USER’S MANUAL
DVD MICRO SYSTEM
XR-DV30
Please read this User Manual carefully before using this product and keep this
manual for future reference.

IMPORTANT – SAFETY INFORMATION
1. Read Instructions
All the safety and operating instructions should be read
before the product is operated.
2. Retain Instructions
The safety and operating instructions should be
retained for future reference.
3. Heed Warnings
All warnings on the product and in the operating
instructions should be adhered to.
4. Follow Instructions
All operating instructions should be followed.
5. Cleaning
Unplug this product from the wall outlet before cleaning.
Do not use liquid cleaners or aerosol cleaners. Use a
damp cloth for cleaning.
6. Attachments
Do not use attachments not recommended by the
product manufacture as they may cause hazards.
7. Water and Moisture
Do not use this product near water for example, near a
bathtub, wash bowl, kitchen sink, or laundry tub; in a
wet basement; or near a swimming pool; and the like.
8. Accessories
Do not place this product on an unstable cart, stand,
tripod, bracket, or table. The product may fall, causing
serious injury to a child or adult, and serious damage to
the product. Use only with a cart, stand, tripod, bracket,
or table recommended by the manufacturer, or should
follow the manufacturer’s instructions, and should use
a mounting accessory recommended by the
manufacturer.
9. Portable Cart Warning
A product and cart combination should be moved with
care. Quick stop, excessive force, and uneven surface
may cause the product and cart combination to
overturn.
(Symbol provided by RETAC)
10. Ventilation
Slots and openings in the cabinet are provided for
ventilation and to ensure reliable operation of the
product and to protect it from overheating, and these
openings must not be blocked or covered. The
openings should never be blocked by placing the
product on a bed, sofa, rug, or other similar surface.
This product should not be placed in a built-in
installation such as a bookcase or rack unless proper
ventilation is provided or the manufacturer’s
instructions have been adhered to.
11. Power Sources
This product should be operated only from the type of
power source indicated on the marking label. If you are
not sure of the type of power supply to your home,
consult your product dealer or local power company.
For products intended to operate from battery power or
other sources, refer to the operating instructions.
12. Grounding or Polarization
This product may be equipped with a polarized
alternating current line plug (a plug having one blade
wider than the other). This plug will fit into the power
outlet only one way. This is a safety feature. If you are
unable to insert the plug fully into the outlet, try
reversing the plug. If the plug should still fail to fit,
contact your electrician to replace your obsolete outlet.
Do not defeat the safety purpose of the polarized plug.
13. Power Cord Protection
Power supply cords should be routed so that they are
not likely to be walked on or pinched by items placed
upon or against them, paying particular attention to
cords at plugs, convenience receptacles, and the point
where they exit from the product.

Important Safety Instructions
14. Outdoor Antenna Grounding
If an outside antenna or cable system is connected to
the product, be sure the antenna or cable system is
grounded so as to provide some protection against
voltage surges and built-up static charges. Article 810
of the National Electrical Code, ANSI/NFPA 70,
provides information with regard to proper grounding of
the mast and supporting structure, grounding of the
lead-in wire to an antenna discharge unit, size of
grounding conductors, location of antenna discharge
unit, connection to grounding electrodes, and
requirements for the grounding electrode. See figure
below.
15. Lightning
For added protection for this product during a lightning
storm, or when it is left unattended and unused for long
periods of time, unplug of from the wall outlet and
disconnect the antenna or cable system. This will
prevent damage to the product due to lightning and
power lines surges.
16. Power Lines
An outside antenna system should not be located in the
vicinity of overhead power lines or other electric light or
power circuits, or where it can fall into such power lines
or circuits. When installing an outside antenna system,
extreme care should be taken to keep from touching
such power lines or circuits as contact with them might
be fatal.
17. Overloading
Do not overload wall outlets, extension cords, or
integral convenience receptacles, as this can result in a
risk of fire or electric shock.
18. Object and Liquid Entry
Never push objects of any kind into this product
through openings as they may touch dangerous
voltage points or short-out parts that could result in a
fire or electric shock. Never spill liquid of any kind on
the product.
19. Servicing
Do not attempt to service this product yourself as
opening or removing covers may expose you to
dangerous voltage or other hazards. Refer all servicing
to qualified service personnel.
20. Damage Requiring Service
Unplug this product from the wall outlet and refer
servicing to qualified service personnel under the
following conditions:
A) When the power-supply cord or plug is damaged,
B) If liquid has been spilled, or objects have fallen into
the product,
C) If the product has been exposed to rain or water,
D) If the product does not operate normally by following
the operating instructions. Adjust only those controls
that are covered by the operating instructions as an
improper adjustment of other controls may result in
damage and will often require extensive work by a
qualified technician to restore the product to its normal
operation,
A
NTENNA
LEAD-IN
WIRE
GROUND
CLAMP
A
NTENNA
DISCHARGE
UNIT (NEC
SECTION 810-20) E) If the product has been dropped or damaged in any
way,
F) When the product exhibits a distinct change in
performance this indicates a need for service.
21. Wall or Ceiling Mounting
The product should be mounted to a wall or ceiling only
as recommended by the manufacture.
22. Heat
The product should be situated away from heat
sources such as radiators, heat registers, stoves, or
other products (including amplifiers) that produce heat.
NEC – NATIONAL ELECTRICAL CODE
GROUND
CLAMPS
ELECTRIC
SERVICE
EQUIPMENT GROUNDING CONDUCTORS
(NEC SECTION 810-21)
POWER SERVICE GROUNDING
ELECTRODE SYSTEM
(NEC ART 250, PART H)

Safety Precautions
THE LIGHTNING FLASH WITH
ARROWHEAD SYMBOL WITHINAN
EQUILATERAL TRIANGLE IS INTENDED
TOALERT THE USER TO THE
PRESENCE OF UNINSULATED
“DANGEROUS VOLTAGE” WITHIN THE
UNIT’S CABINET THAT MAY BE OF
SUFFICIENT MAGNITUDE TO
CONSTITUTE A RISK OF ELECTRIC
SHOCK TO PERSONS.
THE EXCLAMATION POINT WITHINAN
EQUILATERAL TRIANGLE IS INTENDED
TOALERT THE USER TO THE
PRESENCE OF IMPORTANT
OPERATING AND MAINTENANCE
(SERVICING) INSTRUCTIONS IN THE
MANUALACCOMPANYING THE UNIT.
THE MAINS PLUG USED AS THE
DISCONNECT DEVICE, THE
DISCONNECT DEVICE SHALL REMAIN
READILY OPERABLE.
THE APPARATUS SHALL NOT BE
EXPOSED TO DRIPPING OR
SPLASHING AND THAT NO OBJECTS
FILLED WITH LIQUIDS, SUCH AS
VASES, SHALL BE PLACED THE
APPARATUS.
THE APPLIANCE COUPLER IS USED AS
THE DISCONNECT DEVICE, THE
DISCONNECT DEVICE SHALL REMAIN
READILY OPERABLE.
ALWAYS REMEMBER TO REMOVE THE
PLUG FROM THE MAINS SOCKET
BEFORE DISCONNECTING THE
POWER LEAD FROM THE BACK OF
THE UNIT.
WARNING:
TO PREVENT FIRE OR ELECTRIC SHOCK, DO NOT
EXPOSE THE UNIT TO RAIN OR MOISTURE.
NEVER ATTEMPT TO OPEN THE CABINET,
DANGEROUS HIGH VOLTAGES ARE PRESENTED
IN THE UNIT. REFER SERVICING TO QUALIFIED
SERVICE PERSONNEL.
CAUTION:
TO PREVENT ELECTRIC SHOCK, MATCH WIDE –
BLADE PLUG WITH WIDE SLOT AND FULLY
INSERT.
THE APPARATUS SHALL NOT BE EXPOSED TO
WATER AND NO OBJECTS FILLED WITH LIQUID
SUCH AS VASES SHALL BE PLACED ON THE
APPARATUS.
CAUTION:
THE UNIT EMPLOYS A LASER SYSTEM. TO
ENSURE THE PROPER USE OF THE UNIT, READ
THIS MANUAL CAREFULLYAND KEEP IT FOR
FUTURE REFERENCE.
IF THE UNIT REQUIRES SERVICING, CONTACT THE
SELLER OR SEE “TROUBLESHOOTING”.
TO PREVENT DIRECT EXPOSURE TO THE LASER
RADIATION, DO NOT OPEN THE CABINET. VISIBLE
LASER MAY RADIATE WHEN THE CABINET IS
OPENED OR THE INTERLOCKS ARE DEFEATED.
DO NOT STARE INTO THE LASER BEAMS.
CAUTION:
THE DVD VIDEO PLAYER IS A CLASS 1 LASER
PRODUCT. USE OF CONTROLS OR ADJUSTMENTS
OR PERFORMANCE OF PROCEDURES OTHER
THAN THOSE SPECIFIED HEREIN MAY RESULT IN
HAZARDOUS RADIATION EXPOSURE.
AS THE LASER BEAM USED IN THIS DVD VIDEO
PLAYER IS HARMFUL TO THE EYES, DO NOT
ATTEMPT TO DISASSEMBLE THE CABINET.
REFER SERVICING TO QUALIFIED PERSONNEL
ONLY.
WARNING:
FCC REGULATIONS STATE THATANY CHANGE OR
MODIFICATION TO THE EQUIPMENT, NOT
EXPRESSLY APPROVED BY MAKER OR ITS
AUTHORIZED PARTIES, COULD VOID USER’S
AUTHORITY TO OPERATE THIS EQUIPMENT.
This symbol indicates that this product incorporates double insulation between hazardous mains
voltage and user accessible parts. When servicing use only identical replacement parts.
WARNING: To reduce the risk of fire ore electric shock, do not expose this apparatus to rain or
cords.
EN-1

TABLE OF CONTENTS
Safety Precautions ................................…….. 1
Table of Contents ....................................…… 2
About Your DVD Player ..........................….. 3
Front and Back panels .......................……….. 4
Front Panel.................................................…..4
Back Panel...................................................... 5
Remote Control .......................................….. 6
Operating the remote control.....................….. 7
Connections................................….... 8 9 10 11
Connecting power supply ..................…....... 12
Basic DVD operation ....................….. 13 14 15
Playing the radio...................................……. 16
MPEG4/ MP3 PLAYBACK........................…. 17
FUNCTION OF USB.................................…. 18
CD RIPPING FUNCTION ...........................
18
SYSTEM Setup.....................18 19 20 21 22 23
LANGUAGE Setup ............…................. 24 25
AUDIO SETUP.................................………. 26
VIDEO SETUP .................................….. 27 28
SPEAKER Setup ..............................……. 29
DIGITAL Setup ...................................…….. 30
Trouble shooting...................................….... 31
Technical specifications .........................….. 32
EN-2

ABOUT YOUR DVD PLAYER
Disc formats supported by this player:
MPEG4 files on discs
Dolby Digital
KODAK picture CD
MP3 files on CD-R/CD-RW
DVD video
Multi-angle
Subtitle choices
Audio choices
TV Aspect Ratio modes
Parental Lock
You can help protect the environment!
Please remember to respect the local regulations: hand in the non-working
electrical equipments to an appropriate waste disposal center.
This product incorporates copyright protection technology that is protected by method claims of certain U.S.
patents and other intellectual property rights owned by Macrovision Corporation and other rights owners.
Use of this copyright protection technology must be authorized by Macrovision Corporation, and is
intendedfor home and other limited viewing uses only unless otherwise authorized by Macrovision
Corporation. Reverse engineering or disassembly is prohibited.
The product complies with the KODAK Picture CD format and will display KODAK Picture CDs. The "KODAK Picture
CD Compatible" logo is a trademark of Eastman Kodak Company and is used with permission.
Manufactured under license from Dolby Laboratories. "Dolby" and the double-D symbol are trademarks of Dolby
Laboratories. Confidential Unpublished Works. C 1992-1997 Dolby Laboratories, Inc.All rights reserved.
EN-3

FRONT AND BACK PANELS
Front Panel Functions
1. PHONE
2. VOLUME
Use this button to control the unit's volume. It
controls 2 channels simultaneously.
3. OPEN/CLOSE
Use this button to open and close the disc tray
while in DVD mode.
4. PLAY/PAUSE
Use this button to begin play function while in
DVD mode. Use this button to pause play function
while in DVD mode.
5. PREV
While in the DVD status, you may press this
button for previous track.
6. NEXT
While in the DVD status, you may press this
button for next track.
7. INPUT SIGNAL SOURCE
Use this button to select the proper input signal
source. (Note: The selected input will correspond
to the selected input terminal on the rear panel.)
8. POWER
9. USB CONNECT
Use only USB Memory Device
EN-4

FRONT AND BACK PANELS
Back Panel Functions
1. FRONT/MAIN
Use to connect the four terminals of the left and
right front or main speakers.
2. AUX INPUT
Use to connect input for auxiliary music source.
3. LINE OUT
4. COAXIAL DIGITAL AUDIO OUTPUT
5. COMPONENT VIDEOS OUTPUT
(Y, Cr/Pr, Cb/Pb)
6. VIDEO OUTPUT
7. S-VIDEO OUTPUT
8. SCART IN/OUT
9. ANTENNA
Use to connect the provided indoor FM and AM
loop antennas.
10. 100 – 240 ~ 50/60Hz
This unit comes with an AC power cord. Be sure
its prongs are dry before plugging it into an
electrical outlet. Take caution not to overextend
the cord or walk on it.
EN-5

REMOTE CONTROLLER
1 MUTE
2 AUX
3 SCART
4 0-9 NUMBER KEYS
5 SETUP
6 PRE/TUN
7 SCROLL UP
8 SCROLL RIGHT
9 AUTO
10 STOP
11 PLAY
12 CH- CH+
13 FWD
14 REV BUTTON
15 A-B
16 SLOW
17 DISPLAY
18 MENU (PBC)
19 ANGLE
20 LANGUAGE
21 VIDEO
22 R/L
23 RDS
24 OPEN/CLOSE
25 DVD
26 TUNER
27 FM MODE
28 SCROLL LEFT
29 ENTER
30 SCROLL DOWN
31 MEMO
32 PAUSE/STEP
33 VOL- VOL+
34 PREV BUTTON
35 NEXT BUTTON
36 ZOOM
37 PROG
38 GOTO
39 TITLE
40 SUBTITLE
41 N/P
42 RESUME
43 REPEAT
44 RETURN
EN-6

OPERATING THE REMOTE CONTROL
1. Push down and out on the battery
Compartment cover to remove it.
2. Insert the two "AAA" batteries into the battery
compartment of the remote control, making
sure the + and - signs on the batteries and
inside the batteries compartment match up.
3. Replace the battery compartment cover.
Notes:
zDo not mix batteries from different
manufacturers, nor old ones with new.
zIf the remote control will not be used for an
extended period of time, remove the batteries
to prevent damage-causing corrosion.
zRemove dead batteries immediately to
prevent damage-causing corrosion.
zIf battery leakage occurs, wipe the battery
liquid from the battery compartment, then
replace both batteries.
zAlways replace both batteries at the same
time, using new, fully charged batteries.
zLife expectancy of batteries may vary
depending on amount of use.
Point the remote control at the remote sensor.
(The pictures below are for reference only.)
Notes:
zPoint the remote control directly at the
player's remote sensor.
zDo not leave the remote control in an
extremely hot or humid place.
zDo not spill water or put anything wet on
the remote control.
zBattery life is ~1 year under normal
conditions.
Notes:
Battery Installation
zDo not direct the remote sensor toward any
light source, such as direct sunlight or a
strong fluorescent light, as it may cause the
unit to not operate correctly.
zWhen other remote controls are used nearby
or when the remote is used near equipment
using infrared rays, interference may occur.
zPlacing an object on the remote control may
cause it to inadvertently depress a button,
changing a function and shortening battery
life.
zDo not glaze the front of the DVD receiver
with colored glass, as it may cause
interference with normal operation of the
controller.
zMake sure there is no barrier between the
remote control and remote sensor, as it could
prevent the unit from receiving the signal.
zDo not spill water or put wet items on the
remote control.
zNever disassemble remote control.
Using the Remote Control
EN-7

CONNECTING DEVICES
Connections
Connecting the System
It is recommended that you turn off all components (or unplug AC power) while you are connecting the
system.
1 – Connect TV
Composite Video
Connect the video cable from the Video Out jack on the back panel of the DVD system to your
television’s Video In jack.
S-Video
For better video quality, you can connect the system to your TV with a S-Video cable (not
included).
Connect the S-Video cable from the S-Video Out jack on the back panel of the system to your
television’s S-Video In jack.
SCART Video
You can connect the system to your TV with a scart cable. Set the [Video Type] to [TV-RGB].
Y/Pb/Pr
Use the COMPONENT Cable (not supplied) to connect DVD system to your TV. Set the [Video
Type] to [YUV]. If the TV set supports P-Scan function, you can set [Video Type] to [Y, Pb, Pr].
2 – Place Speakers
For the best result, arrange the 2 speakers as shown in your listening area:
Front Speakers (L, R)
Align the front speakers at ear level and at a horizontal angle of 45 degrees to the primary
listening area.
1. TV set or screen
2. Front or main left speaker 3. Front or main right speaker 4. Viewer’s location
EN-8

CONNECTING DEVICES
3 – Connect Speakers
1) Make sure the power is turned off to prevent possible damage to the system.
2) Connect the speakers’ wires to the connectors on the back panel of the DVD system.
3) To insert a speaker wire, press down the thumb levers, fully insert each tip of the wire into its
connector, and then release the thumb levers to lock the wire in place.
CAUTION – To prevent damage to circuits, do not short-circuit the positive and negative speaker
output jacks. Make sure the exposed tips of each speaker wire are separated to the distance that
they cannot touch each other after they are inserted into the connectors.
- Do not connect any other speakers or devices that are not included with this system.
Main speaker Main speaker
EN-9

CONNECTING DEVICES
4 – Connect AM Loop Antenna
1) Assemble the supplied AM loop antenna by rotating the base and snapping it into place.
2) Connect the two wires from the AM loop antenna to the AM antenna connector on the back
panel.
Press down the thumb levers to insert each wire, and then release the thumb levers to lock the
wires in place.
- To prevent noise pickup, keep the AM loop antenna away from the system and other
components.
5 – Connect FM Wire Antenna
1) Connect the supplied FM wire antenna to the FM antenna connector on the back panel.
2) Be sure to fully extend the FM wire antenna. Make use of the small loop at the free end of the
antenna to maintain its position.
3) If noise or interference occurs, use an external antenna with a 75 ohm coaxial cable (not
included).
Outdoor AM antenna
EN-10

CONNECTING DEVICES
Coaxial Cable (75 ohm)
Coaxial Cable (75 ohm)
Outdoor FM antenna
6 – Connect External Audio
The back panel of the DVD system provides.
1 AUX IN
Connect to an external stereo audio input.
2 Line Out
Connect to the inputs of external Audio System.
3 COAXIAL Out
Connect to an external audio decoder.
EN-11

CONNECTING POWER SUPPLY
POWER
Before plugging the power cord into the AC outlet, check to make sure all of the connections have been
properly completed. When they have been, carefully plug power cord into outlet.
Press the POWER button on the front panel to power the unit. The display panel will light.
When the unit is initially powered, a brief surge of electricity may cause interference with other electronic
equipment on the same circuit. If this occurs, connect the unit to an outlet on a different circuit.
EN-12

BASIC DVD OPERATION
Chapter 1 Basic Operation
1. Turn On the TV and Your DVD Receiver
Press the Power button on the player or the remote controller, and “Read” appears on the TV screen. If there
hasn’t a disc in the DVD player, “No disc” will be displayed on both the screen and the VFD.
2. Place A Disc
Press the Open/Close button on the remote controller or the front of the DVD player, and “Open” appears on
the screen. Then place a disc gently into the tray with the disc’s label facing up (double-sided discs have
content on both sides, so you can place either side up), and press the Open/Close button again to close the
disc tray. “Close” appears and the player stars to read. Then the disc starts playing automatically.
(Note: Of some certain type discs, after reading out the type, the Play or Enter button should be pressed to
start playing.)
3. Play
The contents of each disc menu vary according to how the disc was authored and what features are included.
The disc menu will be turned on for you to select, when Menu button pressed. Also play and pause can be
switched with the Pause button on the remote. Moreover, such as menu play, title play, sequence play etc.,
these different play modes are offered.
a) Menu Play (compatible with DVD, SVCD, VCD2.0 discs)
I. Press Menu button
zTV screen displays the DVD Rood Menu when a DVD disc is loaded.
zPBC is initialized on when a SVCD or VCD2.0 disc is loaded.
II. When a DVD disc is loaded, you can press Arrow buttons to highlight the menu item you want to choose;
III. Press Enter or Play button, you can begin play with the highlighted.
IV. Return when playing: When a DVD disc is playing, press Menu (PBC) button, and you can return to
Rood Menu; As SVCD, VCD2.0, and PBC is on, press Return button, you can return to the menu.
V. Stop
1) Press STOP once during playback to stop and hold playback.
2) Press PLAY to resume playback from the point you pressed STOP.
3) Press STOP twice to stop playback completely.
For the disc protection, before you press Open/Close button to eject the disc tray when playing, please press
Stop button at first. After taking out the disc,
zPress Open/Close again to close the tray.
zIf you’re going to use the DVD player for a long time, be sure to remove the electronic plug.
EN-13

BASIC DVD OPERATION
b) Title Play (compatible DVD discs only)
I. During DVD playback, press Title button to display the DVD title content.
II. Press the Arrow buttons to highlight the title you want to choose, and press Enter; Also you can press
numeric buttons to choose.
III. The DVD player begins with the chapter 1 of the chosen titile.
c) Sequence Play
I. When a SVCD or VCD disc is loaded and MENU(PBC) is on, once MENU(PBC) button pressed,
MENU(PBC) button switches off. Then the player can play in sequence playback mode; when MENU(PBC)
button pressed twice, MENU(PBC) switches on.
II. Except for SVCD or VCD discs, in the stop state, when press Play button, the player then enters
sequence playback mode. This feature is effective to all the compatible discs.
d) Program Play
The Program Playback option allows you to enter the order in which you want chapters or tracks to play,
maximum to 16.
zProgram Menu
DVD, MP3, JPEG discs:
EN-14

BASIC DVD OPERATION
SVCD, VCD, CD discs:
* If PBC is on, this operation will turn PBC off while the chapters / tracks plays in programmed order.
zAccording to the highlight, use the Numeric buttons to enter the chapters / tracks in the order you want
them to play. Then press Play or use Arrow buttons to highlight the “PLAY” item and press Enter. The
chapters / tracks will play in the programmed order.
* You can program maximum 16 titles / chapters / tracks.
zAccording to the Direction Indicator on the menu, you can press Arrow buttons to highlight where you
want to enter.
zDuring Program Playback, if Program button pressed, the programmed order and the contents will be
displayed on the screen, and the Program Playback will be stopped; Also you can press Stop and Play
to resume normal playback.
zNotes:
* To clear the programmed order, use Arrow buttons to highlight the “CLEAR” item, then press Enter.
* To modify the programmed order, use Arrow buttons to highlight the modifying item and enter the new
chapter / track you want to program directly.
1. Press any function button (Tuner Scart,AUX)
to select the desired sound source.
The appropriate symbol will appear in the
display.
2. When the AM/FM tuner button is pressed,
the last station listened to will play.
The volume may be adjusted by either turning
the large volume knob on the front panel or
using the appropriate volume button on the
remote control.
Pressing the MUTE button temporarily mutes
every speaker. To resume audio, press MUTE
button again.
Selecting Sound Source Volume Control
Mute
EN-15

PLAYING THE RADIO
Tuner button
Number button
1. Press TUNER button to select desired wave band
(AM or FM).
2. Press CH+ or CH- button to find a station. The
frequency will change with each press. When a
station's signal is received, it will appear in the
display.
3. To lock onto a station quickly, hold the CH+ or CH-
button for two seconds. The unit will start
automatic tuning. When a station is found,
automatic tuning stops.
4. To listen a frequency-known station, you can input
the station frequency directly by pressing the
number keys one by one in tune state.
5. To add a station to memory, press the MEMO
button. The memory storage number will blink for
four seconds in the display. Press MEMO again to
store the station.
6. To reduce noise when an FM-stereo program has
been received, press the FM mode button. The
word STEREO will disappear from the display.
The program is now heard in monographic form,
reducing the noise. To resume stereo play, press
the FM mode button again.
This unit will store up to total 50 AM or FM radio
stations in its memory.
1. Press the AUTO/SCAN button. The automatic
tuning mode is activated.
2. Stations will be stored in ascending order until 50
stations of that particular wave band have been
saved. When a station is stored, the memory
storage number, as well as the station's frequency,
will flash for four seconds in the display.
3.When the total number of stations reaches 50, in a
particular wave's (AM or FM) memory, no further
station in that wave band will be saved.
1. To play preset stations
2. Press the PRESET/TUN button.
3. Press any of the numbered buttons to select the
desired station's memory number. For example, to
play the station at memory #5, simply press the 5
button; for memory #17, press the 1 button
followed by the 7 button.
4. Stations in the memory function may also be
accessed by pressing the CH- or CH+ button.
If there is “RDS” radio station in your area, when you
tune on that radio, you can choose different kind of
“RDS” information by pressing “RDS” key on the
Remote Control.
Basic Operations Automatic Tuning
Press the TUNER button to select the desired wave band
Memor
y
Numbe
r
Wave band Station frequency
RDS Function
EN-16

MPEG4/MP3 PLAYBACK
When a MPEG4 and a Mp3 disc is loaded, the screen will display as follows:
Current MP3/JPEG file
name. If a JPEG file is
playing, the name should
have a JPEG extension.
Current
directory
name
File Switch Region: Displays
the file type of the playing
and the switching.
The playing file
is a MP3 audio
file.
The playing file is a
JPEG picture file.
Current Mp4 file name.
If a JPEG file is playing,
the name should have a
JPEG extension.
Current
directory
name
File Switch Region: Displays
the file type of the playing
and the switching.
The playing file
is a MP3 audio
file. The playing file is a
JPEG picture file.
Press to select the file when the cursor appears in the file window.
Press enter to play the current file selected by the cursor.
Press to switch between the directory window and the file window.
Note: The player will not function correctly under the following condition:
1. The disc is badly scratched, damaged or dirty.
2. The disc is not finalized.
3. The recording format is not supported by the player.
EN-17
