MDS-G4000-4XGS/
MDS-G4000-L3-4XGS Series
Quick Installation Guide
Version 1.1, September 2022
Technical Support Contact Information
www.moxa.com/support

2022 Moxa Inc. All rights reserved.

- 2 -
Package Checklist
Moxa’s MDS-G4000-4XGS/MDS-G4000-L3-4XGS Series industrial
modular DIN-rail switch is shipped with the following items. If any of
these items are missing or damaged, please contact your customer
service representative for assistance.
•1 MDS-G4000-4XGS or MDS-G4000-L3-4XGS switch
•Pre-installed DIN-rail kit
•2 screws (M4 x 8 mm & M3 x 8 mm)
•Quick installation guide (printed)
•Substance Disclosure Table
•Product Certificate of Quality Inspection (Simplified Chinese)
•Product Notices (Simplified Chinese)
•Warranty card
NOTE
You can find information and software downloads on the
relevant p
roduct pages located on Moxa’s website:
www.moxa.com
Default Settings
•IP address: 192.168.127.253
•Subnet mask: 255.255.255.0
•Username: admin
•Password: moxa
Panel Layouts
1. System status LEDs (from left to right, top to bottom)
STATE, FAULT, MASTER/HEAD, COUPLER/TAIL, and SYNC LED
indicators
2. USB storage port
3. Module Status
4. Switch and Control Module slot 1 (embedded)
5. Ethernet module slot 2
6. Ethernet module slot 3
7. External power input status from EPS
8. Ethernet module slot 4
9. Ethernet module slot 5
10. Ethernet module slot 6
11. Ethernet module slot 7

- 3 -
12. External Power Supply (EPS) input for PoE
13. Redundant power module slot 1
14. Redundant power module slot 2
15. RS-232 console port with RJ45 interface
16. Reset button (Pin hole 0.9 mm diameter)
17. Relay output and Digital Input port
18. Relay output
19. Power input
20. Grounding screw
Dimensions
MDS-G4012-4XGS and MDS-G4012-L3-4XGS Series
MDS-G4020-4XGS and MDS-G4020-L3-4XGS Series
MDS-G4028-4XGS and MDS-G4028-L3-4XGS Series
Unit: mm (inch)
Ethernet Modules (Hardware Rev.2.0.0 and above)
LM-7000H-4GTX
LM-7000H-4GSFP
LM-7000H-4GPoE
LM-7000H-4TX

- 4 -
LM-7000H-4PoE
Power Modules (Hardware Rev.2.1.0 and above)
PWR-HV-P48-A
PWR-LV-P48-A
PWR-HV-NP
PWR-LV-NP
DIN-rail Dimension and Instructions
Unit: mm (inch)
1. Insert the upper lip of the DIN rail into the DIN-rail mounting kit.
2. Press the device towards the DIN rail until it snaps into place.
3. Pull down the two latches one by one to release the DIN-rail kit
and lift up to remove the device from the DIN rail.
NOTE
The DIN-rail must use TS35 (15 mm) specification for the MDS-
G4000-4XGS/MDS-G4000-L3-4XGS Series.

- 5 -
Wall Mount Dimension and Instructions (Optional:
WK-112-01)
NOTE
The wall-mount kit is certified for Hazardous Location usage.
Mounting the switch to a wall requires four screws per
kit
(there are two kits). The heads of the screws
should be between 6.0 to 9.0 mm in diameter, and the
diameter of screw thread should be between 3.5 to 4
mm, as shown in the figure on the right. Use the
switch with the wall
-mounting kit attached as a guide
to mark the correct locations of the eight screws.
MDS-G4012-4XGS and MDS-G4012-L3-4XGS Series
MDS-G4020-4XGS and MDS-G4020-L3-4XGS Series
MDS-G4028-4XGS and MDS-G4028-L3-4XGS Series
Please note, there are two wall-mount kit screws for the MDS Series
(M4 x 8 mm and M3 x 6 mm).

- 6 -
Rack-mounting Kit Dimensions and Instructions
(Optional: RK-3U-02)
Please refer to the RK-3U-02 Series QIG.
Matters That Require Attention
1. Elevated Operating Temperature:If installed in a closed or
multi-unit rack assembly, the operating ambient temperature of
the rack environment may be greater than room temperature.
Therefore, consideration should be given to installing the
equipment in an environment compatible with the maximum
ambient temperature (Tma) specified by the manufacturer.
NOTE
In order to ensure reliable operations, please make sure the
operating temp
erature of the environment does not exceed the
spec. When mounting a rack
-mounted switch with other
operating units in a cabinet without forced ventilation, it is
recommended that 1U of space is reserved between each rack
-
mounted switch and/or device.
2. Required Air Flow: Installation of the equipment in a rack should
be such that the amount of air flow required for safe operation of
the equipment is not compromised.
3. Mechanical Loading: Mounting of the equipment in the rack
should be such that a hazardous condition is not achieved due to
uneven mechanical loading.
4. Circuit Overloading: Consideration should be given to the
connection of the equipment to the supply circuit and the effect
that overloading of the circuits might have on overcurrent
protection and supply wiring. Appropriate consideration of
equipment nameplate ratings should be used when addressing this
concern.
5. Reliable Grounding: Reliable grounding of rack-mounted
equipment should be maintained. Particular attention should be
given to supply connections other than direct connections to the
branch circuit (e.g. use of power strips).
ATTENTION
Safety First
!
Be sure to disconnect the power cord before installing and/or
wiring your Ethernet Switch. Calculate the maximum
possible
current in each power wire and common wire. Observe all
electrical codes dictating the maximum current allowable for
each wire size. If the current goes above the maximum ratings,
the wiring could overheat,
which can cause serious damage to
your equipment.
WARNING
When end users are
using Optical SFP Communications
modules, these must be limited to Laser Class 1.

- 7 -
Connecting the Power Inputs
NOTE
The required power module depends on the choice of LM-7000H
module. Refer to the following power/module combination
requirements.
•
LM-7000H non-PoE modules:
Any power module
•
LM-7000H PoE modules:
PWR-HV-P48-A, PWR-LV-P48-A only
The MDS-G4000-4XGS/MDS-G4000-L3-4XGS Series supports 4 types of
power supply:
•PWR-HV-P48-A: one 110/220 VAC/VDC (90 to 264 VAC, 88 to 300
VDC), one 48 VDC PoE power input for PoE+ ports.
•PWR-LV-P48-A: one 24/48 VDC (18 to 72 VDC), one 48 VDC PoE
power input for PoE+ ports.
•PWR-HV-NP: one 110/220 VAC/VDC (90 to 264 VAC, 88 to 300
VDC) power input.
•PWR-LV-NP: one 24/48 VDC (18 to 72 VDC) power input.
For the PWR-HV-P48-A, the 110/220 VAC/VDC power supplies provide
power to the switch. Separate 48 VDC power supplies are required to
provide power to all PoE+ ports (50 to 57 VDC is recommended for
IEEE 802.3at devices. The maximum PoE output from an external
power supply is 720 W when the operating temperature is under 60°C;
360 W when the operating temperature is under 75°C.)
For the PWR-LV-P48-A models, the 24/48 VDC power supplies provide
power to the switch. Separate 48 VDC power supplies are required to
provide power to all PoE+ ports (50 to 57 VDC is recommended for
IEEE 802.3at devices. The maximum PoE output from an external
power supply is 720 W when the operating temperature is under 60°C;
360 W when the operating temperature is under 75°C.)
For the PWR-HV-NP, the 110/220 VAC/VDC power supplies provide
power to the switch. For the PWR-LV-NP, the 24/48 VDC power supplies
provide power to the switch.
Power Terminal Blocks
The connections for the power input are on the power modules.

- 8 -
PWR-HV-P48-A/PWR-HV-NP
Step 1: Insert the neutral/line (L/N/Ground) AC wires into the
terminals.
Step 2: Insert the terminal block connector into the terminal block
receptor.
PWR-LV-P48-A/PWR-LV-NP
Step 1: Insert the negative/positive (-/+) DC wires into the terminals.
Step 2: Insert the terminal block connector prongs into the terminal
block receptor.
PoE Power Terminal Blocks
Step 1: Insert the negative/positive DC wires into the -/+ terminals,
respectively.
Step 2: Insert the terminal block connector prongs into the terminal
block receptor.
NOTE
In order to have higher levels of protection against surge, it is
suggested to install
a surge protector in front of the power
input of the PoE powered device so that it is suitable for use in
IEC 61850 conditions.
WARNING
When wiring the power input, we suggest using the cable type -
AWG
(American Wire Gauge) 16 (1.31 mm2) and the
corresponding pin type cable terminals. The rated temperature
of the wiring should be at least 105°C and the wire type should
be CU.

- 9 -
NOTE
When two power units are installed on the MDS-G4000-
4XGS/MDS
-G4000-L3-4XGS Series
switch, both power units will
be activated simultaneously, which will enab
le power
redundancy.
NOTE
The reverse power input connection will not activate the device
or PoE input. In addition, the PoE will only activate when the
external power supply is installed on the same power unit.
Wiring the Relay Contact
Each power module has one relay output that can provide two types of
relay output. Refer to the table below for detailed information.
The relay contact is used to detect user-configured events. Two wires
are attached to the relay pins with normally close and normally open
options.
FAULT: The relay contact of the 3-pin terminal block connector is used
to detect user-configured events. The module provides normally open
and normally closed circuits depending on what the user chooses. For
pin definitions, refer to the table below.
Relay Connection
Power Off
Boot up Ready
Event Trigger
NO and COM
Closed Circuit
Open Circuit
Closed Circuit
NC and COM
Open Circuit
Closed Circuit
Open Circuit
WARNING
When wiring the relay contact, we suggest using the cable type
-
AWG (American Wire Gauge) 16-21 (1.31-0.412 mm2) and
the corresponding pin type
cable terminals. The rated
temperature of the wiring should be at least 105°C
and the wire
type should be CU.
Digital Input/Output
Digital Output
1 relay output with a current carrying capacity of 2 A @ 30 VDC.
Digital Input
1 digital output with the same ground, but electrically isolated from the
electronics.
•+13 to +30 V for state 1
•-30 to +1 V for state 0
•Max. input current: 8 mA

- 10 -
WARNING
When wiring the Digital Input/Output contact, we suggest using
the cable
type - AWG (American Wire Gauge) 16-28 (1.31-
0.081 mm
2) and the corresponding pin type cable terminals.
The rated temperature of the wiring should be at least 105°C
and the wire type should be CU.
Installing and Removing the Ethernet Modules
The Ethernet modules are hot-swappable for the same module type.
You can mount or remove the Ethernet module while the device is
operating.
NOTE
1.
When performing a cold start, you cannot remove and
insert a module before the device has fully booted up as
this will cause the module to fail initialization.
2.
The default module is 4XGS. If this is the first time
mounting a 4TX or SFP module, please reboot the switch
after inserting it. The hot-swappable function, as defined
above, will work after the device is rebooted for the first
time.
3.
When swapping out a slotted module with a different type
of module, it is recommended to reconfigure the settings
or
reset the device to factory default settings after rebooting
the switch.
The installation procedure is as follows:
1. Insert the Ethernet module straight into the slot
2. Fasten the module to the device by tightening the 2 screws. The
tightening torque is 3.5 kgf-cm (0.35 Nm)
The removal procedure is as follows:
1. Loosen the 2 screws of the module
2. Pull the module out of the slot
3. Insert the dummy module into the slot in order to have better
protection against dust and EMI
4. Fasten the dummy module using the 2 screws. The tightening
torque is 4 kgf-cm (0.4 Nm)
Installing and Removing the Power Modules
The power supply units are hot-swappable when both power modules
are installed. You can mount or remove the power supply units while
the device is operating.
The installation procedure is as follows:
1. Insert the power unit straight into the slot
2. Fasten the unit to the device by tightening the 2 screws. The
tightening torque is 3.5 kgf-cm (0.35 Nm)
The removal procedure is as follows:
1. Loosen the 2 screws of the module
2. Pull the module out of the slot

- 11 -
3. Insert the dummy module into the slot in order to have better
protection against dust and EMI.
4. Fasten the dummy module using the 2 screws. The tightening
torque is 4 kgf-cm (0.4 Nm)
NOTE
If one of the modules is removed from the device, it is
recommended
to insert a dummy module in order to provide
better protection against dust and EMI.
Grounding the Moxa Industrial DIN-rail Switch
Grounding and wire routing help limit the effects of noise due to
electromagnetic interference (EMI). Run the ground connection from
the ground screw to the grounding surface prior to connecting devices.
ATTENTION
T
his product is intended to be mounted to a well-grounded
mounting surface, such as a metal panel. We use the
green-
and
-yellow cable type AWG (American Wire Gauge) min. 16
(1.31 mm
2
) for grounding.
NOTE
The PoE power connection is for indoor and local area network
usage only.
NOTE
Using a shielded cable achieves better electromagnetic
resistance.
RS-232 with RJ45 Interface Console Connection
The switch has an RS-232 serial console with an RJ45 interface. Please
use a Moxa 9-pin female console cable to connect to your PC's COM
port (or via USB-to-Serial converters or hubs). You can then use a
console terminal program, such as Moxa’s PComm Terminal Emulator,
to access the console configuration utility of the switch.
RS-232 Setup:
•Baud rate: 115,200
•Data Bits: 8
•Parity: None
•Stop Bits: 1
•Terminal Type: VT100
USB Storage Connection
Use Moxa’s ABC-02-USB automatic backup configurator to connect to
the USB storage port (Type A connector; see the diagram below for
pinout assignments) to perform configuration backup, firmware
upgrade, or system log file backup.
Pin
Description
1
VCC (+5V)
2
D- (Data-)

- 12 -
3
D+ (Data+)
4
GND (Ground)
The Reset Button (diameter 0.9 mm)
The reset button can perform two functions. One is to reset the switch
to factory default settings and the other is to reboot the switch if the
button has been depressed and release immediately.
Resetting to Factory Default Settings
Depress the Reset button for five seconds to load the factory default
settings. Use a pointed object, such as a straightened paper clip or
needle (the diameter must not exceed 0.9 mm), to depress the Reset
button. When you do so, the STATE LED will start to blink about four
times per second. Continue to depress the STATE LED until it begins
blinking more rapidly; this indicates that the button has been depressed
for five seconds and you can release the Reset button to load factory
default settings.
NOTE
Do NOT power off the switch when loading default settings.
LED Indicators
The function of each LED is described in the table below.
LED
Color
State
Description
System LEDs
STA
(STATE)
Green
On
Normal operation.
Blinking
The system is booting up.
Off
N/A
Red
On
The system initialization has failed.
FLT
(FAULT) Red
On
1. Switch failed to initialize, or
2. EEPROM information error.
Blinking
The switch boots up and the
firmware loads to memory.
Off
The system is operating normally.
M/H
(MSTR/
HEAD)
Green
On The switch is the Master/Head of the
Turbo Ring/Turbo Chain.
Blinking
The switch is the Ring Master/Head
of the Turbo Ring/Turbo Chain and
the Turbo Ring/Turbo Chain is
broken.
Off
The switch is not the Master/Head of
this Turbo Ring/Turbo Chain.
C/T
(CPLR/TAIL) Green
On
1. The switch enables the coupling
function to form a backup path,
or
2. The switch is the tail of the
Turbo
Chain.
Blinking
This is the switch that enables Turbo
Chain, but the Turbo Chain function
is not working.
Off
When the switch disables the
coupling or tail role of the Turbo
Chain.

- 13 -
LED
Color
State
Description
SYNC
Amber
On
The PTP function is enabled.
Blinking
The switch is receiving sync packets.
Off
The PTP function is disabled.
Green On The PTP function has successfully
converged.
System LEDs
(Except
PWR)
Green/
Amber/
Red
Blinking
The switch is being
discovered/located by the locator
function. The System LED includes
the STA, FLT, M/H, C/T, and SYNC
LEDs.
SWC-4XGSFP
LED
Color
State
Description
MS
(Module
State)
Green
On
Normal operation.
Blinking
The module is booting up.
Off
The module is out of service.
Red On
1. The module initialization has
failed, or
2.
A module designed for a different
model was inserted.
SFP+
(10 GbE)
Green
On The port is active and is linked at 10
Gbps.
Blinking
The port’s data is being transmitted
at 10 Gbps.
Off
The port is inactive or the link is
down.
Amber
On When the port is active and is linked
at 1000 Mbps.
Blinking
The port’s data is being transmitted
at 1000 Mbps.
Off
The port is inactive or the link is
down.

- 14 -
LM-7000H-4GTX/LM-7000H-4GSFP/LM-7000H-4TX
LED
Color
State
Description
MS
(Module
State)
Green
On
Normal operation.
Blinking
The module is booting up.
Off
The module is out of service.
Red On
1. The module initialization has
failed, or
2.
A module designed for a different
model was inserted.
Copper
(10/100
Mbps)
Green
On
The port is active and is linked at 100
Mbps.
Blinking The port’s data is being transmitted
at 100 Mbps.
Off
The port is inactive or the link is
down.
Amber
On
The port is active and is linked at 10
Mbps.
Blinking The port’s data is being transmitted
at 10 Mbps.
Off
The port is inactive or the link is
down.
Copper
(10/100/
1000 Mbps)
Green
On
The port is active and is linked at
1000 Mbps.
Blinking The port’s data is being transmitted
at 1000 Mbps.
Off
When the port is inactive or the link
is down.
Amber
On
The port is active and is linked at
10/100 Mbps.
Blinking
When the port’s data is being
transmitted at 10/100 Mbps.
Off The port is inactive or the link is
down.
SFP
(100/1000
Mbps)
Green
On
The port is active and is linked at
1000 Mbps.
Blinking
The port’s data is being transmitted
at 1000 Mbps.
Off The port is inactive or the link is
down.
Amber
On
The port is active and is linked at 100
Mbps.
Blinking
The port’s data is being transmitted
at 100 Mbps.
Off The port is inactive or the link is
down.

- 15 -
LM-7000H-4GPoE/LM-7000H-4PoE
LED
Color
State
Description
MS
(Module State)
Green
On
Normal operation.
Blinking
The module is booting up.
Off
This module is out of service.
Red On
1. The module failed to initialize.
2. A user inserted a module designed
for a different model.
3. When performing a cold start, the
module was removed and inserted
before initialization was complete.
EPS
(External Power
Supply for PoE
module)
Amber
On
Normal operation.
Off No external power supply for PoE.
Copper
(10/100
Mbps)
Green
On
When the port is active and links on
at 100 Mbps.
Blinking
When the port’s data is being
transmitted at 100 Mbps.
Off
When the port is inactive or link
down.
Amber
On
When the port is active and links on
at 10 Mbps.
Blinking
When the port’s data is being
transmitted at 10 Mbps.
Off When the port is inactive or link
down.
Copper
(10/100/
1000Mbps)
Green
On
When the port is active and links on
at 1,000 Mbps.
Blinking
When the port’s data is being
transmitted at 1,000 Mbps.
Off When the port is inactive or link
down.
Amber
On
When the port is active and links on
at 10/100Mbps.
Blinking
When the port’s data is being
transmitted at 10/100 Mbps.
Off When the port is inactive or link
down.
PoE/PoE+
Green
On
When the port is connected to an
IEEE 802.3at powered device (PD).
Off
1. When power is not being supplied
to a powered device (PD), or
2. The port is not connected to an
IEEE 802.3at standard PD.
Amber
On
When the port is connected to an
IEEE 802.3af powered device (PD).
Blinking
The PoE power has been shut off
because of low power budget.
Red
On
Powered device (PD) detection
failure.
Blinking
Over current or short circuit on the
powered Device (PD) was detected.

- 16 -
PWR-HV-P48-A/PWR-LV-P48-A
LED
Color
State
Description
EPS (External
Power Supply) Amber
On External power is being supplied to
the module's EPS input.
Off
No external power supply.
PWR Amber
On Power is being supplied to the
module's power input.
Off
Power is not being supplied to the
module's power input.
PWR-HV-NP/PWR-LV-NP
LED
Color
State
Description
PWR Amber
On Power is being supplied to the
module's power input.
Off
Power is not being supplied to the
module's power input.
Specifications
Interface
10 GbE Ethernet
4-ports 10 GbE SFP+ slots
Gigabit Ethernet
Up to 24 ports
Console Port
RS-232 console with an RJ45 interface
LED Indicators
PWR, EPS, STATE, SYNC, FAULT, MSTR/HEAD,
CPLR/TAIL
Relay Output
2 A @ 30 VDC
Power Requirements
Input Voltage
PWR-HV-P48–A: 110/220 VDC, 110 VAC, 60 HZ,
220 VAC, 50 Hz, PoE: 48 VDC
PWR-LV-P48–A: 24/48 VDC, PoE: 48 VDC
PWR-HV-NP: 110/220 VDC, 110 VAC, 60 HZ, 220
VAC, 50 Hz
PWR-LV-NP: 24/48 VDC
Operating
Voltage
PWR-HV-P48-A: 88 to 300 VDC, 90 to 264 VAC, 47
to 63 Hz; PoE: 46 to 57 VDC
PWR-LV-P48-A: 18 to 72 VDC; PoE: 46 to 57 VDC
PWR-HV-NP: 88 to 300 VDC, 90 to 264 VAC, 47 to
63 Hz
PWR-LV-NP: 18 to 72 VDC
Power
Consumption
(without modules
consumption)
When using PWR-HV-P48-A:
110 VDC: 12.43 W
220 VDC: 12.87 W
110 VAC: 13.42 W
220 VAC: 14.08 W
When using PWR-LV-P48-A:
24 VDC: 12.67 W
48 VDC: 13.2 W
Power
Consumption of
module
LM-7000H-4GTX: 3.63 W
LM-7000H-4GPoE: 3.8 W
LM-7000H-4GSFP: 4.8 W
LM-7000H-4TX: 1.85 W
LM-7000H-4PoE: 1.85 W

- 17 -
Input Current
(without modules
consumption)
When using PWR-HV-P48-A/PWR-HV-NP:
110 VDC: 0.11 A
220 VDC: 0.06 A
110 VAC: 0.29 A
220 VAC: 0.18 A
When using PWR-LV-P48-A/PWR-LV-NP:
24 VDC: 0.53 A
48 VDC: 0.28 A
Peak Inrush
Current
PWR-HV-P48-A/PWR-HV-NP:
110 VAC: < 10 A (t > 0.1 ms)
220 VAC: < 20 A (t > 0.1 ms)
PWR-LV-P48-A/PWR-LV-NP:
24 VDC: < 5 A (t > 0.1 ms)
48 VDC: < 10 A (t > 0.1 ms)
Maximum PoE
Power Output per
Port
36 W
Total PoE Power
Budget
Max. 360 W (with one power supply) for total PD
consumption at 48 VDC input for PoE systems
Max. 360 W (with one power supply) for total PD
consumption at 53 to 57 VDC input for PoE+ systems
Max. 720 W (with two power supplies) for total PD
consumption at 48 VDC input for PoE systems
Max. 720 W (with two power supplies) for total PD
consumption at 53 to 57 VDC input for PoE+ systems
Overload Current
Protection
Present
Reverse Polarity
Protection
Present
Physical Characteristics
Ingress
Protection Rating
IP40 (This rating will only be achieved when the relay
output terminal block and all modules are installed.)
Dimensions
MDS-G4012-4XGS/MDS-G4012-L3-4XGS:
197 x 115 x 163.25 mm
212 x 115 x 163.25 mm with dual PWR-HV-P48-A/
PWR-LV-P48-A power modules installed
MDS-G4020-4XGS/MDS-G4020-L3-4XGS:
239 x 115 x 163.25 mm
254 x 115 x 163.25 mm with dual PWR-HV-P48-A/
PWR-LV-P48-A power modules installed
MDS-G4028-4XGS/MDS-G4028-L3-4XGS:
281 x 115 x 163.25 mm
296 x 115 x 163.25 mm with dual PWR-HV-P48-A/
PWR-LV-P48-A power modules installed

- 18 -
Weight
MDS-G4012-4XGS-T/MDS-G4012-L3-4XGS-T Series:
3.03 kg (6.68 lb)
MDS-G4020-4XGS-T/MDS-G4020-L3-4XGS-T Series:
3.40 kg (7.50 lb)
MDS-G4028-4XGS-T/MDS-G4028-L3-4XGS-T Series:
3.79 kg (8.36 lb)
LM-7000H-4GSFP: 0.30 kg (0.66 lb)
LM-7000H-4GTX: 0.24 kg (0.53 lb)
LM-7000H-4GPoE: 0.31 kg (0.69 lb)
LM-7000H-4TX: 0.24 kg (0.53 lb)
LM-7000H-4PoE: 0.31 kg (0.69 lb)
PWR-HV-P48-A: 0.42 kg (0.93 lb)
PWR-LV-P48-A: 0.40 kg (0.88 lb)
PWR-HV-NP/PWR-LV-NP: 0.34 kg (0.75 lb)
Installation
DIN-rail mount: Pre-installed by default
Wall mount: WK-112-01 (with optional kit)
19-inch rack mount: RK-3U-02 (with optional kit)
Environmental Limits
Operating Temp.
-40 to 75°C (-40 to 167°F)
Storage Temp.
-40 to 85°C (-40 to 185°F)
Ambient Relative
Humidity
5 to 95% (non-condensing)
Standards and Certifications
Safety EN 61010-2-201, UL 61010-2-201/62368-1,
IEC 62368-1/60950-1
EMC
EN 55032/35, EN 61000-6-2, EN 61000-6-4
EMI
CISPR 32, FCC Part 15B Class A
EMS IEC 61000-4-2 ESD: Contact: 8 kV; Air: 15 kV
IEC 61000-4-3 RS: 80 MHz to 1 GHz: 20 V/m
IEC 61000-4-4 EFT: Power: 4 kV; Signal: 4 kV
IEC 61000-4-5 Surge: Power 4 kV; Signal: 4 kV
IEC 61000-4-6 CS: 10V
IEC 61000-4-8 PFMF
IEC 61000-4-11 Voltage Dips & Interruptions
Rail Traffic
EN 50121-4
Traffic Control
NEMA TS2
Shock
IEC 60068-2-27
Freefall
IEC 60068-2-31
Vibration
IEC 60068-2-6
Power Substation
IEC 61850-3, IEEE 1613
Warranty
Warranty Period
5 years
Details
See www.moxa.com/warranty
Restricted Access Locations
•
This equipment is intended to be used in Restricted
Access Locations, such as a computer room, with
access limited to service personnel or users who have
been instructed on how to handle the metal chassis of
equipment that is very hot. The location should only be accessible
with a key or through a security system.
•External metal parts of this equipment are extremely hot. Before
touching the equipment, you must take special precautions to
protect your hands and body from serious injury.

- 19 -
ATTENTION
•
This device is an open-type equipment and should be
installed in a suitable enclosure.
•
Please use an optical transceiver (SFP) that complies with
IEC 60825-1, 21 CFR 1040 Section 1040.10 and 1040.11,
classified as Class 1 laser product.
•
If the equipment is used in a manner not specified by the
manufacturer, the protection provided by the equipment
may be impaired.
•
The installation and the safety of any system incorporating
the equipment is the responsibility of the assembler of the
system.
•For any repair or maintenance needs, please contact us.
NOTE
•This device is intended for use indoor and at altitudes up to
2000 meters.
•
Overvoltage category II.
•Pollution degree 2.
