MR. RESISTOR TVDMA868A01 User manual

DOC.: T559.03
TVDMAxxxA01-A02 DATE: 07/10/16
110-230V~DIMMER WITH BUILT-IN RADIO RECEIVER
AND DALI OUTPUT FOR CONTROL BALLASTS AND
LAMPS. Push-button input for manual controls.
Product code
TVDMA868A01 ≤ 20 slaves, 868.3Mhz TVDMA868A02 ≤ 64 slaves, 868.3Mhz
TVDMA916A01 ≤ 20 slaves, 916Mhz TVDMA916A02 ≤ 64 slaves, 916Mhz
165 mm
Hole for fixing with screw (under the cover) Flat surface mounting
70 mm
185 mm
IT - Foro per il fissaggio con vite (sotto lo sportello)
EN - Hole for fixing with screw (under the cover)
FR - Trou pour fixation avec vis (sous le couvercle)
DE - Loch für die Montage mit Schraube (unter dem Deckel)
IT - Montaggio su superficie piana
EN - Flat surface mounting
FR - Fixation sur surface plate
DE - Montage auf ebene Oberfläche
74 mm (50 mm)
56 mm
151 mm
47 mm
40 mm
Mounting
Led 1
P1
P2
P3 Led 2
Led 3
Led 4
L
L
N
N
DA1
DA1
DA2
DA2
230V~
IN
230V~
OUT
DALI IN
DALI OUT
5 4 3 2 1
DIP
J1
J2
T3
Remove J1 and J2 if an external DALI power supply is used!
*
*
Push-button input for manual controls. It’s possible to connect in parallel
more than one push-button.
= ON/OFF
< 0,5 s = DIMMER
ꜛ ꜜ
> 0,5 s
MR RESISTOR

2
L
L
N
N
DA1
DA2
230V~ DALI OUT
DIP
J1
J2
T3
L
L
N
N
DA1
DA1
DA2
DA2
DALI IN
DALI OUT
DIP
J1
J2
T3
SLAVE 1 SLAVE 2
ON
1 2 3 4 5
230V~
ON
1 2 3 4 5
DALI GROUP SLAVE SLAVE
DALI
POWER SUPPLY
UNIT
...
SLAVE SLAVE
DALI GROUP
DALI GROUP
Wirings
TVDMAxxxA01 ≤ 20 slaves
TVDMAxxxA02 ≤ 64 slaves
BROADCAST
DALI GROUP (0..15)
DIP1..5 = OFF
DIP5 = ON
GROUP DIP1 DIP2 DIP3 DIP4
0 OFF OFF OFF OFF
1 OFF OFF OFF ON
2 OFF OFF ON OFF
3 OFF OFF ON ON
4 OFF ON OFF OFF
5 OFF ON OFF ON
6 OFF ON ON OFF
7 OFF ON ON ON
GROUP DIP1 DIP2 DIP3 DIP4
8 ON OFF OFF OFF
9 ON OFF OFF ON
10 ON OFF ON OFF
11 ON OFF ON ON
12 ON ON OFF OFF
13 ON ON OFF ON
14 ON ON ON OFF
15 ON ON ON ON
To test the led wiring: P1
ON/OFF
< 1s
DIMMER
ꜛ ꜜ
> 1s
Remove J1 and J2 if an external DALI power supply is used!

3
Activation/deactivation of the memory of the last light intensity value
1.1
Assigning a GROUP to the connected SLAVE devices
1.2 P2+P3
( 3 s)
P1+P3
Activation
LED4 OFF
Deactivation
Press the buttons P1 and P3 at the same time.
P3
+
P1
LED4 ON
=ON
100%
=last value
ON
Restoring DALI default values of the SLAVES
1.3
Press P2 and P3 simultaneously twice and hold them the second time for 3 s.
CONFIGURED
DEFAULT VALUE
Press the buttons P2 and P3 at the same time.
P3
+
P2
LED4 ON (1 s)
P3
P2
GROUP LED1 LED2 LED3 LED4
0 OFF OFF OFF OFF
1 OFF OFF OFF ON
2 OFF OFF ON OFF
3 OFF OFF ON ON
4 OFF ON OFF OFF
5 OFF ON OFF ON
6 OFF ON ON OFF
7 OFF ON ON ON
GROUP LED1 LED2 LED3 LED4
8 ON OFF OFF OFF
9 ON OFF OFF ON
10 ON OFF ON OFF
11 ON OFF ON ON
12 ON ON OFF OFF
13 ON ON OFF ON
14 ON ON ON OFF
15 ON ON ON ON = default
LED 1 2 3 4
P3
P3
+
P2
( 3s)
P3
+
P2
P2+P3
POWER ON LEVEL: 0
MINIMUM LEVEL: 85 (1%)
MAXIMUM LEVEL: 254 (100%)
FADE TIME: 1
FADE RATE: 1
SYSTEM FAILURE LEVEL: 254 (100%)
DALI OUT
ON 1 s

4
Wireless command devices
7/42 channels transmitter
OFF
100%
75%
50%
Min.
DIM +
DIM -
CH1
CH2
CH3
CH4
CH5
CH6
CH7
OFF
100%
75%
50%
Min.
DIM +
DIM -
CH1
CH2
CH3
CH4
CH5
CH6
CH7 ON/OFF
DIM +
DIM -
CH5
CH6
CH7
3/6/18 channels transmitter
ON/OFF
DIM +
DIM -
CH5
CH6
CH7
CH5
CH6
CH7
CH5
CH6
CH7 ON/OFF
DIM +
DIM -
ON/OFF
DIM +
DIM -
Green Mouse
Transmitter with integrated light sensor
See the product’s instructions for details.
2
Single command channel with function ON, OFF or ON/OFF/DIM

5
*The buzzer will make a beep each press.
TYPE OF MEMORIZATION
(see description p.4)
7channels *
x1
Press the button of the
transmitter relative to the code to
memorize.
1 button: *
x2
1 button with function ON *
x3
1 button with function OFF *
x4
3channels *
x5
Green Mouse *
x6
...
keep it pressed
continuous sound
intermittent sound
ON/OFF
< 1 s
DIMMER
ꜛ ꜜ
> 1 s
P2
2.1 Radio codes memorization

6
2.2 Radio codes deletion
TYPE OF DELETION P3
Single radio code *
x1 Press the button of the transmitter relative to the code to delete.
All the radio codes *
x2
...
keep it pressed
continuous sound
intermittent sound
(10 s)
P3
If any transmitter with modified light values is used in the remote memorization (3.1), the added transmitter will have the same modified values.
Modification of the preset light values of a 7/42 channel transmitter
2.3
CH1
CH2
CH3
CH4
CH5
CH6
CH7
21 CH1
CH2
CH3
CH4
CH5
CH6
CH7
CH1
CH2
CH3
CH4
CH5
CH6
CH7
3
( 5 s)
LED
OFF
LED
ON
continuous sound
1. Press the button relative to the value to modify (CH1..CH4). 2. Adjust the value with buttons CH5 and CH6. 3. Press CH7 and keep it pressed for 5s.
The buzzer will make a beep each press.

7
Press the button P3 of the memorized transmitter. Press the button relative
to a memorized code. Press the button relative to the new code.
1 s< 5 s
continuous sound intermittent sound
...
P3
memorized memorized
< 5 s
continuous sound new
P3 button is located inside the
transmitter. The added radio code will
have the same functions of the code
used for the memorization. This
procedure is compatible with any type
of transmitter.
P3 button is located inside the transmitter.
Press three times the button P3 of the memorized transmitter. Press the button relative to the code to delete.
x 3
1 s
continuous sound intermittent sound
...
P3
memorized
< 5 s
continuous sound
3.1 Remote memorization of further radio codes
3.2 Remote deletion of a radio code

8
SCENES programming
Example -
7/42 c.
OFF 100%
2
address
3
5
OFFOFF50% 100%
1 42
address
OFF25% 75%
2 54
address
OFF OFF
1 32
100%
address
Setting the address of the receiver (1..20) P1+P2
Press the buttons P1 and P2 at the same time.
9
10
11
12
13
14
1
2
3
4
5
6
7
8
9
10
11
12
13
14
1
2
3
4
9
10
11
12
13
14
1
2
3
4
9
10
11
12
13
14
1
2
3
4
9
10
11
12
13
14
1
2
3
4
9
10
11
12
13
14
1
2
3
4
ID:
1..20
LED2
Units
The flashing of LED2 and LED3 shows the address.
address
Press P3 as many times as the address to assign. Confirm with P1.
. . .
*LED1 turns off each press.
P3
4
CH1
CH2
CH3
CH4 4
scene
CH1
CH2
CH3
CH4
3
scene
CH1
CH2
CH3
CH4 2
scene
CH1
CH2
CH3
CH4 1
scene
P2
+
P1
P3 P1
continuous sound
*
Tens
LED3
LED1 ON

9
Modification of the preset light values of a 7/42 channel transmitter memorized in more than one receiver
Press the button CH1, CH2, CH3 or CH4 and keep it pressed 5 s.
Press CH7 for memorizing. In order to modify
further scenes, repeat the steps 2..5, otherwise...
Select the receiver with CH5 or CH6. The selected dimmer will have the load OFF.
address
+
-
Press the button relative to the value to modify (CH1..CH4). Adjust the value with CH5 and CH6, or press the same button (CH1..CH4) for OFF or UNAFFECTED.
intensity
or
1time
times
2
Exit by CH7
1CH1
CH2
CH3
CH4
CH5
CH6
CH7
( 5 s)
OUT
OFF
OUT
ON
continuous sound
2CH1
CH2
CH3
CH4
CH5
CH6
CH7 OK!
RECEIVER
y
x
. . . OUT
OFF . . .
z
3CH1
CH2
CH3
CH4
CH5
CH6
CH7
RECEIVER
y
x
. . .
OUT
OFF
. . .
z
OUT
ON +
-
4CH1
CH2
CH3
CH4
CH5
CH6
CH7
CH1
CH2
CH3
CH4
CH5
CH6
CH7
OUT
OFF
5CH1
CH2
CH3
CH4
CH5
CH6
CH7
6CH1
CH2
CH3
CH4
CH5
CH6
CH7
OUT
OFF

10
WARNING: READ CAREFULLY THIS INSTRUCTIONS BEFORE INSTALLING
AND COMMISSIONING THE PRODUCT. SAVE THESE INSTRUCTIONS FOR FUTURE
REFERENCE.
PRODUCT INSTALLATION
The product at issue must be installed,
commissioned and maintained only by licensed
and authorised people, respecting the laws
concerning the electrical installations. Not
conforming installations, wrong adjustments or
product alterations may cause fire, electric shock,
or personal injuries. The manufacturer is not
responsible for any damage due to wrong
installation or improper use.
ELECTRICAL CONNECTIONS
All the connections must be rated for a single-
phase 110-230Vac power supply, with the
relative Earth connection. For the disconnection from
the power line, use an all-pole switch with
contacts having a dimension of at least
3,5mm. Arrange all the necessary safety
devices and use only materials complying with
the standard of electrical installations. The cable
must have a section properly rated according to the
load connected. Attention: If any cable is
damaged, it must be immediately replaced by
a qualified person in order to avoid any
hazard. manufacturer reserves the right for
changing technical data and features without prior
notice.
SAFETY INFORMATION
Do not operate in the high voltage area of the electronic
board, when it is supplied. Use the product only in
combination with devices which can guarantee a safe
extended time functioning. The radio signal reception of
the device could be disturbed by the presence of
electrical disturbances being transmitted by other
appliances working on the same frequency or if the
product is somehow shielded by metal parts.
PRODUCT DISPOSAL
At the end of this product’s useful life, it must not be
disposed of as domestic waste, but must be taken to a
collection centre for waste electrical and electronic
equipment. It is the user’s responsibility to dispose of this
appliance through the appropriate channels at the end of
its useful life. Failure to do so may incur the penalties
established by laws governing waste disposal.
Hereby automation s.r.l. declares that the product
complies with the essential requirements and other
relevant provisions, established by the Directive
1999/5/EC. In the view of a constant
development of their products, the
manufacturer reserves the right for changing
technical data and features without prior notice.

Technical specifications
Power supply 110-230V~
Max. DALI BUS output power
22V - 80mA = 20 SLAVES
(TVDMAxxxA01)
22V - 250mA = 64 SLAVES
(TVDMAxxxA02)
The connection cables must have a section suitable to the maximum load applied to the output (≥
1mm², ≤ 300m), and to the additional devices connected to the input (≤ 100m).
Protection rating IP20
Operating temperature range -20°C / +50°C
Reception frequency 868.3 MHz (TVDMA868A0x)
916 MHz (TVDMA916A0x)
Radio memory capability (transmitters) 42
This manual suits for next models
3
Table of contents
Popular Controllers manuals by other brands

Omega Engineering
Omega Engineering WB-31 user guide

Brooks
Brooks Granville-Phillips Convectron 316 Series instruction manual

Fireye
Fireye SB Series manual

VigilLink
VigilLink VL-IPC265-1 user manual

YASKAWA
YASKAWA SGDV series user manual

RADEMACHER
RADEMACHER DuoFern 9433-1 Translation of the original Installation and Commissioning Manual
