M+D JS-MD 1C 2017 Technical specifications

JS-MD 1C Aircraft Flight Manual MD01-AFM-00-001
Issue: 02
Rev. 00 Rev. Date: 14.09.2017 Page i
JS-MD 1C AIRCRAFT FLIGHT MANUAL
Type: JS-MD Single
Model: JS-MD 1C
Serial number:
Registration Number:
Document number: MD01-AFM-00-001
Title: JS-MD 1C Aircraft Flight Manual
Issue 02
Date of issue: 14 September 2017
Responsible for content:
Issue 02 of this JS-MD 1C Aircraft Flight Manual is approved under the
authority of APDOA EASA.AP175.
Sections 2, 3, 4, and 5.2 are approved by the EASA through
EASA.A.616.
Copyright ©:
M&D Flugzeugbau GmbH & Co.KG
Streeker Straße 5b

D-26446 Friedeburg
-All rights reserved-
Digital unterschrieben von Sören
Pedersen
Datum: 2017.09.18 16:55:13 +02'00'

JS-MD 1C Aircraft Flight Manual MD01-AFM-00-001
Issue: 02
Rev. 00 Rev. Date: 14.09.2017 Page ii
Intentionally left blank

JS-MD 1C Aircraft Flight Manual MD01-AFM-00-001
Issue: 02
Rev. 00 Rev. Date: 14.09.2017 Page 0–1
0. Document Management
0.1 List of Issues
Issue Date Reason for Change
01 15.05.2017 Initial Issue
02 14.09.2017
Editorial Changes,
Section 2.13 (Placard
Placement adjusted)

JS-MD 1C Aircraft Flight Manual MD01-AFM-00-001
Issue: 02
Rev. 00 Rev. Date: 14.09.2017 Page 0–2
0.2 List of effective sections
Section Revision Date Number
of Pages Reference
0 00 14.09.2017
6
1 00 14.09.2017
6
2 00 14.09.2017
18
3 00 14.09.2017
14
4 00 14.09.2017
32
5 00 14.09.2017
8
6 00 14.09.2017
14
7 00 14.09.2017
28
8 00 14.09.2017
10
9 00 14.09.2017
2
10 00 14.09.2017
2
11 00 14.09.2017
1

JS-MD 1C Aircraft Flight Manual MD01-AFM-00-001
Issue: 02
Rev. 00 Rev. Date: 14.09.2017 Page 0–3
0.3 Record of Amendments
Date of Issue/
Revision
Date of
Insertion Signature

JS-MD 1C Aircraft Flight Manual MD01-AFM-00-001
Issue: 02
Rev. 00 Rev. Date: 14.09.2017 Page 0–4
0.4 Table of contents
JS-MD 1C AIRCRAFT FLIGHT MANUAL............................................i
0. Document Management .........................................................0–1
0.1 Record of Revision ......Fehler! Textmarke nicht definiert.
0.2 List of effective sections .................................................0–2
0.3 Record of Amendments..................................................0–3
0.4 Table of contents ............................................................0–4
1. General.....................................................................................1–1
1.1 Introduction .....................................................................1–1
1.2 Certification basis ...........................................................1–2
1.3 Warnings, cautions and notes ........................................1–2
1.4 Descriptive data..............................................................1–3
1.5 Technical data ................................................................1–4
1.6 Three-view drawings ......................................................1–5
2. Limitations...............................................................................2–1
2.1 Introduction .....................................................................2–1
2.2 Airspeed limits ................................................................2–2
2.3 Airspeed indicator marking.............................................2–4
2.4 Mass ...............................................................................2–5
2.5 Centre of gravity .............................................................2–6
2.6 Approved manoeuvres ...................................................2–8
2.7 Flight load factor limits....................................................2–9
2.8 Flight crew ....................................................................2–10
2.9 Types of operation........................................................2–11
2.10 Minimum equipment list................................................2–12
2.11 Aerotow and winch launching.......................................2–13
2.12 Other limitations............................................................2–14
2.13 Limitations placards......................................................2–17
3. Emergency procedures..........................................................3–1
3.1 Introduction .....................................................................3–1
3.2 Canopy jettison...............................................................3–1
3.3 Bailing out.......................................................................3–2
3.4 Stall recovery..................................................................3–3
3.5 Spin recovery..................................................................3–4

JS-MD 1C Aircraft Flight Manual MD01-AFM-00-001
Issue: 02
Rev. 00 Rev. Date: 14.09.2017 Page 0–5
3.6 Spiral dive recovery ........................................................3–4
3.7 Excessive sideslip recovery............................................3–6
3.8 Electrical fire ...................................................................3–7
3.9 Land as soon as possible. ..............................................3–7
3.10 Other emergencies .........................................................3–8
4. Normal operating procedures ...............................................4–1
4.1 Introduction .....................................................................4–1
4.2 Rigging and de-rigging ...................................................4–2
4.3 Daily inspection ..............................................................4–8
4.4 Pre-flight check.............................................................4–13
4.5 Normal procedures and recommended speeds ...........4–14
5. Performance ............................................................................5–1
5.1 Introduction .....................................................................5–1
5.2 Approved data ................................................................5–1
5.3 Non-approved information..............................................5–5
6. Weight and balance .................................................................6-1
6.1 Introduction ......................................................................6-1
6.2 Weight and balance record..............................................6-1
6.3 Permitted payload-range and CG envelope....................6-3
6.4 Optimisation of centre of gravity......................................6-9
7. System description..................................................................7-1
7.1 Introduction ......................................................................7-1
7.2 Cockpit controls ...............................................................7-2
7.4 Instrument panel..............................................................7-8
7.5 Microphone and antenna.................................................7-9
7.6 Landing gear system .....................................................7-10
7.7 Seats and safety harness ..............................................7-11
7.8 Pitot and static system...................................................7-13
7.9 Airbrake system .............................................................7-15
7.10 Baggage Compartment .................................................7-17
7.11 Water ballast system .....................................................7-18
7.12 Electrical system............................................................7-20
7.13 Miscellaneous equipment..............................................7-23
8. Handling and maintenance .....................................................8-1
8.1 Aircraft inspection periods ...............................................8-2

JS-MD 1C Aircraft Flight Manual MD01-AFM-00-001
Issue: 02
Rev. 00 Rev. Date: 14.09.2017 Page 0–6
8.2 Ground handling ..............................................................8-3
8.3 Cleaning and care ...........................................................8-5
8.4 Long-term storage ...........................................................8-9
9. Supplements ............................................................................9-1
9.1 Introduction ......................................................................9-1
9.2 List of ancillary equipment ...............................................9-1
10. Service Bulletins ....................................................................10-1
11. STCs and Minor Change Approvals.....................................11-1

JS-MD 1C Aircraft Flight Manual MD01-AFM-00-001
Issue: 02
Rev. 00 Rev. Date: 14.09.2017 Page 1–1
1. General
1.1 Introduction
This Flight Manual has been prepared to provide pilots and instructors
with all the information required for safe and efficient operation of the
JS-MD 1C. All the data that is required by the Airworthiness
Requirement CS-22 to furnish the pilot is contained in this manual. It
also contains supplementary data supplied by the sailplane
manufacturer.
The JS-MD 1C is a high-performance sailplane and not a trainer. Even
though it possesses excellent performance and handling qualities, it
can only be flown by a skilled pilot who complies with the limitations and
recommendations set out in this manual.

JS-MD 1C Aircraft Flight Manual MD01-AFM-00-001
Issue: 02
Rev. 00 Rev. Date: 14.09.2017 Page 1–2
1.2 Certification basis
This aircraft, with production designation (type) JS-MD Single (model
JS-MD 1C) has been approved by the European Aviation Safety
Agency (EASA) in accordance with CS-22 including Amendment AMC
22.1555 (a), AMC 22.1585 (f).
The category of airworthiness is U (Utility).
1.3 Warnings, cautions and notes
The following definitions apply to warnings, cautions and notes used in
this Flight Manual.
WARNING: means that the non-observation of the corresponding
procedure leads to an immediate or important
degradation of the flight safety.
CAUTION: means that the non-observation of the corresponding
procedure leads to a minor or to a longer term
degradation of the flight safety.
NOTE: draws the attention on any special item not directly
related to safety but which is important or unusual.

JS-MD 1C Aircraft Flight Manual MD01-AFM-00-001
Issue: 02
Rev. 00 Rev. Date: 14.09.2017 Page 1–3
1.4 Descriptive data
The JS-MD 1C is a high-performance single-seat sailplane of a
conventional layout with a T-tail. Two wingspan configurations (18 m
and 21 m) can be selected, both feature full-span flaperons.
The cockpit is designed to protect the pilot in the event of a crash.
Safety features include a crumple zone in the forward structure. The
wing structure consists of spar caps made of carbon fibre rovings and
skins of carbon fibre fabric. The wings are attached to each other with
a tongue and fork type spare connection, secured with two main pins.
The airbrakes are a triple blade design on the upper surface of the wing.
Boundary layer control is achieved on the main wing bottom surfaces,
the horizontal stabilizer and vertical fin. All control surface hinge gaps
are sealed with Mylar strips and Teflon-coated tape.
The water ballast system consists of two main tanks, each integral to a
wing and holding approximately 90 litres of water, and two trim tanks in
the vertical fin. The tail ballast tanks consist of an expendable tank of
approximately 7.5 litres and a non-expendable tank of approximately 5
litres. The 21 m wing tips also feature integral tanks, with a capacity of
approximately 17 litres each. The landing gear consists of a 5 inch
retractable sprung main landing gear with a fixed tail wheel.
All controls are automatically connected during rigging.

JS-MD 1C Aircraft Flight Manual MD01-AFM-00-001
Issue: 02
Rev. 00 Rev. Date: 14.09.2017 Page 1–4
1.5 Technical data
Geometry JS-MD 1C 18 m JS-MD 1C 21 m
Wing Span 18 m / 59.06 ft 21 m/ 68.88 ft
Wing Area 11.19 m² /
120.45 ft
2
12.25 m² /
131.86 ft
2
Aspect Ratio 28.8 35.9
Fuselage Length 7.052 m / 23.14 ft
Fuselage Height 1.32 m / 4.33 ft
Weight JS-MD 1C 18 m JS-MD 1C 21 m
Empty Weight without
Engine 310 kg / 683 lbs 330 kg / 728 lbs
Maximum Weight 600 kg / 1323
lbs
720 kg / 1587
lbs
Wing Loading (min) (70 kg
pilot)
34.1 kg/m² /
6.98 lb/ft
2
32.6 kg/m² /
6.68 lb/ft
2
Wing Loading (max) 53.6 kg/m²
10.98 lb/ft
2
58.7 kg/m²
12.02 lb/ft
2
Glide performance JS-MD 1C 18 m JS-MD 1C 21 m
Best Glide Ratio 53 60
Best Glide Speed at
MAUW
Flap Setting 4 (9° - 13.5°)
120 km/h
65 kts
Best Glide Speed at 450 kg
Flap Setting 4 (9° - 13.5°)
100 km/h
54 kts
Minimum Sink Rate at
empty weight
0.5 m/s
100 ft/min
0.48 m/s
95 ft/min
Table 1.5
.0
-
1

JS-MD 1C Aircraft Flight Manual MD01-AFM-00-001
Issue: 02
Rev. 00 Rev. Date: 14.09.2017 Page 1–5
1.6 Three-view drawings
JS-MD 1C 18 m
Figure 1.6.1-1

JS-MD 1C Aircraft Flight Manual MD01-AFM-00-001
Issue: 02
Rev. 00 Rev. Date: 14.09.2017 Page 1–6
JS-MD 1C 21 m
Figure 1.6.2-1

JS-MD 1C Aircraft Flight Manual MD01-AFM-00-001
Issue: 02
Rev. 00 Rev. Date: 14.09.2017 Page 2–1
2. Limitations
2.1 Introduction
Section 2 includes operating limitations, instrument markings, and
basic placards necessary for safe operation of the aircraft, standard
systems and standard equipment.
The limitations included in this section and the limitations under
Section 9 have been approved by EASA.

JS-MD 1C Aircraft Flight Manual MD01-AFM-00-001
Issue: 02
Rev. 00 Rev. Date: 14.09.2017 Page 2–2
2.2 Airspeed limits
Speed limitations and their operational significance are illustrated in
Table 2.2.0-1.
Speed IAS Remarks
18 m 21 m
V
NE
Never exceed
speed
270 km/h
146 kts
Do not exceed this speed in
any operation and do not use
more than 1/3 of control
deflection
V
RA
Rough air speed 203 km/h
110 kts
Do not exceed this speed
except in smooth air, and then
only with caution. Examples of
rough air are lee wave rotor,
thunderclouds etc.
V
A
Manoeuvring
speed
203 km/h
110 kts
Do not make full or abrupt
control movement above this
speed, because under certain
conditions the sailplane may
be overstressed by full control
movement.
V
FE
Maximum flap
extended speed
See
Table 2.2.0-2
Do not exceed these speeds
with the given flap setting.
V
W
Maximum winch
launching speed
150 km/h
81 kts
140 km/h
76 kts
Do not exceed this speed
during winch or auto tow
launching
V
T
Maximum aerotow
speed
180 km/h
97 kts
Do not exceed this speed
during aerotow.
V
lo
Maximum
landing
gear operating
speed
180 km/h
97 kts
Do not extend or retract the
landing gear above this speed.
Table 2.2.0-1
The following table shows the maximum allowable airspeed for each
flap setting:

JS-MD 1C Aircraft Flight Manual MD01-AFM-00-001
Issue: 02
Rev. 00 Rev. Date: 14.09.2017 Page 2–3
Flap
setting
Deflection
(°)
V
FE
18 m 21 m
1 -3° 270 km/h
146 kts
2 +0°
3 +5° 230 km/h / 124 kts
4 +13.5° 165 km/h / 89 kts
5 +16.6° 165 km/h / 89 kts
L +20° 160 km/h / 86 kts
Table 2.2.0-2
The maximum allowable airspeeds for each flap setting are indicated
on the airspeed indicator (ASI) with white triangles next to the flap
position number, as indicated in Fig. 2.2.0-1 (ASI in km/h) and Fig.
2.2.0- 2 (ASI in knots).
Figure 2.2.0-1 Figure 2.2.0-2

JS-MD 1C Aircraft Flight Manual MD01-AFM-00-001
Issue: 02
Rev. 00 Rev. Date: 14.09.2017 Page 2–4
2.3 Airspeed indicator marking
The airspeed indicator markings and their colour code significance are
given in Table 2.3.0-1:
Marking IAS Significance
18 m 21 m
White Arc 98 to 160 km/h
53 to 86 kts
Positive Flap Operating Range. (Lower limit is 1.1
V
S01
in landing configuration at maximum weight.
Upper limit is maximum speed permissible with
flaps extended positive)
Green Arc 103 to 203 km/h
56 to 110 kts
Normal Operating Range. (Lower limit is 1.1V
S12
at
maximum weight and most forward c. g. with flaps
neutral. Upper limit is rough air speed.)
Yellow Arc 203 to 270 km/h
110 to 146 kts
Manoeuvres must be conducted with caution and
only in smooth air.
Red Line _
270 km/h
146 kts
Maximum speed limit for all operations.
Blue line
_
Refer to Engine Operating
Instructions Section 2.3
Best rate of climb speed V
Y
(if engine is fitted)
Yellow
Triangle
101 km/h
55 kts
Approach speed at maximum weight without water
ballast.
Table 2.3.0-1
1
V
SO
is defined as the stall speed at maximum weight, in the landing configuration, with
the CG in the most unfavourable position
2
V
S1
is defined as the stall speed at maximum weight, in a specific selected configuration,
with the CG in the most unfavourable position
