Moxa Technologies NPort Express DE-211 Manual

NPort Express DE-211
Hardware Installation Guide
For DE-211
Edition 9.1, September 2017
www.moxa.com/product
© 2017 Moxa Inc. All rights reserved.

NPort Express DE-211
Hardware Installation Guide
The software described in this manual is furnished under a license
agreement and may be used only in accordance with the terms of that
agreement.
Copyright Notice
© 2017 Moxa Inc. All rights reserved.
Trademarks
The MOXA logo is a registered trademark of Moxa Inc.
All other trademarks or registered marks in this manual belong to their
respective manufacturers.
Disclaimer
Information in this document is subject to change without notice and does
not represent a commitment on the part of Moxa.
Moxa provides this document as is, without warranty of any kind, either
expressed or implied, including, but not limited to, its particular purpose.
Moxa reserves the right to make improvements and/or changes to this
manual, or to the products and/or the programs described in this manual,
at any time.
Information provided in this manual is intended to be accurate and
reliable. However, Moxa assumes no responsibility for its use, or for any
infringements on the rights of third parties that may result from its use.
This product might include unintentional technical or typographical errors.
Changes are periodically made to the information herein to correct such
errors, and these changes are incorporated into new editions of the
publication.

Technical Support Contact Information
www.moxa.com/support
Moxa Americas
Toll
-free: 1-888-669-2872
Tel:
[phone]
Fax:
[phone]
Moxa China (Shanghai
office)
Toll
-free: 800-820-5036
Tel:
[phone]
Fax: [phone]
Moxa Europe
Tel:
[phone]
Fax: [phone]
Moxa Asia-Pacific
Tel:
[phone]
Fax: [phone]

Table of Contents
1. Introduction ............................................................. 6
Features .................................................................... 7
Product Specifications .................................................. 8
Package Checklist........................................................ 9
Front/Top/Rear/Bottom Panel Views .............................10
2. Overview................................................................ 11
LED Indicators ...........................................................12
Housing ....................................................................13
DIN Rail..................................................................13
Wall Mount..............................................................14
3. Serial Installation .................................................. 15
DIP Switch Settings ....................................................16
Female DB25 Connector Pinout ....................................17
RS-232 Wiring ...........................................................17
RS-422 Wiring ...........................................................19
Using a DB25 Connector ...........................................19
Using the Optional Terminal Block..............................20
RS-485 Wiring ...........................................................20
Using a DB25 Connector ...........................................20
Using the Optional Terminal Block..............................21
Enabling a Termination Resistor ...................................23
Enabling the Built-In 120 Ω Terminator ......................23
Enabling a User-Supplied Terminator .........................24
4. Ethernet Installation .............................................. 25
Connecting to the Ethernet Port ...................................26
Connecting to a Hub or Switch ..................................26
Connecting to a PC ..................................................26
5. Power Connection .................................................. 27
Using the Power Adapter .............................................28
Using Power Over Serial..............................................28
Power Status Check....................................................31
A. Return Procedure ................................................... 32

B. Compliance Notice.................................................. 33

1
1. Introduction
Welcome to Moxa NPort Express, a compact palm-sized communications
device that allows you to control RS-232/422/485 serial devices over a
TCP/IP Ethernet.
The following topics are covered in this chapter:
Features

Product Specifications

Package Checklist
Front/Top/Rear/Bottom Panel Views

NPort Express DE-211 Introduction
7
NPort Express DE-211 provides a data communications solution for
connecting Windows and Linux hosts to asynchronous serial devices over
a TCP/IP Ethernet. You may connect your Windows host to a native
RS-232/422/485 serial port, or your PC-based Linux host to a real tty port,
through a TCP/IP Ethernet. With one asynchronous serial port connection
on one end, and a 10 Mbps Ethernet connection on the other, NPort
Express allows virtually any serial device to attach to a network. NPort
Express works like an add-on single-port serial board to your PC server,
but with one major advantage—the TCP/IP network. Since the host
communicates with the COM port on NPort Express over a TCP/IP network,
you are able to control your asynchronous serial device from virtually any
location.
Although it connects through the virtual link of the Ethernet, the port on
NPort Express is recognized as a real COM port by Windows or a real tty
port by Linux. NPort Express provides both the basic transmit/receive
data functions, as well as RTS, CTS, DTR, DSR, and DCD control signals.
NPort Express can be used with your existing applications that support
serial communication, and come with a utility program providing a simple
step-by-step installation procedure and a maintenance wizard that gives
you easy access to your asynchronous device.
Features
•3-in-1 RS-232/422/485 interface and 10 Mbps Ethernet
•Supports 4- and 2-wire RS-485 with patented ADDC™ and built-in
terminator
•Supports industrial 12/24 VDC power input and optional Power over
Serial
•Terminal block accessory for easy RS-422/485 serial wiring
•Supports MAC based IP configuration
•Supports configuration store and copy for easy deployment
•Supports Windows Real COM driver and Linux real TTY driver
•Supports Driver Mode, TCP Server/Client, UDP Server/Client,
Ethernet Modem, Pair Connection

NPort Express DE-211 Introduction
8
Product Specifications
Interface
LAN: 10BaseT
Serial: RS-232/422/485 (DIP switch selectable)
Number of Ports: 1
Signals:
RS-232: TxD, RxD, RTS, CTS,DTR, DSR, DCD, GND
RS-422: TxD+/-, RxD+/-, GND
RS-485 2-wire: Data+/-, GND
RS-485 4-wire: TxD+/-, RxD+/-, GND
Performance
Speed: 150 bps to 230.4 Kbps
Configuration
Parity: None, Even, Odd, Space, Mark
Data Bits: 5, 6, 7, 8
Stop Bits: 1, 1.5, 2
OS Supported
Real COM drivers for: Windows
95/98/ME/NT/2000/XP/2003/Vista/2008/7/XP x64/2003 x64/Vista
x64/2008 x64/7 x64
Real TTY driver for: Linux 2.4.x, 2.6.x kernel
Fixed TTY drivers for: SCO Unix, SCO OpenServer 5,OpenServer 6,
UnixWare 7, UnixWare 2.1, SVR4.2, QNX 4.25, QNX 6, Solaris 10,
FreeBSD 5, FreeBSD 6
Operation Modes
Driver Mode, TCP Server, TCP Client, UDP Server/Client, Ethernet
Modem, Pair Connection
Management
Serial console
Telnet console
NPort Configurator for Windows/Linux
Real COM Installer for Windows
Monitor Utility for Windows
Firmware upgrade function supported
Power and Environment
Power requirements: DC 12V to 30V
150 mA (max.) at 12V
92 mA (max.) at 24
Operating temp.: 0 – 55◦C
Operating humidity: 5 – 95% RH
Dimensions (W×D×H): 90 × 100.4 × 22 mm (with ears),

NPort Express DE-211 Introduction
9
67 × 100.4 × 22 mm (without ears)
Surge protection: 15 KV ESD (RS-232), 12KV ESD (RS-422/485)
Magnetic isolation: 1.5 KV for Ethernet
Regulatory approvals: EMC: CE Class B, FCC Class B
Safety: UL 60950-1, EN 60950-1
Package Checklist
•1 NPort Express DE-211
•Quick Installation Guide
•NPort Documentation & Software CD
•Product Warranty Booklet
Optional Accessories
NP21101 30 cm DB25 male to DB9 female RS-232 cable
NP21102 30 cm DB25 male to DB9 male RS-232 cable
NP21103 DB25 terminal block kit for RS-422/485
DK-35A For 35 mm DIN Rail; includes 4 screws

NPort Express DE-211 Introduction
10
Front/Top/Rear/Bottom Panel Views
1.
Female DB25 serial port
2. DIN Rail screw holes
3. Wall mount screw holes
4. RJ45 10BaseT Ethernet
port
5. Reset button—press
continuously for
a. 3 sec to erase
password
After3 sec, the
ready LED will flash
on/off every half
second. Rele
ase the
reset
button at this
time to erase
password.
b. 10 sec to load
factory defaults
After 10 sec, the
ready LED will flash
on/off every fifth of
a second. Release
the reset button at
this time to load
factory defaults.
6. DIP Switches
7. Power input
8. Rubber base pads

2
2. Overview
The following topics are covered in this chapter:
LED Indicators

Housing
DIN Rail
Wall Mount

NPort Express DE-211 Overview
12
LED Indicators
NPort Express’s top panel contains five LED indicators, as described in the
following table.
LED Name
LED Color
LED Function
PWR
red
Power is on.
off
Power is off, or power error condition exists.
Link
orange
10 Mbps Ethernet connection.
off
Ethernet cable is disconnected, or has a
short.
Ready
green
NPort Server system is ready.
blinking
NPort is requesting an IP address from the
DHCP or BootP server. After receiving the
IP, the LED will stop blinking.
Note: The LED will also blink when you press
the reset button; see page 1-5 for details.
off
NPort Server has malfunctioned.
Serial Tx
green
Serial data is being transmitted.
off
Serial data is not being transmitted.
Serial Rx
orange
Serial data is being received.
off
Serial data is not being received.

NPort Express DE-211 Overview
13
Housing
DIN Rail
For many industrial applications, you will find it convenient to use the DIN
Rail attachments, as shown below.
STEP 1: Use 2 screws per ear to attach DIN Rail mounts to each of NPort
Express’s two ears.
⇒
STEP 2: Insert the top of the DIN Rail
into slot A of the DIN Rail mount.
STEP 3: Push the bottom of NPort
Express so that the bottom of the
DIN Rail snaps into slot B of the
DIN Rail mount.
NOTE
The Din Rail mounting kit is an optional accessory.
To remove NPort Express from the DIN Rail, simply reverse Steps 2 and 3
above by grasping the bottom of the NPort Express unit with both hands,
and then using your fingers to pull down slightly on the DIN Rail mounts
at slot B. This releases the bottom of the DIN Rail from the DIN Rail
mount.

NPort Express DE-211 Overview
14
Wall Mount
For many industrial applications, you will find it convenient to mount
NPort Express on the wall, using two screws, as indicated below.
STEP 1: Screw two screws, separated by 7.8 cm, into the wall. The heads
of the screws should be no greater than 6.5 mm in diameter, and the
shafts should be no greater than 3 mm in diameter. Do not screw the
screws in all the way—leave a space of about 2 mm to allow room for
sliding the NPort Express unit’s ears between the wall and the screws.
STEP 2: Insert the two screw heads
through the large parts of the
keyhole shaped apertures, and then
slide NPort Express downwards, as
indicated.
STEP 3: For added stability, simply
tighten the two screws.
To remove NPort Express from the wall mount, simply reverse Steps 2
and 3.

3
3. Serial Installation
The following topics are covered in this chapter:
DIP Switch Settings

Female DB25 Connector Pinout

RS-232 Wiring

RS-422 Wiring
Using a DB25 Connector
Using the Optional Terminal Block

RS-485 Wiring
Using a DB25 Connector
Using the Optional Terminal Block

Enabling a Termination Resistor
Enabling the Built-In 120 ΩTerminator
Enabling a User-Supplied Terminator

NPort Express DE-211 Serial Installation
16
DIP Switch Settings
The top panel of NPort Express contains the following table, which
describes how to set up the serial port using the four DIP switches located
on NPort
SW1
Serial
Connection
SW2
SW3
SW4
Serial Interface Mode
OFF
OFF
OFF
RS-232
ON RS-232
Console
OFF
ON
ON
RS-422
ON
OFF
ON
4-wire RS-485 by RTS
OFF Data Comm
ON
ON
ON
4-wire RS-485 by ADDC
ON
OFF
OFF
2-wire RS-485 by RTS
ON
ON
OFF
2-wire RS-485 by ADDC
Switch SW1 controls the function of the serial port (ON, or up, for RS-232
Console connection, and down for Data Communication, such as when
NPort Express is connected to your serial device). Note that after
changing the setting of SW1, NPort Express will reboot to initialize the
new setting. You must wait a few seconds for the green Ready light to
blink off and then on again, indicating that the function of the serial port
has been changed.
Switches SW2, SW3, and SW4 control the serial port’s data
communication Interface Mode. (Note that RTS stands for Ready To Send
and ADDC stands for Automatic Data Direction Control.)
Keep the following points in mind when setting the DIP switches.
RS-232 Console
To use the serial port as a console connection, such as when using MOXA
PComm Terminal Emulator or HyperTerminal, set SW1 to the ON position.
Telnet Connection
Some setup procedures can be carried out through a Telnet connection,
during which data is transmitted through NPort Express’s Ethernet port.
However, you must set SW1 to the OFF position to establish a Telnet
connection.

NPort Express DE-211 Serial Installation
17
Female DB25 Connector Pinout
* This pin is reserved debugging. Connections this pin yourself could
result in irreparable damage to your device.
RS-232 Wiring
* NP21101 is an optional accessory for DE-211

NPort Express DE-211 Serial Installation
18
* NP21102 is an optional accessory for DE-211
NOTE
The following pinout diagram shows how to use a DB25 (M) to
DB25 (F) cable
NOTE
In Ethernet Modem Mode, you need a special cable
—
shown in the
following pinout diagram—to simulate a DCD signal.

NPort Express DE-211 Serial Installation
19
RS-422 Wiring
Using a DB25 Connector

NPort Express DE-211 Serial Installation
20
Using the Optional Terminal Block
NOTE
Use a flathead screwdriver to tighten the two attachment screws
that connect the terminal block to NPort Express.
RS-485 Wiring
Using a DB25 Connector
