NPort 6150 Series
Quick Installation Guide
Fifth Edition, May 2013
Overview
The NPort 6150 series secure serial device servers provide reliable
serial-to-Ethernet connectivity for a wide range of serial devices.
The NPort 6150 supports TCP Server, TCP Client, UDP, and
Pair-Connection operation modes to ensure the compatibility of
network software. In addition, the NPort 6150 also supports
Secure TCP Server, Secure TCP Client, Secure Pair-Connection,
and Secure Real COM modes for security critical applications such
as banking, telecom, access control, and remote site
management.
Package Checklist
Before Installing the NPort 6150 secure device server, verify that
the package contains the following items:
•1 NPort 6150
•Power adaptor
•2 wallmount ears
•Documentation and software CD
•Quick installation guide (this guide)
•Warranty card
Optional Accessories
•DK-35A: DIN-rail mounting kit (35 mm)
•DIN-rail power supply
•CBL-RJ45M9-150: 8-pin RJ45 to male DB9 cable
•CBL-RJ45M25-150: 8-pin RJ45 to male DB25 cable
NOTE: Please notify your sales representative if any of the above
items are missing or damaged.
Hardware Introduction
Reset Button—Press the Reset button continuously for 5 sec to
load factory defaults. Use a pointed object, such as a straightened
paper clip or toothpick, to press the reset button. This will cause
the Ready LED to blink on and off. The factory defaults will be
loaded once the Ready LED stops blinking (after about 5 seconds).
At this point, you should release the reset button.
LED Indicators
LED Name
LED Color
LED Function
PWR
Red
Power is being supplied to the power input.
Ready
Red
Steady on:
Power is on and the NPort
6150 is booting up.
Blinking:
Indicates an IP conflict, or, the
DHCP or BOOTP
server did not
respond properly or a relay
output occurred. Check the
relay output first. If after
resolving the relay output the
RDY LED is still blinking, then
there is an IP conflict, or the
DHCP or BOOTP server did not
respond properly.
Green
Steady on:
Power is on and the NPort
6150 is functioning normally.
Blinking:
The device server has been
located by the Administrator’s
Location function.
Off
Power is off, or power error condition
exists.
Link
Orange
10 Mbps Ethernet connection
Green
100 Mbps Ethernet connection
Off
Ethernet cable is disconnected, or has a
short.
P1
Orange
Serial port is receiving data.
Green
Serial port is transmitting data.
Off
No data is being transmitted or received
through the serial port.
P1 in-use
LED
Green
Serial port was opened by server side
software.
Off
Serial port has not been opened by server
side software.
Adjustable pull high/low resistor for RS-422/485
(150 K? or 1 K?)
Jumpers are used to set the pull
high/low resistors. The default is
150 kΩ. Short the jumpers to set
this value to 1 kΩ. Do not use the
kΩ setting with RS
-232 mode,
since doing so will degrade the
RS
-232 signals and shorten the
communication distance.

– 4 – – 5 – – 6 –
www.moxa.com/support
The Americas:
[phone] (toll-free: 1-888-669-2872)
Europe:
[phone]
Asia-Pacific:
[phone]
China:
[phone] (toll-free: 800-820-5036)
2008 Moxa Inc. All rights reserved.
Hardware Installation Procedure
STEP 1:
Connect the 12-48 VDC power adaptor to the NPort 6150
and then plug the power adaptor into a DC outlet.
STEP 2:
For first-time configuration, use a cross-over Ethernet
cable to connect the NPort 6150 directly to your
computer’s Ethernet cable. For connecting to a network,
use a standard straight-through Ethernet cable to
connect to a hub or switch.
STEP 3:
Connect the NPort 6150’s serial port to a serial device.
Placement Options
The NPort 6150 can be placed flat on a desktop or other horizontal
surface. In addition, you may use the DIN-rail or wallmount
options, as illustrated below.
Wallmount
Din Rail
Software Installation Information
The Documentation and software CD contains the user’s manual,
NPort Search Utility, and the PComm Lite Suite. Insert the CD and
follow the on-screen instructions. Please refer to the user’s manual
for additional details on using the NPort Search Utility and PComm
Lite.
Pin Assignments and Cable Wiring
RS-232/422/485 Pin Assignment (male DB9)
Pin RS-232
RS-422
4-wire RS-485
2-wire
RS-485
1
DCD
TxD-(A)
–
2
RXD
TxD+(B)
–
3
TXD
RxD+(B)
Data+(B)
4
DTR
RxD-(A)
Data-(A)
5
GND
GND
GND
6
DSR
–
–
7
RTS
–
–
8
CTS
–
–
9
–
–
–
Two serial cables for connecting the NPort 6150 to a serial device
can be purchased separately. The wiring diagrams for the two
cables are shown below.
Specifications
LAN
Ethernet
10/100 Mbps, RJ45
Protection
Built-in 1.5 KV magnetic isolation
Serial
No. of ports
1
Interface
RS-232/422/485 (male DB9)
Serial Communication Parameters
Parity
None, Even, Odd, Space, Mark
Data bits
5, 6, 7, 8
Stop bit(s)
1, 1.5, 2
Flow control
RTS/CTS, XON/XOFF, DTR/DSR
Speed
50 bps to 921.6 Kbps
Console Port
RS-232 (please see the User’s Manual for
detailed operating instructions)
Software Features
Protocols
ICMP, IPv4/v6, TCP, UDP, DHCP, BOOTP,
Telnet, DNS, SNMP, HTTP, SMTP, HTTPS,
SSL, SSH, PPPoE, RFC2217
Utilities
NPort Search Utility for Windows
98/ME/NT/2000/XP/2003/Vista/2008/XP
x64/2003 x64/Vista x64/2008 x64
Security Protocols
DES/3DES/AES
OS Driver Support
Windows Real COM drivers:
Windows
95/98/ME/NT/2000/XP/2003/Vista/XP
x64/2003 x64/Vista x64
Real TTY drivers: Linux 2.4 and 2.6
Fixed TTY drivers: SCO Unix, SCO
OpenServer 5, OpenServer 6, UnixWare 7,
UnixWare 2.1, SVR4.2, QNX 4.25, QNX 6,
Solaris 10, FreeBSD 5, FreeBSD 6
Configuration
Web Console, Serial/Telnet Console,
Windows utility
Power Requirements
Power input
12 to 48 VDC
Mechanical Specifications
Material
Aluminum (1 mm)
Environmental Limits
Operating
Temperature
0-55°C (32 to 131°F), 5 to 95% RH
Storage Temperature
-20 to 85°C (-4 to 185°F), 5 to 95%RH
Regulatory Approvals
EMC
FCC Class A, CE Class A
Safety
UL, CUL, TUV
