Overview
Moxa Sub-1G module(ZB-DCU3-T, ZB-PM3-T, ZB-WAN1-T) uses ATMEL
wireless microcontroller which pro ides a comprehensi e solution with large
memory(256KB Flash and 16KB SRAM), high CPU and radio performance and all
RF components included.
The module is a range of ultra low power, high performance surface mount
modules targeted at Sub-1G networking applications, enabling users to realize
products with minimum time to market and at the lowest cost. Sub-1G
module(ZB-DCU3-T, ZB-PM3-T, ZB-WAN1-T) can implement networking stacks,
such as ZigBee, as well as customer applications
Note:
* The Sub-1G module will implement into Moxa System’s DCU and CFE Protecsa’s
Smart Meter application. So, it should follow Moxa System’s DCU-8620-T specification
and CFE Protecsa AMI specification that provided by CFE company.
Features
• Support SCM setting
• Support upgrade firmware o er the AIR
• Support AES-128 compatible encryption
• Support large packets fragmentation
• Support Mesh topology
Specifications
Sub-1G Interface
Internal Memory: 256KB
Flash : 256KB. SRAM: 16KB
RF Standard: IEEE 802.15.4
Frequency Band: 769 ~ 935 MHz
RF Data Rate: 20 ~ 40 Kbps (BPSK modulation)
RF Channel: 10 channel
Tx Power: +10 dBm
Rx sensitivity: -110 dBm
Distance: 900M
Serial Communication Parameters
UART Baud Rate: 50 bps to 115.2K Kbps
Power Requirement
Power consumption: RX：26 mA TX：110 mA
Operating Supply Voltage: 3.3 V

Environmental Limits
Operating Temperature: -40 to 75°C (-40 to 167°F)
Operating Humidity: 5 to 95% RH
Storage Temperature: -40 to 85°C (-40 to 185°F)
Physical Characteristics
Dimension: ZB-DCU3-T/ZB-WAN1-T (48x30x1.6mm), ZB-PM3-T (45x38x1.6mm)
Standard and Certifications
EMC: CE (EN55022 and EN55024 Class A), FCC Part 15 Subpart B Class A
Reliability
Automatic Reboot Trigger: Built-in WDT (watchdog timer)
MTBF (meantime between failures): Over 10 years
Warranty
Warranty Period: 5 years
Details: See www.moxa.com/warranty

2
2. Getting Started
This chapter co ers the module layout, and block diagram, hardware installation
of the Sub-1G module. Software installation is co ered in the next chapter.
󰆌 Module Layout
󰆌 Block Diagram
󰆌 Connector Locations
󰆌 Hardware Installation
󰆌 Software Installation

Module Layout
ZB-DCU3-T, ZB-WAN1-T
+
ZB-PM3-T
+
Block Diagram
=
=

PIN Define
ZB-DCU3-T, ZB-WAN1-T
PIN Number PIN Function PIN Number PIN Function
1 3.3V 2 3.3V
3 GND 4 GND
5 GND 6 GND
7 NC 8 NC
9 NC 10 NC
11 RXD 12 NC
13 TXD 14 NC
15 NC 16 NC
17 NC 18 NC
19 NC 20 RESET
ZB-PM3-T
PIN Number
PIN Function
1 VCC
2 TXD
3 RXD
4
RST
5
NC
6
GND
7
GND
Hardware Installation
The Sub-1G Module can be installed into Moxa DCU-8620-T Embedded
Computer system and Power Meter.
Steps for Installation on DCU
1. Attach the WLAN antenna to connector UI.
2. Let Sub-1G Module(ZB-DCU3-T and ZB-WAN1-T) connect to DCU-8620-T.
3. Screw on the Sub-1G Module
Steps for Installation on Power Meter
1. Let Sub-1G Module(ZB-PM3-T) connect to Power Meter.
2. Reco er the Power Meter.

Software Installation
After physically installing the Sub-1G module, the module will be recognized on
the new system board after the following steps.
Steps for Installation
1. Apply power to the system board.
2. Run DCU-8620-T application program. Make sure it could communicate with
Sub-1G module(ZB-WAN1-T and ZB-DCU3-T).
3. Apply power to the Power Meter. Make sure the LED of “Ready” light-on on
Power Meter.
4. Run DCU-8620-T application program, make sure it could read data from
Power Meter through the air.
