MOTORSCAN MEMOBIKE 6050 User manual

1
OPERATING INSTRUCTIONS
TECH SUPPORT
HOTLINE
[phone] x1
[e-mail]

OPERATING INSTRUCTIONS
MS6050EN
Mod. 6050_EN
First Edition
February 2014
A.Cavalca
Release 01
February 2016
A.Cavalca
Release 02
March 2016
A.Cavalca
Any printed or digital reproduction of this manual is forbidden without the authorization of
the copyright holder.
Printing the digital version of this manual is permitted only for the purpose of producing a
back-up copy for the user of the product.
The features and data described in this manual are not binding on the manufacturer. The
right is reserved to make changes or modifications without prior notice or product
replacement.
Product and business names appearing in this manual may or may not be registered
trademarks and are used for identification purposes only. All trademarks are the property
of their respective owners.

MS6050EN
OPERATING INSTRUCTIONS
Dear Customer,
This product is part of the MOTORSCAN®family of products. It is the result of many
years of research and development.
The EOS S.r.l. Motorscan® Division is glad to have you as a customer.
Please contact one of our authorized distributors or our customer service department
for any technical questions.

OPERATING INSTRUCTIONS
MS6050EN
Blank Page

MS6050EN
OPERATING INSTRUCTIONS
INDEX I
INDEX
INDEX...........................................................................................................................................i
INTRODUCTION.................................................................................................................1
INSTALLATION...................................................................................................................4
OPERATING INFORMATION .............................................................................................4
SYMBOLS...........................................................................................................................6
1.0.0 - PRODUCT DESCRIPTION......................................................................................7
1.1.0 - GENERAL................................................................................................................7
1.2.0 - SPECIFICATIONS ...................................................................................................7
1.3.0 - FRONT / CONNECTIONS VIEW .............................................................................8
1.4.0 - KEYBOARD VIEW ...................................................................................................8
1.5.0 - STANDARD ACCESSORIES.................................................................................10
1.6.0 - OPTIONAL.............................................................................................................12
2.0.0 - CONNECTING.......................................................................................................22
2.1.0 - POWERING THE TOOL.........................................................................................23
2.2.0 - MOTORCYCLE IDENTIFICATION.........................................................................23
2.3.0 - CONNECTING TO THE MOTORCYCLE USING A MASTER/SLAVE CABLE ......26
2.4.0 - CONNECTING TO THE MOTORCYCLE USING THE “UNIVERSAL” CABLE ......27
2.5.0 - CONNECTING TO THE MOTORCYCLE USING BMW SLAVE CABLE................28
3.0.0 - OPERATION..........................................................................................................29
3.1.0 - SETUP MENU........................................................................................................30
3.2.0 - SETTING MENU....................................................................................................32
3.2.1 - SCREENSHOT MANAGEMENT............................................................................37
3.2.2 - REPORT................................................................................................................38
3.3.0 - BATTERY INFORMATION SCREEN.....................................................................41
3.4.0 - DTC GLOBAL SEARCH.........................................................................................45
3.4.1 - DATA LOGGER .....................................................................................................48
3.5.0 - SELECTING THE SEARCH MODE FOR SYSTEMS INSTALLED ........................53
3.5.1 - MANUAL SEARCH ................................................................................................53
3.5.2 - MANUAL SEARCH BY VEHICLE SELECTION .....................................................54
3.5.3 - MANUAL SEARCH BY ECU SELECTION.............................................................58
3.5.4 - AUTOMATIC SEARCH CONNECTION .................................................................61
3.6.0 - ECU MENU............................................................................................................63
3.6.1 - ECU DATA.............................................................................................................64
3.6.2 - PARAMETERS.......................................................................................................64
3.6.3 - READING STORED FAULTS ................................................................................65
3.6.4 - ERASING STORED FAULTS.................................................................................67
3.6.5 - DIAGNOSTIC PROCEDURES...............................................................................68
3.6.6 - CONFIGURATIONS...............................................................................................69
4.0.0 - APPENDIX.............................................................................................................71
4.1.0 - SCREEN ................................................................................................................71
4.1.1 - “START-UP” SCREEN ...........................................................................................71
4.1.2 - “MENU” SCREEN ..................................................................................................72
4.1.3 - “PROCEED - EXIT” SCREEN ................................................................................73
4.1.4 - “BINARY SELECTION” SCREEN ..........................................................................73

OPERATING INSTRUCTIONS
MS6050EN
II INDEX
4.1.5 - “MESSAGE” SCREEN ...........................................................................................74
4.1.6 - “MULTIPLE SELECTION” SCREEN ......................................................................74
4.1.7 - “PARAMETERS TABLE” SCREEN ........................................................................75
4.2.0 - TYPES OF DIAGNOSTICS....................................................................................76
4.2.1 - SERIAL COMMUNICATION...................................................................................76
4.2.2 - BLINKING CODES.................................................................................................76
4.2.3 - DISPLAY CODES ..................................................................................................77
4.2.4 - MANUAL PROCEDURE.........................................................................................77

MS6050EN
MOD:6050
OPERATING INSTRUCTIONS 1
INTRODUCTION
This manual is an integral part of the product. Read these instructions carefully before using
the tool and keep them in a safe place. EOS S.r.l. Motorscan® Division apologizes for any
errors in the text.
Brand names and products mentioned in the document are registered brands of the relevant
owners.
EOS S.r.l. Motorscan® Division is not responsible to third parties for specific, collateral,
accidental, direct, or indirect damage related to, or deriving from the product purchase and use.
Copies of this document and technical information are available from an authorized distributor of
EOS S.r.l. Motorscan® Division.
This document may not be copied or distributed, in part or its entirety, in any form or by any
means, without prior written authorisation from EOS S.r.l. Motorscan® Division.
EOS S.r.l.
Motorscan® Division
Via Monte Aquila, 2 Corcagnano
43124 PARMA –Italy
Tel. [phone]
www.motorscan.com
[e-mail]
[e-mail]

MOD: 6050
MS6050EN
2 OPERATING INSTRUCTIONS
IMPORTANT INFORMATION ABOUT PERSONAL SAFETY
GENERAL SAFETY IN THE WORKSHOP.
DANGER OF SUFFOCATION
GASOLINE ENGINES
Exhaust gases from gasoline vehicles contain Carbon Monoxide, a colorless and odorless
gas which, in case of inhalation, can cause serious physical injury or death. When working
under a vehicle, be very careful. Some components of exhaust gases are heavier than air.
Be careful also when working on LPG-propelled vehicles.
DIESEL ENGINES
The exhaust gas from a diesel engine has a composition that varies according to: type of
engine, of induction, conditions of use, and fuel composition. The diesel exhaust includes
gas (CO, CO2, NO and HC) and particles (soot, sulphates and PAHs). The small carbon
particles forming soot remain suspended in the air and can be breathed in. Small amounts
of toxic components are also present.
SAFETY MEASURES:
Always ensure good ventilation and breathing protection (especially when working under a
vehicle. Always operate the exhaust fan system when working in confined spaces.
DANGER OF CRUSHING
Ensure that the vehicle is locked in place to prevent possible crushing.
SAFETY MEASURES:
Make sure that the vehicle is unable to move by engaging the hand brake and locking the
wheels.
DANGER OF INJURY
Whether engines are at a standstill or operating, there are moving parts (belts, etc.) that can
injure hands and arms. Pay particular attention to electrically operated fans since these may
unexpectedly start up even when the engine itself is off.
SAFETY MEASURES:
Never place hands near moving parts when the engine is on. When working near electrically
operated fans, let the engine cool first and then unplug the fan.
Keep the test instrument connection wires as far as possible away from moving parts of the
engine.

MS6050EN
MOD:6050
OPERATING INSTRUCTIONS 3
DANGER OF BURNS
Some of the components in engines (exhaust gas manifold, etc.) can become very hot, as can
certain sensors. Remember to never touch these parts.
SAFETY MEASURES:
Wear protective gloves. Never allow the test instrument connection wires to rest on or near hot
parts. Never keep the engine running after the tests.
DANGER OF FIRE OR EXPLOSION
When work is being carried out on the fuel system (fuel pump, injectors and carburetor, etc.)
there may be a risk of fire or explosion owing to the fuels used and/or the vapors that these
products form.
SAFETY MEASURES:
Disconnect the ignition system. Allow the engine to cool.
Do not use open flames or anything liable to produce sparks.
Do not smoke.
Collect any spilled fuel.
Operate exhaust fans in closed rooms.
SOUND LEVEL
When working near a vehicle, especially at high engine speed, noise levels can reach 90dB.
Long term exposure to such noise sources can cause hearing damage.
SAFETY MEASURES:
Wear hearing protection.
DANGEROUS VOLTAGE
Work safely on vehicle electrical systems. Do not touch electrically “live” parts of engines. Be
aware of the risk of shock from damaged connections.
SAFETY MEASURES:
Only use the cables supplied with the test instrument. Make sure that the insulation is not
damaged.
Do not touch live parts of the vehicle when testing with the engine running.
Only make test connections with suitable systems (test cables, specific adapter cables).

MOD: 6050
MS6050EN
4 OPERATING INSTRUCTIONS
DANGER OF ASFIXIATION
If subjected to high temperatures (over 250 °C or owing to fire outbreaks), exhaust gas hoses
may release highly toxic gases.
SAFETY MEASURES:
Immediately contact a physician if such gas is inhaled.
Use neoprene or PVC gloves to eliminate combustion residuals.
Fire residuals can be neutralized with a calcium hydroxide solution. This forms calcium fluoride
which can be removed with water.
DANGER OF CORROSION
Acids can harm the skin if not protected.
The residual condensate in gas sampling hoses and the condensate separator unit contains
acids.
Take great care when replacing the oxygen sensor (O2) and the nitric oxide sensor (NO). They
contain highly corrosive substances.
Corrosive liquid may be spilled if a liquid crystal indicator is broken. This liquid should never be
touched, inhaled or swallowed.
SAFETY MEASURES:
In case of contact with the skin, immediately wash the affected area with water and contact a
physician.
Immediately contact a physician if such products are inhaled or swallowed.
GENERAL INFORMATION
INSTALLATION
Never allow the instrument to be exposed to the sun for long periods of time or to allow it to
stand near hot equipment (stoves, heaters, etc.): the maximum operating temperature is 40
°C/105 F.
Do not move the instrument from a hot place to a cold place and vice versa. The formation of
condensation inside the device may damage the electronic circuits.
Protect the instrument from rain or from excessive moisture.
OPERATING INFORMATION
To prevent contamination from toxic gas, it is advisable to use the instrument in a sufficiently
ventilated place or to channel exhaust gases outdoors.
Never pull on the instrument’s cables.
All connections should be made when the vehicle engine in question is off.
Check that all cables are far away from hot parts (over 50 °C/130F) or moving parts.
Disconnect all engine connections before moving the vehicle in question.
