Moultrie Mobile X Series User manual

Please register your camera at www.MoultrieFeeders.com/warranty to activate your warranty.
X-SERIES CELLULAR GAME CAMERA INSTRUCTION MANUAL
Table of Contents
Account Set Up.........2
Install Batteries........3
Install SD Card..........4
Format SD card ........5
LED Color Chart.... 6-7
Test Image................8
Camera Settings.......9
Update Firmware....10
Mount Camera........11
IMPORTANT! READ BEFORE YOU START:
• We recommend that you go through the entire set up process
at home to ensure your camera is operating as expected and
images are transmitting prior to taking to the field for use.
• You must have an ACTIVE Moultrie Mobile account to operate
camera and retrieve images. Log on to MoultrieMobile.com
to set up an account or use the free Moultrie Mobile app.
Plan purchased from Moultrie at time of activation.
• 12 AA batteries and a compatible SD card are required;
we recommend an 8GB or smaller Class 10 SD card.
NOTE: See page 3 for important battery information.
• Each time you insert an SD card, be sure to format the SD card
in your camera to ensure it will work properly. See page 5 for
instructions on how to format SD card.
• 4G Network Coverage is required. Go to MoultrieMobile.com
to verify coverage in your location.

2
1. ACCOUNT SET UP AND CAMERA ACTIVATION
IMPORTANT: After submitting your registration, you will receive an email. You will not be able to log in
to your account until you have confirmed your registration through this email. Please check your spam,
clutter or junk folders for this email.
• Log-on to your Moultrie Mobile account via app or website.
• From the MY ACCOUNT section, select “Activate Device” and follow the on-screen instructions.
– The Serial Number and Modem ID can be found on the sticker inside of the camera above the
battery compartment.
– If activating mid-billing cycle, the amount owed at activation as well as the number of pictures
purchased will be prorated. The next billing cycle will reflect full monthly payment and number
of pictures for the plan chosen.
• Click PURCHASE to complete activation of camera.
NOTE: It can take several hours for the device to become active on the cell provider’s network.
During this time, the device will not be able to connect to the server. Please keep trying. If after
24 hours your device has not successfully connected to the server, please contact customer service.
SET UP MOULTRIE MOBILE ACCOUNT
(Skip this step if already a Moultrie Mobile customer)
Go to MoultrieMobile.com and click REGISTER NEW ACCOUNT or go to the
Moultrie Mobile app and click SIGN UP to get started.
2. INSTALL BATTERIES

1. ACCOUNT SET UP AND CAMERA ACTIVATION
+
_
3
2. INSTALL BATTERIES
Open camera housing and install 12 AA batteries.
Important Battery Information
• Only use alkaline or lithium batteries. We recommend the use of Energizer™ lithium batteries
for optimum performance.
• Do not mix old and new batteries. Always replace ALL the batteries at the same time.
• Do not mix different brands of batteries or alkaline and lithium batteries.
• When the camera is not in use, please remove the batteries.
• DO NOT USE RECHARGEABLE BATTERIES.
• Be sure batteries are inserted correctly into the battery compartment before powering
on the device.
Note: When using lithium batteries, the Moultrie Mobile system may report near full capacity
and then quickly drop to indicate low voltage within a short period. This is due to the properties
of lithium batteries and is expected behavior.
Note: Internal batteries are required when using an external battery source.

4
3. INSTALL SD CARD
Locate SD card slot on side of camera and insert SD card. Make sure to
format the SD card in the camera to ensure proper operation. See page 5
for formatting instructions.
Important SD Card Information
• We recommend that you use an 8GB or smaller Class 10 SD card.
• Do NOT use micro SD cards, SDXC or cards designated as “turbo”, “ultra”, or “super speed”,
as the speed required by these cards to operate may cause instability in the cameras.
• We recommend that you have one dedicated SD card for each camera.
• Avoid swapping SD cards between cameras or other digital devices.
• Always format your SD card in the camera before each use.

5
4. FORMAT SD CARD
SD
1. Press and hold the FORMAT SD CARD button until the SD CARD LED blinks yellow.
2. Once the card is formatted, the SD CARD LED will turn solid green indicating success.
3. If the SD card LED turns solid red, the SD card was not formatted. Repeat the process
until SD card LED is solid green. If the SD card LED does not turn green, try
another card.
FORMAT SD CARD VIA APP/WEBSITE
Once you’ve completed the steps above, you will have the option to format your SD card from
the Moultrie Mobile app or website under your camera settings. After you have elected to
format your SD card, it will format the next time the camera checks in with the Moultrie Mobile.
Power camera on by flipping ON/OFF SWITCH to the ON position.
Anytime the camera’s power switch is flipped from the OFF to ON position, there is a
60-second delay to allow time to format the SD card. Please follow the steps below:

6
5. LED COLOR DEFINITIONS AND SOLUTIONS
• The BATTERY and SD CARD LEDs will illuminate to show status. Green BATTERY LED indicates
power is full and green SD CARD LED indicates card is good. The LED indicators can also be
yellow or red. Refer to the table on page 7 for color definitions.
• SIGNAL LED will flash yellow while acquiring signal and turn to solid green if signal is good,
yellow if signal is ok, and red if signal is bad.
• SERVER LED will flash yellow while connecting to Moultrie Mobile and turn green when
connected. This could take some time, be patient.
Note: To display the status of the Signal, Battery, SD card or Server, you can briefly press
CONNECT/STATUS button. Camera will attempt connection to Moultrie Mobile and display
LED status.
Only LEDs illuminate. If switch or buttons appear to be illuminated, it is due to illumination from
surrounding LEDs.
CONNECT/
STATUS
FORMAT
SD CARD
SERVERBATTERYSIGNAL SD CARD OFF
SD
ON
5. LED COLOR DEFINITIONS AND SOLUTIONS (cont.)

5. LED COLOR DEFINITIONS AND SOLUTIONS
7
GREEN YELLOW RED
SIGNAL Good signal Weak signal No signal
Move camera
BATTERY 50% to 100% 11-49% 0-10%
Replace batteries
SD CARD Good card Card full / Locked Bad / No card
Format/Erase or Replace card
SERVER Connected Connecting... Can’t connect
5. LED COLOR DEFINITIONS AND SOLUTIONS (cont.)
Note: The SIGNAL and SERVER LED’s will flash yellow indicating the camera is
connecting to Moultrie Mobile. Once the LEDs stop flashing, the illuminated color
will reflect connection status.

7. CAMERA SETTINGS
8
6. TRANSMIT TEST IMAGE
• Press and hold CONNECT/STATUS button for minimum of 5 seconds.
– Status LEDs will illuminate to display status, refer to table on page 7 for color definitions.
– SIGNAL and SERVER LEDs will flash yellow until connection is established, then
illuminate to indicate status. See table on page 7 for color definitions.
• Test image is taken and successfully transmitted once the server LED illuminates green and
then all LEDs turn off.
We strongly recommend you confirm receipt of test picture by logging in to
your Moultrie Mobile account via the app or website.
MANUALLY TRANSMIT IMAGES
You have the option to transmit any photos captured since the last connection by briefly
pressing and realeasing the CONNECT/STATUS button. Once the transmission is complete,
all LEDs will turn off.
Note: Upload frequency setting is not affected by manual image transmit.

9
7. CAMERA SETTINGS
Once you have successfully taken and transmitted a test image, go to the website or app
to update your camera settings.
Changing settings:
• Go to the cameras section from the Moultrie Mobile website or app.
• Select the camera you wish to update settings for.
• Choose your camera settings as well as the upload frequency and press SAVE.
Note: There are icons next to each setting that when clicked will display descriptions
and useful tips.
Note: This camera can be set to record video, but video will not transmit to
Moultrie Mobile. The video will remain on the SD card.
Important: After camera settings are selected and saved, the settings will be changed
on the camera the next time the camera connects to Moultrie Mobile. To manually
connect, press the CONNECT/STATUS button to connect to Moultrie Mobile and update
settings immediately.
Confirm status of camera using the LED indicators before leaving your camera.
6. TRANSMIT TEST IMAGE

9. MOUNTING CAMERA
1010
8. UPDATING YOUR FIRMWARE
UPDATE FIRMWARE MANUALLY
The XA-7000i / XV-7000i is designed to perform firmware updates automatically.
In the event you need to perform a manual camera firmware update, please follow
the below instructions:
Important: To install firmware manually you must first download the firmware to a clean SD card.
Go to MoultrieFeeders.com/firmware-faq for a complete list of firmware and instructions on
how to download firmware to an SD card.
• Insert the SD card containing firmware into the SD slot.
• With camera OFF and no LEDs illuminated, press and hold CONNECT/STATUS button while
sliding ON/OFF switch to the ON position.
• Firmware begins updating when all LEDs begin to chase yellow.
• Firmware update is successful when all LEDs turn off and the camera reboots, going through
the initial powered on LED sequence (waiting for all four LEDs to illuminate and stay illuminated).
• Firmware update is unsuccessful if all LEDs turn solid red for 10 seconds and then all LEDs
turn off. Please try again.

11
9. MOUNTING CAMERA
• Thread mounting strap through slots on back of camera case.
• Mount camera to a tree or pole approximately three (3) feet
from ground. You may need to adjust for uneven terrain.
For added security, you can attach the camera to a tree with
a Master Lock Python™ cable locking system. Or you can use
the 1/4”-20 mount with the Moultrie EZ Tree Mount or Camera
Stake accessories. Visit MoultrieFeeders.com to purchase
these mounting accessories.
Tips for Best Photos:
• Face the camera North or South to avoid overexposure from the sun.
• Clear brush away from the front of the camera to avoid
false-movement triggers.
• When covering a game trail,
face camera looking down
the trail instead of directly
at it (see graphics).
3 ft.
INCORRECT CORRECT
8. UPDATING YOUR FIRMWARE

For questions go to the “Contact Us” section of MoultrieMobile.com or the Moultrie Mobile app.
PRADCO Outdoor Brands • 3280 Highway 31, Ste. B • Calera, AL 35040
03192019
FCC Statements
Note: Changes and modifications not expressly approved by the party responsible could void the user’s authority to operate this device.
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful
interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.
NOTE: THE MANUFACTURER IS NOT RESPONSIBLE FOR ANY RADIO OR TV INTERFERENCE CAUSED BY UNAUTHORIZED MODIFICATIONS TO THIS
EQUIPMENT. SUCH MODIFICATIONS COULD VOID THE USER’S AUTHORITY TO OPERATE THE EQUIPMENT.
NOTE: This device complies with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference in a residential installation. This device generates, uses, and can radiate radio frequency
energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However,
there is no guarantee that interference will not occur in a particular installation.
If this device does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the
user is encouraged to try to correct the interference by one or more of the following measures:
• Reorient or relocate the receiving antenna.
• lncrease the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help.
XV-7000i
MCG-13309
XA-7000i
MCG-13310
Moultrie Limited Warranty
This product has been thoroughly tested and inspected before shipment. It is guaranteed from defects in material and workmanship from the date of
purchase for 2 years. Under this limited guarantee we agree to replace or repair free of charge any part or parts which have been found to be defective
in original material or workmanship. Should you require in-warranty service, visit MoultrieMobile.com/contact and follow the instructions under
the Return section. Physical damage, alterations or tampering with the equipment is not covered under warranty and will invalidate your warranty.
