MP-Man XRM-15 User manual

or C m F usto erUse
tN hi Enter below he Serial o. w ch islocated
n O the bottom of the cabinet. Retain this
r or e Info mation f futur reference.
o.Mode N
NSerial o.
XRM-15
STEREO RADIO CASSETTE RECORDER
WITH MP3/CD/CD-R/USB/SD PLAYER
R

PREPARATION FOR USE
Unpacking and Setup
* Carefully remove the unit from the display carton and remove all packing material from the unit itself.
* Remove any descriptive labels that may be found on either the front or top cabinet of the unit. Do not
remove any labels located on either the back or button cabinet of the unit.
1
AUX IN CONNECTIONS WAYS
2
1
2
3
4
5
6
7
8
9
12
13
14
15
16
17
18
19
20
21
22
23
PROG .PROG .
-10/FO L--10/FO L-+10/FO L++10/FO L+
RREEPP..
//
RRAANN..
POWERPOWER
BASSBASS
SD/MM C CARD
USBUSB
10
11
24
25
EN-3
17.REPEAT/RANDOM BUTTON
18.+10/FOL+BUTTON
19.NEXT BUTTON(:)
20.FUNCTION SWITCH
21.TUNING CONTROL
22.OPEN/CLOSE BUTTON
23.CD DOOR
24.USB JACK
25.SD/MMC CARD JACK
26.LEFT/RIGHT SPEAKER BOX
27.FM ANTENNA
28.EXT SPEAKER
29.AC MAINS
1.LCD DISPLAY
2.FM STEREO INDICATOR
3.STANDBY STEREO INDICATOR
4.PLAY/PAUSE/USB BUTTON( )
5.STOP/SD BUTTON
6.-10/FOL-BUTTON
7.BACK BUTTON(9)
8.VOLUME CONTROL
9.BAND SWITCH
10.PHONES JACK
11.AUX IN JACK
12. BASS INDICATOR
13.BASS BUTTON
14.REMOTE SENSOR
15.POWER BUTTON
16.PROGRAM BUTTON
4
;
26 26
27 28
29
EN-2
Power Sources
Using AC Power
Connect the AC power into Standard household wall outlet. For dual voltage version.
Make sure that the AC VOLTAGE SELECTOR is switched to your local voltage.

1.LCD DISPLAY
- show the AM/FM dial frequency
- show the number of tracks
3.STANDBY
4.PLAY/PAUSE/USB BUTTON
- start or pause MP3/CD/USB/SD/MMC
play
- Press and Hold more than 1.5 sec
change CD/USB media.
5.STOP/SD BUTTON
- stop CD/MP3/USB/SD/MMC playback;
erase a CD program.
Press and Hold more than 1.5 sec
Chang USB1.1/MMC(SD)media ( only
USB)
6.-10/FOL-button
7.SEARCH BACK
BACK track selection
- Press and Hold more than 1.5 sec BACK
Search intra track
8.VOLUME
- adjust volume level.
9.BAND SELECTOR (AM·FM·FM ST.)
- select AM/FM/FM ST. Waveband
10.STEREO HEADPHONE JACK
- 3.5 mm stereo headphone jack.
11.AUX JACK
-Push FUNC button , select MP3/AUX Station.
play 、 、
Mp3 DISCMAN WALKMAN AUX
INSERT When no disc.
12.BASS INDICATOR
13.BASS BUTTON
14.REMOTE SENSOR
15.POWER BUTTON
-Press POWER button on
16.PROGRAM
-program and review programmed
track numbers.
17.REPEAT/RANDOM BUTTON
- repeata track/CD/MP3/USB/SD
/MMC/program
Random button
- play CD/MP3 tracks in random orde
18.+ 10/FOL+button
EN-5
19.SEARCH NEXT
NEXT track selection
- Press and Hold more than 1.5 sec
Forward Search intra track
20.FUNCTION SELECT
- select source of sound MP3/AUX or
RADIO.
21.TUNING CONTROL
- select AM/FM/FM ST. Stations
22.CD DOOR OPEN BUTTON
- press here to open/close the CD door.
23.CD DOOR
24.USB JACK
To listen to your USB flash memory
stick with Mp3 music files.
25.SD/MMC CARD JACK
- To listen to your SD/MMC Card
with Mp3 music files.
26.LEFT&RIGHT SPEAKER BOXES
27.FM ANTENNA
- to improve FM reception
28.SPEAKER WIRE CONNECTOR(L/R)
29.AC MAINS
- inlet for power cord
1
3
2
PROGRA M
REPEAT/RAN DO M
10/FOL-
STOP/S D
10/FOL+
4
6
5
7
8
/
/
/USB
1.Program button
2. -10/FOL- button
3. +10/FOL+ button
4.Play/pause( )/usb
5.Back( )/search( )
6.Next( )/search( )
7.Stop/sd button
8.Repeat/Random button
9.volume - button
10.volume +button
3
REMOTE CONTROL HANDSET (See )
3
VOL-VO L+
10
9
2.FM STEREO INDICATOR
- show the FM stereo indicator
110
~~
The remote control buttons function is the same
as the button of CD/MP3/USB/SD section
Select the CD/MP3 tracks by (+ 10)/ (- 10) button.
EN-4

EN-11
EN-10
Insert a CD,MP3, CD-R.
No CD/MP3 inserted
The CD/MP3 skips tracks
CD/MP3 damaged or dirty
Replace or clean CD/MP3
- CD-R、CD-RW is blank or the disc is
not finalized
Use a finalized CD-R、CD-RW
CD/MP3/USB/SD playback does not work
CD/MP3/USB/SD badly scratched/dirty
Replace/clean CD/MP3/USB/SD
(see maintenance)
In case of malfunction due to electrostatic
discharge just reset the product(reconnect
of power source may be required)to resume
normal operation.
Note

EN-12
TECHNICAL SPECIFICATIONS
GENERAL
Power Requirement ............................................................230V～50HZ
Power consumption .............................................................AC 15 Watts
Dimensions......................................................Approx.469 mm(L)x 218 mm(W) x 229 mm(H)
Operation temperature.........................................................+5 ℃ - +35℃
RECEIVER SECTION
Receiving Bands...................................................................AM/FM
Tuning Range..........................................................AM:522-1620KHZ
FM:87.5-108MHZ
COMPACT DISC SECTION
Optical Pickup...................................................................... .3-Beam Laser
Frequency Response.............................................................100Hz - 16KH z
AUDIO SECTION
Power output .........................................................................Maximum 3 Watt x 2
Headphone Impedance ............................................................4 ~ 32 Ohms
ACCESSORIES
Instruction Booklet.....................................................................1
Remote control.....................................................................1
For more information please visit our website www.mpmaneurope.com
