MotoSAT DataStorm D2 User manual

v.1
Table of Contents
Step 1
Finding the iDirect Modem’s IP Address __ 1-2
Step 2
Configuring your Network _____________ 2-3
Step 3
Configuring the D2 ____________________4-5
Step 4
iDirect Username/Password for the D2 ___ 5-6
Step 5
Searching for the Satellite ______________ 7-8
D2/iDirect User Guide

v.1
Step 1: Finding the iDirect modem’s IP Address Cont.
| The iDirect Modem’s IP Address Cont. |
> When the user name and password prompt appears:
| User Name: admin
| Password: [Your password is provided by your iDirect paperwork or by your
iDirect ISP]
> When able to type commands you will see only a ‘>’ symbol.
> To find the iDirect’s IP address type in the command ‘laninfo’all one word.
> This command will pull up the iDirect modems IP address information. This
information will be used to configure your router [you may use a switch only if
you have a 5 IP address iDirect package]:
> Write these down for future reference and go to step 2.
Step 2: Configuring your Network
| Configuring your Netowrk |
> The D2, iDirect modem, and your computer[s], will all connect via Etherner into
switch.
2
D2/iDirect User Guide

v.1
Step 4: iDirect Username/Password for the D2 Cont.
| iDirect Username/Password for the D2 Cont. |
> Click Start>Run>telnet [D2’s IP Address]>OK
> A prompt will appear with the DATASTORM %
> You will now need to set the username and password in the D2. The commands are:
| setvalue modemUsername admin , [hit enter]
| setvalue modemPassword [your iDirect modem password] , [hit enter]
[If your password is different please enter it here]
> Exit [Close] the telnet prompt.
> Here are a few tips on these commands:
| The commands:
- getvalue modemUsername
- getvalue modemPassword
Can be used to determine the current username and password stored in
the D2.
| These parameters are stored in Non-Volatile RAM [memory that can be
erased and written to via commands]. If ever an NVCLEAR is performed
[where the D2’s Non-Volatile RAM is erased], you will need to run through
these commands again.
> Now move on to Step 5. 7
D2/iDirect User Guide

v.1
Step 5: Searching for the Satellite
| Searching for the Satellite |
> Open your internet browser and type in the new IP address of the D2 [in this case
192.168.1.250].
> The D2’s status page will appear. There are two things you could see:
| A good search screen will show a‘0’next to signal quality, TX status will read
‘Transmitter unavailable due to receive signal problem’, RX will read
‘Receiver not locked to a signal’.
| A screen that reads error-25 indicates the D2 is waiting for the modem.
This is temporary and will refresh to be able to search.
> After confirming the system status readings you need to make sure the
status buttons read good for a satellite search:
> The LNB, LAN, GPS, and STOW* lights should be lit.
*[Stow can only be lit if a stow operation has been done.]
> With all these criteria met you can now click‘Search’.
> During a search, signal quality will read‘0’. If you see ANY signal quality,
you’re on the right satellite and the DataStorm will peak accordingly with
typical high signal quality.
> When the DataStorm has finished peaking, the system status will read
‘Search Operation Completed’ and the ‘Ready’ light will be lit. This indicates
that a connection to the Internet has been attained.
8
D2/iDirect User Guide
LNB LAN GPS READY BUSY STOW
The iDirect Modem’s network light will stay solid
when connected to the Internet.

D2/iDirect User Guide v.1
9
© MOTOSAT 2005 | ALL RIGHTS RESERVED
This concludes the D2/iDirect Guide.
MotoSAT | www.motosat.com | 1-800-247-7486
For additional help on connecting to the Internet
or other Internet related questions, contact your iDirect ISP
