Motorola 2 Way FRS Radio User manual

RADIO
2-WAY FRS
6881041B05-A
User’s Guide
020317-A

6881041B05a.book Page 2 Friday, July 12, 2002 1:22 PM

N
2-Way Radio Quick Reference
Lower sound
Move down through options
for each radio setting
Move through different
radio settings
Lock/unlock keypad (when
held down in Standby mode)
Send call tone
Turn radio on and off
Display
Raise sound
Move up through options for
each radio setting
Ta l k
Save radio settings
Monitor channel activity
Microphone
Speaker
Disney/Pixar Elements © Disney/Pixar
QR.fm Page 1 Thursday, May 9, 2002 8:48 AM

Call Tone
Settings: 1 through 5
Interference
Eliminator Code
Settings: 0 through 38
Channel
Settings: 1 through 14
Talk Confirmation
Tone
Settings: M (On), L (Off)
Keypress Alert Tone
Settings: M (On), L (Off)
1
21
1
1
N
Changing Radio Settings
Press Gto move through radio settings.
Press Band Cto move through options for each radio setting.
Press Ato save radio settings.
Disney/Pixar Elements © Disney/Pixar
QR.fm Page 2 Thursday, May 9, 2002 8:48 AM

Introduction
Introduction
Disney Motorola 2-way radios operate on Family Radio Service (FRS) frequencies.
This license-free, 2-way radio service is for family and group recreational use. Use
of this radio outside the country where it was intended to be distributed is subject to
government regulations and may be prohibited. Read this manual carefully and
make sure you know how to properly operate radio before use.
For a copy of a large-print version of this guide, or for product-
related questions, contact:
1-800-353-2729 U.S.A.
1-800-461-4575 Canada
1-888-390-6456 TTY (Text Telephone)
On the web, refer to: www.motorola.com/talkabout
Congratulations on your purchase of a Motorola 2-way radio!
Product registration is an important step toward enjoying your new Motorola radio.
Registering helps us with warranty service, and permits us to contact you should
your Motorola 2-way radio require an update or other service. Registration is not
required for warranty coverage. To register your product on-line, visit
www.motorola.com/warranty/radios.
Retain your original dated sales receipt for your records. For warranty service of
your Motorola 2-way radio you will need to provide a copy of your dated sales receipt
to confirm warranty status.
6881041B05a.book Page 3 Friday, July 12, 2002 1:22 PM

Contents
Introduction . . . . . . . . . . . . . . . . . . . . . . . . .
Safety and General Information . . . . . . . . 1
Getting Started . . . . . . . . . . . . . . . . . . . . . . 9
Turning On Your Radio . . . . . . . . . . . . . . . 9
Sharing Radio Channels . . . . . . . . . . . . . .9
Parts of Your Radio . . . . . . . . . . . . . . . . . 10
What is on Your Display . . . . . . . . . . . . . 11
Installing Batteries . . . . . . . . . . . . . . . . . .12
Talking and Listening . . . . . . . . . . . . . . . 13
Talk Range . . . . . . . . . . . . . . . . . . . . . . . 13
Making Radio Sound Quieter or Louder .14
Sending Call Tones . . . . . . . . . . . . . . . .14
Changing Call Tones . . . . . . . . . . . . . . .15
Changing Channels . . . . . . . . . . . . . . . . 16
Changing Interference Eliminator Code .17
Listening to a Channel . . . . . . . . . . . . . .18
Time-Out Timer . . . . . . . . . . . . . . . . . . . .18
Locking the Keypad . . . . . . . . . . . . . . . . .19
Alerts . . . . . . . . . . . . . . . . . . . . . . . . . . . . .20
Talk Confirmation Tone . . . . . . . . . . . . . .20
Keypress Alert Tone . . . . . . . . . . . . . . . .21
Fixing Problems . . . . . . . . . . . . . . . . . . . .23
Use and Care . . . . . . . . . . . . . . . . . . . . . .25
Limited Warranty . . . . . . . . . . . . . . . . . . .27
FCC License Not Required . . . . . . . . . . .34
Software Copyright Notice . . . . . . . . . . .34
Export Law Assurances . . . . . . . . . . . . .35
6881041B05a.book Page 4 Friday, July 12, 2002 1:22 PM

Safety and General Information
1
SAFETY AND GENERAL INFORMATION
IMPORTANT INFORMATION ON SAFE AND EFFICIENT OPERATION
READ THIS INFORMATION BEFORE USING YOUR RADIO
The information provided in this document supersedes the general safety
information contained in user guides published prior to July 2000.
This device complies with Part 15 of the FCC Rules. Operation is subject to the
following two conditions: (1) this device may not cause harmful interference, and (2)
this device must accept any interference received, including interference that may
cause undesired operation.
Transmit and Receive Procedure
Your two-way radio contains a transmitter and a receiver. To transmit (talk), you must
push the Talk button; to receive (listen), release the Talk button.
Exposure To Radio Frequency Energy
Your Motorola radio is designed to comply with the following national and
international standards and guidelines regarding exposure of human beings to radio
frequency electromagnetic energy:
• United States Federal Communications Commission, Code of Federal
Regulations; 47 CFR part 2 sub-part J
6881041B05a.book Page 1 Friday, July 12, 2002 1:22 PM

Safety and General Information
2
• American National Standards Institute (ANSI) / Institute of Electrical and
Electronic Engineers (IEEE) C95. 1-1992
• Institute of Electrical and Electronic Engineers (IEEE) C95.1-1999 Edition
• International Commission on Non-Ionizing Radiation Protection
(ICNIRP) 1998
• Ministry of Health (Canada) Safety Code 6. Limits of Human Exposure to
Radiofrequency Electromagnetic Fields in the Frequency Range from 3 kHz
to 300 GHz, 1999
• Australian Communications Authority Radiocommunications
(Electromagnetic Radiation - Human Exposure) Standard 2001 (applicable
to wireless phones only)
• ANATEL, Brasil Regulatory Authority, Resolution 256 (April 11, 2001)
“additional requirements for SMR, cellular and PCS product certification.”
To assure optimal radio performance and make sure human exposure to radio
frequency electromagnetic energy is within the guidelines set forth in the above
standards, always adhere to the following procedures:
PORTABLE RADIO OPERATION AND EME EXPOSURE
Antenna Care
Use only the supplied or an approved replacement antenna. Unauthorized
antennas, modifications, or attachments could damage the radio and may violate
FCC regulations.
6881041B05a.book Page 2 Friday, July 12, 2002 1:22 PM

Safety and General Information
3
DO NOT hold the antenna when the radio is “IN USE.” Holding the antenna
affects call quality and may cause the radio to operate at a higher power level than
needed.
Two-way Radio Operation
When using your radio as a traditional two-way radio, hold the radio in a
vertical position with the microphone one to two inches (2.5 to 5 cm) away
from the lips.
Body-worn Operation
To maintain compliance with FCC/Health Canada RF exposure guidelines, if you
wear a radio on your body when transmitting, always place the radio in a Motorola
supplied or approved clip, holder, holster, case, or body harness for this product.
Use of non-Motorola-approved accessories may exceed FCC/Health Canada RF
exposure guidelines. If you do not use one of the Motorola-supplied or approved
body-worn accessories, and are not using the radio held in the normal use position,
ensure the radio and its antenna are at least one inch (2.5 cm) away from your
body when transmitting.
To control your exposure and ensure compliance with the general population/
uncontrolled environment exposure limits, always adhere to the following procedure:
• Transmit no more than 50% of the time.
• To transmit (talk), push the Talk button.
• To receive calls, release the Talk button.
6881041B05a.book Page 3 Friday, July 12, 2002 1:22 PM

Safety and General Information
4
Transmitting 50% of the time, or less, is important because the radio generates
measurable RF energy exposure only when transmitting (in terms of measuring
standards compliance).
Data Operation
If applicable, when using any data feature of the radio, with or without an accessory
cable, position the radio and its antenna at least one inch (2.5 cm) away from
the body.
Approved Accessories
For a list of approved Motorola accessories visit our website at www.mot.com.
ELECTROMAGNETIC INTERFERENCE/COMPATIBILITY
Note: Nearly every electronic device is susceptible to electromagnetic interference
(EMI) if inadequately shielded, designed or otherwise configured for
electromagnetic compatibility.
• FACILITIES
To avoid electromagnetic interference and/or compatibility conflicts, turn off your
radio in any facility where posted notices instruct you to do so. Hospitals or
health care facilities may be using equipment that is sensitive to external RF
energy.
• AIRCRAFT
When instructed to do so, turn off your radio when on board an aircraft. Any use
of a radio must be in accordance with applicable regulations per airline crew
instructions.
6881041B05a.book Page 4 Friday, July 12, 2002 1:22 PM

Safety and General Information
5
• MEDICAL DEVICES
Pacemakers
The Advanced Medical Technology Association recommends that a minimum
separation of 6 inches (15 centimeters) be maintained between a handheld
wireless radio and a pacemaker. These recommendations are consistent with
the independent research by, and recommendations of, the United States Food
and Drug Administration.
Persons with pacemakers should:
• ALWAYS keep the radio more than six inches (15 centimeters) from their
pacemaker when the radio is turned ON.
• not carry the radio in the breast pocket.
• use the ear opposite the pacemaker to minimize the potential for
interference.
• turn the radio OFF immediately if you have any reason to suspect that
interference is taking place.
Hearing Aids
Some digital wireless radios may interfere with some hearing aids. In the event
of such interference, you may want to consult your hearing aid manufacturer to
discuss alternatives.
Other Medical Devices
If you use any other personal medical device, consult the manufacturer of your
device to determine if it is adequately shielded from RF energy. Your physician
may be able to assist you in obtaining this information.
6881041B05a.book Page 5 Friday, July 12, 2002 1:22 PM

Safety and General Information
6
Safety and General Use While Driving
Check the laws and regulations on the use of radio in the area where you drive.
Always obey them.
When using your radio while driving, please:
• Give full attention to driving and to the road.
• Use hands-free operation, if available.
• Pull off the road and park before making or answering a call if driving
conditions so require.
OPERATIONAL WARNINGS
• FOR VEHICLES WITH AN AIR BAG
Do not place a portable radio in the area over an air bag or in the air bag
deployment area. Air bags inflate with great force. If a portable radio is placed in
the air bag deployment area and the air bag inflates, the radio may be propelled
with great force and cause serious injury to occupants of the vehicle.
• POTENTIALLY EXPLOSIVE ATMOSPHERES
Turn off your radio prior to entering any area with a potentially explosive
atmosphere, unless it is a radio type especially qualified for use in such areas as
“Intrinsically Safe.” Do not remove, install, or charge batteries in such areas.
Sparks in a potentially explosive atmosphere can cause an explosion or fire
resulting in bodily injury or even death.
Note: The areas with potentially explosive atmospheres referred to above include
fueling areas such as below decks on boats, fuel or chemical transfer or
6881041B05a.book Page 6 Friday, July 12, 2002 1:22 PM

Safety and General Information
7
storage facilities, areas where the air contains chemicals or particles, such
as grain, dust or metal powders, and any other area where you would
normally be advised to turn off your vehicle engine. Areas with potentially
explosive atmospheres are often but not always posted.
BLASTING CAPS AND AREAS
To avoid possible interference with blasting operations, turn off your radio when
you are near electrical blasting caps, in a blasting area, or in areas posted: “Turn
off two-way radio.” Obey all signs and instructions.
OPERATIONAL CAUTIONS
• ANTENNAS
Do not use any portable radio that has a damaged antenna. If a damaged
antenna comes into contact with your skin, a minor burn can result.
•BATTERIES
All batteries can cause property damage and/or bodily injury such as burns if a
conductive material such as jewelry, keys, or beaded chains touch exposed
terminals. The conductive material may complete an electrical circuit (short
circuit) and become quite hot. Exercise care in handling any charged battery,
particularly when placing it inside a pocket, purse, or other container with metal
objects.
6881041B05a.book Page 7 Friday, July 12, 2002 1:22 PM

Safety and General Information
8
6881041B05a.book Page 8 Friday, July 12, 2002 1:22 PM

9
Getting Started
Getting Started
Turning On Your Radio
Sharing Radio Channels
Your radio has 14 channels that you share with other groups on a “take turns” basis.
Other groups may be talking on the channels. Do not talk over someone who is
already using the channel – your message may not be completely heard. If someone
is using your channel, change to a different channel and press Fto see if it is clear.
If you hear static while holding down F, the channel is clear to use.
Do This Result
Press and hold Efor 2
seconds.
The radio display shows the Standby
screen.
See page 11 for descriptions of other things
you might see on the screen.
1
1
P
N
Channel
Call Tone
Character
Interference
Eliminator
Code (0-38)
(1-14)
Disney/Pixar Elements © Disney/Pixar
6881041B05a.book Page 9 Friday, July 12, 2002 1:22 PM

Parts of Your Radio
10
Parts of Your Radio
Press B to:
• Lower the sound
• Move down through
options when changing
radio settings
Press G to:
• Move through different
radio settings
• Lock/unlock the keypad
(when held down in
Standby screen)
Press D to:
Send call tone
Press and hold E to:
• Turn radio on and off
Display
Press
C to:
• Raise the sound
• Move up through options
when changing radio
settings
Press and hold A to:
• Talk
Press A to:
• Save a radio setting
Press F to:
• Monitor channel activity
Microphone
Speaker
N
Disney/Pixar Elements © Disney/Pixar
6881041B05a.book Page 10 Friday, July 12, 2002 1:22 PM

11
What is on Your Display
What is on Your Display
The following picture shows some of the things you might see while using your radio.
11
N
Battery Low
Talk Confirmation
Tone On
(see page 20) Keypress Alert
Tone On
(see page 21)
Talking (if on, not
flashing) or
Channel Busy
(if flashing)
Keypad
Locked
(see
page 19)
Channel (1-14)
Interference
Eliminator Code (0-38)
Disney/Pixar Elements © Disney/Pixar
6881041B05a.book Page 11 Friday, July 12, 2002 1:22 PM

Installing Batteries
12
Installing Batteries
Low Battery Alert
When batteries are low, K appears on the display. Also, the radio beeps:
• 1 to 2 seconds after turning radio on
• Every 10 minutes in Standby mode
• After you release Abutton
1. With back of radio facing you, press
down cover latch with a screwdriver.
2. Remove cover.
3. Insert 4 AAA Alkaline batteries as
shown.
4. Put cover back on and press down.
Note: Do not mix old and new batteries.
+
+
+
6881041B05a.book Page 12 Friday, July 12, 2002 1:22 PM

13
Talking and Listening
Talking and Listening
All radios in your group must be set to the same channel (1-14) and interference
eliminator code (0-38).
• Hold radio 2 to 3 inches from mouth.
• Press and hold the Abutton and talk into the microphone. The Qindicator
appears on the right side of the display while you talk.
• To listen to others, release Abutton.
Talk Range
Do not use the radios closer than 5 feet apart.
Best Range Outdoors
Flat, open areas
Medium Range Outdoors
Buildings or trees
Also near houses
Worst Range Outdoors
Forests or mountains
Also inside some buildings
6881041B05a.book Page 13 Friday, July 12, 2002 1:22 PM

Talking and Listening
14
Making Radio Sound Quieter or Louder
Sending Call Tones
Call tones are sounds you can send to get your listener’s attention before you start
talking. Your radio has 5 different sounds you can send. Each sound is a different
Disney character’s voice. The picture on the radio display shows the selected
character.
To send a call tone, press D. Listeners who are using the same channel and code
will hear your call tone.
Do This Result
1. Press Bto make sound
quieter or Cto make sound
louder.
Display shows Iand current volume
setting (1-16).
2. Press Ato save
setting.
Display returns to Standby screen.
16
6881041B05a.book Page 14 Friday, July 12, 2002 1:22 PM
