Introduction
1
Introduction
Hi, I’m QuickStart and I’m going to help you get started!
The MotorolaâTalkabout®T6200, T6210, and T6220 radios
are durable two-way radios that operate on Family Radio
Service (FRS) frequencies, require no service fee or license,
and can be used anywhere in the United States and other
areas as listed by the FCC.
These radios offer more than just a way of keeping in touch.
The T6200 provides 14 channels and 38 interference eliminator
codes, five audible call tones, accessory connector, signal-
strength indicator, auto power off, and QuieT6000TM.
The T6210 includes all the features found on the Motorola Talkabout T6200 plus
features such as Eavesdrop Reducer and VibraCall®alert.
The T6220 includes five additional call tones, eight NOAA weather channels, and
weather alert.
A detachable quick reference peel-off sticker that you can stick on the back of your
radio is included. This sticker will help you identify the settings and icons displayed
on your radio. This information is also included in the Getting Started section which
begins on page 14.
1 T6200.book Page 1 Tuesday, March 20, 2001 10:41 AM

Motorola, the Stylized M Logo, and all other trademarks indicated as such herein are
trademarks of Motorola, Inc.
âReg. U.S. Pat. & Tm. Off.
© 2001 Motorola, Inc. All rights reserved. Printed in the U.S.A.
Consumer Products Division
1125 Satellite Road, Suite 101
Suwanee, GA 30024-2880
For a copy of a large-print version of this guide, or for
product-related questions, please call the following
numbers:
1-800-353-2729 (U.S.A.) 1-800-461-4575 (Canada)
1-888-390-6456 TTY (Text Telephone)
1-888-390-6456 TTY (Text Telephone)
On the web, please refer to the Two-Way Radio section of
www.motorola.com/store
1 T6200.book Page 2 Tuesday, March 20, 2001 10:41 AM

Contents
3
Contents
Introduction . . . . . . . . . . . . . . . . . . .1
Contents . . . . . . . . . . . . . . . . . . . . .3
Safety and General
Information . . . . . . . . . . . . . . . . .5
Charging Safety Instructions . .11
Single-Unit Charger . . . . . . . .12
Batteries. . . . . . . . . . . . . . . . . .12
Getting Started . . . . . . . . . . . . . . .14
Basic Operation of Your Radio .14
Installing Batteries . . . . . . . . . . .16
Battery Meter . . . . . . . . . . . .18
Battery Life . . . . . . . . . . . . .18
Charging the NiMH battery .19
Charging Status . . . . . . . . . .20
Charging Dock . . . . . . . . . . .21
Turning On Your Radio . . . . . . .23
Your Radio’s Display . . . . . .24
Turning Off Your Radio . . . . . . .24
Changing Settings While
Turning On Your Radio . . . . .25
Accessing and Setting
Features . . . . . . . . . . . . . . . . .26
Setting the Battery Type . . . . . .26
Backlight . . . . . . . . . . . . . . . . . .27
Talking and Listening . . . . . . . . . 28
Before You Can Talk . . . . . . . . . 28
Setting the Channel . . . . . . 28
Setting the Interference
Eliminator Code . . . . . . . . . 29
Volume . . . . . . . . . . . . . . . . 29
To Talk . . . . . . . . . . . . . . . . . . . 30
Talking Range . . . . . . . . . . . 30
Using Accessories . . . . . . . 31
Monitor/Signal Strength
Indicator . . . . . . . . . . . . . . . . . 31
Alerts . . . . . . . . . . . . . . . . . . . . . . . 32
Call Tone and Call Display . . . . 32
Ring Only (T6200 Only) . . . . . . 33
Ring and/or VibraCall®
(T6210 and T6220 Only) . . . . 34
Talk Confirmation Tone . . . . . . . 35
Button Beeps . . . . . . . . . . . . . . 35
Hands-Free Use (VOX) . . . . . . . . . 36
Hands-Free Use
With Accessories . . . . . . . . . . 36
Setting Sensitivity Level . . . 37
1 T6200.book Page 3 Tuesday, March 20, 2001 10:41 AM

Contents
4
Privacy . . . . . . . . . . . . . . . . . . . . . .38
Eavesdrop Reducer
(T6210 and T6220 Only) . . . . .38
QuieT6000™. . . . . . . . . . . . . . .39
Unique Situations . . . . . . . . .40
Weather (T6220 Only) . . . . . . . . . .41
Turning On Weather
Channel Reception . . . . . . . . .41
Setting the Weather
Channel . . . . . . . . . . . . . . . . .42
Setting the Weather Alert . . . . .42
Other Important Features . . . . . . 44
Lock . . . . . . . . . . . . . . . . . . . . . 44
Scanning . . . . . . . . . . . . . . . . . 44
Auto Power Off . . . . . . . . . . . . 45
Reset . . . . . . . . . . . . . . . . . . . . 46
Simple Menu . . . . . . . . . . . . . . 46
Use and Care . . . . . . . . . . . . . . . . 47
Frequency and Code Charts . . . 48
Troubleshooting . . . . . . . . . . . . . 50
Motorola Limited Warranty . . . . 53
1 T6200.book Page 4 Tuesday, March 20, 2001 10:41 AM

Safety and General Information
5
Safety and General Information
Important Information on Safe and Efficient Operation
Read This Information Before Using Your Radio
The information provided in this document supersedes the general safety
information contained in user guides published prior to July 2000. For information
regarding radio use in a hazardous atmosphere please refer to the Factory Mutual
(FM) Approval Manual Supplement or Instruction Card, which is included with radio
models that offer this capability.
RF Operational Characteristics
Your radio contains a transmitter and a receiver. When it is ON, it receives and
transmits radio frequency (RF) energy. The radio operates in the frequency range of
450 MHz to 470 MHz.
Exposure to Radio Frequency Energy
Your Motorola radio is designed to comply with the following national and
international standards and guidelines regarding exposure of human beings to radio
frequency electromagnetic energy:
•United States Federal Communications Commission, Code of Federal
Regulations; 47 CFR part 2 sub-part J
•American National Standards Institute (ANSI) / Institute of Electrical and
Electronic Engineers (IEEE) C95. 1-1992
•Institute of Electrical and Electronic Engineers (IEEE) C95.1-1999 Edition
1 T6200.book Page 5 Tuesday, March 20, 2001 10:41 AM

Safety and General Information
6
•National Council on Radiation Protection and Measurements (NCRP) of the
United States, Report 86, 1986
•International Commission on Non-Ionizing Radiation Protection (ICNIRP) 1998
•National Radiological Protection Board of the United Kingdom 1995
•Ministry of Health (Canada) Safety Code 6. Limits of Human Exposure to Radio
Frequency Electromagnetic Fields in the Frequency Range from 3 kHz to
300 GHz, 1999
•Australian Communications Authority Radiocommunications (Electromagnetic
Radiation - Human Exposure) Standard 1999
To assure optimal radio performance and make sure human exposure to radio
frequency electromagnetic energy is within the guidelines set forth in the above
standards, always adhere to the following procedures:
Portable Radio Operation and EME Exposure
Antenna Care
Use only the supplied or an approved replacement antenna. Unauthorized
antennas, modifications, or attachments could damage the radio and may violate
FCC regulations.
DO NOT hold the antenna when the radio is “IN USE”. Holding the antenna
affects the effective range.
1 T6200.book Page 6 Tuesday, March 20, 2001 10:41 AM

Safety and General Information
7
Two-Way Radio Operation
When using your radio as a traditional two-way radio, hold the radio in
a vertical position with the microphone two to three inches (5.0 to
7.5 cm) away from the lips.
Body-Worn Operation
To maintain compliance with FCC RF exposure guidelines, if you wear a radio on
your body when transmitting, always place the radio in a Motorola supplied or
approved clip, holder, holster, case, or body harness. Use of non-Motorola-
approved accessories may exceed FCC RF exposure guidelines. If you do not use
a body-worn accessory, ensure the antenna is at least one inch (2.5 cm) from
your body when transmitting.
Approved Accessories
For a list of approved Motorola accessories refer to the Two-Way Radio section of
www.motorola.com/store.
Electromagnetic Interference/Compatibility
Note: Nearly every electronic device is susceptible to electromagnetic interference
(EMI) if inadequately shielded, designed or otherwise configured for
electromagnetic compatibility.
1 T6200.book Page 7 Tuesday, March 20, 2001 10:41 AM

Safety and General Information
8
Facilities
To avoid electromagnetic interference and/or compatibility conflicts, turn off your
radio in any facility where posted notices instruct you to do so. Hospitals or health
care facilities may be using equipment that is sensitive to external RF energy.
Aircraft
When instructed to do so, turn off your radio when on board an aircraft. Any use of a
radio must be in accordance with applicable regulations per airline crew instructions.
Medical Devices
Pacemakers
The Health Industry Manufacturers Association recommends that a minimum
separation of 6 inches (15 centimeters) be maintained between a handheld wireless
radio and a pacemaker. These recommendations are consistent with the
independent research by, and recommendations of, Wireless Technology Research.
Persons with pacemakers should:
•ALWAYS keep the radio more than six inches (15 centimeters) from their pace-
maker when the radio is turned ON.
•not carry the radio in the breast pocket.
•use the ear opposite the pacemaker to minimize the potential for interference.
•turn the radio OFF immediately if you have any reason to suspect that interference
is taking place.
1 T6200.book Page 8 Tuesday, March 20, 2001 10:41 AM

Safety and General Information
9
Hearing Aids
Some wireless radios may interfere with some hearing aids. In the event of such
interference, you may want to consult your hearing aid manufacturer to discuss
alternatives.
Other Medical Devices
If you use any other personal medical device, consult the manufacturer of your
device to determine if it is adequately shielded from RF energy. Your physician may
be able to assist you in obtaining this information.
Safety and General Use While Driving
Check the laws and regulations on the use of radios in the area where you drive.
Always obey them.
When using your radio while driving, please:
•Give full attention to driving and to the road.
•Use hands-free operation, if available.
•Pull off the road and park before making or answering a call if driving conditions
so require.
1 T6200.book Page 9 Tuesday, March 20, 2001 10:41 AM

Safety and General Information
10
Operational Warnings
For Vehicles with an Air Bag
Do not place a portable radio in the area over an air bag or in the air bag deployment
area. Air bags inflate with great force. If a portable radio is placed in the air bag
deployment area and the air bag inflates, the radio may be propelled with great force
and cause serious injury to occupants of the vehicle.
Potentially Explosive Atmospheres
Turn off your radio prior to entering any area with a potentially explosive
atmosphere, unless it is a radio type especially qualified for use in such areas as
“Intrinsically Safe”(for example, Factory Mutual, CSA, or UL Approved). Do not
remove, install, or charge batteries in such areas. Sparks in a potentially explosive
atmosphere can cause an explosion or fire resulting in bodily injury or even death.
Blasting Caps and Areas
To avoid possible interference with blasting operations, turn off your radio when you
are near electrical blasting caps, in a blasting area, or in areas posted: “Turn off two-
way radio”. Obey all signs and instructions.
Note: The areas with potentially explosive atmospheres referred to above include
fueling areas such as below decks on boats, fuel or chemical transfer or
storage facilities, areas where the air contains chemicals or particles, such
as grain, dust or metal powders, and any other area where you would
normally be advised to turn off your vehicle engine. Areas with potentially
explosive atmospheres are often but not always posted.
1 T6200.book Page 10 Tuesday, March 20, 2001 10:41 AM

Safety and General Information
11
Operational Cautions
Antennas
Do not use any portable radio that has a damaged antenna. If a damaged antenna
comes into contact with your skin, a minor burn can result.
Batteries
All batteries can cause property damage and/or bodily injury such as burns if a
conductive material such as jewelry, keys, or beaded chains touch exposed
terminals. The conductive material may complete an electrical circuit (short circuit)
and become quite hot. Exercise care in handling any charged battery, particularly
when placing it inside a pocket, purse, or other container with metal objects.
Charging Safety Instructions
Before using the battery charger, read all instructions and cautionary markings on
the:
1. battery
2. battery charger, and
3. radio using the battery.
Caution: To reduce the risk of injury, charge only the rechargeable batteries listed.
Other types of batteries may burst, causing personal injury and damage.
1 T6200.book Page 11 Tuesday, March 20, 2001 10:41 AM

Safety and General Information
12
Single-Unit Charger
Batteries
Save these Instructions
1. Do not expose the charger to rain or snow.
2. Do not operate the charger if it has received a sharp blow, or has been dropped
or damaged in any way.
3. Do not disassemble the charger if it has received a sharp blow, or has been
dropped or damaged in any way.
4. Never alter the AC cord or plug provided with the unit. If plug will not fit the
outlet, have proper outlet installed by a qualified electrician. An improper
condition can result in a risk of electric shock.
5. To reduce risk of damage to cord or plug, pull the plug rather than the cord
when disconnecting charger from AC receptacle.
6. To reduce the risk of electric shock, unplug the charger from the outlet before
attempting any maintenance or cleaning.
Kit Number Description
NTN9393 110V - NiMH Charging Adapter
Kit Number Capacity in
milliampere-hour mAH Description Composition
NTN9395 550 mAH T6000-Series NiMH
1 T6200.book Page 12 Tuesday, March 20, 2001 10:41 AM

Safety and General Information
13
7. Use of an attachment not recommended or sold by Motorola may result in a risk
of fire, electric shock, or personal injury.
8. Make sure that the cord is located so that it will not be stepped on, tripped over,
or subjected to damage or stress.
9. An extension cord should not be used unless absolutely necessary. Use of an
improper extension cord could result in a risk of fire and/or electric shock. If an
extension cord must be used, make sure:
- That the pins on the plug of the extension cord are the same number, size and
shape as those on the plug of the charger.
- That the extension cord is properly wired and in good electrical condition, and
- That the cord size is18 AWG for lengths up to 100 feet, and 16 AWG for
lengths up to 150 feet.
10. The supply cord of this charger cannot be replaced. If the cord is damaged, call
Motorola Product Services at:
1-800-353-2729 (U.S.A.) 1-800-461-4575 (Canada)
1-888-390-6456 TTY (Text Telephone)
1-888-390-6456 TTY (Text Telephone)
1 T6200.book Page 13 Tuesday, March 20, 2001 10:41 AM

Getting Started
14
Getting Started
Basic Operation of Your Radio
Microphone
Indicator Light
Use P(Power) to:
•Turn power on/off
Use \to:
•Scroll through menus
•Lock the keypad (when
held down and not in a
menu)
•Exit the menu (when held
down while in a menu)
Use ((Call) to:
•Transmit call tone
Use Mto:
•Talk on the radio
•Exit the menu (when briefly
pressed while in a menu)
Use )(Scan/Monitor) to:
•Turn Scan on/off
(short press)
•Monitor the channel &
check signal strength
(long press)
Use Qto:
•Turn on backlight
(short press).
•Press and hold to switch
between Weather Mode
and Two-Way Mode
(T6220 Only).
Use [and ]to:
•Adjust volume
•Scroll through menu
settings
1 T6200.book Page 14 Tuesday, March 20, 2001 10:41 AM

Getting Started
15
000884-O
Belt Clip
- Squeeze the top and
bottom of the clip to attach
or detach the clip from the radio.
Note: The belt clip holds the
radio while being worn
on your belt. It was designed
for your convenience and is
not meant to secure your radio
under all circumstances. For
NiMH Battery Charging Contacts
When using audio
they are plugged in before
you turn on the radio. *
high activity environments, an
accessory carry case is more
appropriate to secure the radio.
Check out the accessory brochure for other cool stuff
available from Motorola.
*Motorola recommends
that the volume level be
kept at a comfortable
listening level when using
audio accessories.
accessories, ensure that
1 T6200.book Page 15 Tuesday, March 20, 2001 10:41 AM

Getting Started
16
Installing Batteries
Your radio uses three AA batteries or a rechargeable Nickel-Metal Hydride
(NiMH) battery.
Some radio packages include a NiMH battery with charger adapter cover, charging
dock, and charger. If you don’t have these items, they’re also available in the NiMH
battery upgrade kit (56319). Call 1-800-353-2729 (U.S.A.) or 1-800-461-4575
(Canada) for the dealer nearest you.
• Turn off the radio by pressing and holding P .
•Push latch up until it clicks.
•Lift back cover off. Latch
1 T6200.book Page 16 Tuesday, March 20, 2001 10:41 AM

Getting Started
17
•Remove and replace batteries so the
+ marking matches the one in the
compartment or the NiMH charge
contacts are facing out toward the
battery door.
•Hook back cover on the hinges.
•Close the battery door, pressing
lightly until the latch clicks and returns
to its original position.
1 T6200.book Page 17 Tuesday, March 20, 2001 10:41 AM

Getting Started
18
Battery Meter
The battery meter on the top-left corner of the display shows how much
battery power you have. It shows d(full), b(two-thirds full), c
(one-third full), and a(empty). When it’s c, the radio beeps every
10 minutes. So, change or charge those batteries!
Battery Life
The following chart lists the approximate battery life during two-way use for alkaline
and NiMH batteries. See page 26.
*Two-way use is defined as 90% standby time, 5% talk time, and 5% receive time.
Battery Type Two-Way Use*
AA alkaline 35 hours
NiMH 12 hours
Note: Battery life will be reduced if you regularly use Hands-Free (VOX) accessories,
Weather, or Scan.
1 T6200.book Page 18 Tuesday, March 20, 2001 10:41 AM
