Motorola MD4150 Series User manual

TM
MD4150 Series User Guide
Guide de l'utilisateur de la série MD4150
2.4 GHz Digital Cordless Telephone
Téléphone numérique sans fil à 2,4 GHz

For product-related questions, please
visit us online:
www.motorola.com/cordless
or call us at:
1-800-461-4575 Canada
1-888-390-6456 TTY (Text Telephone)
Motorola reserves the right to revise this publication
and to make changes in content from time to time
without obligation on the part of Motorola to provide
notification of such revision or change. Motorola
provides this guide without warranty of any kind,
either implied or expressed, including but not limited
to, the implied warranties of merchantability and
fitness for a particular purpose. Motorola may make
improvements or changes in the product(s)
described in this manual at any time.
MOTOROLA and the Stylized M Logo are registered in
the U.S. Patent and Trademark Office. All other product
or service names are the property of their
respective owners.
Copyright © 2005 Motorola, Inc.
All rights reserved. No part of this publication may be
reproduced in any form or by any means or used to
make any derivative work (such as translation,
transformation or adaptation) without written
permission from Motorola, Inc.

i
Welcome
Welcome
Congratulations on your purchase of a Motorola
MD4150 Series Cordless Telephone. Take a moment
to ensure that your purchase includes each of the
items pictured below.

ii
Welcome
MD4150 Series Handset
Volume control
Ringing Status LED
Access Caller ID/
Scroll down
Make/Answer call/
Switch between
active calls
Switch between
Pulse (rotary)/Tone
Mute/delete
caller information
Microphone
Switch to
hands-free mode
Earphone jack
Access Directory/
Scroll up
Select menu options/
Transfer call/
Menu options
End call/
Cancel command
Call second
Handset
Antenna
Redial last
number called/
Insert Pauses

iii
Welcome
Base Unit
Locate Handset(s)
Handset charging LED
Handset in use LED
Voice mail LED

iv
Welcome
Stand Alone Charger
Charge LED

v
Table of Contents
Welcome . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . i
Table of Contents . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . v
Important Safety Instructions . . . . . . . . . . . . . . . . . . . vii
Industry Canada (IC) Information . . . . . . . . . . . . . . . . . x
Getting Started . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
Battery Safety Instructions . . . . . . . . . . . . . . . . . . . . . . 1
Charging the Battery . . . . . . . . . . . . . . . . . . . . . . . . . . 2
Handset Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Installation. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Setting Up . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Personalizing Your Handset . . . . . . . . . . . . . . . . . . . . . 7
Selecting Ring Tones . . . . . . . . . . . . . . . . . . . . . . . . 7
Naming Your Handset . . . . . . . . . . . . . . . . . . . . . . . . 8
Selecting Language Preference . . . . . . . . . . . . . . . . 8
Setting Touch Tone or Pulse Dialing . . . . . . . . . . . . . 9
Turning the Key Beeps Off/On . . . . . . . . . . . . . . . . . 9
Using the Handset . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
Making a Call . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
Answering/Ending a Call . . . . . . . . . . . . . . . . . . . . . . 11
Locating a Misplaced Handset . . . . . . . . . . . . . . . . . . 11
Adjusting the Ringer Volume . . . . . . . . . . . . . . . . . . . 11
Adjusting the Volume . . . . . . . . . . . . . . . . . . . . . . . 12
Using the Mute Feature . . . . . . . . . . . . . . . . . . . . . 12
Making Intercom Calls . . . . . . . . . . . . . . . . . . . . . . . . 12
Forwarding a Call . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
Using Call Transfer . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
Using Conference Calling . . . . . . . . . . . . . . . . . . . . . . 14
Storing Numbers in Memory . . . . . . . . . . . . . . . . . . . 14

vi
Storing a New Entry . . . . . . . . . . . . . . . . . . . . . . . . 14
Deleting a Phonebook Entry . . . . . . . . . . . . . . . . . 15
Dialing Phonebook Numbers . . . . . . . . . . . . . . . . . 15
Editing a Phonebook Entry . . . . . . . . . . . . . . . . . . 16
Using Caller ID Functions . . . . . . . . . . . . . . . . . . . . . 16
Storing a Caller ID Entry in Memory . . . . . . . . . . . 16
Dialing a Caller ID Listing . . . . . . . . . . . . . . . . . . . . 17
Reviewing Caller ID Lists . . . . . . . . . . . . . . . . . . . . 17
Deleting a Specific Caller ID Listing . . . . . . . . . . . . 17
Deleting All Caller ID Listings . . . . . . . . . . . . . . . . . 18
Motorola Limited Warranty . . . . . . . . . . . . . . . . . . . . . 19

vii
Safety Info
Important Safety Instructions
Follow these safety precautions when using your
cordless phone to reduce the risk of fire, electric shock
and injury to persons or property:
To reduce the risk of fire and shock:
1. Keep all slits and openings of the phone unblocked.
Do not set the phone on a heating register or over a
radiator. Ensure that proper ventilation is provided
at the installation site.
2. Do not use while wet or while standing in water.
3. Do not use this product near water (for example,
near a bath tub, kitchen sink, or swimming pool).
4. Do not allow anything to rest on the power cord.
Place the power cord so that it will not be
walked on.
5. Never insert objects of any kind into the product
slits as that may result in fire or shock.
6. Unplug this product from the wall outlet before
cleaning. Do not use liquid cleaners or aerosol
cleaners. Use a damp cloth for cleaning.
7. Do not disassemble this product. If service or repair
work is required, contact the Motorola address
found in the back of this user guide.
8. Do not overload wall outlets and extension cords.
9. Avoid using during an electrical storm. Use a surge
protector to protect the equipment.
10. Do not use this cordless phone to report a gas leak,
especially if you are in the vicinity of the gas line.
Caution: To reduce the risk of fire, use only No. 26
AWG or larger UL listed or CSA Certified
Telecommunication Line Cord.

viii
Safety Info
Unplug this cordless phone immediately from
an outlet if:
• The power cord or plug is damaged or frayed.
• Liquid has been spilled into the product.
• The product has been exposed to rain or water. Do
not retrieve the handset or base until after you have
unplugged the power and phone from the wall.
Then retrieve the unit by the unplugged cords.
• The product has been dropped or the cabinet has
been damaged.
• The product exhibits a distinct change in perfor-
mance.
Installation Guidelines
1. Read and understand all instructions and save
them for future reference.
2. Follow all warnings and instructions marked on
the product.
3. Do not install this product near a bath tub, sink,
or shower.
4. Operate this phone using only the power source
that is indicated on the marking label. If you are
unsure of the power supply to your home, consult
your dealer or local power company.
5. Do not place this product on an unstable cart,
stand, or table. This product may fall, causing
serious damage to the product.
6. Adjust only those controls that are covered by
the operating instructions. Improper adjustment
of other controls may result in damage and will
often require extensive work to restore the
product to normal operation.
7. Clean this product with a soft, damp cloth. Do not
use chemicals or cleaning agents.

ix
Safety Info
8. Use only the power supply that came with this
unit. Using other power supplies may damage
the unit.
9. Because cordless phones operate on electricity,
you should have at least one phone in your home
that isn’t cordless, in case the power in your
home goes out.
10.To avoid interference to nearby appliances, do
not place the base of the cordless phone on or
near a TV, microwave oven, refrigerator, or VCR.
Caution: To maintain compliance with the FCC’s RF
exposure guidelines, place the base unit at least 20
cm from nearby persons.

x
Industry Canada (IC)
Information
Industry Canada (IC) Information
This equipment meets the applicable Industry Canada (IC)
radio and terminal equipment technical specifications. This
is confirmed by the certification/registration number found
on the label on the bottom of the base unit. The
abbreviation IC before the certification/registration number
only signifies that registration was performed based on a
Declaration of Conformity and that the Industry Canada
technical specifications were met. It does not imply that
Industry Canada approved the equipment. The term “IC:”
before the certification/registration number only signifies
that the Industry Canada technical specifications were
met.
The Ringer Equivalency Number (REN) for this equipment
is located on the FCC/IC label on the telephone base unit.
The REN is useful in determining the maximum number of
devices you may connect to your telephone line and still
have all of these devices ring when your telephone
number is called. The sum of the RENs of all devices
connected to one line may not exceed 5.
Before installing this cordless phone, you should make sure
that it is permissible to be connected to the facilities of the
local telecommunications company. The equipment must be
installed using an acceptable method of connection. In some
cases, the telecommunications company’s inside wiring
associated with a single line individual service may be
extended by means of a certified connector assembly
(telephone extension cord). You should be aware that
compliance with the above conditions may not prevent
degradation of service in some situations.
The plug and jack used to connect this equipment to the
premises wiring and telephone network must comply with
the rules and requirements in Industry Canada’s CS-03. A
compliant telephone cord and modular plug is provided
with this product. It is designed to be connected to a
compatible modular jack that is also compliant.

xi
Industry Canada
(IC) Information
For your protection, ensure that the electrical ground
connections of the power utility, telephone lines, and
internal metallic water pipe system, if present, are
connected together. This precaution may be particularly
important in rural areas.
You should not attempt to make such connections
yourself. Contact the appropriate electrical inspection
authority or an electrician, as appropriate.If your home has
specially wired alarm equipment connected to the
telephone line, ensure the installation of this cordless
phone does not disable your alarm equipment. If you have
questions about what will disable alarm equipment, consult
your telephone company or a qualified installer.
Repairs
Repairs to this equipment should be made by an
authorized Canadian maintenance facility designated by
Motorola. Any repairs or alterations made by the
consumer, or any malfunctions of this equipment, may give
the telecommunications company cause to request that
you disconnect the equipment, and may void the limited
warranty.
Privacy
Privacy of communications may not be ensured when
using this telephone. Other devices, including other
cordless telephones, may interfere with the operation of
this cordless phone or cause noise during operation. Units
without code access may be accessed by other radio
communications devices.
Hearing Aid Compatibility
This telephone system meets Industry Canada standards
for hearing aid compatibility.
Interference Information
This device complies with Industry Canada’s RSS-210.
Operation is subject to the following two conditions:
(1) This device may not cause harmful interference; and

xii
Industry Canada (IC)
Information
(2) This device must accept any interference received,
including interference that may cause undesired operation.
This equipment has been tested and found to comply with
the limits for a Class B digital device, pursuant to Industry
Canada’s ICES-003. These limits are designed to provide
reasonable protection against harmful interference in a
residential installation.
This equipment generates, uses, and can radiate radio
frequency energy and, if not installed and used in
accordance with the instructions, may cause harmful
interference to radio communications. However, there is
no guarantee that interference will not occur in a particular
installation.
If this equipment does cause harmful interference to
radio or television reception, which can be
determined by turning the equipment on and off, the
user is encouraged to try to correct the interference
with one or more of the following measures:
•Reorient or relocate the receiving antenna (that is, the
antenna for radio or television that is “receiving” the
interference).
•Reorient or relocate and increase the separation
between the telecommunications equipment and the
receiving antenna.
•Connect the telecommunications equipment into an
outlet on a circuit different from that to which the
receiving antenna is connected.
If these measures do not eliminate the interference, please
consult your dealer or an experienced radio/television
technician for additional suggestions.
Industry Canada publishes several publications to assist
consumers with solving interference problems, which are
available from its offices or from its web site
(strategis.gc.ca).

1
Getting Started
Getting Started
Before you can use your new Motorola telephone to
make or receive calls, you must charge the batteries.
Battery Safety Instructions
• Do not burn, disassemble, mutilate, or puncture the
battery. The battery contains toxic materials that could
be released, resulting in injury.
• Caution: There is a risk of explosion if you replace
the battery with an incorrect battery type. Use only the
battery that came with your phone or an authorized
replacement recommended by the manufacturer.
• Keep batteries out of the reach of children.
• Remove batteries if storing over 30 days.
• Do not dispose of batteries in fire, which could result
in explosion.
• The rechargeable batteries that power this
product must be disposed of properly and may
need to be recycled. Refer to your battery’s
label for battery type. Contact your local recycling
center for proper disposal methods.

2
Getting Started
Charging the Battery
Your MD4150 series telephone comes with a Base
Unit, and a Stand Alone Charger. Use the Charger to
charge one of your two handsets. See “Installation”
on page 6 for step-by-step instructions on installing
the Base Unit.
1Remove any stickers if present.
2Press the indentation on the battery door and
slide downwards to remove.
3Insert the battery (bottom edge first) into the
battery compartment.

3
Getting Started
4Replace the battery door.
5Attach the Belt Clip (optional).
Note: For initial charge, please charge battery for at
least 12 hours.

4
Getting Started
6Plug the power cord into the bottom of the
Charger and into an electrical outlet.
7Place the handset in the Charger.
8Charge the battery for at least 12 hours before
using for the first time. The glowing LED light
indicates that the handset is charging.
Charge LED

5
Getting Started
Handset Overview
Use the at-a-glance image below to familiarize
yourself with the MD4150 series handset’s display
screen. See “Personalizing Your Handset” on page 7
for step-by-step instructions on setting preferences.
Main Display Screen
Note: Caller ID information is supplied only if you
subscribe to the service with your local telephone
company.
•If you subscribe to caller ID service, but INCOMING CALL
or No Data is displayed for all of your incoming calls,
contact your telephone company.
Muted
microphone
indicator
Speakerphone
indicator
New call
log entry
indicator
CID date
and time
information
Low battery
/
charging
indicator
Name
and number
display area
Muted
ringer
indicator

6
Installation
Installation
1 Select a location convenient to both an electrical
outlet and a telephone jack.
2 Insert the telephone cord and power cord into the
bottom of the Base Unit.
3 Place your second handset into the base unit to
charge. Do not plug the telephone cord into the wall
jack until the handset is fully charged (12 hours).
4 Plug the telephone cord into the telephone
wall jack.
5 Plug the power cord into the electrical outlet.
Note: Install the base unit away from electronic
equipment, such as computers, televisions, or
microwave ovens. Avoid excessive heat, cold, dust,
or moisture.
