Motorola MTM800 E User manual

6871076M01-R
*6871076M01*
March 2014 EN 繁
© 2014Motorola Solutions, Inc. All rights reserved.
Mobile Release 5.14.10
MTM800 E
FEATURE USER GUIDE
特別使用者手冊

Contents
List of Figures.................................................................................................................................. 9
List of Tables.................................................................................................................................. 11
Chapter 1: General Information...........................................................................13
Safety Information...............................................................................................................................................13
Copyrights........................................................................................................................................................... 13
Icon Conventions.................................................................................................................................................14
Using this Guide..................................................................................................................................................14
Feature and Service Availability......................................................................................................................... 15
Chapter 2: Getting Started....................................................................................17
Product Technical Information............................................................................................................................17
Controls and Indicators....................................................................................................................................... 18
Display.................................................................................................................................................................20
Status Icons..........................................................................................................................................................21
Powering On the Radio....................................................................................................................................... 24
Unlocking Your Radio........................................................................................................................................ 24
Unblocking Your Radio.......................................................................................................................... 25
Locking/Unlocking the Keys/Buttons.................................................................................................................25
Entering TMO / DMO Mode...............................................................................................................................25
Transmit Inhibit Mode.........................................................................................................................................25
Selecting Talkgroups...........................................................................................................................................26
Talkgroup Icon Selection.................................................................................................................................... 27
Using Timed Talkgroup Change......................................................................................................................... 27
Activating Talkgroup Scanning...........................................................................................................................27
Broadcast Call..................................................................................................................................................... 28
Ambience Listening (AL) Call............................................................................................................................28
One-Touch Button Feature..................................................................................................................................28
Terminal Temporary Disable/Enable.................................................................................................................. 29
Terminal Permanent Disable...............................................................................................................................29
During the Call.................................................................................................................................................... 30
Writing Text........................................................................................................................................................ 30
Selecting Text Entry Modes....................................................................................................................30
Selecting Text Entry Methods and Languages........................................................................................30
Text Entry Icons...................................................................................................................................... 31
Keys Usage..............................................................................................................................................31
Writing in iTAP Alphanumeric...............................................................................................................33
Writing in TAP Alphanumeric................................................................................................................33
Word Locking..........................................................................................................................................34
Adding Words to the Dictionary............................................................................................................. 34
Home Display Text Message.............................................................................................................................. 34
Chapter 3: Modes...................................................................................................35
Using Networks...................................................................................................................................................35
Trunked Mode Operation.................................................................................................................................... 35
Entering TMO Mode...............................................................................................................................36
Selecting Talkgroups...............................................................................................................................36
Making Group Calls in TMO.................................................................................................................. 36
Contents | 3

Receiving Group Calls in Idle.................................................................................................................36
Receiving Group Calls during Ongoing Group Calls............................................................................. 36
Dynamic Group Number Assignment (DGNA)......................................................................................37
DGNA Reception.................................................................................................................................... 37
DGNA Auto Select Group...................................................................................................................... 37
DGNA Auto Reselect Group...................................................................................................................37
Viewing DGNA Talkgroups................................................................................................................... 37
Broadcast Calls Initiated by Users.......................................................................................................... 37
Initializing Broadcast Calls..................................................................................................................... 38
Phone and PABX Calls........................................................................................................................... 38
Private Call..............................................................................................................................................38
Making Private Calls...............................................................................................................................38
Assistance Call........................................................................................................................................ 39
Call Modification.................................................................................................................................... 39
Local Site Trunking.............................................................................................................................................39
Entering Local Site Trunking..................................................................................................................40
Exiting Local Site Trunking....................................................................................................................40
Direct Mode Operation........................................................................................................................................40
Entering DMO Mode...............................................................................................................................41
Selecting Talkgroups...............................................................................................................................41
Making Group Calls in DMO..................................................................................................................41
Receiving Group Calls in Idle.................................................................................................................41
Private Call..............................................................................................................................................42
Making Private Calls...............................................................................................................................42
Private Call With Presence Check...........................................................................................................43
Talkgroup for Individual Calls................................................................................................................43
Communication through Repeaters.........................................................................................................43
Communication through Gateways.........................................................................................................43
Selecting DMO Group Call Options....................................................................................................... 44
Transmit Inhibit Mode.........................................................................................................................................44
Emergency Operations........................................................................................................................................ 45
Emergency Group Call............................................................................................................................46
Making Emergency Group Calls.............................................................................................................46
Receiving Emergency Group Calls......................................................................................................... 46
Non-Tactical Emergency.........................................................................................................................47
Emergency Individual Calls (Private or MS-ISDN)............................................................................... 47
Emergency Alarm....................................................................................................................................47
Emergency SDS Status............................................................................................................................47
Emergency Hot Microphone................................................................................................................... 47
Alternating Hot Microphone................................................................................................................... 48
Silent Emergency Mode.......................................................................................................................... 48
Invisible Emergency................................................................................................................................49
Emergency Mode by Dialing.................................................................................................................. 49
Disaster Alert...........................................................................................................................................49
Initializing Disaster Alert Calls...............................................................................................................49
Exiting Emergency Operations............................................................................................................... 49
Chapter 4: GPS Location Service.........................................................................51
Enhancing GPS Performance.............................................................................................................................. 52
Enabling GPS...................................................................................................................................................... 52
GPS Icon..............................................................................................................................................................52
GPS Different Location Displays........................................................................................................................52
Viewing Your Position........................................................................................................................................53
GPS – Things to Keep in Mind........................................................................................................................... 53
4 | Contents

Chapter 5: Main Menu.......................................................................................... 55
Scrolling through the Menu.................................................................................................................................55
Menu Icons..........................................................................................................................................................55
Messages............................................................................................................................................................. 56
New Message.......................................................................................................................................... 57
Sending Messages to Private/Phone............................................................................................57
Sending Messages to Groups...................................................................................................... 57
Sending Store and Forward Messages.........................................................................................57
Delivery Report........................................................................................................................... 58
Viewing Delivery Reports...........................................................................................................58
Configuring Delivery Reports.....................................................................................................58
Inbox........................................................................................................................................................58
Entering the Inbox.......................................................................................................................59
Receiving New Messages............................................................................................................59
Using Submenus in the Inbox and the Outbox............................................................................59
Embedded Number......................................................................................................................60
Storing Numbers from Messages................................................................................................ 60
Calling Numbers in Messages.....................................................................................................60
Making Group Calls on theTalkgroup of the Message Sender................................................... 60
Immediate Message.....................................................................................................................61
Outbox.....................................................................................................................................................61
CO Box....................................................................................................................................................61
RMS Box.................................................................................................................................................61
WAP Box................................................................................................................................................ 61
Templates................................................................................................................................................ 62
Sending User-Defined Templates............................................................................................... 62
Setting User-Defined Templates................................................................................................. 62
Predefined Templates..............................................................................................................................62
Viewing Predefined Templates................................................................................................... 62
Sending Predefined Templates....................................................................................................62
Status Messages.......................................................................................................................................63
Viewing a Status Message Number.............................................................................................63
Sending Status Messages.............................................................................................................63
Targeted Status Messages........................................................................................................... 63
Sending Targeted Status Messages............................................................................................. 63
Contacts...............................................................................................................................................................64
Creating Contacts.................................................................................................................................... 64
Editing Contacts...................................................................................................................................... 65
Deleting Numbers....................................................................................................................................65
Deleting Contacts.................................................................................................................................... 65
Checking Capacity.................................................................................................................................. 65
Dialing through the Contact List.............................................................................................................66
Browser............................................................................................................................................................... 66
Security................................................................................................................................................................66
PIN Protect.............................................................................................................................................. 66
Protecting the Radio with a PIN Code........................................................................................ 66
Unblocking Your Radio.............................................................................................................. 66
Changing PIN Codes...................................................................................................................67
Keylock Setup......................................................................................................................................... 67
Keypad Lock Notification...........................................................................................................67
Setting Automatic Keylock Delay...............................................................................................67
Setting Keylock on Startup..........................................................................................................68
Air Encryption.........................................................................................................................................68
Viewing the Air Encryption State............................................................................................... 68
Contents | 5

Air Encryption Key Deletion...................................................................................................... 68
K Validity................................................................................................................................................68
Verifying K Validity................................................................................................................... 69
SCK (Air Interface Encryption Class 2)..................................................................................................69
TMO SCK................................................................................................................................... 69
DMO SCK...................................................................................................................................69
Changing DMO SCK.................................................................................................................. 69
Verifying TMSCK Validity.....................................................................................................................69
Verifying DMSCK Validity.................................................................................................................... 70
Covert Mode............................................................................................................................................70
Activating the Covert Mode........................................................................................................70
SDS Remote Control...............................................................................................................................70
Setting SDS Remote Control.......................................................................................................71
Setup....................................................................................................................................................................71
Ring Style................................................................................................................................................71
Setting Ring Style........................................................................................................................71
Set Volume..............................................................................................................................................71
Setting Volume............................................................................................................................71
Language................................................................................................................................................. 72
Setting Language.........................................................................................................................72
Data Setup............................................................................................................................................... 72
Setting Data Function..................................................................................................................72
Audio.......................................................................................................................................................72
Volume Adjustment Mode.......................................................................................................... 73
Setting Volume Adjustment Mode..............................................................................................73
Tones....................................................................................................................................................... 73
Keypad Tone............................................................................................................................... 73
Setting Keypad Tone...................................................................................................................73
All Tones..................................................................................................................................... 73
Setting All Tones.........................................................................................................................73
Talk Permit..................................................................................................................................74
Setting Talk Permit......................................................................................................................74
Clear to Send............................................................................................................................... 74
Setting Clear to Send...................................................................................................................74
Periodic Alert.............................................................................................................................. 74
Setting Periodic Alert.................................................................................................................. 74
D-PTT Tones...............................................................................................................................74
Setting D-PTT Tones...................................................................................................................75
Display.....................................................................................................................................................75
Setting Text Size......................................................................................................................... 75
Setting Screen Saver....................................................................................................................75
Setting Backlight......................................................................................................................... 75
Setting Wallpaper........................................................................................................................76
Time and Date......................................................................................................................................... 76
Setting Time and Date on the Display.........................................................................................76
Setting the Time Format..............................................................................................................76
Setting the Time Manually..........................................................................................................77
Setting the Date Format...............................................................................................................77
Setting the Date Manually...........................................................................................................77
Setting Time Offset..................................................................................................................... 77
Setting Automatic Updates for the Time and Date .................................................................... 77
Accry (Accessory) Type..........................................................................................................................78
Selecting the Accessory Type..................................................................................................... 78
Book On.................................................................................................................................................. 78
Editing Book On Settings............................................................................................................78
Rotary Knob............................................................................................................................................ 78
6 | Contents

Setting Rotary Knob Mode..........................................................................................................78
Setting Rotary Lock.....................................................................................................................79
Setting In Keypad Lock...............................................................................................................79
Setting Rotary Knob Wrap Around.............................................................................................79
Setting Rotary Knob Scroll Range.............................................................................................. 79
Setting Rotary Knob Talkgroup Selection.................................................................................. 80
Group Setup.........................................................................................................................................................80
Scan......................................................................................................................................................... 80
Activating Talkgroup Scanning...................................................................................................80
Setting Talkgroups in the Active Scan List.................................................................................80
Setting Scan Lists........................................................................................................................ 81
Deleting Talkgroups from Scan Lists..........................................................................................81
My Groups...............................................................................................................................................81
Adding Favorite Folders..............................................................................................................81
Adding Talkgroups to Favorite Folders...................................................................................... 81
Editing My Folder List................................................................................................................82
Deleting Talkgroup from Favorite Folders................................................................................. 82
My Info................................................................................................................................................................82
Viewing and Modifying Personal Information....................................................................................... 82
Recent Calls.........................................................................................................................................................83
Viewing Recent Calls..............................................................................................................................83
Calling from Recent Calls....................................................................................................................... 83
Storing Recent Calls to Contacts.............................................................................................................84
Deleting Recent Calls..............................................................................................................................84
Shortcuts..............................................................................................................................................................84
Creating Menu Shortcuts.........................................................................................................................84
Editing Menu Shortcut Lists....................................................................................................................85
RUI...................................................................................................................................................................... 85
Logging On..............................................................................................................................................85
Logging Off.............................................................................................................................................85
Networks............................................................................................................................................................. 85
Selecting Network Operation Mode........................................................................................................86
Selecting Your Network..........................................................................................................................86
Using the Select Net Registration........................................................................................................... 86
Using the Foreign Network Registration.................................................................................................86
Using Any Network.................................................................................................................................87
Using the Migrate To Registration..........................................................................................................87
Location...............................................................................................................................................................87
Viewing Your Position............................................................................................................................87
Packet Data..........................................................................................................................................................87
Viewing Data Statistics........................................................................................................................... 88
Viewing Encryption Status......................................................................................................................88
Chapter 6: Features............................................................................................... 89
Private Call..........................................................................................................................................................89
Making Private Calls...............................................................................................................................89
Radio Messaging System (RMS)........................................................................................................................ 90
RMS Icons...............................................................................................................................................90
Sending an RMS Status...........................................................................................................................90
One-Touch Dial...................................................................................................................................................91
Talkgroup Dialing by Index................................................................................................................................ 91
Viewing the Talkgroup Speed Number...................................................................................................91
Selecting Talkgroups by Index................................................................................................................91
Phone and PABX Calls....................................................................................................................................... 91
Making Phone or PABX Calls................................................................................................................ 92
Contents | 7

Phone/PABX Speed Dial.....................................................................................................................................92
Using the Phone/PABX Speed Dial........................................................................................................ 92
DTMF Overdial...................................................................................................................................................92
Short Number Dial.............................................................................................................................................. 92
RUA/RUI.............................................................................................................................................................92
WAP.................................................................................................................................................................... 93
WAP Browser..........................................................................................................................................93
Entering the Browser...............................................................................................................................93
Entering Browser Menu Panes................................................................................................................94
Tips for Browsing....................................................................................................................................94
Creating Bookmarks through the Navigate Pane........................................................................ 94
Creating Bookmarks through the Bookmarks Pane.................................................................... 94
Using Bookmarks........................................................................................................................94
Creating Hotkeys.........................................................................................................................95
Using Hotkeys............................................................................................................................. 95
Saving Pages................................................................................................................................95
Selecting Saved Pages.................................................................................................................95
Disabled Packet Data Service..................................................................................................................95
Disabled Browser Entry.......................................................................................................................... 95
Keys Usage..............................................................................................................................................96
Browser Menu Panes Overview..............................................................................................................97
Navigate Pane..........................................................................................................................................97
Advanced.................................................................................................................................................97
Bookmarks Pane......................................................................................................................................98
Working with the Options Pane for Selected Bookmarks...........................................................98
Working with the Saved Pages Folder........................................................................................ 98
History Pane............................................................................................................................................ 99
Navigating to Recently Visited URLs.........................................................................................99
Tools Pane............................................................................................................................................... 99
Options Pane............................................................................................................................................99
Image Pane.............................................................................................................................................. 99
Text Input Pane....................................................................................................................................... 99
WAP Push............................................................................................................................................. 100
New WAP Messages.................................................................................................................100
Viewing WAP Messages...........................................................................................................101
Call-Out.............................................................................................................................................................101
Types of Call-Out Alerts....................................................................................................................... 101
Call-Out Modes Interaction...................................................................................................................102
Call-Out Service Phases........................................................................................................................ 102
Voice Operating Transmission (VOX) Control................................................................................................ 102
Appendix A: Tones...............................................................................................103
Appendix B: LED Indications.............................................................................105
Appendix C: Troubleshooting.............................................................................107
8 | Contents

List of Figures
Figure 1: Trunked Mode Operation ................................................................................................35
Figure 2: Direct Mode Operation ................................................................................................... 41
Figure 3: Call-Out Message ..........................................................................................................101
List of Figures | 9

10 | List of Figures

List of Tables
Table 1: Special Notations ..............................................................................................................15
Table 2: Product Technical Information .........................................................................................17
Table 3: Controls and Indicators .....................................................................................................19
Table 4: Display ..............................................................................................................................20
Table 5: Colors of the Soft Key Area ............................................................................................. 21
Table 6: Status Icons .......................................................................................................................21
Table 7: Talkgroup Icon ................................................................................................................. 27
Table 8: One-Touch Button Features ............................................................................................. 28
Table 9: During the Call ................................................................................................................. 30
Table 10: Text Entry Screen Icons ................................................................................................. 31
Table 11: Keys Usage .....................................................................................................................31
Table 12: Other Keys ......................................................................................................................32
Table 13: Different Location Displays ........................................................................................... 52
Table 14: Menu Icons ..................................................................................................................... 55
Table 15: Inbox Icons ..................................................................................................................... 59
Table 16: Outbox Icons .................................................................................................................. 61
Table 17: Contact Types .................................................................................................................64
Table 18: RMS Icons ...................................................................................................................... 90
Table 19: Browser Keys Usage ...................................................................................................... 96
Table 20: Browser Menu Panes ......................................................................................................97
Table 21: Additional Menu Panes .................................................................................................. 97
Table 22: Browser Text Input Icons ............................................................................................. 100
Table 23: Radio Tones ..................................................................................................................103
Table 24: LED Indications ............................................................................................................105
Table 25: Displayed Messages ..................................................................................................... 107
List of Tables | 11

12 | List of Tables

Chapter
1
General Information
Safety Information
RF Energy Exposure and Product Safety Guide For Two-Way Radios
ATTENTION!
Before using this product, read the RF Energy Exposure and Safety Guide that ships with the radio which contains
important operating instructions for safe usage and RF energy awareness and control for Compliance with applicable
standards and regulations.
Copyrights
The Motorola products described in this document may include copyrighted Motorola computer programs. Laws in
the United States and other countries preserve for Motorola certain exclusive rights for copyrighted computer
programs. Accordingly, any copyrighted Motorola computer programs contained in the Motorola products described
in this document may not be copied or reproduced in any manner without the express written permission of Motorola.
© 2014 Motorola Solutions, Inc. All Rights Reserved.
No part of this document may be reproduced, transmitted, stored in a retrieval system, or translated into any language
or computer language, in any form or by any means, without the prior written permission of Motorola Solutions, Inc.
Furthermore, the purchase of Motorola products shall not be deemed to grant either directly or by implication,
estoppel or otherwise, any license under the copyrights, patents or patent applications of Motorola, except for the
normal nonexclusive, royalty-free license to use that arises by operation of law in the sale of a product.
Disclaimer
Please note that certain features, facilities, and capabilities described in this document may not be applicable to or
licensed for use on a particular system, or may be dependent upon the characteristics of a particular mobile subscriber
unit or configuration of certain parameters. Please refer to your Motorola contact for further information.
Trademarks
MOTOROLA, MOTO, MOTOROLA SOLUTIONS, and the Stylized M Logo are trademarks or registered
trademarks of Motorola Trademark Holdings, LLC and are used under license. All other trademarks are the property
of their respective owners.
| | Send Feedback

European Union (EU) Waste of Electrical and Electronic Equipment (WEEE)
directive
The European Union's WEEE directive requires that products sold into EU countries must have the crossed out
trashbin label on the product (or the package in some cases).
As defined by the WEEE directive, this cross-out trashbin label means that customers and end-users in EU countries
should not dispose of electronic and electrical equipment or accessories in household waste.
Customers or end-users in EU countries should contact their local equipment supplier representative or service centre
for information about the waste collection system in their country.
Open Source Software (OSS) Legal Notices
For details on OSS Legal Notices visit Motorola Online (emeaonline.motorolasolutions.com) or browse the CPS Plus
disc.
Icon Conventions
The following graphic icons, which help identify situations or settings crucial to proper radio operation and user
safety, are used throughout this document:
Danger: The signal word DANGER with the associated safety icon indicates information that, if
disregarded, will result in death or serious injury.
Warning: The signal word WARNING with the associated safety icon indicates information that, if
disregarded, could result in death or serious injury, or serious product damage.
Caution: The signal word CAUTION with the associated safety icon indicates information that, if
disregarded, may result in minor or moderate injury, or serious product damage.
Caution: The signal word CAUTION may be used without the safety icon to state potential damage or
injury that is not related to the product.
Important: IMPORTANT statements contain information that is crucial to the discussion at hand, but is
not CAUTION or WARNING. There is no warning level associated with the IMPORTANT statement.
Note: NOTE contains information more important than the surrounding text, such as exceptions or
preconditions. They also refer the reader elsewhere for additional information, remind the reader how to
complete an action (when it is not part of the current procedure, for instance), or tell the reader where
something is located on the screen. There is no warning level associated with a note.
Suggestion: SUGGESTION indicates a recommendation from Motorola that does not require to be
followed, but might be helpful. There is no warning level associated with SUGGESTION.
Using this Guide
The following special notations are used throughout the text to highlight certain information or items:
14 | General Information
Send Feedback | |

Table 1: Special Notations
Example Description
MENU key or EMERGENCY button Capital letters indicate a name of a key or button.
Entering TMO tone Italic words indicate a name of the tone.
Powering Off Bold words indicate the soft menu items, MMI strings, or
messages displayed on the radio.
Setup → Tones → All Tones Bold words with the arrow between indicate navigation
structure in the menu items.
Feature and Service Availability
This guide describes all available radio features and services. Your service provider may have customized your radio
to optimize its use for your individual needs. Check with you service provider to find out the differences from this
guide.
General Information | 15
| | Send Feedback

Chapter
2
Getting Started
This chapter contains basic information on how to use the radio.
Product Technical Information
Table 2: Product Technical Information
Description Value
Maximum RF Power 3.16 W
Maximum Speaker Load 10 W at 4 Ω
Antenna Impedance 50 Ω
Ambient Temperature Range -30 °C to +60 °C
Note: If the radio is in service, the surface temperature can rise
up to 70 °C. Do not touch the hot surface.
Operating Time Continuous/Intermittent
Note: The communication system determines the radio transmit and receive time (operating cycle time).
During overload, or beyond the systems specifications at high ambient temperatures, the thermal control
cuts down the RF power output, which reduces the radio coverage range.
| | Send Feedback

Controls and Indicators
76543
15
16
21 8
13 1412114109
18 | Getting Started
Send Feedback | |

Table 3: Controls and Indicators
Annotation Description
1 EMERGENCY button
Press and hold EMERGENCY button to enter Emergency operation. By default, when your radio
is off, press and hold to power on in Emergency Mode.
2 ROTARY KNOB
• Press and hold to turn your radio on.
• Rotate to set the volume.
• Press and rotate to select a different talkgroup.
• Press and hold the ROTARY KNOB to lock/unlock it. Powering off also unlocks a locked
ROTARY KNOB.
3 DISPLAY
Provides alphanumeric text and images within 65,536 colors and 640 x 480 pixels with
backlighting and scalable fonts.
Note: Before using your radio for the first time, remove the plastic lens protector
from the display.
4 SOFT key
Press upper or lower SOFT key, to select the option that appears on the screen next to it.
5 ON/OFF/END/HOME key
• Press and hold to turn on/off your radio.
• Press to end calls.
• Press to return to the home screen.
6 NAVIGATION key
Press up, down, left or right NAVIGATION key for list scrolling, while moving around the
menu hierarchy, or for alphanumeric text editing.
From the home screen, press to activate one of the following:
• down NAVIGATION key — enters Recent Calls menu item.
• up NAVIGATION key — changes My Groups talkgroup folder.
• left and right NAVIGATION key — toggles through the talkgroups.
7 KEYPAD
Use the keypad to enter alphanumeric characters for dialing, contact entries, and text
messages.
8 LED
9 MOBILE MICROPHONE PORT
Provides connection for accessories such as fist microphone with PTT.
10 MENU key
Press to enter the main menu and the context-sensitive menu.
11 SEND key
Table continued…
Getting Started | 19
| | Send Feedback

Annotation Description
Press to initiate or answer duplex calls, or send messages.
12 EXTERNAL ALARM key
Press to activate One-Touch Button feature (activates/deactivates the horn and lights by
default).
13 SPEAKER CONTROL key
Press to activate One-Touch Button feature (turns the speaker on/off by default).
14 BACKLIGHT key
Press to activate One-Touch Button feature (dims the backlight by default).
15 PTT (Push-To-Talk)
• Press and hold to talk in simplex calls or to initiate a group call, release it to listen.
• Press to send status and text messages.
16 MICROPHONE
Note:
• It is recommended to turn off the terminal before connecting any of the accessories.
• A detailed list of compatible accessories is included in Accessory Leaflet, part number: 6866539D39.
To obtain the document, contact your service provider.
Display
This section presents the radio's default home screen elements.
Table 4: Display
Annotation Description
1 Status icon area
2 Text display area
3 SOFT key area
4 MENU/Context sensitive icon
The color of the SOFT key area changes according to the mode the radio is in.
20 | Getting Started
Send Feedback | |
