................................25
5.2.1 Redial the last number ........................................................................25
5.2.2 View and dial a number in the redial list.............................................25
5.2.3 Copy a redial number to the phonebook ..........................................26

5
5.2.4 Delete a redial list entry ......................................................................26
5.2.5 Delete entire redial list........................................................................26
6. Clock & Alarm ....................................................................27
6.1 Set date and time...........................................................................................27
6.2 Set alarm ........................................................................................................27
6.3 Set alarm melody...........................................................................................27
7. Personal settings.................................................................28
7.1 Handset tones................................................................................................28
7.1.1 Ring volume........................................................................................28
7.1.2 Ring melody........................................................................................28
7.1.3 Group melody ....................................................................................28
7.1.4 Key tones on/o..................................................................................29
7.1.5 First ring ..............................................................................................29
7.2 Handset name................................................................................................29
7.3 Auto pick up...................................................................................................29
7.4 Auto hang up .................................................................................................30
7.5 Display language ...........................................................................................30
7.6 Room monitor on/o.....................................................................................30
7.7 Room monitor................................................................................................30
7.8 Backlight on/o..............................................................................................31
7.9 Keypad lock ...................................................................................................31
8. Advanced settings..............................................................32
8.1 Recall time .....................................................................................................32
8.2 Dial mode.......................................................................................................32
8.2.1 Temporarily switch from Pulse to Tone dialling..................................32
8.3 Call barring ....................................................................................................32
8.3.1 Switch call barring on/o....................................................................33
8.3.2 Set a number to be barred..................................................................33
8.4 Easy call..........................................................................................................33
8.4.1 Switch Easy call on/o ........................................................................33
8.4.2 Set the Easy call number.....................................................................33
8.4.3 Dial an Easy call number.....................................................................34
8.5 Registration....................................................................................................34
8.6 Register a handset .........................................................................................34
8.7 Select a base..................................................................................................34
8.8 Unregister a handset......................................................................................35
8.9 PIN..................................................................................................................35
8.10 Reset ..............................................................................................................35
8.11 Default settings..............................................................................................36
8.12 Auto prex......................................................................................................36
8.13 Country..........................................................................................................37
8.14 Intrusion .........................................................................................................37
8.15 ECO mode ....................................................................................................37

6
9. Help.....................................................................................38
10. General information ...........................................................39
11. Wall mounting ....................................................................45

7Getting started
1. Getting started
IMPORTANT
Do not place your D10 in the bathroom or other humid areas.
Location
You need to place your D10 base within 2 metres of the mains power socket and telephone
wall socket so that the cables will reach. The socket-outlet should be installed near the
equipment and should be easily accessible.
Make sure it is at least 1 metre away from other electrical appliances to avoid interference.
Your D10 works by sending radio signals between the handset and base. The strength of
the signal depends on where you place the base. Putting it as high as possible ensures the
best signal.
HANDSET RANGE
The unit has a range of up to 300 metres outdoors when there is a clear line of sight
between the base and handset. Any obstruction between the base and handset will
reduce the range signicantly. With the base indoors and the handset either indoors or
outdoors, the range will normally be up to 50 metres. Thick concrete and stone walls can
severely aect the range.
SIGNAL STRENGTH
The icon on your handset indicates that you are within range of the base. When out of
range of the base, the screen shows SEARCHING and the icon flashes.
If you are on a call, the line will hang up if the handset moves out of range of the base.
Move back within range. The handset will automatically re-connect to the base.
Setting up
IMPORTANT
The base station must be plugged into the mains power at all times. Do not connect the
telephone line cord into the wall socket until the handset is fully charged. Use only the
power adaptor and telephone line cord supplied with the product.
WHICH POWER ADAPTOR?
The power adaptor with a clear connector is for the base unit and the power adaptor with
a red colour connector is for the charger unit.

8 Getting started
Connecting the base
1. Plug the telephone line cord into the socket marked on the underside of the base.
2. Plug the mains power cable with the clear connector into the socket marked on the
underside of the base and plug the other end into the mains power wall socket. Switch
on the mains power.
Installing and charging the handset
1. Remove the battery cover from the back of the handset and insert the rechargeable
Ni-MH battery cells supplied. Please note the ’+’ and ’-’ markings inside the battery
compartment and insert in the correct direction.
2. Slide the battery cover back into place.
3. If you are charging the batteries for the rst time, place the handset on the base to
charge for at least 24 hours continuously.
4. When the handset is fully charged, icon will appear steady on the display. Plug the
other end of the telephone line cord (make sure that one end is already plugged into
the base) into the telephone wall socket.
Connecting the handset and charger
(for multi-pack only)
If you have purchased a multiple pack, you will need to carry out this process for all the
handsets and chargers.

9Getting started
1. Plug the mains power cable with the red connector into the socket marked on the
underside of the charger and plug the other end into the mains power wall socket.
2. Remove the battery cover from the back of the handset and insert the 2 x AAA NiMH
rechargeable batteries supplied. Please note the ’+’ and ’-’ markings inside the battery
compartment and insert in the correct direction.
3. Slide the battery cover back into place.
4. If you are charging the batteries for the rst time, place the handset on the charger to
charge for at least 24 hours continuously.
5. When the handset is fully charged, icon will appear steady on the display. The
display will show HANDSET and handset number (e.g. 2) to indicate that it is registered
to the base.
IMPORTANT
Warning! Use only the approved rechargeable Ni-MH battery cells (2 x AAA Ni-MH 550mA
rechargeable batteries) supplied with your D10.
BATTERY LOW WARNING
If icon flashes in the display, you will need to recharge the handset before you can
use it again.
When charging, icon will scroll on the display.
Once fully charged scrolling will stop.
BATTERY PERFORMANCE
In ideal conditions, fully charged batteries should give up to 10 hours talk time or up to 150
hours standby time on a single charge.1
Note that new batteries do not reach their full capacity until they have been put to normal
use for several days.
To keep your batteries in the best condition, leave the handset o the base for a few hours
at a time.
Running the batteries right down at least once a week will help them last as long as
possible.
The charge capacity of rechargeable batteries will reduce with time as they wear out,
giving the handset less talk / standby time. Eventually they will need to be replaced.
After charging your handset for the rst time, subsequent charging time is about 6–8 hours
a day. Batteries and handset may become warm during charging. This is normal.
1All talk and standby times are approximate and depend on features selected and usage
pattern.

10 Getting started
Setting up your D10
Welcome screen
1. WELCOME is displayed and scrolls in dierent languages. Press m. The country
name is shown on the display.
2. Scroll uor dto your country and press m. CONFIRM? is displayed.
3. Press mto conrm.
The handset and base will reset to load the correct settings. The standby screen is then
displayed and your phone is ready to use.
You can still make and receive calls without rst selecting your country and network
operator, however the Welcome screen will re-appear until you have congured your
phone country settings.
Date and time
If you have subscribed to a Caller ID Service, the date and time is set automatically for all
handsets when you receive your rst call.
If you do not have a Caller ID service, you can set the date and time manually.
1. Press m, scroll dto CLOCK/ALARM and press m.
2. DATE & TIME is highlighted. Press m.
3. Enter the date using the format DD/MM e.g. 04/08 for 4 August and press m.
4. Enter the time using 24 hour format (HH:MM) e.g. 14:45 for 2:45pm and press m.
5. Press >to return to standby.
Your D10 is now ready for use.

11Getting to know your phone
2. Getting to know your phone
Overview of your handset
A Earpiece
B Display
See page 13 for display icons.
C Call list / Scroll Up / Volume up
Press uto enter the Calls list.
Scroll up through lists and settings.
D Menu / OK
Enter the main menu.
Select the option displayed on screen.
Conrm menu option – OK is displayed on screen.
A
B
C
D
E
F
G
H
N
M
L
K
J
I

12 Getting to know your phone
E Talk / Recall
Make or answer a call.
Use recall (R) functions.
When on an external call, press this key once to get a fresh dial tone or to access a
Call Waiting Line when you hear the call waiting prompt signal. Press this key again to
toggle between the two calls. Also used with switchboard / PABX services and some
network services.
F Pulse to Tone Dialling / * / Keypad lock
During a call, press and hold to switch from pulse dialling to tone dialling.
Dial a *.
In standby mode press and hold to lock/unlock the keypad.
G Hands-free key
Activate and deactivate hands-free during a call.
IMPORTANT
Hands-free activation can suddenly increase the volume in the earpiece to a very high
level. Make sure the handset is not too close to your ear.
H Redial / Scroll right / Clear / Mute / Back
Open the redial list. Scroll to the right.
Delete characters on screen when entering names and numbers.
Mute / unmute the microphone during a call.
Go back to previous menu level - BACK is displayed on the screen.
I Navigator glow ring
Illuminates when the phone is in use. Flashes to indicate new Voicemail messages.
J End call / Exit / Switch handset on/o
End a call.
When in a menu, go back to standby mode.
Press and hold to switch handset o (when in standby) or on.
K Phonebook / Scroll Down / Volume down
Open the phonebook.
Scroll down through lists and menus.
Decrease the earpiece volume.
L Ringer o / Pause / #
Press and hold to switch handset ringer on or o.
When dialling or storing a number, press and hold to enter a pause (P).
Dial a #.
M Intercom
Press to make an internal call.
N Microphone

13Getting to know your phone
Handset display
Display icons
On when the line is in use.
Flashes when there is an incoming call.
Flashes when you have new voicemail messages.1
O when you have no voicemail messages.
Flashes when you have missed calls and new number(s) are in the Calls list.2
Phonebook is open.
The alarm clock has been set.
Hands-free mode is activated.
Handset ringer is o.
Steady when the handset is registered and within range of the base. Flashes when
the handset is out of range or searching for base.
The approximate power levels of your battery are indicated as below:
Battery is fully charged.
Battery is partially charged.
Battery is running low.
Battery is almost empty. The battery icon will flash and emit a warning beep every
minute during call.
1This feature is dependent on your Network Service provider supporting the service. A
subscription fee may be payable.
2For this feature to work, you must subscribe to Caller ID Service from your network
operator. A subscription fee may be payable.

14 Getting to know your phone
Overview of the base
A Paging key
Paging is a useful way of nding lost handsets.
1. Press pon the base.
All handsets ring.
2. Press pagain to cancel the paging call or press any key on the handset to stop the
paging call.
Navigating the menus
The basic steps of navigating through the menu and on-screen options.
1. From the standby screen, press m.
The main menu is opened.
2. Use the uor dkeys to scroll through the menu.
3. Soft key options OK and BACK are displayed. Press mto select OK and open a
sub-menu or validate an option.
Press BACK to go back to previous menu level, correct a character or cancel an action.
4. Press >to return to standby.
NOTE
If you do not press any button on the handset for 15 seconds the display will automatically
return to standby. It will also return to standby when the handset is placed on the base or
charger.
A

15Getting to know your phone
Menu Map
PHONEBOOK ADVANCED SET
NEW ENTRY RECALL TIME
LIST ENTRY DIAL MODE
<NAME>CALL BARRING
EDIT ENTRY EASY CALL
DELETE ENTRY REGISTRATION
DELETE ALL SELECT BASE
DIRECT MEM REGIST. BASE
PB TRANSFER1UNREGISTER
CLOCK/ALARM PIN
DATE & TIME RESET UNIT
SET ALARM PREFIX
ALARM TONE SEL. COUNTRY
PERSONAL SET INTRUSION
HANDSET TONE ECO MODE
RING VOLUME
RING MELODY
GROUP MELODY
KEY TONE
FIRST RING
HANDSET NAME
AUTO PICK-UP
AUTO HANG-UP
LANGUAGE
ROOM MONITOR
BACKLIGHT
1This option is only available if more than one D10 handset is registered to the base.

16 Using the phone
3. Using the phone
3.1 Make a call
1. Press <.
2. Dial the telephone number.
3.2 Pre-dial
1. Enter the phone number (maximum 24 digits). If you make a mistake press .
2. Press <to dial the phone number entered.
3.3 Dial one touch numbers 1 to 9
1. Press and hold a key from 1to 9until the number is displayed and dialled.
NOTE
To store a one touch number, see page 22.
3.4 Call from the phonebook
1. Press d. The rst entry in the phonebook is displayed.
2. Scroll uor dto the entry you want.
3. Press <to dial the number.
NOTE
Instead of scrolling to browse the phonebook entries, press the numeric key corresponding
to the rst letter of the entry you wish to locate. For example, pressing 2will show the
entries starting with A. Pressing 2again will show the entries starting with B, etc...
3.5 Call from the Calls list
NOTE
You need to subscribe to your network’s Caller ID service to be able to see the caller’s
number in the Calls list. See “Calls list” on page 24 for more details.
1. Press uto enter the Calls list. The rst entry in the calls list is displayed.
2. Scroll uor dto the entry you want.
3. Press <to dial the number.
3.6 Answer a call
1. When the phone rings and flashes in the display, if the handset is o the base press
<to answer the call, or if the handset is on the base simply lift the handset to answer
the call.
2. Press to answer the call via hands-free.
3. To switch between hands-free and the earpiece press .

17Using the phone
IMPORTANT
When the phone is ringing, avoid holding the earpiece too close to your ear as it may
damage your hearing.
NOTE
If you have subscribed to your Network’s Caller ID service and assigned a VIP Group to
the caller’s number, the caller’s details are displayed before the phone starts ringing (see
“Store an entry” on page 19 and “Group melody” on page 28). You can set your phone
to give the default ringtone as soon as the call is received then once the caller’s identity is
displayed, the assigned ringtone will start. See “First ring” on page 29.
If Auto Pick up mode (see page 29) is on, simply lift up the handset from its base to answer
the call. The default setting is ON. See all “Default settings” on page 36.
An incoming call has priority over other events. Whenever there is an incoming call, other
operations in progress such as phone settings, menu navigation, etc. will be ended.
3.7 Adjust volume
1. During a call, press uor dto adjust the earpiece or hands-free volume. The level is
shown in the handset display.
3.8 Mute
Mute the microphone so that you can talk to someone else in the room without your caller
hearing you.
1. During a call, press . The microphone is muted.
2. Press again to turn the microphone back on.
3.9 End a call
1. Press >.
After you hang up, the duration the phone is o-hook is displayed for 5 seconds.
NOTE
If auto hang-up is on (see page 30) simply replace the handset on the base to end the call.
The default setting is ON .
3.10 Switch handset on/o
1. Press and hold >to switch the handset on or o.
3.11 Intercom
This feature is only available when there are at least 2 registered handsets. It allows you
to make internal calls, transfer external calls from one handset to another and use the
conference option.
3.11.1 Call another handset
1. Press .
• If you have two handsets, the other handset is called automatically.

18 Using the phone
• If more than two handsets are registered to the base, their numbers are displayed,
e.g. 2345*. Enter the number of the handset you want to call or press to ring all
handsets.
2. Press >to hang up.
NOTE
If the handset does not belong to D10 range, this function may not be available.
3.11.2 Transfer an external call to another handset
1. During an external call, press .
Your caller is put on hold.
2. Enter the number of the handset you want to call or press to ring all handsets.
If there are only two handsets, the other handset is called automatically.
3. When the other handset answers, announce the caller then press >to transfer the
call. If the other handset does not answer, press to talk to your caller again.
3.11.3 Three-party conference call
1. During an external call, press .
Your caller is put on hold.
2. Enter the number of the handset you want to call or press to ring all handsets.
If there are only two handsets, the other handset is called automatically.
3. When the other handset answers, announce the call then press and hold to
connect both calls. If the other handset does not answer, press to talk to
your caller again.
4. Press >to hang up.

19Phonebook
4. Phonebook
The D10 handset phonebook can store up to 100 names and numbers.
Numbers can be up to 24 digits long and names up to 12 characters long. Entries are
stored in alphabetical order.
4.1 View and dial phonebook entries
1. Press d. Display shows the rst entry.
2. Scroll uor dto the entry you want.
Or
To search alphabetically, press dthen press the key with the rst letter
of the name, e.g. if the name begins with N, press 6twice.
The display shows the rst entry beginning with N. If required, press uor dto scroll
to the exact entry.
3. Press <to dial the entry displayed.
4.2 Store an entry
1. Press m. PHONEBOOK is displayed.
2. Press m. NEW ENTRY is displayed.
3. Press m. ENTER NAME is displayed.
4. Enter a name and press m.
5. Enter a number. Press mto save. Press uor dto select NO GROUP , GROUP A , B
or C and press mto conrm.
6. Press >to return to standby.
NOTE
You can assign individual contacts to specic groups of your choice. For example, Group
A contains phone numbers of all your co-workers. You can also assign a specic ring
melody to that group (see “Group melody” on page 28). You can benet from this feature
only if you have subscribed to Caller ID service from your network provider. If it is the case,
every time someone from that group calls you, you will hear the designated melody for
that group.
Cancel storing an entry by pressing >at any time during the process.
4.3 Entering names
Use the alphanumeric keypad to enter names in the phonebook.
For instance to enter the name Paul
P Press 7once
A Press 2once
U Press 8twice
L Press 5three times

20 Phonebook
To enter a space press 1
Press to delete a character or press and hold to delete all characters.
4.4 Character map
Use the keypad to enter names and characters.
Key Assigned characters and symbols
1Space 1 - < > *
2A B C 2
3D E F 3
4G H I 4
5J K L 5
6M N O 6
7P Q R S 7
8T U V 8 ?
9W X Y Z 9
00 - / \ # +
4.5 Enter a pause
If your D10 is connected to a switchboard, you may need to enter a pause in a stored
number. This gives the switchboard time to get an outside line. A pause is normally stored
after the switchboard access code (e.g. 9)
1. When storing a number, press and hold until the display shows P. You can then
continue storing the phone number.
4.6 View an entry
In standby:
1. Press d.
2. Enter the rst letter of the name to search alphabetically then scroll uor dto the
exact entry. The name is displayed.
3. Press to display the number. If there are more than 12 digits, press again to
see the rest of the number.
4. Press >to return to standby.
