Motorola RS507 Series User manual

RS507 Hands-Free Imager
Quick Reference Guide
QRG_507.fm Page 1 Wednesday, January 28, 2009 8:37 PM

2 RS507 Hands-Free Imager
©2009 MOTOROLA, INC. All rights reserved.
Motorola reserves the right to make changes to any product to improve reliability,
function, or design.
Motorola does not assume any product liability arising out of, or in connection
with, the application or use of any product, circuit, or application described herein.
No license is granted, either expressly or by implication, estoppel, or otherwise
under any patent right or patent, covering or relating to any combination, system,
apparatus, machine, material, method, or process in which Motorola products
might be used. An implied license exists only for equipment, circuits, and
subsystems contained in Motorola products.
MOTOROLA and the Stylized M Logo are registered trademarks of Motorola, Inc.
Other product names mentioned in this manual may be trademarks or registered
trademarks of their respective companies and are hereby acknowledged.
Motorola, Inc.
One Motorola Plaza
Holtsville, N.Y. 11742-1300
www.motorola.com/enterprisemobility.
Warranty
For the complete Motorola hardware product warranty statement, go to:
www.motorola.com/enterprisemobility/warranty.
Patents
This product is covered by one or more patents. For patent information go to:
www.motorola.com/enterprisemobility/patents.
QRG_507.fm Page 2 Wednesday, January 28, 2009 8:37 PM

Quick Reference Guide 3
Introduction
The RS507 Hands-Free Imager (also referred to as Imager) is wearable barcode
scan solution for both 1D and 2D barcode symbologies. The Imager is also
compatible with a wide range of mobile computers communicating over Bluetooth.
The Imager is designed for a wide range of applications from management of
products in a warehouse, processing deliveries at a courier facility, hospitality to
scanning lift tickets at a ski resort.
The Imager uses camera-based scanning technology, designed to offer flexible
hands-free operation with ergonomic comfort for right or left hand users.
The Imager can be operated in both manual and auto-triggering modes.
Auto-triggering is a patented Intelligent Sensing Technology combining motion
and proximity sensing for triggering the Imager.
The Imager durability is built to last and rated for indoor and outdoor daily use in
intensive scan environments. Built on magnesium chassis, the Imager offers
durability associated with the most rugged mobile computers.
About this Guide
This guide provides basic information on the following topics:
•Cordless Configuration Features on page 5
•Change Trigger Position on page 7
•Getting Started - Cordless Configuration on page 8
•Getting Started - Corded Configuration on page 9
•Establish Bluetooth Connection on page 11
•Scan on page 13
•Status Indications on page 11
•Troubleshooting on page 16
•Resetting the Imager on page 17
•Field Replaceable Parts on page 18
•Cleaning on page 21
•Ergonomic Recommendations on page 24
•Regulatory Information on page 23
•Waste Electrical and Electronic Equipment (WEEE) on page 34
For more information, refer to the RS507 Hands-Free Imager Product Reference
Guide, p/n 72-120802-01 available at:
www.motorola.com/enterprisemobility/manuals.
QRG_507.fm Page 3 Wednesday, January 28, 2009 8:37 PM

4 RS507 Hands-Free Imager
Unpacking the Imager
After opening the shipping box, inspect the contents. You should have received
the following:
Inspect the equipment for damage. If you are missing any equipment or if you find
any damaged equipment, contact Motorola Enterprise Mobility Support
immediately. See Service Information on backcover for contact information.
Model Description RS507 Standard
Battery Extended Battery Corded Adapter Quick Start Guide
RS507-IM200000STWR
Triggered RS507
with standard
battery
RS507-IM200000SNWR Triggerless RS507
with standard
battery
RS507-IM200000ENWE Triggerless RS507
with extended
battery
RS507-IM200000CTWR Corded and
Triggered RS507
QRG_507.fm Page 4 Wednesday, January 28, 2009 8:37 PM

Quick Reference Guide 5
Cordless Configuration Features
Imager Window
Battery
Battery Release Latch
Fingers Strap Scan Trigger
Strap Buckle
Beeper
Restore Key
Left Scan LED
Strap
Right Scan LED
Comfort Pad
Trigger Assembly
NOTE When the imager is provided as triggerless configuration, the
auto-triggering mode is enabled by default.
Asset Control Label
QRG_507.fm Page 5 Wednesday, January 28, 2009 8:37 PM

6 RS507 Hands-Free Imager
Corded Configuration Features
Release Latch
Imager Window
Fingers Strap Scan Trigger
Comfort Pad
Corded Adapter
Strap Buckle
Beeper
Restore Key
Left Scan LED Strap
Right Scan LED
Trigger Assembly
Interface Cable Connector to WT4090
Asset Control Label
QRG_507.fm Page 6 Wednesday, January 28, 2009 8:37 PM

Quick Reference Guide 7
Change Trigger Position
The Trigger Assembly of the Imager rotates to provide left-hand or right-hand use.
1. Remove the Fingers Strap from the Strap Buckle.
2. From bottom of Imager, Hold and pull the Comfort Pad out of the Barcode
Imager.
3. Determine whether the Imager is used on the right or left hand and rotate the
Trigger Assembly.
4. Rotate the Trigger Assembly so that the Scan Trigger is positioned next to the
thumb when the Imager is placed on the index and middle fingers.
5. Position the Comfort Pad onto the Imager.
6. Press the Comfort Pad onto the Imager. When properly installed, the Comfort
Pad “locks” into place.
7. Insert the Fingers Strap into the Strap Buckle
CAUTION The Trigger Assembly only rotates 180° around the back of the
scan assembly. Do not rotate the Trigger Assembly past the
designed stops
Fingers Strap
Strap Buckle
Comfort Pad
Trigger
Assembly
Trigger Assembly
QRG_507.fm Page 7 Wednesday, January 28, 2009 8:37 PM

8 RS507 Hands-Free Imager
Getting Started - Cordless Configuration
Before using the Imager, charge the battery. The 8-Bay Battery Charger supports
both standard and extended capacity batteries.
Charge the Battery
To charge the Imager battery, refer to SAC5070 Quick Start Guide.
Install the Battery
1. Align the Battery on top of the Imager.
2. Push the battery all the way into the
Locking Slots of the Imager.
3. Firmly press the Battery into the Imager
until a “click” is heard ensuring the
Battery Release Latch is fully engaged
with the Imager.
Remove the Battery
1. Hold the Imager in one hand.
2. Press the Battery Release Latch.
3. Pull up the Battery to release from the Locking Slots of the Imager.
Wear the Imager
1. Slide the Imager onto the index and middle fingers with the Scan Trigger next
to the thumb.
Locking Slots
Battery
Battery Release
Latch
Scan Trigger
QRG_507.fm Page 8 Wednesday, January 28, 2009 8:37 PM

Quick Reference Guide 9
2. Tighten the Fingers Strap.
Getting Started - Corded Configuration
In order to start using the Imager you must install the Corded Adapter.
Connect Corded Adapter
1. Align the Corded Adapter on top of the
Imager.
2. Push the Corded Adapter all the way
into the Locking Slots of the Imager.
3. Firmly press the Corded Adapter into the
Imager until a “click” is heard ensuring
the Adapter Release Latch is fully
engaged with the Imager.
Remove the Corded Adapter
1. Hold the Imager in one hand.
2. Press the Adapter Release Latch.
3. Pull up the Corded Adapter to release
from the Locking Slots of the Imager.
aaaaaaaaaaaaaaaa
aaaaaaaaaaaaaaaa
aaaaaaaaaaaaaaaa
aaaaaaaaaaaaaaaa
aaaaaaaaaaaaaaaa
aaaaaaaaaaaaaaaa
aaaaaaaaaaaaaaaa
aaaaaaaaaaaaaaaa
aaaaaaaaaaaaaaaa
aaaaaaaaaaaaaaaa
aaaaaaaaaaaaaaaa
aaaaaaaaaaaaaaaa
aaaaaaaaaaaaaaaa
aaaaaaaaaaaaaaaa
aaaaaaaaaaaaaaaa
aaaaaaaaaaaaaaaa
aaaaaaaaaaaaaaaa
Fingers
Strap
Locking Slots
Adapter Release
Latch Corded
Adapter
QRG_507.fm Page 9 Wednesday, January 28, 2009 8:37 PM

10 RS507 Hands-Free Imager
Connect to a Wearable Terminal
The Imager connects to the
WT4090 and mounts on the fingers.
1. On the WT4090, remove the
connector cover.
2. Connect the Imager Interface
Cable Connector to the WT4090
Interface Connector.
Wear the Imager
1. Slide the Imager onto the index
and middle fingers with the Scan
Trigger next to the thumb.
2. Tighten the Fingers Strap.
Interface Cable
Connector
WT4090 Interface
Connector
Scan Trigger
aaaaaaaaaaaaaaaaaa
aaaaaaaaaaaaaaaaaa
aaaaaaaaaaaaaaaaaa
aaaaaaaaaaaaaaaaaa
aaaaaaaaaaaaaaaaaa
aaaaaaaaaaaaaaaaaa
aaaaaaaaaaaaaaaaaa
aaaaaaaaaaaaaaaaaa
aaaaaaaaaaaaaaaaaa
aaaaaaaaaaaaaaaaaa
aaaaaaaaaaaaaaaaaa
aaaaaaaaaaaaaaaaaa
aaaaaaaaaaaaaaaaaa
aaaaaaaaaaaaaaaaaa
aaaaaaaaaaaaaaaaaa
aaaaaaaaaaaaaaaaaa
aaaaaaaaaaaaaaaaaa
4t×Q
Fingers
Strap
QRG_507.fm Page 10 Wednesday, January 28, 2009 8:37 PM

Quick Reference Guide 11
Status Indications
The Imager has two Scan LEDs that provide identical indications. The Imager is
also equipped with a beeper that generates sound indications in variable tones.
NOTE In corded adapter configuration, beep indications are emitted only from the
WT4090.
Bluetooth Connection
Establish Bluetooth Connection
To establish Bluetooth connection with a mobile computer:
1. Ensure that the Imager is within a range of 10 meters (30 feet) from the mobile
computer.
2. Install the battery on the Imager.
No. LED Beep Indication Description
1. None High/low Bluetooth communication is
disconnected
2. Short green
flashes None Attempting to connect over Bluetooth
3. None Low/high Imager is connected over
Bluetooth
4. None High/low Bluetooth communication is
disconnected - Imager is out of
range
5. None high/low/high/low Properly decoded scan of
Bluetooth pairing Barcode
6. None Long low/
long high/ Bluetooth connection attempt failed
7. None Long low/
long high/
Long low/
long high/
Bluetooth connection attempt is
rejected
8. One green
flash High Proper scanning indication
9. None 4 long beeps No Bluetooth communication after
scanning time-out
QRG_507.fm Page 11 Wednesday, January 28, 2009 8:37 PM

12 RS507 Hands-Free Imager
3. Launch the Bluetooth Device (BD) Address application on the mobile
computer. Most BD Address applications display a pairing barcode image on
the screen of the mobile computer.
4. Scan a pairing barcode form the mobile computer screen or any provided label.
When scanning, the Imager emits one string of high/low/high/low beeps.
5. The Scan LED starts flashing green indicating that the Imager is attempting to
establish connection with a mobile computer.
6. When connection is established, the Scan LED turns Off and the Imager emits
one string of low/high beeps. The Imager is connected and ready for scanning.
NOTE When replacing the Imager battery, the Imager memory retains the pairing
information of last paired mobile computer (e.g WT4090).
Remove Bluetooth Connection
1. Scan an unpairing barcode label with the Bluetooth address for disconnecting
the Imager from the mobile computer (e.g WT4090).
2. The Imager emits one string of high/low beeps indicating that Bluetooth
communication with the mobile computer is disconnected.
Restore Lost Bluetooth Connection
The Imager maintains Bluetooth communication with a mobile computer within a
range of 10 meters (30 feet). When the Imager fails to establish connection or
connection is lost during operation, the Imager emits one string of low/high beeps.
To reestablish Bluetooth connection with a mobile computer (e.g WT4090):
1. Ensure that the Imager is within a range of 10 meters (30 feet) from the mobile
computer.
2. Ensure that the mobile computer is On and “awake” (not in Suspend mode).
3. The Imager automatically attempts reconnecting to the mobile computer for 30
seconds (Scan LED flashes green). If automatic re-connection fails, verify that
the Imager is within Bluetooth range and briefly press the Restore Key on the
Imager to reconnect.
4. The Scan LED starts flashing green indicating that the Imager is attempting to
establish connection with a mobile computer (e.g WT4090).
5. The Scan LED turns Off and the Imager emits one string of low/high beeps
indicating that the Imager is connected and ready for scanning.
QRG_507.fm Page 12 Wednesday, January 28, 2009 8:37 PM

Quick Reference Guide 13
Scan
The Imager uses digital camera technology to take a picture of a barcode and
software decoding algorithms are executed to extract the barcode data from the
image.
Scan Triggering Modes
Manual Triggering (Triggered models only)
1. Launch a scanning software application on the mobile computer or WT4090.
2. Press the Scan Trigger and position the aiming cross hair laser to cover the
barcode. The Imager takes a digital picture (image) of the barcode and stores it
in memory for decoding.
3. One green flash and a high beep sounds to indicate that the barcode was
properly decoded.
NOTE In some configurations proper decoding of a barcode is indicated by
software application running on mobile computer or WT4090.
Auto-triggering (Triggered models only)
The Imager is provided with auto-triggering capability.
In auto-triggering mode, both motion and proximity sensors are used to trigger the
Imager when the user intends to scan a barcode.
With auto-triggering activated, the Imager automatically scans when motion stops
and a barcode is placed within the depth of field of the Imager. The Imager scans
the barcode and turns off to conserve power.
To scan barcode in auto-triggering mode:
1. Bring the Imager within 9 inches ± 1 inch (22.86 cm ± 2.54 cm) of a barcode
label.
2. Hold the Imager steady, aiming at the barcode label.
3. The Imager takes a picture (image) of the barcode and stores it in memory for
decoding.
4. One green flash of the Scan LED and a high beep indicates that a barcode was
properly decoded.
NOTE In some configurations, proper decoding of a barcode is indicated by a
software application running on mobile computer or WT4090.
QRG_507.fm Page 13 Wednesday, January 28, 2009 8:37 PM

14 RS507 Hands-Free Imager
Aiming the Imager
The aimer of the Imager is a cross hair laser with bright center dot (shown below).
The virtual rectangle made by the Cross Hair Lines reflects the field of view of the
Imager. The aimer is used to position the barcode or object within the field of view.
1. Enter the symbol in any orientation within the virtual rectangle made by the
cross hair lines.
The imager can also read a barcode presented within the aiming pattern but
not centered, such as the figure below on the left. The figure on the right,
however, may not be decoded.
The aiming pattern is smaller when the Imager is closer to the symbol and
larger when it is farther from the symbol. Scan symbols with smaller bars or
elements (mil size) closer to the unit and those with larger bars or elements
(mil size) farther from the unit.
2. Hold the Imager between two and eleven inches (depending on symbol
density) from the symbol, centering the aiming pattern cross hairs on the
symbol.
3. Press the Scan Button. The aimer pattern illuminates red indicating that the
Laser is on. One green flash of the Scan LED and a high beep indicates that a
barcode was properly decoded.
Virtual rectangle made by the
Cross Hair Lines
Cross Hair Lines of
Imager Aimer
PDF417 Symbol
Linear Barcode
Symbol
Aimer Pattern
@1234@
@1234@ @1234@
Wrong
Right
QRG_507.fm Page 14 Wednesday, January 28, 2009 8:37 PM

Quick Reference Guide 15
Customize the Imager Behavior
The Imager behavior can be configured by scanning custom barcode tables. The
following table provides examples of configurable Imager features.
Feature Description Default Setting
Beep on
reconnection
attempt
When this parameter is enabled, the
Imager emits a low/high beep when
Bluetooth link is reconnected.
The beep on
reconnection
attempt feature is
disabled by default.
Motion
sensing When this parameter is enabled, the Imager automatically scans when motion
stops in front of the Imager and a barcode
is placed within the depth of field of the
Imager.
Motion sensing is
set by default to on
for triggerless
models and off for
triggered models.
Proximity
sensing When this parameter is enabled, the Imager automatically scans when sensing
proximity to an object and a barcode is
placed within the depth of field of the
Imager.
Proximity sensing is
set by default to on
for trigger less
models and off for
triggered models.
Proximity
distance When using proximity sensing, you can set proximity distance to Short, Mid or Long. Proximity distance is set to Long by
default.
Low battery
indication When this parameter is enabled, the Imager flashes red every 15 seconds when
battery power is low.
Low battery
indication is
disabled by default.
Bluetooth
auto connect The Imager automatically tries to reconnect to a remote device when a disconnection
occurs that is due to the radio losing
communication. This can happen if the
Imager goes out of the mobile computer
range.
The following auto connect options are
available: “None”, “On power up”, “Back in
Bluetooth range”, “On power up & back in
Bluetooth range”.
Bluetooth auto
connect is set to
“Back in Bluetooth
range” by default.
QRG_507.fm Page 15 Wednesday, January 28, 2009 8:37 PM

16 RS507 Hands-Free Imager
Troubleshooting
Problem Cause Solution
Laser aimer does
not display when
pressing the Scan
Trigger
Corded: Interface
cable is not secure
Cordless: Battery is
not charged
Verify that the interface cable is
properly connected
Replace or charge battery
Power is not applied
to Imager
Corded: Verify that the mobile
computer (e.g WT4090) has a
charged battery installed
Cordless: Replace or Charge Imager
battery
Scan application on
the mobile computer
(e.g WT4090) is not
functioning
Restart the scanning application on
the mobile computer (e.g WT4090)
Imager software
does not respond Reset the Imager (See Resetting the Imager on page 17)
Imager does not
decode a barcode Barcode is unreadable Verify that the barcode is not defective, i.e., smudged or broken
Exit window is dirty Clean exit window with a lens tissue.
Tissues for eyeglasses work well. Do
not use tissues coated with lotion
Barcode symbology
is not supported or
enabled
See your system administrator
Cordless: Bluetooth
link is disconnected Reestablish Bluetooth connection (See Establish Bluetooth Connection
on page 11)
QRG_507.fm Page 16 Wednesday, January 28, 2009 8:37 PM

Quick Reference Guide 17
Resetting the Imager
If the Imager stops responding to input, reset it. There are two reset functions,
warm boot and cold boot. Perform a warm boot first. If the Imager still does not
respond, perform a cold boot.
Warm Boot
To perform warm boot, press and hold the Restore Key for more than six seconds.
Cold Boot
Cold boot restores the Imager’s operation by resetting it’s software. To perform
cold boot, remove and re-insert the battery into the Imager. When using a corded
RS507 model with WT4090, remove and reconnect the interface cable that
connects between the Imager and the WT4090.
QRG_507.fm Page 17 Wednesday, January 28, 2009 8:37 PM

18 RS507 Hands-Free Imager
Field Replaceable Parts
Part Description
1 CLMPT-RS507-R Trigger Assembly
2 KT-BKL-RS507-R Set of 10 Strap Buckles
3 CLMPN-RS507-R Triggerless Fingers Clamp
4 KT-PAD-RS507-R Set of 10 Comfort Pads
5 KT-STRPN-RS507-R Set of 10 Triggerless Fingers Strap with Fingers
Support
6 KT-STRPT-RS507-R Set of 10 Trigger Fingers Strap with Fingers
Support
7 BTRY-RS50EAB00-01 Standard Battery
8 BTRY-RS50EAB02-01 Extended Battery
9 ADPTRWT -RS507-R Corded Adapter
a
1
2
34
56
78
9
Fingers
Support
QRG_507.fm Page 18 Wednesday, January 28, 2009 8:37 PM

Quick Reference Guide 19
Comfort Pad Replacement
Removal
Hold and pull Comfort Pad out of the Barcode Imager.
Installation
1. Position the Comfort Pad onto the Imager as
shown.
2. Press the Comfort Pad onto the Imager. When
properly installed, the Comfort Pad “locks” into
place.
Trigger Assembly Replacement
Removal
1. Turn the Imager upside-down.
2. Remove the Comfort Pad.
3. Rotate the Trigger Assembly to
align with the back of the Imager.
4. Use a paper clip or similar object to
press the Release Latch.
5. Lift the Trigger Assembly off the
scan assembly.
Installation
1. Turn the Imager upside-down.
2. Position the Trigger Assembly to
align with the back of the Imager.
3. Lower the Trigger Assembly to
the scan assembly.
4. Rotate Trigger Assembly 1/4 turn
counterclockwise.
5. Press the Comfort Pad onto the
Imager. When properly installed,
the Comfort Pad “locks” into
place.
1
2
3
Release Latch
Imager Back
1
Triggerless
Finger Clamp
2
QRG_507.fm Page 19 Wednesday, January 28, 2009 8:37 PM

20 RS507 Hands-Free Imager
Note: An optional Triggerless Finger Clamp should be installed when the
Imager is intended to be used in Motion and Proximity Initiated Barcode Read
mode.
Fingers Strap Replacement (Trigger Assembly)
Removal
1. Remove the Fingers Strap from the
Strap Buckle.
2. Pull the Fingers Strap out of the
Trigger Assembly.
Installation
1. Align a new Finger Strap with the
Slots in the Trigger Assembly.
2. Gently press the Strap Pins to
engage with the Slots of the Trigger
Assembly. The Strap Pins snap into
the Slots.
3. Slip the Fingers Strap through the
Strap Buckle.
Strap Pins
Slots
Strap Buckle
Fingers Strap
Trigger Assembl
y
QRG_507.fm Page 20 Wednesday, January 28, 2009 8:37 PM
