MP-Man CSD DV70 User manual

READ THESE INSTRUCTIONS INCLUDED IN THIS IM THOROUGHLY PRIOR TO CONNECTING AND OPERATING.
PLEASE RETAIN THIS MANUAL IN CASE YOU MAY NEED IT FOR FUTURE REFERENCE.
THE ILLUSTRATIONS & GRAPHICS HEREIN ARE FOR REFERENCE ONLY AND SUBJECT TO CHANGE WITHOUT NOTICE.
DVD/CD PLAYER WITH STEREO RADIO
USB PORT & SD/MMC CARD SLOT
AND REMOTE CONTROL
User Manual
WWW.MPMANEUROPE.COM
CSD DV70

1.
2.
3.
4.
5.
7.
8.
9.
10.
11.
12.
13.
15.
16.
17.
18.
19. REPEAT
20. AUDIO
21. DISPLAY
22.
25.
26.
27.
28.
29.
32.
33.
34. POWER ON/OFF BUTTON
POWER INDICATOR
FM STEREO INDICATOR
DISC TRAY OPEN/CLOSE BUTTON
REMOTE SENSOR
SPEAKERS
6. AUDIO IN JACK
MIC JACK
MIC LEVEL CONTROL
USB PORT
SD/MMC CARD SLOT
DISC TRAY
VOLUME CONTROL
PHONES JACK
14. HANDLE
TFT DISPLAY
TUNING CONTROL
FUNCTION SWITCH
MENU BUTTON
BUTTON
BUTTON
BUTTON
BUTTON
23.
24. BUTTON
PLAY/PAUSE BUTTON
BAND SWITCH
TELESCOPIC FM ANTENNA
VIDEO JACK
AUDIO RIGHT JACK
30. AUDIO LEFT JACK
31. BATTERY COMPARTMENT
VOLTAGE SELECTOR (OPTIONAL)
AC SOCKET
STOP/USB/SD/MMC CARD
SKIP DOWN & FAST BACKWARD BUTTON
SKIP UP & FAST FORWARD
Illustration of the Controls/Jacks On the Main Unit
12 34
55
678910
11
12 13 14 15 16
17 19 21 22 24 26
18 20 23 25
27 28 29 30
31 32 33
Illustration of the Keys on the Remote Controller and Their Main Functions
1
2
3
4
5
6
7
820
19
18
17
16
15
14
13
12
11
10
9
1. SCREEN ON/OFF & BRI/COL BUTTON
2. TITLE BUTTON
3. PREV/F.BWD BUTTON
4. NEXT/F.FWD BUTTON
5. NAVIGATION BUTTONS
6. NUMERIC BUTTONS
7. PROGRAM/ANGLE BUTTON
8. MUTE BUTTON
9. OPEN/CLOSE BUTTON
10. SETUP BUTTON
11. MENU BUTTON
12. DISPLAY BUTTON
13. STOP BUTTON
14. OK(PLAY/PAUSE) BUTTON
15. SUBTITLE BUTTON
16. AUDIO BUTTON
17. SEARCH BUTTON
18. REPEAT BUTTON
19. ZOOM/SLOW BUTTON
20. USB/CARD BUTTON
1
34

Basic connection
Ü







It is recommended to be connected to a multi-system TV.
Ensure that this player and other equipment to be
connected to the unit are in the off mode and disconnect
the AC power cords before commencing connection.
Do not block ventilation holes of any piece of the equipment
and arrange them so that air can circulate freely.
Read through the instructions before connecting other
equipment.
Ensure that you observe the color coding when connecting
audio, video cables.
During DVD play, the TV volume may be at a lower level
than during TV broadcasts, etc. If this is the case, adjust
the volume to the desired level.
If the DVD/CD player is connected to the TV through a
video cassette recorder, the picture may not be played back
normally with some DVDs. If this is the case, do not
connect the player via the VCR.
Note:
The mains plug is used as disconnect device, the
disconnect device shall remain readily operable.
To power outlet
AC power cord
To video input connector (yellow)
To audio input connectors (red, white)
Video/audio cable
2
LR
OPERATIONS
PREPARATION
GET STARTED
ADJUST THE VOLUME
MUTE
SKIP AHEAD OR BACK
Power on the TV set and select video input mode.
1. Insert the AC cord to the AC socket of player, and plug the
other end to an applicable wall outlet. Slide the FUNCTION
switch to the DVD/USB/CARD position.
2. Press disc tray OPEN/CLOSE button to open the disc tray.
3. Place a disc onto the disc tray.
4. Press disc tray OPEN/CLOSE button to close the disc tray and
the playback starts automatically.
5. When a menu screen appears on the TV, move the navigation
buttons or press the numeric buttons to select a preferred
track number, then press OK button to start playback.
Adjust the volume to your favorite by rotating the volume
control.
Press MUTE button, the audio output of the main unit will be
shut off; pressing this button again will resume the audio
output.
Press NEXT or PREVIOUS button once during play to skip a
chapter (DVD) or a track (CD) ahead or backwards.
RAPID ADVANCE/REVERSE
STOP PLAYBACK
SLOW-MOTION PLAY (DVD)
SEARCH FOR PREFERRED SCENE
PROGRAM PLAY (UP TO 16 MEMORIES)
ON SCREEN DISPLAY INFORMATION
During playback, press and hold F.FWD button or F. BWD
button several times to scan the disc forward or backward at
X2, X4, X8, X20 normal speed.
Press PLAY button to resume normal play.
Press STOP button during playback to stop playback; the
player activates its resume function when STOP is pressed in
STOP mode; press PLAY button again, playback resumes at
the point it stopped previously; open the disc tray or press the
STOP button one more time to clear the resume function.
Press and hold ZOOM/SLOW button on the remote control
during playback, the disc will be played at 1/ 2 normal speed
at first, each time this button is pressed, the play speed
becomes slower (down to 1/7 normal speed.)
Press PLAY/PAUSE button, normal play will resume.
Press REPEAT button during play, it will repeat play one
chapter/title or repeat all (for DVD disc), or repeat play a track
or all tracks (CD), or repeat the specified points (A-B).
1. Press SEARCH button during play and highlight the item to
be played (Title, Chapter, or Chapter time)by navigation
buttons.
2. Input the desired number or time via the numeric buttons.
3. Press OK Button to confirm and the playback from the
located scene starts.
4. To exit search menu, press SEARCH button directly.
1. Press PROGRAM during playback to display the program
menu.
2. Select location(s) to be memorized via navigation buttons
and then enter desired Titles/Chapters numbers via
numeric buttons.
: Inputting leading zero is not necessary. If the
chapter/title/track number is behind the cardinal 10, press
the unit digital key first and then another unit digit. Some
figure inputs may be useless, because it 's greater figure
than total title/chapter/track number on the disc.
Example: Track 3, press "3"
Track 12, press "1" and then "2"
Track 21, press "2" and then "1"
3. To start programmed playback, select PLAY on the menu, and
then press OK Button to start program playback;
Press PROGRAM button again to exit programming.
4. To clear all items, select the <CLEAR> on the menu, and then
press OK Button to confirm.
5. To change programmed items, scroll the Navigation button to
the item to be changed and enter the desired track number on
the screen, the selected item will be changed.
6. You can also cancel program mode by clearing all the items in
the program menu.
Press the ZOOM/SLOW key continuously to zoom in the picture
by 2, 3, and 4 times, zoom out by 1/2, 1/3, 1/4 normal size.
Press this key once more when the picture is at 1/4 size to return
to the normal size display.
Scroll to view the enlarged picture using Navigation buttons.
When the player is in operation, press DISPLAY button
continuously on the remote control, the screen will display parts
of information(current disc type, title number, chapter number,
playtime, audio language, audio type, subtitle language and
multi angle, etc) in a sequence.
REPEAT
Note
ZOOM PLAY

3
5.
6.
EXTERNAL MEMORY MEDIA OPERATION (USB&SD/MMC
CARD)
Prepare the player for External Memory media operation
PICTURE ZOOM IN/OUT
SLIDE SHOW TRANSITION MODES
COLOR AND BRIGHTNESS ADJUSTMENT (FOR THE LCD
SCREEN)
Press ZOOM/SLOW button continuously, the picture zooms in
by 2, 3, 4 times or zooms out by 1/2, 1/3, 1/4 the original size.
Press this button once more when the picture getting 1/4 size to
return to the normal play.
If the picture is enlarged, you may use the navigation buttons to
view blocked parts of the picture.
During slide show playback, press the PROGRAM button
cyclically to select one of the modes to play.
Press the SCREEN ON/OFF&BRI/COL button repeatedly to
enter the picture adjustment mode, and press the NAVIGATION
LEFT/RIGHT buttons to adjust. Press and hold this button to turn
on or turn off the LCD screen.
1. Make sure the power is connected; slide the FUNCTION
switch to DVD/USB/CARD position, POWER indicator will
light.
2. Insert a USB data traveller filled with Audio/video files into
the USB port or insert a SD/MMC card filled with
audio/video files into SD/MMC Card Slot, the USB or Card
is successfully detected and read after a few seconds, at
the same time, the TV screen will show all its folders.
3. You may play the files stored in the storage media much in
the same way as you do the MP3 disc.
4. Press USB/CARD button on the remote control or press
and hold the STOP/USB/SD/MMC CARD button on the
main unit to switch among disc, USB data traveller and card
by pressing Navigation up/down button on the remote or
skip up/down button on the main unit, then press
PLAY/PAUSE to begin playback.
CHANGING AUDIO SOUNDTRACK LANGUAGE (DVD)
MULTI-ANGLE VIEWING (DVD ONLY)
CHANGING SUBTITLE LANGUAGE (DVD ONLY)
MP3/MPEG 4 PLAYBACK
KODAK PICTURE CD / JPEG CD PLAYBACK
KODAK PICTURE CD / JPEG CD OPERATIONS
1. PLAY MODES
SKIP TO NEXT/PREVIOUS PICTURE
PICTURE ROTATIONS
PICTURE FLIPS
It is possible to change the audio soundtrack language to a
different language from the one selected at the initial settings
(This operation works only with discs on which multiple audio
soundtrack languages are recorded).
Press AUDIO button during DVD disc play, the sound track
language changes with the current sound track number shown
on the TV screen.
NOTE: When no soundtrack languages are recorded, pressing
this button will not work.
Press and hold ANGLE button during playback to display the
number of angles being played and then select a desired
angle to view the scene.
only the DVDs shot with multi-angle scenes have this
function.
Press SUBTITLE button during playback, the subtitle
language shown on the screen will change as a response to
each press;
When the desired language appears, release the button to
view the subtitle in that language.
this function only works on the DVDs recorded with
multi-language subtitles.
During playback, press MENU button to return to main menu
and press TITLE button to play the title.
Load the MP3/MPEG 4 disc onto the disc tray and the TV
screen will show all its folders after a few seconds.
2. Select the folder you want by the navigation buttons and then
OK button to confirm.
3. The files in this folder are displayed and select your favourable
song via navigation buttons and press OK button to start
playback.
Press NEXT and PREVIOUS button to select track directly.
Press REPEAT button change play mode.
Slide show of Kodak Picture CD after being loaded begins
automatically;
Folders of JPEG picture CD after being loaded are displayed on
the TV screen; use the navigation buttons to select the desired
folder and then press OK Button to confirm.
The files in this folder are displayed and you can select your
favourable pictures using the up/down navigation buttons and
press OK button to start playback.
Preview of the picture will be displayed while you scroll across
the filenames.
Press repeat button during play to change the play modes.
During playback, press STOP to enter preview mode.
Press NEXT button to skip to the next picture, skip to the
previous picture via PREVIOUS button .
If no key is pressed for a few seconds, it will skip to next picture
automatically.
Press RIGHT and LEFT navigation buttons to rotate the picture
Clockwise and anti-clockwise respectively.
Press UP navigation button to flip the picture vertically.
Press DOWN navigation button to flip the picture horizontally.
Note:
Note:
RETURN TO MAIN MENU AND PLAY THE TITLE (DVD)
2.
3.
4.
1.
4.
5. INITIAL SETTINGS
Initial settings page is for you to make your preferred settings
up for your player. Once the initial settings are done they are
retained in the CPU of the player until otherwise modified.
1. Press SETUP button.
2. Use the navigation buttons to select the item you want to
modify, setting page with further setting items displayed
shows on the TV screen. Again use up/down navigation
buttons to select the item to be changed, press navigation
right button to enter further setting options, then make
modifications by pressing up/down navigation button and
OK Button.
3. Use navigation buttons to switch to another setting on the
main setting page.
4. Press SETUP button to exit main setting page.
COMMON PROCEDURES FOR INITIAL SETTINGS
1. SYSTEM SETUP
SYSTEM SETUP
TV SYSTEM
PASSWORD
RATING
DEFAULT
EXIT SETUP
TV TYPE
SCREEN SAVER
1.1 TV SYSTEM -
1.2 SCREEN SAVER-
it is used to select the TV mode.
Please select this option as per your TV set.
when the play is not in used for several
minutes, a running DVD logo will move across the TV screen
to protect the TV Screen.

4
Options: ON: screen saver is enabled
OFF: screen saver is disabled.
it is used to select the TV scan mode, please set
as per your TV set.
Options: Normal Pan & scan mode
Normal Letter box mode
16:9 wide screen mode
- input password to unlock the system.
The steps are as follows:
1.4.1 Enter SYSTEM SETUP, select the PASSWORD item by
scrolling the down navigation button, and then press the
right navigation button to select the input box.
1.4.2 Input user's password "0000" to unlock it, in this case,
select the input box again to change the password by
inputing another new four numeric numbers and then
press OK button to confirm. When the password is
changed, you are needed to input the new one to unlock
the system.
1.4.3 Once you forget your own password, use the supervisor's
password "8200" to unlock it.
Set the rating of this player. If you want to change
the rating of parental lock, please input the password to unlock
first.
Options: 1 KID SAFE / 2 G / 3 PG / 4 PG 13 / 5 PG-R / 6 R /
7 NC-17 / 8ADULT
Reset to factory settings.
Options: RESTORE
1.3 TV TYPE-
4:3PS :
4:3LB :
16:9 :
1.4 PASSWORD
1.5 RATING -
1.6 DEFAULT -
LANGUAGE SETUP
OSD LANGUAGE
AUDIO LANG
SUBTITLE LANG
MENU LANG
EXIT SETUP
2.1 OSD LANGUAGE -
2.2 AUDIO LANG -
It is used to select different On Screen
Display language for different user.
select preferred audio language.
(DVD only, need disc software support)
2.3 SUBTITLE LANG -
2.4 MENU LANG -
Select preferred subtitle language.
(DVD only, need disc software support)
Select preferred disc menu language.
(DVD only, need disc software support)
2. LANGUAGE SETUP
3. VIDEO SETUP
VIDEO SETUP
BRIGHTNESS
CONTRAST
HUE
SATURATION
EXIT SETUP
4. SPEAKER SETUP
4.1 DOWNMIX
Options: Left/Right mix mode.
Select this (Option) for stereo mode.
LT/RT -
STEREO -
3.1 BRIGHTNESS - to set the brightness for the display.
Options: 0/2/4/6/8/10/12
Options:
3.2 CONTRAST -
3.3 HUE -
3.4 SATURATION -
to set the contrast effect for display.
0/2/4/6/8/10/12
to set the colour impression for display.
Options: -6/-4/-2/0/+2/+4/+6
to set the saturation level for display.
Options: 0/2/4/6/8/10/12
SPEAKER SETUP
DOWNMIX
EXIT SETUP
RADIO OPERATION
TO PLAY THE RADIO
NOTES:
1. Slide the FUNCTION switch to the RADIO position, the
POWER Indicator will light up.
2. Select the desired band with the BAND switch.
3. Tune to the desired station by rotating the TUNING control
(Move the control back and forth until you get the strongest
clearest sound).
4. The built-in AM antenna and external FM TELESCOPIC
ANTENNA are directional.
When receiving an FM broadcast, fully extend the
TELESCOPIC ANTENNA and position for the best
reception.
For AM broadcasts, rotate the whole set until the best
reception is heard.
5. Adjust the volume level to a comfortable listening level.
6. To turn off the radio,
If a particular FM (STEREO) station is weak, or you hear
too much background noise, try moving the position of
the band selector switch to the FM (MONO) position.
This can often result in a much clearer reception.
When the band selector switch is set to FM STEREO
and a stereo broadcast is being received, the FM
STEREO indicator on the top of the unit will be lit.
·
·
·
·
press POWER ON/OFF button on the
rear of the unit.
STEREO HEADPHONE JACK
MIC AND MIC LEVEL CONTROL
AUDIO IN
A stereo headphone jack has been provided on the top of the
unit so that you can listen to the unit without disturbing others. To
use this jack, plug in the headphones/earphones (not included)
and adjust the VOLUME control to a comfortable listening level.
Connect the Microphone to MIC jack. Then adjust the MIC
volume to proper level that you want. (Only works in DVD and
USB modes)
Your player can be used as a power amplifier to playback the
programs from portable radio, TV set or MP3 player or
whatever provided this appliance is so designed that audio
signal may be produced through a LINE-OUT jack or the like.
Observe the following steps to connect the player to another
appliance:
1. Power the player on using the supplied AC Power Cord.
2. Slide Function Switch to AUDIO IN position.
3. Connect the appliance into the player's AUDIO in socket
with the supplied LINE OUT cable of the appliance.
4. Power on the appliance and begin play.
Easy job, right? At this time you will be able to hear the sound
produced from the programs the connected appliance is
broadcasting.
NOTE: When external headphones/earphones are connected,
the sound to the unit's main speakers will be muted.
Caution: Listening at high power for a long moment could
damage users' ears.








Hold the disc by the edge so the surface will not be soiled with finger prints. Finger prints, dirt and scratches can
cause skipping and distortion.
Do not write on the label side with a ball-point pen or other writing utensils.
Do not apply benzine, thinner, and liquid that prevents against static electricity.
Be careful not to drop or bend the disc.
Install only one disc on the disc tray.
Do not try to close the disc tray when the disc is not in stalled properly.
Be sure to store the disc in its case when not in use.
DISC HANDLING PRECAUTIONS
5
TROUBLESHOOTING
If your DVD player does not seem to be functioning properly, check the items below before you contact an authorized service center.
Symptom Check
Make sure the AC cord is securely plugged into both AC outlet and the AC socket of this player.
Turn the power off and then back on.
Check that the battery is inserted in the "+' and "-" direction properly.
The batteries may be flat. Replace them with new ones.
Check that the signal transmission is directed at the remote control sensor on the DVD player.
Remove the obstacle between the remote controller and remote control sensor.
Check that the A/V cables are securely connected.
Check that the disc is a DVD (region number 1 or all), DVD-RW or AUDIO CD.
Do not use a disc that has scratches or dirt.
Check that the label-side of the disc is facing up.
The pick-up lens of the DVD player may be dirty. Contact the service center for lens cleaning.
Check that the TV channel is set to VIDEO or AV if viewing with a TV.
Power does not turn on or
suddenly turns off.
Remote control won't work
No picture or sound
Check image brightness and contrast settings.
Check the volume setting. If set to zero, turn up volume level.
Check that the headphones are plugged into the PHONES socket.
Speakers cannot be used with the headphones.
Check that the batteries are properly installed and AC cord is properly connected.
Use a disc without scratches or dents.
No sound
No picture and sound
Distorted video or sound
Image is unclear or distorted Check the direction, position and connection of the antenna.
No image or image is black
and white
Adjust color settings.
Check color settings.
WWW.MPMANEUROPE.COM
