MD2431-S-03 INSTALLATION INSTRUCTION
17"~39" Max:200x200mm/8"x8"
Min:75x75mm/3"x3"
Für die Installationsanweisungen auf Deutsch, siehe Seite 10-11.
Pour l'instruction en Français, veuillez vous reporter à la page 12-13.
Para las instrucciones de la instalación en Español, favor vea la página 14-15.
Per le Istruzioni in Italiano, vedi pagina 16-17.
x3 x1
If you have any questions, please contact us via [e-mail]
TV
1 2
(DE-B1)

Before getting started, let’s make sure this mount is perfect for you!
1 Is your TV VESA
equal to/greater than
75x75mm/3x3"
and equal to/less than
200x200mm/8x8"?
2 Does your TV
(including accessories)
weigh less than
77 LBS (35 KG)?
4 Installation Tools
(Not Included)
Yes --- Perfect!
No --- This mount is NOT compatible.
MAX:200mm/8"
MAX:
200mm/8"
Yes --- Perfect!
No --- This mount is NOT compatible.
CAUTION:
Drywall with
wood studs?
Band Tape
2M2M
5 Safety Caution
Please read this instruction carefully before installation.
If you do not understand these instructions or have doubts about the safety of the
installation, assembly or use of this product, contact Customer Service via
[e-mail] .
● This product is designed for use in wood stud and solid concrete wall.
- DO NOT install into drywall alone.
● The wall must be capable of supporting five times the weight of the TV and mount
combined.
● Do not apply this product to any purpose not indicated by Mounting Dream.
● Incorrect installation may result in product damage or body injury. Mounting Dream shall
bear no responsibility for any damage or injury resulted from incorrect installation,
incorrect assembly or misuse.
Solid concrete
wall?
Pencil Screwdriver Electrodrill Socket Wrench
1/2"(13mm)
Stud Finder Awl 5/32"(4mm)
Wood Drill Bit
3/8"(10mm)
Masonry Drill Bit Hammer
1
3 What is your wall
made of?

Parts and Hardware
WARNING:This product contains small items that could be a choking hazard if
swallowed. Before starting assembly, verify all parts are included and undamaged. For parts
shortage or damage, please contact us via [e-mail].
NOTE: Not all hardware included will be used.
2
TV Plate
Allen Key
x1
Spacers
TV Screws
① 75mm x 75mm
② 100mm x 100mm
③ 100mm x 200mm
④ 150mm x 150mm
⑤ 200mm x 100mm
⑥ 200mm x 150mm
⑦ 200mm x 200mm
M4x12mm
M6x12mm
M8x25mm
M4x30mm
M6x35mm
M8x45mm
M6x17mm M8x22mm
M4 M6
10mm 2.5mm
Washers
x4 x4
x4 x4
x4 x4
x4
x4 x4
x4 x8
x4
x1
1-1 Choose Configuration
① ①
① ①
③ ③
③ ③
④
④
④
④
②②
② ②
⑦ ⑦
⑦⑦
⑤⑤
⑤⑤
⑥ ⑥
⑥ ⑥

M8
M6
M4
1-2 Select TV Screws
TV back
Bracket Washer
Bracket
Long Screw
Spacer
No, go to PAGE 3 for detailed combination.
Yes, go to PAGE 3 for detailed combination.
TV back
1-3 Need Spacer?
Short Screw
Washer
Tips: If you need to combine M6(e) or M8(c/f) screw with 2.5mm spacer(j), you have to
remove the inner circle.
Screw and washer
Spacer(s), screw and washer
1-4 Attach TV Plate to TV Back
No!
3

For wood stud installation, follow STEP 2A
For concrete installation, follow STEP 2B on PAGE 6
Parts and Hardware
Lag Bolt M7x70mm
x3 x2
<16mm
(5/8")
Min. Wood Stud Size:
nominal 2"(51mm)
actual 1 1/2"(38mm)
Min. Wood Stud Size:
nominal 4"(102mm)
actual 3 1/2"(89mm)
Wood Stud Installation
Wall plate
Mounting Template
4
M6x12mm Bolt
x1
Concrete Wall Anchor 3pcs
CAUTION:Do not use in drywall or wood
Fischer UX10x60 R
