Motorola ROKR E2 User manual

APPLICANT: MOTOROLA, INC.FCCID: IHDT56FC1
EXHIBIT 8
INSTRUCTION MANUAL
A preliminary draft copy of the Users Manual follows:

motorola.com
ROKR E2
GSM
C over.Print.Front.UG.landscape-ROKRE2.UG.fm Page 1 W ednesday,October26,2005 4:33 PM

C over.Print.Front.UG.landscape-ROKRE2.UG.fm Page 2 W ednesday,October26,2005 4:33 PM

1
HELLOMOTO
Introducing your new Motorola ROKR E2 GSM wireless phone. Here’s a quick anatomy lesson.
Scroll up, down, left, or right.
Press in to select.
Right Soft Key
Voice Key
Clear/Back Key
Microphone
Turn on & off, hang up, exit menus.
Left Soft Key
Volume Keys
Charge up or connect mini USB.
Play music.
Lock keypad.
Go handsfree.
Make & answer calls.

2
Main Menu
Options Back
Options Main Menu
Service Provider 10:15
Contacts
Settings
Web Access
Office Tools
Multimedia
Messages
Recent Calls
Browser
Help
Home Screen Main Menu
Press and hold the
Power Key u for a
few seconds or
until the display
lights up to turn on
your phone.
1
Press the Navigation
Key
up, down, left, or
right
( S ) to highlight
a menu feature.
3
Press the Navigation
Key
in ( s ) to select
it.
4
Press the Main Menu
soft key to open the
Main Menu .
2

3
Motorola, Inc.
Consumer Advocacy Office
1307 East Algonquin Road
Schaumburg, IL 60196
www.hellomoto.com
Certain mobile phone features are dependent on the capabilities
and settings of your service provider’s network. Additionally,
certain features may not be activated by your service provider,
and/or the provider's network settings may limit the feature’s
functionality. Always contact your service provider about feature
availability and functionality. All features, functionality, and other
product specifications, as well as the information contained in this
user's guide are based upon the latest available information and
are believed to be accurate at the time of printing. Motorola
reserves the right to change or modify any information or
specifications without notice or obligation.
MOTOROLA and the Stylized M Logo are registered in the US
Patent & Trademark Office. All other product or service names are
the property of their respective owners. The Bluetooth trademarks
are owned by their proprietor and used by Motorola, Inc. under
license. Java and all other Java-based marks are trademarks or
registered trademarks of Sun Microsystems, Inc. in the U.S. and
other countries.
© Motorola, Inc., 2006.
Caution: Changes or modifications made in the radio phone, not
expressly approved by Motorola, will void the user’s authority to
operate the equipment.
Manual Number:

4
contents
contents
menu map . . . . . . . . . . . . 6
Use and Care . . . . . . . . . . 8
essentials . . . . . . . . . . . . . 9
about this guide. . . . . . . 9
SIM card . . . . . . . . . . . 10
battery . . . . . . . . . . . . . 11
turn it on & off . . . . . . . 13
make a call. . . . . . . . . . 13
answer a call . . . . . . . . 13
store a phone number in
the contact list. . . . . . . 13
call a stored phone
number . . . . . . . . . . . . 14
your phone number . . . 14
main attractions . . . . . . 16
audio player . . . . . . . . . 16
FM radio . . . . . . . . . . . 21
airplane mode . . . . . . . 23
memory card . . . . . . . . 23
voice commands . . . . . 27
photos . . . . . . . . . . . . . 29
video clips . . . . . . . . . . 31
Bluetooth™ wireless . . 33
synchronize phone
information . . . . . . . . . 37
phone updates. . . . . . . 38
basics . . . . . . . . . . . . . . . 40
display . . . . . . . . . . . . . 40
text entry . . . . . . . . . . . 43
volume. . . . . . . . . . . . . 47
handsfree speaker. . . . 47
lock & unlock keypad . . 47
lock & unlock phone . . 48
codes & passwords. . . 48
customize. . . . . . . . . . . . 50
profiles. . . . . . . . . . . . . 50
time & date . . . . . . . . . 51
themes . . . . . . . . . . . . 51
display appearance . . . 53
answer options . . . . . . 53
calls. . . . . . . . . . . . . . . . . 55
turn off a call alert . . . . 55
recent calls . . . . . . . . . 55
redial . . . . . . . . . . . . . . 56
return a call . . . . . . . . . 56
notes . . . . . . . . . . . . . . 57
hold or mute a call . . . . 57
call waiting. . . . . . . . . . 57
caller ID . . . . . . . . . . . . 58
emergency calls . . . . . 58
international calls . . . . . 59

contents
5
speed dial . . . . . . . . . . 59
voicemail . . . . . . . . . . 59
other features . . . . . . . . 60
advanced calling . . . . . 60
contacts . . . . . . . . . . . 63
messages . . . . . . . . . . 68
personalize . . . . . . . . . 70
call times & costs . . . . 73
handsfree . . . . . . . . . . . 74
data & fax calls . . . . . . 75
network . . . . . . . . . . . 76
personal organizer . . . 76
security. . . . . . . . . . . . 80
fun & games. . . . . . . . 80
service and repairs . . . . 83
SAR Data. . . . . . . . . . . . 84
SAR Data. . . . . . . . . . . . 86
EU Conformance . . . . . 87
GNU License . . . . . . . . . 88
Safety Information . . . . 90
Warranty (except Mexico)
. . . . . . . . . . . . . . . . . . . . 95
Warranty (Mexico) . . . . 99
index . . . . . . . . . . . . . . 101

6
menu map
menu map
<=0>
main menu
n Contacts
e Messages
• Create Message
• Inbox
• My Folders
• Templates
•Drafts
• Outbox
•Email
• Call Voicemail
É Office Tools
• Calendar
•Email
•MOTOSYNC
• Download Manager
• File Manager
•AlarmClock
• World Clock
• SIM Applications *
•Calculator
• Dialing Services
• Fixed Dial
• Service Dial *
•TaskList
• Notes
h Multimedia
• Media Finder
•Games
•Camera
• Video Camera
• Voice Recorder
•FMRadio
V Browser
s Recent Calls
Tip: Press # to change the main menu to
a list view and back. For feature help,
select
1Help in the main menu.
á Web Access
•Browser
•MyBookmarks
• My Web Pages
•History
• Go To Page
•BrowserSetup
w Settings
• (see next page)
1 Help
This is the standard main menu layout.
Your phone’s menu may be different.
* optional features

menu map
7
settings menu
•Profiles
•Normal
• Vibrate
• Silent
• Meeting
• Airplane Mode
• Sleeping
•Active
•Car
•Themes
• Connections
• Bluetooth™™
• Modem
• USB Settings
• Data Connections
• Call Settings
• Speed Dial
•CallForward
• In-Call Setup
• My Caller ID
• Call Waiting
• In-Call Message Alert
• Active Line
• In-Call Timer
• Answer Options
• Auto Redial
•RoamAlert
•DTMF
• Call Barring
• Fixed Dialing
• Call Drop Tone
• My SIM Number
• Phone Settings
• Display Settings
• Backlight Timeout
• Display Timeout
• Screensaver Timeout
• Brightness
• Battery Meter
• Battery Save
•Time&Date
• Language
• Talking Phone
•TextEntry
• Reset
• Reset All Settings
• Delete All Data
• Properties
• Java™ System
• Software Update
• Headset Settings
• Auto-Answer
• Voice Dial
• TTY Settings *
•Security
• Phone Lock
• Application Lock
•SIMPINLock
• Change Passwords
•Network
• Current Network
• Scan Available Networks
• Search For New Network
• My Network List
• Search Setup
• Service Tone
Tip: You can press number keys to select
options that have numbers next to them.
This is the standard main menu layout.
Your phone’s menu may be different.
* optional features

8
Use and Care
Use and Care
Use and Care <=0>
To care for your Motorola phone, please keep it away from:
liquids of any kind dust and dirt
Don’t expose your phone to water, rain,
extreme humidity, sweat, or other moisture.
Don’t expose your phone to dust, dirt, sand,
food, or other inappropriate materials.
extreme heat or cold cleaning solutions
Avoid temperatures below -10°C/14°F or
above 45°C/113°F.
To clean your phone, use only a dry soft cloth.
Don’t use alcohol or other cleaning solutions.
microwaves the ground
Don’t try to dry your phone in a microwave
oven.
Don’t drop your phone.

9
essentials
essentials
about this guide
This guide shows how to locate a menu
feature as follows:
Find it: Press Main Menu > ÉOffice Tools
>
Calculator
This example shows that, from the home
screen, you press the
Main Menu soft key to
open the menu, scroll to and select
ÉOffice Tools , then scroll to and select Calculator .
Press the navigation key up, down, left, or
right
S to scroll to a menu feature. Press the
navigation key in
s to select the highlighted
menu feature.
<=0>
CAUTION: Before using the
phone for the first time, read the
Important Safety and Legal
Information
included in the gray-
edged pages at the back of this
guide.
symbols
This means a feature is
network/subscription dependent
and may not be available in all areas.
Contact your service provider for
more information.

10
essentials
SIM card
Caution: Don’t bend or scratch your SIM card.
Keep it away from static electricity, water, and
dirt.
Your Subscriber Identity Module (SIM) card
contains personal information like your phone
number and phonebook entries. It can also
contain your voicemail, text message, and
Internet access settings. If you put your SIM
card in another phone, that phone uses your
phone number.
Insert the SIM card with the gold plate facing
down and the notch in the upper right corner
as shown:
<=0>
This means a feature requires an
optional accessory.
symbols
12

11
essentials
battery
battery installation
<=0>
battery charging
New batteries are
not fully charged.
Plug the battery
charger into your
phone and an
electrical outlet.
Your phone might
take several
seconds to start charging the battery. Your
display shows
Charge Complete when finished.
Tip: Relax, you can’t overcharge your battery.
It will perform best after you fully charge and
discharge it a few times.
Note: You can charge your battery
by connecting a cable from your
phone's mini-USB port to a USB
port on a computer. Both your
phone and the computer must be turned on,
and your computer must have the correct
1 Pull the release
button down
and hold it there
while you lift up
the battery
door.
23

12
essentials
software drivers installed. Cables and
software drivers are available in
Motorola Original data kits, sold separately.
battery tips
Battery life depends on the network, signal
strength, temperature, features, and
accessories you use.
• Always use
Motorola Original batteries
and chargers. The warranty
does not cover damage
caused by non-Motorola batteries
and/or chargers.
• New batteries or batteries stored for a
long time may take more time to
charge.
• When charging your battery, keep it
near room temperature.
• When storing your battery, keep it
uncharged in a cool, dark, dry place,
such as a refrigerator.
• Never expose batteries to
temperatures below -10°C (14°F) or
above 45°C (113°F). Always take your
phone with you when you leave your
vehicle.
• It is normal for batteries to gradually
wear down and require longer charging
times. If you notice a change in your
battery life, it is probably time to
purchase a new battery.
Contact your local recycling center for
proper battery disposal.
Warning: Never dispose of batteries in a fire
because they may explode.
Before using your phone, read the battery
safety information in the “Safety and General

13
essentials
Information” section included in the
gray-edged pages at the back of this guide.
turn it on & off
Caution: Some phones ask for your SIM card
PIN code when you turn them on. If you enter
an incorrect PIN code three times before the
correct code, your SIM card is disabled, and
your display shows
SIM Blocked . Contact your
service provider.
To turn on your phone,
press and hold
O for
a few seconds or until
the display lights up. If
prompted, enter your four-digit SIM card PIN
code and/or four-digit unlock code.
To turn off your phone, press and hold
O for
two seconds.
make a call
Enter a phone number and press N to make
a call.
To “hang up,” press
O .
answer a call
When your phone rings and/or vibrates, just
press
N to answer.
To “hang up,” press
O .
store a phone number
in the contact list
You can store a phone number in your Contacts
list.
Note: You can store a contact in phone
memory or on your SIM card. You can’t set a

14
essentials
picture ID or special alerts for contacts stored
on the SIM card. To change your default save
location to phone, SIM card, or both, see
page 63.
1 Enter a phone number in the home
screen.
2 Press the Save key.
3 Enter a name for the phone number, and
specify the number type if necessary. To
select a highlighted item, press the
navigation key in
s
4 Press the Save key to store the contact.
To edit or store additional information about
the contact, see page 64. To delete a contact,
see page 67.
call a stored phone
number
Find it: Press the Main Menu key > nContacts
1 Scroll to the contact.
Shortcut: In the contact list, press keypad
keys to enter the first letters of the
contact you want. Press the
navigation key in
s to go to the contact.
2 Press N to call the contact.
your phone number
To see your phone number from the home
screen, press the
Main Menu key > wSettings
>
Call Settings > My SIM Number .
To see your phone number while you’re on a
call, press the
Options key > My Telephone Number .

15
essentials
To store or edit your name and phone number
on your SIM card, select the field you want to
edit. If you don’t know your phone number,
contact your service provider.

16
main attractions
main attractions
You can do much more with your phone than
make and receive calls!
audio player
load music files on your
computer
To load music on your phone, you need to
have a digital music library on your computer.
Here is how to create a digital music library on
your computer:
1 Insert a music CD in your computer's CD
drive.
2 Launch your computer's music player
program (such as Windows® Media
Player).
3 Copy the music CD to your media player
program's library (also called ripping the
CD).
If your computer is connected to the Internet
when you insert your music CD, the music
player program may retrieve data about the
Album such as Song Titles, Album name,
Artist name, and Album art work. This data
can be edited or entered manually by using
your computer's music player application. This
data will be displayed in your phone’s audio
player.

17
main attractions
load music files on your phone
To transfer your music from your computer’s
digital music library to your phone and its
SD memory card, see page 25. To download
songs from the Web, see page 81. For a list of
the file formats your phone can play, see
page 26.
Note: Your SD memory card is formatted with
FAT16 and has limits on how many
files/folders you can store at the top level. We
recommend that you create a folder on your
SD card and then store your files inside that
folder.
play music files
Your phone can play and store audio
files (for a list of formats, see page 26).
You can use a removable SD memory card
with your phone to store more songs (see
page 23).
Note: You can use any stereo
headset with a 3.5 mm plug. For
best performance, use a
Motorola Original headset or a
headset with an impedance rating between
16-32 ohm.
Find it: Press f . Then, press S up or down
to scroll to an option, and press the
navigation key in
s to select the option:
<=0>
options
All Show and play individual songs.
Note: All of your phone’s songs
appear in the
All list. Some songs
may not have any
Artist , Album , or
Genre information stored, so they
don’t appear in those lists.
Playlists Create or play a playlist of songs
(see page 20).
